Sharp VL-A111S/H/E User manual

1
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
Page
1. SPECIFICATIONS .............................................................................................................................. 2
2. PART NAMES AND FUNCTION ........................................................................................................ 3
3. DISASSEMBLY OF THE SET ............................................................................................................ 4
4. MECHANISM ADJUSTMENT........................................................................................................... 10
5. ADJUSTMENT OF THE ELECTRICAL CIRCUITS .......................................................................... 21
6. BLOCK DIAGRAMS.......................................................................................................................... 34
7. SCHEMATIC DIAGRAMS................................................................................................................. 44
8. PRINTED WIRING BOARD ASSEMBLIES ...................................................................................... 88
9. REPLACEMENT PARTS LIST ......................................................................................................... 99
10.PACKING OF THE SET.................................................................................................................. 116
S32G4VL-A111S
SERVICE MANUAL
LIQUID CRYSTAL CAMCORDER Hi 8 PAL
CONTENTS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
originalconditionandonlyparts identical to those specified
be used.
MODELS
SERVICE MANUAL LIQUID CRYSTAL CAMCORDER Hi PAL
8
SHARP CORPORATION
MODELS VL-A111S/H/E/AH131S/H/E/AH151S/H/E
VL-A111S/H/E
VL-AH131S/H/E
VL-AH151S/H/E

2
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
Signal System: PAL standard
Recording System: 2 rotary heads, helical scanning system
Cassette: A111S/H/E: 8 mm video tape, MP type
AH131S/H/E/AH151S/H/E: 8 mm video tape, MP type or Hi8 MP, ME
type
Recording/Playback Time: 120 minutes (P5-120)
Tape Speed: 20.051 mm/second
Pickup Device: 1/4" (6.4mm, effective size: 4.5 mm) CCD image sensor (with approx.
320,000 pixels including optical black)
Lens: 16 ×power zoom lens (F1.4, f=4.0-64.0 mm), and full-range auto focus
Lens Filter Diameter: 46 mm
Monitor: 3" (7.5 cm) full-color LCD screen (TFT active matrix)
Microphone: Electret monaural microphone
Color Temperature Compensation: Auto white balance with white balance lock
Minimum Illumination: 0.8 lux* (with gain-up, F1.4)
Video Output Level: 1.0 Vp-p 75-ohm unbalanced
Audio Output Level: –8 dBs, impedance less than 2.2 kohms
Speaker Output: 200 mW
Power Requirement: DC 3.6V (with battery pack)
DC 7.0V (with AC adapter)
Power Consumption: A111S/H/E/AH131S/H/E: 4.9W
AH151S/H/E: 5.0W
(during camera recording in full auto mode with
zoom motor off and backlight in normal mode)
Operating Temperature: 0°C to + 40°C
Operating Humidity: 30% to 80%
Storage Temperature: –20°C to +60°C
Dimensions (approx.): 183 mm (W) ×109 mm (H) ×99 mm (D)
Weight (approx.): 720g
(without battery pack, lithium battery, video cassette, and lens cap)
1. SPECIFICATIONS
Specifications are subject to change without notice.
*Minimum illumination: Since there is no widely accepted testing procedure for determining minimum illumination
capability, lux ratings are comparable only between models from the same manufacturer.
AC Adapter(UADP-0313TAZZ)
Power Requirement: AC 110-240 V, 50/60 Hz
DC Output: 7.0 V
Power Consumption: 15 W
Dimensions (approx.): 68 mm (W) ×37 mm (H) ×130 mm (D)
Weight (approx.): 233 g

3
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
2. PART NAMES AND FUNCTION
For details on the use of each control.
Front view
When the cassette compartment door is open
Terminal cover
Microphone
Zoom lens
Speaker
VIDEO jack
DC IN jack
Shoulder strap loop
Lithium battery holder
Cassette holder
Lens hood
Cassette compartment door release
Cassette compartment door
AUDIO jack
Rear view
Bottom view
Battery compartment door
Power Zoom Wide angle/ Telephoto control VOLume control
DISPLAY button
Operation buttons
CHARGE indicator
Remote Sensor (VL-AH151S/H/E only)
MENU button
LCD monitor screen
RECord START/STOP button
Shoulder strap loop FADE button Hand strap
Tripod socket
Battery compartment door release
Power switch (CAMERA/VCR select switch)

4
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
3. DISASSEMBLY OFTHE SET
3-1. REMOVAL OF THE CAMERA SECTION
Note:
Before removing the cabinet, turn off the power supply, and ascertain that the battery has been removed.
Pull out
Lens connector
(d)
(b) Pull out (a)
(a)
(1)
Camera front cabinet
1. Remove one screw ((d)XiPSF20P04000), one screw ((b)LX-
HZ0018TAFF), two screws ((a)LX-HZ0018TAFN), and pull
out the camera front cabinet (1).
(c)
Lens holder
4. Pulling the lens holder, pull out the lens upwards. Then,
remove the lens connector.
2. Remove one screw ((b)LX-HZ0018TAFF), one screw
((d)XiPSF20P04000) and two screws ((a)LX-HZ0018TAFN)
and pull out the camera rear cabinet (2) backwards.
Remove the FPC in the camera rear cabinet.
(b)
(d)
Connector
(a)
(a)
Pull out
(2)
Camera rear cabinet
1
2
6. Remove two screws ((b)LX-HZ0018TAFF) and pull out the
camera side cover from the tilt frame C.
(b)
(b)
Pull out
9.AfterremovingthecameraPWBfromthetiltframeC,remove
the connector on the rear of the PWB.
8.Removeone connector ofthe cameraPWB,and removetwo
screws ((c)LX-HZ0045TAFN) fixing the PWB.
7. Remove the battery catcher from the camera side cover.
3. Firstly,removetheCCDconnectorfromtheCameraPWB,then
removeonescrew ((c)LX-HZ0045TAFN), on the reverse side in
this figure (Do not remove the lens holder in this section).
5. Remove the connector of the 6-cell detection switch, and
remove two screws ((b)LX-HZ0018TAFF) fixing the battery
catcher.
CCD
connector
(b)
Connector
Tilt frame C
Connector
(c)
Connector
PSPAH0031TAZZ
FPC
Ferrite

5
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
3-2. DISASSEMBLYOFTHEVCRMAINBODY
(1) Slide the “VCR lid knob” in the arrow direction, and slide the
VCRlidinthearrowdirectionasfarasthecabinetLfastening
screw is visible. (Left figure) Since the connector of the
microphone is still connected, take care to prevent exces-
sively sliding the VCR lid.
<2. Disassembly of the cabinet L>
(3) Pull out the VCR lid shaft head which projects beyond the
surface of the VCR lid.
<Detailof areaA>
(2) Bring the jig (example: slotted precision screwdriver) into
contact with the removal groove of the VCR lid shaft, and
slidethescrewdriverwithcaretopreventdamagingtheVCR
lid and frame V.
(1) Remove one screw ((k)LX-HZ0063TAFN). (2) Remove five screws ((b)LX-HZ0018TAFF).
(3) Turn the tilt frame C so that the screwdriver can be easily
inserted, and remove two screws ((i)XiPSN20P04000).
(4) Remove one screw ((i)XiPSN20P04000).
(b)
(i)
(i)
(k)
(5) Remove the cabinet L partway, and disconnect the FPC
connector.
<1. Removal of the VCR lid shaft>
VCR lid shaft
Area A
VCR lid
Frame V
VCR lid shaft
VCR lid VCR lid knob
Tilt frame C
FPC connector
Cabinet L

6
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
<3. Removal of the VCR lid> Caution for installation of the VCR lid
<Detail of area B>
<Detail of area B>
When installing the VCR lid, move the VCR lid in the arrow
direction, keeping the VCR lid parallel to the main body as
shown above.
(2) Removetheconnectorcablefromtheholeofthemicrophone
wire spacer.
(1) Disconnect the microphone connector.
(3) Remove the microphone wire spacer from the Frame V.
(4) Pulloutthemicrophonewirecablewithcaretopreventitfrom
interfering with the mechanical parts, and remove the VCR
lid.
Pull out
(b)
(b)
<4. Removal of the AV unit and AV unit cover>
<5. Disassembly of the LCD holder>
(b)
(b) (b)
(1) Peel the wire fixing tape.
(2) Remove the AV unit wire.
(3) Remove the AV unit FPC.
(4) Removetwoscrews ((b)LX-HZ0018TAFF) fixingthe AV unit
and LCD holder.
(d)
(1) Remove three screws ((d)XiPSF20P04000) and pull out the
tripod angle.
(2) Removethreescrews((b)LX-HZ0018TAFF)onthetiltframe
V.
Move the tilt frame V by a looseness of the tilt FPC.
(d)
Microphone connector
Area B
Microphone wire
spacer
Microphone connector
Microphone connector
Microphone wire spacer
Microphone connector
Frame V
VCR Lid
VCR lid
AV unit wire
Wirefixingtape
AV unit FPC
Tripod angle
(d)

7
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
<8. Removal of the Lithium PWB>
(b)
<7. Removal of the speaker cover>
<6. Removal of the tilt unit> <9. Disassembly of the frame V>
(e)
(e) (e)
A
D
C
E
<10. Removal of the cassette compartment lid>
(1) Using the slotted precision screwdriver, push and turn the
two claws (C and D) which fasten the cassette compartment
lid, and the cassette compartment lid will be removed from
the hook area of the cassette component.
(2) Turning the cassette compartment lid in the arrow direction,
liftit,andtheclawsAandBwill be disengaged toremovethe
cassette compartment lid.
Note:
Take care to prevent breaking the claws of the cassette com-
partment lid.
(2) Remove the screw ((b)LX-HZ0018TAFF) fixing the speaker
cover.
(3) Move the speaker holder in the direction of the arrow to
remove it.
B
(1) Remove three screws ((e)LX-BZ0191TAFD) and one con-
nector, and remove the frame V from the main body.
(1) Disconnect three connectors.
Remove the tilt unit from the cabinet of the main body.
(3) Remove two screws ((b)LX-HZ0018TAFF) and two connec-
tors, and remove the LCD unit (with inverter) from the main
body.
(1) Remove the connector of the Lithium PWB from the Main
PWB.
(2) Move the lithium unit in the direction of the arrow.
Connector
LCD unit (b)
Inverter transformer
Battery terminal
unit
Tilt frame C
Tilt frame V
Main PWB
Connector
Lithium PWB
Main PWB
Connector
Frame V Connector
Mechanism unit
CB
F
D
A
(1) Remove the connector of the speaker cover from the Main
PWB.

8
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
<11. Disassembly of the LCD panel>
Light guide plate
Reflection sheet
(C)
Prism sheet
Diffusion sheet
1. Disengage two claws (A), and remove the lamp inverter unit (1) from the LCD holder (2).
2. Remove the sheets from the LCD holder (2).
3. Pull the LCD glass retaining (3).
4. Remove the FPC from Arm(D) and (E).
5. Disengage the claw (B), and slide the LCD panel (4) in the (C) direction to remove the LCD holder (2).
Note:
When handling the prism sheet, diffusion sheet, light guide plate and reflection sheet do not touch any parts other than lugs and
sides.
With the light guide plate and reflection sheet between reflectors of lamp, install them together with the lamp ass'y.
Note:
Whenfixingthecassettecompartmentlid,firstengagetheclaws
AandB,andthenengagetheclawsCandD,confirmthatthefour
claws (A, B, C and D) of the cassette compartment lid are
securely engaged as shown in the view above.
Claw C
Claw A
Claw B
Claw D
View E
View F
(2)
(4)
Arm(D)
FPC
Arm(E)
Claw (B) Disengage the claw, and remove the
LCD panel.
(1)
Claw (A)
(2)
Claw (A)
Lugs Lugs
(3)

9
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
3-3-2. REMOVAL OF CCD
1) Unsolder the CCD sensor leads from the sensor PWB.
2) Take out the sensor PWB.
3) Remove the two screws (6), and remove the sensor holder and CCD sensor.
3-3-3. MOUNTING OF CCD
1) Place the lens unit upright (since the CCD sensor mount ID faces upward, care must be taken so as not to damage the front lens of
unit),putthe crystal filterfirst and thenthedust protectionrubberinto the CCDholder of lensunit.Set thecrystalunit with itsthinside
toward the lens unit.
2) Place the CCD sensor so that the its No. 1 pin is at the right lower (Positioning hole to be at right), and put the CCD sensor into the
CCD holder. For smooth and tight fitting, press the right lower part of back of CCD sensor, and then press the left upper part.
Note: Pay attention to the direction of CCD sensor.
3) Placethesensorholdersothatitstworoundmarkingsbevisible,andfixthesensorholderwiththetwoscrews((6)LX-HZ0013TAFF).
4) Mount the sensor PWB so that the CCD sensor leads go thorough the PWB holes.
5) Solder the CCD sensor lead to the sensor PWB.
Note: Take care not to apply excessive heat.
Rubber
Lens
Side CCD
Side
The THIN SIDE
faces the lens
Crystal
CCD Sensor
Sensor Holder
(6)
Mark
The mark must be on
this face.
3-3. REPLACEMENT OF CCD SENSOR
3-3-1. BEFORE REPLACEMENT
1) The CCD image sensor is more sensitive to electrostatic breakage than C-MOS LSI. Therefore sufficient means to prevent
electrostatic damage must be taken when it is replaced.
•Ground the soldering iron.
•Ground also the human body, using the wrist strap(through an 1 Mohm resistor).
•Until the CCD sensor is mounted on the PWB, fit it to the conductive sponge, and short-circuit the foot lead.
2) Takeutmostcaresothatthesurfaceglassof CCD sensor andopticalfilterarenotcontaminatedordamaged.If any contamination
is found, for example fingerprint, wipe it off with silicon paper or clean chamois skin.
3) When replacing the CCD sensor, perform quick soldering with a soldering iron which is grounded to prevent static electricity.
JAPAN
SHARP
Index Mark
LZ2423H5
YYWWXXX
17
14 8
CCD Rear face

10
VL-A111S/H/E/AH131S/H/E
VL-AH151S/H/E
4. MECHANISM ADJUSTMENT
4-1. MECHANISM CHECKING/ADJUSTING JIGS, TOOLS AND PARTS
4-1-1. Mechanism checking/adjusting jigs and tools
<Note: The entries of list>
Configuration
1. Name
2. Part No.
3. Code
* Model, Application
1. Screw locking agent
(1401B)
* Three Bond
1. Cleaning liquid
(Industrial-useethylalcohol)
* Commercially available
item
1. Oil
COSMOHYDRO HV100
* Cosmo Oil Co., Ltd.
1. Greases
Morycoat YM-103/X5-6020
* Dow Corning 1. Superfine swab
* Commercially available
item
1. Cleaning paper
2. JiGDUSPER
3. AP
* Dusper ∑(Sigma) (Ozu Co., Ltd.)
1. Height adjusting jig
2. 9DAGH-E31S
3. BM
* For adjustment of Tu
guide height and Si
roller height
1. Master plane
2. JiGMP-MX7U
3. CG
* For adjustment of Tu guide
height and Si roller height and
checking of reel disk height
<Others>
(1) Slide calipers
(2) High-precisionscrew-
drivers(Phillipshead,
slotted head)
(3) Long-nose pliers
(with thin jaws)
(4) A pair of tweezers
<Note: The entries of list>
Configuration
1. Name
2. Part No.
3. Code
* Model, Application
1. Cassette torquemeter
for PB
2. JiG8T-012
3. CV
* (10 g·cm/25 g·cm)
1. Cassette torquemeter
for VS-REW
2. JiG8T-032
3. CV
* (50 g·cm/25 g·cm)
1. Torque gauge
2. JiGTG0045
3. CN
* For measurement of
loading brake torque
1. Torque gauge head
2. JiGTH-MX7U
3. BS
* For torque gauge listed
left
1. Torque driver
(1.5 kg·cm)
2. JiGTD1500RT0H
3. CB
1.8
4
Tolerance±0.1
Edge
thickness 0.5
2
4-1-2. Parts for periodic inspection and maintenance
1. Alignment tape
2. VR2DB0PS
3. BT TAPE CONTENTS
VIDEO IMAGE AUDIO TIME
MONOSCOPE L-CH 400Hz 30MIN
R-CH 1,000Hz
1. Tu guide height
adjusting driver
2. 9EQDRiVER-V712
3. BL
1. Guide roller height adjusting driver
2. JiGDRiVERHMX7U
3. BU
* Bit shape (See the figure above.)
1. Hex wrench
* For loosening or tight-
ening of Motor stator
(1.3mm)
1.TensionBandandPlate
Adjusting Jig
2. JiGDRiVERMX7U2
3. BN
