Selec RPS60-24-CE User manual

Doc. name: OP INST RPS60-24-CE OP907-V02(Page 1 of 2)
WIRING INSTRUCTIONS
1. To prevent risk of electric shock, power supply equipment must be
kept OFF while wiring.
2. Terminals and electrically charged parts must not be touched when
the power is ON.
3. Wiring shall be done strictly according to terminal layout provided
in the operating manual.
43*109.8*102.7mm (W*H*D)
285 gms
DIMENSIONAL DIAGRAM
DIMENSION
WEIGHT
OP907-V02
INPUT SPECIFICATIONS
100 - 240VAC
INPUT VOLTAGE RANGE
AC CURRENT(TYP.)
1.2A @ 115VAC; 0.8A @ 230VAC
EFFICIENCY(TYP.)
>87% @ 230VAC
INRUSH CURRENT(TYP.)
<4 Amps; Measured at 264VAC,
25 C Ambient, Cold Start
8
0
Power supply shuts down when the temperature of PCB
below main transformer reaches typically 120 C; Turns
on only after the temperature falls below 90 C typically
and AC power is recycled there after .
0
0
PROTECTIONS
OUTPUT OVER VOLTAGE
OVER TEMPERATURE
110% to 140% of rated output current
Protection type : Hiccup mode; recovers
automatically after fault condition is removed.
31 VDC
Protection type :
.5 ± 1VDC
Latched; Input AC power
has to be recycled to recover the power supply.
2A - 250VAC Internal
Hiccup mode when output is shorted; Recovers
automatically after fault condition is removed.
INPUT FUSED
OUTPUT SHORT CIRCUIT
OUTPUT OVER LOAD
Ø
Ø
Ø
Ø
AC 100-240V Wide-range Input.
Cost optimized without compromising quality or reliability.
Full power between -25 C and +50 .
Compact size.
00
C
FEATURES
ALTITUDE
2000m
5 to 95% RH, Non Condensing
ENVIRONMENT
STORAGE TEMPERATURE
-40 C to +85 C.
00
-25 C to +70 C
*De-rate output power at W/ C above +50 C Ambient.
00
00
1.5
OPERATING TEMPERATURE
HUMIDITY
SPECIFICATION
selec
WIRING DIAGRAM
FREQUENCY RANGE
50-60Hz
INTENDED USE
This device is designed for installation in an enclosure and is intended for the
general professional use such as in
ndustrial control communication .
Do not use this power supply in equipment where malfunction may cause
severe personal injury or threaten human life.
instrumentation equipment, office,
i and
SAFETY INSTRUCTION
PE (Protective
Earth) Input
102.7
109.80
4.90
43
OUTPUT SPECIFICATIONS
≥≥60ms at 230VAC & 15ms at 115VAC, Full Load
HOLD UP TIME
24 - 28VDC
<1% of Vout
2.5A at 24V; 2.14A at 28V
OUTPUT VOLTAGE
OUTPUT CURRENT
RIPPLE AND NOISE
LINE AND LOAD REGULATION
±1%
Possible for up to two power supplies
(with external diode)
SERIES OPERATION
START UP TIME
1 Sec@ 230VAC & <3 Sec@115VAC, Full Load
<
DC ON
LN
RPS60-24-CE
60W
INPUT
24VDC 2.5A
OUTPUT
LN
RPS60-24-CE
60W
DC ON
Vo ADJ.
100 - 240VAC ; 50/60Hz
INPUT
24VDC 2.5A
OUTPUT
+
-
±10% ; 127 - 370VDC
EMS IMMUNITY
Compliance to IEC61000-4-4,5,11
EN55022 ; Class A
RADIATED EMISSION
EN55022 ; Class A
CONDUCTED EMISSION
DIELECTRIC WITHSTAND
VOLTAGE
I/P to Earth : 2500VAC
I/P to O/P : 4000VAC
O/P to Earth : 1500VAC
100 M min. (between all outputs and all inputs/
terminals) at 500 VDCPE
INSULATION RESISTANCE
Ω
SAFETY & EMC
Designed to meet IEC 62368-1
SAFETY STANDARDS
Processing for UL-508
RPS60-24-CE
Operating Instruction

Attention:(Fig. 1)
Mounting:(Fig.2)
Removal:(Fig.3)
1. Do not block the ventilation holes of power supply.
2. Keep at least 20mm clearance around the switching power supply.
3. The Equipment should not be installed in environmental conditions other than
those specified in this manual.
1. Slightly tilt the unit to engage on the top side of Din Rail mounting.
2. Press it downward until it gets locked in Din Rail.
1. Before removing power supply unit from Din Rail ensure that supply has been
switched off.
2. Unscrew all the wire connections of power supply unit.
3. Insert a screw driver into the mounting clamp slot & pull it down to remove the
power supply from Din Rail.
Doc. name: OP INST RPS60-24-CE OP907-V02(Page 2 of 2)
OUTPUT
INPUT
Fig. 1Fig. 1
Fig. 2
Fig. 3
This power supply is not field serviceable product. In case of failure or
malfunction, send back the power supply to factory.
Please contact service center for repair on the following numbers:
(Specifications are subject to change, since development is a
continuous process.)
Tel. No. : [phone];
Email : [email protected]
NO WARRANTY ON UNIT DAMAGED DUE TO WRONG CONNECTION OF
POWER SUPPLY.
Factory Address :
91-22-28476443 / 1882
I
EL-27/1, Electronic Zone, TTC Industrial Area,
MIDC, Mahape, Navi Mumbai - 400 710, INDIA.
Tel. No. : +
Fax No. : [phone] I Toll free : 1800 227 353
Website: www.selec.com Email: [email protected]
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONSMEANING OF PRODUCT SAFETY SYMBOL
SERVICE DETAILS
3. Make sure mains power supply is off before wiring the power
supply unit. Make sure of correct wiring. Incorrect wiring may
cause electrical shock or damage.
4. Do not touch the power supply during operation or immediately
after turning off because some parts get hot or are at high
voltage which may cause burns or electrical shock.
5. Do not install the power supply where human body may come into
contact while power is supplied to the power supply.
6.
1. Do not use the power supply without proper grounding (Protective
Earth).
2. Do not use in wet locations or in areas where moisture or
condensation can be expected.
Do not repair the power supply at user end . Modification or
repairing of the power supply by users may cause electrical
shocks, damage, & other accidents.
7. If damage or malfunction occurs during operation,
immediately turn off mains power.
WARNING : Risk of electrical shock, fire, personal injury or death.
Minor burns may occasionally occur. Do not touch the
product while power is being supplied or immediately
after power is turned OFF.
CAUTION
Minor injury due to electric shock may occasionally occur.
Do not touch the terminals while power is being supplied.
If the external breaker or fuse is tripped, the equipment may
have been seriously damaged. Do not turn ON the input
again.
Minor electric shock, fire or product failure may occasionally
occur. Do not allow any pieces of metal or conductors or
any clippings or cuttings resulting from installation work to
enter the product.
ØThis manual is meant for personnel involved in wiring installation
operation & routine maintenance of the equipment.
Disconnect power supply of your system before starting any
installation operation or wiring.
Improper installation operation or wiring may impair safety & failure
of the unit or electrical shock or damage.
Connect the ground completely. A protective earthing terminal
stipulated in safety standards is used. Electric shock or
malfunction may occur if ground is not connected properly.
Ø
Ø
Ø
SAFETY INSTRUCTIONS
Indicates the possibility of electrical shock under
specific conditions
Indicates the possibility of injuries by high temperature
under specific condition
Indicates the instructions of unspecified general action.
