Seneca USB-ISO User manual

ENGLISH - 1/3
MI005210-E THE ORIGINAL IS IN ITALIAN
This document is property of SENECA Srl. Duplication and reproduction are forbidden, if not authorized.
Contents of the present documentation refers to products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial requirements.
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
Tel. [phone] - Fax [phone]
Manuals and configuration software are available at website: www.seneca.it/products/usb-iso
INSTALLATION MANUAL
USB-ISO
USB galvanic insulator
EN
EN

ENGLISH - 2/3
POWER SUPPLY
5 V – 1 A
INSULATION
ENVIRONMENTAL
CONDITION
Temperature: 0 + 50°C–
Humidity: 30% – ing.90% non condens
–Storage temperature: -20 + 65°C
MAXIMUM DATA
TRANSFER SPEED
12 Mbps
TECHNICAL SPECIFICATIONS
MODULE LAYOUT
weight
25 g.
Case
Material ABS, black.
Power
Supply
2ac500 V
5 V 1 A/
M USBicro
to PC
USB
to device
PRELIMINARY WARNINGS
20,6 mm
50,7 mm
43 mm
WARNING: Before performing any operation it is mandatory to read the full contents of this manual.
The module must only be used by qualified and skilled technicians in the field of electric installation.
www.seneca.it\products\r-16di-8do.Specific documentation is available for download from website:
The symbol with the word .!WARNING identifies conditions and actions that pose hazard(s) to the user
The symbol with the word identifies conditions and actions that may damage the device or the equipements
!CAUTION
connected.
The warranty is null and void in case of improper use or tampering of the device or accessories supplied by the
manufacturer necessary for its correct operation and if the instructions in this manual are not followed.
Only the Manufacturer is authorized to repair the module or to replace damaged parts.
Theproductissusceptibletoelectrostaticdischarge,takeappropriatecountermeasuresduringanyoperation.
CAUTION: device .It is forbidden to install the near heat sources
Disposal of electrical & electronic equipment (applicable throughout the EU and other
countries with separate collection programs). found on this product or on itsThe symbol
packaging indicates that this product it must be handed over to,a collection point authorized to
recycle electrical and electronic equipment.

ENGLISH - 3/3
CONNECTIONS
LED POWER
MINI USB TO PC
MICRO USB POWER SUPPLY USB TO DEVICE
MSC
CONTACTS
WARNING
If you need to use USB-ISO isolator with the MSC calibrator please use the power supply (MSC-POWER)
supplied with the MSC calibrator in order to avoid reading errors or malfunction of the instrument.
POWER SUPPLY
MSC-POWER
ACCESSORIES
20 21
19
23 24
22 11 12
10
Z-GPRS3
MSC-POWER
PRODUCT DESCRIPTION
USB-ISO is a USB port isolator with external power supply, capable of providing power to an USB device up to 1A.
This isolator allows you to avoid "groung-loop" between PC and USB devices connected and/or to protect the PC
from any surges applied to the USB device. USB-ISO can also be used as an amplifier to extend USB connections.
This device is galvanically isolated in 2 ways up to 2.5 kVac and has a LED status indicator for power supply.
It is equipped with USB-A port (towards your USB instrument), micro USB port (towards the power supply),
and mini USB port (towards your PC workstation). USB-ISO is mandatory if you need to connect multiple MSC
calibrators to the same workstation (one isolator per calibrator). If you need to use it with MSC calibrator, in
order to avoid measuring problems, is mandatory to use the power supply (MSC-POWER) supplied with the
MSC calibrator.
Technical support
[email protected]
Product Informations
[email protected]
