1
VL-Z3U/Z5U
Supplement
SUPPLEMENT
S73G1VL-Z3U//
LIQUID CRYSTAL DISPLAY CAMCORDER NTSC
SERVICE MANUAL
SHARP CORPORATION
VL-Z3U
VL-Z5U
MODELS
Page
JAPAN PRODUCTION TO SMM PRODUCTION ........................................................................2
In the Parts List of the Service Manual in question, there are some modifications in the service parts
because the model is now manufactured in SMM, not in Japan. Accordingly, we have issued this
revised one with the modified parts listed. For the other parts, you are requested to refer back to
the already issued Service Manual for VL-Z3U/Z5U(S53A8VL-Z3U//).
CONTENTS

2
VL-Z3U/Z5U
Supplement
JAPAN PRODUCTION TO SMM PRODUCTION
 1 Japan Productiion,2SMM Productiion
MODEL VL-Z3U VL-Z3U VL-Z3U VL-Z5U VL-Z5U
Japan Productiion 1 (A3VLZ3U) 1 (A3VLZ3UMM) 1 (A3VLZ3C) 1 (A3VLZ5U) 1 (A3VLZ5C)
SMM Productiion 2 (A3QUZ3U) 2 (A3QUZ3UMM) 2 (A3QUZ3C) 2 (A3QUZ5U) 2 (A3QUZ5C)
Ref no. Description Japan Parts SMM Parts Interchangebility
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
MAIN PWB Unit(VL-Z5U) DUNTKB722QA02 DUNTKB722QA46 V D ー
MAIN PWB Unit(VL-Z3U/Z3C) DUNTKB722QA07 DUNTKB722QA35 V A ー
MAIN PWB Unit(VL-Z3UMM) DUNTKB722QA54 V D ー
CCD PWB Unit(VL-Z5U) DUNTKB724QA00 DUNTKB724QA24 V D ー
CCD PWB Unit(VL-Z3U/Z3C) DUNTKB724QA02 DUNTKB724QA20 V A ー
CCD PWB Unit(VL-Z3UMM) DUNKTB724QA22 V D ー
SUB PWB Unit(VL-Z5U) DUNTKB729QA04 DUNTKB729QA22 V D ー
SUB PWB Unit(VL-Z3U/Z3C) DUNTKB729QA09 DUNTKB729QA20 V A ー
SUB PWB Unit(VL-Z3UMM) DUNTKB729QA20 V A ー
LCD PWB Unit DUNTKB726QA00 DUNTKB726QA05 V A ー
LCD PWB Unit(VL-Z3UMM) DUNTKB726QA05 V A ー
HEAD AMP PWB Unit DUNTKB733QA00 DUNTKB733QA05 V A ー
HEAD AMP PWB Unit(VL-Z3UMM) DUNTKB733QA05 V A ー
LITHIUM PWB Unit DUNTKB731PM00 DUNTKB731PM20 V A ー
LITHIUM PWB Unit(VL-Z3UMM) DUNTKB731PM20 V A ー
OPERATION SW PWB Unit DUNTKB730PM00 DUNTKB730PM20 V A ー
OPERATION SW PWB Unit(VL-Z3UMM) DUNTKB730PM20 V A ー
VCR OPERATION PWB Unit DUNTKB734PM00 DUNTKB734PM20 V A ー
VCR OPERATION PWB Unit(VL-Z3UMM) DUNTKB734PM20 V A ー
ZOOM SW PWB Unit DUNTKB735PM00 DUNTKB735PM20 V A ー
ZOOM SW PWB Unit(VL-Z3UMM) DUNTKB735PM20 V A ー
MEKA REVERSION DETECTION PWB Unit DUNTKB732PM00 DUNTKB732PM20 V A ー
MEKA REVERSION DETECTION PWB Unit(VL-Z3UMM) DUNTKB732PM20 V A ー
CABINET PARTS LIST
1 KS Adjusting Cover CCOVHA030WJK1 CCOVHA030LM01 V A AH
3 KS Camera L Cabinet(L-Z3U) CCABBA185WJK1 CCABBA185WJK3 V A AV
4 Ks Terminal Cabinet(VL-Z3U/Z3C) CCABCA010WJK1 CCABCA010WJK4 V A AQ
5
KS Camera Front Cover(VL-Z3U/Z3C ) CCOVAA321WJK6 CCOVAA321LM01 V A AX
6 KS Camera Top Face Cover CCOVAA379WJK1 CCOVAA379LM01 V A AN
7 KS Camera Bottom Cover CCOVAA373WJK1 CCOVAA373LM01 V A AN
8-1 Slide Support Holder Ass’y DHLDZA154WJ01 DHLDZA154WJ02 V A AZ
10-1 KS LCD Shield Case(Rear) CANGKA117WJ01 CANGKA117LM01 V A AL
10-3 LCD Tilt Unit Ass’y CCOVAA314WJK1 CCOVAA314LM01 V A BA
10-4 Lamp Unit CLMPVA002WJ01 CLMPVA002QA01 V A AR
10-6 LCD PWB Unit DUNTKB726QA00 DUNTKB726QA05 V A ー
12 SUB PWB Unit(VL-Z5U/Z5C) DUNTKB729QA04 DUNTKB729QA22 V A ー
29 Model Label(L-Z3U) TLABMA443WJZZ TLABMA540WJZZ V D AC
CABINET MECHANISM PARTS LIST
101 KS Camera Tilt CANGKA141WJ01 CANGKA141WJ02 V A BA
103
KS Preparation Cover(VL-Z3U/Z3C) CCOVAA353WJK2 CCOVAA353WJKA V A AS
105 KS VCR Operation Cover CCOVAA354WJK1 CCOVAA354WJK4 V A AT
LENS Unit PARTS LIST
2 CCD PWB Unit(VL-Z5U) DUNTKB724QA00 DUNTKB724QA24 V A ー
2 CCD PWB Unit(VL-Z3U/Z3C) DUNTKB724QA02 DUNTKB724QA20 V A ー
ACCESSORIES
A/VS Cable QCNW-B173WJZZ QCNW-B173WJZZ V A AR
USB Cable QCNW-A703WJZZ QCNW-B400WJPZ V A AH
Operation Manual(VL-Z3U/Z5U) TiNSEA050WJZZ TiNSEA050WJN1 V A AL
Operation Manual(Z3C) TINSLA053WJZZ TINSLA053WJN1 V A AT
CD-ROM CDSKAA028WJ01 CDSKAA028WJN1 V A AH
ACCESSORIES
(NOT REPLACEMENT ITEM)
Guarantee Card(VL-Z3U/Z5U) TGANE0044TAZZ TGANE0071TAZZ V A ー
PACKING PARTS
(NOT REPLACEMENT ITEM)
Paking Case SPAKCA577WJZZ SPAKCA734WJZZ V Dー
Packing Add.(Bottom) SPAKAA089WJZZ SPAKAA097WJZZ V A ー
A: Completely interchangeable. ................................ (OLD = NEW)
B: Interchangeable from OLD to NEW. ..................... (OLD to NEW)
C: Interchangeable from NEW to OLD...................... (NEW to OLD)
D: Not interchangeable. ............................................. (NEW x OLD)
Interchangeability
Price
Code
★MARK : SPARE PARTS-DELIVERY SECTION:ALL SMM
★
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
~~
~~
~
