SELT Pergola SB400 User manual

TECHNICAL AND OPERATIONAL DOCUMENTATION
INSTALLATION MANUAL,
OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE
(Translated from the original manual)
5.Steel and aluminium components and structural sets
5.8. Pergola SB400
5.8
DT-E

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 2 / 64
PRODUCT NAME:
ALUMINIUM CONSTRUCTION
PERGOLA SB400
MARKING OF PRODUCT MANUFACTURER:
Manufacturer name:
SELT Sp. z o. o.
KRS 0000589791, share capital: 64 000 000 PLN
NIP: 7543103311, REGON: 363154414, BDO no 000009177
Manufacturer’s registered office:
45- 449 Opole, ul. Wschodnia 23A
Contact details:
Tel: [phone]
Website:
www.selt.com
E-mail:
[email protected]
PRODUCT SAFETY MARKING:
The product meets the CE safety requirements.
THIS TECHNICAL AND OPERATIONAL DOCUMENTATION:
Is valid from: 01 August 2023
Is applicable to the above listed product versions.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 3 / 64
TABLE OF CONTENTS
1INTRODUCTION............................................................................................................................................................ 4
1.1 SAFETY GUIDELINES FOR THE PRODUCT................................................................................................................. 4
1.2 EXPLANATION OF SYMBOLS AND SIGNS ................................................................................................................. 4
1.3 TERMS AND DEFINITIONS ....................................................................................................................................... 5
1.4 SUBJECT, INTENDED USE AND CONTENTS OF THE DOCUMENTATION................................................................... 6
2PRODUCT TECHNICAL INFORMATION.......................................................................................................................... 7
2.1 TECHNICAL PARAMETERS ....................................................................................................................................... 7
2.2 PRODUCT SPECIFICATION ....................................................................................................................................... 9
3TRANSPORT AND STORAGE OF THE PRODUCT............................................................................................................ 9
3.1 COMLETENESS AND QUALITY CONDITION OF DELIVERY ........................................................................................ 9
3.2 GENERAL CONDITIONS FOR TRANSPORT AND STORAGE OF THE PRODUCT ........................................................ 10
3.3 OBLIGATORY DESCRIPTIONS TO BE PLACED ON THE PRODUCT PACKAGING ....................................................... 10
4PRODUCT INSTALLATION........................................................................................................................................... 11
4.1 GENERAL REQUIREMENTS FOR SAFE INSTALLATION ............................................................................................ 11
4.2 REQUIREMENTS FOR SAFE INSTALLATION OF THE PRODUCT AT HEIGHTS........................................................... 11
4.3 PREPARATION FOR INSTALLATION........................................................................................................................ 11
4.4 GENERAL GUIDELINES FOR PRODUCT INSTALLATION........................................................................................... 12
4.5 INSTALLATION TOOLS ........................................................................................................................................... 13
4.6 INSTALLATION....................................................................................................................................................... 14
4.6.1 INSTALLATION OF THE STANDARD FEET................................................................................................. 19
4.6.2 INSTALLATION OF ADJUSTABLE FEET ..................................................................................................... 19
4.6.3 INSTALLATION OF THE FRAME ............................................................................................................... 20
4.6.3.1 FREE-STANDING VERSION WITH 2 GUTTERS .......................................................................................... 21
4.6.3.2 FREE-STANDING VERSION WITH 4 GUTTERS .......................................................................................... 23
4.6.3.3 WALL-MOUNTED VERSION WITH 2 GUTTERS......................................................................................... 25
4.6.3.4 WALL-MOUNTED VERSION –4 GUTTERS ............................................................................................... 27
4.6.4 MODULAR INSTALLATION ................................................................................................................................ 30
4.6.5. GUTTERS INSTALLATION .......................................................................................................................................... 31
4.6.6 INSTALLATION OF BLADES AND DRIVE UNIT.................................................................................................... 33
4.6.6.1 INSTALLATION OF THE DRIVE ................................................................................................................. 35
4.6.7 WALL INSTALLATION ........................................................................................................................................ 37
4.6.7.1 WALL INSTALLATION –CROSS BEAM...................................................................................................... 40
4.6.7.2 WALL INSTALLATION –LENGTHWISE BEAM........................................................................................... 41
4.7 FOUNDATION GUIDELINES.................................................................................................................................... 42
5SYSTEM OPERATION AND PRODUCT SAFETY............................................................................................................. 44
5.1 GENERAL REQUIREMENTS FOR OCCUPATIONAL HEALTH AND SAFETY ................................................................ 44
5.2 SAFETY REQUIREMENTS RELATED TO SPECIAL CONDITIONS AND PLACES OF PRODUCT USE.............................. 44
5.3 SPECIAL REQUIREMENTS FOR SNOW LOAD.......................................................................................................... 45
5.4 OPERATIONAL SAFETY........................................................................................................................................... 45
5.5 CONNECTION TO ELECTRICAL INSTALLATION....................................................................................................... 47
5.6 CONTROL............................................................................................................................................................... 49
5.7 START-UP AND ADJUSTMENT ............................................................................................................................... 51
5.8 MISUSE OF THE SYSTEM........................................................................................................................................ 55
6SYSTEM USE AND MAINTENANCE.............................................................................................................................. 56
6.1 USING THE PRODUCT IN ACCORDANCE WITH ITS INTENDED USE........................................................................ 56
6.2 INSTRUCTION FOR NON-PROFESSIONALS............................................................................................................. 56
6.3 INDICATIONS OF RISK, BREAKDOWN OR ACCIDENT ............................................................................................. 57
6.4. TECHNICAL INSPECTIONS AND REPAIRS........................................................................................................................ 58
7COMPLAINT / TECHNICAL DEFECTS ........................................................................................................................... 59
7.1 COMPLAINTS (MANUFACTURER’S WARRANTY) ................................................................................................... 59
7.2 TECHNICAL DEFECTS ............................................................................................................................................. 59
8PRODUCT DISASSEMBLY / UTILISATION / DISPOSAL.................................................................................................. 59
9MARKING AND LABELLING THE PRODUCT WITH THE CE MARK ................................................................................ 60
9.1 PRODUCT COMPLIANCE WITH THE CE STANDARD ............................................................................................... 60
9.2 INFORMATION ACCOMPANYING THE CE MARKING ............................................................................................. 60
10 WARRANTY EXCLUSIONS ........................................................................................................................................... 63
10.1 WARRANTY EXCLUSIONS ...................................................................................................................................... 63
APPENDIX 1 (PICOLO XL MOTOR OPERATING MANUAL) ......................................................................................................... 64
APPENDIX 2 (24V DC MOTOR OPERATING MANUAL) .............................................................................................................. 64

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 4 / 64
1INTRODUCTION
1.1 SAFETY GUIDELINES FOR THE PRODUCT
The product has been manufactured in accordance with the latest technical knowledge in the field of construction and
manufacturing and meets the safety requirements in accordance with the following standards.
No.
Subject
European Legal Basis
Polish Legal Basis
1
Execution of steel and
aluminium structures
Part 1: Requirements for
conformity assessment of
structural components
EN 1090-1:2009 +A1:2011
PN-EN 1090-1+A1:2012
2
Shutters and external venetian
blinds. Performance
requirements including safety.
EN 13659:2015
PN-EN 13659:2015
3
Construction Products
Regulation (CPR)
Regulation (EU) no 305/2011
of the European Parliament
and of the Council
Act of April 16, 2004 on building products (i.e.
Journal of Laws 2020, item 215) as amended
4
Essential requirements for the
machinery
Directive 2006/42/EC of the
European Parliament and the
Council
Regulation of the Minister of Economy of
October 21, 2008 on the essential
requirements for machines (Journal of Laws
2008 No. 199, item 1228) as amended
5
Low Voltage Directive (LVD)
Directive 2014/35/EU of the
European Parliament and the
Council
Regulation of the Minister of Development of
June 2, 2016 on the requirements for electrical
equipment (Journal of Laws of 2016, item 806)
Act of June 13, 2019 on the conformity
assessment and market surveillance system
(Journal of Laws of 2019, item 544) as
amended
6
Electromagnetic Compatibility
Directive (EMC)
Directive 2014/30/EU of the
European Parliament and the
Council
Act of April 13, 2007 on electromagnetic
compatibility (Journal of Laws of 2019, item
2388)
Act of June 13, 2019 on the conformity
assessment and market surveillance system
(Journal of Laws of 2019, item 544) as
amended
Related documents: Declaration of performance for compliance with EN 1090-1:2009 +A1:2011,
Declaration of performance for compliance with EN 13659:2015 and installation instruction, user’s manual for motors
and control.
1.2 EXPLANATION OF SYMBOLS AND SIGNS
The following symbols (pictograms) indicate particularly important threats and safety information.
Pictogram
Pictogram meaning
Information
INFORMATION
Prior to using the product, its operating manual should be read.
Following the operating manual guarantees:
- failure-free use of the product
- usage according to its intended use,
- warranty coverage against product defects.
Keep the operating manual for safety of people.
INFORMATION
No harmful or dangerous consequences for people or facilities.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 5 / 64
NOTE!
A situation likely to cause product damage or other damage.
No threat for people.
DANGER!
This symbol indicates all information concerning safety, which could pose a
hazard to human health or life in case of non-observance. The health of life
hazard. Risk: a hazard of serious personal injury or death. The hazardous
operation which could cause injuries or damages to the product.
WARNING!
Threat to human life or health due to electric shock.
DANGER!
Hand crushing threat.
WARNING!
Head injury threat.
ENVIRONMENT
Marking of electronic or electric equipment, which should be collected in the
designated points.
1.3 TERMS AND DEFINITIONS
For the purposes of this documentation the following terms and definitions shall apply:
Product: PERGOLA SB400
Pergola SB400 system is made of powder-coated aluminium profiles and stainless components. Roof framework made of
movable aluminium blades. The angle of inclination of the blades can be changed. Product design is offered in colour from
RAL colour chart after confirmation of their availability by the manufacturer.
NOTE: the set includes: two lengthwise beams (drive and bearing), two cross beams (front and rear); gutters; posts, feet,
wall brackets, LED strips (depending on the configuration), a movable roof consisting of aluminium blades, a rod with pins
and a motor.
Mobile roof:
Consists of blades fixed to cross beams with the option to change the inclination angle of the blades. Blades are moved by a
control mechanism driven by an electric motor.
Blades: Part of the product, made of extruded aluminium profiles with an aesthetic appearance. The shape of the blade
enables drainage of rainwater from the roof surface within the limits of the design assumptions (see point 2.2) and
protection against sunlight and snow load up to the limit value (see point 2.2).
VERSIONS:
Free-standing –Self-supporting structure containing single mobile roof module supported on front and rear posts.
Modular - Self-supporting structure consisting of single stand-alone modules joined together using mechanical fasteners
(screw connections).
Wall-mounted –Structure consisting of a mobile roof module supported partially on posts and fixed by a roof beam to a
supporting wall (along the rear or side edge of the roof) with the use of wall brackets.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 6 / 64
1.4 SUBJECT, INTENDED USE AND CONTENTS OF THE DOCUMENTATION
This documentation covers the products manufactured by SELT Sp. z o.o.
This documentation applies to all types of PERGOLA SB400.
User’s manual and instructions for safe use, with motor manual, should be handed over to the end user.
IMPORTANT INSTRUCTION RELATED TO SAFETY
WARNING - IT IS VERY IMPORTANT TO PROCEED ACCORDING TO THIS MANUAL
TO ENSURE PEOPLE SAFETY.
KEEP THIS MANUAL
The documentation is part of product delivery and should be permanently kept nearby all the time.
This documentation contains:
important guidelines for installation, use and maintenance of the product,
important recommendations for storage and transport,
guidelines, which observance would ensure operation of the product.
SELT Sp. z o.o. shall not be responsible for damages resulting from non-observance of the recommendations included in
this documentation.
For further improvement of the product, SELT Sp. z o.o. reserves the right to introduce changes, which, while maintaining
significant technical parameters, will be considered as appropriate for increasing the quality of product operation and
safety of use.
Copyrights for this documentation remains with SELT Sp. z o.o. with its registered office in Opole. The documentation
cannot be used, in whole or in part, for competitive purposes or made available to third parties without permission.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 7 / 64
2PRODUCT TECHNICAL INFORMATION
Technical specifications of the product are available after logging in on website www.selt.com
2.1 TECHNICAL PARAMETERS
Pergola SB400 –free-standing
Fig. 1. Pergola SB400 free-standing –Overall dimensions: B max –maximum width, L max –maximum projection, H max –
maximum frame height (3012 mm), H1 max –maximum height of the clearance, H2 max –maximum height of position of
the mechanism intended to change the angle of the blades (~3140 mm).
Pergola SB400–modular
Fig. 2. Pergola SB400 modular –Overall dimensions: B –system width, B1 max –maximum width of a single module,
L max –maximum projection, H max –maximum frame height (3012 mm), H1 max –maximum height of the clearance, H2
max –maximum height of position of the mechanism intended to change the angle of the blades (~3140 mm).

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 8 / 64
System module dimensions:
Width*
Projection*
Height*
Height in the
light*
Supporting structure
up to 4000 mm
up to 7000 mm**
up to 3140 mm*
(*-when the roof
is open)
up to 2800mm
Axial spacing of roof blades
200 mm
Difference in fastening of blade’s ends
(transverse slope –of blade axis)
Choice of: 20 mm difference (from the motor or towards the motor) or no slope
Scope of use / exploitation
Ambient temperature
(min/max)
+5 do +40°C (opening / closing of the mobile roof)
Humidity (max)
90% no steam condensation (opening / closing of the mobile roof)
Drive (type of drives):
Linear drive.
The drive can be started manually with a switch or through an external wired or
radio control receiver.
Connection to electrical installation
approximately 4 m power cord (after installation the cord should be properly
secured).
Electric drive - motor with the following parameters:
Model of the motor
ELERO Picolo XL
24C DC motor
- supply voltage
230V/50Hz AC
24 V DC
- power
126 W
24 W
- power consumption
0,55 A
1,8 A
- protection level
IP 65
IP 67
- continuous work time
up to 5 min (depending on the
ambient temperature)
up to 2 min, cooling 18 min (depending
on the ambient temperature)
- extension, axial force
max 200 mm, extension force 1200N
max. 300 mm, extension force 600N
- extension speed
approx. 6 mm/s
10,5 mm/s
- operating temperature (min/max)
-20°C to +80°C
-20°C to +60°C
LED power supply data:
LED lighting
Optional - LED gutters, LED points in blades. Power supply 24V DC, 150W, max.
6.25A, IP66 fixed in pergola’s post
Installation:
Intended use
External
Site installation
To the supporting base or to the wall (with universal wall brackets)
*- tolerances of external dimensions are +/-10 mm.
**- drilling for wall brackets in a beam with motor is possible only with a projection of more than 200 cm
Detailed data for parameters of the individual motors are available on the websites of motor manufacturers and on the
website:
www.selt.com→ OUR OFFER →ELECTRIC EQUIPMENT

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 9 / 64
2.2 PRODUCT SPECIFICATION
Products manufactured by SELT Sp. z o. o. have appropriate technical and operational parameters.
List of product types:
Free-standing,
Modular,
Installed outside the building, started by electromechanical drive connected with the control system.
They have the following features:
Roof (blades) electrically opened, designed to protect against the sun and rain (according to the parameters of the
product and its location).
Permissible outdoor use of the product in accordance with the product parameters.
Location, a method of finishing, installation and seals as well as extreme weather conditions including heavy
rainfall and/or snowfall have an essential influence on waterproofness of the product.
The movable roof blades allow to regulate the access of sunlight.
The application and use of the product should take place within the limits set by the sixth wind class (according to
EN 13659); and/or maximum snow load.
It is forbidden to start the blade rotation during snowfall or ice build-up and outside the temperature range given
in the manual and if permitted it may result in product damage or even personal injury or death.
They do not release any toxic substances during operation.
Noise emission by the product with the electro-mechanical drive (connected with the working movement of the
mobile components, generated by the electric motor during operation) is not considered as a significant threat
and is a matter of comfort.
The motors have an IP65 protection degree.
Product and drive design allows safe stop of the blades in any position in the working range and staying there in
the rest position.
Rotational motion of the blades can be started by a manual switch or by remote control.
The difference of angle of mobile roof’s blades closing may differ by 2° and it is a natural feature of the system
due to production and process tolerances of the components.
Covers of movable components have been designed and executed in a way ensuring safety for the operating
personnel provided that they are correctly operated.
Water vapour may condense on the product, especially its lower part, and water may drip or run down.
Water resistance, aesthetic water drainage through an integrated gutter and poles with drains.
Two variants possible: two lengthwise gutters without drainage or four gutters around the perimeter connected
by overflows in the corners, also without drainage.
Optional LED lighting in the gutters and/or in the blades.
Maximum drainage efficiency –rain intensity up to 0,04 l/s/m2with a maximum duration of 5,3 min (depending
on the configuration of the drainage holes). The intensity is given with no slope of the blades axis. In the case of a
difference in inclination, the efficiency is reduced and, with prolonged rainfall, it may cause the gutter to overflow
from the side of the lower blade attachment.
For pergolas will full cover of the walls, with the length of the blades over 3.5 m, there may be light reflections
and gaps at the junction of adjacent blades, resulting from technological standards.
Permitted use for protection against snowfall (up to 50 kg/m2) - as an even layer of the same height.
It is unacceptable to use ordinary silicone to seal the product. Use only Crystal Fix or equivalent sealant with
the parameters specified in point 4.4
3TRANSPORT AND STORAGE OF THE PRODUCT
3.1 COMLETENESS AND QUALITY CONDITION OF DELIVERY
Goods produced by SELT Sp. z o. o. are in accordance with their production technology. In the event of any reservations as
to the product or damage to the product packaging, the reservations or comments should be reported to the driver /
warehouseman / assembly team and marked on the WZ document under pain of losing claims in this respect, and a
protocol describing these reservations or comments should be drawn up with the driver's participation.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 10 / 64
Upon receipt, first of all, mechanical damage, scratches, cracks, etc., as well as quantitative non-conformities should be
reported, otherwise they will be considered non-existent. Hidden defects must be reported in accordance with the terms of
the guarantee or warranty.
3.2 GENERAL CONDITIONS FOR TRANSPORT AND STORAGE OF THE PRODUCT
List:
the product is factory packed in cardboard packaging protecting against damage during storage, during transport
and during relocation to the final installation location,
products for transport/storage should be set in accordance with the arrows indicated on the product packaging,
do not stack the products in more than two (2) layers because the packing material can be crushed, what in turn
may lead to permanent damage to the product,
do not load the product packaging with other objects,
products places on means of transport should be protected against relocation and damage during the transport
(e.g. with distance pieces, protecting belts etc.),
during transport the product should be protected against rain or snow,
storage locations should be dry, well-ventilated and protected against harmful impact of the weather (sun, rain,
etc.),
if product weight exceeds 25 kg its relocation to the final installation location should be carried out by at least two
persons (depending on the weight of the ordered product).
3.3 OBLIGATORY DESCRIPTIONS TO BE PLACED ON THE PRODUCT PACKAGING
Prior to installation and use of the product please read carefully the operation and maintenance
manual available at the following website: https://www.selt.com/dte-en

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 11 / 64
4PRODUCT INSTALLATION
This chapter contains general requirements concerning the product installation.
Correct assembly is a necessary condition for smooth operation of the product.
SELT Sp. o.o. recommends using only professional assembly crews, which guarantee the Purchaser that the conducted
installation will be correct.
4.1 GENERAL REQUIREMENTS FOR SAFE INSTALLATION
it is necessary to observe general rules of good building practice,
it is necessary to comply with applicable Occupational Health and Safety regulations concerning in particular
those applying to the safety of operation of electrical equipment and work on heights,
product should be installed in a mechanical way, foams, adhesives or similar materials should be used in
accordance with the recommendations of their manufacturers, taking into account the specificity of the product,
base, to which the product brackets will be fixed, should be a reliable structure with appropriate parameters,
before starting the assembly, remove all unnecessary objects from the assembly area, including electric wires
(check the course of the installation in the area of the fixing places to exclude their damage), and also mark the
place of assembly and apply appropriate measures to protect people.
Information table regarding the substrate to which the substructure is to be installed
The product should be mounted to a substrate with appropriate parameters or a substructure with appropriate
parameters.
The above-mentioned requirements for the substrate and substructure require the assessment of a specialist and
burden the investor and the contractor.
A different assembly method than suggested by SELT is possible, provided that the requirements of building
knowledge and safety are observed. In any case, this requires specialist knowledge and is done at the risk of the
investor or contractor.
It is recommended to make arrangements with an authorized designer.
4.2 REQUIREMENTS FOR SAFE INSTALLATION OF THE PRODUCT AT HEIGHTS
Product installation, due to a necessity of execution of works on heights, is classified to the particularly
hazardous works because it causes high risk of occurrence of threats for human health and safety - in
particular in case of fall from heights.
Obligation to ensure preparation of occupational health and safety plan during installation is the responsibility of the
person performing the installation (hereinafter referred to as Installer) or ordering such works (hereinafter referred to as
the Investor).
Installer/Investor should define the detailed health and safety requirements when performing work at heights, and
especially ensure:
direct supervision of execution by person appointed for this purpose (e.g. site manager, foreman),
proper protection equipment, in particular equipment protecting against fall from heights,
detailed guidance for employees working at heights.
Works performed at heights above 2m, requiring the use of personal protection equipment against falling from heights,
should be carried out by at least two persons.
Works at height should be organised and performed in a manner that does not force an employee to lean beyond the
handrail of railings or outline of the device on which he/she stands. Do not stand on the elements of the product.
The investor/installer is obliged to ensure access to location, where the works on heights are executed, only for authorized
persons and persons, who were properly instructed. The Investor/installer should inform about the works carried out at
heights and the necessary safety measures to be used during these works by persons staying or likely to stay in the area
where such works are carried out or in the vicinity of this area.
4.3 PREPARATION FOR INSTALLATION
unpack the product and check if there are all components necessary for assembling,
prior to installation you should check whether the substrate has sufficient load capacity allowing safe assembly
and operation.
Note: Purchase and selection of the screws, pins and bolts connecting the system with the facility structure
should be done by installer or investor.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 12 / 64
4.4 GENERAL GUIDELINES FOR PRODUCT INSTALLATION
Pergola SB400 is an open external terrace covering. The equipment under the pergola must be intended for
outdoor use.
Four people are required for the safe installation of the support structure.
Incorrect assembly or errors during assembly may have serious consequences during product operation.
Before starting the installation, check whether the installation space is free of obstacles, including people and
things, and ensure that the installation site and the adjacent area are properly marked and secured.
Anchoring components intended for fixing the product to the wall or floor are not enclosed because they should
be individually selected by the fitter depending on the material to which they are to be installed (it is
recommended to make arrangements with an authorized designer),
Walls or floor should be load-bearing and adapted for transferring of forces from product anchoring.
SELT shall not be responsible for damages caused by use of too weak anchoring components or fixing in the floor
with too small load bearing.
The product should be protected against dirt (e.g. bricklaying mortar, caulking foam, silicone), which may cause its
damage.
If it is necessary to use polyurethane foam, silicone or other agents, it is absolutely necessary to follow the
manufacturer's instructions on the packaging.
The incorrect assembly may cause hazardous situations for the user.
Fig. 3. Standard direction of blades opening for Pergola SB400.
The drawings are for illustrative purposes only and do not reflect all product features, e.g. related to the use of gaskets.
For sealing you should use only the following sealant: FIX ALL CRYSTAL by Soudal company or a product with
equivalent parameters.
Technical data (according to the manufacturer of the sealant):
- consistency
Paste
Elongation at break
350% (ISO 37)
- skin forming time
ca. 4 min. (at 23°C/
50% RH)
Allowed distortion
+/-20% (ISO 11600)
- curing speed
ca. 4 mm/24h (at
23°C/ 50% RH)
Thermal resistance (after
curing)
from -40 °C to +90 °C
- relative density
1,05 g/cm3
Elasticity modulus
0,6 N/mm2(ISO 37)

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 13 / 64
- hardness (Shore A)
38 +/- 5
Max. tension
1,8 N/mm2(ISO 37)
Elastic recovery
>75% (ISO 7389)
Application temperature
from +5 °C to +35 °C
4.5 INSTALLATION TOOLS
Installation instructions, operation and maintenance manual and instructions for safe use are available at www.selt.com
after logging in.
List:
drill bits for metal and concrete,
hammer drill,
ladder / scaffolding, crane, bucket truck, loader crane, hydraulic crane,
screwdriver,
measure,
hammer,
pencil/marker pen,
spirit level,
flat wrenches,
wrench spanners (Allen keys),
rope for protections / hoisting / removal of components,
torque wrench.
In addition, persons who assemble the product must be provided with appropriate personal protective equipment (such as
protective clothing, gloves, helmet, protective glasses and other according to individual conditions, such as height
protection).
Sample content of the box with accessories:
Content (depending on type):
- feet with assembly bones
- M8x20 stainless steel tapered screws with hexagonal
thread
- lacquered (black) St4,2 screws with raised head
- stainless steel screws M5x20 with cylinder head and
recess hexagon socket + washers
- stainless pins for guiding bracket
- large plastic slip rings
- small plastic slip rings
- Clip plastic rings (large)
- small stainless snap-rings (Seger)
- silicone (tube) –Crystal Fix
- control unit + remote control (in manufacturer’s
packaging)
- countersunk stainless tapered M8 nuts
- stainless steel threaded studs M8
- protective crates for gutter overflows
- case with remote control and leaflet
- gasket for 1 sealing blade
- plastic drain covers with ST4.2x19 stainless screws
- screws for fastening the motor bracket (depending on the
model) stainless steel countersunk ST6.3x16-C-H
- corner overflows (only in pergolas with outflow on the
side)
The motor together with the motor’s bracket and the guiding bracket (right and left version) is not fixed to the
beam due to the elimination of the risk of damage to the power cable (depending on the motor model). It
should be attached to the holes made on the lengthwise beam by taking into account the direction of blades
opening (clockwise or counterclockwise) and the modified movement of the motor’s piston – retracting
when closing the blades.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 14 / 64
Pergola feet as well as intermediate post attachment
and feet have cast connectors that have from the metal
sheet side factory-made outflow holes on wide and
narrow side of the connector.
4.6 INSTALLATION
Fig 4a. View of the assembly of elements of free-standing Pergola SB400.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 15 / 64
Fig. 4b. View of the assembly of elements of wall-mounted Pergola SB400.
(note: wall bracket in a new version: universal bent)

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 16 / 64
Fig. 5. View of the assembly of modular Pergola SB400.

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 17 / 64
Note:
Before proceeding with the assembly, it is necessary to verify the visual condition of the packaging of the
elements delivered for assembly, the visual condition of the elements and their completeness. For
damages arising after the delivery (transfer of risk) SELT Sp. z o.o. is not responsible.
The elements are delivered in a package and a stretch cover for protection during assembly.
Accessories (feet, bolts, screws, small and large snap-rings, blade pins, silicone, assembly instructions) are
packed in cardboard boxes.
Fig. 6. Marking of the types of feet (view from above) of Pergola SB400.
Foot A
Foot B
Foot C
Foot D/F
Foot E
Foot G
Foot H
Foot I
Note: the above types of feet can be ordered in a variant with a linearly adjustable height in the range of 0-50 mm.
Fig. 7. Types of feet for Pergola SB400

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 18 / 64
Note:
Prior anchoring you should check installation correctness of the support structure by checking the
diagonals between the posts and whole support structure and correct structure setting if necessary.
Assembled supporting structure should be permanently fixed to the substrate in destination location by
anchoring the feet, using anchors ensuring stable fixing. Anchoring should be selected by the licensed
designer every time. We recommend using screws/anchors of 12 mm diameter for fixing the footing to the
substrate.
Fig. 8a Placement of the crossbeams of the SB400 pergola
Fig. 8b Holes for wiring
At their ends, in the area of bones, the beams
have special openings ø 30 for cable routing (fig.
8b). Before assembling the pergola beams, insert
the cables inside the beams (fig. 8a-right).

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 19 / 64
4.6.1 INSTALLATION OF THE STANDARD FEET
1. Install all feet to the appropriate post types.
Screw on both sides with conical screws with
M8x20 Allen socket (fig. 9).
2. For feet with outflow set up the cutouts in the
bottom of the sheet and the mouse hole
accordingly for the drainage of water in the
post and the foot.
Figure 9
4.6.2 INSTALLATION OF ADJUSTABLE FEET
1. Assembly is possible only for posts with
adapted drilling (with an additional third hole
at the bottom edge of the post)- fig. 10 left.
Place all feet in the appropriate post types
(according to the order form).
2. On the wider side of the post insert M8x20
conical screws with an Allen socket from the
outside into the two holes located above.
From the inside of the post they should be
screwed into a common pressure stainless
steel flat bar. Leave room for insertion of the
foot into the bone (fig. 10-right). Repeat this
action on the opposite wall of the post.
Figure 10
3. Slide the post profile with the pressure flat
bars onto the bone so that the fastening
screws enter the slots in the bone and the
pressure flat bars slide from the inside of the
bone (fig. 11-left). The extension adjustment
range allows you to obtain a gap between the
bottom of the post profile and the top of the
sheet in the range of 0 to 50 mm (fig. 11-right).
4. Slide the post onto the bone while respecting
the allowable range of the gap and tighten
with torque of 17 Nm.
Figure 11
5. We recommend that the final stabilization of
the foot extension be performed after the
frame is fully assembled and the verticality of
the posts, the levelling of the beams and the
compliance of the diagonals are checked. For
the location next to the wall, make the target
drilling before moving it to the wall.
6. After determining the selected extension and
tightening the M8 screws, and completing the
assembly of the frame, drill through the bone
with a fi 10.5 drill through the bottom hole of
the post
7. Fit M8 sleeve nuts with M8 threaded stud on
both sides and tighten with a torque of 17 Nm
(fig. 12).
Figure 12

DT-E 5.8: ALUMINIUM CONSTRUCTION –SYSTEM PERGOLA SB400
Edition 8 / August 2023 / EN page 20 / 64
4.6.3 INSTALLATION OF THE FRAME
NOTE: Elements of the load-bearing structure during assembly should be secured against tipping over or falling
onto the persons performing the assembly. The assembled supporting structure (frame) should be placed in the
right place and anchored to the ground with a suitable fastening product. Suggested size of the anchors is M12.
The purchase and selection of elements for anchoring the structure is the responsibility of the buyer of the system.
Figure 13
In accessories, 1 piece of gasket for sealing blade is rolled up in a string bag.
Before assembling the frame, slide into the groove of the sealing blade of one crossbeam, where it is fixed as “U”
(gutter)- fig. 13. For the second crossbeam, the gasket is not used.
NOTE: In case of visible uneveness of the beam and post edges (fig. 12a) it can
be corrected by:
- checking if the diagonals of pergola are identical and, if needed, correcting
the position of the base of the foot
- remove the beam from the socket/bone, loosen M8 screws securing the
socket/bone in the post and use a hammer to move the protruding end of
the socket in the correct direction. Tighten the socket again.
Complete or make a new seal around the perimeter of the beam. Place the
beam so that its plane is aligned with the post.
Figure 12a
