Sharp LC-32LB591U User manual

Note: Images do not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
START HERE
How do I attach the stands to my TV?
(not for wall mounting)
You’ll need: Phillips screwdriver and a soft surface to lay the TV on.
1 Carefully place your TV face-down on a cushioned,
clean surface.
2 Slide the stands into the slots on the back of the TV.
Make sure that the long ends of the stands face the
front of the TV.
3 Secure the stands to the TV with the two provided screws.
QUICK SETUP GUIDE
Power cord
TV stands
Included accessories
STOP!
Do not plug your
power cord in until
all other devices
have been
connected.
Remote control
and two AAA
batteries
WHAT YOU NEED
(not included)
Wireless router*
(needed for streaming)
Internet connection*
(needed for streaming)
A Phillips screw driver
*Subscription or other payment may
be required to access certain content.
Back view
How do I prepare my TV for wall mounting?
(not for use with the TV stands)
You’ll need: Phillips screwdriver and a soft surface to lay the TV on.
1 Carefully place your TV face-down on a cushioned, clean surface.
2 See the instructions that came with your wall mount for more
information about how to correctly mount your TV.
OR
Final flat size: 593.85 x 419.61
Features
Front view
2
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your User Guide is
not provided in the box but is available online.
Go to: https://www.sharptvusa.com/support
Find your model. Under Owners Manual, find the
language you want, then click Download.
Your online User Guide opens.
MAKING CONNECTIONS
How do I watch TV or connect a device such as a DVD or Blu-ray disc player,
game console, or tablet?
Using an HDMI cable
(BEST)
Using an AV cable
(GOOD)
How do I connect my TV to an antenna or cable wall jack?
OVER
Multi-purpose jack: You
can plug any device
that uses HDMI into any
HDMI jack. However,
certain devices
must be connected to
the HDMI 1 (ARC) jack.
See the instructions that
came with your
ARC-enabled device for
more information.
1
2
LC-32LB591U
HD LED 720p TV
[1]
CONNECTING AUDIO DEVICES
How do I connect my TV to external speakers?
3
Your TV has four VESA mounting holes on the back. If you attach a
wall-mount bracket to the back of your TV, the bracket must be securely
attached, using all four holes. If you do not use all four mounting holes,
your TV may fall and cause property damage or personal injury.
See the documentation that came with your wall mount for
complete mounting instructions.
Wall mount installation guide (not included)
M4 (10 mm length)
(2 pcs.)
*Note: If the volume on the device connected to the analog audio jack is too low, try increasing the volume on your TV.
Using analog audio
OR
digital audio
AV cable option
3
Power connector
AUDIO IN
Analog audio*
[1]
(31.5" Diagonal)
[2]
OR
OR
AUDIO IN
Analog audio*
M4 × 10 mm screws
Power indicator
Remote control sensor
INPUT
Digital audio
C
M
Y
CM
MY
CY
CMY
K
Sharp LC-32LB591U_LC-32LB591C_17-0047_QSG_V1_ENG_Final.ai 1 2/21/2017 2:32:06PMSharp LC-32LB591U_LC-32LB591C_17-0047_QSG_V1_ENG_Final.ai 1 2/21/2017 2:32:06PM

V1 ENGLISH 17-0047
One-year limited warranty
Visit https://www.sharptvusa.com/support
Need additional help?
See your online User Guide! This comprehensive guide includes
everything from basic how-to steps to more advanced features.
Go to: https://www.sharptvusa.com/support
Find your model. Under Owners Manual, find the language you
want, then click Download. Your online User Guide opens.
We’re here for you.
https://www.sharptvusa.com/support
For customer service, call: 855-544-2030
All rights reserved. SHARP is a trademark of Sharp Corporation;
used under license by Hisense International (Hong Kong)
America investment Co., Limited.
4 5
Help
TURNING ON MY TV
When can I turn on my TV?
When your television is in place:
1Plug one end of the power
cord into the AC IN connector
on the back of your TV and the
other end into a power outlet.
2Remove the remote control cover
and install the batteries.
3Press (power) on your remote
control.
4Follow the on-screen instructions.
USING YOUR REMOTE CONTROL
COMPLETE GUIDED SETUP (OPTIONAL)
Establish your network connection.
CONNECTING BRINGS OUT YOUR TV'S FULL POTENTIAL!
If you connected a cable or satellite box,
skip this step.
If you connected your TV to an antenna or
cable wall jack (no box):
1When the setup wizard is complete,
select the
ANTENNA TV tile from
the Home screen.
2Follow the on-screen instructions.
3Whenever you want to watch TV,
select this tile.
Antenna TV
HOME
Displays your TV's Home screen.
Stops playback if you are watching TV
or streaming content.
Side view
VOLUME UP
Increases the volume or
un-mutes the sound.
VOLUME DOWN
Decreases the volume.
MUTE
Mutes or un-mutes
the sound.
Using your cable set-top box or satellite receiver remote as a universal remote.
If you prefer to use your cable set-top box or satellite receiver remote as a universal remote, please refer to the manual that your
cable or satellite service provided. It will include instructions on how to program their remote to your television. You can find
codes that work with your Sharp•Roku TV and the most common cable and satellite provider’s universal remote controls
at www.roku.com/universalremote.
TROUBLESHOOTING
Having trouble completing the
guided setup?
Don't worry, it's usually an easy fix.
If you cannot see a picture on your TV
• Make sure that your TV and the device you
want to watch (cable box, Blu-ray player,
game console, etc.) are turned on and
plugged into a working wall outlet.
• Make sure that your power cable is
connected.
If you cannot connect to your wireless
home network during guided setup
• Make sure that the correct wireless network
name is selected.
• Make sure that the wireless network password is
correctly entered (password is case sensitive).
• Improve wireless signal by rotating the router
slightly (even a few inches can help).
If you cannot hear sound
• Make sure that the TV volume is turned up and
not on mute.
• Try only the TV speakers by disconnecting any
connection to audio devices (like headphones
or audio video receivers).
If the TV remote control isn't working
• Remove any obstruction and point the remote
at the TV's remote control sensor
(Features).
• Try a fresh set of batteries.
• If the status light on the front of your TV flashes
once each time you press a remote button,
the problem is not with the remote.
• Unplug the TV and plug it back in.
BACK
Returns to the previous screen.
STREAMING CHANNELS SHORTCUTS
When you press a button:
• If you have not added the channel,
displays a sign up page.
• If you have added the channel,
displays the channel's home page.
• If your TV is off, turns on your TV and
displays the channel’s home page.
SLEEP
Sets the sleep timer.
VIEW MORE OPTIONS
Gives you easy access to
picture settings, display options,
and more. Press *on any
screen to access options.
PLAY/PAUSE
Pauses or resumes playback.
Front view
REWIND
Rewind streaming video, jumps
to the previous audio track or
selection, jumps up one page
in menus.
Directional keypad
Watching local broadcast TV.
How do I scan for channels?
OPTIONAL
POWER
Turns your TV on or off.
FAST FORWARD
Fast forwards streaming video,
jumps to the next audio track or
selection, jumps down one page
in menus.
6
You'll have access to thousands of streaming channels.*
CHANNEL RECALL/JUMP BACK
AND INSTANT REPLAY
Changes to the previous channel
when viewing antenna or cable
(no set-top box) programming. Jumps
back one position in video
when viewing streaming content.
Backspaces one letter during menu
entries, such as Search.
Make any night a movie night
Access more than 450,000 movies and TV episodes across major
streaming services like Netflix, Hulu, Amazon Video, VUDU, and
more. Choose from free, rental, and subscription services.
Stream sports on the big screen.
Choose from over 140 sports channels like WatchESPN, FOX
Sports Go, NBA, NFL, MLB, WWE, CBS Sports, and more.*
Explore your passions
In addition to popular streaming channels like HBO NOW, SHOWTIME,
PBS KIDS, and FOX NOW, your Sharp • Roku TV also offers hundreds
of streaming channels to fuel your passions – including fitness,
cooking, religion, outdoors, international programming, and
much more.
Enjoy tons of free channels and free trials
Your Sharp • Roku TV has hundreds of popular free channels like
Crackle, CBS News, PBS, VEVO, and more. Plus, free trials** to popular
subscription services like HBO NOW, SHOWTIME, Netflix,
Amazon Video, and Hulu.
*Subscription or other payment may be required to access certain channels. Content may
not be available in all areas in which the Sharp • Roku TV is sold and channel availability is
subject to change.
**Cancel before your free trial ends to avoid subscription fees. A credit card may be
required.
ROKU, ROKU TV, and the ROKU logo are trademarks and the property of Roku, Inc.
Other channel logos, brand, and product names are trademarks or
registered trademarks of their respective holders.
1 Your TV automatically detects your wireless network, so have your
network name and password handy and follow the easy on-screen
instructions.
2You’ll be prompted to create your Roku account online at
https://my.roku.com/link. Your TV will generate a unique code that
links your TV to your new account.
Note: Roku accounts are free, and while a valid credit card number
is not required, providing your card information makes renting and
purchasing entertainment a breeze.You won’t be charged unless you
agree to the terms and cost of the content.
3Once connected to your account, your TV will automatically update
with the latest software, and you can start streaming immediately.
4If you aren’t ready to connect your TV to a wireless network, you can
still use it as a regular TV.
.
The best time to turn on your TV is after you have connected all devices
and either attached the TV stand or wall-mounted your TV.
