Sharp LC-60C46U User manual

DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS...............................i
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRE-
CAUTION ...........................................................ii
PRECAUTIONS A PRENDRE LORS DE
LA REPARATION .............................................. iii
PRECAUTIONS FOR USING LEAD-FREE
SOLDER ...........................................................iv
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS ......................................... 1-1
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL .................................. 2-1
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS ................................................ 3-1
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS ................... 4-1
Parts Guide
SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
TopPage
CONTENTS
No. S17B3LC60C46U
LC-60C46U
MODEL
LCD COLOR TELEVISION
In the interests of user-safety (Required by safety regulations in some countries) the set should
be restored to its original condition and only parts identical to those specified should be used.
OUTLINE
This model is based on the LC-46D62U and is changed some parts. This Service Manual covers the modifications
alone. For the other points, refer to the LC-46/52D62U Service Manual.
LC-60C46U
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
SUPPLEMENT ATTACHED

LC-60C46U
i
LC-60C46U Service Manual
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS
Ref. No. Description LC-46D62U LC-60C46U Note
PWB ASSEMBLIES
R/C, LED Unit DUNTKD909FM02 ←—
KEY Unit DUNTKD910FM02 ←—
MAIN Unit DUNTKD934FM01 DUNTKD934FM07 No Internal parts change
TERMINAL Unit DUNTKD935FM01 DUNTKD935FM07 No Internal parts change
POWER SUPPLY Unit RDENCA184WJQZ ←—
CABINET AND MECHANICAL PARTS
Please refer to a Parts list.
PACKING PARTS, ACCESSORIES AND SERVICE JIGS
Please refer to a Parts list.

LC-60C46U
ii
LC-60C46U Service Manual
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER (Fire &
Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 120 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a nonpolarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5 mA rms AC.) or
more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by " " and shaded areas in the Replacement Parts List
and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION: FOR CO N T INU E D PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAME TYPE FUSE.
F701 (250V, 8A), F702 (250V, 1A)
F4702 (250V, 4A)
F4701/F4703 (250V, 3A, 127
O
C)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-60C46U
iii
PRECAUTIONS A PRENDRE LORS DE LA REPARATION
De nombreuses pièces, électriques et mécaniques, dans les télévi-
seur ACL présentent des caractéristiques spéciales relatives à la sé-
curité, qui ne sont souvent pas évidentes à vue. Le degré de protec-
tion ne peut pas être nécessairement augmentée en utilisant des
pièces de remplacement étalonnées pour haute tension, puissance,
etc.
Les pièces de remplacement qui présentent ces caractéristiques sont
identifiées dans ce manuel; les pièces électriques qui présentent ces
particularités sont identifiées par la marque " " et hachurées dans la
liste des pièces de remplacement et les diagrammes schématiques.
Pour assurer la protection, ces pièces doivent être identiques à celles
utilisées dans le circuit d'origine. L'utilisation de pièces qui n'ont pas
les mêmes caractéristiques que les pièces recommandées par l'usine,
indiquées dans ce manuel, peut provoquer des électrocutions, incen-
dies, radiations X ou autres accidents.
AVERTISSEMENT
1.
2.
3.
4.
5.
•
•
•
•
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux
conseils suivants.
N'entreprendre aucune modification de tout circuit. C'est danger-
eux.
Débrancher le récepteur avant toute réparation.
Inspecter tous les faisceaux de câbles pour s'assurer que les fils
ne soient pas pincés ou qu'un outil ne soit pas placé entre le châs-
sis et les autres pièces métalliques du récepteur.
Inspecter tous les dispositifs de protection comme les boutons de
commande non-métalliques, les isolants, le dos du coffret, les cou-
vercles ou blindages de réglage et de compartiment, les réseaux
de résistancecapacité, les isolateurs mécaniques, etc.
S'assurer qu'il n'y ait pas de danger d'électrocution en vérifiant la
fuite de courant, de la facon suivante:
Brancher le cordon d'alimentation directem-ent à une prise de cou-
rant de 120V. (Ne pas utiliser de transformateur d'isolation pour
cet essai).
A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ
10 watts en parallèle avec un condensateur de 0.15µF en série
avec toutes les pièces métalliques exposées du coffret et une terre
connue comme une conduite électrique ou une prise de terre
branchée à la terre.
Utiliser un voltmètre CA d'une sensibilité d'au moins 5000Ω/V pour
mesurer la chute de tension en travers de la résistance.
Toucher avec la sonde d'essai les pièces métalliques exposées qui
présentent une voie de retour au châssis (antenne, coffret métalli-
que, tête des vis, arbres de commande et des boutons, écusson,
etc.) et mesurer la chute de tension CA en-travers de la résistance.
Toutes les vérifications doivent être refaites après avoir inversé la
fiche du cordon d'alimentation. (Si nécessaire, une prise
d'adpatation non polarisée peut être utilisée dans le but de termin-
er ces vérifications.)
La tension de pointe mesurèe ne doit pas dépasser 0.75V (corre-
spondante au courant CA de pointe de 0.5mA).
Dans le cas contraire, il y a une possibilité de choc électrique qui
doit être supprimée avant de rendre le récepteur au client.
PRECAUTION:POURLAPROTECTIONCON-
TINUE CONTRE LES RISQUES D'INCENDIE,
REMPLACER LE FUSIBLE
VERIFICATIONS CONTRE L'INCEN-DIE ET LE
CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer les vérifica-
tions suivantes.
DVM
ECHELLE CA
1.5k ohm
10W
0.15
µ F
SONDE D'ESSAI
AUX PIECES
METALLIQUES
EXPOSEES
BRANCHER A UNE
TERRE CONNUE
AVIS POUR LA SECURITE
F701 (250V, 8A), F702 (250V, 1A)
F4702 (250V, 4A)
F4701/F4703 (250V, 3A, 127 OC)

LC-60C46U
iv
PRECAUTIONS FOR USING LEAD-FREE SOLDER
Employing lead-free solder
• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Indicates lead-free solder of tin, silver and copper. Indicates lead-free solder of tin, silver and copper.
PARTS CODE PRICE
RANK
PART
DELIVERY DESCRIPTION
ZHNDAi123250E BL J φ0.3mm 250g (1roll)
ZHNDAi126500E BK J φ0.6mm 500g (1roll)
ZHNDAi12801KE BM J φ1.0mm 1kg (1roll)

LC-60C46U
1 – 1
LC-60C46U Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Digital cable *
1
(64/256 QAM)
1-135ch (non-scrambled channel only)
*
1
Emergency alert messages via Cable are unreceivable.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
LCD panel
Number of dots
TV
Function
TV-standard (CCIR)
Receiving
Channel
VHF/UHF
CATV
Digital Terrestrial
Broadcast (8VSB)
Audio multiplex
Audio out
Terminals Rear INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
ANTENNA
DIGITAL AUDIO OUTPUT
OUTPUT
OSD language
Power Requirement
Power Consumption
Weight
Dimension
(W H D)
Operating temperature
6,220,800 dots (1920 1080 3 dots)
American TV Standard ATSC/NTSC System
VHF 2-13ch, UHF 14-69ch
1-135ch (non-scrambled channel only)
2-69ch
BTSC System
15W 2
AV in, COMPONENT in
AV in, COMPONENT in
S-VIDEO in, AV in
Audio in, HDMI in with HDCP
HDMI in with HDCP
75 Unbalance, F Type
1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
Optical Digital audio output 1 (PCM/Dolby Digital)
Audio out
English/French/Spanish
AC 120 V, 60 Hz (FOR NORTH AMERICA)
AC 110-240 V, 50/60 Hz (FOR OTHERS)
32°F to 104°F (0°C to 40°C)
Item Model: LC-60C46U
46" Advanced Super View & BLACK TFT
LCD
with stand
w/o stand
w/o stand
with stand
270 W (0.7 W Standby with AC 120V)
70.6 lbs./32.0 kg
78.3 lbs./35.5 kg
44
27
/
64
33
5
/
64
13
7
/
16
inch
44
27
/
64
30
13
/
64
4
59
/
64
inch
++ +

LC-60C46U
2 – 1
LC-60C46U Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part names
POWER button
TV (Front)
Channel buttons
(CH /)
Volume
buttons
(VOL /)
INPUT button
OPC indicator*
POWER indicator**
OPC sensor*
Remote control sensor
SLEEP indicator**
TV (Rear)
HDMI terminal (INPUT 4)
INPUT 3 terminals
AUDIO OUTPUT terminals
HDMI terminal (INPUT 5)
DIGITAL AUDIO OUTPUT terminal
Antenna/Cable in
INPUT 1 terminals
AC INPUT terminal
AUDIO terminal (INPUT 4)
INPUT 2 terminals
+
-

LC-60C46U
2 – 2
3
2
114
5
6
4
8
17
15
16
18
19
7
20
10
9
21
11 23
24
25
12
13 27
22
26
Part names
1 TV POWER: Switch the TV power on or enters standby
mode.
2 DISPLAY: Display the channel information.
3 SOURCE POWER: Turns the power of the external
equipment on and off.
4 External equipment operational buttons: Operate the
external equipment.
50
_9: Set the channel.
6 (DOT):
7INPUT:Select a TV input source. (TV, INPUT 1, INPUT 2,
INPUT 3, INPUT 4, INPUT 5)
8VOL/:Set the volume.
9 SURROUND: Select Surround settings.
10 FREEZE: Set the still image. Press again to return to
normal screen.
11 EXIT: Turn off the menu screen.
12 SLEEP: Set the sleep timer.
13 AUDIO: Selects the MTS/SAP or the audio mode during
multi-channel audio broadcasts.
14 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights up
for the current mode.
* To enter the code registration mode, you need to press
FUNCTION and DISPLAY at the same time.
15 LIGHT : When pressed all buttons on the remote
control unit will light. The lighting will turn off if no
operations are performed within about 5 seconds. This
button is used for performing operations in low-light
situations.
16 VIEW MODE: Select the screen size.
17 ENT: Jumps to a channel after selecting with the 0_9
buttons.
18 FLASHBACK:Return to the previous channel or external
input mode.
19 CH / : Select the channel.
20 MUTE: Mute the sound.
21 MENU: Display the menu screen.
22 ////ENTER: Select a desired item on the
screen.
23 RETURN: Return to the previous menu screen.
24 FAVORITE CH
A, B, C, D: Select 4 preset favorite channels in 4 different
categories.
While watching, you can toggle the selected channels by
pressing A, B, C and D.
25 FAVORITE: Register favorite channel.
26 CC: Display captions from a closed-caption source.
27 AV MODE: Select an audio or video setting. (When the
input source is TV, INPUT 1, 2 or 3: STANDARD, MOVIE,
GAME, USER, DYNAMIC (Fixed), DYNAMIC. When
the input source is INPUT 4 or 5: STANDARD, MOVIE,
GAME, PC, USER, DYNAMIC (Fixed), DYNAMIC)
Remote control unit
NOTE
When using the remote control unit, point it at the TV.

LC-60C46U
3 – 1
LC-60C46U Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS
77/8(200)
361/64 (100)
77/8(200)
2613/16 (681)
459/64 (125)45/8(117)
137/16 (341)
4427/64 (1128)
407/32 (1021.4)
27/8(73) 3013/64 (767)
335/64 (840)
195/8(498)
2221/32 (575.4)
Unit: inch/(mm)

LC-60C46U
4 – 1
LC-60C46U Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Detach the SD Card Cover .
2. Remove the 4 lock screws and detach the Stand.
3. Remove the 5 lock screws .
4. Remove the 13 lock screws and detach the Rear Cabinet.
4
3
2
3
1
SD Card Cover
2
Rear Cabinet
Stand

LC-60C46U
4 – 2
5. Remove the 12 lock screws and detach the Bridge Angle and Chassis Fix Angle.
6. Remove the 8 lock screws 8 lock point and detach the Stand St Cover-R.
7. Remove the 4 hook and detach the Stand Assist Holder.
8. Remove the 8 lock screws and detach the Stand Fix Angle.
9. Remove the 7 lock screws and detach the Main Shield.
Bridge Angle Bridge Angle
555
5
55
8
7
6
7
6
Chassis
Fix Angle
Main Shield
Stand Fix Angle
Stand Assist Holder
Stand St Cover-R
Hook Hook

LC-60C46U
4 – 3
10.Disconnect all the connectors from all the PWBs.
11.Remove the 2 lock screws and detach the KEY PWB.
10
KEY PWB
Top Cover
[KM]
[KM]
[LB]
[PH]
[PD]
[MA][FC] [SA]
[SP]
[PD]
[PH]
[LA]
[LA]
[LC]
[RA]
[LA]
[LB]
[LC]
[RA]

LC-60C46U
4 – 4
12.Remove the 1 rivet and detach the earth plate.
13.Remove the 9 lock screws and detach the Tray Chassis.
14.Disconnect the 3 connectors (MA, FC, SA), and COAXIAL Wire.
15.Remove the 2 lock screws , 3 lock screws and detach the Terminal Angle.
16.Remove the 7 lock screws and detach the POWER SUPPLY PWB.
17.Remove the 4 lock screws and detach the TERMINAL PWB.
18.Remove the 4 lock screws , and the spacer, rivet and detach the Heat Sink and MAIN PWB.
19.Disconnect the 2 connectors , and detach the Speaker-L and R.
20.Remove the 2 lock screws and detach the R/C, LED PWB.
21.Remove the 4 lock screws and detach the plates.
18
17
12
13
11
15
12
22
14
16
21
19 20
17
Spacer
MAIN PWB
Earth
Plate
POWER SUPPLY PWB
Tray Chassis
Plate
TERMINAL PWB
R/C, LED PWB
R/C, LED
Cover
Speaker-R Speaker-L
Terminal Angle
COAXIAL Wire
MA FC SA
Heat Sink

LC-60C46U
4 – 5
22.Remove the 4 lock screws and detach the LCD Panel Module.
23.Remove the 8 lock screws and detach the Chassis Fix Angle T/B.
24 23 23 24
24 23 23 24
Chassis Fix
Angle T/B
LCD Panel Module

PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-60C46U
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
No. S17B3LC60C46U
LC-60C46U
MODEL
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] CABINET AND MECHANICAL
PARTS
[3] SUPPLIED ACCESSORIES
[4] PACKING PARTS (NOT
REPLACEMENT ITEM)
[5] SERVICE JIG (USE FOR
SERVICING)

LC-60C46U
2
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
NDUNTKD909FM02 AQ X R/C, LED Unit
NDUNTKD910FM02 AH X KEY Unit
NDUNTKD934FM07 CQ N R MAIN Unit
NDUNTKD935FM07 BG N X TERMINAL Unit
NRDENCA184WJQZ BU X POWER SUPPLY Unit (Unit exchange)

LC-60C46U
3
[2] CABINET AND MECHANICAL PARTS
33-1
3-2
38
7
53
20
48
58
48
20
58
25
48
20
48
20
58
63
63
62
58
5
39
47
46
41
53
6
1-8
1-7
1-8
1-7
1-7
1-7
1-5
1-7
1-8
1-10
1-5
1
1-9
1-1 1-7
1-8
1-5
1-2
1-6
1-4
1-11
1-3
1-5
54
59 16 56
59
2-3
2
2-1
2-2
19-3
19-3
19-3
19-3
48
19
19-2
19-1
48
19-1
19-2
17
12
13
48
48 17
12
13
48
48
68
69
69
15 52
11
14
51
34
18
35 28
50
70
27
50
30
60
33
32
33
8
37
50
31
64
43
42
36
50
10
50
22
22-2
29
22-3
22-3
44
50
9
26
40
22-1
61
45
65
50
1-9
1-9
1-9
1-12
22-4
66 66
67

LC-60C46U
4
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[2] CABINET AND MECHANICAL PARTS
1CCABAB523WJ01 BZ X Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - N - Front Cover
1-3 Not Available - N - LED Cover
1-4 HBDGBA061WJSA AG X Badge, "SHARP"
1-5 Not Available - N - Corner Cover, x4
1-6 HPNC-A159WJSA BB N X Punching Net
1-7 PSPAHA899WJZZ N X Spacer, x6
1-8 XEBS930P08000 AA X Screw for Conner Cover, x4
1-9 Not Available - N - Spacer, x6
1-10 Not Available - N - Jersey Net
1-11 TLABZA635WJZZ AD X E-Star Label
1-12 TLABZB393WJSA AF X POP Label
2CCABBA898WJ01 BR X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 LHLDWA012WJKZ AC X Wire Holder
2-3 LHLDWA131WJKZ AF X Wire Holder
3CCOVAB823WJ01 AD X Top Cover Ass'y
3-1 Not Available - - Top Cover
3-2 Not Available - N - Control Button
5R1LK460D3LZ10Y GC X 46"LCD Panel Module Unit
6DUNTKD909FM02 AQ X R/C, LED Unit
7DUNTKD910FM02 AH X KEY Unit
8DUNTKD934FM07 CQ N R MAIN Unit
9DUNTKD935FM07 BG N X TERMINAL Unit
10 RDENCA184WJQZ BU X POWER SUPPLY Unit
11 GCOVAA678WJKA AG X SD Cover
12 LHLDZA797WJKA AD X Stand Assist Holder, x2
13 GCOVAB822WJKA AD X Stand Bottom Cover, x2
14 HINDPB715WJSA AF X Terminal Label
15 HINDPB893WJSA AH X Jack Indicator Plate.
16 HINDPC129WJSA AH N X Model Label
17 LANGKA819WJN1 AP X Stand Fix Angle, x2
18 LANGKA820WJFW AK X Terminal Angle
19 CANGTA373WJ01 BB X Bridge Angle Ass'y
19-1 Not Available - - Bridge Angle, x2
19-2 LANGTA377WJFW N X Fix Angle Center, x2
19-3 XBBS740P08000 AB X Screw for Angle Fix, x8
20 LANGTA375WJFW AK X Chassis Fix Angle Top/Bottom, x4
22 CCHSMA341WJ01 BA X Tray Chassis Ass'y
22-1 Not Available - - Tray Chassis
22-2 LHLDWA102WJKZ AB X Wire Holder, x2
22-3 LHLDWA120WJKZ AB X Wire Holder, x4
22-4 LHLDWA123WJKZ AB X Wire Holder, x2
25 LHLDWA123WJKZ AB X Wire Holder
26 LHLDWA150WJKZ AC X Wire Holder for IF PWB
27 PCLICA004WJKZ AC R Rivet
28 LX-NZ3047GEZZ AB X Hexiagonal Nut
29 PCLICA008WJZZ AB X Rivet
30 PRDARA390WJFW AM X Heat Sink for Main Unit
31 PSLDMA910WJN1 AV X Main Shield
32 PSPAZB192WJKZ AG X Cool Sheet
33 PSPAZA917WJKZ AH R Cool Sheet, x2
34 QCNCWA496WJZZ AK X F-RCA Connector
35 QCNW-E249WJPZ AH R Connecting Cord (Tuner)
36 QCNW-E258WJQZ AG R Connecting Cord (PD)
37 QCNW-E894WJQZ AP R Connecting Cord (LP)
38 QCNW-E895WJQZ AG R Connecting Cord (KM)
39 QCNW-F199WJQZ AH N X Connecting Cord (SP)
40 QCNW-E898WJQZ AH N X Connecting Cord (LB)
41 QCNW-E901WJQZ AM N X Connecting Cord (RA)
42 QCNW-E902WJQZ AH R Connecting Cord (PH)
43 QCNW-E903WJQZ AN N X Connecting Cord (LA)
44 QEARPA228WJFW AD X Earth Plate
45 QPWBHD838WJQZ AY X Printed Wiring Board (LV)
46 RSP-ZA192WJZZ AX X Speaker (Right)
47 RSP-ZA193WJZZ AX X Speaker (Left)
48 XBBS740P08000 AB X Screw for Angle Fix, x28
50 XBPS730P06WS0 AB X Screw for Angle, x35
51 XBPS830P06000 AA X Screw for HDMI, x2
52 XEBS930P08000 AA X Screw for Jack, x3
53 XEBS930P10000 AA X Screw, x4
54 XEBS940P20000 AA X Screw for Rear Cabinet, x13
56 Not Available - - Label
58 XEBSN40P16000 AB R Screw for Panel Angle, x4
59 XBPS930P08JS0 AB R Screw for Rear Cabinet, x5
60 XWHS742-10120 AB X Washer
61 LHLDW1141CEZZ AE R Wire Holder for LV
62 LHLDWA141WJZZ AD X Wire Holder For Speaker Wire
63 LHLDW1173CEZZ AD R Wire Holder For Speaker Wire, x2
64 RCORFA020WJZZ AN R Core
65 QEARBA025WJZZ AD X Ground Part, x4
66 LX-BZA162WJF7 N X Screw for Stand Ass'y, x6
67 Not Available - N - Screw to Set, x4
68 Not Available - N - Stand Base Ass'y

LC-60C46U
5
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[3] SUPPLIED ACCESSORIES
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
69 CDAI-A310WJ01 AZ X Support Ass'y, x2
70 QCNW-F382WJQZ AE N R Connecting Cord (for P2003)
[3] SUPPLIED ACCESSORIES
X1 LHLDWA083WJ00 AD X Cable Band
X2 LHLDWA149WJSB AF X Cable Clamp, x2
!
X3 QACCDA039WJPZ AR X AC Cord
X4 RRMCGA416WJSB AZ X Remote Control Unit
X5 TCADEA208WJZZ AD X Enquete Card
X6 TINS-D031WJZZ AN N X Operation Manual
X7 TCAUHA263WJZZ AD N X Setup Guide
X8 CDAI-A309WJ04 BN X Stand Unit
X9 Not Available - - "AAA" Size Battery
X10 TGAN-A768WJZZ AD X Guarantee Card
[2] CABINET AND MECHANICAL PARTS
Operation Manual "AAA" Size Battery
Remote Control Unit
X4
Cable Clamp
X2
Cable Band
X1
AC Cord
X3
X6 X9 X8
Stand Unit

LC-60C46U
6
[4] PACKING PARTS (NOT REPLACEMENT ITEM)
S3
S9
S9
S5
S9
S1
S6
S9
S9
S2
S14
S10
S4
S7
S8
S13
S11
S12
