Z01-A19NAE26
LED Wireless A19 Bulb
User Manual
LED + Smart Control

Features
•
•
•
•
•
•
EN
On/Off and dimming via mobile app, home hub display,
as well as web portal.
Report the current power consumption.
Independent color temperature tuning from 2700 to 6500K.
Compatible with major wall dimmer (See Appendix:Compati-
ble wall dimmer list).
Compatible with most smart home hubs supporting Zigbee
HA 1.2.1 to control lighting schedules rules, and more.
Zigbee Alliance certified.
Product Specifications
•
•
•
•
•
•
•
•
•
•
Model: Z01-A19NAE26
Power: 9.8 W
Brightness: 800 lumens
Beam Angle: 270°
Input: 100-120 V AC, 60 Hz, 88 mA
Light Socket: E26
Operating Temperature: -4 °F ~ + 104 °F (-20 °C ~ + 40 °C)
Storage Temperature: -40 °F ~ + 158 °F (-40 °C ~ +70 °C)
Operating Humidity: 0 ≤RH ≤95%, non-condensing
Dimensions: Dia: 2.4 in (60mm); H: 4.6 in (117mm)
Installation Instructions
Adding the bulb to any smart home hub involves the following
two steps:
Step 1: Prepare the bulb to enter pairing mode.
• Turn the light switch to OFF position prior to installing the LED
bulb, then screw the bulb into a standard light socket and turn
the switch on.
• Brand new bulbs right out of the box will automatically enter
pairing mode for three minutes upon power on. If one misses
the three-minute window, power cycle the bulb will bring
back the pairing mode for another three minutes.
• If one is unsure if the bulb is in pairing mode, factory reset the
bulb to restart the pairing mode.
Step 2: Scan and pair the bulb from smart home hub via mobile
device App or hub control panel. Please read the instructions
provided by the specific hub system on how to complete pairing
with the bulb.
Package Includes
•
•
One Z01-A19NAE26 A19 Bulb
Welcome card containing online user manual

Operations of the bulb
•
•
•
•
•
Dimming and on/off control
Use the mobile app or home hub panel to control on/off and
dimming
Rejoin wireless network from the bulb
Power cycle the bulb (off then back on) five times quickly.
The bulb will blink two times indicating network rejoin.
Factory default reset
Power cycle the bulb (off then back on) quickly for at
minimum ten times.The bulb will blink five times indicating
pairing mode.
EZ-Mode commissioning from the bulb:
Power cycle the bulb (off then back on) seven times quickly
to enable EZ-Mode. The bulb will blink to indicate that it is in
this mode for three minutes. To exit this mode earlier, power
off the bulb via the wall switch, wait for two seconds and
then power it back on.
Setting the bulb’s dim level via wall switch:
Enable dimming by powering the bulb off and then on
within one second. The light will gradually change from its
current brightness setting to the maximum. Following this,
the brightness will change from the maximum to the
minimum and finally back to the maximum again. When the
brightness is changing, power off the bulb when the bulb
reaches the desired dim level. Power the bulb back on and
the bulb should now be set to the new dim level. If no power
off action is taken, the light will remain at maximum
brightness level.
EN
Troubleshoot the device
•
•
•
•
•
•
Having trouble pairing with the hub?
Try moving the bulb to a location closer to the hub.
Remove obstacles or other wireless devices between the
bulb and the hub.
Ensure neither the bulb nor the hub is located near
other wireless devices such as a Wi-Fi access point/router.
After factory resetting a bulb, it will stay in pairing mode for
only the next three minutes. You may re-trigger pairing mode
by simply power cycling the bulb once.
Bulb was communicating with the hub, but hub
eventually loses control of the bulb.
Check if the power cord to the bulb has been disconnected or
if the power switch is in the OFF position.
Power cycle the bulb using the wall switch. The bulb should
rejoin the hub automatically.
If the previous steps do not resolve the problem, delete the
bulb from the hub, then follow the installation
instructions above to add the bulb again to the hub.

EN
Important Safety Instructions
© 2017 Sengled, Incorporated. All rights reserved. Sengled
Element is a trademark of Sengled, Incorporated, registered in
the United States and other countries. Specifications are
subject to change without notice. Other trademarks and trade
names are the property of their respective owners.
•
•
•
NOT FOR EMERGENCY LIGHTING
RISK OF ELECTRIC SHOCK-DO NOT USE WHERE DIRECTLY
EXPOSED TO WATER
This product is intended for indoor use only
FCC ID：2ABX8SH-000000010 IC：12219A-00000000010

Appendix: Compatible wall dimmer list
No. Company Name Part Number
1 LUTRON MAELV-600
2 LUTRON MACL-153M
3 LUTRON PD-6WCL
4 LUTRON LGCL-153PLH
5 LUTRON TG-603PGH
6 LUTRON TG-600PH
7 LUTRON TT-300NLH
8 LUTRON TTCL-100H
9 LUTRON NLV-600
10 LUTRON D-600PH-DK
11 LUTRON D-603PGH-DK
12 LUTRON AY-600P
13 LUTRON VTELV-600M-B
14 LUTRON RRD-6NA
15 LUTRON CTELV-303P
16 LUTRON CTCL-153P
17 LUTRON S-600P
18 LUTRON S-603PG
19 LUTRON SELVB-300P
20 LUTRON SELV-300P
21 LUTRON S-600H
22 LUTRON LX-600PL
23 LUTRON LXLV-603PL
24 LUTRON DVLV-600P
25 LUTRON DVELV-303P
26 LUTRON DVELV-300P
27 LUTRON DV-600P
28 LUTRON DVCL-153P
29 LEVITON 6674-P0W
30 LEVITON 6633-P
31 LEVITON 6613-PLW
32 LEVITON 6672
33 LEVITON 6615
34 LEVITON 6631
35 LEVITON 6681-1W
36 LEVITON 6602-IW
37 LEVITON 6683-10Z
38 LEVITON RPI06
39 LEVITON 6161
40 LEVITON IPI06-1LZ
41 LEVITON TBL03
42 GE 18023
43 GE 0747
* Sengled laboratory test data for reference only

Rev 1.0 2017.08
