Sharp DL-HB9 User manual

DATE TYPE
FIRM NAME
PROJECT
COMMENTS
DL-HB9
High-Bay
High-Bay
INTENDED USE
The Sharp DL-HB Series
High-Bay for ambient lighting.
APPLICATION
The DL-HB Series luminaire is a
high ecacy LED lighting solution
perfectly suited for high-bay
applications.
CONSTRUCTION
The housing consists of a durable
extruded aluminum body assembled
with a highly conductive extruded
aluminum heat sink.
OPTIC
Durable, high eciency glass optic
ensures long life performance.
LED DRIVER
High Eciency, long life driver.
WARRANTY
 year limited warranty
RATED LIFE
Calculated Lumen Maintenace,
L  , hrs*
* Calculated using TM- Calculator based
on , hrs of testing.
PERFORMANCE SUMMARY
• Delivered Lumens (nom) , lm
• Ecacy  to  lm/W
• Color Accuracy (CRI) 
• Color Appearance (CCT) K
• Color Accuracy (SDCM)  SDCM
• Center Beam Candelpower  cd
(CBCP)
• Distribution .
Zonal Lumen
Density -
• Distribution .
Zonal Lumen
Density -
• Input Power W
• Input Voltage -V, -V
• Surge Class A C.
• EMI FCC Compliant
WEIGHT
. lbs
CERTIFICATIONS/LISTINGS
Damp Locations.
Not all product configurations are
listed with Designlights Consortium.
Please refer to http://www.
designlights.org/solidstate.about.
QualifiedProductsList_Publicv2.php
for listed configurations.
Subject to change without notice.
¾" ¾"
¾
MADE IN MEMPHIS, TN
FROM DOMESTIC & IMPORTED PARTS
PAGE  OF  DL-HB / HIGHBAY_I
Model Combination Tables
Example : DL-HBJP
DL-HB 9 J P
Product Classication / Size / Optics Product Size Lumens Color Temerature / CRI Voltage
DLHB High Bay Fixture 9Square J20,000-23,999 P
5700K
4120-277 V LED Lamps/Fixture
27347-480 V LED Lamps/Fixture
28480 V LED Lamps/Fixture

High-Bay
Candlepower
Summary
0 90
0 7706 7706
15 7529 7522
30 6868 6844
45 5516 5521
60 3405 3404
75 1153 1075
90 0 3
Coecients Of Utilization - Zonal Cavity Method
Eective Floor Cavity Reectance 0.20
RC 80% 70% 50%
RW 70% 50% 30% 50% 30% 10% 50% 30% 10%
0 119 119 119 116 116 116 111 111 111
1 107 101 96 99 94 90 95 91 87
2 96 87 79 85 78 72 81 75 70
3 87 75 66 74 65 59 71 64 58
4 79 66 57 65 56 49 62 54 48
5 72 59 49 57 48 42 55 47 41
6 66 52 43 51 42 36 49 41 35
7 61 47 38 46 37 31 44 36 31
8 57 42 33 42 33 27 40 32 27
9 53 38 30 38 30 24 37 29 24
10 49 35 27 35 27 21 34 26 21
LED:  K,  CRI
System Delivered Lumens: , lm
Fixture Ecacy:  lm/ W
Zonal Lumen Summary
Zone Lumens % Fixt
0°-30° 6167 27
0°-60° 18454 82
0°-90° 22569 100
90°-180° 0 0
0°-180° 22569 100
PERFORMANCE COMPARISON
Luminaire Type Delivered
Lumens (lm)
Luminaire
Ecacy (lm / W)
Input
Power (W)
Power Saved per
Luminare (W)
Rated Lamp
Life (hr)
SHARP DL-HB9JP8 23,380 101 231 — 100,000
400 MH (typical) 21,000 48 442 211 20,000
6x 54W T5 (typical) 25,550 70 365 134 35,000
1906
3813
5719
7625
SHARP ELECTRONICS CORPORATION
Sharp Plaza Blvd., Memphis, TN 38193
1-877-312-5331 • Email: [e-mail]
www.sharpledlighting.com
© 2013 Sharp Electronics Corporation. All rights reserved.
PAGE  OF  DL-HB / HIGHBAY_I
