LC-42GD7T 1st
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
No. S37D6LC42GD7T
LC-42GD7TMODEL
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL (NOTE: THE PARTS
HERE SHOWN ARE SUPPLIED AS
AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKD909VJ05 (R/C, LED Unit)
[4] DUNTKD932VJ25 (MAIN Unit)
[5] DUNTKD939VJ02 (TERMINAL Unit)
[6] RUNTKA263WJPZ (DIGITAL Unit)
[7] CABINET AND MECHANICAL
PARTS
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS (NOT
REPLACEMENT ITEM)
[10] SERVICE JIGS (USE FOR
SERVICING)

LC-42GD7T 1st
2
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
NDUNTKD684VJ08 AT N J FRONT Unit
NDUNTKD744UJ02 AH N J SPEAKER-L Unit
NDUNTKD745UJ02 AG N J SPEAKER-R Unit
NDUNTKD909VJ05 AR N J R/C, LED Unit
NDUNTKD910VJ02 AL N J KEY Unit
NDUNTKD932VJ25 N J MAIN Unit
NDUNTKD939VJ02 N J TERMINAL Unit
!
NRDENCA191WJQZ BT N J POWER Unit
NRUNTKA263WJPZ CN J DIGITAL Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
NR1LK420D3LZ10 FG N J 42" WIDE LCD Panel Module Unit
[3] DUNTKD909VJ05 (R/C, LED Unit)
C112 VCKYCY1HB223KY AA J Capacitor, 0.022 50V Ceramic
C114 VCKYCY1HB223KY AA J Capacitor, 0.022 50V Ceramic
[4] DUNTKD932VJ25 (MAIN Unit)
C2013 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
D1404 RH-EX1245CEZZY AB J Zener Diode, 5.1V
D1405 RH-EX1245CEZZY AB J Zener Diode, 5.1V
D1406 RH-EX1245CEZZY AB J Zener Diode, 5.1V
D1407 RH-EX1245CEZZY AB J Zener Diode, 5.1V
FB3301 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3302 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3303 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3304 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3305 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3306 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3307 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
FB3308 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
L3301 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3302 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3303 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3304 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3305 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3306 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L3307 VRS-TV1JD000JY AA J Resistor, 0 1/10W Metal Oxide
L9605 VPCEM101M7R0NY AB J Peaking 100µH
X2500 RCRSB0250GEZZ AG J Crystal, 18.432kHz
NQCNW-F687WJQZ N J Connecting Cord (KM)
[5] DUNTKD939VJ02 (TERMINAL Unit)
FB2715 RBLN-A206WJZZY AA J Ferrite Core
FB2716 RBLN-A206WJZZY AA J Ferrite Core
[6] RUNTKA263WJPZ (DIGITAL Unit)
U23 9JJ61TU1216001 J TU1216/FHEPX6M

LC-42GD7T 1st
3
[7] CABINET AND MECHANICAL PARTS
3
6
1-1
1-2 1-3
1-5
1-5
30
3-1
8-1
8-1
8-2
8-2
8
8
3-2
3-3
1-4
1-4
1-4
1-4
1-5
1-5
2
5
7
5-1
5-2
10-1
10-2
10-2
10-2
10-3 10-3
10
10-3
1-7
1-6 1-7
2-1
2-2
2-3
2-4
2-4
2-4
2-4 2-5
2-6
2-7
2-7
2-8
2-9
2-9
2-10
1-6
MAIN Unit
TERMINAL Unit
DIGITAL Unit
POWER Unit
SPEAKER-L Unit
SPEAKER-R Unit
KEY Unit
R/C, LED Unit
5-3
5-6
5-4
FRONT Unit
4
4-2
4-1
4-3
4-5 4-5
4-4
78
4-3
4-3
4-3
5-5
7-1 7-2
7-3
9
11
31
31
11-1
11-2
11-3
12
71
73
13
82
14
15
16
67
17
19
18
20
20
21
22
22
24
25
26
26
26
27
28
29
29
32
32
32
33
33 33
34
35
36
37
39
40
41
42
43
44
45
46
47
48
50
51
81
81-1
81-2
81-3
52
53
54
56 57
58
59
60
61
62
63
64
64
64
64
65
66
23
69 70
70
72
72
75
77
77
79-1
79-2
79-3
79-5
79-4
79-3
80
79
76
76
76
76
76
76
76
1
74
74
74
74
74
74
74
74
74
74
68
74
74
74
74
74
74 74
74
55
38
49

LC-42GD7T 1st
4
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[7] CABINET AND MECHANICAL PARTS
1CCABAB787WJ01 N J Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - - Badge, SHARP
1-3 HDECQA606WJSA AD J LED Decoration
1-4 HDECQA657WJKA AF J Corner Decoration, x4
1-5 XEBSN30P08000 AA J Screw for Front Cover, x4
1-6 PSPAHA936WJZZ AC J Himeron, x2
1-7 PSPAHA937WJZZ AC J Himeron, x2
2CCABBB079WJ01 N J Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 GCOVAA838WJKC AD J Hole Cover, x4
2-3 GCOVAB162WJKA AD J Bus Connector Cover
2-4 GCOVAB789WJKA AF J Speaker Area Cover LR, x4
2-5 HINDPC211WJSA N J MODEL Label
2-6 LHLDWA055WJKZ AC J Wire Holder for AC Code
2-7 LHLDZ0132CEZZ AD J Speaker Bush, x2
2-8 PSPAHA971WJZZ AC J Himeron
2-9 PSPAHB068WJZZ AB J Himeron, x2
2-10 PSPAHB454WJZZ N J Himeron
3CCOVAB843WJ01 AP N J Top Cover Ass'y
3-1 Not Available - N - Top Cover
3-2 JBTN-A583WJKA AF N J Operation Button
3-3 JBTN-A587WJKA AD N J Power Button
4CDAI-A293WJ01 BH J Stand Base Ass'y
4-1 Not Available - N - Stand Base
4-2 LANGKA769WJZZ N J Base Angle
4-3 PSPAZB210WJZZ AC J LEG Cushion-A, x4
4-4 PSPAZB166WJZZ AB N J LEG Cushion-B, x4
4-5 XEBS940P10000 AB J Screw (for Base), x10
5CHNG-A155WJN1 BG N J Stand Hinge Ass'y
5-1 Not Available - N - Stand Hinge
5-2 GDAI-A322WJSA N J Support
5-3 LANGKA893WJFN N J Swivel Base
5-4 LX-NZA036WJFN J Nut
5-5 PSPAZB307WJZZ N J Spacer, x2
5-6 XJBS850P30000 AB J Screw, x4
6R1LK420D3LZ10 FG N J 42" WIDE LCD Panel Module Unit
7CANGKA835WJN1 AU J Stand Angle Ass'y
7-1 Not Available - N - Stand Angle
7-2 LHLDW1226CEZZ AC J Wire Holder, x3
7-3 LHLDWA043WJKZ AB J Wire Holder
8CANGKA852WJN1 AN J Fix Angle Bottom Ass'y, x2
8-1 Not Available - N - Fix Angle Bottom L/R
8-2 PSPAHA991WJZZ AA J Himeron
9CANGTA390WJ01 AQ J SUB PWB Angle Ass'y
9-1 Not Available - N - SUB PWB Angle
9-2 PRDARA400WJFW N J Radiator A
9-3 PRDARA401WJFW N J Radiator B
9-4 PRDARA405WJFW N J Radiator F
10 CCHSMA335WJ02 BC N J Chassis Tray Ass'y
10-1 Not Available - N - Chassis Tray
10-2 LHLDWA120WJKZ AB J Wire Holder, x6
10-3 LHLDWA123WJKZ AB J Wire Holder, x3
11 CCOVAB838WJ01 AT J AV Terminal Cover Ass'y
11-1 Not Available - N - AV Terminal Cover
11-2 GCOVAB897WJSA N J Protect Cover
11-3 GCOVAB899WJZZ N J Under Cover
12 GCOVAB571WJKD AR J Hinge Cover
13 GCOVAB635WJKA AG J B-CAS Cover
14 GCOVAB807WJKA AD J SD Card Cover
15 GCOVAB851WJSA AK J Tuner Terminal Cover
16 GCOVAB864WJK1 AM J Cover L
17 GCOVAB865WJK1 AM J Cover R
18 GCOVAB866WJKA AP J Stand Area Cover
19 GCOVAB884WJK1 AW J Terminal Cover
20 LANGKA833WJN1 AU J Center Angle, x2
21 LANGKA850WJN1 AL J Fix Angle
22 LANGKA851WJFW AK J Fix Angle Top L/R, x2
23 LANGTA396WJM1 N J Cover
24 LHLDW1025TAZZ AB J Wire Holder
25 LHLDW1123GEZZ AB J Wire Holder
26 LHLDWA004WJZZ AD J Wire Holder, x4
27 LHLDWA045WJZZ AD J Wire Holder
28 LHLDWA132WJKZ AC J Wire Holder
29 LHLDWA134WJKZ AB J Wire Holder, x2
30 LHLDWA150WJKZ AC J Wire Holder
31 NSFTZ0134CEFW AD J Shaft, x6
32 PMLT-A389WJZZ AK J Gasket, x5
33 PMLT-A400WJZZ J Gasket, x3
34 PMLT-A404WJZZ J Gasket
35 PMLT-A405WJZZ J Gasket
36 PMLT-A406WJZZ N J Gasket
37 PRDARA393WJFW AH J Radiator D
38 PSLDMA224WJZZ AG J Gasket
39 PSLDMA584WJZZ AE J Gasket

LC-42GD7T 1st
5
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
40 PSLDMB077WJZZ J Electric wave absorption Sheet
41 PSLDMB085WJZZ J Electric wave absorption Sheet
42 PSLDMB090WJZZ J Conductive Cloth
43 PSLDMB105WJZZ J Conductive Cloth
44 PSLDMB114WJZZ J Conductive Cloth
45 PSLDMB154WJQZ N J Gasket, x2
46 PSPAHA632WJZZ AB J Himeron, x2
47 PSPAHA853WJZZ AB J Himeron
48 PSPAZB263WJKZ AH N J Spacer
49 PSPAZB313WJKZ AC J Spacer
50 PSPAZB354WJKZ J Spacer, x2
51 QCNCWA001WJZZ AH J Connector (F-RCA)
52 QCNW-E258WJQZ AG J Connecting Cord (PD)
53 QCNW-E902WJQZ AH J Connecting Cord (PH)
54 QCNW-E942WJQZ AX N J Connecting Cord (LV)
55 QCNW-E943WJQZ AM N J Connecting Cord (LP)
56 QCNW-F224WJQZ N J Connecting Cord (MS)
57 QCNW-F423WJPZ AH N J Connecting Cord (F-RCA RF CABLE)
58 QCNW-F605WJQZ J Connecting Cord (LA)
59 QCNW-F607WJQZ N J Connecting Cord (LB)
60 QCNW-F608WJQZ N J Connecting Cord (VD)
61 QCNW-F609WJQZ N J Connecting Cord (SP)
62 QCNW-F687WJQZ N J Connecting Cord (KM)
63 QCNW-F888WJQZ N J Connecting Cord (RA)
64 RCORFA012WJZZ AG J Core, x4
65 RCORFA023WJZZ AK J Core
66 RCORFA061WJZZ J Core, x2
67 RSP-ZA198WJN2 BS J Under Speaker
68 TLABK0023TAZZ AA J Bar Code Label
69 XBBS740P06000 AA J Screw, x4
70 XBBS830P08000 AA J Screw for AC/Cover, x5
71 XBBS940P08000 AB J Screw for Hinge
72 XBBS940P25000 AB J Screw, x4
73 XBBSN50P12JS0 AF J Screw for Stand, x4
74 XBPS730P06WS0 AA J Screw, x62
75 XBPS830P06000 AA J Screw for I-LINK_HDMI_SCR, x2
76 XEBS930P10000 AA J Screw for RCA_DTANSI_TANSI/JAK, x12
77 XEBS940P20000 AB J Screw for Cabinet B, x12
78 XJSS850P30000 AB J Screw for Stand Ass'y, x4
79 CPNLSA088WJ01 J Speaker Panel Ass'y
79-1 Not Available - - Speaker Panel
79-2 HPNC-A165WJSA BS J Punching Metal
79-3 PCUSUA001WJZZ AD J Speaker Port Cushion, x2
79-4 PSPAHB042WJZZ AD N J SP-Spacer
79-5 PSPAZB235WJSA AG J Jersey Net
80 CSLDMB126WJ01 J Shield Ass'y
80-1 Not Available - N - Shield
80-2 PSPAHB058WJZZ J Spacer
81 CCOVAB853WJ01 AM N J FRONT Unit Cover Ass'y
81-1 Not Available - N - FRONT Unit Cover
81-2 LANGKA779WJFW AG J FRONT Unit Fix Angle
81-3 LHLDWA072WJKZ AC J Wire Holder
82 TLABNB967WJZZ N J No. Label
[7] CABINET AND MECHANICAL PARTS

LC-42GD7T 1st
6
[8] SUPPLIED ACCESSORIES
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[8] SUPPLIED ACCESSORIES
X1 LHLDW0110CEZZ AE J Cable Clamp
X2 LHLDW1164CEZZ AA J Clamp, x2
X3 LHLDWA131WJKZ AE J Cable Clamp for CAB
X4 LHLDZA759WJZZ AD J Restraining Band
!
X5 QACCZA084WJPZ N J AC Cord
X6 RRMCGA508WJSA AW N J Remote Control Unit
X7 TINS-C833WJZZ N J Operation Manual
X8 Not Available - - "AAA" Size Battery
X9 XBBS940P14000 AB J Screw for Band
X10 XTBS940P16000 AB J Screw for clamps, x2
X11 TLABHA072WJZZ AN J English-Chinese contrast table
Operation Manual "AAA" Size Battery
Cable Clamp Cable Clamp
X3
Remote Control Unit
X6 X5
AC Cord
X1
X7 X8 X11
X4 X9 X2 X10
Safety Restraints English-Chinese
contrast table
Restraining
Band
Screw
for Band
Screws for
clamps

LC-42GD7T 1st
7
[9] PACKING PARTS (NOT REPLACEMENT ITEM)
S2
S3
S13
S1
S8
S11
S5
S5
S14
S15
S9
S9
S10
S8 S4
S6
S12
S7

LC-42GD7T 1st
8
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[9] PACKING PARTS (NOT REPLACEMENT ITEM)
S1 SPAKCC974WJN1 - - Packing Case (Bottom)
S2 SPAKCD281WJZZ - N - Packing Case
S3 SPAKFA958WJZZ - - Enclosure Case
S4 SPAKFB248WJZZ - N - Top Pad
S5 SPAKL0023CEZZ - - Joint, x4
S6 SPAKPA487WJZZ - - Wrapping Paper (Stand)
S7 SPAKPA751WJZZ - - Wrapping Paper (Monitor)
S8 SPAKXB501WJZZ - N - Packing Add. (Top)
S9 SPAKXB502WJZZ - N - Packing Add. (Bottom)
S10 SPAKXB503WJZZ - N - Packing Add. (Stand)
S11 SPAKXB504WJZZ - N - Packing Add. (Top Center)
S12 SPAKXB512WJZZ - - Packing Add. (Bottom Center)
S13 SSAKA0170CEZZ - - Polyethylene Bag
S14 TLABK0001TAZZ - - No. Label, x2
S15 TLABKA013WJZZ - - Bar Code Label
[10] SERVICE JIGS (USE FOR SERVICING)
NQCNW-C222WJQZ AW J Connecting Cord (FFC, 100cm)
NQCNW-F135WJQZ AS J Connecting Cord (LA, 100cm)
NQCNW-F136WJQZ AP J Connecting Cord (LB, 100cm)
NQCNW-F137WJQZ AX J Connecting Cord (LP, 100cm)
NQCNW-E134WJQZ BG J Connecting Cord (LV, 40cm)
NQCNW-F139WJQZ AX J Connecting Cord (RA, 100cm)
