Sharp R-207 User manual

R-207(IN)
R-207(W)
35
TABLE OF CONTENTS Page
CAUTION, MICROWAVE RADIATION............................................................... INSIDE FRONT COVER
WARNING.................................................................................................................................................1
SERVICING ............................................................................................................................................. 2
PRODUCT SPECIFICATIONS .................................................................................................................5
GENERAL INFORMATION.......................................................................................................................5
APPEARANCE VIEW .............................................................................................................................. 6
OPERATION SEQUENCE........................................................................................................................7
FUNCTION OF IMPORTANT COMPONENTS ....................................................................................... 8
TROUBLESHOOTING GUIDE .................................................................................................................9
TEST PROCEDURE.............................................................................................................................. 10
CONTROL PANEL ASSEMBLY ............................................................................................................15
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE.................................................. 18
MICROWAVE MEASUREMENT ........................................................................................................... 23
TEST DATA AT A GLANCE .................................................................................................................. 24
WIRING DIAGRAM................................................................................................................................ 25
PICTORIAL DIAGRAM .......................................................................................................................... 26
CONTROL PANEL CIRCUIT ..................................................................................................................27
PRINTED WIRING BOARD ....................................................................................................................28
PARTS LIST .......................................................................................................................................... 29
S1301R207PHW/
MICROWAVE OVEN
MODELS R-207(IN)
R-207(W)
In interests of user-safety the oven should be restored to its original
condition and only parts identical to those specified should be used.
SERVICE MANUAL
SHARP CORPORATION

36
R-207(IN)
R-207(W)
CAUTION
MICROWAVE RADIATION
Personnel should not be exposed to the microwave energy which may radiate from the
magnetron or other microwave generating devices if it is improperly used or connected.
All input and output microwave connections, waveguides, flanges and gaskets must be
secured.
Never operate the device without a microwave energy absorbing load attached.
Never look into an open waveguide or antenna while the device is energized.
VARNING
MICKROVAGSSTRALING
Personal får inte utsättas för mikrovågsenergi som kan ustrala från magnetronen eller
andre mikrovågsalstrande anordningar om dessa är felanslutna eller används på fel sätt.
Alla in-och utgångsanslutningar för mikrovågor, vagledare, flänsar och packningar måste
vara fast anslutna.
Mikrovågsgeneratorn får inte arbeta utan att absorberande belastning är ansluten. Titta
aldrig in i ën öppen vågledare eller antenn när mikrovågsgeneratorn är påkopplad eller
laddad.
VAROITUS
MIKROAALTOSÄTELYÄ
Käyttäjä ei saa joutua alttiiksi mikroaaltoenergialle, jota voi säteillä magnetronista tai
muusta mikroaaltoja kehittävästä laitteesta, jos sitä käytetään tai jos se kytketään väärin.
Kaikkien mikroaaltoliitäntöjen sekä syöttö-että ulostulopuolella, aaltoputkien laippojen ja
tiivisteiden tulee olla varmistettuja.
Mikroaaltouunnia ei koskaan saa käyttää ilman kuormaa jossa mikroaaltoenergiaa kuluu.
Avoimeen aaltoputkeen tai antenniin ei koskaan saa katsoa virran ollessa kytkettynä.
ADVARSEL
MIKROBØLGESTRÅLING
Personell må ikke utsettes for mikrobølge-energi som kan utståles fra magnetronen eller
andre mikrobølge-generende deler dersom apparatet feilbetjenes eller blir feiltikoplet.
Alle inn-og ut-tilkoplinger i forbindelse med mikrobølge-strålingen, bølgeledere, flenser og
tetningsringer/pakninger må festes ordentlig.
Aldri bruk apparatet med mindre en mikrobålge-absorberende last er plassert i
ovnsrommet.
Aldri se direkte inn i en åpen bølgeleder eller antenne imens apparatet er strømførende.
ADVARSEL
MIKROBØLGEBESTRÄLING
Man bør ikke udsætte sig for mikrobølgebestråling fra magnetronen eller andre
mikrobølgefrembringende anordninger, hvilket kan ske hvis apparatet er forkert tilsluttet
eller bruges forkert. Alle mikrobølgeindgange og-udgange, bølgeledere, flanger og
tætningsstrimler må være forsvarligt udført.
Anvend aldrig ovnen uden en mikrobølgesabsorberende anordning. Se aldrig ind i en
åben bølgeleder eller antenne, mens ovnen er i brug.

R-207(IN)
R-207(W)
1
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained
service engineers.
Removal of the outer wrap gives access to potential above 250V.
All the parts marked "∆" on the parts list may cause undue
microwave exposure, by themselves, or when they are dam-
aged, loosened or removed.
SHARP CORPORATION
OSAKA, JAPAN
SERVICE MANUAL
MICROWAVE OVEN
R-207(IN)/ R-207(W)
GENERAL IMPORTANT INFORMATION
This Manual has been prepared to provide Sharp Corp. Service
engineers with Operation and Service Information.
It is recommended that service engineers carefully study the entire
text of this manual, so they will be qualified to render satisfactory
customer service.
WARNING
Note: Thepartsmarked "*" are used at voltagemore
than 250V. (Parts List)
Anm: Delar märket med "*" har en spänning
överstigande 250V.
Huom: Huolto-ohjeeseen merkitty "tähdella" osat
joissa jännite on yli 250 V.
Bemerk: Deler som er merket "asterisk" er utsatt for
spenninger over 250V til jord.
Bemærk: "Dele mærket med stjerne benyttes med
højere spænding end 250 volt.
SERVICING
PRODUCT SPECIFICATIONS
GENERAL INFORMATION
APPEARANCE VIEW
OPERATING SEQUENCE
FUNCTION OF IMPORTANT
COMPONENTS
TROUBLESHOOTING GUIDE
AND TEST PROCEDURE
TOUCH CONTROL PANEL
COMPONENT REPLACEMENT
AND ADJUSTMENT PROCEDURE
MICROWAVE MEASUREMENT
TEST DATA AT A GLANCE
WIRING DIAGRAM
PARTS LIST

2
R-207(IN)
R-207(W)
REMEMBER TO CHECK 3D
1) Disconnect the supply.
2) Door opened, and wedged open.
3) Discharge high voltage capacitor.
WARNING: AGAINST THE CHARGE OF THE HIGH-
VOLTAGE CAPACITOR
The high-voltage capacitor remains charged about 60 sec-
onds after the oven has been switched off. Wait for 60
seconds and then short-circuit the connection of the high-
voltage capacitor (that is, of the connecting lead of the high-
voltage rectifier) against the chassis with the use of an
insulated screwdriver.
Sharp recommend that wherever possible fault-finding is
carried out with the supply disconnected. It may in, some
cases, be necessary to connect the supply after the outer
case has been removed, in this event carry out 3D checks and
then disconnect the leads to the primary of the power trans-
former. Ensure that these leads remain isolated from other
components and the oven chassis. (Use insulation tape if
necessary.) When the testing is completed carry out 3D
checks and reconnect the leads to the primary of the power
transformer.
SERVICING
WARNING TO SERVICE PERSONNEL
GB Microwave ovens contain circuitry capable of producing very high voltage and current, contact with following parts will
result in electrocution.
High voltage capacitor, Power transformer, Magnetron, High voltage rectifier assembly, High voltage harness.
REMEMBER TO CHECK 4R
1) Reconnect all leads removed from components during
testing.
2) Replace the outer case (cabinet).
3) Reconnect the supply.
4) Run the oven. Check all functions.
Microwave ovens should not be run empty. To test for the
presence of microwave energy within a cavity, place a cup of
cold water on the oven turntable, close the door and set the
power to HIGH and set the microwave timer for two (2) minutes.
When the two minutes has elapsed (timer at zero) carefully
check that the water is now hot. If the water remains cold carry
out 3D checks and re-examine the connections to the compo-
nent being tested.
When all service work is completed, and the oven is fully
assembled, the microwave power output should be checked and
a microwave leakage test should be carried out.
NL Magnetronovens bevatten circuits die een zeer hoge spanning en stroom kunnen voortbrengen. Contact met de
volgende onderdelen kan elektrocutie tot gevolg hebben.
Hoogspanningscondensator, hoogspanningstransformator, magnetron, hoogspanningsgelijkrichter, hoogspannings
kabelboom.
VERGEET DE VOLGENDE 3 STAPPEN NIET
1) Haal de stekker uit het stopcontact.
2) Open de deur en zorg ervoor dat hij niet dicht kan vallen.
3) Ontlaad de hoogspanningscondensator.
PAS OP VOOR DE ELECTRISCHE LADING VAN DE
HOOGSPANNINGSCONDENSATOR
De hoogspanningscondensator blijft nog ongeveer 60
seconden lang opgeladen, nadat de oven is uitgeschakeld.
Wacht 60 seconden voordat u de verbinding van de
hoogspannings-condensator (m.a.w. de verbindingsdraad
van de hoogspanningsgelijkrichter) met een geïsoleerde
schroevedraaier kortsluit tegen het chassis.
Sharp beveelt ten sterkste aan dat, voor zover mogelijk,
defecten worden opgespoord wanneer de stekker uit het
stopcontactisgehaald.Somsishetnodigomdestroomtoevoer
weer tot stand te brengen nadat de buitenmantel verwijderd
is. Herhaal dan de bovengenoemde 3 stappen en haal de
electrische draden uit de primaire zijde van de
vermogenstransformator. Zorg ervoor dat deze draden
geïsoleerd blijven van andere elementen en van het chassis
van de oven. (Gebruik zo nodig isolatieband.) Wanneer de
test is uitgevoerd, herhaalt u de bovenstaande 3 stappen en
verbindt u de electrische draden weer aan de primaire zijde
van de vermogenstransformator.
VERGEET DE VOLGENDE 4 STAPPEN NIET
1) Sluit de draden weer aan diezijn losgehaald voor de test.
2) Plaats de buitenmantel weer om het toestel heen (kabinet).
3) Stop de stekker weer in het stopcontact.
4) Zet de oven aan. Controleer alle functies.
Magnetronovens mogen niet leeg aangezet worden. Om te
controleren of er microgolf-energie binnen de oven wordt
geproduceerd, plaatst u een mok met koud water op de
draaitafel van de oven, sluit de deur, zet de oven op HIGH en
steltde klokvan demagnetronin optwee (2)minuten.Wanneer
de twee minuten voorbij zijn (klok staat op nul), controleert u
voorzichtig of het water heet is. Indien het water nog steeds
koud is, herhaalt u de allereerste drie stappen en controleer
nogmaals de aansluitingen naar de geteste onderdelen.
Wanneer alle reparaties zijn uitgevoerd en de oven weer in
elkaar is gezet, moet de het magnetronvermogen worden
gecontroleerd en moet worden gecontroleerd of er geen
microgolflekkage is.

R-207(IN)
R-207(W)
3
ELos hornos de microondas contienen circuitos eléctricos capaces de producir voltajes de alta tensión y descargas
eléctricas. Para evitar el riesgo de electrocución, absténgase de tocar los siguientes componentes: condensador de alta
tensión, transformador de alta tensión, magnetrón, dispositivo del rectificador de alta tensión y arnés de alta tensión.
RECUERDE LA COMPROBACION 3D
1) Desconecte la alimentación.
2) Deje la puerta abierta y calzada.
3) Descargue el condensador de alto voltaje.
ADVERTENCIA SOBRE LA CARGA DEL
CONDENSADOR DE ALTOVOLTAJE
El condensador de alto voltaje permanece cargado unos
60 segundos después de haber apagado el horno.Espere
60 segundos y luego ponga en cortocircuito la conexión del
condensador de alto voltaje (esto es, del conductor de
conexión del rectificador de alto voltaje) al chasis con un
destornillador de mango aislado.
Se recomienda encarecidamente que siempre que sea
posible la localización de fallos se realice con la alimentación
desconectada. Puede ser que en algunos casos sea
necesario conectar la alimentación después de haber retirado
la carcasa exterior.En este caso, realice las comprobaciones
3D y luego desconecte los conductores del primario del
transformador de alimentación. Asegúrese de que estos
conductores permanezcan aislados de otros componentes y
del chasis del horno. (Use cinta aislante si es necesario).
Cuando termine la prueba efectúe las comprobaciones 3D y
reconecte los conductores al primario del transformador de
alimentación.
RECUERDE LA COMPROBACION 4C
1) Conecte todos los componentes desconectados de los
componentes durante la prueba.
2) Coloque la carcasa exterior (cabina).
3) Conecte la alimentación.
4) Compruebe todas sus funciones despues de poner en
marcha el horno.
Los hornos de microondas no deben funcionar vacíos. Para
comprobar la presencia de energía de microondas dentro de
una cavidad, coloque una taza de agua fría en el plato giratorio
del horno, cierre la puerta y ponga la potencia en HIGH (alta)
y coloque el temporizador en dos (2) minutos. Cuando
transcurran los dos minutos (temporizador a cero) compruebe
cuidadosamente que el agua se ha calentado. Si el agua
permaneciese fría, efectúe las comprobaciones 3D y vuelva a
examinar las conexiones de los componentes que han sido
probados.
Cuando haya terminado la intervención en el equipo y el horno
haya sido ensamblado de nuevo completamente, deberá
comprobar la potencia de salida de microondas y realizar una
prueba de fugas de microondas.
SV Mikrovågsugnar innehåller kretsar som producerar mycket höga spänningar och strömmar.
Kontakt med följande komponenter kan leda till dödsfall:
Högspänningskondensator, transformator, magnetron, högspännings likriktare, högspännings kablage.
KOM IHÅG ATT KONTROLLERA 3 STEG
1) Koppla från strömkällan.
2) Öppna dörren på glänt.
3) Ladda ur högspänningskondensatorn.
VARNING FÖR LADDNINGEN I
HÖGSPÄNNINGSKONDENSATORN
Högspänningskondensatorn är laddad i 60 sekunder efter
det att ugnen stängts av. Vänta 60 sekunder och korislut
sedan kondensatoms anslutning (dvs anslutningen till
högspänningslikriktaren)till chassietmedhjälpavenisolerad
skruvmejsel.
Sharp rekommenderar att felsökning sker med strömmen
fränkopplad. Ibland kan det var nödvändigt att koppla på
strömmen efter det att höljet avlägsnats, utför da 3 Steg
kontrollen och koppla sedan från ledarna till transformatorns
primärsida. Se till att ledarna är isolerade från andra
komponenter och chassiet. (Använd isoleringsband om det
behövs). När Du testat färdigt utför Du 3 Steg kontrollen och
ansluter ledningarna till transformatorns primärsida igen.
KOM IHÅG ATT KONTROLLERA 4 STEG
1) Anslut alla ledningar som använts vid testning
2) Sätt tillbaka ytterhöljet.
3) Anslut strömkällan på nytt.
4) Sätt på ugnen. Kontrollera alla funktioner.
Mikrovågsugnar får inte användas tomma. Kontrollera
mikrovågsstrålningen i olika delar av ugnen genom att placera
en kopp med kallt vatten på ugnens tallrik, stäng dörren, ställ
in HIGH och ställ in 2 minuter på timern. När två minuter har gått
(timem visar 0) kontrollerar du om vattnet är varmt. Om vattnet
fortfarande är kallt utför Du 3 steg kontroller och kontrollerar
anslutningarna till varje enskild komponent på nytt.
När all service är klar och ugnen ihopskruvad skall ugnens
uteffekt och eventuellt mikrovågsläckage kontrolleras.

4
R-207(IN)
R-207(W)
IIforni a microonde contengono un circuito elettrico in grado di generare tensioni e correnti estremamente elevate.
L’eventuale contatto con i seguenti componenti può causare la folgorazione:
condensatore ad alta tensione; trasformatore ad alta tensione; magnetron; rettificatore alta tensione; cablaggio ad
alta tensione.
TRE OPERAZIONI IMPORTANTI PER
INCOMINCIARE
1) Scollegare l'alimentazione elettrica.
2) Verificare che la porta sia bloccata in posizione
aperta.
3) Scaricare il condensatore ad alta tensione.
ATTENZIONE AL CONDENSATORE AD ALTA
TENSIONE: PUO ESSERE CARICO
Il condensatore ad alta tensione rimane carico per circa
60 secondi dopo lo spegnimento del forno.Occorre quindi
spettare 60 secondi prima di cortocircuitare, utilizzando
un cacciavite con impugnatura isolata, il collegamento
del condensatore ad alta tensione (cioè del conduttore
di collegamento del raddrizzatore ad alta tensione) sul
telaio del forno.
Sharp raccomanda, nei limiti del possibile, che la ricerca
dei guasti avvenga in assenza di alimentazione elettrica.
In alcuni casi tuttavia, può essere necessario alimentare
l'apparecchio dopo aver rimosso la scatola esterna. In
questo caso eseguire i tre controlli sopra citati e quindi
scollegare i connettori dal primario del trasformatore.
Assicurarsi che tali connettori non vengano a contatto con
altri componenti, ne con il telaio del forno (fare uso, se
necessario, di nastro isolante). Al termine dell'intervento,
eseguire nuovamente i tre controlli e ricollegare i conduttori
al primario del trasformatore.
QUATTRO VERIFICHE IMPORTANTI DA NON
DIMENTICARE
1) Ricollegare tutti i conduttori staccati dai vari componenti
durante l'intervento.
2) Rimontare la scatola esterna.
3) Ripristinare l'alimentazione elettrica.
4) Rimettere in funzione il forno.Controllare tutte le funzioni.
I forni a microonde non devono mai funzionare a vuoto. Per
verificare la presenza di energia da microonde all'interno
di una cavitá, mettere una tazza di acqua fredda sul piatto
rotante del forno, chiudere la porta, regolare la potenza su
HIGH ed impostate il temporizzatore su due (2) minuti.
Trascorsi i due minuti (temporizzatore a zero), controllare
accuratamente che ora l'acqua sia calda. Se l'acqua è
rimasta fredda, eseguire i tre controlli iniziali e verificare
nuovamente i collegamenti del componente in questione.
Dopo aver portato a termine le operazioni di manutenzione
e rimontato il forno, è necessario controllare la potenza delle
microonde emesse ed eseguire un test per verificare che
non vi sia alcuna dispersione.

R-207(IN)
R-207(W)
5
PRODUCT DESCRIPTION
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption 1.18 kW
Power Output 800 W nominal of RF microwave energy (measured by method of IEC 60705)
Operating fequency 2450 MHz
Case Dimensions Width 460 mm
Height 275 mm including foot
Depth 353 mm
Cooking Cavity Dimensions Width 322 mm
Height 187 mm
Depth 336 mm
Turntable diameter 272 mm
Control Complement Timer (0 - 30 minutes)
Microwave Power for Variable Cooking
Repetition Rate;
800W ...............................Full power throughout the cooking time
560W ................................................. approx. 70% of Full Power
400W ................................................. approx. 50% of Full Power
240W ................................................. approx. 30% of Full Power
80W ................................................... approx. 10% of Full Power
Set Weight Approx. 12 kg
GENERAL INFORMATION
WARNING
THIS APPLIANCE MUST BE EARTHED
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE

6
R-207(IN)
R-207(W)
APPEARANCE VIEW
OVEN
1. Control panel
2. Door opening button
3. Waveguide cover
4. Seal packing
5. Oven cavity
6. Door
7. Door safety latch
CONTROL PANEL
8. Door hinges
9. Door seals and sealing surfaces
10.Oven lamp
11.Ventilation openings
12.Outer case
13.Power cord
Turntable
Roller stay
Seal packing
1. Place the roller stay on the floor of the oven cavity,
engaging shaft into turntable motor shaft.
2. Then place the turntable on the roller stay.
DOOR OPENING BUTTON
MICROWAVE POWER
CONTROL knob
TIMER knob (0 - 30 Min.)
12
11
13
5
10
9
8
764 37
1
2

R-207(IN)
R-207(W)
7
OPERATION SEQUENCE
OFF CONDITION
1. When the timer knob is at " ", the oven is OFF
condition.
2. Closing the oven door activates the monitored latch
switch and the latch switch.
IMPORTANT
When the oven door is closed, the contacts (COM-NC) of
the monitor switch SW2 must be open.
When the microwave oven is plugged in a wall outlet, rated
voltage is supplied to the noise filter and the control unit.
Figure O-1 on page 25
MICROWAVE COOKING CONDITION
HIGH COOKING
Set the Microwave power control knob to 800W and
then set the timer.
Function sequence
Figure O-2 on page 25
1. Following components are energized.
High voltage rectifier High voltage transformer
High voltage capacitor High voltage fuse
Turntable motor Timer motor Fan motor
Magnetron Oven lamp Control unit
CONNECTED COMPONENTS RELAY
High voltage transformer RY1
2. Rated voltage is supplied to the primary winding of the
high voltage transformer T. The voltage is converted to
about 3.3 volts A.C. output on the filament winding and
high voltage of approximately 2000 volts A.C. on the
secondary winding.
3. The filament winding voltage (3.3 volts) heats the
magnetron filament and the high voltage (2000 volts) is
sent to the voltage doubling circuit, where it is doubled
to negative voltage of approximately 4000 volts D.C..
4. The 2450 MHz microwave energy produced in the
magnetron MG generates a wave length of 12.24 cm.
This energy is channelled through the waveguide
(transport channel) into the oven cavity, where the food
is placed to be cooked.
5. When the cooking time is up, the timer returns to " ",
the bell rings and the contacts of the timer switch are
opened. The following components are turned off.
High voltage rectifier High voltage transformer
High voltage capacitor High voltage fuse
Turntable motor Timer motor Fan motor
Magnetron Oven lamp Control unit
6. When the oven door is opened during a cook cycle, the
switches come to the following position and they are
common to the other cooking conditions too.
CONDITION
DURING DOOR OPEN
SWITCH CONTACT COOKING (NOCOOKING)
Monitored latch switch COM-NO Closed Open
Latch switch COM-NO Closed Open
Monitor switch COM-NC Open Closed
The circuits to the high voltage transformer T, turntable
motor TTM, timer motor TM, fan motor FM, oven lamp
OL and control unit are cut off when the contacts
(COM-NO) of the monitored latch switch SW1 and
latch switch SW3 are made open.
The timer stops to indicate how much cooking time
remains.
7. MONITOR SWITCH CIRCUIT
The monitor switch SW2 is mechanically controlled by
oven door, and monitors the operation of the monitored
latch switch SW1.
7-1 When the oven door is opened during or after the
cycle of a cooking program, the monitored latch
switch SW1 and latch switch SW3 must open their
contacts(COM-NO)first.Afterthatthecontacts(COM-
NC) of the monitor switch SW2 can be closed.
7-2. When the oven door is closed, the contacts (COM-
NC) of the monitor switch SW2 must be opened first.
And then the contacts (COM-NO) of the monitored
latch switch SW1 and the latch switch SW3 are
closed.
7-3. When the oven door is opened and the contacts
(COM-NO) of the monitored latch switch SW1 and
contacts of the timer switch remain closed. The fuse
F1 T6.3A will blow, because the monitor switch is
closed and a short circuit is caused.
POWER LEVEL COOKING
When the microwave oven is preset for variable cooking
power, rated voltage is supplied to the high voltage trans-
former intermittently within a 32-second time base through
the relay contact which is coupled with the current-limiting
relay. The following levels of microwave power are given.
SETTING;
NOTE: The ON/OFF time ratio does not exactly corre-
spond to the percentage of microwave power,
because approx. 3 seconds are needed for heat-
ing up the magnetron filament.
POWER OUTPUT REDUCTION
1. If the oven is set for more than 20 minutes at 800W,
after the first 20 minutes the power level will automati-
cally adjust itself to 70% power to avoid overcooking.
2. If the oven is operated for more than 90 minutes
continuously (at any power levels), the relay RY1
opens. And the circuit to the high voltage transformer
will be cut off.
32 sec. ON
Approx. 70%
100%
800W
560W
400W
240W
80W
24 sec. ON 8 sec. OFF
14 sec. OFF
10 sec. OFF
26 sec. OFF
Approx. 50%
18 sec. ON
Approx. 30%
12 sec. ON
Approx. 10%
6 sec. ON

8
R-207(IN)
R-207(W)
DOOR OPEN MECHANISM
The door is opened by pushing the open button on the
control panel, refer to the Figure D-1.
When the open button is pushed, the open button pushes
up the switch lever, and then the switch lever pushes up
the latch head. The latch heads are moved upward and
released from latch hook. Now the door will open.
Figure D-1. Door Open Mechanism
MONITORED LATCH SWITCH SW1 AND LATCH
SWITCH SW3
1. When the oven door is closed, the contacts (COM-NO)
must be closed.
MONITOR SWITCH SW2
1. When the oven door is closed, the contacts (COM-NC)
must be opened.
2. When the oven door is opened, the contacts (COM-
NC) must be closed.
3. If the oven door is opened and he contacts (COM-NO)
of the moniored latch switch SW1 fail to open, the fuse
F1 T6.3A blows immediately after closing the contacts
(COM-NC) of the monitor switch SW2.
CAUTION: BEFORE REPLACING A BLOWN FUSE F1
TEST MONITORED LATCH SWITCH SW1
AND MONITOR SWITCH SW2 FOR
PROPER OPERATION. (REFER TO CHAP-
TER “TEST PROCEDURE”).
FUSE F1 T6.3A
1. The fuse F1 T6.3A blows when the contacts (COM-
NO) of the monitored latch switch SW1 remain closed
with the oven door open and when the contacts (COM-
NC) of the monitor switch SW2 are closes.
2. If the wire harness or electrical components are short-
circuited,thefuse F1 T6.3Ablows to preventanelectric
shock or fire hazard.
HIGH VOLTAGE FUSE F2
The high voltage fuse blows when the high voltage rectifier
or the magnetron is shorted.
TEMPERATURE FUSE TF
The temperature fuse, located on the top of the oven
cavity, is designed to prevent damage to the oven by fire.
FUNCTION OF IMPORTANT COMPONENTS
If the food load is overcooked, by either error in cook time
or defect in the control unit, the temperature fuse will open.
Under normal operation, the temperature fuse remains
closed. However, when abnormally high temperatures are
reached within the oven cavity, the temperature fuse will
open at 248˚F(120˚C), causing the oven to shut down.
TURNTABLE MOTOR TTM
The turntable motor drives the turntable roller assembly to
rotate the turntable.
FAN MOTOR FM
Thefanmotor drives abladewhich draws externalcoolair.
This cool air is directed through the air vents surrounding
the magnetron and cools the magnetron. This air is chan-
nelled through the oven cavity to remove steam and
vapours given off from heating food. It is then exhausted
through the exhausting air vents at the rear of the oven
cavity.
TIMER MOTOR TM
Timer switch
1. When the timer switch is at " " position, the switch of
the timer is opened.
2. When the timer is turned clockwise from " " position,
the switch of the timer is closed.
NOISE FILTER
The noise filter assembly prevents radio frequency inter-
ference that might flow back in the power circuit.
Latch Heads
Latch Hook
Door
SW1:
Monitored
Latch Switch
SW3:
Latch Switch
SW2:
Monitor Switch
Switch Lever

R-207(IN)
R-207(W)
9
TROUBLESHOOTING GUIDE
When troubleshooting the microwave oven, it is helpful
to follow the Sequence of Operation in performing the
checks. Many of the possible causes of trouble will
require that a specific test be performed. These tests
are given a procedure letter which will be found in the
“Test Procedure” section.
IMPORTANT: If the oven becomes inoperative because
of a blown fuse F1 T6.3A in the monitored
latch switch SW1 - timer switch - monitor
switch circuit, check the monitored latch
switch SW1, timer switch and monitor
switch SW2 before replacing the fuse F1
T6.3A.
CK = Check / RE = Replace
MAGNETRON
HIGH VOLTAGE TRANSFORMER
H.V. RECTIFIER ASSEMBLY
HIGH VOLTAGE WIRE
HIGH VOLTAGE CAPACITOR
MONITORED LATCH SWITCH SW1
LATCH SWITCH SW3
MONITOR SWITCH SW2
TEMPERATURE FUSE TF
TIMER MOTOR
TIMER SWITCH
FAN MOTOR
TURNTABLE MOTOR
FUSE F1 T6.3A
CONTROL UNIT
RELAY (RY-1)
FOIL PATERN ON P.W.B.
POWER SUPPLY CORD
SHORTED WIRE HARNESS
OPENED WIRE HARNESS
OVEN LAMP
WALL OUTLET
MISADJUSTMENT SWITCH
HOME FUSE OR BREAKER
BLOCKED COOLING FAN
BLOCKED VENTILATION
NOISE FILTER
H.V. FUSE F2
Home fuse blows when power
supply cord is plugged into
wall outlet.
FUSE F1 T6.3A blows when
power supply cord is plugged
into wall outlet.
Oven does not start when the
timer is set.
Oven lamp does not light
(Other function is normal.)
Fan motor does not operate.
(Other function is normal.)
Turntable motor does not op-
erate. (Other function is nor-
mal.)
Oven or any electrical parts
does not stop.
Oven seems to be operating
butlittle or noheatis produced
in oven load. (Microwave
powerlevel is setat 800W)
Oven does not seems to be
operating properly when
560W, 400W, 240W
or 80W is set. (Oven oper-
ates properly at 800W.)
Oven goes into cook cycle but
shutsdownbeforeendofcook-
ing cycle.
OFF
CONDITION
PROBLEM
CONDITION
POSSIBLE CAUSE
AND
DEFECTIVE PARTS
TEST PROCEDURE
ON
CONDITION
ABC CK D EEEFKKI IGLMNRECKCKRECK CKCKCKCK HJ

10
R-207(IN)
R-207(W)
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
AMAGNETRON TEST
CARRY OUT 3D CHECKS.
Isolate the magnetron from the high voltage circuit by removing all leads connected to the filament
terminal.
To test for an open circuit filament use an ohmmeter to make a continuity test between the magnetron
filament terminals, the meter should show a reading of less than 1 ohm.
To test for a short circuit filament to anode condition, connect ohmmeter between one of the filament
terminals and the case of the magnetron (ground). This test should be indicated an infinite resistance.
If a low or zero resistance reading is obtained then the magnetron should be replaced.
MICROWAVE OUTPUT POWER (IEC60705)
The following test procedure should be carried out with the microwave oven in a fully assembled
condition (outer case fitted). Microwave output power from the magnetron can be measured by IEC
test procedure, i.e. it can be measured by using water load how much it can be absorbed by the water
load. To measure the microwave output power in the microwave oven, the relation of calorie and watt
is used. When P(W) heating works for t(second), approximately P x t/4.187 calorie is generated. On
the other hand, if the temperature of the water with V(ml) rises ∆T (˚C) during this microwave heating
period, the calorie of the water is V x ∆T.
The formula is as follows;
P x t / 4.187 = V x ∆T+ 0.55 x mc (T2-T0)/4.187 P (W) = 4.187 x V x ∆T / t + 0.55 x mc (T2-T0)/t
Our condition for water load is as follows:
Room temperature (T0) ... around 20°CPower supply Voltage.............. Rated voltage
Water load..................................1000 g Initial temperature (T1) ...................... 10±1°C
Heating time.............................. 52 sec. Mass of container (mc) ......................... 330 g
T2............................ Final Temperature P = 80 x ∆T + 0.55 x mc (T2-T0)/52
Measuring condition:
1. Container
The water container must be a cylindrical borosilicate glass vessel having a maximum material
thickness of 3 mm and an outside diameter of approximately 190 mm.
2. Temperature of the oven and vessel
The oven and the empty vessel are at ambient temperature prior to the start of the test.
3. Temperature of the water
The initial temperature of the water is (10±1)˚C.
4. Select the initial and final water temperature so that the maximum difference between the final water
temperature and the ambient temperature is 5˚C.
5. Select stirring devices and measuring instruments in order to minimize addition or removal of heat.
6. The graduation of the thermometer must be scaled by 0.1˚C at minimum and an accurate
thermometer.
7. The water load must be (1000±5) g.
8. “t” is measured while the microwave generator is operating at full power. Magnetron filament heat-
up time is not included.
NOTE: The operation time of the microwave oven is “t + 3” sec. 3 sec. is magnetron filament heat-up
time.
Measuring method:
1. Measure the initial temperature of the water before the water is added to the vessel.
(Example: The initial temperature T1 = 11˚C)
2. Add the 1 litre water to the vessel.
3. Place the load on the centre of the shelf.
4. Operate the microwave oven at HIGH for the temperature of the water rises by a value ∆T of
10 ˚C.
5. Stir the water to equalize temperature throughout the vessel.
6. Measure the final water temperature. (Example: The final temperature T2 = 21°C)
7. Calculate the microwave power output P in watts from above formula.
NEVER TOUCH ANY PART IN THE CIRCUIT WITH YOUR HAND OR AN INSULATED TOOL
WHILE THE OVEN IS IN OPERATION.

R-207(IN)
R-207(W)
11
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
Room temperature ....................... To = 21˚C Initial temperature .................... T1 = 11°C
Temperature after (52 + 3) = 55 sec. ..................................................................... T2 = 21°C
Temperature difference Cold-Warm.................................................................... ∆T1 = 10°C
Measured output power
The equation is “P = 80 x ∆T” ...................................................... P = 80 x 10°C = 800 Watts
JUDGEMENT: The measured output power should be at least ±15 % of the rated output power.
CAUTION: 1°C CORRESPONDS TO 80 WATTS. REPEAT MEASUREMENT IF THE POWER IS
INSUFFICIENT.
Heat up for 55 sec.
BHIGH VOLTAGE TRANSFORMER TEST
WARNING: High voltage and large currents are present at the secondary winding and
filament winding of the high voltage transformer. It is very dangerous to work
near this part when the oven is on. NEVER make any voltage measurements
of the high-voltage circuits, including the magnetron filament.
CARRY OUT 3D CHECKS.
Disconnect the leads to the primary winding of the high voltage transformer. Disconnect the filament
and secondary winding connections from the rest of the HV circuitry. Using an ohmmeter, set on a low
range, it is possible to check the continuity of all three winding. The following readings should be
obtained:- a. Primary winding .......................... 2.7 ohms approximately
b. Secondary winding .................... 205 ohms approximately
c. Filament winding..................................... less than 1 ohm
If the readings obtained are not stated as above, then the high voltage transformer is probably faulty
and should be replaced.
CARRY OUT 4R CHECKS.
CHIGH VOLTAGE RECTIFIER TEST
CARRY OUT 3D CHECKS.
Isolate the high voltage rectifier assembly from the HV circuit. The high voltage rectifier can be tested
using an ohmmeter set to its highest range. Connect the ohmmeter across the terminal of the high
voltage rectifier and note the reading obtained. Reverse the meter leads and note this second reading.
The normal resistance is infinite in one direction and more than 100 kΩin the other direction.
CARRY OUT 4R CHECKS.
NOTE: FOR MEASUREMENT OF THE RESISTANCE OF THE RECTIFIER, THE BATTERIES OF
THE MEASURING INSTRUMENT MUST HAVE A VOLTAGE AT LEAST 6 VOLTS, BECAUSE
OTHERWISE AN INFINITE RESISTANCE MIGHT BE SHOWN IN BOTH DIRECTIONS.
CARRY OUT 3D CHECKS.
A. Isolate the high voltage capacitor from the circuit.
B. Continuity check must be carried out with measuring instrument which is set to the highest
resistance range.
D HIGH VOLTAGE CAPACITOR TEST
1000g
1000g
1000g
T1˚C T2˚C

12
R-207(IN)
R-207(W)
FTEMPERATURE FUSE TEST
CARRY OUT 3D CHECKS.
A continuity check across the temperature fuse terminals should indicate a closed circuit unless the
temperature of the temperature fuse reaches approximately 248˚F(120˚C).
An open temperature fuse indicates overheating of the oven, exchange the temperature fuse and
check inside of oven cavity and for improper setting of cooking time or operation of control unit. Check
for restricted air flow through the vent holes of the oven cavity, especially the cooling fan and air guide.
CARRY OUT 4R CHECKS.
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
C. A normal capacitor shows continuity for a short time (kick) and then a resistance of about 10MΩ
after it has been charged.
D. A short-circuited capacitor shows continuity all the time.
E. An open capacitor constantly shows a resistance about 10 MΩbecause of its internal 10MΩ
resistance.
F. When the internal wire is opened in the high voltage capacitor, the capacitor shows an infinite
resistance.
G. The resistance across all the terminals and the chassis must be infinite when the capacitor is
normal.
If incorrect reading are obtained, the high voltage capacitor must be replaced.
CARRY OUT 4R CHECKS.
ESWITCH TEST
Table: Terminal Connection of Switch
Plunger Operation COM to NO COM to NC
Released Open circuit Short circuit
Depressed Short circuit Open circuit
COM; Common terminal,
NO; Normally open terminal
NC; Normally close terminal
If incorrect readings are obtained, make the necessary switch adjustment or replace the switch.
CARRY OUT 4R CHECKS.
CARRY OUT 3D CHECKS.
Isolate the switch to be tested and using an ohmmeter check between the terminals as described in
the following table.
GBLOWN FUSE F1
CARRY OUT 3D CHECKS.
1. If the fuse F1 is blown, there could be a shorts or grounds in electrical parts or wire harness. Check
them and replace the defective parts or repair the wire harness.
2. If the fuse F1 is blown when the door is opened, check the monitored latch switch SW1, monitor
switch SW2, timer switch and relay RY1.
If the fuse F1 is blown by incorrect door switching replace the defective switch(es) and the fuse F1.
CARRY OUT 4R CHECKS.
CAUTION: Only replace fuse with the correct value replacement.
HNOISE FILTER TEST
CARRY OUT 3D CHECKS.
Disconnect the leads from the terminals of noise filter.
Using an ohmmeter, check between the terminals as described in the following table.

R-207(IN)
R-207(W)
13
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
MEASURING POINTS INDICATION OF OHMMETER
Between N and L Open circuit
Between terminal N and WHITE Short circuit
Between terminal L and RED Short circuit
If incorrect readings are obtained, replace the noise filter unit.
CARRY OUT 4R CHECKS.
IMOTOR WINDING TEST
CARRY OUT 3D CHECKS.
Disconnect the leads from the motor. Using an ohmmeter, check the resistance between the two
terminals as described in the table below.
Table: Resistance of Motor
Motors Resistance
Fan motor Approximately 400 Ω
Turntable motor Approximately 14.8 kΩ
If incorrect readings are obtained, replace the motor.
CARRY OUT 4R CHECKS.
CARRY OUT 3D CHECKS.
If the high voltage fuse is blown, there could be a short in the high voltage rectifier or the magnetron.
Check them and replace the defective parts and the high voltage fuse.
CARRY OUT 4R CHECKS.
CAUTION: ONLY REPLACE HIGH VOLTAGE FUSE WITH THE CORRECT VALUE REPLACEMENT.
JHIGH VOLTAGE FUSE F2 TEST
KTIMER MOTOR TEST
CARRY OUT 3D CHECKS before any of the following timer tests.
TIMER SWITCH- CONTACTS
Disconnect the leads from terminals described at following table. Connect an ohmmeter across
terminals described at following table.
Advance the timer and check that a short circuit reading is obtained on the meter.
Turn the timer back to the zero (0) position and check that an open circuit reading is obtained on the
meter. If these readings are not obtained then replace the timer.
Disconnecting and checking terminals 1 and 2
TIMER - MOTOR
Disconnect the leads from terminals described at following table. Connect an ohmmeter across the
timer motor winding, terminals are described at following table, and check that a reading of resistance
described at following table is indicated.
If this reading is not obtained then the timer is probably defective and should be replaced.
Disconnecting and checking terminals 3 and 4
Resistance of motor winding approximately 22.2 kohms
CARRY OUT 4R CHECKS after any of the above tests.
FUSE
T6.3A
F1:
NL
LINE CROSS CAPACITOR
0.068µ/AC250V
NOISE SUPPRESSION COIL
LINE BYPASS
CAPACITOR
0.0022µ/AC250V
LINE BYPASS
CAPACITOR
0.0022µ/AC250V
NOISE FILTER
WHT RED
M
4
2
3
1

14
R-207(IN)
R-207(W)
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
LCONTROL UNIT TEST
CAUTION: DO NOT TOUCH THE ELECTRICAL PARTS AND THE PRINTED WIRING BOARD TO
PREVENTANELECTRIC SHOCK. BECAUSE THECONTROLUNIT IS “TRANSLESS
CIRCUIT ” AND ALL ELECTRICAL PARTS ARE USED AT A.C. LINE VOLTAGE.
The control unit consists of circuits including semiconductors such as LSI, etc. Therefore, unlike
conventional microwave ovens, proper maintenance can not be performed with only a voltmeter and
ohmmeter. In this service manual, troubleshooting by unit replacement is described according to the
symptoms indicated.
Control unit.
The following symptoms indicate a defective control unit.
a) When rotating the potentiometer, the power level can not be selected.
b) Cooking is not possible.
CARRY OUT 3D CHECKS.
Remove the outer case and check voltage between Pin No. 3 of the 2 pin connector (A) and the
common terminal of the relay RY1 on the control unit with an A.C. voltmeter.
The meter should indicate 230 volts, if not check oven circuit.
Relay Test
Check voltage at the relay coil with a D.C. voltmeter during the microwave cooking operation.
DC. voltage indicated.......... Defective relay.
DC. voltage not indicated.... Check diode which is connected to the relay coil. If diode is good,
control unit is defective.
RELAY SYMBOL OPERATIONAL VOLTAGE CONNECTED COMPONENTS
RY1 Approx. 12.0V D.C. Oven lamp / Turntable motor / Fan motor
RY2 Approx. 11.0V D.C. High voltage transformer
CARRY OUT 4R CHECKS.
N PROCEDURES TO BE TAKEN WHEN THE FOIL PATTERN ON THE PRINTED WIRING
BOARD (PWB) IS OPEN
To protect the electronic circuits, this model is provided with a fine foil pattern added to the input circuit
on the PWB, this foil pattern acts as a fuse. If the foil pattern is open, follow the troubleshooting guide
given below for repair.
Problem: POWER ON.
CARRY OUT 3D CHECKS.
STEPS OCCURRENCE CAUSE OR CORRECTION
1The rated voltage is not applied between Pin Check supply voltage and oven power cord.
No. 3 of the 2 pin connector (A) and the
common terminal of the relay RY1.
2Only pattern at “a” is broken. *Insert jumper wire J1 and solder.
3Pattern at “a” and “b” are broken. *Insert the coil RCILF2003YAZZ between “c” and “d”.
NOTE: *At the time of making these repairs,
make a visual inspection of the varistor.
Check for burned damage. If any abnor-
mal condition is detected, replace the
defective parts.
CARRY OUT 4R CHECKS.
MRELAY TEST
D71
R75
(F1) (J2)
D1
(J1)
a
b
c
d
D70

R-207(IN)
R-207(W)
15
The control unit consists of the following circuits as shown in the control unit circuit.
The principal functions of these circuits and their related signals are explained below.
Control Unit
Control unit consists of LSI, reset circuit, power source circuit, relay circuit and synchronizing signal circuit.
1) Reset Circuit
This circuit generates a signal which resets the LSI to the initial state when power is supplied.
2) Potentiometer Circuit
The circuit makes setting of the power level by variable resistance.
3) Power Source Circuit
This circuit generates voltage necessary in the control unit from the AC line voltage. In addition, the synchronizing
signal is available in order to compose a basic standard time in the clock circuit.
Symbol Voltage Application
VDD +5V LSI(IC-1)
VSS 0V LSI(IC-1)
4) Relay Circuit
To drive the magnetron, fan motor, turntable motor and light the oven lamp.
5) Synchronizing Signal Circuit
The power source synchronizing signal is available in order to compose a basic standard time in the clock circuit.
It accompanies a very small error because it works on commercial frequency.
CONTROL UNIT ASSEMBLY
OUTLINE OF CONTROL UNIT

16
R-207(IN)
R-207(W)
DESCRIPTION OF LSI
The I/O signal of the LSI are detailed in the following table.
Pin No. Signal I/O Description
1VDD IN Power source voltage: 5V.
Connected to 5V.
2VSS IN Power source voltage: 0V.
Connected to 0V.
3XIN IN Internal clock oscillation frequency input setting.
The internal clock frequency is generated by connecting the capacitor and resistor
to XIN.
4XOUT OUT Terminal not used.
5CNVSS IN Connected to VSS through resistor.
6RESET IN Auto clear terminal.
Signal is inputted to reset the LSI to the initial state when power is supplied.
7AIN1 IN Signal coming from potentiometer.
Voltage from potentiometer is converted into the power level by the A/D converter
built into the LSI.
8AIN0 IN Cooking start detection terminal.
When “H” level is inputted to AIN0, cooking starts.
9D3OUT Signal to allow Magnetron high-voltage circuit to be drived.
While the signal (Sqrare Waveform) is
generating from D3, the Magnetron high-
voltage circuit is allowed to be drived.
10 D2 OUT Signal to check the model.
11 D1 OUT Magnetron high-voltage circuit driving signal.
To turn on and off the cook relay (RY1). The
signal holds “L” level during microwave
cooking and “H” level while not cooking. In
other cooking modes (70%, 50%, 30%, 10%)
the signal turns to “H” level and “L” level in
repetition according to the power level.
12 D0 OUT Terminal not used.
13 INT IN Signal to synchronize LSI with commercial power source frequency.
This is basic timing for all real time processing of LSI.
14-16 P12-P10 OUT Terminal not used.
17-20 P03-P00 IN Terminal to change the Models and functions.
ON/OFF time ratio in Mi-
cro cooking
(a. 32second time base)
MICRO ON OFF
COOK
100% 32sec. 0sec.
70% 24sec. 8sec.
50% 18sec. 14sec.
30% 12sec. 20sec.
10% 6sec. 26sec.
20 msec
During cooking
H
L
20 msec
H : 5V
L : 0V

R-207(IN)
R-207(W)
17
SERVICING
As for the sensor-related controls of the touch
control panel, checking them is possible if the
dummy resistor(s) with resistance equal to that
of the controls are used.
(2)Servicing the touch control panel with power
supply from an external power source:
Disconnect the touch control panel completely from
the oven proper, and short both ends of the door
sensing switch (on PWB) of the touch control panel,
which brings about an operational state that is
equivalent to the oven door being closed. Connect
an external power source to the power input termi-
nal of the touch control panel, then it is possible to
check and repair the controls of the touch control
panel; it is also possible to check the sensor-related
controls of the touch control panel by using the
dummy resistor(s).
3. Servicing Tools
Tools required to service the touch control panel as-
sembly.
1) Soldering iron: 30W
(It is recommended to use a soldering iron with a
grounding terminal.)
2) Oscilloscope: Single beam, frequency range: DC -
10MHz type or more advanced model.
3) Others: Hand tools
4. Other Precautions
1) Before turning on the power source of the control
unit, remove the aluminium foil applied for prevent-
ing static electricity.
2) Connect the connector of the key unit to the control
unit being sure that the lead wires are not twisted.
3) After aluminium foil is removed, be careful that
abnormal voltage due to static electricity etc. is not
applied to the input or output terminals.
4) Attach connectors, electrolytic capacitors, etc. to
PWB, making sure that all connections are tight.
5) Be sure to use specified components where high
precision is required.
1. Precautions for Handling Electronic Components
This unit uses CMOS LSI in the integral part of the
circuits. When handling these parts, the following pre-
cautions should be strictly followed. CMOS LSI have
extremely high impedance at its input and output
terminals. For this reason, it is easily influenced by the
surrounding high voltage power source, static electric-
ity charge in clothes, etc., and sometimes it is not fully
protected by the built-in protection circuit.
In order to protect CMOS LSI.
1) When storing and transporting, thoroughly wrap
them in aluminium foil. Also wrap PW boards con-
taining them in aluminium foil.
2) When soldering, ground the technician as shown in
the figure and use grounded soldering iron and
work table.
2. Servicing of Touch Control Panel
We describe the procedures to permit servicing of the
touch control panel of the microwave oven and the
precautions you must take when doing so.
To perform the servicing, power to the touch control
panel is available either from the power line of the oven
itself or from an external power source.
(1)Servicing the touch control panel with power
supply of the oven :
CAUTION:
THE HIGH VOLTAGE TRANSFORMER OF THE
MICROWAVE OVEN IS STILL LIVE DURING
SERVICING AND PRESENTS A HAZARD .
Therefore, when checking the performance of the
touch control panel, put the outer cabinet on the
oven to avoid touching the high voltage trans-
former, or unplug the primary terminal (connector)
of the high voltage transformer to turn it off; the end
of such connector must be insulated with an insulat-
ing tape. After servicing, be sure to replace the
leads to their original locations.
A. On some models, the power supply cord be-
tween the touch control panel and the oven itself
is so short that the two can't be separated.
For those models, check and repair all the
controls (sensor-related ones included) of the
touch control panel while keeping it connected
to the oven.
B. On some models, the power supply cord be-
tween the touch control panel and the oven
proper is so long enough that they may be
separated from each other. For those models,
therefore, it is possible to check and repair the
controls of the touch control panel while keeping
it apart from the oven proper; in this case you
must short both ends of the door sensing switch
(on PWB) of the touch control panel with a
jumper, which brings about an operational state
that is equivalent to the oven door being closed.
approx. 1M ohm

18
R-207(IN)
R-207(W)
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE
WARNING: Avoid possible exposure to microwave energy. Please follow the instructions below
before operating the oven.
1. Disconnect oven from power supply.
2. Make sure that a definite” click” can be heard when
the microwave oven door is unlatched. (Hold the door
in a closed position with one hand, then push the door
open button with the other, this causes the latch leads
to rise, it is then possible to hear a “click’ as the door
switches operate.)
3. Visually check the door and cavity face plate for
damage (dents, cracks, signs of arcing etc.).
Carry out any remedial work that is necessary before
operating the oven.
Do not operate the oven if any of the following conditions
exist;
1. Door does not close firmly.
2. Door hinge, support or latch hook is damaged.
3. The door gasket or seal is damaged.
4. The door is bent or warped.
5. There are defective parts in the door interlock system.
6. There are defective parts in the microwave generat-
ing and transmission assembly.
7. There is visible damage to the oven.
Do not operate the oven:
1. Without the RF gasket (Magnetron).
2. If the wave guide or oven cavity are not intact.
3. If the door is not closed.
4. If the outer case (cabinet) is not fitted.
Please refer to ‘OVEN PARTS, CABINET PARTS, CONTROL PANEL PARTS, DOOR PARTS’, when carrying out any
of the following removal procedures:
WARNING FOR WIRING
To prevent an electric shock, take the following
manners.
1. Before wiring,
1) Disconnect the power supply.
2) Open the door and wedge the door open.
3) Discharge the high voltage capacitor and wait for
60 seconds.
2. Don't let the wire leads touch to the following parts;
1) High voltage parts:
Magnetron, High voltage transformer, High volt-
age capacitor, High voltage rectifier assembly
and High voltage fuse.
2) Hot parts:
Oven lamp, Magnetron, High voltage transformer
and Oven cavity.
3) Sharp edge:
Oven cavity, Waveguide flange, other metallic
plate.
4) Movable parts (to prevent a fault)
Fan blade, Fan motor, Switch, Turntable motor
and Timer motor.
3. Do not catch the wire leads in the outer case cabinet.
4. Insert the positive lock connector certainly until its pin
is locked. And make sure that the wire leads should
not come off even if the wire leads is pulled.
5. To prevent an error function, connect the wire leads
correctly, referring to the Pictorial Diagram.
3) Discharge high voltage capacitor.
REMEMBER TO CHECK 3D
1) Disconnect the supply.
2) Door opened, and wedged open.
To To remove the outer case, procedure as follows.
1. Disconnect the power supply cord.
2. Open the oven door and block it open.
3. Remove the two (2) screws along the right side of the
outer case.
4. Remove the remaining five (5) screws from the rear of
the outer case.
5. Slide the entire outer case back out about 1 inch (3 cm)
to free it from retaining clips on the cavity face plate.
6. Lift entire outer case from the unit.
7. Discharge the H. V. capacitor before curring out any
OUTER CASE REMOVAL
further work.
8. Do not operate the oven with the outer case removed.
NOTE: Step 1, 2 and 7 form the basis of the 3D checks.
CAUTION:1. DISCONNECT OVEN FROM POWER
SUPPLY BEFORE REMOVING OUTER
CASE.
2. DISCHARGE THE HIGH VOLTAGE CA-
PACITOR BEFORE TOUCHING ANY
OVEN COMPONENTS OR WIRING.
