Sharp R-85STM Instruction Manual

900W (IEC 60705)
OPERATION MANUAL
with COOKBOOK
R-85STM
MICROWAVE OVEN
with TOP & BOTTOM GRILLS
and CONVECTION
R-85STM Operation Manual 27/07/2004 08:42 Page A

OPERATION MANUAL
This operation manual contains important information which you
should read carefully before using your microwave oven.
IMPORTANT:
There may be a serious risk to health if this operation manual is
not followed or if the oven is modified so that it operates with the
door open.
If you require any advice or assistance regarding your
Sharp product, please visit our website:
www.sharp.co.uk/customersupport
Customers without Internet access may telephone:
08705 274277 (9am - 5pm)
[phone] (from Ireland)
R-85STM Operation Manual 23/06/2004 15:18 Page B

1
CONTENTS
YOUR OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SAFETY:
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 5
OPERATION:
Heating Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
How Your Oven Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Microwave Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Energy Save Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
How to Operate Your Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 11
Grill Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Preheating the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Convection Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Dual Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 - 16
Instant Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 - 18
Express Cook / Express Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 - 21
CONVENIENT FUNCTIONS
Sequence Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Less and More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Kitchen Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Auto Minute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Information Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
COOKING ADVICE:
Microwave Cooking Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 - 27
Suitable Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Defrosting Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Reheating Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
AFTERCARE:
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 - 33
To Replace the Mains Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 - 62
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
R-85STM Operation Manual 23/06/2004 15:18 Page 1

2
YOUR OVEN AND ACCESSORIES
ACCESSORIES:
Check to make sure the following accessories are
provided:
14. Turntable 15. High rack
16. Low rack
•Place the turntable on to the turntable motor
shaft, ensuring it is located firmly.
•To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
•For use of the racks, refer to the grilling, dual
grilling and oven sections on pages 12 to 16.
Never touch the grills when they are hot.
OVEN:
1. Control panel
2. Oven lamp
3. Door opening button
4. Waveguide cover (DO NOT REMOVE)
5. Bottom grill heating element
6. Turntable motor shaft
7. Oven cavity
8. Door seals and sealing surfaces
9. Door latches
10. Top grill heating element
11. Ventilation openings
12. Outer cabinet
13. Power cord
NOTES:
•The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it
is not damaged.
•After cooking fatty foods without a cover, always clean the cavity and especially the grill heating
elements thoroughly, these must be dry and free from grease. Built-up grease may overheat and
begin to smoke or catch fire.
•Always operate the oven with the turntable fitted correctly. This promotes thorough, even cooking.
A badly fitted turntable may rattle, may not rotate properly and could cause damage to the oven.
•The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you
start the oven. This does not affect cooking performance.
•When you order accessories, please quote both the PART NAME and MODEL NUMBER to
your dealer or SHARP approved service facility. The model number is located at the bottom of the
control panel.
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
11
13 12
14
4789 6 5
10
1516
1
3
2
R-85STM Operation Manual 23/06/2004 15:18 Page 2

3
CONTROL PANEL
1. DIGITAL DISPLAY
KEYS:
2. TIME
3. CONV. (0C)
4. COMBI
5. INSTANT COOK
6. EXPRESS COOK
7. EXPRESS DEFROST
8. LESS/MORE
9. INFO
10. START/AUTO MINUTE
11. STOP/CLEAR
12. KITCHEN TIMER/CLOCK SET
13. WEIGHT UP/DOWN
14. MICRO POWER
15. GRILL
DIGITAL DISPLAY
INDICATORS:
1. LESS/MORE
2. INFO
3. MICROWAVE POWER LEVEL
4. WEIGHT
5. MICROWAVE
6. CONVECTION
7. BOTTOM GRILL
8. TOP GRILL
9. COOK
10. DEFROST
11. AUTO
1
4
11
10
9
3 256
7
8
1
3
4
5
9
10
8
2
6
7
13
12
11
14
15
R-85STM Operation Manual 23/06/2004 15:18 Page 3

4
IMPORTANT SAFETY INSTRUCTIONS
Pacemaker: If you have a heart pacemaker,
consult your doctor or the pacemaker
manufacturer prior to oven use.
Oven Use:
•The oven is for domestic use only.
•Never operate when empty, except as directed
in the ‘Grill cooking’ section on page 12.
•Do not leave or store anything inside the oven
when not in use.
•Never attempt to use the oven with the door
open. It is important not to force or tamper
with the door safety latches.
•Never operate the oven with any object caught
in the door.
•Do not insert fingers or objects in the holes of
the door latches or air-vent openings as this may
damage the oven and cause an electric shock.
•If water or food drops inside the air vent
openings switch the oven off immediately,
unplug it and call a SHARP approved service
facility. (See page 34).
•Never move the oven while it is operating.
•The door, outer cabinet, oven cavity, turntable,
dishes, accessories and especially the grills will
become very hot during operation. Care
should be taken to avoid touching these areas.
To prevent burns, always use thick oven gloves.
Before cleaning make sure they are not hot.
FIRE: If smoke is observed, switch off
and unplug the appliance and keep the
door closed in order to stifle any flames.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
LIQUIDS: Microwave heating of
beverages can result in delayed eruptive
boiling, therefore care has to be taken
when handling the container. Stir the
liquid prior to and during heating/
reheating, let liquid stand for at least 20
seconds in the oven after cooking.
WARNING: Do not allow children
to use the oven without supervision
until adequate instructions have been
given, so that the child is able to use the
oven in a safe way and understands the
hazards of improper use.
INSTALLATION
WARNING:
Inspect the Oven:
•Check the oven carefully for damage
before and regularly after installation.
•Make sure the door closes properly,
that it is not misaligned or warped.
•Check the hinges and door safety
latches are not broken or loose.
•Ensure the door seal and sealing
surfaces are not damaged.
•Inspect the oven interior and door for
dents.
IMPORTANT:
If any damage is apparent, do not
operate the oven in any way, until it has
been repaired by a SHARP trained
engineer. (See page 34 for details).
1. Remove all packing materials including the
feature sticker (if present). Do not remove
the plastic film from the inside of the oven
window as this protects it from dirt. The
waveguide cover prevents food and grease
from entering the
waveguide area where it
could cause damage.
DO NOT REMOVE THE
WAVEGUIDE COVER.
2. The oven door will become hot during
cooking. Place or mount the oven so that the
bottom of the oven is 85cm or more above
the floor. Ensure the surface or mounting
position is strong enough to take the oven
weight, plus the heaviest item likely to be
cooked in the oven.
R-85STM Operation Manual 23/06/2004 15:18 Page 4

5
INSTALLATION
3. The minimum
height of free space
necessary above the
top surface of the
oven is 19cm.
4. Do not place the oven where heat, moisture
or high humidity are generated, (for example,
near or above a conventional oven) or near
combustible materials (for example, curtains).
Do not block or obstruct air vent openings.
Do not place objects on top of the oven.
5. Make sure the power supply cord is
undamaged (See “ELECTRICAL
CONNECTION” opposite).
Do not allow the power supply cord to
run over any hot or sharp surfaces, such
as the hot air vent area at the top rear of
the oven.
6. The socket must be readily accessible so that
it can be easily unplugged in an emergency.
7. Do not use the oven outdoors.
BUILDING-IN-KIT.
An installation frame is available which enables
the microwave oven to be integrated within a
kitchen unit.
The microwave oven is not designed to be built
above or near a conventional oven.
SHARP recommend the use of the build in kit
EBR-47ST, available from your SHARP dealer.
Only the use of this frame will guarantee the
quality and safety of the oven.
ELECTRICAL CONNECTION.
•Do not allow water to come into contact with
the power supply cord or plug.
•Insert the plug properly into the socket.
•Do not connect other appliances to the same
socket using an adaptor plug.
•If the power supply cord is damaged, it must be
replaced by a SHARP approved service facility
or a similarly qualified person to avoid a hazard.
•When removing the plug from the socket
always grip the plug, never the cord as this may
damage the power supply cord and the
connections inside the plug.
•If the plug fitted to your oven is a rewireable
type and in the event of the socket outlet in
your home not being compatible with the plug
supplied, remove the plug properly (do not
cut off).
•If the plug fitted to your oven is a non-
rewirable type and in the event of the socket
outlet in your home not being compatible with
the plug supplied, cut-off the mains plug.
•Refit with a suitable type, observing the wiring
code given in `To replace the mains plug’ on
page 34.
IMPORTANT!
•The fuse from the cut-off plug should be
removed and the plug disposed of in a safe
manner.
•Under no circumstances should the cut-off
plug be inserted into a socket outlet as a
serious electric shock may occur.
•The plug must not be used without the fuse
cover fitted.
•If you have any doubt about your microwave
oven obtain the help of a qualified electrician.
•When replacing the plug please ensure that
you use a BSI or ASTA approved plug to
BS1363, this should be fitted with a brown
coloured 13 amp fuse approved by BSI or
ASTA to BS1362. If you have any doubt about
electrical connection seek the help of a
qualified electrician.
WARNING: THIS APPLIANCE
MUST BE EARTHED
To wire an appropriate plug, follow the wiring
code given in `To replace the mains plug’ on
page 34.
19cm
R-85STM Operation Manual 23/06/2004 15:18 Page 5

6
HEATING CATEGORY
The heating category (a letter A to E) developed
by MAFF (Ministry of Agriculture, Fisheries and
Food) with microwave oven and food
manufacturers indicates the ability of the oven to
heat small quantities of food (up to 500g [1lb
2oz]). It does not represent the general
performance of the oven.
HOW YOUR OVEN WORKS
Microwaves are energy waves, similar to those
used for TV and radio signals.
Electrical energy is converted into microwave
energy, which is directed into the oven cavity via
a waveguide. To prevent food and grease entering
the wave guide it is protected by the waveguide
cover.
Microwaves cannot pass through metal, because
of this the oven cavity is made of metal and there
is a fine metal mesh on the door.
During cooking the microwaves bounce off the
sides of the oven cavity at random.
Microwaves will pass through certain materials,
such as glass and plastic, to heat the food.
(See ‘Suitable Cookware’ on page 28).
Water, sugar and fat in food absorb microwaves
which cause them to vibrate. This creates heat by
friction, in the same way your hands get warm
when you rub them together.
The outer areas of the food are heated by the
microwave energy, then the heat moves to the
centre by conduction, as it does in conventional
cooking. It is important to turn, rearrange or stir
food to ensure even heating.
Once cooking is complete, the oven
automatically stops producing microwaves.
Standing time is necessary after cooking, as it
enables the heat to disperse equally throughout
the food.
Microwave output power
in Watts (based on
international (IEC 60705)
standard).
600 700 800 900 1000 Watts
OVEN
OUTPUT
POWER
Less heating time required
More heating time required
OVEN
OUTPUT
CATEGORY
Less heating time required
More heating time required
Letter representing the
oven heating category.
Microwave Symbol.
A B C D E
Food packs carry cooking instructions for heating
categories A to E. Follow instructions for the
letter corresponding to the oven’s heating
category. The higher the output power and
heating category of the oven the less heating time
is required as shown opposite.
R-85STM Operation Manual 23/06/2004 15:18 Page 6

7
BEFORE OPERATION
Your oven comes pre-set in Energy Save Mode (see page 8 for details).
To operate the oven in Energy Save Mode:
1. Plug in the oven. Nothing will appear on the display at this time.
2. Open the door.
The display will flash:
3. Close the door.
The display will show:
NOTES: In Energy Save Mode, if you do not operate the oven for 3 minutes or more (i.e. after
closing the door, pressing the STOP/CLEAR key, or at the end of cooking), you will not be
able to operate the oven until you open and close the oven door.
When new, the very first time the grills are used, smoke and odour will be given off.
To avoid this happening when food is being cooked, heat the grills without food for approx.
20 minutes. (Please refer to note on page 12.)
MICROWAVE POWER LEVELS
Power Level Press the Percentage
MICRO
POWER key
HIGH x 1 100%
MEDIUM HIGH x 2 70%
MEDIUM x 3 50%
MEDIUM LOW x 4 30%
(Defrost)
LOW x 5 10%
(Defrost)
•Your oven has 5 power levels, as shown
opposite.
•To change the power level for cooking, enter
the cooking time and then press the MICRO
POWER key.
Power level:
The microwave power level is varied by the
microwave energy switching on and off.
When using power levels other than 100% you
will be able to hear the microwave energy pulsing
on and off as the food cooks or defrosts.
IMPORTANT: The microwave power level will
cook at 100% unless you press the MICRO
POWER key to the desired setting.
Check the power level:
To check the microwave power level during
cooking, press the MICRO POWER key.
As long as your finger is pressing the MICRO
POWER key the power level will be displayed.
The oven continues to count down although the
display will show the power level.
MICRO POWER
KEY
R-85STM Operation Manual 23/06/2004 15:18 Page 7

8
ENERGY SAVE MODE
Your oven has an Energy Save Mode.
This facility saves electricity when the oven is not
in use.
•If the oven is not used, it will default to Energy
Save Mode after 3 minutes. The display is blank
and the oven cannot be operated.
•To operate the oven, open and then close the
door. “0” will be displayed and the oven is
ready to use.
To cancel Energy Save Mode, set the clock.
(Please refer to page 9.)
To cancel the clock, follow the procedure
opposite. (This will restart Energy Save Mode.)
Notes:
•If you unplug your oven at any stage you will
have to reset the clock to cancel Energy Save
Mode.
•If the clock has been set, cancelling Energy
Save Mode, then your oven has a safety feature
which prevents INSTANT COOK and
START/AUTO MINUTE key from working
if the oven has not been in use for more than 3
minutes. Press the STOP/CLEAR key or
open and close the door to re-use the oven.
1. Time of day appears on the display.
2. Press the KITCHEN TIMER/CLOCK
SET key 3 times.
3. Press the START/AUTO MINUTE key.
The power will be off and the display will
show nothing.
x3
x1
R-85STM Operation Manual 23/06/2004 15:18 Page 8
