Server 81220 User manual

Twin Topping Warmer | with Pump
MODEL:
TWIN FS COMPLETE BASE ONLY
120V USA 81220 81210
MODEL:
TWIN FS/FSP COMPLETE BASE ONLY
120V USA 81290 81210
MODEL:
TWIN FSP COMPLETE BASE ONLY
120V USA 81230 81210
230V CONT. EUROPE 81260
230V UNITED KINGDOM 84990
...for purchasing our topping warmer.
Its temperature sensing thermostat helps reduce food
costs while delivering a superior product.
SERVE BETTER WITH DISTINCTIVE DESSERTS
Thank You
for purchasing a Server topping warmer. Its
temperature-sensing thermostat prevents
accidental overheating, so you can focus on
serving a superior product.
SERVE BETTER WITH DISTINCTIVE DESSERTS
Thank You

Page 2
SAFETY
WARNING-
ELECTRICAL SHOCK COULD OCCUR
This unit must be earthed or grounded.
This requires all three prongs (terminals) on cord
plug to be plugged into power source.
According to food and safety regulations, most
foods must be stored and/or served at certain
temperatures or they could become hazardous.
Check with local food and safety regulators for
specic guidelines.
Be aware of the product you are serving and the
temperature the product is required to maintain.
Server Products, Inc. can not be responsible for the
serving of potentially hazardous product.
PUMP
81320
230V units include:
STAINLESS STEEL JAR
94009
LID
82509
ADAPTER
82507
LADLE
82561
SPACER
82063
BASE
(see cover
for part
number)
WATER
VESSEL
BASIN
PARTS
PARTS MAY VARY DEPENDING ON UNIT
FS FSP

Page 3
UNIT SET-UP
WASH ALL PARTS PROPERLY BEFORE EVERY USE. See page 6.
SEE SEPARATE PUMP MANUAL FOR PUMP INSTRUCTIONS.
• Fill 2.5 cups (20 oz/0.59 liter) of water up to
water level line inside each basin.
• Do not overll.
FILL WATER VESSEL BASINS
1
SET THERMOSTAT KNOBS
INSTALL LID ACCESSORIES OR
PUMP(S)
7
4
PRESS SWITCHES to the “ON” position.
6
to food manufacturer’s recommended
serving temperature(s).
• Pull knobs out to turn and adjust.
• Push knobs in to lock.
• Dial indicators use increments of 5ºF.
• Thermostat range is 75º—210ºF.
(24º—99ºC)
• To heat unit faster, thermostat may
TEMPORARILY be rotated to maximum.
• Product being served must be
inside #10 cans or stainless steel jars.
Never place food directly into water
vessel basin of unit.
PUT FOOD CONTAINERS
INTO WATER VESSEL BASINS
3
INSERT SPACERS
2
TIP: Check water levels
throughout the holding period
to ensure even heating.
Filtered water is recommended
to deter corrosion.
TIP: Simplify change-outs
with stainless steel jars.
Order item #94009.
PLUG CORD into power source.
5

Page 4
1 1
2 2
3
PRE-HEAT UNIT
for at least 5 minutes
with:
• Correct amount of water in basin.
• Lid closed.
• Thermostat knob set at maximum setting.
ADD FOOD PRODUCT
• Put food which has already been
preheated to 150°F (66°C) into
container in water vessel basin.
• Maximum capacity of food product is
3 quarts (96 oz./12 cups). Do not overll.
PRE-HEAT UNIT
for at least 5 minutes
with:
• Correct amount of water in basin.
• Lid closed.
• Thermostat knob set at maximum setting.
ADD FOOD PRODUCT
• Put food container into the water
vessel basin.
• Maximum capacity of food product is
3 quarts (96 oz./12 cups). Do not overll.
MAINTAIN SAFE
HOT FOOD HOLDING
• After food reaches safe serving temperature
of 165°F (74°C), maintain product
temperature at or above 150°F (66°C).
• Adjust controller if needed to avoid
overheating food.
NSF International and ANSI (American National Standards Institute) list the
Twin FS model as a “Rethermalization and Hot Food Holding unit (Standard 4).”
The Twin FS/FSP & Twin FSP models are listed as a “Rethermalization unit (Standard 4).”
Rethermalization of food products is achieved by
this appliance when it elevates the food product
temperature from a refrigerated 40°F (4°C) to a
safe serving temperature of 165°F (74°C) within a
period of 2 hours.
Hot Food Holding is achieved with this appliance
when it maintains a food product temperature at or
above 150°F (66°C), in all locations throughout the
product, for a minimum of 2 hours, even if any lid,
cover, or pump is removed. The lid, cover, or pump is
recommended to help maintain product temperature.
MONITOR FOOD CLOSELY FOR FOOD SAFETY.
The United States Public Health Service
recommends that hot food be held at a minimum
of 140°F (60°C) to help prevent bacteria growth.
COLD FOOD IS NOT TO BE ADDED TO THE UNIT
FOR RETHERMALIZATION WHILE HOT FOOD IS
BEING HELD.
RETHERMALIZATION HOT FOOD HOLDING
SMART TIP
WITHOUT SPACER
Food may overheat from resting
on the bottom.
Water may overow into food
container.
Excess product may be left in
food container.
WITH SPACER
ALWAYS USE SPACERS
BENEATH FOOD CONTAINERS

Page 5
UNIT TAKE-DOWN
PRESS SWITCHES to the “OFF” position.
1
EMPTY WATER FROM
WATER VESSEL BASINS
after each use.
5
DRY
thoroughly with a soft dry cloth.
6
REMOVE PUMP(S) OR LID(S)
3
REMOVE FOOD CONTAINERS &
SPACERS
4
UNPLUG CORD
CAUTION- HOT
Allow unit to cool before continuing.
2
TIP: Remember to empty the water
each day rather than add—
This will greatly extend the life of
your warmer.
Proper drying after each use helps
maintain the stainless steel.
SEE SEPARATE PUMP MANUAL FOR PUMP INSTRUCTIONS.

Page 6
CLEANING
WARNING-
ELECTRICAL SHOCK COULD OCCUR
• Electrical components of unit could be
damaged from water exposure or any liquid.
• Never immerse unit into water or any liquid.
• Never use any water jet or pressure sprayer
on unit.
• Ensure unit is “OFF” and unplugged.
CAUTION- HOT
Allow unit to cool before cleaning.
WASH REMOVABLE PARTS
• Before rst use and after use daily,
disassemble and clean unit.
• Ensure unit is “OFF” and unplugged.
• Wash with dishwashing soap and hot water.
1
RINSE fully with clear water.
2
SANITIZE all parts according to local
sanitization requirements. All parts in contact
with food must be sanitized.
3
DRY all parts fully with a clean soft cloth.
4
CLEAN EXTERNAL SURFACES
• Wipe daily with a clean damp cloth.
• Dry with a clean soft cloth.
• Glass and surface cleaners approved for use
in food contact areas may be used.
5
• A mildly abrasive nylon or brass brush may
be used to remove any stubborn food or
mineral deposits on interior surfaces of unit.
• Fully rinsing and drying all parts can help
prevent corrosion. Elements and minerals in
tap water can accumulate on stainless steel
parts and create corrosion.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use products containing acids,
alkalines, chlorine, or salt. These agents can
corrode stainless steel.
• Do not use metal scrapers or cleaning pads
that could scratch surfaces.
This warmer and accessories
are constructed of stainless
steel— one of the best materials
for food serving and storage.
If you notice corrosion beginning on any stainless
steel surface, you may need to change the
cleansing agent, sanitizing agent, or the cleaning
procedures you are using.
CARE OF STAINLESS STEEL
SEE SEPARATE PUMP MANUAL
FOR PUMP INSTRUCTIONS.

Page 7
2A 1A
2 1
2A 1A
2 1
FLAG FLAG
BLUE
BROWN
YELLOW
GREEN
WIRING
Cord Assembly
Bushing/Strain Relief
Thermal Cut-Out
Rocker Switch
3
4
51
2
Wire Assembly, 13"
Wire Assembly, 9"
500W Heating Element
Thermostat
8
9
6
7
Wire Assembly, 4"
Wire Assembly, 13"
Hole Bushing
10
11
UNIT 81210 | 120V | USA
UNITS | 81260 & 84990
230V | CONT. EUROPE, UK
Cord Assembly
Wire Assembly
Rocker Switch
Thermal Cutout
Thermostat
3 8
4 9
5
1 6
2 7
500W Heating Element
Wire Nut
Strain Relief Bushing
Hole Bushing
BLACK
WHITE
G
REEN
FLAG
FLAG
2 1
2 1
2
1
2
1
1 8 2 3 4
5
6
7
9
11
2
1
10 5
4
9 8 67
3

Page 8 Manual#EM_01834_RevG_TwinToppingWarmerWithPump110922
GENERAL SERVICE,
REPAIR OR RETURNS
GRAPHIC TEMPLATES
UNIT DOES NOT HEAT?
• Ensure cord is securely plugged in.
• Ensure power is available from source.
• Ensure unit is on.
• Ensure thermostat knob is set correctly.
• Ensure
that the correct amount of water is in basin.
• Do not allow any of the electrical components
to get wet. Moisture may cause the unit to
trip breaker or GCFI. If moisture is suspected,
discontinue use. Allow unit to fully air dry.
PREVENT PITTING ON INSIDE
SURFACE OF VESSEL
• Empty water from water vessel basin each day.
• Thoroughly dry basin each day.
• If possible, use ltered water to ll vessel basin.
Before sending any item to Server Products for service,
repair, or return, contact Server Products customer
service to request a Return Authorization Number.
Merchandise must be sent to Server Products with this
number. Service is extremely prompt. Typically, units
are repaired and ship out within 48 hours of receipt.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days
old and will be subject to a 20% restocking charge.
Electrical parts (thermostats, heating elements, etc.)
are not returnable.
Servicing Cord: Specic tools are required for safe and
proper power supply cord removal and installation. If
cord must be replaced, only a representative of the
OEM (original equipment manufacturer) or a qualied
technician may replace cord. Cord must meet code
designation H05 RN-F requirements.
Would you like to add branding or imagery
onto your warmer?
Templates are available for download.
Please visit:
server-products/Graphics-01834.pdf
TROUBLESHOOTING
SERVER PRODUCTS
LIMITED WARRANTY
This Server product is backed by a two-year
limited warranty against defects in materials and
workmanship. See Server-Products.com for details.
NEED HELP?
Please be prepared with your Model, P/N and
Series located on the lid or base of the unit.
Example:
Chat with us!
[email protected]
262.628.5600 | 800.558.8722
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
MODEL
XXXX
P/N
#####
SERIES
##X ##X
