R-1874
SUPPLEMENTAL SERVICE MANUAL
TABLE OF CONTENTS Page
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICE TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ................... INSIDEFRONTCOVER
BEFORESERVICING ...................................................................................................... INSIDEFRONTCOVER
MICROWAVEMEASUREMENTPROCEDURE.....................................................................................................1
WARNING TO SERVICE PERSONNEL..........................................................................................................3
FOREWORD..........................................................................................................................................................4
PRODUCTSPECIFICATIONS...............................................................................................................................5
GENERAL INFORMATION ...................................................................................................................................5
PICTORIALDIAGRAM ..........................................................................................................................................7
CONTROLPANELCIRCUIT ..................................................................................................................................8
PARTS LIST..........................................................................................................................................................9
PACKINGANDACCESSORIES .........................................................................................................................15
SHARP ELECTRONICS CORPORATION
This document has been published to be used for after sales service only. The contents are subject to change without notice.
Service Headquarters: Sharp Plaza, Mahwah, New Jersey, 07430-2135
OR:
SHARP CORPORATION
SHARP ELECTRONICS OF CANADA LTD.
Head Office: 335 Britannia Road East, Mississauga, Ontario L4Z 1W9
[phone]
This is a supplemental Service Manual for Model R-1874.
This model is quite similar to Base Model R-1855A (S/M# S01M177R1875E).
Use this supplemental manual together with the Base Model Service Manual for complete operation and service information
In the interest of user-safety, the oven should be restored to its original condition and only parts identical to those specified
should be used.
WARNING TO SERVICE PERSONNEL: Microwave ovens contain circuitry capable of producing very high voltage and
current, contact with following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor, High
Voltage Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness etc..)
S52M187R1874E
OVERTHE RANGE
MICROWAVEOVEN
MODEL R-1874
(INUSA):
(INCANADA):
MIX CONV
DEFROST
SENSOR
TURNTABLE ON OFF COOK LBS OZ KG HELP

R-1874
PRECAUTIONSTO BE OBSERVED BEFORE AND
DURING SERVICINGTO AVOID POSSIBLE
EXPOSURETO EXCESSIVE MICROWAVE
ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other
microwave source, and make repairs as necessary: (1) interlock operation (2) proper door closing, (3)
seal and sealing surfaces (arcing, wear, and other damage), (4) damage to or loosening of hinges and
latches, (5) evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection within the microwave generating
compartments, check the magnetron, wave guide or transmission line, and cavity for proper alignment,
integrity, and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door seal, and microwave
generation and transmission systems shall be repaired, replaced, or adjusted by procedures described
in this manual before the oven is released to the owner.
(e) A microwave leakage check to verify compliance with the Federal Performance Standard should be
performed on each oven prior to release to the owner.
BEFORE SERVICING (CANADA)
Before servicing an operative unit, perform a microwave emission check as per the Microwave
Measurement Procedure outlined in this service manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS OF
CANADA LTD. immediately.
Ifthe unit operateswith thedooropen, serviceperson should 1)tell the usernot tooperatethe oven
and 2) contact SHARP ELECTRONICS OF CANADA LTD. and NHW, CANADA immediately.
Service personnel should inform SHARP ELECTRONICS OF CANADA LTD. of any certified unit
found with emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use
the unit until the oven has been brought into compliance.
BEFORE SERVICING (USA)
Before servicing an operative unit, perform a microwave emission check as per the Microwave
MeasurementProcedure outlined in thisservice manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS
CORPORATIONimmediately @1-800-237-4277.
If the unit operates with the door open, service person should 1) tell the user not to operate the oven
and2)contactSHARPELECTRONICSCORPORATIONandFoodandDrugAdministration'sCenter
forDevices andRadiologicalHealth immediately.
ServicepersonnelshouldinformSHARPELECTRONICSCORPORATIONofanycertifiedunitfound
with emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use the unit
until the oven has been brought into compliance.

1
R-1874
MICROWAVE MEASUREMENT PROCEDURE (USA)
A. Requirements:
1) Microwave leakage limit (Power density limit): The power density of microwave radiation emitted by a microwave oven
shouldnotexceed1mW/cm2atanypoint5cmormorefromtheexternalsurfaceoftheoven,measuredpriortoacquisition
byapurchaser,and thereafter(throughtheusefullife of theoven),5mW/cm2atanypoint 5cmormorefromthe external
surface of the oven.
2) Safety interlock switches:Primaryinterlockrelayanddoorsensing switch shall preventmicrowaveradiationemissionin
excessoftherequirementasabovementioned,secondaryinterlockswitchshallpreventmicrowaveradiationemissionin
excess of 5 mW/cm2at any point 5cm or more from the external surface of the oven.
B. Preparation for testing:
Before beginning the actual measurement of leakage, proceed as follows:
1) Make sure that the actual instrument is operating normally as specified in its instruction booklet.
Important:
Surveyinstrumentsthatcomplywiththerequirementfor instrumentation as prescribed by the performance standard
for microwave ovens, 21 CFR 1030.10(c)(3)(i), must be used for testing.
2) Place the oven tray in the oven cavity.
3) Place the load of 275±15 ml (9.8 oz) of tap water initially at 20±5½C (68½F) in the center of the oven cavity.
The water container shall be a low form of 600 ml (20 oz) beaker with an inside diameter of approx. 8.5 cm (3-1/2
in.) and made of an electrically nonconductive material such as glass or plastic.
Theplacingofthisstandardloadintheovenisimportantnotonlytoprotecttheoven,butalsotoinsurethatanyleakage
is measured accurately.
4) Set the cooking control on Full Power Cooking Mode
5) Close the door and select a cook cycle of several minutes. If the water begins to boil before the survey is completed,
replace it with 275 ml of cool water.
C. Leakage test:
Closed-door leakage test (microwave measurement)
1) Grasptheprobeofthesurveyinstrumentandholditperpendiculartothegapbetweenthedoorandthebodyoftheoven.
2) Move the probe slowly, not faster than 1 in./sec. (2.5 cm/sec.) along the gap, watching for the maximum indication on
the meter.
3) Check for leakage at the door screen, sheet metal seams and other accessible positions where the continuity of the
metal has been breached (eg., around the switches, indicator, and vents).
Whiletestingforleakagearoundthedoorpullthedoorawayfromthefrontoftheovenasfarasispermittedbytheclosed
latch assembly.
4) Measure carefully at the point of highest leakage and make sure that the highest leakage is no greater than 4mW/cm2,
and that the secondary interlock switch does turn the oven OFF before any door movement.
NOTE: After servicing, record data on service invoice and microwave leakage report.

2
R-1874
MICROWAVE MEASUREMENT PROCEDURE (CANADA)
Afteradjustmentofthedoorswitchesarecompletedindividuallyorcollectively,switchtestandmicrowaveleakagetestmust
beperformedwithsurveyinstrumentandtestresultmustbeconfirmedtomeettherequirementoftheperformancestandard
formicrowaveovensasundermentioned.
A.Requirements:
Every microwave oven shall function in such a manner that when the oven is fully assembled and operating with its service
controls and user controls adjusted to yield the maximum output, the leakage radiation, at all points at least 5 cm. from the
external surface of the oven, does not exceed:
1) 1.0mW/cm2 with the test load of 275 ± 15 ml of water at an initial temperature 20 ±5oC.
2) 5.0mW/cm2 whentheouterenclosureisremovedwithatestloadof275±15mlofwaterataninitialtemperature20±5oC.
3) 5.0mW/cm2 without a test load.
B.Preparationfortesting:
Beforebeginningtheactualmeasurementofleakage,proceed asfollows:
1) Make sure that the actual instrument is operating normally as specified in its instruction booklet.
Important:
SurveyinstrumentsthatcomplywiththerequirementforinstrumentationasprescribedbyCSAandNHWperformancestandard
for microwave ovens must be used for testing recommended instruments are , NARDA 8100 and NARDA 8200.
2) Place the oven tray in the oven cavity.
3) Place the load of 275±15 ml of tap water initially at 20±5oC in the center of the oven cavity.
The water container shall be a low form of 600 ml beaker with an inside diameter of approx. 8.5 cm (3-1/2 in.) and made
of an electrically nonconductive material such as glass or plastic.
Theplacing of this standard load intheovenis important not only toprotecttheoven, but also to insure thatanyleakage
ismeasured accurately.
4) SetthecookingcontrolonFullPowerCookingMode,Closethedoorandselectacookcycleofseveralminutes.Ifthewater
begins to boil before the survey is completed, replace it with 275 ml of cool water.
C. Leakagetestwithenclosureinstalled:
1) Grasptheprobeofthesurveyinstrumentandholditperpendiculartothegapbetweenthedoorandthebodyoftheoven.
2) Move the probe slowly, not faster than 2.5 cm/sec. along the gap, watching for the maximum indication on the meter.
3) Checkforleakageatthedoorscreen,sheetmetalseamsandotheraccessiblepositionswherethecontinuityofthemetal
hasbeen breached (eg., aroundthe switches, indicator, andvents).
Whiletestingforleakagearoundthedoorpullthedoorawayfromthefrontoftheovenasfarasispermittedbytheclosed
latch assembly.
4) Measurecarefullyatthepointofhighestleakageandmakesurethatthehighestleakageisnogreaterthan4mW/cm2,and
that the secondary interlock switch does turn the oven OFF before any door movement.
C. Leakagetestwithoutenclosure:
1) Removetheenclosure(cabinet).
2) Grasp the probe of the survey instrumentandholditperpendiculartoallmechanicalandelectricpartsofthe oven that is
accessibletotheuseroftheovenincluding,butnotlimitedto,thewaveguide,cavityseams,magnetrongapbetweenthe
door and the body of the oven.
3) Move the probe slowly, not faster than 2.5 cm/sec. along the gap, watching for the maximum indication on the meter.
4) Measure carefully at the point of highest leakage and make sure that the highest leakage is under 5mW/cm2.
CAUTION:SpecialattentionshouldbegiventoavoidelectricalshockbecauseHIGHVOLTAGEisgeneratedduringthistest
NoLoadtest
1) Operate the oven without a load and measure the leakage by the same method as the above test procedure " Leakage
test with enclosure installed"
2. Make sure that the highest leakage should not exceed 5mW/cm2.
NOTE: After servicing, record data on service invoice and microwave leakage report.

3
R-1874
WARNINGTO SERVICE PERSONNEL
Microwave ovens contain circuitry capable of pro-
ducing very high voltage and current, contact with
followingparts
mayresultinasevere,possiblyfatal,
electricalshock.
(Example)
HighVoltageCapacitor,HighVoltagePowerTrans-
former,Magnetron,HighVoltageRectifierAssem-
bly, High Voltage Harness etc..
Read the Service Manual carefully and follow all
instructions.
Before Servicing
1. Disconnect the power supply cord , and then
remove outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
WARNING:RISK OF ELECTRIC SHOCK.
DISCHARGETHEHIGH-VOLTAGE
CAPACITORBEFORESERVICING.
The high-voltage capacitor remains charged about 60
seconds after the oven has been switched off. Wait for
60 seconds and then short-circuit the connection of the
high-voltage capacitor (that is the connecting lead of the
high-voltage rectifier) against the chassis with the use of
an insulated screwdriver.
Whenever troubleshooting is performed the power supply
mustbedisconnected.Itmayin,somecases,benecessary
to connect the power supply after the outer case has been
removed, in this event,
1. Disconnect the power supply cord, and then remove
outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Disconnect the leads to the primary of the power
transformer.
5. Ensure that these leads remain isolated from other
components and oven chassis by using insulation tape.
6. After that procedure, reconnect the power supply cord.
When the testing is completed,
1. Disconnect the power supply cord, and then remove
outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Reconnect the leads to the primary of the power
transformer.
5. Reinstall the outer case (cabinet).
6. Reconnect the power supply cord after theoutercaseis
installed.
7. Run the oven and check all functions.
After repairing
1. Reconnect all leads removed from components during
testing.
2. Reinstall the outer case (cabinet).
3. Reconnect the power supply cord after theoutercaseis
installed.
4. Run the oven and check all functions.
Microwave ovens should not be run empty. To test for the
presence of microwave energy within a cavity, place a cup
of cold water on the oven turntable, close the door and set
the power to HIGH and set the microwave timer for two (2)
minutes.When the two minutes haselapsed(timer at zero)
carefully check that the water is now hot. If the water
remainscoldcarryoutBeforeServicingprocedureandre-
examine the connections to the component being tested.
When all service work is completed and the oven is fully
assembled,themicrowavepoweroutputshouldbechecked
and microwave leakage test should be carried out.
Don't Touch !
Danger High Voltag
e

4
R-1874
SUPPLEMENTAL
SERVICE MANUAL
MICROWAVEOVEN
R-1874
FOREWORD
This Manual has been prepared to provide Sharp Electronics Corp.
ServicePersonnelwithOperationandServiceInformationfortheSHARP
MICROWAVEOVEN,R-1874.
Themodel R-1874 is quite similartobase model R-1855A
(Ref.# S99M138R1855E)
Itisrecommendedthatservicepersonnel carefully study the entire text
ofthismanualandthebasemodel'smanualsothattheywillbequalified
to render satisfactory customer service.
Check the interlock switches and the door seal carefully. Special
attention should be given to avoid electrical shock and microwave
radiationhazard.
WARNING
Never operate the oven until the following points are ensured:
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is no other visible damage with the oven.
Servicing and repair work must be carried out only by trained service
personnel. DANGER
Certaininitialpartsareintentionallynotgroundedandpresent
ariskofelectricalshockonlyduringservicing.Serviceperson-
nel - Do not contact the following parts while the appliance is
energized;
High Voltage Capacitor, Power Transformer, Magnetron, High
VoltageRectifierAssembly, HighVoltageHarness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
Allthepartsmarked“*”onpartslistare used at voltages more than
250V.
Removal of the outer wrap gives access to voltage above 250V.
PRODUCTDESCRIPTION
GENERALINFORMATION
OPERATION
WIRINGDIAGRAM
PARTS LIST
SHARPELECTRONICSCORPORATION
SHARP PLAZA, MAHWAH,
NEW JERSEY 07430-2135
USAMODEL
CANADIANMODEL
OSAKA, JAPAN

5
R-1874
ITEM DESCRIPTION
PowerRequirements 120Volts/13.2Amperes(Microwave),13.2 Amperes(Convection)-[ULRating]
116Volts/13.0Amperes(Microwave),13.0 Amperes(Convection)-[CFSRating]
60Hertz
Singlephase,3wiregrounded
PowerOutput 850watts(IEC-705TESTPROCEDURE)
Operatingfrequencyof2450MHz
ConvectionPowerOutput 1400watts
CaseDimensions Width29-15/16"
Height16-11/32"
Depth 15-9/32"
CookingCavityDimensions Width17-1/8"
Height8-1/16"
1.1 Cubic Feet Depth 13-13/16"
Hoodlamp 2 bulbs, 20W x 2, Incandescent light bulbs
Hoodfan Horizontal discharge 230 C.F.M. , Vertical discharge 240 C.F.M. ,
ControlComplement TouchControlSystem
Clock ( 1:00 - 12:59 )
Timer (0 - 99 min. 99 seconds)
MicrowavePowerforVariableCooking
Repetition Rate;
P-HI................................................... Fullpower throughoutthecookingtime
P-90 .....................................................................approx. 90% of Full Power
P-80 .....................................................................approx. 80% of Full Power
P-70 .....................................................................approx. 70% of Full Power
P-60 .....................................................................approx. 60% of Full Power
P-50 .....................................................................approx. 50% of Full Power
P-40 ......................................................................approx.40%ofFullPower
P-30 ......................................................................approx.30%ofFullPower
P-20 .....................................................................approx. 20% of Full Power
P-10 .......................................................................approx. 10% of FullPowe
P-0 ......................................................Nopower throughoutthecookingtime
CUSTOM HELP pad, SENSOR COOK pad, COMPU BROIL pad, COMPU ROAST pad
COMPU BAKE pad, SENSOR REHEAT pad, MINUTE PLUS pad, POPCORN pad
COMPU DEFROST pad, CONVECTION pad, REHEAT pad, LOW MIX/BAKE pad
HIGH MIX/ROAST pad, BROIL pad, SLOW COOK pad, KITCHEN TIMER pad
Number and temperature selection pads, CLOCK pad, KEEP WARM pad
TURNTABLE ON / OFF pad, POWER LEVEL pad, STOP/CLEAR pad,
START / TOUCH ON pad, Fan Hi/Lo, Light.
OvenCavityLight Yes 20W x 1 Incandescent light bulb
SafetyStandard UL Listed FCC Authorized
DHHSRules,CFR,Title21,Chapter 1, Subchapter J
CanadianStandardsAssociation.
DepartmentofNationalHealthandWelfareCANADA,IndustryCANADA.
Weight Approx. 71 lbs.
SPECIFICATION
GENERAL INFORMATION
GROUNDING INSTRUCTIONS
Thisovenisequippedwithathreepronggroundingplug.Itmustbepluggedintoawallreceptaclethatisproperlyinstalledand
groundedinaccordancewiththeNationalElectricalCodeand local codes and ordinances.
Intheeventofanelectricalshortcircuit,groundingreducestheriskofelectricshockbyprovidinganescapewirefortheelectric
current.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.

6
R-1874
3-Pronged Plug Grounded
Receptacle Box
Grounding Pin
3-Pronged Receptacle
Electrical Requirements
The oven is equipped with a 3-prong grounding plug. DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE
GROUNDING PIN FROM THE PLUG.
The power supply cord and plug must be connected to a separate 120 Volt AC, 60 Hz, 15 Amp. or more branch circuit, using
a grounded receptacle. The receptacle should be located inside the cabinet directly above the Microwave Oven/Hood
system mounting location.
OVEN DIAGRAM
1. Oven door with see-through window.
2. Door hinges.
3. Stirrer cover.
4. Turntable motor shaft.
5. Oven lamp.
It will light when oven is operating or door is open.
6. Door latches.
The oven will not operate unless the door is securely closed.
7. One touch door open button.
Push to open door.
8. Auto-Touch control panel.
9. Ventilation openings.
10. Light Cover.
11. Grease filters.
12. Removable turntable.
The turntable will rotate clockwise or counterclockwise.
Only remove for cleaning.
13. Removable turntable support.
14. Plug
66
1
9
8
12
13
10
11
714
2
35
4
NOTE:
Some one-touch cooking features
as"MINUTEPLUS"aredisabledaf-
teroneminutewhentheovenisnot
used.Thesefeaturesare automati-
cally enabled when the door is
opened and closed or the STOP/
CLEARpadispressed.

7
R-1874
6
45
123
6
45
123
A
B
C D E F
G H
A
B
C D E F
G H
Figure S-1. Pictorial Diagram
6
45
123
6
45
123
A
B
C D E F
G H
A
B
C D E F
G H
Figure S-1. Pictorial Diagram
HIGH VOLTAGE
CAPACITOR
H.V.
RECTIFIER
HIGH VOLTAGE COMPONENTS
MAGNETRON
POWER TRANSFORMER
FFA
Power Supply
cord 120V 60Hz
GRN
BLK
BLK
1
2
3
WHT
GRN
BLK
HOOD FAN
THERMAL
CUT-OUT
CONVECTION
MOTOR
HEATING
ELEMENT
THERMISTOR
TEMPERATURE FUSE (MG.)
B
L
K
B
L
K
B
R
N
R
E
D
BLK
WHT
RED
BRN
WHT
BLK
FAN
MOTOR
DAMPER
MOTOR
DAMPER
SWITCH
TURNTABLE
MOTOR
GRY
BRN
GRY
BRN
ORG
WHT
HOOD LAMPS
& SOCKETS
GRY
Blue
Marking
Blue Marking
OVEN LAMP & SOCKET
to oven cavity
front flange
CN-E
CN-F
1
2YLW
GRY
CN-A
5
4
RED
GRY
WHT
WHT
BLK
BLK
SECONDARY
INTERLOCK
SWITCH
N.O.
N.C.
COM.
COM.
MONITOR
SWITCH
MONITOR
FUSE AND
FUSE HOLDER
N.O.
N.O.
COM.
COM.
GRN
GRN PNK
N.O.
COM.
DOOR SENSING SWITCH
CN-C
CN-E
CN-F
CN-A
PRIMARY
INTERLOCK
RELAY
RY3
RY1
RY9
RY7
CN-F
T1
1
2RED
WHT
3AH. SENSOR HOOD FAN MOTOR
STIRRER MOTOR
GRY
BLK
BLK
BLK
BLK 1
2
GRY-GRY
BRN-BRN
GRY
PNK 1
2
1
2
3
4
5
6
WHT
RED
YLW
BLU
BLK
BLU
YLW
RED
GRY
PPL
1
2
3
4
5
6
BRN
BLK
BLK
BLK
WHT
PNK
GRN
1
2
3
4
5
6
7
RED
BLK
BLU
ORG
CN-B
BLK
WHT
WHT
RED
WHT
BLK
WHT
BLU
GRY
RED
GRY
YLW
B
L
K
RED PPL
PPL
GRN
GRN
1
2
3
4
5
6
7
BLK
PPL
BLU
PNK
8
9BRN
CN-C
3
IC1
N.O. COM.
RY2
RY2:
N.O. COM.
CN-B
CN-G
RY10
RY8
RY6 RY5 RY4
BRN BLK
BLK BLK
YLW
BRN

8
R-1874
6
45
123
6
45
123
A
B
C D E F
G H
A
B
C D E F
G H
Figure S-2. Touch Control Panel Circuit
+
–
+
–
+
–
+
–
A5
A1
A3
B1
B3
B5
B7
C1
C3
C9
C5
C7
F3
G12
G11
G10
G 9
G 8
G 1 G 2 G 3 G 4 G 5 G 6 G 7
F2F1E6E5
Q20 KR A 101M
Q90 KR A101M
VRS1
10G471K
C1 0.1µ/50v
D20D21D22D23D24D25D26D27D28
D32
D31
D65
D29
C2 1000µ/35v
C3 0.1µ/50v
C9
0.1µ/50v
C10 0.1µ/50v
C74 330pF
C73 330pF
C72 330pF
C71 330pF
C70 330pF
C50 C60
C30
D30
DOOR
SWITCH
DAMPE R
SWITCH
AC120V
60Hz
MOTOR RUN
CAPACITOR
TURNTABLE
MOT OR
DAMPE R
MOT OR
CONVECTION
MOT OR
HOOD LAMP
COM
LOW
HIGH
COM
HOOD THE R MO
HOOD MOTOR
OVEN LAMP
MIC R O
CONVECTION
HE R TE R
FAN MOTOR
OVEN
THERMISTOR
AH S E NS OR
(VP )
(VP )
FMIX C ONV
DE F R OS T
SENSOR
ON OFF COOK LBS OZ K G HELP
TURNTABLE
1, 2
31, 32
4
F
P1
IC2 IZA495DR
FLUORESCENT DISPLAY TUBE
KEY UNIT
CUSTOM
HELP
KITCHEN
TIMER
TURNTABLE
ON / OFF
CLOCK
SLOW
COOK
POWER
LEVE L
KEEP
WARM
STOP
CLEAR
START
TOUCH ON
1
100°F
2
150°F
3
275°F
4
300°F
5
325°F
6
350°F
7
375°F
8
400°F
9
425°F
0
450°F
BROIL
SENSOR
REHEAT
MINUTE
PLUS
CONVEC
SENSOR
COOK
COMPU
BROIL
COMPU
ROAST
FAN
HI/LO LIGHT
COMPU
BAKE
POPCORN
PREHEAT LOW MIX
BAKE
HIGH MIX
ROAST
COMPU
DE FR OS T
CONTROL UNIT
1
VRE F
AN7
AN6
AN5
AN4
AN3
AN2
AN1
AN0
P55
P30
P31
P32
P33
P34
P35
P36
P37
P00
P01
P02
P03
P04
P05
P06
P07
P10
P11
P12
P13
P14
P15
P16
P17
P20
P21
P22
P23
P24
P25
P26
P27
P54
P53
P52
P51
P50
P47
P46
P45
P44
P43
P42
P40
P71
P70
XIN
XOUT
VSS
RST
INT1
VCC
VEE
AVS S
12
(A)
(A) (B) (C)
(B)(C)
C4 10µ/35v
+
–
C12
10µ/35v
+–
C65
100µ/16v
C20 10µ/35v
R 30 15k
R 50 15k
R 63 220F R 64 3.6 kF
R 31 4. 7k R 62 36kF
R 51 4. 7k
R 65 1k
C5
IC1 IZA719DR
C21 0.1µ/50v
ZD3 HZ5C2
R 1 4. 3k
1/2w
R 2 1. 5k
R 7 4. 7k
R 40 3. 3k
R 70 3. 3k
R 91 100k
P2 5
6 7 8 9
10 11 12 13 15 16 17 18 19 20 23 22 24 25 26 27 28 29
P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 1G 2G 3G 4G 5G 6G 7G 8G
R 100 330 1w
R 92 100k R 93 100k
R 71 3. 3k R 72 3. 3k R 73 3. 3k R 74 3. 3k
R 78 3. 3k R 82 3. 3k
R79 R80 R81
3.3k 3.3k 3.3k
R 77 3. 3k R 76 3. 3k
D70 D71
D72
D73 D74 D75 D76
R 8 4. 7k
R 75 100k
SP40
C7
C8
C11
R 3 680 1w R 90 100k
NOTE
: IF NOT S P E CIF IE E D, 1/4w ± 5%
: IF NOT SPECIFIEED, 1SS270A
: IF NOT S P E CIF IE E D, 0.01µF/16v
R 4 510 1/2w
Q1 2S B1238
ZD1
HZ6A3
ZD2
HZ16-1
ZD4
HZ4A2
a
2
1
T1
5
6
3D1
D2
D1-D4 : 11E S 1
D3
D4
4
C100
RY4
RY5
RY6
RY7
RY8
RY9
RY10
RY1
RY2
RY3
b
c
d
(J1)
(J2) (J4) (J6) (J3) (J5) (J7)
Q21 KR A 101M
Q22 KR A 101M
Q23 KR A 101M
Q24 KR A 101M
Q26 KR A 101M
Q28 KR A 101M
Q27
KRC243M
Q30
KRA101M
Q60
KRC102M
Q3
KRA101M
Q4
DT A123E S
Q40
KRA101M
CF1 4MHz
Q29 KR A 101M
Q25 KR A 101M
E4E3E2E1
NO
NO
NO
COM
COM
COM
(H)
(N)
