Sencor SHF 910BL User manual

Humidifier
User's manual
EN
EN-1
02/2015
2015,
SHF 910BL / SHF 911GR
Before first use, please read all instructions contained in this user's manual carefully, even if you are
already familiar with using similar products. Only use this product in accordance with the instructions
described in the user's manual. Keep this user's manual in a safe place where it can be easily retrieved
for future use.
We recommend saving the original cardboard box, packaging material, purchase receipt and
responsibility statement of the vendor and warranty card for at least the duration of the legal liability
for unsatisfactory performance or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.

EN-2
EN
02/2015
2015,
Humidifier
SHF 910BL / SHF 911GR
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .......................................................3
DESCRIPTION OF THE HUMIDIFIER ........................................................5
PLACEMENT OF THE HUMIDIFIER AND FILLING UP THE WATER TANK ...........................6
USING THE HUMIDIFIER .................................................................7
CLEANING AND MAINTENANCE ..........................................................7
TROUBLESHOOTING ....................................................................8
TECHNICAL SPECIFICATIONS .............................................................9
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS . . 10
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT ...............................10

EN
EN-3
02/2015
2015,
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may be used by children 8 years of age and
older and by persons with physical or mental impairments or
by inexperienced persons, if they are properly supervised or have
been informed about how to use the product in a safe manner
and understand the potential dangers. Children must not play
with the appliance. Cleaning and maintenance that may be
performed by the user must not be performed by unsupervised
children.
• The appliance is designed for use in households, offices and
similar types of areas. Always install it on an even, dry and stable
surface. Do not place it in the vicinity of an open flame, gas
appliances or devices that are sources of heat and do not expose
it to direct sunlight.
• Before connecting the appliance to a power socket, check that
the technical details on its rating label match the electrical
voltage in the socket.
• Do not use the appliance in rooms where there is a risk of
flammable gases or chemical vapours leaking or in rooms
that are very dusty. When the appliance is running, it must be
located at a sufficient distance from curtains or drapes and at
least 1 metre from electrical or electronic devices or materials
sensitive to moisture in order not to damage them by the effect
of increased humidity.
• Do not replace any part of this appliance with parts or accessories
from another manufacturer.
• Only fill the water tank with clean cold water without any
additions. Do not pour water into the water tank through the
steam outlet.
• Before putting the appliance into operation, check that it is
properly assembled and that the water tank is filled.
Humidifier
SHF 910BL / SHF 911GR

EN-4
EN
Humidifier
SHF 910BL / SHF 911GR
02/2015
2015,
• Do not cover the appliance when it is running. Do not insert any
items into the steam outlet or the ventilation openings and make
sure that none of these openings are blocked by foreign objects.
• As a result of increased humidity in the room, water may
condensate on window panes or interior furnishings. If this
situation arises, turn the appliance off.
• Always turn off the appliance and disconnect it from the power
socket, before filling up the water tank, installing, removing,
moving or cleaning it.
• Be especially careful not to spill water when carrying the
appliance with water in the water tank.
• To avoid potential injury by electric shock, do not submerge any
part of the appliance's base unit in water or any other liquid.
• Do not touch the nebulizer (surfaces for the condensation of
water) with sharp objects in order not to damage it.
• Do not disconnect the appliance from the power socket by
pulling on the power cord. This could damage the power cord
or the power socket. Disconnect the cord from the power socket
by gently pulling the plug of the power cord.
• If the power cord is damaged, have it replaced at a professional
service centre. It is forbidden to use the appliance if it has
a damaged power cord or plug.
• Do not use the appliance if it is not working correctly, if it has
been damaged or has been submerged in water. To avoid the
danger of injury by electrical shock, do not repair the appliance
yourself or make any adjustments to it. Have all repairs or
adjustments of the appliance performed at an authorised service
centre. By tampering with the appliance you risk voiding your
legal rights arising from unsatisfactory performance or quality
warranty.

Humidifier
SHF 910BL / SHF 911GR
EN
EN-5
02/2015
2015,
DESCRIPTION OF THE HUMIDIFIER
A
7
8
9
0
qa
1
3
4
5
6
2
1 Steam exhaust nozzle
2 Water tank with a capacity of 2.2 l
3 Plug of the water tank filling opening
with a water release switch
4 Air exhaust opening
5 Indicator light
indicates connection to a power socket,
operation of the appliance and a low
water level in the water tank.
6 Control dial for On/Off and regulating
humidification output
7 Power cord
8 Water level sensor
9 Water holder
Water is pumped into the water holder
from the water tank.
0 Nebulizer
A surface where water is converted into
cold steam (mist).
qa Base unit

EN-6
EN
Humidifier
SHF 910BL / SHF 911GR
02/2015
2015,
PLACEMENT OF THE HUMIDIFIER AND FILLING UP THE WATER TANK
1. Always place the humidifier on an even, dry and stable surface at a minimum distance of:
– 60 cm from the floor;
– 30 cm from walls or sides of furniture and at a sufficient distance from curtains or drapes;
– 100 cm from electrical and electronic devices or materials sensitive to moisture to prevent their
damage by the effects of increased humidity.
2. Check that the humidifier is turned off and disconnected from the el. power socket. Lift the water
tank A2 off the base unit Aqa. Turn it upside down and anticlockwise unscrew the plug A3 of the
filling opening of the water tank.
B
3. Fill the water tank A2 with clean cold tap water. After filling up the water tank A2, properly screw
in the plug A3 clockwise. Turn the water tank A2 upside down with the plug A3 facing downwards
and place it back on to the base unit Aqa so that both parts fit into each other properly. When the
water tank A2 is placed on the base unit Aqa, water will start flowing into the water holder A9.
C
Attention:
Fill the water tank A2 with water that has a max. temperature of 40 °C. Do not fill it up with
water that is hotter. The water tank A2 has a maximum capacity of 2.2 litres of water.
If you need to move the humidifier, be especially careful not to spill the water contained in the
water holder A9.

Humidifier
SHF 910BL / SHF 911GR
EN
EN-7
02/2015
2015,
USING THE HUMIDIFIER
1. Check that the humidifier is correctly assembled. Connect the power cord to an el. power socket.
The indicator light A5 will be lit red. Turn the control dial A6 clockwise to turn on the humidifier.
After turning on the humidifier, the indicator light A5 will be lit green. Set the required steam
output. Turn the control dial A6 clockwise to increase steam output and turn it anticlockwise to
reduce steam output. The humidifier will start producing cold steam within a few moments. Ensure
that during operation that the steam is not directed at furniture or items sensitive to moisture.
Attention:
If the humidifier was transported at temperatures below the freezing point, first put it into
room temperature and wait approx. 30 minutes before turning it on.
Use the humidifier at an ambient temperature in the range of 5 to 40 °C. In the event that the
ambient temperature falls below 0 °C, turn the humidifier off and remove the water inside the
water tank A2 and the water holder A9, to prevent it from being damaged.
Never lift the water tank A2 out of the base unit Aqa or touch the nebulizer A0 when the
humidifier is running.
2. You can increase or decrease the steam output at any time by turning the control dial A6. If you
fill the tank A2 all the way to the edge, the expected operating time is approximately 7 hours with
the steam output set to maximum intensity.
3. If water in the water holder A9 starts running out, the indicator light A5 will start flashing. When the
water level falls below a certain level, the humidifier will automatically stop producing steam and the
indicator light A5 will turn off. This is a safety function to prevent the nebulizer A0 from being damaged.
If necessary, fill up the water according to the instructions in point 2 and 3 in chapter Placement of
the humidifier and filling up the water tank. Then you can start the humidifier again.
4. To turn off the humidifier, turn the control dial A6 anticlockwise until you hear a click. The indicator
light A5 will be lit red. Disconnect the humidifier from the el. power socket and clean it out according
to the instructions contained in the chapter Cleaning and maintenance.
CLEANING AND MAINTENANCE
• Before cleaning the humidifier, turn it off and disconnect it from the el. power socket.
• Please adhere to the following instructions relating to the cleaning and maintenance of the
humidifier. Otherwise its performance may be negatively affected and undesirable microorganisms
may multiply inside the humidifier.
Clean after every use
• Take the water tank A2 out of the base unit Aqa and take it to the sink. Turn it upside down and
screw out the plug A3. Remove any remaining water from the water tank A2 and then rinse it
out with clean water. Dry the surface of the water tank A2 with a fine wiping cloth and screw in
the plug A3.
• Remove the water from the water holder A9 and wipe it dry using a fine clean cloth.
Thorough cleaning (once per week)
• Remove water from the water tank A2 and the water holder A9.
• Pour approximately 100 ml of vinegar into the water holder A9 and allow it to act for 15 minutes.
Using a brush with soft bristles, remove the limescale deposits in the water holder A9 and the
nebulizer A0. Then clean out all the remaining limescale and vinegar using a cloth dampened in
clean water and wipe dry.

EN-8
EN
Humidifier
SHF 910BL / SHF 911GR
02/2015
2015,
• Clean the outer surface of the humidifier as required using a fine clean cloth lightly dampened in
lukewarm water.
• For cleaning, do not use abrasive cleaning products and solvents as this could damage the surface
of the appliance.
Attention:
Do not leave water in the water tank A2 or in the water holder A9 for longer than a week.
Do not submerge the base unit Aqa in water or rinse it under running water.
TROUBLESHOOTING
Problem Possible cause Solution
The indicator light
A5 is not lit and
the humidifier
is not producing
steam despite the
required steam out
being set.
The humidifier is connected to
a faulty power socket or is not
connected to a power socket
at all.
Connect the humidifier to a working power
socket.
There is not enough water in
the water holder A9 or there
is no water at all.
Turn off the humidifier unit and disconnect it
from the power socket. Fill up the water tank A2
with cold clean water. Assemble the humidifier,
connect it to a power socket and start it again.
An odour can
be sensed in the
steam.
The odour may be sensed
when the humidifier is used
for the first time.
Open the water tank plug A3 and allow the
water tank A2 to ventilate for at least 12 hours.
Inside the water tank A2 /
water holder A9 there is dirty
water or you have left water
in the water tank A2 / water
holder A9 for too long.
Turn off the humidifier and disconnect it from the
power socket. Remove the water from the water
tank A2 and from the water holder A9. Clean
everything. Fill up the water tank A2 with cold
clean water. Connect the humidifier to a power
socket and start it again.
The humidifier
is producing
an insufficient
amount of steam
or is not producing
any steam at all.
There is not enough water in
the water holder A9 or there
is no water at all.
Turn off the humidifier and disconnect it from the
power socket. Fill up the water tank A2 with cold
clean water. Connect the humidifier to a power
socket and start it again.
The control dial A6 is set to
the off position or a low steam
output intensity is set.
Turn the control dial A6 clockwise to turn on the
humidifier. To increase the steam output intensity,
keep turning the control dial A6 clockwise.
The nebulizer A0 is clogged
with mineral deposits.
Turn off the humidifier and disconnect it from
the power socket. Clean out the nebulizer A0
according to the instructions in chapter Cleaning
and maintenance.
Inside the water tank A2 /
water holder A9 there is dirty
water or you have left water
in the water tank A2 / water
holder A9 for too long.
Turn off the humidifier and disconnect it from the
power socket. Remove the water from the water
tank A2 and from the water holder A9. Clean
everything. Fill up the water tank A2 with cold
clean water. Connect the humidifier to a power
socket and start it again.
The water tank A2 is not
correctly seated in the base
unit Aqa.
Place the water tank A2 on to the base unit Aqa
so that both parts fit together properly.
The nebulizer A0 or fan is not
working.
Contact an authorised service centre.

Humidifier
SHF 910BL / SHF 911GR
EN
EN-9
02/2015
2015,
Problem Possible cause Solution
The humidifier or
windows in the
room are fogging
up.
The room in which the
humidifier is located is either
too small or too humid.
Lower the steam output intensity to minimum
by turning the control dial A6 anticlockwise or
turn the humidifier off completely.
Mineral
deposits quickly
accumulate on the
nebulizer A0.
You are using water that is
too hard.
Use softer water.
TECHNICAL SPECIFICATIONS
Rated voltage ................................................................220−240 V
Rated frequency ................................................................ 50/60 Hz
Rated power input .................................................................30 W
Electric shock protection class ........................................................... II
Noise level .................................................................... 35 dB(A)
Water tank capacity ................................................................ 2.2 l
Humidifying output ........................................................350 (±35) ml/h
Operating time per single fill up ..................................up to 7 hours at max. output
Recommended room area ...........................................................20 m2
Dimensions (width x depth x height) .......................................23 x 17.5 x 24.5 cm
Length of the power cord .........................................................185 cm
Weight .......................................................................... 950 g
The declared noise emission level of the appliance is 35 dB(A), which represents a level A of acoustic
power with respect to a reference acoustic power of 1 pW.
Explanation of technical terminology
Safety class for electric shock protection:
Class II – Electric shock protection is provided by double or heavy-duty insulation.
Amendments to text and technical parameters are reserved.

EN-10
EN
Humidifier
SHF 910BL / SHF 911GR
02/2015
2015,
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or electronic
products must not be added to ordinary municipal waste. For proper disposal, renewal
and recycling hand over these appliances to determined collection points. Alternatively,
in some European Union states or other European countries you may return your appli-
ances to the local retailer when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources and prevents po-
tential negative effects on the environment and human health, which could result from
improper waste disposal. Ask your local authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect dis-
posal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your vendor
This appliance meets all the basic requirements of EU directives related to it.
