SERVIS S45514LMSS User manual

1
Single Door Larder Refrigerator
S45514LMSS
INSTRUCTIONS:
Please read and keep safe for future use.

2
Features…………………………………………………………………………………………………..
3Transportation instructions.........................................................................
4Introduction & safety warnings..................................................................
5Electrical Requirements/Installation...........................................................
Food Storage……………………………..................................................................
Defrosting...................................................................................................
Temperature Control / Cleaning and Care ………………………….………………….
Replacing the interior light bulb.................................................................
Top Tips ………………………………………………………………………………………………….
Problem solving........................................................................................
Health and Safety.....................................................................................
Warranty Information...............................................................................
1Customer Care ……………………………………………………………………………………….
INSTALLATION AND USER INSTRUCTIONS

3
1
Thermostat
2
Refrigerator Shelves
3
Crisper Cover
4
Salad Crisper
5
Adjustable Feet
6
Bottle Retainers
Features

4
•When transporting, never tilt to more than 45 degrees.
•The appliance should be transported only in a vertical upright position
•The packaging as supplied must be intact during transportation
•If during the course of transport the appliance has to be transported
horizontally, it must only be laid on its left hand side when standing in the
front of the appliance. After bringing it to the upright position, it must not
be operated for at least 4 hours to allow the system to settle. Shomar Ltd
will not be held responsible if these instructions are disregarded.
•The appliance must be protected against rain and moisture
•When positioning your appliance take care not to damage your flooring,
Kitchen furniture, related parts and doors, pipes, wall coverings etc.
•Empty any water in the drain tray before moving. See section ‘Defrosting’
and ‘Care & cleaning’ for further information
•Do not move the appliance by pulling by the door
•Hold the base and lift the refrigerator carefully
•Never hold the door handle as support
•Never place the refrigerator upside down or lie it down
•Move refrigerator by using its two hind roller feet as an axis and then
tilting it slightly to move
•Make sure that the defrost water pipe at the back of the product is fixed
to the plastic evaporating pan on the top of the compressor, to avoid
defrost water spillage on the floor.
IMPORTANT:
Care must be taken while cleaning / carrying the appliance to avoid
Touching the bottom of the condenser metal wires at the back of the
Appliance as you might injure your fingers and hands.
Make sure that mains cable is not caught under the appliance
During and after carrying / moving the appliance, to avoid the mains
Cable being damaged
Transportation of your Appliance

5
IMPORTANT! DO NOT connect your appliance to the electricity supply until all
Packing and transit protectors have been removed.
•Leave to stand for at least 4 hours before switching on to allow
compressor oil to settle if transported horizontally
•If you are discarding an old refrigerator with a lock or latch fitted to the
door, disable the lock/latch, ensure that it is left in a safe condition to
prevent the entrapment of young children
•This fridge/freezer must only be used for its intended purpose i.e. the
storing and freezing of edible foodstuff
•Do not dispose of the appliance on a fire
•Take care not to damage, the cooling circuit, if damaged immediately
ventilate the room where the appliance is situated
•This appliance should not be used in an unheated, cold room i.e. Garage,
conservatory, annex, shed, out-house etc.
•Ensure that the plug remains readily accessible
•Failure to observe these instructions may invalidate your right to free
service during the guarantee period
•We recommend a separate switch be used to ensure easy switch on / off.
•Children should be supervised to ensure that they do not play with the
appliance
•This appliance is intended to be used in a household environment
•Do not use mechanical devices or other means to accelerate the
defrosting process
WARNING: Keep ventilation openings, in the appliance enclosure or
In the built-in structure clear of obstruction.
Before First Use

6
Before you insert the plug into the wall socket make sure that the voltage and
The frequency shown in the rating plate inside the appliance corresponds to
Your electricity supply. We recommend that this appliance is connected to the
mains supply via a suitable switched and fused socket in a readily accessible
position.
Should the mains lead of the appliance become damaged or should it need
Replacing at any time, it must be replaced by a special purpose made mains
Lead which can only be obtained from Shomar Ltd.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted plug is not suitable for your socket, then the plug should be removed
and an appropriate plug fitted. Destroy the old plug which is cut off as a plug with
bared cord could cause a shock hazard if inserted into a socket. The plug on this
appliance incorporates a 13 A fuse. Should the fuse need to be a fuse of the same
rating must be used. Ensure that the fuse cover is refitted.
1. Install the refrigerator on a flat surface in order to prevent vibration and
noise.
2. Choose a dry well-ventilated place. A space of no less than 10cm must be
left around the refrigerator.
3. Minimum space in the room where the refrigerator is being installed is
than 10 cubic metres.
4. Choose a location where there is no heat source. Keep the refrigerator
away from direct sunlight, oven etc.
Electrical Requirements
Installation Instructions

7
5. Do not place the appliance near cookers, radiators or in direct sunlight as
This will cause your appliance to work harder. . If installed next to a
source of heat or freezer, maintain the following minimum side
clearances:
From Cookers 50 mm
From Radiators 300 mm
From Freezers 25 mm
Before you start using the fridge check that:
1. The interior is dry and air can circulate freely at the rear of the cabinet.
2. Clean the interior as recommended under "CLEANING AND CARE."
3. Insert the plug into the wall socket and switch on the electricity supply.
4. You will hear a noise as the compressor starts up. The liquid and gases
sealed within the refrigeration system may also give rise to noise,
whether the compressor is running or not which is quite normal.
5. When the door is open the fridge interior light will come on.
6. Set the thermostat (2) to 3 and close door. After 30 minutes you should
observe a drop in temperature.
7. Front edges of the cabinet may feel warm. This is normal.
8. Do not load the appliance immediately it is switched on. Wait until the
Correct storage temperature has been reached. We recommend that you
Check the temperature with an accurate
How to Use the Refrigerator Compartment:
•Cooked /fresh foods may be stored in your refrigerator. Hot foods must
first to allowed to reach room temperature before storage
•Eggs and Bottle’s should be stored on the shelves provided in the door
•Meat and fish should be covered to prevent loss of moisture and odours.
wrap such foods in aluminium foil or polythene or store in an airtight
container
Food Storage

8
•It is advisable to store cooked food on top shelves and fresh food on the
lower shelves to prevent cross contamination
DEFROSTING THE REFRIGERATOR
The fridge compartment defrosts automatically. The defrosting water runs
To the drain tube via a collection container at the back of the appliance. During
defrosting water droplets may form at the back of the fridge compartment where
the concealed evaporator is located. Some droplets may remain on the liner and
refreeze when defrosting is completed. Do not use pointed or sharp edged objects
such as knives, forks to remove the droplets which have frozen. If at any time the
defrost water does not drain from the collection channel, check to ensure that no
food particles have blocked the drain tube. The drain tube can be cleared
manually.
In case of a temporary ice build- up in the fridge compartment, reduce the
Thermostat setting to 1, monitoring at the same time that the fridge temperature
Is maximum +5 degrees C [41 degrees F]. Once the ice build-up disappears
And the appliance starts auto defrosting again as normal, then you may increase
The thermostat setting, if required.
The following guidelines and recommendations are suggested to obtain the
Best results:
1. Fresh wrapped produce can be placed on the shelf. Fresh fruit and
vegetables should be cleaned and stored in the crisper bins.
2. Bottles can be placed in the door section.
Defrosting
Arrangement of Food in the Fridge

9
3. To store raw meat, wrap in polythene bags and place on the lowest shelf.
Do not allow to come into contact with cooked food to avoid
contamination. For safety, only store raw meat for two to three days.
4. Keep the food packed wrapped or covered. Allow hot food and beverages
to cool before placing them in the fridge. Do not store explosive
substances.
5. High proof alcohol must be stored upright in sealed containers.
6. Left over canned food should not be stored in the can.
7. Fizzy drinks should not be frozen and products such as flavoured water
ices should not be consumed too cold.
8. Some fruit and vegetables suffer damage if kept at too low a
temperature. It helps to wrap pineapples, melons, cucumbers, tomatoes
and similar produce in polythene bags.
9. Place chilled cooked food and similar food near the rear of the fridge
inner liner where the cold wall is located.
10. Shelves, racks, crisper bins, drawers are all removable.
11. Do not leave frozen food at room temperature to thaw; the best way to
defrost food is to put it in the fridge to thaw slowly.
12. For hygiene reasons, always wrap food using a suitable packaging
material before storing in your appliance to avoid contact with the
appliance surface.
Temperature Control
The temperature of the appliance can be adjusted by turning the thermostat dial.
• The thermostat can be set between 1 and 7.
• 1 is the warmest setting.
• 7 is the coldest setting.
Temperature Control

10
• The recommended setting is 4.
• Set the dial to 0 to turn off the cooling function.
Internal temperature of the appliance can vary based on ambient temperature,
the quantity of items stored and how frequently the door is opened.
1. The thermostat located in the sidewall of the refrigerator
2. Turn the thermostat knob to increase the temperature.
3. Set the temperature selector to 4 positions for normal use
When the appliance is switched on for the first time, the setting knob should be
Adjusted so that after 24 hours, the average fridge temperature is no higher
Than +5 degrees Celsius.Some sections of the fridge may be cooler or warmer
(such as the salad crisper and the top part of the cabinet) which is quite normal.
We recommend that you check the temperature with an accurate thermometer
To ensure that the storage compartments are kept to the desired temperature.
Please remember each time the door is opened cold air escapes and the internal
Temperature rises. Therefore never leave the door open and ensure it is closed
Immediately after food is put in or removed.
•We recommend that you switch off the appliance at the socket outlet and
pull out the mains plug before cleaning
•Never use any sharp abrasive instrument, soap, household cleaner,
detergent and wax polish for cleaning
•Use lukewarm water to clean the cabinet of the appliance and wipe it dry
•Wipe the inside and outside of refrigerator with a damp soft cloth, a soft
cloth with a mild detergent may also be used if required.
•Make sure that no water enters the lamp housing
•Clear the defrost drain situated at the back
•Check door seals regularly to ensure they are clean and free from food
particles
Cleaning and Care

11
•To remove door racks, remove all the contents and then simply push the
door rack upwards from the base
•To remove a freezer drawer, pull it as far as possible, and then tilt it
upwards, and then pull it out completely
If you are going away on holiday or for any other reason, wish to leave the
refrigerator idle for any period of time, proceed as follows:
•Disconnect the refrigerator from the electric power supply by removing
the plug from the wall socket
•Remove all food
•Clean and dry the inside as instructed in the direction given above for
cleaning
•Leave the doors open to prevent any unpleasant smells from building up
while the refrigerator is not used
1. Before carrying out the bulb replacement always press and turn the
thermostat control to dial to position “OFF”, then disconnecting the mains
supply.
2. Hold and lift up the light bulb cover.
3. Remove the old bulb by unscrewing it in an anti-clockwise direction.
4. Replace with a new bulb (Max.10W) by screwing it in a clockwise direction
marking sure that it is secure in the bulb holder.
5. Refit the light cover and re-connect your Fridge/Freezer to the mains supply
and switch on.
•Clean and defrost your appliance regularly
•Keep raw meat and poultry below cooked food and dairy products
•Take off any unusable leaves on vegetables and wipe off any soil
•Wrap cheese firstly in greaseproof paper
•Wrap raw meat and poultry loosely in polythene or aluminium foil
Replacing the Interior Light Bulb
Top Tips

12
•Wrap fish and offal in polythene bags
•Wrap food which have a strong odour in polythene bags, aluminium foil
or place in an airtight container
•Wrap bread well to keep it fresh
•Keep food for as short a time as possible and adhere to "Best Before""Use
by" etc. dates
•Store commercially frozen food in accordance with the instructions given
on the packets that you buy
•Prepare fresh food for freezing in small portions to ensure rapid freezing
•Don't store bananas or melon in your fridge compartment
•Don't store poisonous or any dangerous substances in your appliance
•Don't consume food which has been stored for an excessive time in the
fridge
•Don't leave the door open for long periods as this will make the appliance
more costly to run and cause excessive ice formation
•Don't put hot food into the appliance
•Keep electrical cable away from all sources of heat / high temperature
•Keep ventilation openings clear of obstructions
•The appliance should only be used indoors and should not be exposed to
rain or moisture
•Don't place any heavy objects onto the refrigerator
ENERGY SAVING TIPS
•Ensure your appliance is installed in a well ventilated area. If the ambient
temperature is low (but in no case lower than 5 degrees C), then the
energy saving will be more
•Do not leave the door of your appliance open longer than necessary and
ensure they are closed properly after each opening.

13
Check the following:
•That the plug is inserted properly in the socket and that the power supply
is on
•That the fuse has blown/circuit breaker has tripped/main distribution
switch has been turned off
•That the temperature control has been set correctly
•That the plug is wired correctly if you have changed the fitted plug
If the appliance is still not operating after the above checks, please contact
Shomar Ltd, see contact details.
Please ensure that the above checks have been made as a charge will be made
if no fault is found.
Working Defects and Failures
Symptom: Appliance will not work at all.
Cause: The power supply plug is not inserted in the wall socket or the
plug and the outlet is loose.
To test the supply socket a lamp or small electrical appliance may be used to
check that the socket is working.
Symptom: Noisy running.
Cause: The appliance has not been properly levelled.
The refrigerator contact with the wall or the accessories in the refrigerator are
placed wrong position.
Symptom: Appliance does not cool sufficiently.
Problem Solving

14
Cause: Door has been opened too often, or for too long a time
There may be too much food in the refrigerator, possible incorrect temperature
selection
Symptom: Smell inside the appliance.
Cause: Some of the food is not properly wrapped or covered.
The inside of the refrigerator needs cleaning; Liquids such as milk may have been
spilled in the fridge.
The following are normal:
•Refrigerant running in pipes gives a gentle sound of water running in pipes
•In high humidity the outer surface of the refrigerator may be covered with
condensation that should simply be wiped away
•The compressor and the rear condenser will become hot and should not
be touched.
If after checking all of the above and the problem persists contact the Shomar
Service Department
The use of any electrical appliance requires the following common sense
safety rules. There is danger of injury or death to the person and damage to
the appliance.
Location
•This appliance is intended to be used in household and residential type
environments. It is not suitable for use in shops, offices and other
working environments.
•Do not use outdoors or in a bathroom
•Do not place appliance on a highly polished wooden surface as damage
may occur to the surface
Health & Safety

15
•Do not place the appliance on or near a hot surface
•This appliance should not be used in an unheated, cold room i.e. Garage,
conservatory, annex, shed, out-house etc.
Mains Cable
•Do not let the lead run across an open space
•Do not let the cable run across a cooker or hot area which may damage
the cable
•The mains cable should reach from the socket to the base unit without
straining the connections
•The power cord cannot be replaced
Personal Safety
•Avoid touching moving parts. Keep hands, hair and clothing and utensils
away from the appliance and fan to prevent personal injury and/or
damage to the appliance.
•To protect against the risk of electric shock ensure the electrical
connections are kept dry
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities
Children
•Children should be supervised to ensure that they do not play with this
appliance
•Teach children to be aware of dangers in the kitchen
•Do not allow children to play with the appliance or tamper with the
controls.
Other Safety Considerations
•Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner

16
•The use of attachments or tools not pertaining to this appliance may
cause fire, electric shock or injury
•Do not use the appliance for anything other than its intended purpose
•Unplug from the outlet when not in use or unattended and before
assembling, disassembling and cleaning
•Make sure the appliance is switched off before connecting to or
disconnecting from the mains supply
•If the appliance is dropped or damaged in any manner, return the
appliance to the nearest authorized dealer or after-sales service centre for
examination, repair, electrical or mechanical adjustment
Registering Your2 Year Guarantee
Your standard one year guarantee is extended for an additional 1 year when you
register the product within 28 days of purchase with the supplier Shomar Ltd. If
you do not register the product with Shomar Ltd within 28 days, your product is
guaranteed for 1 year. To validate your 2 year guarantee register with us by
visiting www.servisappliances.ie
Please note that the 2 year guarantee is only available in Ireland.
Please refer to the one year guarantee for more information.
One Year Guarantee
It is important to retain the retailer’s receipt as proof of purchase. Staple your
receipt to this back cover for future reference.
Please quote the following information if the product develops a fault. These
numbers can be found on the product.
Model no.
Serial no.
Warranty Information.

17
Subject to the exclusions set out below (see Exclusions), the faulty appliance will
then be repaired or replaced. If for any reason, this item is replaced during the
guarantee period, the guarantee on the new item will be calculated from original
purchase date. Therefore it is vital to retain your original till receipt or invoice to
indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must have been used according
to the instructions supplied.
Exclusions
Shomar Ltd shall not be liable to replace or repair the goods under the terms of
the guarantee where:
1. The fault has been caused or is attributable to accidental use, misuse,
negligent use or used contrary to the manufacturer’s recommendations
or where the fault has been caused by power surges or damage caused in
transit.
2. The appliance has been used on a voltage supply other than that stamped
on the products.
3. Repairs have been attempted by persons other than our service staff.
4. The appliance has been used for hire purposes or non-domestic use.
5. The appliance is second hand.
This guarantee does not confer any rights other than those expressly set out
above and does not cover any claims for consequential loss or damage. This
guarantee is offered as an additional benefit and does not affect your statutory
rights as a consumer.
This guarantee is valid in Ireland and the UK only.
Servis products are intended for household use only. See usage limitations within
the location safety instructions.
Shomar Ltd has a policy of continuous improvement in product quality and design.
The company, therefore reserves the right to change the specification of its
models at any time.

18
The After Sales Division for Servis Appliances is located at the offices of the Brand
owner and Distributor –
Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland.
Helplines (office hours) & Spare Parts contact number is 01-450 5327 or email
[email protected]
.
Contact Details

19
