Sharp LC-LE831E Series Installation guide

LC-xxLE831E
Training Notes
Issued by:
CE After Sales Service
July 2011

Training Notes
MODEL
LC-40/46/52/60LE831E
Issued by:
CE After Sales Service
July 2011
Note –Please use the ZOOM feature to view the presentation.
Speech bubbles are training notes. Click to access the notes

Contents
1. Model introduction
2. Block Diagram
3. Schematic Diagrams
4. New Technologies
5. Software Updating
6. Service Mode
7. IP Control
8. USB Clone
9. Adjusting Process
Issued by:
CE After Sales Service
July 2011

Model Introduction
Based on LE925 with MEDIATEK Video Processor (MT5395).
RGBY Panel.
Sizes: 40”, 46”, 52” and 60”.
Type of cabinet:
-Front cabinet: Light metallic
-Slim Full-Flat and seamless design
-Stand: Plastic
-Bottom speakers
-Subwoofer
-Touch-sensor keys
Models:
LC-40/46/52/60LE631E → Northern Europe & UK Market
Issued by:
CE After Sales Service
July 2011

Issued by:
CE After Sales Service
July 2011
Model Introduction
Important Specification Notes:
•Models use 2nd generation Quattron panels
•Only HDMI 1 supports the ARC feature
•You can only use USB 1 for the SKYPE camera.
When connected to other USB ports, the unit will
crash and reset
•You can only use USB 2 for devices that require
consistent power such as an external HDD
•You can only use USB 3 for the Wireless LAN.
This port ONLY contains the wireless drivers

Issued by:
CE After Sales Service
July 2011
Model Introduction
• X-GEN TFT LCD 100Hz (double frame driving) (UV2 A).
• New ASV mode Low reflective Black TFT panel.
• Quattron: 4 colour technology.
• LED backlight system (Edge type).
• Full-HD LCD Panel (1920xRGBYx1080) with 4ms response.
• Wide angle vision (H/V: 176º).
• High brightness (418cd/m2) and dynamic contrast (5000:1).
• 200Hz scanning backlight.
• Built-in DVB-T/DVB-T2 / DVB-C Tuner (MPEG2/MPEG4
H.264).
• Dolby Digital Plus (DD+) decoder (E-AC3) and HE-AAC
compatible.
• Optical Digital Audio Output (SPDIF).
• Multi-standard AV.
• OSD multi-language.
• 4 x HDMI 1.4a (1080p 24/50/60Hz) with InstaPort™ feature.
• ARC in HDMI1.
• SD sct for On-demand via Aquos NET+.
• Common Interface Plus (CI+).
• PC input (analog RGB / digital HDMI).
• RGB in EXT1.
• LAN connector (Net-TV).
• RS-232C terminal.
• IP control (B2B, enable <PC or Ctrol panel to control
basic TV functions)
• USB 2.0: JPEG (Photo), MP3 (Music), Movie (avi, mkv,
wmv, asf, mp4, mpg,
mov, DivX + HD) & SERVICE (soft. update).
• AQUOS LINK.
• 8 ECO (Environment Friendly).
• Advance EPG Mode.
• Pyramid Icon: with light-up illumination.
• DLNA
• TimeShift -USB Port Only.
• Digital audio amplifi er 20W (10W+10W)-Subwoofer
(15W).
• AQUOS Net+
• Skype function
• 3D ready model
• Wi-Fi.
• MHP (only LE833)
• FRED technology (Frame Rate Enhanced Driving)
• 3 USB ports
-USB 1: USB memory or Skype camera
-USB 2: HDD port
-USB 3: Wireless LAN
• E-manual (supplied USB memory)
• New 3D glasses AN-3DG20 (rechargeables)

Issued by:
CE After Sales Service
July 2011
Model Introduction

Issued by:
CE After Sales Service
July 2011
Model Introduction

Issued by:
CE After Sales Service
July 2011
Model Introduction

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5391 MT5395
CPU Comparison

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction CPU Comparison

Issued by:
CE After Sales Service
July 2011
Model Introduction
MT5395
CPU Comparison
MT5391

Issued by:
CE After Sales Service
July 2011
Model Introduction Parts Codes
MODEL NAME JPN MOD. MAIN LCD CONTROL POWER ICON
LC40LE831E A3IK4831EP DUNTKF733FM52 DUNTKF906FM54 RUNTKA787WJQZ DUNTKF770FM51
LC46LE831E A3IK5831KP DUNTKF733FM52 RUNTKA4909TPZM RUNTKA791WJQZ DUNTKF770FM51
LC52LE831E A3IK6831KP DUNTKF733FM52 RUNTKA4909TPZH RUNTKA795WJQZ DUNTKF770FM51
LC60LE831E A3IK7831KP DUNTKF733FM52 RUNTK4909TPYN RUNTKA799WJQZ DUNTKF770FM51
MODEL NAME TOUCH-KEY R/C CONTROL IR TRANSMITER PANEL MODULE CABINET
LC40LE831E RTUNKA869WJQZ DUNTKF494FM02 RUNTKA819WJQZ R1LK400D3GW50Y CCABAC653WJ1
1
LC46LE831E RTUNKA869WJQZ DUNTKF494FM02 RUNTKA819WJQZ R1LK460D3GW40Y CCABAC654WJ1
1
LC52LE831E RTUNKA819WJQZ DUNTKF494FM02 RUNTKA869WJQZ R1LK520D3GW40P CCABAC655WJ3
4
LC60LE831E RTUNKA819WJQZ DUNTKF494FM02 RUNTKA869WJQZ R1LK600D3GW40
H
CCABAC656WJ3
5
