SERVICE MANUAL
LC-60C52U
No.SY6Y8LC60C52U
LCD COLOR TELEVISION
LC-60C52U
MODEL
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with spec-
ified ones for maintaining the safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS ............................. i
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRE-
CAUTION ......................................................... ii
PRECAUTIONS A PRENDRE LORS DE
LA REPARATION .............................................iii
PRECAUTION FOR USING LEAD-FREE
SOLDER.......................................................... iv
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS.........................................1-1
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL..................................2-1
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS .................................................3-1
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS ....................4-1
Parts Guide
TopPage
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified be used.
This model is based on theLC-46D62U/LC-52D62U and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-46D62U/LC-
52D62U (No. S86V8LC52D62U) Service Manual.
OUTLINE

LC-60C52U
i
LCD TV
LC-60C52U
Service ManualLC-60C52UMarketE
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS
Refer to the PARTS GUIDE for CABINET PARTS, SUPPLIED ACCESORIES, PACKING PARTS and SERVICE JIGS.
Ref. No. Description LC-46D62U/LC-52D62U LC-60C52U Note
PRINTED WIRING BOARD ASSEMBLIES
R/C, LED Unit DUNTKD909FM02 DUNTKD909FM02 No Changes
KEY Unit DUNTKD910FM02 DUNTKD910FM02 No Changes
MAIN Unit DUNTKD934FM02 DUNTKD934FM08 No Changes
TERMINAL Unit DUNTKD935FM02 DUNTKD935FM08 No Changes
POWER SUPPLY Unit RDENCA184WJQZ RDENCA184WJQZ No Changes

LC-60C52U
ii
LC-60C52U Service Manual
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 120 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a non polarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5 mA rms AC.) or
more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by " " and shaded areas in the Replacement Parts
List and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION: FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAME TYPE FUSE.
F701 (250V 8A), F702 (250V 1A)
F4702 (250V 4A),
F4701/F4703 (250V 3A 127 °C)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-60C52U
iii
PRECAUTIONS A PRENDRE LORS DE LA REP-
ARATION
De nombreuses pièces, électriques et mécaniques, dans les télévi-
seur ACL présentent des caractéristiques spéciales relatives à la sé-
curité, qui ne sont souvent pas évidentes à vue. Le degré de protec-
tion ne peut pas être nécessairement augmentée en utilisant des
pièces de remplacement étalonnées pour haute tension, puissance,
etc.
Les pièces de remplacement qui présentent ces caractéristiques sont
identifiées dans ce manuel; les pièces électriques qui présentent ces
particularités sont identifiées par la marque " " et hachurées dans la
liste des pièces de remplacement et les diagrammes schématiques.
Pour assurer la protection, ces pièces doivent être identiques à celles
utilisées dans le circuit d'origine. L'utilisation de pièces qui n'ont pas
les mêmes caractéristiques que les pièces recommandées par l'usine,
indiquées dans ce manuel, peut provoquer des électrocutions, incen-
dies, radiations X ou autres accidents.
AVERTISSEMENT
1.
2.
3.
4.
5.
•
•
•
•
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux
conseils suivants.
N'entreprendre aucune modification de tout circuit. C'est danger-
eux.
Débrancher le récepteur avant toute réparation.
Inspecter tous les faisceaux de câbles pour s'assurer que les fils
ne soient pas pincés ou qu'un outil ne soit pas placé entre le châs-
sis et les autres pièces métalliques du récepteur.
Inspecter tous les dispositifs de protection comme les boutons de
commande non-métalliques, les isolants, le dos du coffret, les cou-
vercles ou blindages de réglage et de compartiment, les réseaux
de résistancecapacité, les isolateurs mécaniques, etc.
S'assurer qu'il n'y ait pas de danger d'électrocution en vérifiant la
fuite de courant, de la facon suivante:
Brancher le cordon d'alimentation directem-ent à une prise de cou-
rant de 120V. (Ne pas utiliser de transformateur d'isolation pour
cet essai).
A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ
10 watts en parallèle avec un condensateur de 0.15µF en série
avec toutes les pièces métalliques exposées du coffret et une terre
connue comme une conduite électrique ou une prise de terre
branchée à la terre.
Utiliser un voltmètre CA d'une sensibilité d'au moins 5000Ω/V pour
mesurer la chute de tension en travers de la résistance.
Toucher avec la sonde d'essai les pièces métalliques exposées qui
présentent une voie de retour au châssis (antenne, coffret métalli-
que, tête des vis, arbres de commande et des boutons, écusson,
etc.) et mesurer la chute de tension CA en-travers de la résistance.
Toutes les vérifications doivent être refaites après avoir inversé la
fiche du cordon d'alimentation. (Si nécessaire, une prise
d'adpatation non polarisée peut être utilisée dans le but de termin-
er ces vérifications.)
La tension de pointe mesurèe ne doit pas dépasser 0.75V (corre-
spondante au courant CA de pointe de 0.5mA).
Dans le cas contraire, il y a une possibilité de choc électrique qui
doit être supprimée avant de rendre le récepteur au client.
PRECAUTION: POUR LA PROTECTION CON-
TINUE CONTRE LES RISQUES D'INCENDIE,
REMPLACER LE FUSIBLE
F701 (250V 8A), F702 (250V 1A)
F4702 (250V 4A),
F4701/F4703 (250V 3A ~ 127OC)
VERIFICATIONS CONTRE L'INCEN-DIE ET LE
CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer les vérifica-
tions suivantes.
DVM
ECHELLE CA
1.5k ohm
10W
0.15
µ F
SONDE D'ESSAI
AUX PIECES
METALLIQUES
EXPOSEES
BRANCHER A UNE
TERRE CONNUE
AVIS POUR LA SECURITE

LC-60C52U
iv
PRECAUTION FOR USING LEAD-FREE SOLDER
Employing lead-free solder
• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
PARTS CODE
PRICE
RANK
PART
DELIVERY DESCRIPTION
ZHNDAi123250E BL J φ0.3mm 250g (1roll)
ZHNDAi126500E BK J φ0.6mm 500g (1roll)
ZHNDAi12801KE BM J φ1.0mm 1kg (1roll)
LFa
Indicates lead-free solder of tin, silver and copper.
LF a/a
Indicates lead-free solder of tin, silver and copper.

LC-60C52U
1 – 1
LC-60C52U Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS

LC-60C52U
2 – 1
LC-60C52U Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL

LC-60C52U
2 – 2

LC-60C52U
3 – 1
LC-60C52U Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS

LC-60C52U
4 – 1
LCD TV
LC-60C52U
Service ManualLC-60C52UMarketE
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Detach the SD Card Cover .
2. Remove the 4 lock screws and detach the Stand.
3. Remove the 5 lock screws .
4. Remove the 16 lock screws and detach the Rear Cabinet.
1
2
3
4
4
3
2
3
1
SD Card Cover
2Rear Cabinet
Stand

LC-60C52U
4 – 2
5. Remove the 12 lock screws and detach the Bridge Angle and Chassis Fix Angle.
6. Remove the 8 lock screws 8 lock point and detach the Stand St Cover-R.
7. Remove the 4 hook and detach the Stand assist Holder.
8. Remove the 8 lock screws and detach the Stand Fix Angle.
9. Remove the 7 lock screws and detach the Main Shield.
5
6
7
8
Bridge Angle Bridge Angle
555
5
55
8
7
6
7
6
Chassis
Fix Angle
Main Shield
Stand Fix Angle
Stand Assist Holder
Stand St Cover-R
Hook Hook

LC-60C52U
4 – 3
10.Disconnect all the connectors from all the PWBs.
11.Remove the 2 lock screws and detach the KEY PWB.
10
䬌䎯䎤䬍
䬌䎯䎥䬍
䬌䎯䎦䬍
䬌䎵䎤䬍
䬌䎶䎳䬍
䬌䎳䎧䬍
䬌䎳䎫䬍
䬌䎯䎤䬍
䬌䎮䎰䬍
䬌䎵䎤䬍
䬌䎯䎤䬍
䬌䎯䎦䬍
䬌䎯䎥䬍
䬌䎳䎧䬍
䬌䎳䎫䬍
䬌䎮䎰䬍
䬌䎰䎤䬍
䬌䎩䎦䬍䬌䎶䎤䬍
10
Key PWB
Top Cover

LC-60C52U
4 – 4
12.Remove the 1 rivet and the 1 lock screw . Detach the earth plate.
13.Remove the 9 lock screws and detach the Tray Chassis.
14.Disconnect the 3 connectors (MA, FC, SA) , and COAXIAL Wire.
15.Remove the 2 lock screws , 3 lock screws and detach the Terminal Angle.
16.Remove the 7 lock screws and detach the POWER SUPPLY Unit.
17.Remove the 4 lock screws and detach the TERMINAL PWB.
18.Remove the 4 lock screws , and the spacer, rivet and detach the Heat Sink and MAIN PWB.
19.Disconnect the 2 connectors , and detach the Speaker-L and R.
20.Remove the 2 lock screws and detach the R/C, LED PWB.
21.Remove the 4 lock screws and detach the plates.
11 12
13
14 15
16
17
18 19
20 21
22
23
19
18
13
14 12
11
16
13
23
15
17
22
20 21
18
Spacer
Main PWB
Earth
Plate
Power Supply PWB
Chassis Tray
Terminal PWB
R/C, LED
PWB
R/C, LED
Cover
Speaker-R Speaker-L
Terminal Angle
COAXIAL Wire
MA FC SA
Heat Sink

LC-60C52U
4 – 5
22.Remove the 4 lock screws and detach the LCD Panel Module.
23.Remove the 8 lock screws and detach the Chassis Fix Angle T/B.
24
25
25 24 24 25
25 24 24 25
Chassis Fix
Angle T/B
LCD Panel Module

PARTS GUIDE
No. S86V8LC52D62U
LCD COLOR TELEVISION
MODEL
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-60C52U
LC-60C52U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] CABINET AND MECHANICAL
PARTS
[3] SUPPLIED ACCESSORIES
[4] PACKING PARTS (NOT
REPLACEMENT ITEM)
[5] SERVICE JIGS (USE FOR
SERVICING)

LC-60C52U
2
NO. PARTS CODE PRICE
RANK
NEW
MARK PART
DELIVERY DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
NDUNTKD909FM02 AQ N X R/C, LED Unit
NDUNTKD910FM02 AH N X KEY Unit
NDUNTKD934FM08 CQ R MAIN Unit
NDUNTKD935FM08 BG N X TERMINAL Unit
NRDENCA184WJQZ BU N X POWER SUPPLY Unit (Unit exchange)

LC-60C52U
3
[2] CABINET AND MECHANICAL PARTS
33-1
3-2
38
7
53
20
48
58
48
20
58
25
48
20
48
20
58
63
63
62
58
5
39
47
46
41
53
6
1-8
1-7
1-8
1-7
1-7
1-7
1-5
1-7
1-8
1-5
1
1-9
1-1 1-7
1-8
1-5
1-2
1-6
1-4
1-3
1-5
54
59 16 56
59
2-3
2
2-1
2-2
48
48
48
19
48 48
48
17
12
13
48
48 17
12
13
48
48
4-2
4-2
4-1
4
15 52
11
14
51
34
18
35
28
50
27
50
30
60
33
32
33
8
37
50
31
64
43
42
36
50
10
50
23
29
24
24
44
50
9
26
40
22
61
45
65
50
1-9
1-9
1-9
1-12
1-11
25
66 66
67

LC-60C52U
4
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[2] CABINET AND MECHANICAL PARTS
1CCABAB524WJ01 BC X Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Front Cover
1-3 Not Available - N - LED Cover
1-4 HBDGBA061WJSA AG X Badge, "SHARP"
1-5 Not Available - S - Corner Cover, x4
1-6 HPNC-A160WJSA BC N X SP Net
1-7 Not Available - - Mask Himeron, x6
1-8 XEBS930P08000 AA X Screw, x4
1-9 Not Available - - Cover Tape, x6
1-11 TLABZA635WJZZ AD X E-star Label
1-12 TLABZB393WJSA AF X Pop Label
2CCABBA899WJ01 AG X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 LHLDWA012WJKZ AC X Wire Holder
2-3 LHLDWA131WJKZ AF X Wire Holder
3CCOVAB823WJ01 AD X Ks Top Cover Ass'y
3-1 Not Available - N - Top Cover
3-2 Not Available - N - Control Button
4CDAI-A309WJ04 BN X Stand Ass'y
4-1 CDAI-A309WJ03 N X Stand Base Ass'y
4-2 CDAI-A310WJ01 AZ X Stand Support Ass'y, x2
5R1LK520D3LZ10Y HC X 52V LCD Panel Module Unit
6DUNTKD909FM02 AQ N X R/C, LED Unit
7DUNTKD910FM02 AH N X Key Unit
8DUNTKD934FM08 CQ N R Main Unit
9DUNTKD935FM08 BG N X Terminal Unit
10 RDENCA184WJQZ BU N X Power Unit
11 GCOVAA678WJKA AG X SD COVER
12 LHLDZA797WJKA AD X Stand St Cover-F, x2
13 GCOVAB822WJKA AD X Stand St Cover-R, x2
14 HINDPB715WJSA AF X Terminal Label
15 HINDPB893WJSA AH X Terminal Label
16 HINDPC130WJSA AH N X MODEL-LABEL
17 LANGKA819WJN1 AP X Stand Fix Angle, x2
18 LANGKA820WJFW AK X Terminal Angle
19 CANGTA374WJ01 BB X Bridge Angle Ass'y
20 LANGTA375WJFW AK X Chassis Fix Angle T/B, x4
22 CCHSMA341WJ01 BA X Tray Chassis Ass'y
23 LHLDWA102WJKZ AB X Wire Holder, x2
24 LHLDWA120WJKZ AB X Wire Holder, x4
25 LHLDWA123WJKZ AB X Wire Holder, x4
26 LHLDWA150WJKZ AC X Wire Holder
27 PCLICA004WJKZ AC R Clip
28 LX-NZ3047GEZZ AB X Hexagonal Nut
29 PCLICA008WJZZ AB X Clip
30 PRDARA390WJFW AM X Heat Sink
31 PSLDMA910WJN1 AV X Main Shield
32 PSPAZB192WJKZ AG X Spacer
33 PSPAZA917WJKZ AH R Spacer, x2
34 QCNCWA496WJZZ AK X Connector (F-Rca)
35 QCNW-E249WJPZ AH R Connecting Cord (TUNER)
36 QCNW-E258WJQZ AG R Connecting Cord (PD)
37 QCNW-E894WJQZ AP N R Connecting Cord (LP)
38 QCNW-E895WJQZ AG N R Connecting Cord (KM)
39 QCNW-F200WJQZ AK N X Connecting Cord (SP)
40 QCNW-F001WJQZ AH N X Connecting Cord (LB)
41 QCNW-E999WJQZ AN N X Connecting Cord (RA)
42 QCNW-E902WJQZ AH N R Connecting Cord (PH)
43 QCNW-F002WJQZ AN N X Connecting Cord (LA)
44 QEARPA228WJFW AD X Earth Plate
45 QPWBHD838WJQZ AY X Connecting Cord (LV)
46 RSP-ZA192WJZZ AX X Speaker (R)
47 RSP-ZA193WJZZ AX X Speaker (L)
48 XBBS740P08000 AB X Screw, x36
50 XBPS730P06WS0 AB X Screw, x35
51 XBPS830P06000 AA X Screw, x2
52 XEBS930P08000 AA X Screw, x3
53 XEBS930P10000 AA X Screw, x4
54 XEBS940P20000 AB X Screw, x16
56 Not Available - N - No. Label
58 XEBSN40P16000 AB R Screw, x4
59 XBPS930P08JS0 AB R Screw, x5
60 XWHS742-10120 AB X Spacer
61 LHLDW1141CEZZ AE R Wire Holder
62 LHLDWA141WJZZ AD X Wire Holder
63 LHLDW1173CEZZ AD R Wire Holder, x2
64 RCORFA020WJZZ AN R Core
65 QEARBA025WJZZ AD X Plate, x4
66 Not Available - - Screw (for Stand Ass'y), x6
67 Not Available - - Screw (for Stand), x4

LC-60C52U
5
[3] SUPPLIED ACCESSORIES
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[3] SUPPLIED ACCESSORIES
X1 LHLDWA012WJKZ AC X Wire Holder
X2 LHLDWA083WJ00 AD X Cable Tie
X3 LHLDWA131WJKZ AF X Wire Holder
x4 LHLDWA149WJSB AF X Cable Tie
!
X6 QACCDA039WJPZ AR X AC cord
X7 RRMCGA416WJSB AZ X Remote Control Unit
X8 SSAKA0101GJZZ AC X Polyethylene Bag
X9 SSAKAA032WJZZ AB X Polyethylene Bag
X10 TCADEA208WJZZ AD N X Enquete Card
X11 TINS-C914WJZZ AP N X Operation Manual
X12 TCAUHA184WJZZ AD X Setup Guide
X13 CDAI-A309WJ04 BN X Stand Unit
X14 Not Available - - "AAA" size Battery, x2
X15 TGAN-A768WJZZ AD N X Guarantee Card
X7 X14 X6 X1
X3
X2 X13 X11 X4
X8
X9
X10
X12
X15

LC-60C52U
6
[4] PACKING PARTS (NOT REPLACEMENT ITEM)
X7
X6
X8
X10
X11
X1
X2
X3
X4
X5
X9
X12
X13
S5
S4
S7
S4
S2
S3
S8
S1
S4
S4
S4
S6
