SGM GENIO MOBILE User manual

Vi ringraziamo per aver acquistato un prodotto SGM.
Per ottenere i migliori risultati dal suo utilizzo, vi preghiamo di leggere attentamente questo manuale di istruzioni.
Al suo interno troverete le informazioni tecniche e le specifiche d’uso del prodotto. Nelle pagine in appendice tro-
verete inoltre schemi e diagrammi destinati all’assistenza tecnica.
Nell’ottica di qualità SGM, è possibile che l’Azienda apporti migliorie ai suoi prodotti, per cui consigliamo di alle-
gare il manuale al prodotto stesso e di trascrivere il numero di serie nell’ultima pagina della copertina: utilizzando
il presente manuale con un apparecchio fabbricato prima o dopo la sua stampa, potrebbero esserci discrepanze
fra l’apparecchio e quanto riportato nel Manuel stesso.
Thank you for buying an SGM product.
To obtain the best results, please carefully read this instruction manual in which you will find technical information
and specifications for use of the product, as well as diagrams for technical service in the appendix.
In light of SGM quality, the company may make improvements to its products. Therefore, we recommend that the
manual be attached to the product and the serial number copied onto the back cover: using this manual with
equipment manufactured before or after its printing, might show discrepancies between the equipment and the
information listed in the manual.
Wir danken Ihnen für den Kauf eines Produkts von SGM.
Zur Erzielung der besten Resultate bei der Benutzung bitten wir Sie, die vorliegende Bedienungsanleitung aufmerk-
sam zu lesen. Darin finden Sie die technischen Informationen sowie die Anweisungen für die Benutzung des
Produkts. Im Anhang befinden sich auBerdem die Schaltpläne undv Diagramme für den Kundendienst.
SGM behält sich das Recht vor, Verbesserungen an den Produkten vorzunehmen und deshalb empfehlen wir, die
Bedienungsanleitung dem Produkt stets beizulegen und die Seriennummer auf der letzten Seite des Umschlags
einzutragen. Bei der Verwendung dieses Handbuches mit einem Gerät, das vor oder nach der Drucklegung produ-
ziert wurde, können sich Abweichungen zwischen Gerät und dem Inhalt des Handbuches ergeben.
Nous vous remercions d’avoir acheté un produit SGM.
Pour optimiser son utilisation, nous vous prions de bien vouloir lire attentivement cette notice où vous trouverez
les informations techniques et les caractéristiques d’utilisation du produit. En outre, vous trouverez également,
dans les pages en appendice, les schémas et les diagrammes concernant l’assistance technique.
Le concept de qualité SGM, lui permet d’améliorer continuellement ses produits et c’est pourquoi nous vous con-
seillons de joindre la notice au produit et d’inscrire le numéro de sèrie sur la page de couverture. En effet, si on
l’utilise avec un appareil fabriqué avant ou après son impression, il peut y avoir des différences entre l’appareil et
ce qui figure dans la notice.
Les estamos sumamente agradecidos por haber elegido un producto SGM.
Para obtener los mejores resultados, les rogamos leer detenidamente el presente manual de instrucciones. El
mismo contiene las informaciones técnicas y las indicaciones de uso del producto. Las páginas anexas contienen
además los esquemas y diagramas necesarios para la asistencia técnica.
Para mantener la calidad SGM, es posible que la Empresa aporte mejoras sus productos, por ello les aconsejamos
conservar el manual junto con el aparato correspondiente y escribir su número de serie en la última página del
manual; si en cambio se utiliza el presente manual con un aparato frabicado antes o después de su impresión, es
probable que existan discrepancias entre el aparato y las indicaciones del mismo.

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 1 -
Table of Contents
S YMBOLS USED ............................................................................................................... 3
C HANGES TO THIS MANUAL ................................................................................................. 4
G ENERAL W ARNINGS ........................................................................................................ 4
G ENERAL W ARRANTY C ONDITIONS ........................................................................................ 5
1 I NTRODUCTION ......................................................................................................................... 6
1.1 M AIN F EATURES ...........................................................................................................................
L EDS ......................................................................................................................................................................6
L ENSES ...................................................................................................................................................................6
F UNCTION ...............................................................................................................................................................6
C ONTROL S IGNALS ..................................................................................................................................................6
M ICRO C OMPUTER ...................................................................................................................................................7
M OTORS .................................................................................................................................................................7
1.2 G ENIO M OBILE F UNCTIONS .............................................................................................................8
U SITT DMX 512 ......................................................................................................................................................8
C OOLING ................................................................................................................................................................8
C OLOUR ..................................................................................................................................................................8
L EDS ......................................................................................................................................................................8
D IMMER ..................................................................................................................................................................8
S HUTTER .................................................................................................................................................................8
M ACRO ...................................................................................................................................................................8
M EMORIES ..............................................................................................................................................................8
D ISPLAY ..................................................................................................................................................................8
S OFTWARE U PDATE .................................................................................................................................................9
R EMOTE INFRARED CONTROL ....................................................................................................................................9
1.3 M ECHANICAL SPECIFICATIONS ........................................................................................................10
1.4 E LECTRICAL SPECIFICATIONS ..........................................................................................................11
U SER I NTERFACE ...................................................................................................................................................11
L ENSES .................................................................................................................................................................11
L EDS ....................................................................................................................................................................11
1.5 O PTIONAL A CCERRORIES ..............................................................................................................11
2 I NSTALLATION ........................................................................................................................ 12
2.1 U NPACKING THE FIXTURE ..............................................................................................................12
2.2 I NSTALLING THE FIXTURE ON A SUPPORT STRUCTURE ............................................................................13
2.3 P OSITIONING THE FIXTURE ............................................................................................................13
2.4 I NSTALLING THE METAL HANDLE FIXING PLATE .....................................................................................14
2.5 I NSTALLING VIA THE F AST -L OCK “G” CLAMPS .....................................................................................15
2. I NSTALLING VIA THE “A LISCAF ” CLAMP ..............................................................................................1
2.7 W ALL MOUNTING ........................................................................................................................17
2.8 I NSTALLING OPTIONAL LENSES ........................................................................................................18
R EMOVING / I NSTALLING THE F RONT L ENS P LATE ...................................................................................................18
2.9 P OWER CORD CONSTRUCTION ........................................................................................................20
2.10 C ONSTRUCTION OF THE SIGNAL CABLE ..............................................................................................21
2.11 S IGNAL C ABLE WIRING CONNECTIONS ...............................................................................................21
2.12 C ONSTRUCTION OF THE DMX TERMINATION .......................................................................................22
2.13 I NFRARED REMOTE CONTROL ..........................................................................................................23
2.14 RS-232 C ONNECTION .................................................................................................................23
2.15 U PGRADING F IRMWARE ................................................................................................................24
3 M ICRO C OMPUTER C ONTROL ..................................................................................................... 2
3.1 M ICROCOMPUTER “C ONTROL ” ........................................................................................................25
3.2 N AVIGATING THE MENU ................................................................................................................25
3.3 S TRUCTURE OF THE M ENU .............................................................................................................2
3.4 A DDRESSING .............................................................................................................................28

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 2 -
3.5 PAN M OVEMENT ........................................................................................................................28
3. PAN M INIMUM POSITION ..............................................................................................................28
3.7 PAN M AXIMUM POSITION .............................................................................................................29
3.8 TILT M OVEMENT .......................................................................................................................29
3.9 TILT M INIMUM POSITION .............................................................................................................29
3.10 TILT M AXIMUM POSITION .............................................................................................................29
3.11 S WAP ......................................................................................................................................29
3.12 C OLOR B ALANCE .........................................................................................................................30
3.13 B ALANCE ..................................................................................................................................30
3.14 E LAPSED TIME METER ...................................................................................................................30
3.15 I NPUT S IGNAL ...........................................................................................................................31
3.1 PAN AND TILT CONTROL ..............................................................................................................31
3.17 D ISPLAY BRIGHTNESS ...................................................................................................................31
3.18 DMX DELAY ..............................................................................................................................31
3.19 D AY OF THE WEEK .......................................................................................................................31
3.20 T IME .......................................................................................................................................32
3.21 S ETTING DEFAULT PARAMETERS ......................................................................................................32
3.22 R ESETTING DEFAULT PARAMETERS ...................................................................................................32
3.23 T EST FUNCTION .........................................................................................................................33
3.24 H EAD AND MOTORS CARD TEMPERATURE ...........................................................................................33
3.25 C ONFIGURING AS M ASTER .............................................................................................................33
3.2 C ONFIGURING S LAVES .................................................................................................................33
3.27 E NABLING -D ISABLING THE S CHEDULER .............................................................................................34
3.28 I NTERNAL PROGRAM PLAYBACK .......................................................................................................34
3.29 P ROGRAMMER ............................................................................................................................34
3.30 S CHEDULER ...............................................................................................................................34
3.31 E RROR MESSAGE .........................................................................................................................35
4 C ONTROL C HANNELS ................................................................................................................ 36
4.1 C ONTROLLING THE FIXTURE VIA DMX...............................................................................................3
D IMMER C HANNEL C H 2........................................................................................................................................36
R ED C HANNEL C H 3..............................................................................................................................................36
G REEN C HANNEL C H 4..........................................................................................................................................36
B LUE C HANNEL C H 5.............................................................................................................................................36
S TROBE C HANNEL C H 1.........................................................................................................................................37
M ACRO C HANNEL C H 7..........................................................................................................................................37
C OLOUR M ODE C HANNEL C H .............................................................................................................................37
CTC (C OLOUR T EMPERATURE C ORRECTION ) C HANNEL C H 6..................................................................................37
M SPEED (M OVEMENT S PEED ) C HANNEL C H 13 ......................................................................................................38
5 O PERATING THE FIXTURE .......................................................................................................... 40
5.1 W HITE B ALANCING .....................................................................................................................40
5.2 C OLOUR T EMPERATURE C ONTROL (CTC C HANNEL ) ..............................................................................40
5.3 I NFRARED (IR) USE .....................................................................................................................40
5.4 S TAND A LONE PROGRAMMING ........................................................................................................41
5.5 P ROGAMMING G ENIO M OBILE .........................................................................................................41

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 3 -
Symbols used
This manual uses graphic symbols to emphasize any hazards during the operation work described.
THIS SYMBOL INDICATES A GENERAL HAZARD
THIS SYMBOL INDICATES ELECTRIC SHOCK RISK
THIS SYMBOL INDICATES A HOT SURFACE
THIS SYMBOL MEANS “DO NOT PLACE THE UNIT ON INFLAMMABLE PARTS OR MATERIAL”
Changes to this manual
SGM has an on-going product development policy, so the information printed in this manual may not be
completely up to date.
If any doubts arise regarding the topics covered in this manual or should any further help be required, our
online services (internet-server www.sgm.it) are available 24 hours a day. In the FAQ section of the
technical assistance zone, answers can be found to numerous common queries: fixtures, firmware and
manuals can also be downloaded whenever required.

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 4 -
General Warnings
Read the instructions in this handbook carefully, as they give important information regarding safety during
installation, use and maintenance.
Be sure to keep this instructions manual with the fixture, in order to consult it in the future. If
the fixture is sold or given to another operator, make certain he or she also receives the manual,
to be able to read about its operation and follow the relative instructions.
•THIS UNIT IS NOT FOR HOME USE, ONLY PROFESSIONAL APPLICATIONS.
•AFTER HAVING REMOVED THE PACKAGING, CHECK THAT THE FIXTURE IS NOT DAMAGED IN ANY WAY.
IF IN DOUBT , DON'T USE IT AND CONTACT AN AUTHORIZED SGM TECHNICAL SERVICE CENTRE.
•PACKAGING MATERIAL (PLASTIC BAGS, POLYSTIRENE FOAM, NAILS, ETC) MUST NOT BE LEFT WITHIN
CHILDREN’S REACH AS IT CAN BE DANGEROUS.
•THIS FIXTURE MUST ONLY BE OPERATED BY ADULTS. DO NOT ALLOW CHILDREN TO TAMPER OR PLAY
WITH IT.
•ELECTRICAL WORK NECESSARY FOR INSTALLING THE FIXTURE MUST BE CARRIED OUT BY A
QUALIFIED ELECTRICIAN OR EXPERIENCED PERSON. (CAREFULLY READING THIS MANUAL).
•NEVER USE THE FIXTURE UNDER THE FOLLOWING CONDITIONS:
oIN PLACES SUBJECT TO EXCESSIVE HUMIDITY
oIN PLACES SUBJECT TO VIBRATIONS OR DUMPS
oIN PLACES WITH A TEMPERATURE OVER 45° OR LOWER THAN 2°C
•PROTECT THE FIXTURE FROM EXCESSIVE DRYNESS OR HUMIDITY (IDEAL CONDITIONS ARE BETWEEN
35 AND L’80%).
•DO NOT DISMANTLE OR MODIFY THE FIXTURE.
•MAKE CERTAIN THAT NO INFLAMMABLE LIQUIDS, WATER OR METAL OBJECTS ENTER THE FIXTURE.
•SHOULD ANY LIQUID BE SPILLED ON THE FIXTURE, DISCONNECT THE POWER SUPPLY FROM THE
FIXTURE IMMEDIATELY.
•IN THE EVENT OF SERIOUS OPERATING PROBLEMS, STOP USING THE FIXTURE IMMEDIATELY AND
EITHER CONTACT THE NEAREST SGM SALES POINT FOR A CHECK OR CONTACT THE MANUFACTURER
DIRECTLY.
•WAIT AT LEAST 30 MINUTES FROM THE FIXTURE’S POWER OFF BEFORE OPENING THE COVER.
•NEVER TRY TO REPAIR THE FIXTURE YOURSELF. REPAIRS BY UNQUELIFIED PEOPLE COULD CAUSE
DAMAGES OR FAULTY OPERATIONS. CONTACT YOUR NEAREST AUTHORIZED SERVICE CENTRE.
•WHEN CARRYING OUT ANY WORK, ALWAYS COMPLY SCRUPULOUSLY WITH ALL THE NORMS
(PARTICULARLY REGARDING SAFETY) CURRENTLY IN FORCE IN THE COUNTRY IN WHICH THE
FIXTURE’S BEING USED.
•DO NOT PLACE THE UNIT ON INFLAMMABLE PARTS OR MATERIAL.
A LWAYS INSIST ON ORIGINAL SPARE PARTS BEING FITTED

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 5 -
Ge eral Warra ty Co ditio s
This unit is guaranteed for 24 months from the date of purchase against manufacturing material
defects.
Breakdown caused by carelessness and improper use is excluded.
The guarantee is no longer valid if the unit has been tampered with or repaired by unauthorized
personnel.
Replacement of the fixture is not foreseen by the guarantee.
External parts, knobs, switches, removable parts and lamps are excluded from the guarantee.
Transport costs and related risks are borne by the fixture’s owner.
The guarantee is valid to all effects only on presentation of the guarantee certificate to the
manufacturer or to the nearest SGM technical assistance centre.
Always quote the unit’s serial number and model when contacting your reseller for information or
assistance.
Protect the e viro me t: do 't throw packi g material i to your garbage ca retur it to your
SGM retailer or take it to the earest special waste collectio poi t.

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 6 -
1 INTRODUCTION
1.1 Main Features
Compact, agile and able to ensure even, perfectly controllabe wash lighting generated by 16 high power
Luxeon L Ds.
All this is offered by SGM’s Genio Mobile, a reliable high-tech colour changing fixture with features that
make it ideal for applications in buildings, museums, art galleries and shopping centres.
Thanks to its motorized Pan and Tilt and to a protection rate IP65, Genio Mobile is also a practical
flexible unit, so indispensable for theatre and TV lighting professionals.
L DS
Genio Mobile fixtures use LED (Light Emitted Diode) technology as a light source. A series of LED points
mounted on a matrix enables to generate an evenly distributed light beam, suitable for illuminating large
areas. The three types of LED (Red, Green and Blue) that make up the matrix enable la realize and control
any colour of light beam, with perfectly balanced colour at all times.
L NS S
Each Genio Mobile LED is fitted with an interchangeable high efficiency lens. The lens matrices available
enable to project light beams with the following projection angles:
 °
25 °
F UNCTION
RGB colour mixing
Linear Dimmer
Adjustable strobe effects
Colour rainbow effect on pre-programmed Macros
Motorized Pan and Tilt movement
Pan 540°
Tilt 270°
Setting via on-board microcomputer viewable on dispaly
Adjustable display brightness
LED power reduction in the event of overheating
Elapsed time meter for each colour channel Red, Green, Blue
General fixture operating time meter
Master/Slave capabilities
C ONTROL S IGNALS
DMX 512 or RS 232 input signal
Stand-alone operation with built-in programming
Independent day to day control of the on-board programs on a weekly basis
Independent operation of systems with up to 30 fixtures, via Master – Slave links
Infrared (IR) remote controlled

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 7 -
M ICRO C OMPUT R
Fixture personalization according to the type of installation
Test functions for each effect
Fixture addressing via the unit’s display
Access menu for on-board programming functions
Menus for access to calendar and event scheduling programming functions
Firmware upgrade through DMX
M OTORS
2 stepper motors for the movements of PAN and TILT that absorb 12 watt (6 watt each)

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 8 -
1.2 Genio Mobile Functions
U SITT DMX 512
All the Genio Mobile functions can be controlled via USITT standard DMX 512 serial digital signals, or via RS
232 serial signals. Genio Mobile generates a proprietary data transmission protocol when systems run
directly by on-board programming of a Master-Slave nature are used
Genio Mobile requires six channels to control all its attributes. All parameters are controlled and
programmed by an on-board MOTOROLA DSP 56F 03 processor
C OOLING
The radiator on the rear panel of the LED matrix ensures correct convection cooling. A self-adjusting
internal temperature system ensures continuous operation even in critical thermal conditions.
C OLOUR
Three groups of Red, Green and Blue LEDs make up the matrix that generates Genio Mobile’s light beam.
Their layout in the matrix ensures that the emitted light can be controlled as far as Colour, Intensity and
Temperature are concerned. Genio Mobile’s colour generation system is therefore based on the concept of
additive colour mixing, where the sum of the various intensities of Red, Green and Blue, (RGB) enables to
create any other colour with the required tone or saturation
L DS
The source of the Genio consists in 3-Watt LUXEON LEDs, each generating a maximum luminosity of 0
lumen.
D IMM R
The electronic control of the luminous intensity of the LEDs ensures precise emission adjustment, without
colour or colour temperature variation over the entire range from 0 to 100 %, in a regular uniform manner.
S HUTT R
The shutter control parameter ensures instant light beam opening and closing effects. The characteristics of
the LEDs allow to obtain strobe effects with adjustable or random flash power and rate with exceptional
precision and intensity, thanks to the lack of any mechanical form of beam blackout.
M ACRO
The Macro parameter allows to select via DMX a series of preset on-board colour and dimmer (or
combined) effects whenever they are required. Rainbow effects with different speeds and random or
Colour-dimming and Color-strobe, can be enabled without having to be programmed beforehand.
M MORI S
Comprehensive programming can be carried on-board the fixture, thus enabling playback in a fully stand-
alone status without the aid of external DMX control. It’s also possible to program playback times and
modes in the space of 24 hours, with a 7-day repetitive cycle.
Complete stand-alone systems can be realized, with absolutely no external controls and up to 30 fixtures;
with operating times and modes programmed and controlled using Master/Slave connections.
One Show made up of ten scenes can be programmed on each fixture.
D ISPLAY
Genio Mobile has a 2 lines 16 characters display for user-friendly navigation through the fixture’s setting,
diagnosis and programming menus. Flip, Dimm (brightness) and ON/OFF functions are available to
facilitate consultation and use.

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 9 -
S OFTWAR U PDAT
The fixture’s software can be updated from a Personal Computer via RS 232 serial or USB connector cable.
(not included) Updating allows to improve the fixture’s performance through time. Genio Mobile software
will be available on the SGM web site.
R MOT INFRAR D CONTROL
Genio Mobile can be controlled not only through the DMX 512 signal, widly used in the lighting
entertainment field¸ but also through an easy Infrared remote controller able to handle all the functions
availale on the fixture.
The use of the Infrared remote controller find its application in the architectural field such as shopping
centers, malls, or museum where is not strictly necessary a DMX lighting desk to handle the fixtures and
that can results difficult to understand to those operators not accustomed to such specific devices.

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 10 -
1.3 Mechanical specifications
Fixture made up of a twin body: Base + Head.
The base is made up of a die-cast unit containing the power supply, display, three buttons and two
watertight cable glands for mains supply and DMX cables.
Genio mobile can be floor-mounted (or on any other flat surface) without fixing, remaining steady no
matter what the angle of the head.
Concerning the truss or wall mounting applications, the fixture is supplied with an additional handle plate
provided with fixing point either for wall mounting or clamps for trussing.
The head is made up of a radiator (in drawn aluminium), on which the LED matrix and lenses are fitted.
The head can be moved in relation to the base: PAN 540° and TILT 270°.
Material resistant to weather and any acts of vandalism (shatter-proof glass)
P ROT CTION RAT : IP65
W IGHT : 5,3 Kg
D IM NSIONS :

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 11 -
1.4 lectrical specifications
Luminous power: 65 Watt
Power absorbed: 90 Watt
Full-range PFC power supply (does not distort the mains power supply): 90-270V AC, 50-60 Hz
U SER I NTERFACE
2 lines Display with 16 alphanumerical digits
control panel with three buttons
L NS S
Lenses mounted on an interchangeable plate (all the lenses are in a single block) with various beam apertures:
10°
25°
L DS
4 led Blue Luxeon 3 Watt
 led Verde Luxeon 3 Watt
4 led Rosso Luxeon 3 Watt
1.5 Optional Accerrories
Aliscaf Clamp
Safety chain

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 12 -
2 INSTALLATION
2.1 Unpacking the fixture
During unpacking, make certain that all the necessary parts have been received and that the fixture has
not been damaged during transport. Should there be any problems, contact the local authorized SGM
distributor immediately.
Only the customer, in fact, can claim eventual damages in the fixture caused by the transportation.
Genio Mobile fixture
Warranty Label
User manual
Additional fixing handle plate
° Lens Kit
Safety Chain
DO NOT D SP RD TH PACKING L M NTS.
THE PACKING ELEMENTS (PLASTIC BAGS, FOAM, NAILS, ETC.), MUST NEVER BE LEFT NEAR CHILDREN, AS
DANGEROUS. USE THE ORIGINAL PACKAGE IN CASE OF FIXTURE RETURN TO THE MANUFACTURER FOR
REPAIR OR MAINTENANCE SERVICE, IT HAS BEEN SPECIFICALLY MADE TO PROTECT THE FIXTURE
DURING THE TRANSPORT.

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 13 -
2.2 Installing the fixture on a support structure
Read the following safety information before proceeding with the installation of the fixture:
•ONLY FOR PROFESSIONAL APPLICATIONS.
•DO NOT PLACE THE UNIT NEAR SOURCES OF HEAT
•INSTALL THE FIXTURE IN A WELL VENTILATED PLACE.
•NEVER USE THE FIXTURE UNDER THE FOLLOWING CONDITIONS:
oIN PLACES SUBJECT TO EXCESSIVE HUMIDITY
oIN PLACES SUBJECT TO VIBRATIONS OR DUMPS
oIN PLACES WITH A TEMPERATURE OVER 45° OR LOWER THAN 2°C
•
•DO NOT PLACE THE UNIT ON INFLAMMABLE PARTS OR MATERIAL.
•PROTECT THE UNIT FROM EXCESSIVE HUMIDITY (IDEAL VALUES ARE BETWEEN 35 AND 0%).
•AVOID INFLAMMABLE LIQUIDS, WATER OR METALLIC OBJECT ENTERING THE FIXTURE.
2.3 Positioning the fixture
Can be installed in any position.
OK OK
OK

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 14 -
2.4 Installing the bracket
Genio Mobile Mobile is an automated colour-changing fixture suitable for use in decorative/architectural and
show lighting. The type of installation can therefore be varied according to its use.
Genio Mobile can be permanently mounted, in the case of fixed installations, by means of a bracket
supplied along with the fixture, where it will be possible to fit clamps or any other accessories used for
trussing or wall mounting purposes.
. The bracket can be installed on the bottom of the fixture by means of the 4 screws supplied as
standard along with the fixture.

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 15 -
2.5 Installing via the Fast-Lock “G” clamps
The Genio Mobile can be hung on any support or truss structure using Fast-Lock “G clamps. There are no indications
against using any particular position for the clamps in the fixture’s base.
. Insert the quick-lock fasteners of the Fast-Lock “G” clamp into the respective holes on the bracket.
2. Tighten the quick-lock fasteners fully clockwise.
3. Pull the safety-chain through the holes on the bottom of the base and over the trussing system or a
safe fixation spot.
4. Insert the end in the carabine and tighten the safety screw.
The installation of the fixture has to be built and constructed in a way that it can hold 0
times the weight for hour without any harming deformation.
Overhead mounting requires extensive experience, including amongst others calculating working
load limits, installation material being used, and periodic safety inspection of all installation material
and the device. If you lack these qualifications, do not attempt the installation yourself. Improper
installation can result in bodily injury.
The fixture should be installed outside areas where persons may reach it, walk by or be seated
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety cable.
Never stand directly below the device when mounting, removing or servicing the fixture.
The operator has to make sure the safety relating and machine technical installations are approved
by an expert before taking the device into operation for the first time.
These installations have to be approved by a skilled person once a year.
Safety Chain

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 16 -
2.6 Installing via the “Alisca ” clamp
. Screw the “Aliscaf” clamp to the bracket via a M 2 screw, nut and washer
2. Install the metal handle fixing plate on the bottom of the fixture by means of the 4 screws supplied
as standard along with the fixture.
3. Pull the safety-chain through the holes on the bottom of the base and over the trussing system or a
safe fixation spot.
4. Insert the end in the carabine and tighten the safety screw.
The installation of the fixture has to be built and constructed in a way that it can hold 0
times the weight for hour without any harming deformation.
Overhead mounting requires extensive experience, including amongst others calculating working
load limits, installation material being used, and periodic safety inspection of all installation material
and the device. If you lack these qualifications, do not attempt the installation yourself. Improper
installation can result in bodily injury.
The fixture should be installed outside areas where persons may reach it, walk by or be seated
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety cable.
Never stand directly below the device when mounting, removing or servicing the fixture.
The operator has to make sure the safety relating and machine technical installations are approved
by an expert before taking the device into operation for the first time.
These installations have to be approved by a skilled person once a year.
Safety Chain

GB SGM Technology for lighting
Genio Mobile User Manual 1.00
- 17 -
2.7 Wall mounting
. Perform 2 holes into the wall at a distance of 65,5 mm and insert two wall screw plug M6
2. Insert but not tighten two HEX screws M6 and washers into the wall plugs, paying attention to leave
about 6mm gap across the head of the screw and the wall surface.
3. Install the bracket on the bottom of the fixture by means of the 4 screws supplied as standard along
with the fixture.
4. Place the fixture beside the screws fitted in the wall in such a way that the head of the screws are in
front of the holes located on the handle fixing plate.
5. Slide the fixture towards the screws
6. Tighten the screws by using a metric wrench size 0. (see the above picture for your reference)
7. Pull the safety-chain through the holes on the bottom of the base and over the trussing system or a
safe fixation spot.
8. Insert the end in the carabine and tighten the safety screw.
The installation of the fixture has to be built and constructed in a way that it can hold 0
times the weight for hour without any harming deformation.
Overhead mounting requires extensive experience, including amongst others calculating working
load limits, installation material being used, and periodic safety inspection of all installation material
and the device. If you lack these qualifications, do not attempt the installation yourself. Improper
installation can result in bodily injury.
The fixture should be installed outside areas where persons may reach it, walk by or be seated
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety cable.
Never stand directly below the device when mounting, removing or servicing the fixture.
The operator has to make sure the safety relating and machine technical installations are approved
by an expert before taking the device into operation for the first time.
These installations have to be approved by a skilled person once a year.
Safety Chain

SGM Technology for lighting GB
User Manual 1.00 Genio Mobile
- 18 -
2.8 Installing optional lenses
Genio Mobile can be fitted with various types of front lenses, in order to obtain different beam aperture
angles. The following procedure must be followed in the event of the front lenses having to be changed on
the LED matrix.
R MOVING / I NSTALLING TH F RONT L NS P LAT
Removal
1 Remove the 4 HEX screws located on top of the glass of the Genio Mobile’s head, by using an Allen
key metric size 3mm
2 Remove the Front Glass which give the access to the lens plate.
3 Remove the 4 HEX screws which are fixing the lens plate to the LED matrix underneath. Use an allen
key metric size 2,5mm for the purpose.
2
1
3
4
