Sencor SMW 2717 User manual

SMW 2717
Microwave Oven
INSTRUCTION MANUAL
EN
EN-1
Please read these instructions carefully before installing and operating the oven. This manual retain for future
reference.
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 1

Microwave Oven
SMW 2717
EN
CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY . . . . . . . . . . . . . . . . . . . 2
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
BEFORE YOU CALL FOR SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GROUNDING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
RADIO INTERFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
MICROWAVE COOKING PRINCIPLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
UTENSILS GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PART NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CLEANING AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DISPOSAL OF USED ELECTRICAL & ELECTRONIC EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
1. Do not attempt to operate this oven with the door open since open door operation can result in harmful
exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and
that there is no damage to the:
• Door (bent),
• Hinges and latches (broken or loosened),
• Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly qualified service personnel.
SPECIFICATIONS
Power Consumption: 230 V~50 Hz, 1200 W (Microwave)
Rated microwave power output: 700 W
Operation Frequency: 2450 MHz
Outside Dimensions: 262 mm (H) x 452 mm (W) x 335 mm (D)
Oven Capacity: 17 Litres
Cooking Uniformity: Turntable System {쏗245 mm}
Net Weight: Approx. 10.5 kg
Noise Level: 57 dB
* All data subject to change, and verification by the user with data available on the nameplate of the oven.
Complaint of error suffers oblivion.
EN-2
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 2

Microwave Oven
SMW 2717
EN
EN-3
BEFORE YOU CALL FOR SERVICE
If the oven fails to operate:
1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait
10 seconds and plug it in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly, test
the outlet with another appliance.
3. Check to ensure that the control panel is programmed correctly and the timer is set.
4. Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise, the
microwave energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED TECHNICIAN. DO NOT TRY
TO ADJUST OR REPAIR THE OVEN YOURSELF.
INSTALLATION
1. Make sure that all the packing materials are removed from the inside of the door.
2. WARNING: Check the oven for any damage, such as misaligned or bent door, damaged door seals and
sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If
there is any damage, do not operate the oven and contact a qualified service personnel.
3. This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food
likely to be cooked in the oven.
4. Do not place the oven where heat, moisture or high humidity are generated, or near combustible
materials.
5. For correct operation, the oven must have sufficient airflow. Allow 20cm of space above the oven, 10cm
at back and 5cm at both sides. Do not cover or block any openings on the appliance. Do not remove feet.
6. Your product has been designed for use as a stand-alone device. It has not been designed to be
used as a built-in appliance.
7. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
8. Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or
sharp surface.
9. Make sure that wall outlet is easily accessible should you need to disconnect the powe cable quickly in
case of emergency.
10. Do not use the oven outdoors.
GROUNDING INSTRUCTIONS
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with
a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the
event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the
electric current. It is recommended that a separate circuit serving only the oven be provided. Using a high
voltage is dangerous and may result in a fire or other accident causing oven damage.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.
Notes: 1. If you have any questions about the grounding or electrical instructions, consult a qualified
electrician or service person.
2. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or
personal injury resulting from failure to observe the electrical connection procedures.
RADIO INTERFERENCE
Operation of the microwave oven can cause interference to your radio, TV or similar equipment.
When there is interference, it may be reduced or eliminated by taking the following measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or television.
3. Relocate the microwave oven with respect to the receiver.
4. Move the microwave oven away from the receiver.
5. Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch
circuits.
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 3

Microwave Oven
SMW 2717
EN
EN-4
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND SAFE FOR FUTURE REFERENCE
When using electrical appliance basic safety precautions should be followed, including the following:
WARNING: To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
1. Read all instructions before using the appliance.
2. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or
vapors in this appliance. This type of oven is specifically designed to heat, cook or dry food. It is not
designed for industrial or laboratory use.
3. Do not operate the oven when empty.
4. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has
been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
5. WARNING: Only allow children to use the oven without supervision when adequate instructions have
been given so that the child is able to use the oven in a safe way and understands the hazards of
improper use.
6. CAUTION: If the door or the door seal is damaged, do not use the oven until it is repaired by authorized
service centre or similarly qualified technician.
7. WARNING: It is hazardous for anyone other than a trained person to carry out any sevice or repair
operation which involves the removal of any cover which gives protection against exposure to microwave
energy.
8. To reduce the risk of fire in the oven cavity:
When heating food in plastic or paper container, keep an eye on the oven due to the possibility of
ignition.
Remove wire twist-ties from paper or plastic bags before placing bag in oven.
9. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to
stifle any flames.
10. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food in the
cavity when not in use.
11. WARNING: Liquid or other food must not be heated in sealed containers since they are liable to explode.
12. Microwave heating of beverage can result in delayed eruptive boiling, therefore care has to be taken
when handle the container.
13. Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in skin burns.
14. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may
explode even after microwave heating has ended.
15. Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts before cooking.
16. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be
checked before serving in order to avoid burns.
17. Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be
needed to handle the utensil.
18. Utensils should be checked to ensure that they are suitable for use in microwave oven.
MICROWAVE COOKING PRINCIPLES
1. Arrange food carefully. Place thickest areas towards outside of dish.
2. Do not cook food directly on the glass tray. Place food in/ on proper cooking utensil before placing in the
oven.
3. Watch cooking time. Cook for the shortest amount of time indicated and add more as needed. Food
severely overcooked can smoke or ignite.
4. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.
5. Turn foods over once during microwaving to speed cooking of such foods as chicken and hamburgers.
Large items like roasts must be turned over at least once.
6. Rearrange foods such as meatballs halfway through cooking both from top to bottom and from the
center of the dish to the outside.
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 4

Microwave Oven
SMW 2717
EN
EN-5
UTENSILS GUIDE
1. The ideal material for a microwave utensil is transparent to microwave, it allows energy to pass through the
container and heat the food.
2. Microwave can not penetrate metal, so metal utensils or dishes with metallic trim should not be used.
3. Do not use recycled paper products when microwave cooking, as they may contain small metal fragments
which may cause sparks and/or fires.
4. Round /oval dishes rather than square/oblong ones are recommend, as food in corners tends to overcook.
5. Microwave utensils should be used only in accorgance with manufactureręs instructions.
The list below is a general guide to help you select the correct utensils.
PART NAMES
1. Door Safety Lock
System
2. Oven Window
3. Wave Guide
4. Roller Ring
5. Glass Tray
6. Control Panel
COOKWARE MICROWAVE
Heat–Resistant Glass Yes
Non Heat–Resistant Glass No
Heat–Resistant Ceramics Yes
Microwave–Safe Plastic Dish Yes
Kitchen Paper Yes
Metal Tray No
Metal Rack No
Aluminum Foil & Foil Containers No
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 5

Microwave Oven
SMW 2717
EN
EN-6
CONTROL PANEL
Microwave oven performance level setting
– see upper control button on the picture.
HIGH 100% Power Output
M-HIGH 85% Power Output
MED 66% Power Output
M-LOW 48% Power Output
DEFROST 40% Power Output
LOW 17% Power Output
Timer (from 0 to 30 minutes)
– see lower control button on the picture.
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 6

Microwave Oven
SMW 2717
EN
EN-7
OPERATION
To set a cooking program: place food in oven and close the door.
Turn Power Select Control Use Timer to select
to needed power level. correct cooking time.
Firstly, set the required performance level and then select the required cooking time.
NOTE: As soon as the timer is turned, oven will start cooking. When selecting time for less than
2 minutes, turn timer past 2 minutes and then return to the correct time.
CAUTION: ALWAYS RETURN TIMER BACK TO ZERO POSITION if food is removed from oven before the set
cooking time is complete or when oven is not in use. To stop oven during cooking process, push
the door release button and open the door.
CLEANING AND CARE
1. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with
a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray and other
harsh cleaners as they may stain, streak or dull the door surface.
2. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating parts
inside the oven, water should not be allowed to seep into the ventilation openings.
3. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth
to remove any spills or spatters. Do not use abrasive cleaner.
4. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the control
panel, leave oven door open to prevent oven from accidentally turning on.
5. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity conditions, this is normal.
6. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in
a dishwasher.
7. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild sudsy water or
dishwasher. When removing the roller ring from cavity floor for cleaning, be sure to replace in the proper
position.
8. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon
in a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
9. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
10. The oven should be cleaned regulary and any food deposits removed. Failure to maintain the oven in
a clean condition could lead to deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 7

Microwave Oven
SMW 2717
EN
Used packaging material instructions
Dispose of used packaging material properly. Use only authorized waste management and collection centre in
your location.
Disposal of Used Electrical & Electronic Equipment
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this equipment at your applicable
collection point for the recycling of electrical & electronic equipments waste. In the European
Union and Other European countries which there are separate collection systems for used
electrical and electronic product. By ensuring the correct disposal of this product, you will help
prevent potentially hazardous to the environment and to human health, which could otherwise be
caused by unsuitable waste handling of this product. The recycling of materials will help conserve
natural resources. Please do not therefore dispose of your old electrical and electronic equipment
with your household waste. For more detailed information about recycling of this product, please
contact your local city office, your household waste disposal service or the shop where you
purchased the product.
This product complies with all essential rules applicable to it.
EN-8
35985_SMW_2717_EN.qxd 15.1.2007 9:11 Str. 8

CZ-1
SMW 2717
Mikrovlnná trouba
NÁVOD K POUŽITÍ
CZ
Před instalací a použitím trouby si prosím pozorně přečtěte tento návod k obsluze. Manuál si uschovejte
k pozdějšímu nahlédnutí.
35985_SMW_2717_CZ-SK-HU-PL.qxd 15.1.2007 9:13 Str. 1

Mikrovlnná trouba
SMW 2717
CZ
CZ-2
OBSAH
Upozornění, jak se vyvarovat možnému vlivu přebytečné energie mikrovln . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technické údaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Než zavoláte do servisu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Instalace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Instrukce k uzemnění. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rádiové rušení . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Důležité bezpečnostní instrukce. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Zásady vaření v mikrovlnné troubě. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nádobí . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Názvy částí . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ovládací panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Jak troubu nastavit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Čištění . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Likvidace použitých elektrických a elektronických zařízení . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
BEZPEČNOSTNÍ OPATŘENÍ PRO ZABRÁNĚNÍ MOŽNÉMU RIZIKU VYSTAVENÍ
MIKROVLNNÉ ENERGII
1. Nepokoušejte se používat tuto troubu při otevřených dvířkách - mohli byste se vystavit škodlivému působení
mikrovln. Je důležité abyste nepoškodili či neupravovali bezpečnostní zámky dvířek mikrovlné trouby.
2. Neblokujte přední část trouby a dvířka jakýmkoliv předmětem a dbejte na to aby se na částech trouby
s těsněním nekupila špína nebo zbytky čistícího prostředku.
3. Nepoužívejte troubu jestliže je poškozená. Je nadmíru důležité aby se dveře trouby náležitě zavíraly a aby
nebyly poškozeny následující části:
• Dveře (aby nebyly prohnuty)
• Závěsy dveří a zámky (poškozené nebo uvolněné)
• Těsnění dveří a dalších částí.
4. Trouba smí být seřizována nebo opravována pouze kvalifikovaným servisním technikem.
TECHNICKÉ ÚDAJE
Spotřeba: 230 V~50 Hz, 1200 W
Výkon: 700 W
Frekvence: 2450 MHz
Vnější rozměry: 262 mm (V) x 452 mm (Š) x 335 mm (H)
Objem: 17 litrů
Vaření: Otočný talíř {쏗245 mm}
Hmotnost: cca.10,5 kg
Hlučnost: 57 dB
POZNÁMKA: Výše uvedená data podléhají změnám.
35985_SMW_2717_CZ-SK-HU-PL.qxd 15.1.2007 9:13 Str. 2
