Sencor Seg 710bp User manual

Egg Cooker

User's manual

EN-1

SEG 710BP

2015 01/2015

Prior to using this appliance, please read the user's manual thoroughly, even in cases where you have

previously familiarised yourself with the operation of similar types of appliances. Only use the appliance

in the manner described in this user manual. Keep this user's manual in a safe place where it can be

easily retrieved for future use.

We recommend saving the original shipping cardboard box, packaging material, receipt and

responsibility statement of the vendor or warranty card for the duration of warranty. In the event of

transportation, we recommend that you pack the appliance in the original box from the manufacturer.

EN-2

Egg Cooker

SEG 710BP

2015 01/2015

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS .............................................................................................................3

DESCRIPTION OF THE EGG COOKER ..............................................................................................................6

BEFORE FIRST USE ..........................................................................................................................................7

OPERATION OF THE EGG COOKER ................................................................................................................7

CLEANING AND MAINTENANCE ....................................................................................................................8

TECHNICAL SPECIFICATIONS ........................................................................................................................10

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS ....10

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT ..............................................................10

Egg Cooker

SEG 710BP

EN-3

2015 01/2015

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND STORE FOR FUTURE USE.

• This appliance may be used by children 8 years of age and

older and by persons with physical or mental impairments or

by inexperienced persons, if they are properly supervised or

have been informed about how to use of the product in a safe

manner and understand the potential dangers. Cleaning and

maintenance performed by the user must not be performed by

children unless they are older than 8 years of age and under

supervision. Keep this appliance and the power cord out of

reach of children that are younger than 8 years of age.

• Children must not play with the appliance.

• This appliance is designed for domestic use and similar locations

such as:

– staff kitchens in stores, ofﬁces and other workplaces;

– hotel or motel rooms and other living areas;

– bed and breakfast establishments.

• Before connecting this appliance to a power socket, make sure

the voltage stated on the product's rating label corresponds to

the voltage in your power socket. Connect the appliance only

to a properly grounded socket.

• Do not use the appliance outdoors.

• Only place the appliance on an even, dry and stable surface.

• Do not place the appliance on or near an electric or gas stove

or other sources of heat.

• Do not use the appliance in the direct vicinity of a bathtub,

wash basin, shower, pool or other similar sources of water.

• The appliance is designed for boiling eggs. Do not use it for

other purposes.

• Fill the heating plate of the appliance with water so that it

does not ﬂow over its edge. Use the included measuring cup to

measure out the correct amount of water.

EN-4

Egg Cooker

SEG 710BP

2015 01/2015

Attention:

Be especially careful not to injure yourself on the egg piercing

pin located on the underside of the measuring cup.

• Do not turn the appliance on without the removable egg tray

or the lid being properly seated.

• Do not turn on the appliance when it is empty. The incorrect

use of the appliance may negatively affect its lifetime.

Attention:

The appliance heats up during operation and steam is

emitted from the steam outlet. Be especially careful that your

skin does not come into contact with the hot surface or the

emitted steam. Do not open the lid or handle the appliance

in any way. Certain parts of the appliance remain hot even

some time after it is turned off. Use the handles to handle

the appliance.

• Always turn off the appliance and disconnect it from the

power socket if you will not be using it, before disassembly or

assembly, before moving or cleaning it.

• Allow the appliance to cool down before cleaning it.

• Do not wash the appliance (except for the removable lid and

egg tray) under running water and do not submerge it in water

or any other liquid.

• Make sure the power cord is not touching a hot surface. Do not

place heavy items on the power cord.

• Do not disconnect the appliance from the power socket by

pulling on the power cord. This could damage the power cord

or the socket. Disconnect the cord from the power socket by

gently pulling the plug of the power cord.

• If the power cord is damaged, have it replaced at a professional

service centre. It is forbidden to use the appliance if it has

a damaged power cord or plug.

Egg Cooker

SEG 710BP

EN-5

2015 01/2015

• To avoid the danger of injury by electrical shock, do not repair

the appliance yourself or make any adjustments to it. Have

all repairs or adjustments of the appliance performed at an

authorised service centre.

• By tampering with the appliance you risk voiding your legal

rights arising from unsatisfactory performance or quality

warranty.

EN-6

Egg Cooker

SEG 710BP

2015 01/2015

DESCRIPTION OF THE EGG COOKER

1 Removable lid

2 Removable egg tray

holds 1 to 7 eggs

3 Stainless steel heating plate

4 Base unit

5 Power cord storage space

6 Steam exhaust outlet

7 Lid handle

8 Egg tray handle

9 Base unit handle

0 I/0 switch (on/off)

with a light indicating operation

qa Measuring cup

qs Egg piercing pin

Egg Cooker

SEG 710BP

EN-7

2015 01/2015

BEFORE FIRST USE

1. Take the appliance and its accessories out of the packaging materials.

2. Before ﬁrst use, wipe the stainless steel surface of the heating plate A3 using a cloth dampened in

a solution of warm water and neutral kitchen detergent. Use a cloth dampened in warm water to

thoroughly wipe the surface on to which you applied the kitchen detergent and then wipe it dry.

3. Wash the removable lid A1 and the removable egg tray A2 in warm water using a neutral kitchen

detergent. Then rinse these parts under running water and dry them.

4. Now the appliance is ready for operation.

OPERATION OF THE EGG COOKER

1. Unwind the power cord and place the appliance on a stable, even and clean surface.

2. Place the egg tray A2 on the heating plate A3 so that the edge of the heating plate A3 slides

into the groove on the underside of the egg tray A2.

Attention:

Take care not to mistake the top and bottom sides of the egg tray A2. When incorrectly

installed, the egg tray A2 will not be stable and it could fall.

3. Now measure out the water using the included measuring cup Aqa. Only ﬁll the measuring cup Aqa

with cold drinking water. Do not add any other substances, e.g. salt.

The amount of water depends on the desired egg consistency (soft, medium or hard) and the

number of eggs. Three measuring scales are marked on the measuring cup Aqa:

– "Soft" (soft-boiled egg);

– "Medium" (medium-boiled egg);

– "Hard" (hard-boiled egg).

Each scale has marks with numbers 1 to 7, which serve to measure out water according to the

number of eggs.

Example for measuring out the correct amount of water

You need to measure out water for four soft-boiled eggs. Fill the measuring cup Aqa with cold

drinking water up to the mark with the number 4 on the "Soft" scale (soft-boiled).

Note:

Even when the same amount of water and cooking time is used, the consistency of individual

eggs may differ as a result of their varying sizes or freshness.

4. Pour the measured out amount of water on to the heating plate A3. Take care that water is not

spilled on to the base unit of the appliance A4 or that water does not ﬂow over the edge of the

heating plate A3.

5. Place the number of eggs (pointing upwards) corresponding to the measured out water into the

egg tray A2. A maximum of 7 eggs can be boiled at the one time. Always use only fresh eggs.

Tap and pierce the tip of every egg using the piercing pin Aqs located on the underside of the

measuring cup Aqa. Do not use excessive force so as not to crack the egg. As a result of being

pierced, a small amount of egg white may escape on to the surface of the shell, where it will

harden. This is a completely normal event.

Attention:

Be especially careful not to injure yourself on the egg piercing pin Aqs located on the underside

of the measuring cup Aqa.

6. Put on the lid A1 and check that it is properly seated on the egg tray A2.

EN-8

Egg Cooker

SEG 710BP

2015 01/2015

7. Connect the power cord to an el. power socket. Turn the appliance on by setting the I/0 switch

A0 to position I (On). An indicator light will turn on, indicating that the appliance is running. The

heating plate A3 will start heating the water. The following approximate egg cooking time is

required:

Consistency Approximate cooking time

Soft-boiled eggs 5 min

Medium-boiled eggs 10 min

Hard-boiled eggs 15 min

Attention:

The appliance heats up during operation and steam is emitted from the steam outlet A6. Be

especially careful that your skin does not come into contact with the hot surface or the emitted

steam. Do not open the lid A1 or handle the appliance in any way.

Certain parts of the appliance remain hot even some time after it is turned off. Use the handles

to handle the appliance.

Note:

When the appliance is used for the ﬁrst time there may be light smoke emitted. This is completely

normal and is not a defect and it will disappear in a short time.

8. As soon as the cooking process is complete, an acoustic signal will be made. Set the I/0 switch A0

to position 0 (Off). The acoustic signal will turn off and the I/0 switch indicator light A0 will turn

off. Disconnect the power cord from the el. power socket. Hold the lid A1 by the handle A7, take

it off and place it on a heat resistant surface. Take out the egg tray A2 and place it, together with

the eggs, under cold running water. Then the shells will be easier to remove and you will prevent

overcooking your eggs.

9. Clean out the appliance after each use according to the instructions in chapter Cleaning and

maintenance.

CLEANING AND MAINTENANCE

• Before cleaning it, make sure that the appliance is turned off and disconnected from the power

socket. Allow hot parts of the appliance to cool down.

• Wash the removable lid A1 and the egg tray A2 in warm water using a neutral kitchen detergent.

Then thoroughly rinse these parts under running water and dry them.

Note:

Do not wash the removable lid A1 and the egg tray A2 in a dishwasher!

• Wipe the heating plate A3 using a cloth dampened in a solution of warm water and neutral

kitchen detergent. Use a cloth dampened in warm water to thoroughly wipe the surface on to

which you applied the kitchen detergent and then wipe it dry.

Attention:

Never apply limescale deposit cleaning agents on to a hot heating plate A3!

• Use a dry wiping cloth for cleaning the base unit A4. In the event of heavier soiling, dampen the

cloth in a weak solution of neutral kitchen detergent. After applying the kitchen detergent, wipe

the surface of the egg cooker with a lightly damp cloth and then wipe dry.

• Never use abrasive cleaning products, petrol, solvents, steel wool, etc. for cleaning.

Egg Cooker

SEG 710BP

EN-9

2015 01/2015

Removing lime scale deposits

• Egg shells contain many calcium salts so we recommend that lime scale deposits are regularly

removed from the heating plate A3.

• Pour a small amount of vinegar into the measuring cup Aqa and add water. Make sure that the

solution level does not exceed mark 1 on the "Hard" scale. Pour the solution directly on to the

heating plate A3 and allow it to act for 30 minutes. Then remove the solution and wipe the heating

plate A3 with a clean lightly dampened cloth and wipe dry.

Attention:

Never heat up the solution intended for removing limescale deposits in the appliance!

EN-10

Egg Cooker

SEG 710BP

2015 01/2015

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED

PACKAGING MATERIALS

Dispose of used packaging material at a site designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on products or original documents means that used electric or electronic

products must not be added to ordinary municipal waste. For proper disposal, renewal

and recycling hand over these appliances to determined collection points. Alternatively,

in some European Union states or other European countries you may return your

appliances to the local retailer when buying an equivalent new appliance.

Correct disposal of this product helps save valuable natural resources and prevents potential

negative effects on the environment and human health, which could result from improper

waste disposal. Ask your local authorities or collection facility for more details.

In accordance with national regulations penalties may be imposed for the incorrect

disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic appliances, ask your retailer or supplier

for the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product,

request the necessary information about the correct disposal method from the local

council or from your retailer.

This appliance meets all the basic requirements of EU directives related to it.

TECHNICAL SPECIFICATIONS

Rated voltage ................................................................................................................................. 220−240 V

Rated frequency ..................................................................................................................................... 50 Hz

Rated power input ........................................................................................................................ 320–380 W

We reserve the right to change text and technical speciﬁcations.

Table of contents

Other Sencor Egg Cooker manuals
