Sensia MS-53 User manual

MS53 Laboratory Mixer Iss 6.doc
OPERATING, INSTALLATION & MAINTENANCE
MANUAL
FOR
MS-53 LABORATORY MIXER
This JISKOOT Product is designed to provide outstanding service if correctly installed, used
and maintained recognising the effects of the process conditions (temperature, pressure, wax/pour
point, sediment, etc.).
Truly representative sampling of crude oils etc., cannot be achieved by one single product in isolation.
A well designed system and operating procedures as laid down in the Sampling Standards ISO 3171,
API 8.2 and IP Chapter VI section 2 are mandatory.
Please consult Sensia for further information and assistance.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the
express written permission of Sensia.

MS-53 Laboratory Mixer
Issue No 6
TABLE OF CONTENTS
1WARRANTY.......................................................................................................4
2INTRODUCTION................................................................................................. 4
3OPERATING INSTRUCTIONS...........................................................................5
4FULL FUNCTIONAL DESCRIPTION.................................................................5
5UTILITIES REFERENCE....................................................................................5
6INSTALLATION DETAILS .................................................................................6
7MAINTENANCE & TROUBLESHOOTING.........................................................6
8SUB SUPPLIER INFORMATION .......................................................................6
9PRODUCT SPECIFIC DRAWINGS....................................................................7
10 RECOMMENDED SPARES LIST...................................................................7
11 DISCLAIMER..................................................................................................8

MS-53 Laboratory Mixer
Issue No 6 Page 4
1 Warranty
This product should be supplied with a warranty card. Please complete and return it to
register for warranty support.
In the event it is missing, to register for support, please contact us on [phone] or
[e-mail], quoting the Jiskoot Order Number or Serial No with the following
information:
Date installed
Full installation site details, including contact details
Maintenance and operator contact details (where different from above)
Product comments/feedback
If the product has been supplied as part of a Jiskoot system or assembly, please complete the
warranty card for the system.
2 Introduction
The MS-53 Laboratory Mixer is used to ensure that samples of crude oil or other products
extracted from a pipeline or a cargo are thoroughly mixed prior to laboratory analysis, to
ensure that the small amount of sample is truly representative of the whole.
The sample is normally collected in Jiskoot Type PR-23 (9 litre) or PR-53 (18 litre) portable
Sample Receivers over a period of some hours. It may be many hours before it is analysed
and during this time some of the water will fall out and separate.
The standard MS-53 Laboratory Mixer is capable of mixing viscous products of up to 500 Cst
(at operating temperature). Alternative motors and pumps may be required for higher
viscosity applications.

MS-53 Laboratory Mixer
Issue No 6 Page 5
3 Operating Instructions
The MS-53 Laboratory Mixer is simple to operate.
The Mixer must be firmly located on a suitable bench and connected to a suitable electrical
supply.
The 3/4" suction and 1/2" discharge hoses must be connected to the appropriate connections
of the Sample Receiver. Ensure that the quick release couplings are connected properly by
pulling gently on the hoses.
Apply power to the Mixer. Mixing time is a function of gravity, viscosity and various other
factors. Tests have shown that the Laboratory Mixer will successfully mix a variety of oils
within 5-10 minutes, however, the optimum mixing time will vary depending on the
composition of the oil.
When crude oil is sampled at a high temperature, allowed to cool and then reheated,
condensation may form in the Sample Receiver. If this occurs, ensure the can is briefly
shaken by hand to remove water droplets from the top of the receiver.
In some instances the pump may need assistance in priming. To do this lift the receiver up
with the mixer running until the pump primes.
NOTE: To avoid damage to the pump, the Laboratory Mixer should not be operated for periods exceeding
3 minutes if no product available.
When the oil is thoroughly mixed, draw off a sample from the needle valve into laboratory
glassware for analysis. Alternatively, a septum may be fitted to the Mixer to enable the
sample to be taken using a syringe. It is recommended that the initial 10-20ml of sample be
discarded, to ensure all equipment is thoroughly flushed.
When sufficient sample has been obtained, switch off the mixer and thoroughly clean all
equipment to prevent cross contamination.
4 Full Functional Description
The MS-53 Laboratory Mixer consists of a loop drawing oil from the lowest point in the
Sample Receiver through the electric motor driven gear pump. The oil is discharged from the
pump through the static mixer and returned to the receiver. The return pipe of the Sample
Receiver is pointed down, tangentially towards the wall of the receiver to promote extra
mixing.
The Laboratory Mixer is fitted with a needle valve to enable the sample to be drawn off into
laboratory glassware. In addition, a septum may be fitted to enable a sample to be drawn off
via a syringe.
The MS-53 Laboratory Mixer is normally supplied with an electric motor, but is also available
with a pneumatic motor for applications where electricity is not an available power source.
5 Utilities Reference
Electrical Requirements 100/110 or 240/220 Volts, 50 or 60 Hz to suit motor supplied.
Power Requirement 0.5KW
Pneumatic Option 3Barg/45psig lubricated air supply.

MS-53 Laboratory Mixer
Issue No 6 Page 6
6 Installation Details
The Laboratory Mixer must be installed and operated in compliance with any applicable
electrical hazardous area regulations. The electrical supply should be connected to the motor
isolating switch via a suitably certified M20 cable gland, ensuring that earth continuity across
the switch is maintained.
7 Maintenance & Troubleshooting
Other than cleaning after use, the MS-53 Laboratory Mixer requires minimal maintenance.
The septum rubbers are self-sealing, however if a leakage is noted, they must be replaced
with new rubbers.
Both Laboratory Mixer and Sample Receiver must be cleaned to prevent cross-contamination
of samples.
The recommended method for cleaning this equipment is to use a solvent and an inert gas
(e.g. Nitrogen) as follows:-
1) Remove Sample Receiver from Laboratory Mixer and empty.
2) Re-connect Sample Receiver and run Laboratory Mixer for approximately 15
seconds.
3) Disconnect and empty Sample Receiver.
4) Add 2 litres of solvent (Toluene or Kerosene).
5) Turn on Laboratory Mixer and circulate for one minute.
6) Turn off and remove pump suction hose (3/4" connector)
7) Connect suction to inert gas source (Nitrogen) NOT compressed air.
8) Carefully blow out Laboratory Mixer with inert gas. NOTE: The gas pressure will
relieve through the Sample Receiver relief valve.
9) Remove Sample Receiver. Clean with solvent and leave inverted with cover
removed to drain.
DO NOT UNDER ANY CIRCUMSTANCES:-
1) Use compressed air for purging.
2) Run the Laboratory Mixer with the discharge hose disconnected or shut off - high
pressures will build up and may cause the hose to rupture.
3) Run the Laboratory Mixer unprimed or with solvent for long periods
8 Sub Supplier Information
8.1 Electric motor
The electric motor requires no routine maintenance. In the event of a fault, the motor should
be replaced or fully overhauled by a qualified repair shop.
8.2 Gear Pump Overhaul
The gear pump has minimal serviceable components. A replacement seal kit is available for
site replacement if required, but as any wear on the gears and body faces causes loss of
performance, a replacement pump is recommended.
8.3 Pneumatic Motor
Before dismantling the pump, using a broad felt tip marker pen, draw a line on the pump outer
casing from the foot/flange casting across the centre body casting to the end cover casting.
1) Slacken and remove the 4 socket head set pins.
2) Remove end cover casting.

MS-53 Laboratory Mixer
Issue No 6 Page 7
3) Remove centre body casting.
4) Remove gears and shafts.
5) Remove dowels.
6) Clean components, removing traces of paint, and/or gasket material from body sides.
8.3.1 Examine:
1) Shafts for signs of wear (a maximum reduction of .002” difference from diameter of
unworn part of shaft is acceptable).
2) Gears, tooth form and gear end faces for wear, scuffing or damage, and replace if
necessary.
3) Lip Seal/s for damage caused by dirt or metal particles, etc. and replace if necessary.
NOTE: With double lip seal arrangements, ensure that the seals are re-fitted facing exactly the same
direction as the seals they replaced.
8.3.2 Reassembly
1) Ensure that all components are clean and free from dirt and paint etc.
2) Measure the body width and gear width and fit paper gaskets to allow a maximum of
0.002" running clearance.
3) Fit dowels.
4) Align the components to the felt marker line and re-assemble in reverse order to the
dismantling procedure.
5) Tighten the 4 socket head set pins evenly and diagonally whilst rotating the driveshaft
by hand. Ensure that the pump rotates evenly for the full 360owithout tightness.
Should tightness occur, slacken set pins and try again.
6) If the pump cannot be assembled as indicated, examine gears for damage and, if
satisfactory, fit an extra gasket to one face and repeat from 5 above.
9 Product Specific Drawings
9.1.1 Laboratory Mixer Type MS53-E (Electrically Driven)
General Arrangement Drawing B18103
Septum Assembly Drawing E16473
9.1.2 Laboratory Mixer Type MS53-P (Pneumatically Driven)
General Arrangement Drawing B18602
Septum Assembly Drawing E16473
10 Recommended Spares List
Part/Sub- Assembly
Item No's
Commissioning
1 Year
Operation
2 Year
Operation
3/4" Quick Release Coupling
48-0476-00
-
1
1
1/2" Quick Release Coupling
48-0516-00
-
1
1
Septum Seals
(Quantity required will be determined by
degree of usage)
48-0641-00
-
10
10

MS-53 Laboratory Mixer
Issue No 6 Page 8
11 Disclaimer
Whilst Jiskoot Limited has taken every care in the preparation of this document, it cannot
accept responsibility for printing errors or omissions and does not warrant that it is correct and
comprehensive in every particular. Persons with an appropriate level of skill and training
should operate equipment supplied only.
Jiskoot Limited shall not be liable for incidental or consequential damages resulting from the
furnishing, performance or use of this material.
Jiskoot pursues a policy of continuous improvement, and information given herein may be
updated without notice. Further, this information is proprietary to Jiskoot Limited, and must
not be disclosed to any third party except as may be required to operate the equipment
supplied in accordance with the purposes for which it was sold by the persons properly
licensed to operate it.
6
Recommended Spares List corrected
P.Whittle
N.McGee
07/01/2009
5
Company name updated
P.Whittle
M.A.Jiskoot
02/02/2006
4
Note added regarding maximum product viscosity for standard unit
P.Whittle
M.A.Jiskoot
27/08/2003
3
Rewritten in MS Word format
M.Doust
P.Whittle
02/06/2003
2
Drawing and Parts List references updated
P.Whittle
P.Whittle
25/04/2000
1
Issue
Revision History
Issued
Approved
Date

MS-53 Laboratory Mixer
Issue No 6 Page 9
Notes

MS-53 Laboratory Mixer
Issue No 6 Page 10
Notes


www.jiskoot.com
Tunbridge Wells, Kent, TN1 2DJ, UK
Tel [phone], Fax [phone]
e-mail: [email protected]
Houston, TX77014, USA
Tel [phone], Fax [phone]
e-mail: [email protected]

14503 Bammel North Houston Suite 110
Houston Texas 77014
Tel [phone]
Fax [phone]
Email [email protected]
The Jiskoot Lab Mixer MS-53E
1. Baldor Explosion Proof Motor Installation & Operating Manual
2. Viking Pump Technical Service Manuals
3. Koflo Six Element Static Mixer
4. Appleton Switch Housing
5. Cutter-Hammer Single Phase Switch w/ Plug-in Heater
6. Hazardous Area Electrical Certifications

Integral Horsepower
AC Induction Motors
ODP, WPI, WPII Enclosure
TEFC Enclosure
Explosion Proof
Installation & Operating Manual
5/04 MN400

Table of Contents
Table of Contents iMN400
Section 1
General Information 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limited Warranty 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Notice 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receiving 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unpacking 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handling 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 2
Installation & Operation 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Doweling & Bolting 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Connection 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conduit Box 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AC Power 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Time Start Up 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coupled Start Up 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jogging and Repeated Starts 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 3
Maintenance & Troubleshooting 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Inspection 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication & Bearings 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type of Grease 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Intervals 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Procedure 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting Chart 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Section 1
General Information
ii Table of Contents MN400

Section 1
General Information
General Information 1-1MN400
Overview This manual contains general procedures that apply to Baldor Motor products. Be sure to read and
understand the Safety Notice statements in this manual. For your protection, do not install, operate or
attempt to perform maintenance procedures until you understand the Warning and Caution statements. A
Warning statement indicates a possible unsafe condition that can cause harm to personnel. A Caution
statement indicates a condition that can cause damage to equipment.
Important: This instruction manual is not intended to include a comprehensive listing of all details for all
procedures required for installation, operation and maintenance. This manual describes general
guidelines that apply to most of the motor products shipped by Baldor. If you have a question
about a procedure or are uncertain about any detail, Do Not Proceed. Please contact your Baldor
distributor for more information or clarification.
Before you install, operate or perform maintenance, become familiar with the following:
SNEMA Publication MG-2, Safety Standard for Construction and guide
for Selection, Installation and Use of Electric Motors and Generators.
SThe National Electrical Code
SLocal codes and Practices
Limited Warranty
1. Most Baldor products are warranted for 18 months from the date of shipment to Baldor’s customer from Baldor’s
district warehouse or, if applicable, from Baldor’s factory. Baldor Standard–E®standard efficient motors are
warranted for 24 months. Standard–E is limited to three phase, general purpose, 1–200 HP ratings that fall under
the Energy Policy Act (EPAct). Baldor Super–E®premium efficient motors are warranted for 36 months. Baldor
IEEE841 motors are warranted for 60 months. All warranty claims must be submitted to a Baldor Service Center
prior to the expiration of the warranty period.
2. Baldor will, at its option repair or replace a motor which fails due to defects in material or workmanship during the
warranty period if:
a. the purchaser presents the defective motor at or ships it prepaid to, the Baldor plant in Fort Smith, Arkansas
or one of the Baldor Authorized Service Centers and
b. the purchaser gives written notification concerning the motor and the claimed defect including the date
purchased, the task performed by the Baldor motor and the problem encountered.
3. Baldor will not pay the cost of removal of any electric motor from any equipment, the cost of delivery to Fort Smith,
Arkansas or a Baldor Authorized Service Center, or the cost of any incidental or consequential damages resulting
from the claimed defects. (Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above exclusion may not apply to you.) Any implied warranty given by laws shall be limited to
the duration of the warranty period hereunder. (Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.)
4. Baldor Authorized Service Centers, when convinced to their satisfaction that a Baldor motor developed defects in
material or workmanship within the warranty period, are authorized to proceed with the required repairs to fulfill
Baldor’s warranty when the cost of such repairs to be paid by Baldor does not exceed Baldor’s warranty repair
allowance. Baldor will not pay overtime premium repair charges without prior written authorization.
5. The cost of warranty repairs made by centers other than Baldor Authorized Service Centers WILL NOT be paid
unless first authorized in writing by Baldor.
6. Claims by a purchaser that a motor is defective even when a failure results within one hour after being placed into
service are not always justified. Therefore, Baldor Authorized Service Centers must determine from the condition
of the motor as delivered to the center whether or not the motor is defective. If in the opinion of a Baldor
Authorized Service Center, a motor did not fail as a result of defects in material or workmanship, the center is to
proceed with repairs only if the purchaser agrees to pay for such repairs. If the decision is in dispute, the
purchaser should still pay for the repairs and submit the paid invoice and the Authorized Service Center’s signed
service report to Baldor for further consideration.
7. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

1-2 General Information MN400
Safety Notice:This equipment contains high voltage! Electrical shock can cause serious or fatal injury.
Only qualified personnel should attempt installation, operation and maintenance of
electrical equipment.
Be sure that you are completely familiar with NEMA publication MG-2, safety standards
for construction and guide for selection, installation and use of electric motors and
generators, the National Electrical Code and local codes and practices. Unsafe
installation or use can cause conditions that lead to serious or fatal injury. Only qualified
personnel should attempt the installation, operation and maintenance of this equipment.
WARNING: Do not touch electrical connections before you first ensure that
power has been disconnected. Electrical shock can cause serious
or fatal injury. Only qualified personnel should attempt the
installation, operation and maintenance of this equipment.
WARNING: Be sure the system is properly grounded before applying power.
Do not apply AC power before you ensure that all grounding
instructions have been followed. Electrical shock can cause
serious or fatal injury. National Electrical Code and Local codes
must be carefully followed.
WARNING: Avoid extended exposure to machinery with high noise levels. Be
sure to wear ear protective devices to reduce harmful effects to
your hearing.
WARNING: This equipment may be connected to other machinery that has
rotating parts or parts that are driven by this equipment. Improper
use can cause serious or fatal injury. Only qualified personnel
should attempt to install operate or maintain this equipment.
WARNING: Do not by-pass or disable protective devices or safety guards.
Safety features are designed to prevent damage to personnel or
equipment. These devices can only provide protection if they
remain operative.
WARNING: Avoid the use of automatic reset devices if the automatic restarting
of equipment can be hazardous to personnel or equipment.
WARNING: Be sure the load is properly coupled to the motor shaft before
applying power. The shaft key must be fully captive by the load
device. Improper coupling can cause harm to personnel or
equipment if the load decouples from the shaft during operation.
WARNING: Use proper care and procedures that are safe during handling,
lifting, installing, operating and maintaining operations.
Improper methods may cause muscle strain or other harm.
WARNING: Before performing any motor maintenance procedure, be sure that
the equipment connected to the motor shaft cannot cause shaft
rotation. If the load can cause shaft rotation, disconnect the load
from the motor shaft before maintenance is performed. Unexpected
mechanical rotation of the motor parts can cause injury or motor
damage.
WARNING: Disconnect all electrical power from the motor windings and
accessory devices before disassembly of the motor. Electrical
shock can cause serious or fatal injury.
WARNING: Do not use non UL/CSA listed explosion proof motors in the
presence of flammable or combustible vapors or dust. These
motors are not designed for atmospheric conditions that require
explosion proof operation.

Section 1
General Information
General Information 1-3MN400
Safety Notice Continued
WARNING: Motors that are to be used in flammable and/or explosive
atmospheres must display the UL label on the nameplate along with
CSA listed logo.
Specific service conditions for these motors are defined in
NFPA 70 (NEC) Article 500.
WARNING: UL rated motors must only be serviced by authorized Baldor
Service Centers if these motors are to be returned to a flammable
and/or explosive atmosphere.
Caution: To prevent premature equipment failure or damage, only qualified
maintenance personnel should perform maintenance.
Caution: Do not lift the motor and its driven load by the motor lifting
hardware. The motor lifting hardware is adequate for lifting only the
motor. Disconnect the load from the motor shaft before moving the
motor.
Caution: If eye bolts are used for lifting a motor, be sure they are securely
tightened. The lifting direction should not exceed a 20°angle from
the shank of the eye bolt or lifting lug. Excessive lifting angles can
cause damage.
Caution: To prevent equipment damage, be sure that the electrical service is
not capable of delivering more than the maximum motor rated amps
listed on the rating plate.
Caution: If a HI POT test (High Potential Insulation test) must be performed,
follow the precautions and procedure in NEMA MG-1 and MG-2
standards to avoid equipment damage.
If you have any questions or are uncertain about any statement or procedure, or if you
require additional information please contact your Baldor distributor or an Authorized
Baldor Service Center.
