Shark Rocket UV422 Series User manual

UV422
Series
INSTRUCTIONS
sharkclean.com
1-800-798-7398
®

11-800-798-7398
THANK YOU
for purchasing the Shark® Rocket® Ultra-Light Upright
PLEASE READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get
a complete understanding of your new Shark
Rocket Ultra-Light Upright.
If you have any questions, please call the
customer service line at 1-800-798-7398.
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz
Watts: 500W
Amps: 4.2A
REGISTER YOUR PURCHASE
sharkclean.com
1-800-798-7398
TIP: You can find the
model number on the
rating label which is located
behind the dust cup.
TIP: You can locate the
date code on one of the
prongs of the power
cordplug.
RECORD THIS INFORMATION
Model Number: ��������������������������������������
Date Code: �����������������������������������������
Date of Purchase (Keep receipt): �����������������������
Store of Purchase: �����������������������������������

2
sharkclean.com
CONTENTS
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting To Know Your Shark® Rocket® Ultra-Light Upright . . 5
Assembling Your Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the Motorized Floor Nozzle . . . . . . . . . . . . . . . . . . . . . . . 9
Choosing the Appropriate Setting . . . . . . . . . . . . . . . . . . . . . . 10
Using the Dust-Away™ Hard Floor Attachment . . . . . . . . . . . .11
Using Your Vacuum in Above-Floor Mode . . . . . . . . . . . . . . . 12
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Maintaining Your Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Emptying the Dust Cup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
Cleaning the Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �18
Microfiber Pad Care � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �19
Checking for Blockages � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �19
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

31-800-798-7398
THE MOTORIZED FLOOR
NOZZLE, WAND, AND HANDHELD
VACUUM CONTAIN ELECTRICAL
CONNECTIONS:
• These are not serviceable parts.
• Do not use to vacuum any liquids.
• Do not immerse in water when cleaning.
• If handheld vacuum/wand is damaged,
discontinue use.
1Inspect power cord and plug for any
damage before use. DO NOT use vacuum
cleaner with a damaged cord or plug.
Turn off all controls before plugging in or
unplugging the vacuum cleaner. Store
your vacuum cleaner with the power cord
secured around the two cord hooks.
2 DO NOT use outdoors or on wet surfaces.
Use only on dry surfaces.
3Unplug from electrical outlet when not in
use and before servicing.
4If vacuum cleaner is not working as it
should, or has been dropped, damaged,
left outdoors, or dropped into water,
return it to SharkNinja Operating LLC for
examination, repair, or adjustment.
5DO NOT pull or carry vacuum cleaner by
the cord or use the cord as a handle.
6DO NOT unplug by pulling on cord. Grasp
the plug, not the cord.
7DO NOT handle plug or vacuum cleaner
with wet hands.
8DO NOT run the vacuum cleaner over the
power cord, close a door on the cord or
pull the cord around sharp corners.
9The use of an extension cord is NOT
recommended.
10 DO NOT leave vacuum cleaner when
plugged in.
11 Keep cord away from heated surfaces.
GENERAL USE
12 Use only as described in this manual.
1 3 Keep your work area well lit.
14 Keep the vacuum cleaner moving over
the carpet surface at all times to avoid
damaging the carpet fibers.
15 DO NOT place vacuum cleaner on unstable
surfaces such as chairs or tables.
16 DO NOT put any objects into openings. DO
NOT use with any opening blocked; keep
free of dust, lint, hair, and anything that
may reduce airflow.
17 DO NOT allow the appliance to be used by
children. Close attention is necessary when
used near children. This is not a toy.
18 DO NOT use without dust cup and/or filters
in place.
19 DO NOT use if airflow is restricted. If the air
paths or the motorized floor nozzle become
blocked, turn the vacuum cleaner off and
unplug from electrical outlet. Remove
all obstructions before you turn on the
unitagain.
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
WARNING
To reduce the risk of injury, fire, electric shock, and property damage
resulting from improper use of the appliance, carefully observe the following
instructions. This unit contains electrical connections and moving parts that
potentially present risk to the user.

4
sharkclean.com
20 Keep nozzle away from hair, face, fingers,
uncovered feet, or loose clothing.
2 1 Only use manufacturer’s recommended
attachments.
DUST CUP/FILTERS/ACCESSORIES
Before turning on the vacuum:
22 Make sure that all filters are thoroughly dry
after routine cleaning.
23 Make sure that dust cup and all filters are
in place after routine maintenance.
24 Make sure accessories are free of
blockages and keep openings away from
face and body.
25 Only use Shark®-brand filters and
accessories (failure to do so will void
thewarranty).
GENERAL CLEANING
26 DO NOT vacuum up large objects.
27 DO NOT vacuum up hard or sharp objects
such as glass, nails, screws, or coins that
could damage the vacuum cleaner.
28 DO NOT vacuum up drywall dust,
fireplace ash, or embers. DO NOT use
as an attachment to power tools for dust
collection.
30 DO NOT vacuum up smoking or burning
objects such as hot coals, cigarette butts,
or matches.
31 DO NOT vacuum up flammable or
combustible materials (e.g., lighter fluid,
gasoline, or kerosene) or use vacuum in
areas where they may be present.
32
DO NOT vacuum up toxic solutions (e.g.,
chlorine bleach, ammonia, or drain cleaner).
33 DO NOT use in an enclosed space
where vapors are present from paint,
paint thinner, moth-proofing substances,
flammable dust, or other explosive or toxic
materials.
34 DO NOT vacuum up any liquids.
35 DO NOT immerse vacuum cleaner in water
or other liquids.
36 Use extra care when cleaning on stairs.
POLARIZED PLUG
To reduce the risk of electric shock, this
vacuum cleaner has a polarized plug (one
blade is wider than the other). As a safety
feature, this plug will fit into a polarized outlet
only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. DO NOT force
into outlet or try to modify to fit.
SAVE THESE INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE

51-800-798-7398
GETTING TO KNOW YOUR
SHARK® ROCKET® ULTRA-LIGHT UPRIGHT
WELCOME!
Congratulations on
your purchase. Use this
instruction manual to
learn about your new
vacuum’s great features.
From assembly to use
to maintenance, you will
find it all in here.
MAIN UNIT
APower Switch
BHandheld Vacuum
CDust Cup Release
DHandheld Vacuum Catch
ELED Light
FCord Hooks (not visible)
GWand Release
HWand
IOn-Board Tool Clip
JHandheld Vacuum Storage Hook
KLower Wand Release Pedal
LBrushroll Indicator Light
M Motorized Floor Nozzle
NHeadlights
OWall Mount

6
sharkclean.com
Dust Cup
Release
Wand
Release
Dust Cup
Release
Wand
Release
Dust Cup
Release
Wand
Release
Dust Cup
Release
Wand
Release
A
C
D
I
B
E
G
J
K
N
F
M
H
O
L

71-800-798-7398
ASSEMBLING YOUR VACUUM
1Insert the wand into the motorized floor nozzle connector
until you hear a click.
STEP 1
DID YOU KNOW?
The motorized floor nozzle and
handheld vacuum have LED
lights that illuminate the floor
surface being cleaned. The
lights turn on automatically in
either speed setting.
CLICK

8
sharkclean.com
2Insert the handheld vacuum into the top of
the wand until you hear a click.
3This vacuum comes with a detachable
clip to store up to 2 accessories on
board. Snap clip onto the wand. Store
one accessory on top holder and one
accessory on bottom holder.
STEP 2 STEP 3
CLICK
OR

91-800-798-7398
USING THE MOTORIZED
FLOOR NOZZLE
WARNING: This vacuum
does not stand up on
its own, so when taking
a break from cleaning,
rest it against a piece of
furniture or a wall, or lay
it flat on the floor. Using
for an application where
the unit lacks stability
may result in personal
injury.
NOTE: Before vacuuming
your delicate area
rugs or carpet, refer
to the manufacturer’s
recommended cleaning
instructions.
1Plug the unit in and recline the wand.
WHAT DOES THE
BRUSHROLL INDICATOR
LIGHT MEAN?
Solid Green
The brushroll is on and
working as it should.
Solid Red
There is a jam in the brushroll
area. Turn your vacuum off
and remove the blockage.

10
sharkclean.com
CHOOSING THE
APPROPRIATE SETTING
The Rocket®Ultra-Light has a 2-speed Power slider switch on the handle. Slide the Power
switch to appropriate speed setting (I or II) and start cleaning.
Bare Floor, Area Rugs (I) – The brushroll spins slowly to clean bare floors and delicate
arearugs.
High Pile Carpets (II) – The brushroll spins faster to pick up debris below the surface
ofyour carpets.
NOTE: For deep cleaning per ASTM F 608 (embedded dirt in carpets) please set to High Pile Carpets (II).

11 1-800-798-7398
IMPORTANT: Do not
use the Dust-Away Hard
Floor Attachment without
the Microfiber Pad.
NOTE: Both power
settings provide the
same suction power.
TIP: You can attach the
handheld vacuum directly
to the motorized floor
nozzle for convenient
stair cleaning.
USING THE DUST-AWAY™
HARD FLOOR ATTACHMENT
STEP 1 STEP 2
1Slip two tabs between
the nozzle and the duster
base and attach them to
the front fasteners.
2Pull the other two tabs
tightly around to the back
fasteners. Ensure the pad
is flat against the bottom
surface and tightly secured.
Slide the power switch to
either setting to clean hard
floors. Do not use to clean
damp floors or wet/sticky
messes. Use only pads
provided by Shark.
MICROFIBER PAD CARE
Machine or hand wash the
pads separately in warm water
with liquid detergent.
Do not use bleach or fabric
softeners as they may damage
the pads or leave a coating
that will reduce their cleaning
performance.
Tumble dry low or line dry
to extend the life of the
microfiberfabric.
For the best results, replace
your microfiber pads every 3
to 4 months.

12
sharkclean.com
USING YOUR VACUUM
IN ABOVE-FLOOR MODE
STEP 1 STEP 1STEP 2 STEP 2
FOR LONG-REACH CLEANING
1 Stand the vacuum upright. Step on the foot
pedal and pull the wand up to disconnect it
from the motorized floor nozzle.
2 Attach desired cleaning accessory.
FOR SHORT-REACH CLEANING
1 Press the Wand Release button on the
top of the wand to disconnect it from the
handheld vacuum.
2 Attach desired cleaning accessory. The
LED light on the handheld vacuum turns on
automatically when the power is on.
DO NOT SCALE DRAWING
650_motorized_5_asm
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
5
4
3
2
1
Wand
Release
DO NOT SCALE DRAWING
650_motorized_5_asm
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
5
4
3
2
1

13 1-800-798-7398
TIP: If your unit came
with an accessory bag,
you can hang the bag on
the wall mount with the
vacuum.
TIP: Be sure to use the
plastic anchors provided
when mounting into
drywall; alternatively you
may place screws directly
into a stud.
STORAGE
1 Press the Wand Release button on the top of the wand
to release the handheld vacuum. There is a catch on the
bottom of the handheld vacuum. Hang it from the hook
located on the bottom portion of the wand. Wrap the cord
around the two cord hooks.
OPTION 1
Handheld
Vacuum Catch
Handheld Vacuum
Storage Hook

14
sharkclean.com
2 Use the wall mount that is included. Drill two 5/16" holes and insert plastic anchors provided
into the wall. Using a Philips head screwdriver, screw the wall mount into the plastic anchors.
Hook the catch on the bottom of the handheld vacuum onto wall mount.
OPTION 2

15 1-800-798-7398
ACCESSORIES
A 12" Crevice Tool
Clean in between
tight spaces or reach
baseboards and ceilings
with this slim crevice tool.
C Mini Motorized Brush
The power of a full-size
upright in the palm of your
hand. Picks up pet hair and
loose debris and powerfully
cleans dander out of
upholstery and surfaces.
Cannot be used with the
Flexible Hose.
D Dusting Brush
Dust a multitude of
surfaces such as shelves,
baseboards, window/
door frames, and much
more. Turn the brush head
to adjust the angle to the
surface you’re cleaning.
E Dust-Away™ Hard
Floor Attachment with
Microfiber Pad
Direct suction for big
crumbs and debris while
microfiber pad dusts
hardwood and tile floors.
B Pet/Upholstery Tool
Perfect for grabbing pet
hair and lint from furniture
and other upholstered
surfaces.
The top flap of your box shows
the select accessories that are
included with your model.

16
sharkclean.com
E
A B
C
DO NOT SCALE DRAWING
650_motorized_5_asm
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
5
4
3
2
1
D

17 1-800-798-7398
WARNING: Hand
wash filters with
water only to prevent
damage from
cleaning chemicals.
Allow ALL filters
to dry completely
before replacing
in the vacuum to
prevent liquid from
being drawn into
electric parts.
CAUTION: Turn power
off and unplug before
servicing.
IMPORTANT: Clean the
dust screen inside the dust
cup as required.
NOTE: Empty dust cup
when debris reaches the
MAX fill line.
MAINTAINING YOUR VACUUM
Empty
EMPTYING THE DUST CUP
1Press the Wand Release button on the top of the wand to
disconnect it from the handheld vacuum.
OR
Remove the dust cup from the handheld vacuum by
squeezing the two Dust Cup Release buttons on both
sides of the base at the same time and pulling it out.
RECOMMENDED
FILTER CLEANING
SCHEDULE:
Pre-Motor Filter Kit
(Foam & Felt)
1080FTV320
Clean once a month.
Post-Motor Filter
1084FTV320
Clean once a year.
STEP 1

18
sharkclean.com
CLEANING THE FILTERS
1Access the Pre-Motor foam and felt
filters by lifting the latch on the top of the
handheld vacuum. Remove and rinse
the filters with water. Tap loose dirt off
filters between washes as needed. Once
completely dry, insert the felt filter first,
then place the foam filter on top of it.
2Access the Post-Motor filter under the
handle. Remove and rinse the filter
withwater.
2Hold dust cup over a trash bin and press
the Empty button on the front of the dust
cup. The bottom lid will open, allowing the
debris to fall out.
3Once dust cup is empty, close the bottom
lid and insert dust cup back into handheld
vacuum until you hear it click into place.
Empty
DustCup
Release
Monthly
Post-Motor filter
Pre-Motor filters
Foam
Felt
STEP 2

19 1-800-798-7398
MAINTAINING YOUR VACUUM
CHECKING FOR BLOCKAGES:
HANDHELD AND WAND
1Remove the wand from the handheld portion and check all
dust cup intake openings.
2Remove the floor nozzle from the wand and check the
wand for blockages.
WARNING: Do not cut
anything but the hair,
fibers or string that is
on the brushroll.
TIP: Ensure the bottom
of the floor nozzle is
completely sealed and
locked before using.
TIP: You do not need any
tools to open the floor
nozzle—just a coin.
