Senna MASTERPIECE Installation and operation manual

User Manuals
1. Introduction
1.1. Specifications:
MASTERPIECE - LED PANEL
Parameter
Value
Series
Masterpiece
LED configuration
Full RGB + W + W
Dimensions
1100 x 1070 mm
Weight
34 kg
Light aperture
1000 x 1020 mm
Voltage input
48 Vdc +/- 5%
Power consumption
2800W maximum
Unit power connection :
WEIPU 32 series 4 pin
Dimming
0% to 100% continuous
Flicker
flicker free 10% to 100%
Color temperature
2000K –20.000K
Control
Full on board touch screen/wired DMX/LumenRadio CRMX wireless
Beam angle
60° (half peak angle), 15° with optical lens (included)
Color rendering
CRI average > 95
IP rating
IP20
Operation temperature-
Max. power: -20°C to + 30°C; 70% power: >+30°C

User Manuals
MASTERPIECE - POWER SUPPLY
Parameter
Value
Series
PS3000
Dimension
420 x 210 x 175 mm
Weight
approx. 12kg
Input range
100 to 240Vac, 50/60HZ, 3300VA max
Output range
48 Vdc, 64A, 3000VA max
Power input connection
NEUTRIK power CON 16A / Schuko (EU), 2meter
Power output connection
WEIPU 32 series 4pin
Operation temperature
-20°C to + 35°C
1.2. Photometrics
1.3. Components
1. Light fixture
2. Stand adapter
3. Power supply
4. Cabling
5. Grid
6. 2 diffusors
7. 15° optics (16 segments)
8. Rain cover
9. Flight case
Photometrics (lux) 60° lens (Device: Sekonic Spectromaster C-700)
Distance
3200K
5600K
4600K
Red
Green
Blue
1m
129 000
148 000
144 000
13 700
22 300
6 240
3m
25 400
29 500
29 100
2 090
4 190
1 210
5m
10 400
11 900
11 900
843
1 680
483
10m
2 800
3 240
3 200
213
437
126
30m
283
317
318
19.2
36.8
11.3
Photometrics (lux) 15° lens (Device: Sekonic Spectromaster C-700)
Distance
3200K
5600K
4600K
Red
Green
Blue
1m
122 000
132 000
132 000
11 400
20 800
6 140
3m
51 700
57 100
57 300
5 410
8 640
2 430
5m
26 700
29 990
29 800
3 550
4 930
1 330
10m
8 020
8 710
8 900
1 400
1 770
450
30m
1 002
1 010
1 010
211
238
59

User Manuals
2. Manual control of Masterpiece
2.1. Masterpiece dashboard
2.2. Getting started
1. Connect the Masterpiece with power supply box with the enclosed cable.
2. Turn the power supply on.
Power supply display
Masterpiece display
3. The display of power supply will show voltage, current, power and energy consumption (see
the picture above)

User Manuals
4. The display 1 on the Masterpiece control board will show introduction message. The QR code
on the introduction message takes you to www.senna.hr where you can find more info about
Masterpiece.
5. After 10 seconds Main Menu will show on Masterpiece display.
6. These User Manuals are available on Masterpiece display 2. Touch the screen to navigate the
Manuals.
3. The Menu
There are 8 modes available in the
Menu:
1. CCT
2. RGBW
3. HIS
4. GEL
5. XY
6. Effects
7. Settings
8. DMX
-To choose any of these modes simply touch the screen. The icon of the mode you have
selected will turn green.
-In the right down angle there are 2 icons:
Touch to lock/turn off the screen. To turn the screen on again, touch the
screen or turn any knob.
Touch to change the level of fan speed to FULL, HALF or OFF.
Selected level will turn green.

User Manuals
3.1. CCT
1. To choose CCT mode simply touch the CCT icon in the left menu in the screen. The icon will
turn green.
2. There are CCT and CCT+ option for your selection. Touch the screen to choose one. The icon
will turn green.
CCT mode provides temperature range from 2.700K to 20.000K (temporary unavailable!)
CCT+ mode provides temperature range from 3.000K to 6.000K
3. To make adjustments of dimmer, temperature and green/magenta point, you can slide your
finger along the lines or use regulation knobs on the right side of the display:
-Use regulation knob 1 to adjust dimmer
-Use regulation knob 2 to adjust temperature
-Use regulation knob 3 to adjust green/magenta
4. To save the adjustments you have made as a memory pre-set simply touch one of 6 memory
buttons at the bottom of the screen. The number of saved memory pre-set will turn green.
3.2. RGBW

User Manuals
1. To choose RGBW mode simply touch the RGBW icon in the left menu in the screen. The icon
will turn green.
2. To select a colour (Red, Green, Blue, White, Worm) you want to adjust, simply touch the icon
with a color, or use regulation knob 3 (select).
The icon of the colour you have selected will get white frame.
3. To adjust dimmer of a selected color –use regulation knob 2 (single color)
Dimmer percentage will show on the selected color icon.
4. To adjust dimmer in general –use regulation knob 1 (dimmer)
General dimmer percentage will show in the right upper corner of the display.
Please note! General dimmer is limited to 2.8kW power consumption. If you turn all colors
to intensity of 100%, general dimmer will not be 100%, it will get lower in order to maintain
power consumption of 2.8kW.
5. To save the adjustments you have made as a memory pre-set simply touch one of 6 memory
buttons at the bottom of the screen. The number of saved memory pre-set will turn green.
3.3. HIS
1. To choose HSI mode simply touch the HSI icon in the left menu in the screen. The icon will
turn green.
2. To make adjustments of dimmer, hue and saturation you can slide your finger along the lines
or use regulation knobs on the right side of the display:
-Use regulation knob 1 to adjust Dimmer
-Use regulation knob 2 to adjust Hue
-Use regulation knob 3 to adjust Saturation
3. To save the adjustments you have made as a memory pre-set simply touch one of 6 memory
buttons at the bottom of the screen. The number of saved memory pre-set will turn green.

User Manuals
3.4. Gel
1. To choose Gel mode simply touch the Gel icon in the left menu in the screen. The icon will
turn green.
2. There are 3 Gel groups available in this mode:
1. Lee Color correction
2. Lee Filters Color
3. Rosco Color
To select one of these groups simply touch its icon. The icon will turn green.
3. Each of the 3 gel groups has different gels for your selection. Choose any of them by touching
its icon or using the regulation knob 3 (Select)
4. Use regulation knob 1 to adjust Dimmer
5. Use regulation knob 2 to adjust color temperature Base (from 3.200K to 5.600K)
6. To save the adjustments you have made as a memory pre-set simply touch one of 6 memory
buttons at the bottom of the screen. The number of saved memory pre-set will turn green.

User Manuals
3.5. XY - This mode will be available soon!
3.6. Effects
1. To choose Effect mode simply touch the Effect icon in the left menu in the screen. The icon
will turn green.
2. There are 5 groups of effects available in this mode:
1. Basic - TV, Welding, Paparazzi, Kachusha, Fireworks, Explosion, Test
2. Natural - Lightning, Fire single, Fire Multi, Candles, Clouds, Comet, Sunrise, Sunset,
Aurora
3. Warning - Police, Security, Warning, Fireman
4. Party –Color Chase, Strobe, Disco ball
5. Travel - Snake, Snake Reverse, Snake White
To select one of these effects simply touch its icon.
The icon will turn green, and the effect will perform.
3. Use regulation knob 1 to adjust Dimmer
4. Use regulation knob 2 to adjust color temperature
5. Use regulation knob 2 to adjust the speed of effect
3.7. Settings

User Manuals
7. To choose Settings mode simply touch the Settings icon in the left menu in the screen. The
icon will turn green.
8. Display will show these settings:
-Timer
-Sound/Light
-Lumen radio
3.7.1. Timer
To enter timer settings simply touch its icon. Display will show 2 timers:
-General time –shows total time the fixture has been used. This timer cannot be reset!
-User Time –shows time the fixture has been used since last reset of the timer.
To reset User Timer, please follow the steps:
1. Touch the User Timer.
2. You will be asked to enter 4 digits PIN.
3. After you have entered correct pin, press OK
4. User Timer will be set to 00:00
To go back to Settings, simply touch the Settings icon on the left.
3.7.2. Sound/Light
To enter Sound settings simply touch its icon. Display will show 2 settings:
-Volume - If you turn the volume up, the voice will pronounce every command you select in
the menu.
-Logo light –with this command you can adjust the intensity of Masterpiece logo light at the
back side of the Masterpiece body.

User Manuals
To adjust the level of volume and logo light simply slide along the line with your finger.
To go back to Settings, simply touch the Settings icon on the left.
3.7.3. Lumen Radio
Lumen Radio settings enable you to UNLINK Masterpiece from your lumen radio devise.
To do that, please follow the steps:
1. Enter Lumen radio settings by touching its icon. The icon will turn green.
2. Display will show the UNLINK button.
3. Touch UNLINK button.
4. Lumen radio is unlinked.

User Manuals
3.8. DMX
To enter RGBWW mode simply touch the RGBW icon in the left menu. The icon will turn green and
display will show these information:
1. First thing you need to do is to set the range of operation, by choosing the segment(s) of
Masterpiece you want to control separately. You can do that by touching the parts in the
picture (below). Selected segment will turn white:
Control the whole fixture
6 DMX channels in use
Control 2 segments of the
fixture separately
13 DMX Channels in use
Control 4 segments of the
fixture separately
25 DMX Channels in use
Control 16 segments of the
fixture separately
97 DMX Channels in use
2. Set DMX address by touching + - buttons
To set and lock DMX address, turn the
knob 1 until you reach desirable
number and then press knob 1 to lock
your selection. Number will turn green
and you will not be able to change it
with +- buttons.
To unlock the address, press knob 1
once more.

User Manuals
3. Select Dimmer mode. There are 4 dimmer modes available for your selection.
1. Linear
2. Exponent (temporary not available)
3. Logarithm (temporary not available)
4. S curve (temporary not available)
You can select one of these by touching the icon or using the navigation knob 3. Selected
icon will turn green.
4. Now you can select the mode of operation by touching UP or DOWN button or using the
navigation knob 2. Selected icon will turn green.
There are 5 model available:
1. CCT 8 bit
2. RGBW 8 bit
3. HSI 8 bit
4. GEL
5. ULTIMATE 8 bit
3.8.1. CCT DMX Channel Chart
1 Segment Control
2 Segments Control
4 Segments Control
1. Dimmer
2. Color temperature
3. Green/Magenta point
1. General Dimmer
2. Dimmer
3. Color temperature
4. Green/Magenta point
5. Dimmer
6. Color temperature
7. Green/Magenta point
1. General Dimmer
2. Dimmer
3. Color temperature
4. Green/Magenta point
5. Dimmer
6. Color temperature
7. Green/Magenta point
8. Dimmer
9. Color temperature
10. Green/Magenta point
11. Dimmer
12. Color temperature
13. Green/Magenta point

User Manuals
16 Segments Control
1. General Dimmer
2. Dimmer
3. Color temperature
4. Green/Magenta point
5. Dimmer
6. Color temperature
7. Green/Magenta point
8. Dimmer
9. Color temperature
10. Green/Magenta point
11. Dimmer
12. Color temperature
13. Green/Magenta point
14. Dimmer
15. Color temperature
16. Green/Magenta point
17. Dimmer
18. Color temperature
19. Green/Magenta point
20. Dimmer
21. Color temperature
22. Green/Magenta point
23. Dimmer
24. Color temperature
25. Green/Magenta point
26. Dimmer
27. Color temperature
28. Green/Magenta point
29. Dimmer
30. Color temperature
31. Green/Magenta point
32. Dimmer
33. Color temperature
34. Green/Magenta point
35. Dimmer
36. Color temperature
37. Green/Magenta point
38. Dimmer
39. Color temperature
40. Green/Magenta point
41. Dimmer
42. Color temperature
43. Green/Magenta point
44. Dimmer
45. Color temperature
46. Green/Magenta point
47. Dimmer
48. Color temperature
49. Green/Magenta point
3.8.2. RGBWW DMX Channel Chart
1 Segment control
2 Segments control
4 Segments control
50. Dimmer
51. RED dimmer
52. GREEN dimmer
53. BLUE dimmer
54. WHITE dimmer
55. WORM dimmer
8. General Dimmer
9. Dimmer
10. RED dimmer
11. GREEN dimmer
12. BLUE dimmer
13. WHITE dimmer
14. WORM dimmer
15. Dimmer
16. RED dimmer
17. GREEN dimmer
18. BLUE dimmer
19. WHITE dimmer
20. WORM dimmer
14. General Dimmer
15. Dimmer
16. RED dimmer
17. GREEN dimmer
18. BLUE dimmer
19. WHITE dimmer
20. WORM dimmer
21. Dimmer
22. RED dimmer
23. GREEN dimmer
24. BLUE dimmer
25. WHITE dimmer
26. WORM dimmer
27. Dimmer
28. RED dimmer
29. GREEN dimmer
30. BLUE dimmer
31. WHITE dimmer
32. WORM dimmer
33. Dimmer
34. RED dimmer
35. GREEN dimmer
36. BLUE dimmer
37. WHITE dimmer
38. WORM dimmer

User Manuals
16 Segments Control
1. General dimmer
2. Dimmer
3. RED dimmer
4. GREEN dimmer
5. BLUE dimmer
6. WHITE dimmer
7. WORM dimmer
8. Dimmer
9. RED dimmer
10. GREEN dimmer
11. BLUE dimmer
12. WHITE dimmer
13. WORM dimmer
14. Dimmer
15. RED dimmer
16. GREEN dimmer
17. BLUE dimmer
18. WHITE dimmer
19. WORM dimmer
20. Dimmer
21. RED dimmer
22. GREEN dimmer
23. BLUE dimmer
24. WHITE dimmer
25. WORM Dimmer
26. Dimmer
27. RED dimmer
28. GREEN dimmer
29. BLUE dimmer
30. WHITE dimmer
31. WORM dimmer
32. Dimmer
33. RED dimmer
34. GREEN dimmer
35. BLUE dimmer
36. WHITE dimmer
37. WORM dimmer
38. Dimmer
39. RED dimmer
40. GREEN dimmer
41. BLUE dimmer
42. WHITE dimmer
43. WORM dimmer
44. Dimmer
45. RED dimmer
46. GREEN dimmer
47. BLUE dimmer
48. WHITE dimmer
49. WORM Dimmer
50. Dimmer
51. RED dimmer
52. GREEN dimmer
53. BLUE dimmer
54. WHITE dimmer
55. WORM dimmer
56. Dimmer
57. RED dimmer
58. GREEN dimmer
59. BLUE dimmer
60. WHITE dimmer
61. WORM dimmer
62. Dimmer
63. RED dimmer
64. GREEN dimmer
65. BLUE dimmer
66. WHITE dimmer
67. WORM dimmer
68. Dimmer
69. RED dimmer
70. GREEN dimmer
71. BLUE dimmer
72. WHITE dimmer
73. WORM dimmer
74. Dimmer
75. RED dimmer
76. GREEN dimmer
77. BLUE dimmer
78. WHITE dimmer
79. WORM dimmer
80. Dimmer
81. RED dimmer
82. GREEN dimmer
83. BLUE dimmer
84. WHITE dimmer
85. WORM dimmer
86. Dimmer
87. RED dimmer
88. GREEN dimmer
89. BLUE dimmer
90. WHITE dimmer
91. WORM dimmer
92. Dimmer
93. RED dimmer
94. GREEN dimmer
95. BLUE dimmer
96. WHITE dimmer
97. WORM dimmer
3.8.3. HIS DMX Channel Chart
1 Segment Control
2 Segments Control
4 Segments Control
1. Dimmer
2. Hue
3. Saturation
1. General Dimmer
2. Dimmer
3. Hue
4. Saturation
5. Dimmer
6. Hue
7. Saturation
1. General Dimmer
2. Dimmer
3. Hue
4. Saturation
5. Dimmer
6. Hue
7. Saturation
8. Dimmer
9. Hue
10. Saturation
11. Dimmer
12. Hue
13. Saturation

User Manuals
16 Segments Control
1. General Dimmer
2. Dimmer
3. Hue
4. Saturation
5. Dimmer
6. Hue
7. Saturation
8. Dimmer
9. Hue
10. Saturation
11. Dimmer
12. Hue
13. Saturation
14. Dimmer
15. Hue
16. Saturation
17. Dimmer
18. Hue
19. Saturation
20. Dimmer
21. Hue
22. Saturation
23. Dimmer
24. Hue
25. Saturation
26. Dimmer
27. Hue
28. Saturation
29. Dimmer
30. Hue
31. Saturation
32. Dimmer
33. Hue
34. Saturation
35. Dimmer
36. Hue
37. Saturation
38. Dimmer
39. Hue
40. Saturation
41. Dimmer
42. Hue
43. Saturation
44. Dimmer
45. Hue
46. Saturation
47. Dimmer
48. Hue
49. Saturation
3.8.4. GEL DMX Channel Chart
1 Segment control
1. Channel –Dimmer
2. Channel –Color temperature base
3. Channel –1 group (Lee Color Correction)Gel selection –range 5-104
4. Channel –2 group (Lee Filter Color)Gel selection–range 5-94
5. Channel –3 group (Rosco Color)Gel selection –range 5-99
3.8.4.1. GEL Groups Charts
Group 1 - Lee Color Correction
Gel range
Gel Name
Gel Number
5-9
Eighth 1/8 CTO
223
10-14
Quarter 1/4 CTO
206
15-19
Half 1/2 CTO
205
20-24
Three quarters 3/4CTO
285
25-29
Full 1/1 CTO
204
30-34
Double 2/1 CTO
287
35-39
Eighth 1/8 CTB
218
40-44
Quarter 1/4 CTB
203
45-49
Half 1/2 CTB
202

User Manuals
50-54
Three quarters 3/4 CTB
281
55-59
Full 1/1 CTB
201
60-64
Double 2/1 CTB
200
65-69
Plus Green 1/8
278
70-74
Plus Green 1/4
246
75-79
Plus Green 1/2
245
80-84
Plus Green 1/1
244
85-89
Minus Green 1/8
279
90-94
Minus Green 1/4
249
95-99
Minus Green 1/2
248
100-104
Minus Green 1/1
247
105-109
Fluorescent 5700K
241
110-104
Fluorescent 4300K
242
Group 2- Lee Filters Color
Gel range
Gel Name
Gel Number
5-9
Rose Pink
2
10-14
Dark Magenta
46
15-19
Lavender
58
20-24
Pale Blue
63
25-29
Sky Blue
68
30-34
Evening Blue
75
35-39
Moss Green
89
40-44
Dark Yellow Green
90
45-49
Bright Pink
128
50-54
Deep Blue
120
55-59
Yellow
101
60-64
Golden Amber
134
65-69
Apricot
147
70-74
Fire
19
75-79
Cosmetic Peach
184
80-84
Industry Sodium
650
85-89
Sodium
651
90-94
Urban Sodium
652

User Manuals
Group 3- Rosco Color
Gel range
Gel Name
Gel Number
5-9
30 Magenta
4730
10-14
60 Magenta
4760
15-19
90 Magenta
4790
20-24
15 Cyan
4315
25-29
30 Cyan
4330
30-34
60 Cyan
4360
35-39
90 Cyan
4390
40-44
30 Green
4430
45-49
60 Green
4460
50-54
90 Green
4490
55-59
15 Yellow
4515
60-64
30 Yellow
4530
65-69
60 Yellow
4560
70-74
Salmon
R41
75-79
Deep Salmon
R42
80-84
Middle Rose
R44
85-89
Daylight Blue
R65
90-94
Green Blue
R77
95-99
Primary Blue
R80
3.8.5. DMX - Ultimate mode
Ultimate mode enables you to control all the modes at once with your DMX control plate.
To select the Ultimate mode touch UP or DOWN button or use the navigation knob 2 until you reach
Ultimate mode icon. Selected icon will turn green.
Once Ultimate mode is selected, the channels on your DMX control plate will control:
Channel
Modes
1. Channel
All modes - general dimmer
2. Channel
Mode selection :
-CCT (Channel 1-9)
-HSI (Channel 10-19)
-RGBWW (Channel 20-29)
-GEL (Channel 30-39)
3. Channel
-For CCT mode –color temperature
-For HSI mode –HUE

User Manuals
-For RGBWW–RED dimmer
-For GEL –Color Temp. base selection
4. Channel
-For CCT mode –Green/Magenta
-For HSI mode –Saturation
-For RGBWW –GREEN dimmer
-For GEL –Gel selection (Group 1)
5. Channel
-For RGBWW –BLUE dimmer
-For GEL –Gel selection (Group 2)
6. Channel
-For RGBWW –WHITE dimmer
-For GEL –Gel selection (Group 3)
-For EFFECTS - Effect selection
7. Channel
-For RGBWW –WORM dimmer
4. Controlling Masterpiece with SkyBeast console
4.1. Pairing your devices
To be able to control your Masterpiece with SkyBeast console, you should first pair these two
devices.
Here are the settings you need to make on your Masterpiece:
1. Select DMX mode on your Masterpiece
2. Select Ultimate mode (8 bit or 16 bit)
3. Set Lumen radio –ON
4. Select desirable DMX channel of your Masterpiece.
Pay attention that the number of DMX channel selected on your Masterpiece must match
the number of the selected bank on your SkyBeast console!
The picture below shows the necessary selections:

User Manuals
Here are the settings you need to make on your SkyBeast:
Pres and hold the Menu button for
5 seconds to enter the menu
Use General Master (-) and Mode
Select (+)buttons to navigate the
menu until your reach command
Link Lumenradio
Press Menu button shortly to
confirm selection
Display will show Linking
LumenRadio…
When display returns to settings
LumenRadio is linked.
Press and hold Menu button for 5
sec to enter the Menu once again
Use General Master (-) and Mode
Select (+)buttons to navigate the
menu until your reach command
Masterpiece by Senna
Press Menu button shortly to
confirm selection
Display will show Masterpiece
selected
When display shows DMX channels

User Manuals
Masterpiece is paired to the
SkyBeast
Please make sure that the number of DMX channel selected on your Masterpiece matches the
number of the selected bank on your SkyBeast console! There are 16 bank available on your
SkyBeast console (each containing 30 channels) + 4 standard mode channels.
Here are the steps you need to take to select a bank on your SkyBeast console:
1. Press shortly buttons General Master and Mode
select together.
2. The number of the bank on display will start
blinking.
3. Use navigation buttons - General Master (-) and
Mode Select (+) until the desirable DMX bank
number is shown on the display.
4. To confirm your choice press buttons General
Master and Mode select at the same time again
shortly.
You should follow the same steps (above) when you are controlling more than one fixture with
your SkyBeast control, and you want to navigate from one fixture to another!
4.2. Mode selection
To select a mode on your SkyBeast console please follow the steps:
1. Press and hold Mode Select button.
2. While holding Mode Select button, use
1. Channel Potentiometer to navigate
through 6 available modes, and 2.
Channel Potentiometer to navigate
through sub-modes ( for Gel and
Effects). Your navigation will be shown
on the display.
3. When you have reached desirable
mode (and sub-mode), you can release
the Mode Select button.
4. You can now make adjustments in the
selected mode as shown in the scheme
in the next chapter.
1. CCT
Channel potentiometer 1 –Volume
Channel potentiometer 2 –Colour temperature (2800K-10000K)
Channel potentiometer 3 –Green/magenta
2. HSI
Channel potentiometer 1 –Volume
Channel potentiometer 3 –Hue
