QUICKSTORE PORTABLE USB3.0
ENGLISH
Content
1. Features
2. Specifications
3. Parts and accessory
4. The device at a glance
5. Installing a SATA hard disk drive
6. Installing the software
7. The backup software
7.1 Start
7.2 “Quick Launch”
7.3 Backup settings
7.4 File manager
7.5. Program settings

QUICKSTORE PORTABLE USB3.0
ENGLISH
Dear customer!
Congratulations for purchasing this premium quality
SHARKOON product.
For a long life time and to take full advantage of this product we
recommend that you read this manual completely.
Have a good time with our product!
SHARKOON Technologies GmbH
1. Features
• Suitablefor2.5"SATAharddiskdrives(9.5mmheight)
• Toolfreeassembly
• “OneClickBackup”function(onlyWindows)
• Backupsoftwareincluded
• NodriversneededforWindows,MacandLinux
2. Specifications
• Externalinterface: microUSB3.0(compatibletoUSB2.0
       andUSB1.x)
• Internalinterface: SATA(VersionIandII)
• Datatransferrate: max.5Gbit/s
• Dimensions:   135x85x14mm(LxWxH)
• Weight:    ~51g

QUICKSTORE PORTABLE USB3.0
ENGLISH
3. Parts and accessory
• QuickStorePortableUSB3.0(A)
• USB3.0cable(B)
• Quickstartmanual(C)
• ToolsCDincl.backupsoftwareandextensivemanual(PDF/D)
Note:
If you are missing any of the items listed above, please contact
our customer service via e-mail at suppor[email protected] or
call: + 49 (0) 6403 – 775 6100.
D
A B C

QUICKSTORE PORTABLE USB3.0
ENGLISH
A – Case cover lock
A – Case cover
A – SATA connector
  (dataandpower)
B – HDD mounting bay
  (forone2.5"-SATAHDD)
A – QuickStore Portable
in respective version
B – Backupbutton:
pressing this button
starts a backup
  processwiththepre-
  denedsettings(see
  chapter6)
4. The device at a glance
A
A
A
A
B
B

QUICKSTORE PORTABLE USB3.0
ENGLISH
5. Installing a SATA hard disk drive
1. Openthecasecoverlock(g.1).
fig. 1
2. Removethecasecoverfromthecasebody(g.2).
fig. 2
3. Slidea2.5"SATAHDDintotheHDDmountingbay(g.3).
fig. 3

QUICKSTORE PORTABLE USB3.0
ENGLISH
4. Placethecasecoverbackontothecasebody(g.4).
fig. 4
5. Closethelock(g.5).
fig. 5
6. UsetheincludedUSB3.0cabletoconnectthedevice'sMini
 USB3.0connectortoaUSB3.0connectorofyourPC/laptop.
7. The QuickStore Portable will automatically be recognized by
the operating system and all required drivers will be
installed.The device is now ready.

QUICKSTORE PORTABLE USB3.0
ENGLISH
Note:
Brand new HDDs built into the case must be partitioned and
formatted. Proceed as described below (e.g. Windows XP):
Start / Settings / Control Panel / Administrative Tools /
Computer Management / Disk Management. Click the
respective HDD with the right mouse button and choose
partition/format.
6. Installing the software
1. InserttheincludedDriver&ToolsCDintoyourCD/DVD
drive.
2. ChooseyourCD/DVDdrive(e.g.D:\).
3. Open the folder “Sharkoon“.

QUICKSTORE PORTABLE USB3.0
ENGLISH
4. Start“Setup.exe”,thefollowingwindowwillopenup
 (g.1).Click“Install”toinstallthebackupsoftwareor
“Quit” to cancel the installation.
fig. 1
5. Acceptthelicenseagreement(g.2)byclickingthebutton
“Agree”. “Back” will get you to the previous installation
 step,“Quit”cancelstheinstallation.
fig. 2

QUICKSTORE PORTABLE USB3.0
ENGLISH
6. Confirm the destination path for the installation by clicking
 “Install”,“Back”willgetyoutothepreviousinstallation
 step,“Quit”cancelstheinstallation.
 With“CreateDesktopShortcut”youcandecidewhether
you want a program icon to be created on your desktop or
 not(g.3).
fig. 3
7. Completetheinstallationbyclicking“OK”(g.4).
fig. 4

QUICKSTORE PORTABLE USB3.0
ENGLISH
8. Aftertheinstallationiscompletedthefollowingiconwill
 appearinyourtaskbar:
7. The backup software
7.1. Start
1. Click the icon in your task bar with the right mouse button
 once.Thefollowingcontextmenuwillopenup:
2. “About…” shows you information about the software
 (g.5).
fig. 5

QUICKSTORE PORTABLE USB3.0
ENGLISH
3. “Help” starts the help program of the backup software
 (g.6).
fig. 6
4. “ExitPCCloneEX“quitstheprogram(theiconwillbe
 removedfromyourtaskbar).
5. “ShowPCCloneEX”startsthebackupprogram.
 Alternativelyyoumaystarttheprogrambydouble-clicking
 (leftmousebutton)theicon.

QUICKSTORE PORTABLE USB3.0
ENGLISH
7.2. “Quick Launch”
 A – Menubar
B – Start the data backup by clicking the button.
C – These icons are used to start the program help
and to show some information about the
program.
D – Clicking this button minimizes the window.
To completely quit the program see above chapter
6.1. No. 4.
D
A
B
C

QUICKSTORE PORTABLE USB3.0
ENGLISH
7.3. Backup settings
 A – Menubar
B – All folders of your system are shown here.
Choose the folders that will be copied during a
   backup,bytickingtherespectivecheckboxes.
C – These icons are used to start the program help
and to show some information about the program.
 D – Selecttheexternaltargetdevicefromthedropdown
menu.
 E – Startthebackupbyclickingthebutton.
 F – Restorealreadyexistingbackuplesfromthe
   external(backup)drive,byclickingthisbutton.
 G – Clickingthisbuttonminimizesthewindow.
Note:
The backup files are copied to the (hidden) folder “Fnet” on the
target device.This folder must not be deleted!
D
E F G
A
B
C

QUICKSTORE PORTABLE USB3.0
ENGLISH
7.4. File manager
 A – Menubar
B – All fi les of your system are shown here.
   Usetheincludedlemanagertomanageyour
files.
C – These icons are used to start the program help
and to show some information about the program.
D – Clicking this button minimizes the window.
D
A
B
C

QUICKSTORE PORTABLE USB3.0
ENGLISH
7.5. Program settings
D
E
A
A
B
B
C
F
F
G
H
I
I
J

QUICKSTORE PORTABLE USB3.0
ENGLISH
 A – Menubar
 B – Selectbetweenthewindows"FilesBackup"and
   "Others".
C – Decide what shall happen after completing the
backup.
D – Choose whether all or only changed files shall be
secured.
 E – Determineahotkeytostartthebackup.
F – These icons are used to start the program help and
to show some information about the program.
 G – Selectwhichsystemfoldersshallbeincludedinto
the backup.
H – Determine whether the Files Backup folder shall be
hidden and if the quick file backup shall be double
confirmed or not.
I – Clicking this button minimizes the window.
J – Decide if the program shall be started during system
   boot-up.
Warning:
Forpotentiallossofdata,especiallyduetoinappropriatehand-
ling,SHARKOONassumesnoliability.
All named products and descriptions are trademarks and/or
registered trademarks of the respective manufacturers and are
accepted as protected.
AsacontinuingpolicyofproductimprovementatSHARKOON,the
designandspecificationsaresubjecttochangewithoutpriornotice.
National product specifications may vary.
The legal rights of the enclosed software belong to the respective
owner. Please observe the license terms of the manufacturer
before using the software.

QUICKSTORE PORTABLE USB3.0
ENGLISH
All rights reserved especially (also in extracts) for translation,
reprinting, reproduction by copying or other technical means.
Infringements will lead to compensation.
All rights reserved especially in case of assignation of patent
orutilitypatent.Meansofdeliveryandtechnicalmodications
reserved.
