Sharp Aquos LC 37D64U User manual

SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
SHARP CORPORATION
Printed in Mexico
Imprimé au Mexique
Impreso en México
TINS-D490WJZZ 1
08P01-MX-NM
LC-32D64U
LC-37D64U
ENGLISHFRANÇAISESPAÑOL
IMPORTANT : Please read this operation manual before starting operating the equipment.
IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.
OPERATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
LC-3237D64UEHyo.indd1LC-3237D64UEHyo.indd1 2008/02/0112:01:212008/02/0112:01:21

Unit: inch (mm)
Dimensional Drawings
LC-37D64U
LC-32D64U
11 13/16 (300)
3 61/64
(100)
3 3/4
(95)
2 9/16
(65)
30 9/16 (776)
27 5/8(701.5)
2 1/4
(57)
5 1/8
(130)
20 23/64 (517)
35 23/64 (898)
32 15/32 (824.4)
25 1/8(638)
2 1/4
(57) 22 7/8(581)
14 17/32 (369)
18 17/64
(463.8)
22 39/64 (574)
13 5/32 (334)
15 19/32
(395.9)
18 29/32 (480)
18 29/32 (480)
10 3/4(276)
10 3/4(276)
11 13/16
(300)
3 61/64
(100)
3 3/4
(95)
2 9/16
(65)
11 13/16 (300)
11 13/16
(300)
6 11/64
(156.7)
LC-3237D64UEHyo.indd2LC-3237D64UEHyo.indd2 2007/12/139:20:052007/12/139:20:05

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
CAUTION:
1
LC-32D64U
LC-37D64U
OPERATION MANUAL
• The illustrations and on-screen displays in this operation manual are for
explanation purposes and may vary slightly from the actual operations.
• Menu items that are not selectable are grayed out.
• The examples used throughout this manual are based on the LC-32D64U
model.
• To avoid scratching the frame or screen, please use a soft, lint free cloth
for cleaning. Approved cleaning cloths are available directly from Sharp in
single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800
BE SHARP for ordering, or VISIT www.sharpusa.com/SharpDirect.
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV's model and serial numbers in the space provided. The
numbers are located at the rear of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
ENGLISH
LC-3237D64UE.indb1LC-3237D64UE.indb1 2007/12/139:18:462007/12/139:18:46

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.”
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of
mercury. Disposal of these materials may be regulated due to environmental
considerations. For disposal or recycling information, please contact your local
authorities, the Electronic Industries Alliance: www.eiae.org, the lamp recycling
organization: www.lamprecycle.org or Sharp at 1-800-BE-SHARP
(For U.S.A. only)
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www.sharpusa.com
CAUTION:
DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD, BRACKET, OR TABLE.
THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS DAMAGE TO
THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE RECOMMENDED
BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE MANUFACTURER'S
INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING ACCESSORIES
RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART COMBINATION SHOULD BE
MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND UNEVEN SURFACES MAY CAUSE
THE PRODUCT AND CART COMBINATION TO OVERTURN.
2
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
IMPORTANT INFORMATION
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-32D64U/LC-37D64U
Trademarks
• Products that have earned the ENERGY STAR®are designed to protect the environment through superior energy
efficiency.
LC-3237D64UE.indb2LC-3237D64UE.indb2 2007/12/139:18:472007/12/139:18:47

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage
if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and cleaning the product. To ensure your safety
and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully
before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Information
15) Power Sources—This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified technician
to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
19) Replacement Parts—When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
LC-3237D64UE.indb3LC-3237D64UE.indb3 2007/12/139:18:472007/12/139:18:47

IMPORTANT SAFETY INSTRUCTIONS
4
• Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base
can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product
on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the
manufacturer.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer's instructions are followed.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 2,073,600 thin film transistors, giving you fine picture
details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that
this does not affect the performance of your product.
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to
the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC cord under the TV
set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• To prevent fire or shock hazard, do not expose this product to dripping
or splashing.
No objects filled with liquids, such as vases, should be placed on the product.
Precautions when transporting the TV
• Be sure to always carry the TV by two people holding it with two hands — one hand on each side of the TV.
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Use a soft cloth and gently wipe the surface of the display panel. Using a hard cloth may
scratch the panel surface.
• Use a soft damp cloth to gently wipe the panel when it is really dirty.
(It may scratch the panel surface when wiped strongly.)
• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it, such materials may damage
the panel surface.
• To clean the outer cabinet, use the same method. Do not use liquid or aerosol cleaners.
LC-3237D64UE.indb4LC-3237D64UE.indb4 2007/12/139:18:472007/12/139:18:47

5
Hex key
Screws
Soft cushion
1
2
Attaching/Detaching the Stand
• Before attaching (or detaching) the stand, unplug the AC
cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base
area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Do not remove the stand from the TV unless using an
optional wall mount bracket to mount it.
• Be sure to follow the instructions. Incorrect installation
of the stand may result in the TV falling over.
1Confirm that there are 9 screws supplied with the
stand unit.
2Attach the supporting post for the stand unit onto
the base using the box for the stand unit as shown
below.
• To detach the stand, perform the steps in reverse order.
Vertical mounting Angular mounting
Setting the TV on the Wall
CAUTION
• This TV should be mounted on the wall with both
the AN-37AG2 (SHARP) wall mount bracket and the
AN-37P30 (SHARP) attachment of the wall mount
bracket. The TV cannot be mounted when with
only the AN-37AG2 wall mount bracket. The use of
other wall mount brackets may result in an unstable
installation and may cause serious injuries.
• Installing the TV requires special skill that should
only be performed by qualified service personnel.
Customers should not attempt to do the work
themselves. SHARP bears no responsibility for
improper mounting or mounting that results in
accident or injury.
Using an optional bracket to mount the TV
•
You can ask a qualified service professional about
using an optional AN-37AG2 bracket to mount the TV
to the wall.
• Carefully read the instructions that come with the
bracket before beginning work.
Hanging on the wall
AN-37AG2 wall mount bracket.
(See the bracket instructions for details.)
• Detach the cable clamp on the rear of the TV when using
the optional mount bracket.
• Due to the terminal configuration on this TV, when you
wall-mount this model, make sure there is enough space
between the wall and the TV for the cables.
• To use this TV mounted on a wall, first remove the
adhesive tape at the 4 locations on the rear of the TV, and
then use the screws supplied with the wall mount bracket
to secure the bracket to the rear of the TV.
About setting the TV angle
QUICK REFERENCE
Hex key
Screws
2
3
1
LC-32D64U
•
The center of the display:
11/16
inch (17.3 mm) under
the “A” position.
LC-37D64U
•
The center of the display:
1
3/4
inch (44.1 mm) under
the “A” position.
• Refer to the operation
manual of AN-37P30 for
details.
31Insert the stand into the openings on the bottom
of the TV.
2Insert and tighten the 4 screws into the 4 holes
on the rear of the TV.
LC-3237D64UE.indb5LC-3237D64UE.indb5 2007/12/139:18:472007/12/139:18:47

6
Using the Remote Control Unit
Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the
remote control unit and the remote control sensor may prevent proper operation.
30º 30º
30º
30º
17´ (5 m)
Remote Control sensor
■ Cautions regarding the remote control unit
• Do not expose the remote control unit to shock. In addition,
do not expose the remote control unit to liquids, and do not
place in an area with high humidity.
• Do not install or place the remote control unit under direct
sunlight. The heat may cause deformation of the remote
control unit.
• The remote control unit may not work properly if the remote
control sensor on the TV is under direct sunlight or strong
lighting. In such cases, change the angle of the lighting
or the TV, or operate the remote control unit closer to the
remote control sensor.
IMPORTANT:
The POWER indicator on the AQUOS television should light GREEN indicating you have power to the AQUOS television.
If the POWER indicator on the AQUOS television still does not light up, press TV POWER on the remote control to turn the
power on.
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE AQUOS TELEVISION FROM THE OUTLET AND REPEAT THE
INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.
QUICK REFERENCE
Attach your antenna to the back of the AQUOS
television. (See page 7.)
Place the Ferrite core in the space indicated in the
below figure and bundle the cords properly with
the cable clamp and the cable tie.
How to turn on the AQUOS television for the first time.
A) Press POWER on the AQUOS television.
Connect the AC plug for the AQUOS television into
the AC outlet.
B) The POWER indicator on the front of the
AQUOS television lights GREEN.
• Speakers cannot be detached from the TV.
• TV angle cannot be adjusted.
• Place the TV close to the AC outlet, and keep the power
plug within reach.
•TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
1
2
3
4
QUICK INSTALLATION TIPS
AC outlet
Ferrite core
POWER
POWER
indicator
LC-3237D64UE01.indd6LC-3237D64UE01.indd6 2007/12/2810:48:062007/12/2810:48:06

7
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector,
plug it into the antenna terminal at the rear of the TV set.
1.A 75-ohm system is generally a round cable with F-type connector
that can easily be attached to a terminal without tools (Commercially
available).
F-type connector
300-ohm twin-lead cable (flat)
F-type connector
75-ohm coaxial cable (round)
75-ohm coaxial cable
NOTICE
2.A 300-ohm system is a flat “twin-lead” cable that can be attached
to a 75-ohm terminal through a 300/75-ohm adapter (Commercially
available).
When connecting the RF cable to the TV set, do not tighten F-type
connector with tools.
If tools are used, it may cause damage to your TV set. (The breaking
of internal circuit, etc.)
300-ohm twin-lead cable
75-ohm coaxial cable (round)
75-ohm coaxial cable
IN OUT
300-ohm
twin-lead cable
VHF
A
NTENNA
UHF
ANTENNA
Combiner
(commercially available)
300/75-ohm adapter
(commercially available)
300-ohm twin-lead cable (flat)
75-ohm coaxial cable (round)
Cable TV lead-In
Coaxial cable
(commercially available)
Coaxial cable
(commercially available)
Home Antenna
terminal (75-ohm)
Home Antenna
terminal (75-ohm)
or
or
F-type connector should be finger-tightened only.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage
in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a
rash. If you find any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
1 Open the battery cover.
• Place the batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
2Insert two “AAA” size batteries
(supplied with the product).
3Close the battery cover.
Installing Batteries in the Remote Control Unit
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
Preparation
Connecting Antenna Cable
1Cable without a CATV
converter
3Combination VHF/
UHF antenna
4Separate VHF/UHF
antenna
To TV antenna
terminal
2VHF/UHF antenna
• Connect the antenna cable to the TV using one of the methods in the illustration as shown (1, 2, 3or 4).
LC-3237D64UE01.indd7LC-3237D64UE01.indd7 2007/12/1911:36:142007/12/1911:36:14

8
IMPORTANT INFORMATION ..................................1
Trademarks..............................................................2
DEAR SHARP CUSTOMER .....................................3
IMPORTANT SAFETY INSTRUCTIONS..................3
QUICK REFERENCE................................................5
Attaching/Detaching the Stand ............................5
Setting the TV on the Wall....................................5
QUICK INSTALLATION TIPS................................6
Using the Remote Control Unit ............................6
Preparation ..............................................................7
Antennas .............................................................7
Installing Batteries in the Remote Control Unit......7
Contents...................................................................8
Supplied Accessories..............................................8
Part Names ..............................................................9
TV (Front).............................................................9
TV (Top/Side/Rear) ..............................................9
Remote Control Unit ..........................................10
Connecting to External Equipment......................11
Watching TV...........................................................12
Turning On/Off the Power ..................................12
Initial Setup........................................................12
Direct Button Operation........................................13
On-Screen Display Menu......................................17
Menu Items .......................................................17
On-Screen Display Menu Operation...................18
Menu Operation Buttons....................................18
Picture Menu .....................................................19
OPC Setting..................................................19
Advanced Picture Setting ..............................19
Audio Menu .......................................................20
Surround.......................................................20
Bass Enhancer..............................................20
Power Control Menu..........................................21
No Signal Off.................................................21
No Operation Off...........................................21
Setup Menu.......................................................21
EZ Setup.......................................................21
CH Setup......................................................22
Antenna Setup-DIGITAL................................22
Input Skip......................................................22
Input Label ....................................................22
Input Signal (for Analog PC Input Mode Only) ...22
Auto Sync.
(for Analog PC Input Mode Only) .................22
Contents
Fine Sync. ....................................................22
Position.........................................................23
Language......................................................23
Reset ............................................................23
Parental CTRL (Parental Control Setting) .......23
Option Menu......................................................26
Audio Only ....................................................26
Digital Noise Reduction .................................26
Input Select...................................................26
HDMI Setup ..................................................26
Output Select................................................26
Color System ................................................26
Caption Setup...............................................27
Digital Caption Info.
(Digital Caption Information) ........................27
Program Title Display ....................................27
Favorite CH (Favorite Channel Setting) ..........27
Game Play Time............................................27
Operation Lock Out.......................................27
Digital Setup Menu ............................................28
Audio Setup ..................................................28
Identification..................................................28
Software Update ...........................................28
Other Viewing Options ..........................................30
Presetting Remote Control Function ..................30
Operating the Connected Equipment.................30
Using AQUOS LINK ...............................................32
Controlling HDMI Equipment Using AQUOS LINK ...32
AQUOS LINK Menu ...........................................34
Appendix ................................................................35
Troubleshooting.................................................35
Troubleshooting-Digital Broadcasting ................35
RS-232C Port Specifications .............................36
Specifications ....................................................37
Optional Accessory............................................37
PC Compatibility Chart ......................................38
Information on the Software License for This
Product ...........................................................38
Calling for Service .................................................39
LIMITED WARRANTY ............................................39
Dimensional Drawings
• The dimensional drawings for the LCD TV set are shown
on the inside back cover.
Supplied Accessories
• Always use the AC cord supplied with the TV.
Make sure the following accessories are provided with the product.
Remote control unit
(g1)
Page 6
“AAA” size battery
(g2)
Page 7
AC cord
(g1)
Page 6
Stand unit
(g1)
Page 5
Cable clamp (g1)
Cable tie (g1)
Page 6
Operation manual
(g1)
LC-3237D64UE.indb8LC-3237D64UE.indb8 2007/12/139:18:492007/12/139:18:49

9
Part Names
TV (Front)
OPC indicator (See page 19.)
POWER indicator (See page 12.)
OPC sensor (See page 19.)
Remote control sensor
SLEEP indicator (See page 13.)
TV (Top/Side/Rear)
RS-232C terminal
DIGITAL AUDIO OUTPUT
terminal
INPUT 4 terminal (HDMI)
INPUT 5 terminals (HDMI)
INPUT 6 terminals (PC-IN)
Antenna/Cable in
INPUT 1 terminals
AC INPUT terminal
INPUT 2 terminals
AUDIO OUTPUT terminals
SERVICE
terminal
INPUT 3
terminals
POWER button
INPUT button
MENU button
Channel buttons
(CHV/U)
Volume buttons
(VOLl/k)
LC-3237D64UE01.indd9LC-3237D64UE01.indd9 2007/12/1911:36:232007/12/1911:36:23

10
3
2
116
5
6
4
8
19
17
18
20
21
7
22
10
9
23
11
13
12
25
26
27
14
15 29
24
28
Part Names
1TV POWER: Switch the TV power on or enters standby. (See
page 12.)
2DISPLAY: Display the channel information.
3SOURCE POWER: Turns the power of the external equipment
on and off.
4External equipment operational buttons: Operate the external
equipment.
50–9: Set the channel. (See page 13.)
6•(DOT): (See pages 13 and 30.)
7INPUT: Select a TV input source. (TV, INPUT 1, INPUT 2, INPUT 3,
INPUT 4, INPUT 5, INPUT 6) (See page 13.)
8VOLk/l:Set the volume. (See page 13.)
9SURROUND: Select Surround settings. (See page 13.)
10 FREEZE: Set the still image. Press again to return to normal
screen. (See page 13.)
11 EXIT: Turn off the menu screen.
12 OPTION: Display the AQUOS LINK MENU screen. This button
will function only when AQUOS LINK is used. (See pages 32 to 34
for details.)
13 REC STOP: Stops one touch recording. This button will function
only when AQUOS LINK is used. (See pages 32 to 34 for details.)
14 SLEEP: Set the sleep timer. (See page 13.)
15 AUDIO: Selects the MTS/SAP or the audio mode during multi-
channel audio broadcasts. (See page 14.)
16 FUNCTION: Switches the remote control for TV, CBL/SAT, VCR,
DVD and AUDIO operation. Indicator lights up for the current
mode. (See pages 30 to 31 for details.)
* To enter the code registration mode, you need to press
FUNCTION and DISPLAY at the same time.
17 LIGHT D:When this button is pressed, some buttons (for
example, VOLk/land CHr/s) on the remote control unit will
light. The lighting will turn off if no operations are performed within
about 5 seconds. This button is used for performing operations in
low-light situations.
18 VIEW MODE: Select the screen size. (See page 16.)
19 ENT: Jumps to a channel after selecting with the 0–9buttons.
20 FLASHBACK: Return to the previous channel or external input
mode. (See page 13.)
21 CHr/s:Select the channel. (See page 13.)
22 MUTE: Mute the sound. (See page 13.)
23 MENU: Display the menu screen.
24 a/b/c/d,ENTER: Select a desired item on the screen.
25 RETURN: Return to the previous menu screen.
26 FAVORITE CH
A,B,C,D: Select 4 preset favorite channels in 4 different
categories. (See page 27.)
While watching, you can toggle the selected channels by pressing
A, B, C and D.
27 FAVORITE: Set the favorite channels. (See page 27.)
28 CC: Display captions from a closed-caption source. (See page
15.)
29 AV MODE: Select an audio or video setting.
(When the input source is TV, INPUT 1, 2 or 3: STANDARD,
MOVIE, GAME, USER, DYNAMIC (Fixed), DYNAMIC. When the
input source is INPUT 4, 5 or 6: STANDARD, MOVIE, GAME, PC,
xvYCC (INPUT 4/5 only), USER, DYNAMIC (Fixed), DYNAMIC) (See
page 14.)
Remote Control Unit
• When using the remote control unit, point it at the TV.
LC-3237D64UE.indb10LC-3237D64UE.indb10 2007/12/139:18:502007/12/139:18:50

11
Connecting to External Equipment
You can connect many types of external equipment to your TV like a Blu-ray disc player, HD-DVD player, DVD
player, VCR, Digital TV tuner, HDMI equipment, game console or camcorder. To view external source images,
select the input source from INPUT on the remote control unit or on the TV. (See page 13.)
CAUTION
• To protect equipment, always turn off the TV before connecting any external equipment.
• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.
*1 • To enjoy the AQUOS 1080p display capability, connect your external equipment using a component cable and set the
equipment to 1080p output.
*2 • The S-VIDEO terminal takes priority over the video terminals. (INPUT 2 only)
*3 • When using an HDMI-DVI conversion cable, input the audio signal to AUDIO terminal of INPUT 5.
• To enjoy the AQUOS 1080p display capability, connect your Blu-ray disc player, HD-DVD player or other external
equipment using an HDMI-certified cable and set the equipment to 1080p output.
*4 • Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI
connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz and 16 bits.
• The HDMI terminals only support digital signal.
• Refer to page 38 for a list of PC signals compatible with the TV.
Terminal on the TV Cable Terminal on external
equipment
INPUT 1, 2 or 3
INPUT 1 or 3
INPUT 4 or 5
DIGITAL AUDIO
OUTPUT
INPUT 2
Connecting a Blu-ray disc player, HD-DVD player, DVD player, Digital TV STB (Air or Cable), VCR,
game console or camcorder
AV cable (commercially available)
Component video cable (commercially available)
S-VIDEO cable (commercially available)
HDMI-certified cable (commercially available)
Optical fiber cable (commercially available)
Audio cable (commercially available)
Audio cable (commercially available)
*1
*2
*3
*4
Terminal on the TV Cable Terminal on PC
INPUT 6
Connecting a PC
RGB cable (commercially available)
Ø 3.5 mm stereo minijack cable (commercially available)
INPUT 4 or 5 HDMI-certified cable (commercially available)
LC-3237D64UE01.indd11LC-3237D64UE01.indd11 2008/01/0818:05:212008/01/0818:05:21

12
Language
TV Location
Air/Cable
CH Search
English
Español
Français
TV Location
Language
Air/Cable
CH Search
Home Store
TV Location
Air/Cable
Language
CH Search
Analog & Digital Search Start
Cancel
Analog Search Start
POWER
Turning On/Off the Power
Air/Cable
TV Location
Language
CH Search
Start Cancel
4When "Air" is selected in Antenna setting:
Press
c/dto select "Start", and then press ENTER.
When "Cable" is selected in Antenna setting:
Press
a/bto select "Analog & Digital Search Start" to
search both analog and digital broadcasts, or to select
“Analog Search Start” to search only analog broadcasts,
and then press ENTER.
• The Channel search will start automatically.
• To exit the Channel search screen, select "Cancel", and
then press ENTER.
TV POWER
(On/Standby)
Press POWER on the TV, or TV POWER on the remote control unit to
turn the power on.
• POWER indicator (Green): The TV is on. (After a few seconds, a window
appears with sound.)
• The initial setup starts when the TV powers on for the first time. If the TV has
been turned on before, the EZ Setup will not be invoked. See page 21 for
performing EZ Setup from the Setup menu.
Press POWER on the TV, or TV POWER on the remote control unit
again to turn the power off.
• The TV enters standby and the image on the screen disappears.
• The POWER indicator on the TV turns off.
• If you are not going to use this TV for a long period of time, be sure to remove
the AC cord from the AC outlet.
• Weak electric power is still consumed even when the TV is turned off.
Watching TV
Initial Setup
When you turn on the TV for the first time, it will
automatically memorize the broadcasting channels
available in the region where you live. Perform the
following steps before you press TV POWER on the
remote control unit.
1. Insert the batteries into the remote control unit. (See page 7.)
2. Connect the antenna cable to the TV. (See page 7.)
3. Plug in the AC cord to the AC outlet. (See page 6.)
Language (Language setting)
Select from among 3 languages: English, French and Spanish.
1Press a/bto select the desired language listed on the
screen, and then press ENTER.
CH Search (Channel search)
Channel auto search makes the TV look for all channels
viewable in the set area.
TV Location
Select "Home" or "Store" for the location where you plan to
install the TV.
Example
• If no channel is found, confirm the type of connection made
with your TV and try EZ Setup again.
(See page 21.)
2Press c/d to select "Home" or "Store".
Press ENTER to enter the setting.
Air/Cable
TV Location
Language
CH Search
Air Cable
Air/Cable (Antenna setting)
Make sure what kind of connection is made with your TV
when selecting "Air" or "Cable".
Example
3Press c/d to select "Air" or "Cable".
Press ENTER to enter the setting.
• If you select "Home", AV MODE is set to "STANDARD".
• If you select "Store", AV MODE is set to "DYNAMIC (Fixed)".
In case no remote control signal is received within 30 minutes,
AV MODE will change to "DYNAMIC (Fixed)" automatically.
• For changing the TV Location after the setting, see "EZ
Setup" on page 21.
LC-3237D64UE.indb12LC-3237D64UE.indb12 2007/12/139:18:512007/12/139:18:51

13
Direct Button Operation
Sleep Timer
Allows you to set a time when the TV automatically
switches to standby.
Press SLEEP.
The remaining time displays when the sleep timer has been set.
Each time you press SLEEP, the remaining time switches
as shown below.
Off 30 60 90 120
When set, the time automatically starts counting down.
If you want to adjust the sleep timer, you can press SLEEP
twice then change the time setting.
Five minutes before the time expires, the remaining time
displays every minute.
Select "Off" by pressing SLEEP to cancel the sleep timer.
The TV will enter standby when the remaining time reaches zero.
When the sleep timer is set, its indicator on the TV lights red.
FLASHBACK
Press FLASHBACK to switch to the previously tuned
channel.
Press FLASHBACK again to switch back to the currently
tuned channel.
FLASHBACK will not work if no channel has been changed
after the TV is turned on.
SURROUND
The surround function produces Surround effect from
the speakers. Each time you press SURROUND, the
mode changes between On and Off.
On: Makes it possible to enjoy natural, realistic surround
sound.
Off: Outputs the normal sound.
You can have the same settings by choosing "Surround" on
the menu items. (See page 20.)
FREEZE
Allows you to capture and freeze a moving image that
you are watching.
Press FREEZE.
A moving image is captured.
Press FREEZE again to cancel the function.
When this function is not available, "No displaying still
image available." will display.
The still image automatically goes out after 30 minutes.
If you are using the freeze function and a broadcast
activates the V-CHIP BLOCK, the freeze function will be
canceled and a V-CHIP BLOCK message will appear.
INPUT
To view external source images, select the input source
using INPUT on the remote control unit or on the TV.
1Press INPUT.
A list of selectable sources appears.
2Press INPUT again or press a/bto select the
input source.
An image from the selected source automatically displays.
Each time INPUT is pressed, the input source toggles.
If the corresponding input is not plugged in, you cannot change
the input. Be sure to connect the equipment beforehand.
See page 11 for external equipment connection.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Changing Channels
You can change channels by pressing CHr/sor 0-9,
• (DOT).
Examples:
To select a 1 or 2-digit channel number (e. g., Channel 5):
Press 5ENT.
To select a 3-digit channel number (e. g., Channel 115):
Press 115ENT.
To select a 4-digit channel number (e. g., Channel 22.1):
Press 22• (DOT) 1ENT.
When selecting a 1-digit channel number, it is not
necessary to press 0before the number.
When you enter 0-9only, channel selection will be made if
there is no operation within a few seconds.
If you push "0" by itself, nothing will happen.
Complete the above steps within a few seconds.
When you enter 0-9and • (DOT), channel selection will be
made if there is no operation within a few seconds.
Changing Volume
You can change the volume by pressing VOLk/lon
the TV or on the remote control unit.
To increase the volume, press VOLk.
To decrease the volume, press VOLl.
20
Audio status
Output device Output Select
Fixed Variable
Speaker Variable sound Mute
When "Output Select" is set to "Variable", the indicator on
the screen changes as shown below.
60
See page 26 for details on the Output Select function.
MUTE
Mutes the current sound output.
Press MUTE.
" " will be displayed on the screen for 30 minutes, and
the sound is silenced.
Within 30 minutes of pressing MUTE, mute can be
canceled by using one of the methods below.
- Mute will be canceled if you press VOLk/lor MUTE.
Mute will be canceled after 30 minutes have passed.
However, the TV will not suddenly output a loud sound as
the volume level is set to 0 automatically.
•
•
•
•
•
•
•
•
•
•
•
•
LC-3237D64UE02.indd13LC-3237D64UE02.indd13 2007/12/1911:37:002007/12/1911:37:00

14
AV MODE
AV MODE gives you 8 viewing options to choose from
to best match the surrounding environment of the TV,
which can vary due to factors like room brightness,
type of program watched or the type of image input
from external equipment.
Press AV MODE. Current AV MODE displays.
Press AV MODE again before the mode displayed on the
screen disappears. The mode changes as shown below:
Example:
When the input source is TV, INPUT 1, 2 or 3 terminals
STANDARD MOVIE GAME USER [TV]
DYNAMIC DYNAMIC (Fixed)
Example:
When the input source is INPUT 4, 5 or 6 terminals
STANDARD MOVIE GAME PC xvYCC*
DYNAMIC DYNAMIC (Fixed) USER[ ]
"xvYCC" can only be selected when an xvYCC signal is
input using INPUT 4 and 5.
STANDARD: For a highly defined image in a normal
lighting.
[Enhanced Picture Contrast: on]
MOVIE: For a movie.
[Enhanced Picture Contrast: off]
GAME: Lowers image brightness for easier viewing.
[Enhanced Picture Contrast: off]
PC: For PC.
[Enhanced Picture Contrast: off]
xvYCC: Supports the xvYCC international standard
for wide color space. The xvYCC signal allows you
to experience colors that conventional color signals
cannot reproduce.
[Enhanced Picture Contrast: off]
USER: Allows the user to customize settings as desired.
You can set the mode for each input source.
[Enhanced Picture Contrast: off]
DYNAMIC (Fixed): Changes the image and sound
settings to the factory preset values. No adjustments
are allowed.
[Enhanced Picture Contrast: on]
DYNAMIC: For a clear-cut image emphasizing high
contrast, useful for sports viewing.
[Enhanced Picture Contrast: on]
You can select a different AV MODE item for each input
mode. (For example, select STANDARD for TV input and
DYNAMIC for INPUT 1.)
When you play games, "GAME" is recommended for AV
MODE.
"Enhanced Picture Contrast" technology detects the source
video characteristics and smoothly adjusts the screen
brightness accordingly to realize deeper black levels.
•
*
•
•
•
Direct Button Operation
AUDIO
■ MTS/SAP stereo mode
The TV has a feature that allows reception of sound
other than the main audio for the program. This feature
is called Multi-channel Television Sound (MTS). The TV
with MTS can receive mono sound, stereo sound
and Secondary Audio Programs (SAP). The SAP
feature allows a TV station to broadcast other
information, which could be audio in another language
or something completely different like weather
information.
You can enjoy Hi-Fi stereo sound or SAP broadcasts
where available.
Stereo broadcasts: View programs like live sporting
events, shows and concerts in dynamic stereo sound.
SAP broadcasts: Receive TV broadcasts in either MAIN or
SAP sound.
MAIN sound: The normal program soundtrack (either in
mono or stereo).
SAP sound: Listen to a second language, supplementary
commentary or other information. (SAP is mono sound.)
If stereo sound is difficult to hear.
Obtain a clearer sound by manually switching to fixed
mono-sound mode.
You can change MTS as shown below to match the television
broadcast signal.
Press AUDIO to toggle between audio modes.
Examples: when receiving MTS and SAP
STEREO mode: STEREO MONO
STEREO + SAP mode: ST(SAP) SAP(ST) MONO
MAIN + SAP mode: MAIN SAP
MONO mode: MONO
■ Digital broadcasting audio mode
The types of audio transmitted in a digital broadcast include
SURROUND as well as MONO and STEREO. In addition, it
is possible for multiple audio tracks to accompany a single
video track.
Press AUDIO to toggle between audio modes.
Example: when receiving Digital broadcasting
STEREO (Audio1) STEREO (Audio2)
SURROUND (Audio3)
MTS only operates while in TV mode.
•
•
•
•
LC-3237D64UE.indb14LC-3237D64UE.indb14 2007/12/139:18:542007/12/139:18:54

15
2
Air ANALOG
Audio : MONO
CC : 1/2 CC1
Ratings : NONE
1/3 ENG 2/3 CC1 3/3 Text1 Off
Your TV is equipped with an internal Closed Caption
decoder. It allows you to view conversations, narration
and sound effects as subtitles on your TV. Closed
Captions are available on some TV programs and on
some VHS home video tapes at the discretion of the
program provider.
Digital Closed Caption service is a new caption service
available only on digital TV programs (also at the
discretion of the service provider). It is a more flexible
system than the original Closed Caption system,
because it allows for a variety of caption sizes and font
styles. When the Digital Closed Caption service is in
use, it will be indicated by the appearance of a 3-letter
abbreviation that also indicates the language of the
Digital Closed Captions: ENG (English), SPA (Spanish),
FRA (French) or other language codes.
Not all programs and VHS videotapes offer closed
captions. Please look for the “N” symbol to ensure
that captions will be shown.
In the Closed Caption system, there can be more than
one caption service provided. Each is identified by its
own number. The “CC1” and “CC2” services display
subtitles of TV programs superimposed over the
program's picture.
In the Closed Caption system, the “Text1” or “Text2”
services display text that is unrelated to the program
being viewed (e.g., weather or news). These services
are also superimposed over the program currently
being viewed.
Depending on the number of caption services in the
signal being received, you will see information such as
1/2 or 1/4 displayed.
1/2 means “the first of two services”.
Example:
If a program has three services (Digital CC(ENG), CC1
and Text1), the closed caption display will toggle in this
sequence:
•
The CC button keeps a record of the last service
selected in its memory.
If the last closed caption mode (e.g. 1/3ENG) you
selected is not available for the next program, or on
another channel, the closed caption service that is
available is automatically selected, and this service
appears in parentheses, e.g. “1/3(CC1)”.
Closed Caption services that appear in parentheses will
not be stored in the CC button's memory as your last
selected service. Only services that you have selected
with the CC button are stored.
Examples:
In a case where there are two closed caption
services provided (for instance, Digital CC(ENG)
and CC1), and Digital CC(ENG) is displayed
as your current selection, if Digital CC(ENG) is
not broadcast for the next program, the other
closed caption service, CC1, will be displayed in
parentheses.
A closed caption service appears in parentheses
because the service you selected is not available
and a different service is displayed on your screen.
“1/1(CC1)” is displayed instead of “1/2/ENG”.
•
Press CC.
This will present the Closed Caption information
display.
•
Press CC while the Closed Caption information is
still on the screen.
Press repeatedly until you select the desired closed
caption service.
•
Closed Caption
information
See page 27 for detailed closed caption settings.
When the program contains no closed caption, “--” displays
in the closed caption information.
If the language code, e.g. “ENG”, is not found on Digital TV
programs, “--” will be shown.
Four kinds of closed caption service (CC1, CC2, Text1,
Text2) are potentially available, but a broadcast may contain
none or only some of these services at the discretion of the
program provider.
•
•
•
•
Direct Button Operation
1
2
Closed Captions and Digital Closed Captions
LC-3237D64UE.indb15LC-3237D64UE.indb15 2007/12/139:18:552007/12/139:18:55

16
Direct Button Operation
VIEW MODE
You can select the screen size.
1Press VIEW MODE.
The View Mode menu displays.
The menu lists the View Mode options selectable for the type of video signal currently being received.
2Press VIEW MODE or a/bwhile the View Mode menu is displayed to select a desired item on the menu.
You can sequentially select a View Mode that has its own aspect ratio.
■ For 4:3 programs
Example: Screen size images
Side Bar S.Stretch (Smart stretch) Zoom Stretch
Suitable for viewing
conventional 4:3 programs in
their normal format.
Suitable for stretching 4:3
programs to fill the screen.
Suitable for viewing wide-
screen 2.35:1 anamorphic
DVDs in full screen.
This mode is useful for 1.78:1
DVDs. When viewing 1.85:1
DVDs, stretch mode will still show
very thin black bands at the top
and bottom of the screen.
■ For HD programs
Stretch: Suitable for viewing wide-screen 1.78:1 aspect ratio program, stretch mode will still show very thin black bands at
the top and bottom of the screen.
Dot by Dot (1080i/p only): Detects the resolution of the signal and displays an image with the same number of pixels on
the screen.
Full Screen (720p only): You can select "Full Screen" only when receiving a 720p signal.
S.Stretch (Smart stretch): Suitable for stretching 4:3 programs to fill the screen.
Zoom: Suitable for viewing wide-screen 2.35:1 aspect-ratio programs in full screen.
When using Dot by Dot, it is possible to see noise or bars around different outer portions of the screen. Please change view
mode to correct this.
■ For PC input mode
Connect the PC before making adjustments. (See page 11.)
Selectable screen size may vary with input signal type.
Example: Screen size images
Input signal Normal Zoom Stretch Dot by Dot
4:3 Keeps the original
aspect ratio in a full
screen display.
For viewing
widescreen
programs. The top
and bottom of the
image is cropped.
An image fully fills the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
Input signal Stretch Dot by Dot
16:9 An image fully fills the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
•
•
•
•
•
•
LC-3237D64UE02.indd16LC-3237D64UE02.indd16 2007/12/1911:37:132007/12/1911:37:13

17
Menu Items
Some menu items may not be displayed depending on the selected input source.•
Picture Menu
OPC..................................................................................... Page 19
Backlight.............................................................................. Page 19
Contrast .............................................................................. Page 19
Brightness .......................................................................... Page 19
Color ................................................................................... Page 19
Tint ...................................................................................... Page 19
Sharpness .......................................................................... Page 19
Advanced
C.M.S.-Hue ............................................................. Page 19
C.M.S.-Saturation ................................................... Page 19
Color Temp. ............................................................ Page 19
Active Contrast ........................................................ Page 19
I/P Setting ................................................................ Page 20
Film Mode ............................................................... Page 20
3D-Y/C .................................................................... Page 20
Monochrome ........................................................... Page 20
Range of OPC ......................................................... Page 20
Reset .................................................................................. Page 19
Audio Menu
Treble ................................................................................. Page 20
Bass..................................................................................... Page 20
Balance................................................................................ Page 20
Surround.............................................................................. Page 20
Bass Enhancer .................................................................... Page 20
Reset .................................................................................. Page 20
Power Control Menu
No Signal Off ....................................................................... Page 21
No Operation Off ................................................................. Page 21
Setup Menu
EZ Setup.............................................................................. Page 21
CH Setup............................................................................. Page 22
Antenna Setup-DIGITAL...................................................... Page 22
Input Skip ............................................................................ Page 22
Input Label .......................................................................... Page 22
Parental CTRL .............................................................. Pages 23-25
Position................................................................................ Page 23
Language............................................................................. Page 23
Reset ................................................................................... Page 23
Option Menu
AQUOS LINK Setup ..................................................... Pages 32-34
Audio Only........................................................................... Page 26
Digital Noise Reduction....................................................... Page 26
Input Select ......................................................................... Page 26
Output Select ...................................................................... Page 26
Color System....................................................................... Page 26
Caption Setup ..................................................................... Page 27
Digital Caption Info. ............................................................ Page 27
Program Title Display ......................................................... Page 27
Favorite CH ......................................................................... Page 27
Game Play Time .................................................................. Page 27
Operation Lock Out............................................................. Page 27
Digital Setup Menu
Audio Setup......................................................................... Page 28
Identification........................................................................ Page 28
Software Update .......................................................... Pages 28-29
On-Screen Display Menu
For TV/INPUT 1/2/3 Mode For HDMI/PC-IN Mode
Picture Menu
OPC..................................................................................... Page 19
Backlight.............................................................................. Page 19
Contrast .............................................................................. Page 19
Brightness .......................................................................... Page 19
Color ................................................................................... Page 19
Tint ...................................................................................... Page 19
Sharpness .......................................................................... Page 19
Advanced
C.M.S.-Hue ............................................................. Page 19
C.M.S.-Saturation ................................................... Page 19
Color Temp. ............................................................ Page 19
Active Contrast ........................................................ Page 19
I/P Setting ................................................................ Page 20
Film Mode ............................................................... Page 20
Monochrome ........................................................... Page 20
Range of OPC ......................................................... Page 20
Reset .................................................................................. Page 19
Audio Menu
Treble ................................................................................. Page 20
Bass..................................................................................... Page 20
Balance................................................................................ Page 20
Surround.............................................................................. Page 20
Bass Enhancer .................................................................... Page 20
Reset .................................................................................. Page 20
Power Control Menu
No Signal Off ....................................................................... Page 21
No Operation Off ................................................................. Page 21
Setup Menu
Input Skip ............................................................................ Page 22
Input Signal ......................................................................... Page 22
Auto Sync. .......................................................................... Page 22
Input Label .......................................................................... Page 22
Fine Sync. ........................................................................... Page 22
Position................................................................................ Page 23
Language............................................................................. Page 23
Reset ................................................................................... Page 23
Option Menu
AQUOS LINK Setup ..................................................... Pages 32-34
Audio Only........................................................................... Page 26
Digital Noise Reduction....................................................... Page 26
HDMI Setup......................................................................... Page 26
Output Select ...................................................................... Page 26
Game Play Time .................................................................. Page 27
Operation Lock Out............................................................. Page 27
Digital Setup Menu
Software Update .......................................................... Pages 28-29
LC-3237D64UE.indb17LC-3237D64UE.indb17 2007/12/139:18:572007/12/139:18:57

18
ENTER
: Select : Enter MENU : Exit
RETURN
: Back
1 Item displayed in yellow
• This indicates the item currently selected.
• Press ENTER to go to the adjustment screen for this
item.
2Item in brackets
• This indicates the current setting for the item.
3Item displayed in white
• This indicates that the item can be selected.
4Item displayed in gray
• This indicates that the item cannot be selected.
There are various reasons why the items cannot be
selected, but the main reasons are as follows:
—Nothing is connected to the selected input terminal.
—The function is not compatible with the current input
signal.
Menu options differ in the selected input modes, but the
operating procedures are the same.
The screens in the operation manual are for explanation
purposes (some are enlarged, others cropped) and may
vary slightly from the actual screens.
•
•
Contrast
OPC
Brightness
Color
Tint
Sharpness
Advanced
Reset
[b30]
[ 0]
[ 0]
[ 0]
[ b2]
0
a30
a30
a30
a10
b40
b30
b30
b30
b10
Backlight [b12] a16 b16
Off On On : Display
1 Press c/d to select the desired item.
2Press a/b to select the desired item.
3Press c/d to adjust the item.
On-Screen Display Menu
On-Screen Display Menu Operation
MENU: Press to open or close the menu screen.
a/b/c/d:Press to select a desired item on the screen or
adjust a selected item.
ENTER: Press to go to the next step or complete the
setting.
RETURN: Press to return to the previous step.
Option
Audio Only
AQUOS LINK Setup
Digital Noise Reduction
Input Select
Color System
[Off]
[VIDEO]
Output select [Fixed]
[Auto]
[No]Program Title Display
[Off]Game Play Time
[Off]Operation Lock Out
Digital Caption Info.
Caption Setup
Example
The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting screen.
VOLl/k:Cursor c/don the remote control.
CHs/r:Cursor b/aon the remote control.
INPUT: ENTER on the remote control.
MENU: MENU on the remote control.
Example
Menu Operation Buttons
Using the control panel of the main unit
You can also operate the menu with the control panel
of the main unit.
Button operations on the control panel correspond to
the ones on the remote control as shown below.
Using the remote control
Use the following buttons on the remote control to
operate the menu.
LC-3237D64UE03.indd18LC-3237D64UE03.indd18 2007/12/1911:37:402007/12/1911:37:40
