Sensor Electronics SEC 3500 HMI User manual

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 1of 26
SEC 3500 HMI Operator
Interface
Hardware Manual
Sensor Electronics Corporation
12730 Creek View Avenue
Savage, Minnesota 55378 USA
[phone] Fax [phone]
Email [email protected]

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 2of 26
Commitment
Our quality and service are uncompromising. We back each of our products with a two-year warranty on all
materials and workmanship. We offer technical support, user training and on-site service and maintenance
of equipment to meet the needs of our customers.
Gas Detection Service
Individually designed maintenance packages are available for specific customer needs. Service begins with
verification of the system installation that includes an initial system check and calibration. We then offer
customer training programs (on-site and at factory) to insure that technical personnel fully understand
operation and maintenance procedures. When on-the-spot assistance is required, service representatives
are available to handle any questions or problems immediately.
Warranty
Sensor Electronics Corporation (SEC) warrants products manufactured by SEC to be free from defects in
workmanship and materials for a period of two (2) years from date of shipment from the factory. Any parts
returned freight pre-paid to the factory and found defective within the warranty would be repaired or
replaced, at SEC's option. SEC will return repaired or replaced equipment pre-paid lowest cost freight.
This warranty does not apply to items, which by their nature are subject to deterioration or consumption in
normal service. Such items may include:
Fuses and Batteries.
Warranty is voided by abuse including rough handling, mechanical damage, alteration or repair. This
warranty covers the full extent of SEC liability and SEC is not responsible for removal, replacement costs,
local repair costs, transportation costs or contingent expenses incurred without prior written approval.
Sensor Electronics Corporation's obligation under this warranty shall be limited to repair or replacement of
any product that has been returned to Sensor Electronics Corporation for warranty consideration. This
warranty is expressly in lieu of any and all other warranties expressed or implied, and all other obligations
or liabilities on the part of Sensor Electronics Corporation including but not limited to, the fitness for a
particular purpose. In no event shall Sensor Electronics Corporation be liable for direct, incidental, or
consequential loss or damage of any kind connected with the use of its products or failure to function or
operate properly.

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 3of 26
Table of Contents
Contents
I. SPECIFICATIONS...........................................................................................................................5
II. GENERAL DESCRIPTION .............................................................................................................6
III. OPERATION..................................................................................................................................7
IV. INSTALLATION.............................................................................................................................8
V. DRAWINGS....................................................................................................................................9
VI. TESTING.....................................................................................................................................25
VII. MAINTENANCE .........................................................................................................................26

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 4of 26
Revision History
Rev
Date
ECO
Description of Change
Page
032113
03/21/13
-
Initial Release
1
9/20/2016
-
Update to Current P/N Scheme
Update Specifications
Add Installation Steps
Add Testing
Add Maintenance
Add UL2017 Information
All
2
10/26/2016
-
Change model to SEC3500 HMI
Add all Components Inside Enclosure to Specs
Add Recommended Power Supply
Add Earth Ground Callout to Page 9
Add Note about ISO Comm on Repeaters
Add Part about SEC3500 HMI Being the System
All
A
000209
UL2017 Approved
All

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 5of 26
I. SPECIFICATIONS
Model: SEC3500 HMI
Interface
RS485 Port: Interactive “Modbus” (expandable to two)
RS232 Port: “Statcast” System parameter broadcast
Ethernet Port: Remote Screen Access
16 Programmable Relays (expandable to 40)
Construction: Powder Coated Steel
Dimensions: 16” X 16” X 10”
Weight: 45lbs
Operating Temperature Rating:
0to +50C at 0 to 99% RH (non-condensing)
Operating Voltage: 19 to 29 VDC
Power Consumption: 40 Watt Max. (Not including relay contact current or 24VDC power
supplied to external devices)
Relay Contacts: 1 NO, 1 NC per Relay.
Contact Rating: 8A @ 30VDC, 8A @ 250VAC
Type AM System
System Components:
SEC 3500 Operator Interface (Red Lion HMI)
SEC 3100 Gas Transmitter (Not UL 2017 Approved)
SEC 3500 - XX Relay Controller
SEC 3100 AIM Interface Module (Not UL 2017 Approved)
SEC 3100 LIM Interface Module (Not UL 2017 Approved)
SEC 3100 ISO Repeater
SEC 3500 Enclosure
Circuit Breaker
DC to DC Converter 12-24V to 24V 1A
Approvals: CSA: C22.2 No 0, No 0.4-04, No 14-05, No 142
UL 508
ETL: 5002065 UL 2017 (SEC3500 HMI, whole system)
Installation Category: Cat. I, Pollution Degree 2
RS485 Max Line Impedance: ~100-140Ω
Recommended Power Supply: IDEC PS5R-SD24
Input: 100 to 240VAC Output: 24V 2.5A Power Supply
Other supplies may be used as long as they are class 2 power supplies

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 6of 26
II. GENERAL DESCRIPTION
CONVENTIONS
The following conventions are used in this manual.
Warning Statement
VDC (DC Voltage)
SEC 3500 HMI
The SEC3500 HMI Operator Interface, an Attendant-Monitored system, continuously interrogates
up to 254 system devices over the 9600 baud RS485 Modbus Interface. The OI, operating as the
Modbus Master, can communicate with any SEC3XXX Device and any 4-20 transmitter via the
SEC3100AIM.
There is a power indicator LED located on the front panel of the 3500.
Network devices can be interrogated, configured, and calibrated using the password protected
touchscreen user interface.
16 embedded programmable relays provide external device control/interface based on network
events. Additional relays can be located anywhere on the network (groups of 8).
The Statcast RS232 interface continuously scrolls through system operating status. (Read only
for the user)
An Ethernet port allows remote access to system screens.
The SEC3500 HMI refers to the system as a whole, not just the SEC3500 (what is inside the metal
enclosure).
WARNING: SUBSTITUTION OF COMPONENTS MAY IMPAIR SAFETY

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 7of 26
III. OPERATION
The SEC3500 HMI Operator Interface is an intuitive operator interface. For the individual page
operations please refer to the following individual instruction manuals on the SEC website:
3500 OI Basic Operators Guide.pdf
3500 OI Startup Basics Guide.pdf
StatCast.pdf

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 8of 26
IV. INSTALLATION
1. Mounting Instructions:
a. Find an accessible spot for the SEC 3500 to be mounted. This spot
should have enough room for incoming/outgoing wires to be easily
routed around. The SEC 3500 should be accessible at a regular height
so the monitor can be easily accessed at all time alarms. Make sure the
monitor is in a safe location in case of alarm.
b. The SEC 3500 needs to be mounted on a solid wall
c. Recommended Hardware:
i. Use all 4 mounting brackets when mounting the SEC 3500
ii. Bolts: minimum of ¼” – 20 thread, 1 ½” long
iii. Nuts: ¼” – 20 Thread ½” Wide
iv. Washers: Minimum 0.260” ID, 0.750” OD for washers between
the bolt head and the SEC 3500. Maximum 0.375” ID, Minimum
1.50” OD for washers between mounting wall and bolt
2. The SEC 3500 requires an 18-29V DC power supply. This power supply must
cover Class 2 requirements as well as be UL 1310 approved. Then run the
power through the bottom-left hole of the SEC 3500 unit. Then connect the
power supply to the DC-to-DC converter.
3. Run the RS485 (Data Highway) through the bottom-left side hole of the SEC
3500. Then attach to the data highway to the proper terminals on the terminal
block.
4. When connecting 120 VAC (Class 1) circuits to the SEC 3500, wires should be
routed through the top-right opening. Then all class 2 and 3 power circuits going
to the relay switches should go through the bottom-left opening. Class 1 wires
must be kept at least 1/4”inches away from class 2/3 circuits.
5. Relay controller labeled 253 in the SEC3500 HMI housing has relay 1
designated for the alarm horn.
a. The horn needs to be supplied with +24VDC.
6. Sensor Electronics recommends not connecting earth ground and DC common
together. Instead connect earth ground to the bolt inside the enclosure. It is
located inside the enclosure on the bottom left and is connected to the panel
door.
7. For the UL2017 approval, all wiring that interconnects equipment must be
located within the same room.

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 9of 26
Class 2
Power Supply
Earth Ground Bolt
*NOTE: COM ON THE SEC 3100 ISO REFERS TO THE ISO COMMON, NOT DC COMMON

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 10 of 26
V. DRAWINGS
Part Number
Description
1421901
Mounting and Dimensional Drawing
350000016X16X10
Internal Component Layout
1460015 (separate document)
Overall Wiring Diagram
-
Wiring Examples

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 11 of 26

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 12 of 26

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 13 of 26
WIRING TERMINATION
The wiring diagram is for theinput power to the SEC 3500 and RS485 Data Highway Connection.
TB1
Earth Ground Connection 1 2 3 4 5 6 7 8
(Ground Stud)
Enclosure Wall Terminal Description:
1 2 AMP Circuit Breaker Power for SEC 3500 only
2 DC Common
3 LAN Y DATA A
4 LAN Y DATA B
5 LAN Y ISOLATED DC COMMON
6 LAN X DATA A
7 LAN X DATA B
8 LAN X ISOLATED DC COMMON

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 14 of 26
24 VDC
POWER
SUPPLY
1 2 3 4 5 6 7 8 SEC 3500 Terminal Block
WIRING EXAMPLE:
SEC 3500 TO SEC 3100
TRANSMITTERS AND SEC 3500 –8
RELAY CONTROLLER

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 15 of 26
TB 2
(1) 4-20 mA ANALOG OUTPUT
(2) DC COMMON
(3) +24 VDC
(4) DATA ISO COMMON
(5) RS485 DATA B
(6) RS485 DATA A
TB 3
(1) WHITE
(DATA/CAL)
(2) BLUE OR GREEN
(4-20 mA)
(3) RED
(+24 VDC)
(4) BLACK
(DC COMMON)
TB 2
POWER,
DATA HWY,
ANALOG
OUTPUT
TB 3
SENSOR
WIRING
TB 1
RELAY
WIRING
BACK VIEW OF SEC 3100
SEC 3100 WIRING
SENSOR ELECTRONICS CORPORATION
12730 CREEK VIEW AVE
SAVAGE, MINNESOTA 55378 USA
(T) 952.938.9486 (F) 952.938.9617
[e-mail]
TB 1
(12) LOW ALARM N.C.
(11) LOW ALARM COMMON
(10) LOW ALARM N.O.
(9) MID ALARM N.C.
(8) MID ALARM COMMON
(7) MID ALARM N.O.
(6) HIGH ALARM N.C.
(5) HIGH ALARM COMMON
(4) HIGH ALARM N.O.
(3) FAULT (N.E.) N.C.
(2) FAULT (N.E.) COMMON
(1) FAULT (N.E.) N.O.

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 16 of 26
TB 1 Relay Wiring TB 2 Relay Wiring
1High Alarm N.C. 1 Low Alarm N.C.
2High Alarm Common 2 Low Alarm Common
3High Alarm N.O. 3 Low Alarm N.O.
4Fault N.O. 4 Mid Alarm N.C.
5 Fault Common 5 Mid Alarm Common
6 Fault N.C. 6 Mid Alarm N.O.
1 TB1 6 1 TB2 6
1 TB5 4 1 TB6 6
TB 5 Sensor Wiring TB 6 Power / Data Wiring
1DC Common (Black) 1 Data A
2+ 24 VDC (Red) 2 Data B
34- 20 mA (Blue or Green) 3 Iso-Common
4Communication (White) 4 + 24 VDC Input Power
5 DC Common
6 4-20 mA Output
Housing Dimensions
3.54 (W) x 4.17 (L) x 2.28 (H) inches
{90 (W) x 106 (L) x 58 (H) mm}

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 17 of 26
SEC 3500-8 RELAY CONTROLLER
SPECIFICATIONS
INPUT POWER: 10-30 VDC
RELAY CONTACT RATING: 8 AMPS @ 250 VAC OR 8 AMPS @ 30 VDC
COMMUNICATION: ISOLATED RS485 (MODBUS)
WEIGHT: SEC 3500 –8 RELAY CONTROLLER (PN 1421999) 2 LBS
SEC 3500 –16 RELAY CONTROLLER (PN 1422182) 3 LBS
POWER: SEC 3500 –8 RELAY CONTROLLER 4 WATTS @ 24 VDC
SEC 3500 –16 RELAY CONTROLLER 6 WATTS @ 24 VDC
TB 2 AND TB 3 (RELAY CONTACT WIRING)
TB 1 (WIRING CONNECTION FOR POWER AND RS485)

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 18 of 26
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
1
2
3
4
5
6
TOP VIEW OF SEC 3500 - 8
RELAY CONTROLLER
1 2 3 4 5 6
TOP VIEW OF SEC 3500 -16
RELAY CONTROLLER
1 2 3
4 5 6
DATA A
DAT A B
DATA ISO COM
+ 24 VDC
7 8 9 10
11
12
1 2 3 4 5 6
K1 K2 K3 K4
7 8 9 10
1112
1 2 3 4 5 6
K5 K6 K7 K8
7 8 9 10
11
12
1 2 3 4 5 6
K9 K10 K11 K12
7 8 9 10
1112
1 2 3 4 5 6
K13 K14 K15 K16
DATA
LED POWER LED
K1
K2
K3
K4
K5
K6
K7
K8
K16
K15
K14
K13
K12
K11
K10
K9
DATA
LED
POWER
LED
For wiring details
refer to Figure A
Figure C
TB 4 (K9-K12)
TB 5 (K13-K16)
Figure B
TB 2 (K1-K4)
TB 3 (K5-K8)
Figure A
(TB 1)
For wiring details refer to Figure B
For wiring details
refer to Figure A
For wiring details
refer to Figure B
For wiring details
refer to Figure C
K1
K2
K3
K4
K5
K6
K7
K8
DC COMMON

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 19 of 26
SEC 3500-8 RELAY CONTROLLER DIMENSIONS
SEC 3500 –16 RELAY CONTROLLER DIMENSIONS

SEC P/N: 1460014
Rev / ECO: A / 000209
Page 20 of 26
SEC 3100
BACK SIDE
A1 (DATA A)
B1 (DATA B)
ISO COM
+ 24 VDC
DC Common
SEC 3100
BACK SIDE
DC Common
+ 24 VDC
ISO COM
B1 (DATA B)
A1 (DATA A)
*NOTE: COM1
AND COM2
REFER TO THE
ISO COMMON,
NOT DC
COMMON
Operating Voltage Temperature Rating Humidity
18-32 VDC -40to + 70C 0-99% RH (non-condensing)
Operating Current Input / Output (digital) Part Number
50mA @ 24VDC MODBUS RTU 3100-000-REPEAT
SEC 3100 ISO
RS-485 Repeater Module
Operation
The SEC 3100 ISO RS-485 Repeater Module is used in conjunction with the SEC 3100 transmitters and
the SEC 3500 HMI Operator Interface or other MODBUS RS-485 data highway systems. The SEC 3100
ISO RS-485 Repeater Module is used to extend the distance of the RS-485 network and increase the
number of devices on the RS-485 network. The SEC 3100 ISO RS-485 Repeater Module provides 1500
volt isolation bidirectional data flow and transient suppression on the RS-485 data lines. An SEC 3100
ISO RS-485 Repeater Module should be installed for every 1000 feet of data highway cable or 32 network
devices. The SEC 3100 ISO RS-485 Repeater Module is powered by 24 VDC and wired in line with the
SEC RS-485 network devices. A typical wiring diagram is shown below:
SPECIFICATIONS
