SERV-WARE SGSB-36 User manual

FOR QUESTIONS, CONTACT THE
SERVICE DEPARTMENT AT:
[e-mail] or
800•768•5953
Gas Salamander Broiler
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately.
SGSB-36
www.servware.com
800•768•5953
Save These Instructions!
Parts & Service Manuals Available at:
IMPORTANT INFORMATION
ABOUT YOUR UNIT ENCLOSED.
PLEASE READ BEFORE USE!

DANGER
WARNING
CAUTION
www.servware.com
800•768•5953
Service, Installation & Care Manual
1
COMMERCIAL SALAMANDER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential
hazards that can kill or injure you and others. All safety messages
will follow the Safety Alert Symbol and either the words ”DANGER”,
“WARNING” or “CAUTION”.
DANGER means that failure to heed this safety
statement may result in severe personal injury or death.
WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
CAUTION means that failure to heed this safety
statement may result in minor or moderate
personal injury, or property or equipment damage.
All safety messages will alert you to what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard. This appliance is not intended for use by
persons with lack of experience and knowledge regarding this type of equipment, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Cleaning and user maintenance shall not be made by inexperienced persons without
supervision.
Do not store explosive substances such as aerosol cans with a ammable propellant in this
appliance. The appliance uses ammable insulation blowing gas C5H10, disposal of the appliance
shall be in accordance with the regulations of federal, state and local authorities.

www.servware.com
800•768•5953
Service, Installation & Care Manual
2
COMMERCIAL SALAMANDER SAFETY
Safety Notes:
• The installation and maintenance should be done by gas professional persons or those who
have received the gas operation licenses, or the persons that manufacturer authorized.
• When installing or maintaining the appliance, please carefully follow the user’s manual.
• Keep this manual in a visible place so that it can be used as reference by other operators.
• The appliance is only for commercial use, not for household use.
• When the appliance nishes work or the operator is not available to the appliance, please
switch off the appliance and cut off the main gas supply.
• Never use water jet to ush the appliance in case of damaging the control components of
the appliance.
• Clean the stainless steel surface of the appliance periodically.
Warning:
• The appliance is only suitable for gas with low pressure. When supplying LPG, it must equip
with a low pressure relief valve. It is prohibited to use any medium or high pressure relief valve.
• Any retting and wrong installation, adjustment and maintenance can cause property loss and
casualty. Please contact the supplier if you need to adjust or maintain the appliance. And all
these operations should be done by authorized professionals.
• Do not put ammable liquid, gas or other incentive objects around the appliance for your
safety sake.
• Do not change the positions of the air inlet port and ue gas outlet port.
• The appliance is equipped with a thermostat, adjust it to set a proper desired temperature, do
not use the appliance without cooking food, otherwise it will incur serious accident.
• If there is a gas leakage of the appliance, please shut off the general gas valve immediately.
Don’t press any electronic on/off button, and use any phones in the room where appliance
installed. Go outside and call to the service center to ask professional staff to maintain it.
• The control knob only can be operated with hands, do not use any tool to control it.

www.servware.com
800•768•5953
Service, Installation & Care Manual
3
GENERAL INFORMATION............................................................................. 3-4
PRODUCT SPECIFICATION SHEET.............................................................. 5
INSTALLATION............................................................................................... 5-6
TESTING RUN ................................................................................................ 6
OPERATION ................................................................................................... 6
CLEANING...................................................................................................... 7
MAINTENANCE.............................................................................................. 7
BRACKET OR STAND ................................................................................... 7
ATTENTION .................................................................................................... 7
TROUBLESHOOTING CHART....................................................................... 8
© Copyright 2022 Serv-Ware Products Incorporated. All rights reserved.
Reproduction without written permission is prohibited.
CONTENTS

www.servware.com
800•768•5953
Service, Installation & Care Manual
4
GENERAL INFORMATION
Before installing the appliance, please read the instructions of this manual carefully, as it
contains important information on how to install, use and service the appliance safely, properly,
and effectively.
When install, operate, and maintain the appliance, please follow the instructions provided by the
manufacturer, as proper installation, professional operation, and periodical maintenance can
assure the good performance of the appliance, and can extend its lifetime.
The appliance should be installed in compliance with all applicable local regulations.
The high limit temperature is 460.4°F (238°C), which can ensure the appliance to be safe use.
PRODUCT SPECIFICATION SHEET
Characteristics:
• Stainless steel body; and cast iron rack with surface enamel coating, which will not stick food,
and easy to clean. Height of rack can be adjusted; it is very convenient to operate.
• Infrared radiation burner distributes heat energy evenly.
• Flame failure supervision device is equipped; the appliance can be safely used.
MODEL GAS TYPE MANIFOLD
PRESSURE
Total BTU
per Hour
SGSB-36 Natural Gas
Propane Gas
4.0” WC
10.0” WC
48,000
42,000

www.servware.com
800•768•5953
Service, Installation & Care Manual
5
The appliance should be both installed and serviced in accordance with all applicable regulations and
standards in force.
The appliance is not suitable for built-in installation. Because the appliance will be working without
enough oxygen supplying due to the restriction space and the combustion products cannot be
discharged from the kitchen immediately and completely, which is very harmful for the operators’ health.
The appliance cannot be installed onto the inammable oor or other combustible objects. If the
appliance is installed with its sides next to the walls, please keep a minimum clearance of 10cm away
from the walls.
The appliance should be installed in a well-ventilated area, if possible under a vent hood, in compliance
with all applicable regulations in force. This will ensure that all burnt gases produced during the
combustion process are completely exhausted.
Prior to installation, remove all packaging materials from the appliance. Certain parts are wrapped up
in adhesive lm, which should be carefully removed. Remove any glue traces left on the appliance
thoroughly using non-ammable solvents. It is forbidden to use abrasive substances.
Check that the appliance is pre-set to use the gas family available at the place of installation. Make sure
the supply gas is the same with the gas that the appliance allows to use.
If the available gas is different from the gas which the appliance requires to use, please don’t connect it,
and mark the gas pipe with yellow color mark.
The appliance should be connected to the gas supply by means of metal pipes --either rigid or exible--
having an adequate diameter. When joining pipe ttings, never use oakum or Teon as their residues
could get to the valve and jeopardize its operation. Instead, interpose a seal gasket suitable for use in
gas systems. Do not forget to t a shutoff valve on the gas supply line upstream of the appliance, which
should be closed whenever the appliance is not in operation.
If the gas pipe pressure is higher or lower than the rated pressure at 15%, please install a pressure
regulator to adjust the gas pressure.
After connecting the appliance to the gas system, check for leaks at joints and pipe ttings; use soapy
water or a specic leak detector (spray) to check, never check with ame.
INSTALLATION

www.servware.com
800•768•5953
Service, Installation & Care Manual
6
TESTING RUN
OPER ATION
• Check whether the supplying gas and gas pressure are in accordance with that of stating on
the nameplate.
• Make sure all the valves in the gas pipeline are open.
• Switch on the control knob, and to light the burner.
• Use soapy water to check leak.
• When all the burners are light, check T.P.P. pressure.
• Make sure that the burner ame is blue.
• Switch off all the control knobs.
• Check whether the rack is easy to lift up and down.
1. Open the entire valve in the gas pipeline.
2. Put the oil tray, rack holder and rack in place.
3. Turn on the gas supply and ignite the pilot ame with a lighter.
If the unit hasn’t been used in a while or if this is the rst lighting, ignition might take longer.
4. Press the corresponding valve knob of burner and turn 90 degrees counterclockwise. The
burner will be ignited.
5. Adjust the height of rack. Move the rack holder handle right and hang it on a proper position.
6. Pull out the rack, and put the food on the rack.
7. If the surface of food is charred, but inside food is not heating, lower the rack; if the food
cannot be heated fast or the surface of food cannot become golden color, raise the rack.
8. When nished turnoff main burner by rotating the knob clockwise to off position. Pilot should
remain lit.
9. If the appliance cannot operate properly, please contact the dealer.
10. For complete shutdown, ensure that all burner knobs are turned to the off position, and then
turn main gas supply off.

www.servware.com
800•768•5953
Service, Installation & Care Manual
7
CLEANING
MAINTENANCE
BRACKET OR STAND
ATTENTION
1. Carefully remove out the rack holder and rack, use wet cloth to clean them and then put
them in place. Don’t hit the rack in case that the enamel coating falls off.
2. Pull out the oil tray and clean it.
3. Clean the chamber.
Every day properly cleaning the appliance can keep it in a good operating condition and
extend the lifetime.
The lift mechanism should be regularly lubricated by heat resistance lubricant.
User can purchase wall-mounted bracket or stand from the manufacture.
• The heavy duty infrared burner plate is made of high temperature ceramics; it should be
carefully protected so as to keep a good combustion effect.
• The control knob is controlling the gas ow for each burner; a 90° angle of anti-clockwise
turning of knob can make the gas valve in a full open situation.
• Be careful not to be scalded when operating the appliance.
How to Clean:
Use wet cloth with mild solution to clean the appliance, and then use fresh water to wipe it.
Never use acid solution or alkaline solution to clean it, and don’t use wire brush to brush it, in
case that it will rust. For the same reason, also don’t use iron things to touch the appliance.
The important thing is that never use a water hose or pressurized steam cleaning equipment
to wash the appliance.

www.servware.com
800•768•5953
Service, Installation & Care Manual
8
TROUBLESHOOTING CHART
PROBLEMS POSSIBLE SOLUTIONS
The pilot ame cannot
be ignited
• The gas pressure is not high enough. Adjust the relive valve to
get a proper pressure.
• The nozzle is block. Please unblock the nozzle.
The pilot ame is lighted
but the main burner cannot
be ignited
• The gas pressure is not high enough. Adjust the relive valve to
get a proper pressure.
• The nozzle of the main burner is block. Unblock the nozzle.
• The gas control valve has problem. Ask the professional people
to repair or replace a new one.
Turn off the gas valve and
it has a lit-back sound
• The diameter of nozzle is not matched with the gas source.
Please adjust the nozzle diameter.
• The gas pressure is too low. Adjust the relief valve.
• Gas ow is not enough, increase the gas ow.
• The infrared ceramic plate may be broken.
It has red ame and
black smoke
• The diameter of nozzle is not matched with the gas source.
Please adjust the nozzle diameter.
• The gas is nearly used out. Replace the gas.
• Reduce the gas ow.

www.servware.com
800•768•5953
Service, Installation & Care Manual
9
MOUNTING BRACKET
WALL MOUNTING BRACKETS
• Are included
• Need to purchase the expansion bolts locally

www.servware.com
800•768•5953
Service, Installation & Care Manual
10
SERV-WARE PRODUCTS
LIMITED LABOR AND PARTS WARRANTY
SALAMANDERS
Serv-Ware Products warrants to the original owner/user that any Salamander manufactured by Serv-Ware Products (“the
products”) shall be free of defects in material or workmanship under normal and proper use and maintenance service as
specied by Serv-Ware Products and upon proper installation and start-up as well as for a period of one (1) year from
the original installation date or a maximum of eighteen (18) months after the shipment date from Serv-Ware Products.
The obligation of Serv-Ware Products and the rights and remedies of the owner/ user under this warranty are
exclusively limited to (1) the repair or replacement, including labor charges, of parts or assemblies that in Serv-
Ware Products opinion are defective within one year after the original date of installation; The labor warranty
shall include standard straight time labor charges at the product location only and shall exclude charges for travel time,
mileage or other premium charges. Any labor service required to fulll the warranty obligation must be performed by a
service company qualied and accepted by Serv-Ware Products.
(See Specication sheets for warranty period details.)
All claims for labor or parts must be made through Serv-Ware Products. The defective part for which labor
reimbursement is claimed, together with the service invoice, must be returned to the Serv-Ware Products within fteen
days from the date of service to be eligible for labor and parts warranty coverage. All replacement parts must be
approved Serv-Ware Products parts. Incidents of failure that do not require replacement of a part shall be explained in
sufcient detail on the service invoice to identify the failure. All claims shall include the product model number, serial
number, original date of installation and customer identication.
The foregoing warranty shall not apply to (1) any part or assembly (a) that has been altered, modied, or changed, (b)
that has been subjected to misuse, abuse, neglect or accidents, or (c) any Product on which the serial or model number
has been removed or altered, or (2) any Product that has been installed and /or maintained inconsistent with Serv-Ware
Product’s technical publications, or (3) any Product that has been installed or is located outside the standard warranty
coverage area. Warranty valid in United States only. Contact factory for warranty in other countries.
Serv-Ware Products assumes no liability for misuse or inadequate maintenance of the Product. In no event shall the
user by entitled to recover incidental or consequential damages, including but not limited to, damages for
inconvenience, food loss, rental or replacement equipment, loss of prots, or other commercial loss. Warranties
stated above are the only warranties made in connection with the sale and distribution of the Products. ANY AND ALL
OTHER EXPRESSED,STATUTORY AND IMPLIED WARRANTIES APPLICABLE TO THE PRODUCT INCLUDING,
WITHOUT LIMITATION, ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
EXPRESSLY DISCLAIMED. The warranty information set forth above shall be governed by and construed in accordance
with the lawsof the State of North Carolina and, if applicable, the laws of the United States of America. The warranty, as
stated, is extended only to the original owner/user and is not assignable.
This warranty does not include parts or labor coverage for component failure or other damage resulting from:
• External electrical power failure or miswiring to Product for any reason.
• Adverse operating conditions as set forth in the owner/user manual for the Product.
• Failure to clean and/or maintain Product as set forth in the owner/ user manual for the Product.
• Equipment use in a non-commercial setting.
“LIMITATION OF LIABILITY AND OTHER WARRANTIES”

www.servware.com
800•768•5953
Service, Installation & Care Manual
11
NOTES

www.servware.com
800•768•5953
Service, Installation & Care Manual
12
NOTES

www.servware.com
800•768•5953
Parts & Service Manuals Available at:
Products LLC.
222 Hwy 58 South
Kinston, NC 28504
