Shape ISEEI User manual

Owner’s Manual
Interface Unit
Model N.ISEEI
Please read this instruction carefully before using this product,
and save this manual for future use.
If you have any questions, visit www.shapewlb.comm call Free 1.888.968.9810 or 1.450.812.4712

2
THANK YOU FOR PURCHASING THE SHAPE®ISEEI GIMBAL
MOTORIZED GIMBAL STABILIZER GOPRO –SMARTPHONES
SHAPE®introduces a new line of products, the ISEE series. The
camera is balanced on a two axis gimbal and is stabilized on the
tilt axis and on the roll axis using motors and sensors.
The stabilizing device is equipped with a joystick to manually
control the camera movement and is powered by 2x LP-E6
rechargeable batteries.
COPYRIGHT
© SHAPE wlb Inc. 2014
All Rights Reserved

3
CONTENTS
Read this first! ...............................................................................4
Handling the unit………………………………………………………6
What’s in the box………................................................................8
Components................................................................................10
Technical Specifications..............................................................12
Before using the Gimbal..............................................................14
Using the Gimbal with a Smartphone……………………….……..16
Warranty......................................................................................17
Contact Us...................................................................................18
Notes…………………………………………………….……………19

4
READ THIS FIRST!
WARNING:
To reduce the risk of fire, keep this equipment away from all
liquids. Use and store only in locations which are not exposed to
the risk of dripping liquids, and do not place any liquid containers
on top of the equipment.
WARNING:
Always keep equipment out of reach of babies and small children.
WARNING:
This unit is splash/rain resistant.
NOT suitable for showering, swimming, snorkelling, water related
work.
CAUTION:
Do not remove panel covers by unscrewing.
Refer servicing to qualified service personnel.
CAUTION:
To reduce the risk of fire and interference, only use the
recommended accessories.
CAUTION:
The high temperature parts of the device that are in direct contact
with the skin may aggravate low temperature burn injuries.

5
READ THIS FIRST! (continued)
FCC NOTICE (USA)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
CAUTION:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
To assure continued FCC emission limit compliance, follow the
attached installation instructions and the user must use only
shielded interface cables when connecting to host computer or
peripheral devices. Also, any unauthorized changes or
modifications to this equipment could void the user’s authority to
operate this device and void the warranty offered by the
manufacturer.

6
HANDLING THE UNIT
The unit is not splash proof or dust proof.
•Be careful not to allow sand, dust, or water to adhere or
enter into the controller box, and or connector.
•This unit is not waterproof, so it cannot be used
underwater.
•Do not subject the unit to strong shocks or vibration.
Doing so may result in malfunction or damage.
•Keep the unit away from insecticide sprays and other
volatile substances.
•Do not leave the unit in contact with direct heat
sources.
Please allow yourself at least 45 minutes to learn the operating
limits of the device.
Under no circumstances should the unit be used or stored in any
of the follow locations since doing so caused trouble in operation
or malfunctioning.
•In direct sunlight or on a beach in summer
•In locations with high temperature and
humidity levels or where change in
temperature and humidity are acute.
•Where there is fire
•Near heaters, air conditioners or humidifiers
•Where there is vibration
•Inside a vehicle
NOTE: SHAPE® will not be liable for any direct or indirect
damage or lost resulting from operation or malfunction of
this product. The design and specifications found in this
document are subject to change without notice and may
differ from the actual product. If the unit’s board stops due to
a malfunction or error and you continue to operate the unit,
the results may differ from the initial specifications.

7
HANDLING THE UNIT (continued)
GET TO KNOW THE DEVICE’S LIMITS
NOTICE:
Do not tilt up more than 45°.
NOTICE:
Do not tilt on the same side of the motor.
NOTICE:
Do not tilt down more than 45°.

8
WHAT’S IN THE BOX
SHAPE®ISEEI
Charger Battery LP-E6 2x Batteries LP-E6

9
WHAT’S IN THE BOX (continued)
SHILL® Smartphone mount 2x ¼-20 screws
Allen Key ¼-20 Allen Key 10-32
European plug 12v car adapter cable

10
COMPONENTS
Gimbal
Cables
Handle
Weight:
1.6 lbs without batteries
2.0 lbs with batteries
Dimensions:
Height: 11 ½”
Length: 4 ½”
Width: 5 ¼”
Tilt Axis motor
Camera Bracket
Push Button joint
Battery Door
Threaded hole
¼-20
