Sharp IV-C35M User manual

Compact Color Image Sensor Camera
User’s Manual (Introduction and Hardware)
Version 1.0
Produced in Mar. 2002

Thank you for purchasing the SHARP IV-C35M compact color image sensor camera.
Read this introductory user's manual carefully to thoroughly familiarize yourself with the functions and proper
procedures for operation.
Store this user's manual in a safe place. We are confident that the manual will be helpful whenever you
encounter a problem.
In addition to this manual, there are other IV-C35M manuals as follows. Read them in conjunction with this
manual.
IV-C35M User’s Manual (Introduction and Hardware: This manual)
User’s Manual (Function and Operation)
Instruction Manual
Manual type Major subjects How to use
IV-C35M
User's Manual
(Introduction and Hardware)
- Outline of the IV-C35M (features and
functions)
- Description of the hardware
- Startup method
- General performance specifications.
- Example of operation and instruction
- Become acquainted with the IV-C35M
- Learn how to install the IV-C35M and
wire it up
- When mastering the outline of
operation
IV-C35M
User's manual
(Function and Operation)
- Detailed explanations of all the
measurement functions.
- How to make menu selections for
each measurement
- Details of inputting and outputting
data and communications with other
devices.
- Troubleshooting
- Learn how to specify measurement
/inspection conditions, good or NG
judgment conditions, etc.
- Lear how to connect a programmable
controller or personal computer.
- Learn what to do if a problem occurs.
Notes
- This manual was written with the utmost care. However, if you have any questions or
inquiries concerning the product, please feel free to contact our dealers or service agents.
- Copying all or part of this booklet is prohibited.
- The contents of this manual may be revised or modified for improvement without prior
notice.

Safety Precautions
Read this user's manual and the attached documents carefully before installing, operating, or performing any
maintenance, in order to keep the machine working correctly. Make sure you understand all of the equipment
details, safety information, and cautions before using this machine. In this user's manual, the safety
precautions are divided into "Dangers" and "Cautions" as follows.
Danger : Improper handling is likely to lead to death or serious injury.
Caution : Improper handling may lead to injury or damage to equipment.
Even when only a Caution is given, serious results may occur depending on the
circumstances. In all cases, important points are described. Be sure to follow the
advice given.
The following symbols are used to prohibit or explain required action.
: This means do not do what is described. For example, prohibited disassembly is shown as .
: This means an action you must take. For example, a ground connection that must be made is
shown as .
(1) Installation
Caution
- Use only in the environments specified in the instruction manual, or user's manual.
Electric shock, fire or malfunction may result if used in high temperature, high humidity,
dusty or corrosive environments, or if excessive vibration or impact occurs.
- Install the equipment only as described in the manual.
An improper installation may cause the equipment to fail, breakdown, or malfunction.
- Never leave wire cuttings or any other foreign matter lying about.
A fire, breakdown or malfunction may result from inappropriate objects left near the equip-
ment.
(2) Wiring
Caution
- Do not connect any camera not specified by SHARP to the controller.
Connecting any other camera to the controller may damage the controller or the camera.
- Connect only to the specified power source.
Connection to the wrong power source may cause a fire.
- Wiring should be performed by a qualified electrician.
Improper wiring may lead to a fire, machine failure or electric shock.
(3) Use
Danger
- Don't touch the terminals while the power is turned ON or you may receive an electric shock.
- Assemble an external emergency stop circuit and interlock circuit (external to the IV-C35M
compact color image sensor camera). Otherwise a breakdown or damage to other equip-
ment may occur due to a problem with the IV-C35M.
Caution
- Take special care to follow all safety guidelines if you are changing the parameters for the
operating conditions or performing an "enforced output," "run," or "stop" during operation.
Misoperation may damage the machine or cause an accident.
- Turn ON the power supplies in the specified sequence. Turning ON the supplies in the wrong
order may lead to a machine breakdown or cause an accident.

(4) Maintenance
Warning
- The controller contains a lithium battery. Do not expose the IV-C35M directly to flames as the
battery may explode and seriously injure people nearby.
Prohibit
-Don't disassemble or modify the camera.
Fires, breakdowns or malfunctions may occur, if the camera is disassembled.
Caution
- Turn OFF the power source before connecting or disconnecting the IV-C35M.
If you don't, electric shocks, malfunctions or breakdowns may occur.

Chapter 1: Outline
Chapter 2: Precautions for Use
Chapter 3: System Configuration
Chapter 4: Part Names and Functions
Chapter 5: Connection and Installation Methods
Chapter 6: Setting and Operating Outlines
Chapter 7: Setting Examples Using the Set Wizard
Chapter 8: Specifications
Glossary
Appendix
Alphabetical Index

Table of contents
Chapter 1: Outline ................................................................................................ 1 to 15
1-1 Features....................................................................................................................................... 1-1
1-2 Color extraction............................................................................................................................ 1-5
1-3 Color filter .................................................................................................................................... 1-5
1-4 Measurement program ................................................................................................................ 1-6
[1] Color extraction mode ................................................................................................................ 1-6
[2] Color filter mode......................................................................................................................... 1-8
[3] Common for both color extraction and color filter modes ........................................................ 1-14
Chapter 2: Precautions for Use ................................................................................ 2-1
Chapter 3: System Configuration ...................................................................... 3-1 to 6
3-1 Basic system configuration .......................................................................................................... 3-1
3-2 System configuration examples ................................................................................................... 3-3
[1] System configuration example for measurement triggered by an external trigger..................... 3-3
[2] System configuration example for measurement triggered by the internal CCD sensor trigger 3-4
[3] System configuration example for measurement triggered by a command from a PC.............. 3-6
Chapter 4: Part Names and Functions .............................................................. 4-1 to 5
4-1 Controller (IV-C35M) .................................................................................................................... 4-1
4-2 Camera ........................................................................................................................................ 4-2
[1] Camera ...................................................................................................................................... 4-2
[2] Camera lens (IV-S20L16) .......................................................................................................... 4-4
[3] Camera cable (IV-S30KC3/KC5) ............................................................................................... 4-4
4-3 Remote keypad (IV-S30RK1) ...................................................................................................... 4-5
Chapter 5: Connection and Installation Methods .......................................... 5-1 to 24
5-1 Installation conditions .................................................................................................................. 5-1
[1] Lighting equipment..................................................................................................................... 5-1
[2] Optimum lens and resolution ..................................................................................................... 5-2
5-2 Installing, connecting and wiring the IV-C35M controller ............................................................. 5-8
[1] Connecting equipment to the controller ..................................................................................... 5-8
[2] Installation .................................................................................................................................. 5-9
[3] Connecting a power supply.......................................................................................................6-11
[4] Connecting to the input/output terminals (parallel I/F) ............................................................. 5-12
[5] Connection for communications with personal computer (general purpose serial I/F) ............ 5-13
[6] Connecting a programmable controller using the computer link function ................................ 5-15
5-3 Installing and connecting the IV-C30C5, IV-S30C3/S30C4 camera .......................................... 5-16
[1] Installing and connecting the IV-C30C5, IV-S30C3 color/high-speed monochrome cameras . 5-16
[2] Installing and connecting the IV-S30C4 micro, high-speed monochrome cameras................ 5-20
Chapter 6: Setting and Operating Outlines .................................................... 6-1 to 19
6-1 Setting and operating procedures................................................................................................ 6-1
6-2 Description of the operation screen ............................................................................................. 6-2
6-3 Wizard.......................................................................................................................................... 6-5
[1] How to start the standard wizard ............................................................................................... 6-5
[2] Other operations in the "Set wizard" program............................................................................ 6-6
6-4 Operation chart ............................................................................................................................ 6-8

[1] Method for displaying the operation chart .................................................................................. 6-8
[2] How to edit an operation chart ................................................................................................... 6-9
6-5 Menu tree....................................................................................................................................6-11
6-6 Relationship between the set wizard program, the operation chart, and the menu tree............ 6-13
6-7 Editing operation screen ............................................................................................................ 6-14
6-8 Option ........................................................................................................................................ 6-15
6-9 Environment settings ................................................................................................................. 6-16
6-10 Memory card ............................................................................................................................ 6-17
[1] Installation of a memory card ................................................................................................... 6-17
[2] Storage method ....................................................................................................................... 6-18
Chapter 7: Setting Examples Using the Set Wizard....................................... 7-1 to 33
7-1 Color evaluation ........................................................................................................................... 7-1
7-2 Fault inspection.......................................................................................................................... 7-13
7-3 Positional deviation measurement ............................................................................................. 7-23
Chapter 8: Specifications ..................................................................................8--1 to 8
8-1 Controller (IV-C35M) .................................................................................................................... 8-1
8-2 Camera specifications ................................................................................................................. 8-4
[1] Camera (IV-SC30C5/S30C3/S30CC4) ...................................................................................... 8-4
[2] Camera lens (IV-S20L16) .......................................................................................................... 8-5
[3] Camera cable (IV-S30KC3/KC5) ............................................................................................... 8-5
8-3 Support tools................................................................................................................................ 8-6
[1] LCD monitors (IV-10MT/10MTV/10MTK) ................................................................................... 8-6
[2] Monochrome monitor (IV-09MT: When using IV-S30C3/C4) ..................................................... 8-7
[3] LED lighting equipment (IV-60LD: When using IV-S30C3/C4) .................................................. 8-8
Glossary ............................................................................................................ G-1 to 14
Appendix ............................................................................................................. A-1 to 3
Appendix 1: Commercially available peripheral devices .................................................................... A-1
Appendix 2: Working samples ........................................................................................................... A-3
Alphabetical Index ............................................................................................... I-1 to 5

1-1
１
Outline
Chapter 1: Outline
The IV-C35M compact color image sensor camera has an integrated color image processing function
to inspect and measure images, that could not be inspected or measured using a monochrome
camera. Thanks to SHARP's unique partial image capture function and a high-speed gray search
function, it will reduce overall processing time. It will not only contribute to high-speed, high-efficiency
inspection and measurement processes, but also help you keep your prices competitive.
1-1 Features
A variety of color filters and a color extraction function clearly distinguish subtle differences
in tone and density.
In addition to filtering the three primary colors (red, green, and blue), the IV-C35M can make accu-
rate images of objects using brightness and other optional filters.
Color filter functions for the three primary colors (RGB) and brightness and 5 optional
filters.
Select the color components and brightness of an area you want to evaluate, and display just the
specified component brighter. Then convert it to a 256 gray scale or binary image.
The color filter can be set to display the specified color brightly after gray scale image processing.
This is effective in evaluating subtle differences in color, or for finding flaws or dirt that have
similar colors or tones.
Original color image Conventional
monochrome
processing
If the hue or color saturation
is very similar between
adjacent areas, the images
cannot be evaluated.
Conventional gray
image processing
The density of this image
can be measured. However,
the hue and color saturation
cannot be evaluated.
Brightness filter
Displays areas that are within
the specified brightness range
(within the specified upper and
lower limits) more brightly.
Custom filter
Specify the optimum color filter
parameters to use, based on the
original image conditions. The optional
filter is effective if the RGB filters are
not used to show areas as brighter.
R (red) filter
Displays red areas more brightly.
G (green) filter
Displays green areas more brightly.
B (blue) filter
Displays blue areas more brightly.

1-2
１
Outline
Specify a color to extract from the original image.
The controller eliminates all areas of the image except those that have the specified color. Then, it
converts what is left into a binary image. This color extraction function not only works with hue and
saturation, but also with brightness. Therefore, achromatic objects that cannot be processed using
a color filter can still be extracted.
The controller can extract up to 8 colors in one object type. By specifying multiple object types, it
can be used to evaluate even more colors.
The measurement menu has been improved further by adding new menu items.
In addition to conventional measurement menu items, new items have been added for color related
functions including evaluating the color of objects, uneven color inspection, color positional measure-
ment, and fault inspection. You can select the menu program items that match your application from 18
measurement menu items.
Easy operation menu
Setting wizard
The IV-C35M wizard asks you to make selections using a questionnaire, thus allowing anyone to set
up the measurement operations and preferences, and decrease the chance of mistaken settings.
Color extraction
For example, you can extract just the blue
area of the letter E in the image on left.
Color filer
* When a monochrome camera is connected to the IV-C35M, the color evaluation,
color unevenness inspection, and color position measurement features cannot be
used.
Itemsinredarenewmenuitems.
Gray image Binary image
Color extraction
Binary image
- Color evaluation
- Color unevenness inspection
- Color position measurement
- Area measurement by binary conversion
- Object identification by binary conversion
- Count objects by binary conversion
- Area measurement by binary conversion
- Object identification by binary conversion
- Count objects by binary conversion
- BGA/CSP inspection
- Point measurement
- Fault inspection
- Position deviation measurement
- Degree of match inspection
- Lead inspection
- Point measurement
- Multiple position measurement
- Multiple degree of match inspection
STEP10
STORETHISSETTINGASA
SAMPLEINTHEWIZARD?
1
NO □
2
YES ■
RETURN END
・・・
・・・

STEP2
SELECTANIMAGECAPTURING
METHODDURINGOPERATION
1
PARTI AL-IMG ■ 
2
ALL IMAGE □ 
3
NO CAPTURED □ 
ENTER A SHUTTER SPEED
(1/30〜1/10000)
1
SHUTTER SPEED 1/00060
RETURN NEXT
STEP1
SELECT THE MEASUREMENT
START INPUT I/F
1
PARALLEL+SERIAL+USB ■
2
TRIG CCD START
□
NEXT DETAIL

1-3
１
Outline
Capturing whole image
Decreased capturing time
12
Capturing partial image
* When capturing 240 lines from vertical 480 lines.
＊
Tree menu
The tree structure menu lets you find the setting parameter you
need easily. Using the short cut function, you can move directly to a
desired menu.
Operation screen editing function
You can move, remove, enlarge, and decrease the size of the information displayed on the operation
screen.
OBJECTTYPECOND
TYPE00
TYPERUNCOND
IMAGE-ADJ
MEA-CND(CAMERA1)
MEAS0
POSI-CORRECT
MEAS01(MEAS-BIN-AREAP)
MEAS(NEW)
MEA-CND(CAMERA2)
FINALNUM.CALC
FINALOUTPUTCOND
OBJ-TYPEI/O
OBJ-TYPESYS.
TYPE(NEW)
+
+
+

VX.XX
X0〜7 Y0〜7READY
COLORFC1BRT(TYPE00)
OK
MEAS XXXXms2001-10-14 10:38
MEASUREMENT 1 MEAS-BIN-AREA
MNU-CHG MAIN-COND CHG-MEA COND-CHG CHNG-REG SCREEN-CHG CHG-TYPE
A00=001884 OK
A01=
A02=
A03=
A04=
A05=
A06=
A07=
X0〜7Y0〜7READY
COLORFC1BRT(TYPE00)
OK
MEAS XXXXms2001-10-14 10:38
MEASUREMENT 1 MEAS-BIN-AREA
MNU-CHG MAIN-COND CHG-MEA COND-CHG CHNG-REG SCREEN-CHG CHG-TYPE
A00=001884 OK
A01=
A02=
A03=
A04=
A05=
A06=
A07=
OK

VX.XX
Shorten the cycle time by connecting two cameras
The two IV-C30C5 color cameras or two IV-S30C3/C4 high-speed monochrome cameras can be
simultaneously connected to IV-C35M controller. By connecting two cameras, your system can reduce
the processing time by positioning two areas at the same time, and then inspecting two areas at the
same time. By triggering the cameras at the same time, the system can capture two images, and
display the images above and below each other, or left and right.
Note: Combined use of a color camera and a high-speed monochrome camera is not possible.
High-speed processing now possible using a color camera or a high-speed monochrome
camera and partial image capture
Sharp's unique partial image function offers high-speed image capture.

1-4
１
Outline
CCD trigger function does not need an external sensor
After a trigger window is setup, the IV-C35M does not need an external sensor if it is scanning
moving objects. To set up a trigger, you can select from color, binary image conversion, average
density, gray search, and edge detection techniques. The gray search mode is useful for a
workpiece for which you cannot easily establish the density range.
Shutter speed freely set
The shutter speed can be set anywhere between 1/30 and 1/10000 second for each object type.
Practically, this means that the light level can be adjusted without changing the lighting equipment
for each object type. The random shutter function is used to close the shutter when a trigger event is
detected, so that precise still images of moving objects can be scanned.
CE approval applied for, widely accepted in international markets
The reliability of the IV-S30 means that it can be used in units destined for overseas markets.
Displays and transfers NG images while measurements are being made
While in measurement, NG images and NG history of the IV-C35M can be seen. Using the USB
communication, the controller transfers NG images to a personal computer in approximately 7 seconds.
This is convenient to investigate NG images for feedback for designing, and contributes to quality
improvement.
Automatically stores NG images on a flash memory card.
The controller is equipped with an interface for a compact flash memory card. When a compact flash
memory card is inserted in the controller housing, NG images can be stored on the card.
A flash memory card can store up to 264 NG images.
* 512x480 pixels: When a 192 MB capacity flash memory card is used.
Read the OK/NG results easily by looking at a colored display of the measurement area and
evaluation result information.
Since the IV-C35M can display the measurement area in any color and the results of the evaluation
can be display in any specified color, you can easily see for yourself if the result is OK or NG.
This function is available even when a monochrome camera is connected.
Customize to your own specification
An IV-S30LB1 image processing library and IV-S30SP parameter setting support software are both
available. Using these tools, the menu screen can be modified to suit your specialized needs to create
your own unique image processing system.
CCD trigger
Scanning
direction

1-5
１
Outline
1-2 Color extraction
The color extraction function extracts a color in a certain area from the original image, and registers it
as a reference color. The controller converts areas of color that are within the upper and lower limit
ranges of hue, saturation, and brightness of the reference color to binary images, as well as colors
outside of these ranges.
Then, the controller measures these binary images with conventional measurement procedures.
Effects of extracting color
Available measurement programs that can be used with the color extraction function are area
measurement by binary conversion, object counting by binary conversion, object identification by
binary conversion, color evaluation, color unevenness inspection, and color position measurement.
1-3 Color filter
Color filter is to filter red, green, blue, brightness, or optionally, the captured image, and display the
filtered color as bright gray.
Then, the controller measures these gray images with conventional measurement
Filter types
The color filter function can be used with positional deviation measurement, degree of match inspec-
tion, lead inspection, BGA/CSP inspection, area measurement by binary conversion, object counting
by binary conversion, object identification by binary conversion, point measurement, multiple position
measurement, multiple degree of match inspection, and fault inspection.
Originalcolorimage Extractingcolor
R (red) filter Displays red areas more brightly.
G (green) filter Displays green areas more brightly.
B (blue) filter Displays blue areas more brightly.
Brightness filter Displays areas that are within the specified brightness range (within
the specified upper and lower limits) more brightly.
Custom filter Specify the optimum color filter parameters to use, based on the
original image conditions.

1-6
１
Outline
Image after extracting a colorCaptured image
Extracted color (red)
Measurement
area
Measured result
Color degree of match = (Binary area / Measurement area size) x 100
[Inspection procedures]
Capture image →Color extraction (binary conversion)→Measurement
[Measurement results]
・Binary area
・Color degree of match
・Average hue
・Average saturation
Purpose
Example
Evaluate whether the extracted color matches the reference.
Application
* Other colored pencils are
extracted one after the
other.
* When the arrangement is
appropriate, all the
measurement area will be
white after extracted each
color one after the other.
Color extracted area
changes to white.
Inspect arrangement of colored pencils (Check if the colored pencils are arranged in
proper order.)
1-4 Measurement program
The IV-C35M integrates the following measurement programs.
Color extraction mode: Color evaluation, color shading (uneven color) inspection, color position
measurement, area measurement by binary conversion, object identification by
binary conversion, and counting objects by binary conversion.
Color filter mode: Fault inspection, position deviation measurement, degree of match inspection,
lead inspection, BGA/CSP inspection, area measurement by binary conversion,
counting objects by binary conversion, object identification by binary
conversion, point measurement, multiple position measurement, and multiple
degree of match inspection.
You can select operating condition parameters to suit your application of the IV-C35M.
A description of each screen area is shown below.
[1] Color extraction mode
(1) Color evaluation

1-7
１
Outline
Purpose
Example
Evaluate color unevenness based on the size of certain extracted areas of color
that are outside the reference color range.
Application Evaluate ripeness of tomatoes.
[Inspection procedures]
Capture image → Set evaluation conditions (upper and lower limit values)
→Measurement
[Measurement results]
・Number of objects
・Total area
・Area of each object
・Max./min. hue
・Max./min. saturation
・Number of objects having faulty hue
・Number of objects having faulty saturation
Image after extracting a colorCaptured image
Setting
extracting
color
Upper
value
Evaluation
condition
Upper value
Level value
Level
value
Measurement area
Number of
NGs (number
of pixels)
NG
OK
NG
Measured result
NG
OK
(2) Color unevenness inspection (color shading inspection)

1-8
１
Outline
Cell
search area
[Inspection procedures]
Captured image→Specify search area→Specify a cell→Measurement
[Measurement results]
・Average hue
・Average saturation
・Binary area
・Color degree of match
Purpose
Example
Detect flaws or dirt on a workpiece that color was emphasized using a color filter
function.(Using a gray search function after filtering a color, the controller detects
cells having the maximum density and minimum density in the search area. It can
measure the maximum density difference with all of the area (total difference), a
position that has maximum density difference with an adjacent cell (adjacent
difference).
Application
●Inspection of whole of color LCD monitor screen
Detect flaws or dirt on a workpiece that are the same color as was emphasized
using a color filter function.
Image after extracting a colorCaptured image
■1 point search
Extracted color Reference image
Measured result
[Inspection procedures]
Binary conversion of the reference image→Register→Measurement
[Measurement results]
・Coordinate of the reference image
・Positional deviation of a workpiece from the reference image.
・Color degree of match
・Edge detection
・Angular deviation
Purpose
Example
Measure the position coordinates of a workpiece with the same extracted color as
the reference color.
Application Positioning workpieces or parts. Positional deviation inspection.
* Even if the workpiece which has
had the color extracted moves its
position, the controller can
measure the positional coordinate
of this workpiece.
(3) Color positional measurement
[2] Color filter mode
(1) Fault inspection

1-9
１
Outline
(2) Positional deviation measurement
Purpose
Example
Application
The gray scale search function and edge detection function* make possible measuring
positional deviation as well as the absolute position.
- It is also possible to detect the position of sub-pixel units with great accuracy.
- A rotation angle of 360°can be detected. (When a one point gray search is selected).
[Determining the location of the positioning (the fiducial mark) mark that
identifies the position of the substrate]
(1) 1 point search: Detecting the deviation in position in X and Y directions
* Gray scale search / edge detection function
Gray scale search: Compares a workpiece image with the 256-level gray-scale
reference image to find an area that matches the reference image.
-See G-6.
Edge detection: Finds the boundary between light and dark areas in an image.
-See G-3.
- The deviation angle θ, determined in the 2-point search, is used to readjust the
rotation of the image for measurements 1 to 4.
(2) 2 point search: Determining positional deviation in X and Y directions as well
as rotational deviation
Used to determine the position of machine parts and substrates.
[Measurement result]
Center coordinates: (X2,Y2)
Amount of deviation: X2-X1, Y2-Y1
Y2-Y1
Search area
Inspection Image: Center coordinates (X2,Y2)）
Reference image: Center coordinates (X1,Y1)
Reference image a: Center coordinates (Xa1,Ya1)
Inspection image b: Center coordinates (Xb2,Yb2)
Yb2−Yb1
Search area (image b)
Search area
(image a)
Anglar deviation: θ
θ
Xa2-Xa1
Xb2−Xb1
Ya2−Ya1 [Measurement results]
- Center coordinates of image a:
(Xa2,Ya2)
- Amount of deviation of image a:
Xa2-Xa1, Ya2-Ya1
- Center coordinates of image b:
(Xb2,Yb2)
- Amount of deviation of image b:
Xb2-Xb1, Yb2-Yb1
- Deviation angle: θ
X2-X1
Reference image b:
Center coordinates (Xb1,Yb1)
Inspection image a:
Center coordinates (Xa2,Ya2)

1-10
１
Outline
Purpose
Example
・Inspection procedures
Evaluate whether workpieces are present or not at multiple specified points.
- Gray processes or converts to binary the image and evaluates whether specified
pixel area is white or black.
- Obtains average density of specified pixel area, and evaluates whether the
density is within the specified range.
Application
●Inspection for LED lightings on mobile phones
CHR PWR
１
４
７
＊
２
５
８
０
３
６
９
＃
Number of points (max.)
: 128 points at average light levels
256 points in binary images
Point size: 2 m x 2 n pixels
(m, n = 1 to 16)
Image capture Binary conversion Black/white evaluation of points
Average light level Light level evaluation of points
Existence inspection of packing parts, inspect lighting conditions of mobile phones,
LEDs, and fluorescent tubes, and sorting products.
CLR
(3) Degree of match inspection
(4) Point measurement
Search area
for positioning Search area for positioning
Criterion image
for positioning
Criterion image
for measuring object
▲
Good label
Criterion image
for measuring object
Criterion image
for positioning
SERIAL NO.
8F053G26
MODEL
IV
-
C35M
SERIAL NO. 8F053G26 MODEL IV
-
C35M
▲
NG label
Compare a good criterion image to a test image by inspecting matching levels
using the gray scale search function. (Determine whether the part is acceptable or
NG by checking similarities between the criterion image and the workpiece (test)
image.)
Purpose
Example
Application
Detect positional deviation of labels, detect contamination of different parts, inspect
the mounting of electronic parts on PC boards, detect mis-prints, inspect for missing
electric parts such as terminals, and simple letter inspection.
[Measurement results]
- Degree of match compared with the reference image
- Detected coordinates (X/Y) of the measurement image.
- Light level in the measured image (average light level/absolute value of difference)
- Inspection procedure
1Conduct a gray scale search of the criterion image position
2Correct the position of the object being measured from the coordinates for
the criterion image obtained in item 1above.
3If the matching level of the test image is low, the IV-C35M can determine
that the label position is NG.
●Detecting label deviations on packages

1-11
１
Outline
(5) Lead inspection (Gray processing using a brightness filter)
(6) BGA/CSP inspection (Gray processing using a brightness filter)
- Inspection procedure
1Determine the measurement points (K0 to K3) from the mid points of the leads
and the reference line.
2Calculate the distances between the leads (D0 to D2) using the measurement
points.
3Calculate the lead lengths (L0 to L3) from the measurement points (K0 to K3)
toward the lead measurement limit line.
Purpose
Example
Based on positional information obtained from the gray scale search function,
inspect the condition of the IC leads and connector pins. (No. of lead pins that can
be detected in one image: Max. 128.)
Application Inspect the IC leads and connector pins.
●Inspect the layout of the IC leads and connector pins
K0
Lead
Reference line
K1 K2 K3
D1D0
W0 W1 W2 W3
D2
L3 L0 L1 L2
[Lead inspection]
- Number of leads K
- D0 to D2: Distance
between
leads
- W0 to W3: Lead
width
- L0 to L3: Lead
length
Lead measurement
limit line
- Inspection procedure
●Measurement of 6 balls
capture Binary
conversion Measure centers
of gravity
Fillet diameters
Object identification
(numbering)
Inspecting BGA/CSP solder balls.
Area of each
object Ball size
Distance between centers
of gravity for pairs of balls Distance between balls
Number of balls
Object 0 Object 1 Object 2
Object 3 Object 4 Object 5

Measure the center of gravity, area of each object, number of objects, and fillet
diameter using a color that was emphasized by the color filter function.
Purpose
Example
Application
[Measurement results]
- Number of objects: K
- Area of each object: R0 to R127
- Distance between centers of
gravity:
(DX0, DY0) to (DX127, DY127)
- Fillet diameters: FX, FY

1-12
１
Outline
(7) Multiple position measurement
The IV-C35M can detect up to 128 workpieces whose images exceed the specified
matching level (gray search) or threshold value (edge detection) compared with the
reference image.
- The positional deviation measurement needs to have a number of positions
registered for measurement. However, this measurement only requires you to
register one position and reduces the set up time.
Purpose
Example
Application Position measurement of workpieces having complicated density conditions, that
could not be measured by conventional binary conversion and density processing.
[Measurement results]
- Number of points detected
- Coordinates detected for each points
[Measured results]
- Number of images detected
- Coordinates and degree of match detected for each image
●Gray search
●Edge detection
This is useful for obtaining the distance between the coordinates of a position.
- L1 to L3 can be calculated by measuring distances and angles.
L1 L2 L3
Reference image
Four
workpieces
detected

1-13
１
Outline
(8) Multiple degree of match inspection
Using the gray search function, the IV-C35M can detect up to 128 workpieces
whose captured image exceeds the required degree of match with the reference
Purpose
Example
Application Position measurement of workpieces having complicated density conditions, that
could not be measured by conventional binary conversion and density processing.
[Measurement results]
- Number of images detected
- Degree of match, density (average/absolute difference), and detected coordinates
Reference image
Four
workpieces
detected
