Sharp LC-40Q3020U User manual

ES-M1826C1-1

Help SHARP improve the environment by reducing paper waste.
For detailed instructions and feature descriptions, access the full User Manual online.
Quick Start Guide
LC-40Q3000U
LC-40Q3020U
LC-40Q3030U
LC-40Q3040U
LC-40Q3050U
LC-40Q3060U
LC-40Q3070U
LC-40Q3080U
LC-40Q3090U

1
Table of Contents
Register Your TV! .....................................................................................................................2
Packaged Contents ..................................................................................................................3
Buttons and Ports on the TV ....................................................................................................4
Attach the TV Stand or Wall Mount Bracket .............................................................................5
Connect Devices to your TV.....................................................................................................7
Buttons on your TV Remote .....................................................................................................9
Begin Using your Remote.......................................................................................................10
Power on the TV..................................................................................................................... 11
Complete the Setup Wizard....................................................................................................12
Product Speci ications............................................................................................................13
Quick Problem-Solving Tips ...................................................................................................14
Certification and Compliance..................................................................................................16

2

3
PACKAGED CONTENTS
Your package in which you purchased your new TV contains the following items:
● TV ● 2basestands
● 4screws(M4×20) ● RemoteControl
● 2AAAbatteries ● QuickStartGuide(thisdocument)
● ImportantSafetyInformationandWarrantyCard
IMPORTANT:
To prevent accidentally discarding items that came with your TV, be sure to check ALL of the foam in the carton box.
·Please check foam for accessories before discarding.
·Veuillez vérifier la mousse pour qu'il n'y ait pas d'accessoires avant de la jeter.
·Antes de desechar la espuma, asegúrese de retirar todos los accesorios.
Required tools and devices
● Phillipsscrewdriver(notincluded)tosecuretheTVstand
● HDMIandothertypesofcables(notincluded)toconnectexternaldevicestotheTV
● Wallmountbracket(notincluded)ifyouprefertomounttheTVtothewall

4
BUTTONS AND PORTS ON THE TV
Back View of the TV
TV Side View
TV Bottom View

5
STEP 1. Attach the TV Stand or Wall Mount Bracket
Attach the TV Stand
Follow the illustrations and instructions below to complete the installation steps:
1. CarefullyplaceyourTVfacedownonasoft,atsurfacetopreventdamagetotheTVorscratchingtothescreen.
2. Remove the 2 stands from the accessory bag and then insert the stands into the bottom slots of the TV.
3. Use the 4 screws in the accessory bag to secure the BASE STAND to the TV.
Screws
M4×20
BASE STAND
Screws
M4×20
BASE STAND

6
Attach the Wall Mount Bracket (not included)
Before you begin the third-party manufacturer instructions, be
sure to do the following things:
1.Place the TV face down on a clean, safe and cushioned surface.
2.Remove the TV stand if you already attached it.
3.Place the spacers (not included) in the corresponding bracket
holes.
CAUTION:
• Whenyouattachthemount,besuretousethespacers
(providedbythethird-partymanufacturer)betweentheTV
and the bracket.
Screw
(not provided)
Bracket
(not provided)
Spacer
(not provided)
• TopreventinternaldamagetotheTVandensureitis
mountedsecurely,besuretousexingscrews(not
provided)thatare 8-10mminlengthwhenmeasuredfrom
the attaching surface of the mounting hook.
FollowinstructionsprovidedwiththeWallmountbracket.
● Tocompletetheinstallation,pleasecontactthewall-mount
manufacturer or the retailer from which you purchased the TV.
● Theselectedscrewsare8-10mminlengthwhenmeasured
from the attaching surface of the rear cover.
NOTE:Thediameterandlengthofthescrewsdiffer
dependingonthewallmountbracketmodel.
Rear cover of the TV Spacer
Screw
Wall mount bracket
8 - 10 mm
Wall mount hole pattern
VESA (mm) 200 × 200
Wall mount screw size (mm) M6

7
STEP2.ConnectdevicestoyourTV
Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can affect
the quality of the picture image and color.
TV label Port Cable External Equipment Brief Description
ANT
CABLE IN
Antenna
VHF/UHF Antenna
ANT OUT
Connect an outdoor VHF/UHF antenna.
HDMI
DVD Player/Recorder
Set-top Box
Satellite Receiver
Satellite
antenna
cable
VCR
Video
Camera
COMPO-
NENT IN
YGreen
Connect a component video cable and left-right
audio cables from an external AV device.
PBBlue
PRRed
LWhite
RRed
AV IN
VIDEO Yellow
Connect a composite video cable and left-right
audio cables from an external AV device.
LWhite
RRed
Connect a High Definition Multimedia Interface
(HDMI) cable from an external device.
