Shark Navigator NV60 User manual

Owner’s Guide
www.sharkclean.com
NV60

TOLL FREE: 1-800-798-7398
This manual covers model number:
NV60 31
TECHNICAL SPECIFICATIONS
Voltage: 120V.
Watts: 1200W
Amps: 10A
Hertz: 60Hz

1www.sharkclean.com
Contents
Important Safety Instructions 2
Getting Started 4
Using the Vacuum 6
Cleaning with the Vacuum Accessories 7
Emptying the Dust Cup Assembly 8
Proper Care of Your Vacuum 9
Troubleshooting 10
Checking for Blockages 11
Maintenance 12
Warranty and Registration 13
Thank you for
purchasing
the Shark®
Navigator®.

2TOLL FREE: 1-800-798-7398
WARNING:
TO REDUCE THE RISK OF ELECTRIC
SHOCK OR INJURY DO NOT USE
OUTDOORS OR ON WET SURFACES.
WHEN USING YOUR SHARK®NAVIGATOR®
VACUUM, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED,
INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING
YOUR SHARK®NAVIGATOR®VACUUM.
POLARIZED PLUG:
This appliance has a polarized plug (one blade
is wider than the other). As a safety feature, this
plug will fit into a polarized outlet only one way.
Do not force into the outlet or try to
modify the plug to fit.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
GENERAL ELECTRICAL SAFETY:
1. Unplug from electrical outlet when not in use
and before servicing.
2. DO NOT use vacuum with a damaged cord
or plug. If appliance is not working as it
should, has been dropped, damaged, left
outdoors, or dropped into water, return it to
SharkNinja Operating LLC for examination,
repair, or adjustment.
3. DO NOT pull or carry vacuum by the cord.
4. DO NOT unplug by pulling on cord; to
unplug, grasp the plug, not the cord.
5. DO NOT handle plug or appliance with wet
hands.
6. DO NOT run the vacuum over the power
cord.
7. DO NOT use the cord as a handle.
8. DO NOT close a door on the cord.
9. DO NOT pull cord around sharp corners.
The use of an extension cord is not
recommended.
10. DO NOT leave appliance when plugged in.
11. Keep cord away from heated surfaces.
12. Turn off all controls before plugging or
unplugging vacuum cleaner.
13. Always turn off this appliance before
connecting or disconnecting motorized
nozzle.
14. Store your appliance with the power cord
secured around the two cord holders as
shown in the storage instructions.

3www.sharkclean.com
HOSE ATTACHMENTS:
1. DO NOT use if air flow is restricted; if the air
paths, the hose, or the accessories become
blocked, turn the vacuum cleaner off. Remove
all obstructions before you turn on the unit
again.
2. Keep the end of the hose and accessory
openings away from face and body.
3. Keep cleaning tools and hose suction openings
away from hair, face, fingers, uncovered
feet,or loose clothing.
4. Only use manufacturer’s recommended
attachments.
GENERAL USE:
1. Use only as described in this manual.
2. DO NOT put any objects into openings. DO
NOT use with any opening blocked; keep
free of dust, lint, hair, and anything that may
reduce air flow.
3. Keep your work area well lit.
4. Keep the vacuum moving over the carpet
surface at all times to avoid damaging the
carpet fibers.
5. DO NOT place vacuum on unstable surfaces
such as chairs or tables.
6. DO NOT allow young children to operate
the vacuum or use as a toy. Close attention is
necessary when used near children.
7. DO NOT use vacuum cleaner if it has
been dropped, damaged, left outdoors, or
submerged in water. Return to SharkNinja
Operating LLC for examination, repair, or
adjustment.
8. DO NOT use without dust cup and/or filters
in place.
DUST CUP/FILTERS/ACCESSORIES:
Before turning on the vacuum:
1. Make sure that all filters are thoroughly dry
after routine cleaning.
2. Make sure that dust cup and all filters are in
place after routine maintenance.
3. Make sure accessories are free of blockages.
4. Only use filters and accessories provided by
SharkNinja Operating LLC. [Failure to do so
will void the warranty.]
GENERAL CLEANING:
1. DO NOT pick up large-sized objects.
2. DO NOT pick up hard or sharp objects such
as glass, nails, screws or coins that could
damage the vacuum cleaner.
3. DO NOT pick up smoking or burning objects
such as hot coals, cigarette butts, fireplace
ash or matches.
4. DO NOT use to pick up drywall dust.
5. DO NOT pick up flammable or combustible
materials such as lighter fluid, gasoline, or
kerosene or use vacuum in areas where they
may be present.
6. DO NOT pick up toxic solutions such as
chlorine bleach, ammonia, or drain cleaner.
7. DO NOT use in an enclosed space where
vapors are present from paint, paint thinner,
moth-proofing substances, flammable dust or
other explosive or toxic materials.
8. DO NOT vacuum up any liquids.
9. DO NOT immerse vacuum cleaner in water or
other liquids.
10. DO NOT use outdoors or on wet surfaces;
use only on dry surfaces.
11. Use extra care when cleaning on stairs.
SAVE THESE
INSTRUCTIONS

4TOLL FREE: 1-800-798-7398
WHAT’S IN THE BOX YOU JUST
OPENED:
AVacuum Body
BFloor Power Nozzle
CHandle Assembly
DSuper Stretch Hose
ECleaning Wand
FWide Upholstery Tool
GDusting Brush
HCrevice Tool
Getting Started
Your Shark®Navigator®is
easy to assemble:
1Lay your vacuum body on a
level surface.
2Slide the electrical connection
from the power nozzle into the
main body to click into place.
3Connect the hose from the main
body to the power nozzle; push
with a slight turning motion to
create a snug fit.
4Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6Place the vacuum in the upright
position.
7Insert the Cleaning Wand into
the center post on the tool
caddy.
8Store the Crevice Tool, Dusting
Brush on the back of the unit.
A
C
E
H
B
G
D
F
8
4
5
3
7
2

5www.sharkclean.com
11 To carry the vacuum:
With the unit in the standing
position, lift by the Dust Cup
Assembly Handle (carry handle).
CAUTION: When lifting or
carrying, DO NOT press Dust
Cup Assembly release button.
9Attach the Super Stretch Hose:
a) Snap hose into swivel
connector
b) Route under anti-tip hook to
prevent vacuum from tipping
c) Route over upper hose
holder
d) Press securely onto cleaning
wand with handle
IMPORTANT:
Insert the hose into the wand.
This completes the air path and
enables suction to reach the
Floor Power Nozzle.
10 To store the vacuum:
When storing your vacuum,
wind the cord around the two
cord holders and secure with
cord clip:
• Quick Cord release at the
top of the unit – place in the
upright position.
• Cord holder near the base –
turn it until it is pointing down.
To release the cord, turn the Quick
Cord release to the left or right.
9
d
b
a
c10

6TOLL FREE: 1-800-798-7398
Using the Vacuum
Your Shark®Navigator®Vacuum
can be used to clean bare floors or
carpets – with the click of a switch.
Stand the vacuum into the upright
position.
Plug in the vacuum.
1Start with the Power Switch in the
“O"- Off position.
2Place your foot on the Floor Power
Nozzle and pull handle towards
you.
3Set the Power Switch to desired
cleaning setting.
4Push the power cord into the
groove on the handle and then
secure the power cord into the
cord clip.
5Press the On/Off switch to the“I"
position to vacuum bare floors or
cleaning with the hose (straight
suction only) or to the "II"
position to engage the motorized
floor brush (for vacuuming carpets
and rugs).
6Due to the huge suction
power of this vacuum, it may
become necessary to adjust
the suction release on the
hose. If the vacuum is difficult
to push or pull or if it is
lifting up area rugs, adjust the
suction release by opening
the valve at the top end of
the hose. Close the suction
release valve for maximum
suction when vacuuming
floors or when using the Wide
Upholstery Tool.
IMPORTANT:
Your Brushroll Indicator Light
will illuminate solid green when
the brushroll is on, or solid red if
there is a blockage. This feature is
designed to protect your Lifetime
Belt that powers your brushroll.
See Checking for Blockages
on page 11.
NOTE: The height of your power
nozzle has been optimized
for easy pushing and superior
cleaning on all floor types, so there
is no need to make any height
adjustments as you transition to
different floor & carpet types.
IMPORTANT: To protect your
carpets, the brushroll will only
turn on when you have pulled
the handle back towards you and
released the Floor Power Nozzle.
OFF
Bare Floors /
Tools
Carpets
Power Switch
Settings
Suction Release
Release suction for
easier push and pull
on high pile carpets
and area rugs.
4
2
3
6

7www.sharkclean.com
Cleaning with the Vacuum Accessories
Before cleaning with your
accessories:
Stand vacuum into upright position.
Secure Super
Stretch Hose in
the anti-tip hose
hook to prevent
tipping.
Select the “I" - On position for
suction only cleaning.
DO NOT pull vacuum cleaner
around by the hose.
DO NOT overextend the hose.
Vacuum Accessories
Your vacuum comes with a Super
Stretch Hose and Cleaning Wand.
Use one or the other to attach your
cleaning accessories.
1Using the Super Stretch Hose:
Stand the vacuum into upright
position.
Remove the hose from the
Cleaning Wand.
Push the selected tool into the
hose connector.
1
3
4
5
2Using the Cleaning Wand:
Stand the vacuum into upright
position.
Remove the Cleaning Wand
(with hose attached) from the
unit.
Push the selected tool into the
end of the Cleaning Wand.
3Wide Upholstery Tool
4Dusting Brush
5Crevice Tool
To order additional parts and
accessories, go to www.sharkclean.com
or call 1-800-798-7398.
2
3
4
5

8TOLL FREE: 1-800-798-7398
Maintenance
For best results empty the Dust Cup
Assembly after each use, as needed
during prolonged usage or when it
reaches the MAX fill line.
DO NOT OVERFILL.
Turn vacuum off before emptying.
To empty the Dust Cup:
1Grip carry handle and press
the Dust Cup release button to
remove.
2Option A: For Quick Empty:
Insert Dust Cup deep inside
trash receptacle to contain dust
and debris.
Press the bottom Dust Cup
release button; tap container
gently to dislodge and release
dust and debris.
Snap door in place.
Important: If the Dust Cup
Door does not swing open after
pressing the release button,
push the door open using the
bottom door tabs.
CAUTION:
Unplug the vacuum; failure to do
so might result in electric shock.
3Option B: For Allergy Sufferers:
Wrap a trash bag around the
Dust Cup leaving space at the
bottom for the door to swing
open.
Locate the Dust Cup Door
release button within the trash
bag and press to release as you
shake the dust cup to empty
dust and debris.
Snap the bottom door in place.
Note: Option B can also be
performed outside of the home
to further minimize releasing
dust back into the air. Carry just
the Dust Cup and trash bag
outside.
Note: Some dust and debris
may remain in the top of your
dust cup on or near the metal
screen. It is not necessary to
completely remove this material
before continuing to vacuum;
Shark®advanced cyclonic
action will sweep the metal
screen clean once you begin to
refill your dust cup.
1
2
3

9www.sharkclean.com
COMPONENT MAINTENANCE SCHEDULE
Rinse and air dry every month under normal use.
Empty each time you vacuum.
Pre-Motor Foam Filter
Dust Cup
Rinse and air dry every month under normal use. Pre-Motor Felt Filter
Clean once a year under normal use.
Post-Motor HEPA Filter
1
2
3
4
To clean the pre-motor filters:
1 Remove the dust cup.
2 Pull the 2 filters out from the top of the motor
base.
3 Rinse the filters thoroughly in lukewarm water until
the water runs clear.
DO NOT put the filters in the washing machine or
dishwasher.
NOTE: The material in the filters will discolor
over time. This is NORMAL and will not affect the
performance of the filters.
4 Squeeze out excess water and let air-dry for at
least 24 hours before replacing. Do not use a hair
dryer or other heating methods to dry.
5 Place the felt filter in first, then the foam filter.
6 Replace the dust cup.
To clean the post-motor HEPA filter:
1 Remove the filter cover from the front of the
vacuum by pulling up on the tab and pulling the
cover away from the vacuum.
2 Take out the HEPA filter by pulling it straight out.
3 Turn the HEPA filter over so that the dirty side is on
the bottom and vigorously tap it clean against a
garbage can to remove any dust.
4 Wash the HEPA filter under the tap using lukewarm
water with the dirty side face down until the water
runs clear.
DO NOT put the HEPA filter in the washing
machine or dishwasher.
NOTE: The material in the filter will discolor over
time. This is NORMAL and will not affect the
performance of the filter.
5 Allow the HEPA filter to air dry for 24 hours. Do
not use a hair dryer or other heating methods to
dry.
6 Once the HEPA filter is dry, replace it back into the
vacuum.
7 Replace the cover by inserting the two tabs into
the holes at the bottom and then swinging the
cover up until it clicks into place.
DO NOT operate the vacuum without ALL the filters in place.
DO NOT operate the vacuum with WET filters.
Pre-Motor
Foam Filter
Felt Filter
Post Motor
HEPA Filter
IMPORTANT: Loss of Suction may
occur if foam filter is not cleaned
every month. Rinse and allow to air dry
completely. Also, tap loose dirt off filter
between washes as needed.
Foam filters may appear dirty after use -
this is normal.

10 TOLL FREE: 1-800-798-7398
PROBLEM POSSIBLE REASONS & SOLUTIONS
Vacuum is not picking
up dirt.
Check filters to see if they need cleaning. Follow instructions for rinsing
and drying the filters before re-inserting back into the vacuum. (See
“Maintenance” sections for instructions.)
Dust cup may be full; empty dust cup.
Check hose and hose connections for blockages; clear blockages if required.
If dust cup is empty, and attachment inlets are clear, check for other
blockages. (See “Checking for Blockages” for instructions.)
Vacuum lifts scatter rugs
(lightweight, movable
rugs).
Suction is powerful. Take care when vacuuming scatter-type rugs or rugs with
delicately sewn edges. Open the suction release on the hose to decrease
suction power.
Airflow is restricted. No
suction or light suction.
Check filters to see if they need cleaning. Follow instructions for rinsing
and drying the filters before re-inserting back into the vacuum. (See
“Maintenance” sections for instructions.)
Dust cup may be full; empty dust cup.
Check hose, hose connections, nozzles and accessories for blockages; clear
blockages if required.
Close the suction release on the hose to increase suction power.
If dust cup is empty, and attachment inlets are clear, check for other
blockages. (See “Checking for Blockages” for instructions.)
Motorized floor brush
has become jammed or
has shut off.
Immediately turn off and unplug vacuum, disconnect the nozzle and remove
blockage before reconnecting and turning vacuum back on. (See “Checking
for Blockages” for instructions.)
Vacuum turns off on its
own.
This vacuum cleaner is equipped with a motor protective thermostat. If for
some reason your vacuum overheats, the thermostat will automatically turn
the unit off. Should this occur, perform the following steps to restart the
motor thermostat:
1. Move the On/Off switch to the “O” (Off) position.
2. Unplug the vacuum.
3. Empty the dust cup and clean filters. (See “Maintenance” sections for
instructions.)
4. Check for blockages in hose, accessories and inlet openings. (See
"Checking for Blockages” for instructions.)
5. Allow the unit to cool for a minimum of 45 minutes.
6. Plug in the vacuum.
7. Turn the On/Off switch to the “I” (On) position to restart the vacuum.
Note: If vacuum still does not start, contact Customer Service at:
1-800-798-7398.
Troubleshooting
WARNING:
To reduce the risk of electric shock, the power cord must be disconnected before
performing maintenance/troubleshooting checks.

11www.sharkclean.com
Checking for Blockages
Blockages may cause your vacuum
to overheat and shut down. If so,
clear the blockages, then follow
the instructions for Resetting the
Motor Thermostat on page 12.
WARNING: Never insert sharp
objects into any opening to clear
an obstruction.
IMPORTANT: Damages caused
while clearing or attempting to
clear blockages are not covered
under your product’s limited
warranty.
Unplug the vacuum before
checking for blockages.
Reassemble all parts securely
before operating vacuum.
1
3
4
1Dust Cup Air Duct:
Stand vacuum into upright
position.
Remove Dust Cup Assembly and
empty Dust Cup if necessary.
Disconnect the Super Stretch
Hose.
Check Air Duct behind Dust Cup
for clogs; clear before replacing
Dust Cup Assembly.
2Intake Opening behind the
Brushroll:
Lay the vacuum flat to expose
brushroll.
Check opening behind the
brushroll for clogs.
Clear the opening.
Clear the brushroll; use scissors
to carefully cut away threads,
hair or other debris that might
be trapped in the bristles.
3Floor Power Nozzle Hose
Connector:
Lay vacuum flat.
Remove Nozzle Hose and check
for clogs.
Push the Hose Connector back
onto the Floor Power Nozzle.
4Hose:
Stand vacuum upright.
Remove hose from both the unit
and Cleaning Wand ends.
Inspect both ends and the length
of the hose for clogs.
Return the hose to the unit.
2

12 TOLL FREE: 1-800-798-7398
Maintenance
Resetting the Motor Thermostat
Your Shark®Navigator®Vacuum
is equipped with a protective Motor
Thermostat. If the motor should
overheat, the thermostat shuts off
the power.
To reset the Motor Thermostat:
Move the Power Button to the
“O”– Off position.
Unplug the vacuum.
Check for clogged hose or filter;
unclog hose and replace filter.
Refer to Checking for Blockages
on page 11.
Wait 45 minutes for vacuum to cool;
then plug in the vacuum.
Turn the Power Switch to the
“I”– On position to start the
vacuum.
Note: If vacuum still does not start,
contact Customer Service at:
1-800-798-7398.
Cleaning The Motorized Floor
Brush
When your motorized floor brush
needs cleaning or locks onto an
object, it automatically shuts
down to prevent damage to your
lifetime belt. The indicator light will
illuminate red warning you to turn
off the vacuum and clear blockage
immediately. The light will reset itself
once blockage has been cleared
and power has been cycled on/off
or vacuum has been locked in the
upright position.
1Detach the motorized floor
brush from the detachable
canister.
2Inspect the opening underneath
and the rotating brush. If a
build-up of debris is present,
remove it. Carefully cut anything
wound around the rotating
brush with scissors. Avoid
damaging or cutting the bristles.
Rotating
Brush
Ordering Replacement Parts
To order additional parts and accessories,
go to www.sharkclean.com or call
1-800-798-7398.
PART PART NO.
Super Stretch Hose 152FFJ
Dusting Brush &
Crevice Tool 1115FC
Foam & Felt Filters XFF80
Hepa Filter XHF80
Wide Upholstery Tool 261FFJ46
Cleaning Wand 114FFJ

13www.sharkclean.com
Product Registration
Please visit www.sharkclean.com or call 1-800-798-7398 to register your new Shark®product within ten (10)
days of purchase. You will be asked to provide the store name, date of purchase and model number along with your
name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By registering
you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying
instructions.
FIVE (5) YEAR LIMITED WARRANTY
SharkNinja Operating LLC warrants this product to be free from defects in material and workmanship for a
period of one (5) years from the date of the original purchase, when utilized for normal household use, subject to
the following conditions, exclusions and exceptions.
If your appliance fails to operate properly while in use under normal household conditions within the warranty
period, return the complete appliance and accessories, freight prepaid. For assistance with warranty service
options or customer support, please call our customer care and product specialists at, call 1-800-798-7398 or visit
our website www.sharkclean.com.
If the appliance is found to be defective in material or workmanship, SharkNinja Operating LLC will repair or
replace it free of charge. Proof of purchase is required and a fee of $19.95 will apply to cover the cost of return
freight. *
The liability of SharkNinja Operating LLC is limited solely to the cost of the repair or replacement of the unit
at our option. This warranty does not cover normal wear of parts and does not apply to any unit that has been
tampered with or used for commercial purposes. This limited warranty does not cover damage caused by misuse,
abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This warranty does not
cover damage or defects caused by or resulting from damages from shipping or repairs, service or alterations to
the product or any of its parts, which have been performed by a repair person not authorized by SharkNinja
Operating LLC.
This warranty is extended to the original purchaser of the unit and excludes all other legal and/or conventional
warranties. The responsibility of SharkNinja Operating LLC warranty if any, is limited to the specific obligations
expressly assumed by it under the terms of the limited warranty. In no event is SharkNinja Operating LLC
liable for incidental or consequential damages of any nature whatsoever. Some states/provinces do not permit the
exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or
province to province.
*Important: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase
date and to attach tag to item before packing with your name, complete address and phone
number with a note giving purchase information, model number and what you believe is the
problem with the item. We recommend you insure the package (as damage in shipping is not
covered by your warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”.

SharkNinja Operating LLC
U.S.: Newton, MA 02459
Canada: Ville St. Laurent, Québec H4S 1A7
1-800-798-7398
www.sharkclean.com
Copyright © SharkNinja Operating LLC 2016
Printed in China
Illustrations may differ from actual product. We are constantly striving to improve
our products, therefore the specifications contained herein are subject to change
without notice.
For SharkNinja U.S. Patent information visit http://www.sharkninja.com/USPatents.
Shark and Navigator are registered trademarks of SharkNinja Operating LLC.
NV60_31_IB_E_160427_1
