Sharp R-82FBSTM Instruction Manual

900W (IEC 60705)
OPERATION MANUAL
with COOKBOOK
R-82FBSTM
BUILT-IN
COMBINATION
MICROWAVE OVEN
R-82FBSTM Op Man 18/08/2004 09:01 Page A

R-82FBSTM Op Man 18/08/2004 09:01 Page B

1
CONTENTS
YOUR OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SAFETY:
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
OPERATION:
Heating Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
How Your Oven Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Microwave Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Energy Save Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
How to Operate Your Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 - 12
Grill Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Preheating the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Convection Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Dual Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 - 17
Auto Cook / Pizza / Auto Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 - 22
CONVENIENT FUNCTIONS
Auto Minute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Less and More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Information Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
COOKING ADVICE:
Microwave Cooking Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 - 27
Suitable Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Defrosting Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Reheating Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
AFTERCARE:
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 - 33
To Replace the Mains Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 - 62
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
R-82FBSTM Op Man 18/08/2004 09:01 Page 1

2
YOUR OVEN AND ACCESSORIES
17
NOTES:
•The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
•After cooking fatty foods without a cover, always clean the cavity and especially the grill heating elements
thoroughly. These must be dry and free from grease. Built-up grease may overheat and begin to smoke or
catch fire.
•Always operate the oven with the turntable fitted correctly. This promotes thorough, even cooking. A
badly fitted turntable may rattle, may not rotate properly and could cause damage to the oven.
•The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start
the oven. This does not affect cooking performance.
•When you order accessories, please quote both the PART NAME and MODEL NUMBER to your dealer
or SHARP approved service facility. The model number is located at the bottom of the control panel.
ACCESSORIES:
Check to make sure the following accessories are
provided:
17. Turntable 18. High rack 19. Low rack
20. 4 fixing screws (not shown)
•Place the turntable on to the turntable motor
shaft, ensuring it is located firmly.
•To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
•For use of the racks, refer to the grilling, dual
grilling and convection sections on pages
13 to 17.
Never touch the grills when they are hot.
OVEN:
1. Top grill heating element
2. Front trim
3. Oven lamp
4. Control panel
5. Waveguide cover (DO NOT REMOVE)
6. Bottom grill heating element
7. Turntable motor shaft
8. Oven cavity
9. Door seals and sealing surfaces
10. Door opening handle
11. Fixing points (4 points)
12. Ventilation openings
13. Outer cover
14. Rear cabinet
15. Power cord support clips
16. Power cord
19 18
2
10
589 7 6
31
4
16
15 12
11
13
14
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
R-82FBSTM Op Man 18/08/2004 09:01 Page 2

3
CONTROL PANEL
1. DIGITAL DISPLAY
BUTTONS:
2. INFO
3. AUTO COOK
4. AUTO DEFROST
5. PIZZA
6. COOKING MODE
7. CONVECTION (0C)
8. TIME/WEIGHT
9. START/AUTO MINUTE
10. CLOCK SET
11. STOP/CLEAR
12. POWER LEVEL
13. LESS/MORE
DIGITAL DISPLAY
INDICATORS:
1. LESS/MORE
2. INFO
3. TIMER
4. COOKING IN PROGRESS
5. MICROWAVE POWER LEVEL
6. WEIGHT
7. MICROWAVE
8. CONVECTION
9. BOTTOM GRILL
10. TOP GRILL
11. COOK
1
6
11
5 24 378
9
10
13
12
11
2
4
3
5
6
8
7
9
1
10
R-82FBSTM Op Man 18/08/2004 09:01 Page 3

4
IMPORTANT SAFETY INSTRUCTIONS
Pacemaker: If you have a heart pacemaker,
consult your doctor or the pacemaker
manufacturer prior to oven use.
Oven Use:
•The oven is for domestic use only.
•Never operate when empty, except as directed in
the ‘Grill cooking’ section on page 13.
•Do not leave or store anything inside the oven
when not in use.
•Never attempt to use the oven with the door
open. It is important not to force or tamper with
the door safety latches.
•Never operate the oven with any object caught in
the door.
•Do not insert fingers or objects in the holes of the
door latches or air-vent openings as this may
damage the oven and cause an electric shock.
•If water or food drops inside the air vent
openings switch the oven off immediately, unplug
it and call a SHARP approved service facility. (See
page 34).
•Never move the oven while it is operating.
•The door, outer cabinet, oven cavity, turntable,
dishes, accessories and especially the grills will
become very hot during operation. Before
cleaning make sure they are not hot. Care should
be taken to avoid touching these areas. To
prevent burns, always use thick oven gloves.
FIRE: If smoke is observed, switch off
and unplug the appliance and keep the
door closed in order to stifle any flames.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
LIQUIDS: Microwave heating of
beverages can result in delayed eruptive
boiling, therefore care has to be taken
when handling the container. Stir the
liquid prior to and during heating/
reheating, let liquid stand for at least 20
seconds in the oven after cooking.
WARNING: Do not allow children
to use the oven without supervision
until adequate instructions have been
given, so that the child is able to use the
oven in a safe way and understands the
hazards of improper use.
•The waveguide cover
prevents food and grease
from entering the waveguide
area where it could cause
damage.
DO NOT REMOVE THE
WAVEGUIDE COVER.
•Make sure the power supply cord is
undamaged (See “ELECTRICAL
CONNECTION” on page 6).
Do not allow the power supply cord to
run over any hot or sharp surfaces, such
as the hot air vent area at the top rear of
the oven. Any excess cord length must
be secured using the cable clip supplied
in the accessory pack. The clip should be
fixed to the top of the kitchen unit using
the screw provided (see page 5).
•The socket must be readily accessible so that it
can be easily unplugged in an emergency.
•Do not use the oven outdoors.
INSTALLATION
WARNING:
Inspect the Oven:
•Check the oven carefully for damage
before and regularly after installation.
•Make sure the door closes properly,
that it is not misaligned or warped.
•Check the hinges and door safety
latches are not broken or loose.
•Ensure the door seal and sealing
surfaces are not damaged.
•Inspect the oven interior and door for
dents.
IMPORTANT:
If any damage is apparent, do not
operate the oven in any way, until it has
been repaired by a SHARP trained
engineer. (See page 34 for details).
•Remove all packing materials including the
feature sticker (if present). Do not remove the
plastic film from the inside of the oven window
as this protects it from dirt.
R-82FBSTM Op Man 20/08/2004 08:41 Page 4

5
INSTALLATION
INSTALLING THE APPLIANCE
1. Remove all packaging and check carefully for any signs of damage.
2. If fitting the microwave oven above a conventional oven (position A) or a refrigerator (position C)
then you must check the installation instructions for that appliance to determine air intake and
exhaust requirements.
A refrigerator needs a chimney to exhaust warm air from the rear. The installation should be as
shown in fig. 1.
A conventional oven exhausts warm air from the front. The installation should be as shown in fig. 2.
If installing the microwave oven above a conventional oven, the Mylar sheet that is supplied with
the microwave oven should be fitted as shown in fig. 3. This prevents warm air from the microwave
oven from being drawn in by the conventional oven.
3. Fit the appliance into the kitchen cupboard slowly, and without force, until the front frame of the
oven seals against the front opening of the cupboard.
4. Ensure the appliance is stable and not leaning. Ensure that a 5mm gap is kept between the
cupboard door above and the top of the frame (see fig. 4).
5. Fix the oven in position with the screws provided. The fixing points are located on the top and
bottom corners of the oven (see diagram, item 11, on page 2).
6. It is important to ensure that the installation of this product conforms to the instructions in this
operation manual and the conventional oven or refrigerator manufacturer’s installation instructions.
Position A Position B Position C
Conventional
oven
Refrigerator
The microwave oven can be fitted in position A, B or C:
Chimney
Cable clip
Chimney Chimney
Position Niche Size Chimney Gap Between
WD H (min) Cupboard &
Ceiling
A, B + C
562-568 x 550 x 380
45 100
Measurements in (mm)
Microwave
oven
Microwave
oven
Refrigerator Conventional
oven
5 mm
Mylar sheet
Internal width
Service gap
Figure 1 Figure 2
Figure 4 Figure 3
NOTE: Ensure the bottom of the oven is
85 cm or more above the floor.
Cable clip Cable clip
R-82FBSTM Op Man 20/08/2004 08:41 Page 5

6
INSTALLATION
IMPORTANT!
•The fuse from the cut-off plug should be
removed and the plug disposed of in a safe
manner.
•Under no circumstances should the cut-off
plug be inserted into a socket outlet as a
serious electric shock may occur.
•The plug must not be used without the fuse
cover fitted.
•If you have any doubt about your microwave
oven obtain the help of a qualified electrician.
•When replacing the plug please ensure that
you use a BSI or ASTA approved plug to
BS1363, this should be fitted with a brown
coloured 13 amp fuse approved by BSI or
ASTA to BS1362. If you have any doubt about
electrical connection seek the help of a
qualified electrician.
WARNING: THIS APPLIANCE
MUST BE EARTHED
To wire an appropriate plug, follow the wiring
code given in `To replace the mains plug’ on
page 34.
ELECTRICAL CONNECTION.
•Do not allow water to come into contact with
the power supply cord or plug.
•Insert the plug properly into the socket.
•Do not connect other appliances to the same
socket using an adaptor plug.
•If the power supply cord is damaged, it must
be replaced by a SHARP approved service
facility or a similarly qualified person to avoid a
hazard.
•When removing the plug from the socket
always grip the plug, never the cord as this may
damage the power supply cord and the
connections inside the plug.
•If the plug fitted to your oven is a rewireable
type and in the event of the socket outlet in
your home not being compatible with the plug
supplied, remove the plug properly (do not cut
off).
•If the plug fitted to your oven is a non-
rewirable type and in the event of the socket
outlet in your home not being compatible with
the plug supplied, cut-off the mains plug.
•Refit with a suitable type, observing the wiring
code given in `To replace the mains plug’ on
page 34.
•The electrical outlet should be readily accessible so
that the unit can be unplugged easily in an emergency.
•The socket should not be positioned behind the
cupboard.
•The best position is above the cupboard, see (A).
When not connecting the power supply cord to position (A) it
should be removed from the support clips (see diagram, item
15, on page 2) and routed under the oven.
•Connect the appliance to a single phase 230-240V/50Hz
alternating current via a correctly installed earth socket.
The socket must be fused with a 16A fuse.
•If the appliance is to be operated in a non-European
country, the supply voltage, current type and frequency of the appliance indicated on
the rating plate must correspond with the specification of your power supply.
The rating plate can be found on the inside face of the control panel.
•Before installing, tie a piece of string to the power supply cord to facilitate connection to point (A)
when the appliance is being installed.
•When inserting the appliance into the high-sided cupboard, DO NOT crush the power supply cord.
CONNECTING THE APPLIANCE TO THE POWER SUPPLY
(A)
R-82FBSTM Op Man 18/08/2004 09:01 Page 6

7
HEATING CATEGORY
The heating category (a letter A to E) developed
by MAFF (Ministry of Agriculture, Fisheries and
Food) with microwave oven and food
manufacturers indicates the ability of the oven to
heat small quantities of food (up to 500g).
It does not represent the general performance of
the oven.
HOW YOUR OVEN WORKS
Microwaves are energy waves, similar to those
used for TV and radio signals.
Electrical energy is converted into microwave
energy, which is directed into the oven cavity via
a waveguide. To prevent food and grease entering
the wave guide it is protected by the waveguide
cover.
Microwaves cannot pass through metal, because
of this the oven cavity is made of metal and there
is a fine metal mesh on the door.
During cooking the microwaves bounce off the
sides of the oven cavity at random.
Microwaves will pass through certain materials,
such as glass and plastic, to heat the food.
(See ‘Suitable Cookware’ on page 28).
Water, sugar and fat in food absorb microwaves
which cause them to vibrate. This creates heat by
friction, in the same way your hands get warm
when you rub them together.
The outer areas of the food are heated by the
microwave energy, then the heat moves to the
centre by conduction, as it does in conventional
cooking. It is important to turn, rearrange or stir
food to ensure even heating.
Once cooking is complete, the oven
automatically stops producing microwaves.
Standing time is necessary after cooking, as it
enables the heat to disperse equally throughout
the food.
Microwave output power
in Watts (based on
international (IEC 60705)
standard).
600 700 800 900 1000 Watts
OVEN
OUTPUT
POWER
Less heating time required
More heating time required
OVEN
OUTPUT
CATEGORY
Less heating time required
More heating time required
Letter representing the
oven heating category.
Microwave Symbol.
A B C D E
Food packs carry cooking instructions for heating
categories A to E. Follow instructions for the
letter corresponding to the oven’s heating
category. The higher the output power and
heating category of the oven the less heating time
is required as shown opposite.
R-82FBSTM Op Man 18/08/2004 09:01 Page 7

8
MICROWAVE POWER LEVELS
BEFORE OPERATION
Your oven comes pre-set in Energy Save Mode (see page 9 for details).
To operate the oven in Energy Save Mode:
1. Plug in the oven. Nothing will appear on the display at this time.
2. Open the door.
The display will flash:
Close the door.
3. Press the STOP/CLEAR button.
The display will show:
NOTES: In Energy Save Mode, if you do not operate the oven for 3 minutes or more (i.e. after
closing the door, pressing the STOP/CLEAR button, or at the end of cooking), you will
not be able to operate the oven until you open and close the oven door.
When new, the very first time the grills are used, smoke and odour will be given off.
To avoid this happening when food is being cooked, heat the grills without food for approx.
20 minutes. (Please refer to note on page 13.)
Power Level Press the Percentage
POWER
LEVEL button
HIGH x 1 100%
MEDIUM HIGH x 2 70%
MEDIUM x 3 50%
MEDIUM LOW x 4 30%
(Defrost)
LOW x 5 10%
(Defrost)
•Your oven has 5 power levels, as shown
opposite.
•To change the power level for cooking, enter
the cooking time and then press the POWER
LEVEL button.
Power level:
The microwave power level is varied by the
microwave energy switching on and off.
When using power levels other than 100% you
will be able to hear the microwave energy pulsing
on and off as the food cooks or defrosts.
IMPORTANT: The microwave power level will
cook at 100% unless you press the POWER
LEVEL button to the desired setting.
Check the power level:
To check the microwave power level during
cooking, press the POWER LEVEL button. As
long as your finger is pressing the POWER
LEVEL button the power level will be displayed.
The oven continues to count down although the
display will show the power level.
POWER LEVEL
BUTTON
R-82FBSTM Op Man 18/08/2004 09:01 Page 8

9
ENERGY SAVE MODE
Your oven has an Energy Save Mode.
This facility saves electricity when the oven is not
in use.
•If the oven is not used, it will default to Energy
Save Mode after 3 minutes. The display is blank
and the oven cannot be operated.
•To operate the oven, open and then close the
door. “0” will be displayed and the oven is
ready to use.
To cancel Energy Save Mode, set the clock.
(Please refer to page 10.)
To cancel the clock, follow the procedure
opposite. (This will restart Energy Save Mode.)
Notes:
•If you unplug your oven at any stage you will
have to reset the clock to cancel Energy Save
Mode.
•If the clock has been set, cancelling Energy
Save Mode, then your oven has a safety feature
which prevents START/AUTO MINUTE
button from working if the oven has not been
in use for more than 3 minutes. Press the
STOP/CLEAR button or open and close the
door to re-use the oven.
1. Time of day appears on the display.
2. Press the CLOCK SET button once.
4. Press the START/AUTO MINUTE button.
The power will be off and the display will
show nothing.
x1
x1
3. Adjust the display to “0” by rotating the
TIME/WEIGHT knob.
R-82FBSTM Op Man 18/08/2004 09:01 Page 9

10
SETTING THE CLOCK
Your oven has a 12 hour and a 24 hour clock.
•To select the 12 hour clock, press the
CLOCK SET button once.
“12H” will appear on the display.
To set the time of day follow the instructions
opposite.
x1
NOTES:
•Press the STOP/CLEAR button if you make a
mistake during programming.
•To check the time of day during a cooking
process, press the CLOCK SET button and
the time of day will remain on the display as
long as you keep your finger on the button.
This does not affect the cooking process.
•If the clock is set, when cooking is complete,
the display will show the correct time of day.
If the clock has not been set, the display will
only show “.0” when cooking is complete.
•If the electrical power supply to your
microwave oven is interrupted, the display will
intermittently show “.0” after the power is
reinstated. If this occurs during cooking, the
programme will be erased. The time of day will
also be erased.
•When you want to reset the time of day,
follow the opposite example again.
x2
•To select the 24 hour clock, press the
CLOCK SET button twice.
“24H” will appear on the display.
1. Select the clock type required.
2. Enter the hours by turning the
TIME/WEIGHT knob.
3. Press the CLOCK SET button once.
4. Enter the minutes by turning the
TIME/WEIGHT knob.
5. To start the clock, press the CLOCK SET
button once.
x1
x1
R-82FBSTM Op Man 18/08/2004 09:01 Page 10

11
HOW TO OPERATE YOUR OVEN
MANUAL COOKING
•Enter the cooking time and use microwave
power levels 10% to 100% to cook (refer to
page 8).
•Stir or turn the food, where possible, 2 - 3
times during cooking, if required.
•After cooking, cover the food and leave to
stand, if required.
•Refer to the cooking charts in the cookbook
section, pages 37 - 38.
Your oven enables you to cook and defrost food
using the automatic programmes, or to cook and
defrost food manually.
Automatic cooking and defrosting allows you to
cook and defrost using preset programmes
where the timings have been calculated for you,
e.g Auto Cook and Auto Defrost.
Manual cooking and defrosting allows you to
cook/defrost foods and weights which are not
included in the automatic programmes.
The following are examples of manual cooking
and defrosting.
For automatic cooking and defrosting refer to
pages 18 - 22.
Example:
To cook for 2 minutes 30 seconds on 70%
microwave power.
2. Enter the cooking time by turning the
TIME/WEIGHT knob.
3. Input the power level by pressing the
POWER LEVEL button twice.
x2
x1
Starting the oven:
Close the door and press the
START/AUTO MINUTE
button.
Stopping the oven:
If you want to stop the oven
during cooking, press the
STOP/CLEAR button once or
open the oven door.
If you want to cancel the
cooking programme, press the
STOP/CLEAR button twice.
Opening and closing the door:
To open the oven door, pull the door opening
handle.
The display will count down
through the cooking time.
4. Press the START/AUTO MINUTE button
once to start cooking.
1. Select the cooking mode by turning the
COOKING MODE knob to MICROWAVE.
R-82FBSTM Op Man 18/08/2004 09:01 Page 11

12
HOW TO OPERATE YOUR OVEN
NOTES FOR MANUAL COOKING AND
DEFROSTING:
•When the oven starts, the oven lamp will light
and the turntable will rotate clockwise or
anti-clockwise.
•Your oven can be programmed up to 99
minutes, 90 seconds (99.90).
•If the door is opened during cooking/defrosting
to stir or turn over food, the cooking time on
the display stops automatically. The
cooking/defrosting time starts to count down
again when the door is closed and the
START/AUTO MINUTE button is pressed.
•When cooking/defrosting is complete, the time
of day will reappear on the display, if the clock
has been set.
•If you want to know the power level during
cooking, press the POWER LEVEL button.
As long as your finger is touching the button,
the power level will be displayed.
MANUAL DEFROSTING
•Enter the defrosting time and use microwave
power levels 10% or 30% to defrost (refer to
page 8).
•Stir or turn the food, where possible, 2 - 3
times during defrosting.
•After defrosting, cover the food in foil and
leave to stand until thoroughly defrosted.
•Refer to the defrosting chart in the cookbook
section, page 36.
Example:
To defrost for 10 minutes on 30% microwave
power.
2. Enter the defrosting time by turning the
TIME/WEIGHT knob.
3. Input the power level by pressing the
POWER LEVEL button 4 times.
x4
x1
The display will count down
through the defrosting time.
4. Press the START/AUTO MINUTE button
once to start defrosting.
1. Select the cooking mode by turning the
COOKING MODE knob to MICROWAVE.
R-82FBSTM Op Man 18/08/2004 09:01 Page 12

13
GRILL COOKING
x1
The display will count down
through the grilling time.
4. Press the START/AUTO MINUTE button
once to start grilling.
The oven has top and bottom grills which can be
used separately or combined. These have one
power setting only. The grill is assisted by the
turntable which rotates simultaneously to ensure
even browning.
Use the racks for grilling small items of food such
as bacon, gammon and teacakes, turn over
halfway through grilling.
Food can be placed either directly onto the
racks, or into a flan dish/heat-resistant plate on
the high rack.
NOTE: When new, the very first time the
grills are used, smoke and odour will
be given off.
To avoid this happening when food is
being cooked, heat the grills without
food for approx. 20 minutes.
NOTES:
•It is not necessary to preheat the grill before
cooking.
•Follow the recommended grilling times and
procedures in the charts on page 39 of the
cookbook section.
•When browning foods in a deep container,
place on the turntable or low rack.
•After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical
parts. The display may show “NOW
COOLING”.
Grill Mode COOKING MODE
knob position
GRILL-1
(Top Grill)
GRILL-2
(Bottom Grill)
GRILL-3
(Top and
Bottom Grill)
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
Example:
To grill for 20 minutes, using GRILL-3.
2. Enter the grilling time by turning the
TIME/WEIGHT knob.
1. Select the cooking mode by turning the
COOKING MODE knob to GRILL-3.
To select the grill(s) required (Top, Bottom or
Combined), turn the COOKING MODE knob
as shown in the the table below.
R-82FBSTM Op Man 18/08/2004 09:01 Page 13

14
PREHEATING THE OVEN
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
Example:
To preheat the oven to 180ºC.
2. Input the temperature by pressing the
CONVECTION (ºC) button 5 times.
3. Press the START/AUTO MINUTE
button once to start preheating.
4. When the oven reaches 180ºC, the audible
signal will sound and the oven will display
180ºC. Place food in the oven, enter the
desired cooking time and press the
START/AUTO MINUTE button.
NOTES:
•When the oven reaches the desired
temperature, the audible signal will sound and
the temperature will be displayed in ºC.
Do not press the STOP/CLEAR button
after opening and closing the door, as
this will cancel the Convection mode.
•The preheated temperature will be maintained
for approximately 30 minutes.
After this time, preheat will be cancelled.
•During preheating and convection cooking, you
will hear the cooling fan cycling on and off.
This is completely normal and will not affect
the cooking.
•You can check the actual temperature during
preheating by pressing the CONVECTION
(ºC) button.
The temperature will appear on the display.
This will not affect the oven operation.
•If you prefer not to preheat the oven where
recommended in the cookbook section, allow
extra cooking time.
Your oven can be preheated to a desired
temperature prior to convection cooking. 1. Select the cooking mode by turning the
COOKING MODE knob to CONVECTION.
x1
x5
R-82FBSTM Op Man 18/08/2004 09:01 Page 14

15
CONVECTION COOKING
1. Select the cooking mode by turning the
COOKING MODE knob to CONVECTION.
3. Input the temperature by pressing the
CONVECTION (ºC) button 4 times.
4. Press the START/AUTO MINUTE
button once to start cooking.
x1
x4
NOTES:
•Follow convection times and procedures in the
charts and recipes in the cookbook section.
•Food manufacturers instructions are only a
guideline, so cooking times may need to be
adjusted.
•Pressing the CONVECTION (ºC) button
during cooking will display the programmed
temperature. This will not affect the
programme or cooking time.
•Temperature measurements taken whilst the
oven is in convection mode will differ from the
displayed level. This is due to the grill elements
turning on and off in order to regulate the
oven temperature. This will not affect the
cooking results as long as the operation manual
and cookbook are followed correctly.
•After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical
parts. The display may show “NOW COOLING”.
•Heat generated by the oven during convection
cooking may cause the backplate of the oven
to discolour. This is completely normal and will
not affect the performance of the oven.
•This oven is not suitable for baking Yorkshire
Puddings.
•Convection cooking is ideal for roasting and
baking.
•When using the CONVECTION mode all
metal cookware can be used.
(See ‘Suitable Cookware’ on page 28).
Your oven can be programmed to cook with ten
different temperatures by combining the top and
bottom grills with the convection fan. (Please
refer to the notes below.)
The temperatures available in ºC are:
250ºC, 230ºC, 220ºC, 200ºC, 180ºC,
160ºC, 130ºC, 100ºC, 70ºC, 40ºC.
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
Example:
To cook for 20 minutes at 200ºC convection.
The display will count down
through the cooking time.
2. Enter the cooking time by turning the
TIME/WEIGHT knob.
R-82FBSTM Op Man 18/08/2004 09:01 Page 15

16
DUAL COOKING
Dual Cook combines microwave power with
convection or grill.
The combination of microwave power with
convection or grill reduces cooking time and
provides a crisp, brown finish.
There are three Dual Cook modes:
1. Dual-1 - Convection with microwave.
2. Dual-2 - Top grill with microwave.
3. Dual-3 - Bottom grill with microwave.
To select the dual cook mode required, turn the
COOKING MODE knob as shown in the the
table below.
Example for Microwave and Convection:
To cook for 20 minutes using Dual-1, 230ºC,
10% microwave power.
2. Enter the cooking time by turning the
TIME/WEIGHT knob.
The display will count down
through the cooking time.
5. Press the START/AUTO MINUTE button
once to start cooking.
4. Change the power level by pressing the
POWER LEVEL button twice.
3. Change the temperature by pressing the
CONVECTION (ºC) button twice.
WARNING:
The door, outer cabinet, oven cavity,
turntable, dishes, accessories and
especially the grills will become very hot
during operation. To prevent burns,
always use thick oven gloves.
NOTES:
•Dual Cook is preset with 30% microwave
power. If you wish to change the microwave
power level, press the POWER LEVEL
button until the desired power level is shown
on the display.
*You can select power levels 10%, 30%, and
50% for DUAL-1.
*You can select power levels 10%, 30%, 50%,
70% and 100% for DUAL-2 and DUAL-3.
•DUAL-1 is preset with 250ºC convection.
To adjust the convection temperature, press
the CONVECTION (ºC) button.
Dual Cook Mode COOKING MODE
knob position
DUAL-1
(Convection and
Microwave*)
DUAL-2
(Top Grill and
Microwave*)
DUAL-3
(Bottom Grill and
Microwave*)
1. Select the cooking mode by turning the
COOKING MODE knob to DUAL-1.
x1
x2
x2
R-82FBSTM Op Man 18/08/2004 09:01 Page 16

17
DUAL COOKING
NOTES:
•For DUAL-2 and DUAL-3 it is not necessary
to preheat the grill.
•Follow the recommended dual cooking times
and procedures in the charts on pages 40 - 43.
•When browning foods in a deep container,
place on the turntable or low rack.
•Temperature measurements taken whilst the
oven is in convection mode will differ from the
displayed level. This is due to the grill elements
turning on and off in order to regulate the
oven temperature. This will not affect the
cooking results as long as the operation manual
and cook book are followed correctly.
•After cooking is complete the cooling fan will
continue working for a short time to lower the
temperature of the electrical and mechanical
parts. The display may show “NOW
COOLING”.
Example for Microwave and Grill:
To cook for 15 minutes using Dual-2, 50%
microwave power.
WARNING:
The door, outer cabinet, oven cavity,
turntable, dishes, accessories and
especially the grills will become very hot
during operation. To prevent burns,
always use thick oven gloves.
The display will count down
through the cooking time.
5. Press the START/AUTO MINUTE button
once to start cooking.
4. Change the power level by pressing the
POWER LEVEL button 5 times.
x1
x5
2. Enter the cooking time by turning the
TIME/WEIGHT knob.
1. Select the cooking mode by turning the
COOKING MODE knob to DUAL-2.
R-82FBSTM Op Man 18/08/2004 09:01 Page 17

18
AUTO COOK / PIZZA / AUTO DEFROST
NOTE:
You can select the menu by holding down or
pressing the AUTO COOK,PIZZA,AUTO
DEFROST button until the desired menu is
displayed.
AUTO COOK Example:
To cook 0.6kg of Roast Beef from chilled.
2. Enter the weight by turning the
TIME/WEIGHT knob.
AUTO DEFROST Example:
To defrost a 1.2kg Meat Joint.
1. Select the menu required by pressing the
AUTO COOK button once.
The display will count down
through the cooking time.
3. Press the START/AUTO MINUTE button
once to start cooking.
2. Enter the weight by turning the
TIME/WEIGHT knob.
1. Select the menu required by pressing the
AUTO DEFROST button once.
The display will count down
through the cooking time.
3. Press the START/AUTO MINUTE button
once to start defrosting.
WARNING:
The door, outer cabinet, oven cavity,
turntable, dishes, accessories and
especially the grills will become very hot
during operation. To prevent burns,
always use thick oven gloves.
AUTO COOK enables you to cook 12 popular menus from
frozen or chilled. Please refer to the chart on page 19 - 20.
PIZZA enables you to cook pizzas from frozen or chilled.
Please refer to the chart on page 21.
AUTO DEFROST enables you to defrost 3 popular menus.
Please refer to the chart on page 22.
Follow the examples below for details on how to operate these functions.
x1x1
x1 x1
R-82FBSTM Op Man 18/08/2004 09:01 Page 18
Table of contents
Other Sharp Microwave Oven manuals

Sharp
Sharp R-757H User manual

Sharp
Sharp R-254M Instruction Manual

Sharp
Sharp R-830B User manual

Sharp
Sharp R-210A User manual

Sharp
Sharp YC-AS201 User manual

Sharp
Sharp R-600 User manual

Sharp
Sharp KB-6015KK User manual

Sharp
Sharp R-217E Use and care manual

Sharp
Sharp SMC1132CS User manual

Sharp
Sharp R-890SLM User manual

Sharp
Sharp R-340DK User manual

Sharp
Sharp R-405HK User manual

Sharp
Sharp R-742W User manual

Sharp
Sharp r-877h User manual

Sharp
Sharp Carousel R-1512 User manual

Sharp
Sharp R-330E Use and care manual

Sharp
Sharp R-202EK User manual

Sharp
Sharp Carousel R-326FS User manual

Sharp
Sharp R-238A Instruction Manual

Sharp
Sharp R-202EW User manual
