Sharp R210DW User manual

R-21101D(W)
R
MICROWAVE OVEN
Thank you for buying a Sharp Microwave Oven.
Please keep this operation manual handy, as it describes all
the features of your oven and will enable you to cook many
varieties of foods.
The manual is divided into two sections:
1.OPERATION (P2~P12)
This section describes your oven and teaches you how to use
all the features.
2.MANUAL COOKING GUIDES
This section is at the back of the manual, it contains the more
commonly used information such as how to prepare food, which
cooking utensil to use, standing time.
Please take some time to read your operation manual carefully,
paying particular attention to the warnings and special notes,
the automatic cooking menus programmed into your new oven
have been carefully developed to give optimum results when
the step by step instructions are followed.
When selecting another home appliance, please again consider
our full range of Sharp products.
MODEL
CONTENTS Pages
iytnarraW
1gninraW
Special Notes and Warning 2
Oven and Accessories / Installation 3
Control Panel 4
Setting the Clock 5
Microwave Power Level 5
5gnitarepOerofeB
6Microwave Cooking
7Auto Menu Chart Guide
8Other Convenient Functions
Time Defrost and Express Defrost Operation 9
6noitarepOlaunaM
Defrosting Advice 10
11Reheating Advice
12Care and Cleaning
Service Call Check 12
Specifications 12
Manual Chart Guides A-1
Defrost Times for Meat, Poultry and BreadA-1
Fresh Vegetable Chart A-2
Frozen Vegetable Chart A-3
Rice and Pasta Cooking Chart A-3
Scrambled Egg Guide A-3
Notes
Reheating/Defrosting Convenience A-4
Cooking and Utensil Guide A-5
Helpful Hints A-6
Quick Reference Guide A-7

R201T(W) [01-15].indd 1 6/8/10 7:32:07 PM
i
Congratulations on Your Purchase!
This Sharp product is warranted against faults in material and manufacture for the
period as stated in the table below.
Should you need to make a claim against this warranty please take your product back
to the place of purchase.
This warranty does not extend to defects or injuries caused by or resulting from causes
not attributable to faulty parts or the manufacture of the product, including but not
limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of
maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation,
software, or any alterations made to the product which are not authorised by Sharp.
Please retain your sales documentation, as this should be produced to validate a
warranty claim. This warranty is in addition to and in no way limits, varies or excludes
any implied rights and remedies under any relevant legislation in the country of sale.
WARRANTY PERIOD
Microwave Oven 12 months
Small Home Appliances 12 months
IMPORTANT NOTICE: This warranty applies only to products sold in Australia & New Zealand
SHARP CORPORATION OF
AUSTRALIA PTY. LIMITED
ABN 40 003 039 405
1Huntingwood Drive
Huntingwood NSW 2148
SHARP CORPORATION OF
NEW ZEALAND LIMITED
59 Hugo Johnston Drive
Penrose, Auckland
REPLACEMENTWARRANTY
SPform 040 (DECEMBER 2012)
Australian customers: Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure. The criteria of a major failure is defined in the Australian
Consumer Law. Should you require any assistance with a major failure please
contact Sharp Customer Care.
Consumer Electronic Products

IMPORTANT SAFETY INSTRUCTIONS : READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
To reduce the risk of fire in the oven cavity:
a. Do not overcook food.
b. Remove wire twist-ties from paper or plastic bags before placing bag in the oven.
c. Do not heat oil or fat for deep frying. The temperature of the oil cannot be controlled.
d. Look at the oven from time to time when food is heated in disposable containers made of plastic,
paper or other combustible materials for signs of smoke or burning.
e. If materials inside the oven should ignite, or smoke is observed, keep oven door closed, turn oven
off, and disconnect the power plug, or shut off power at the fuse or circuit breaker panel.
To reduce the risk of an explosion or delayed eruptive boiling when handling the container.
Your microwave oven is capable of heating food and beverages very quickly therefore, it is very important
that you select the appropriate cooking time and power level for the type and quantity of food to be
heated. If you are unsure of the cooking time and power level required, begin with low cooking times and
power levels until the food is sufficiently heated evenly throughout.
Additionally:
a. Do not place sealed containers in the oven. Babies bottles fitted with a screw cap or teat are
considered to be sealed containers.
b. Do not use excessive amount of time.
c. When boiling liquids in the oven, use a wide-mouthed container.
d. Stand at least for 20 seconds at the end of cooking to avoid delayed eruptive boiling of liquids.
e. Stir the liquid before and during cooking. Use extreme care when handling the container or inserting
a spoon or other utensil into the container.
This oven is for home food preparation only and should only be used for heating, cooking and defrosting
food and beverage.
It is not suitable for commercial, laboratory use, or heating therapeutic devices eg. Wheat bags.
Never operate the oven whilst any object is caught or jammed between the door and the oven.
Do not try to adjust or repair the oven yourself.
It is hazardous for anyone other than a qualified service technician trained by SHARP to carry out any
service or repair operation. Especially those which involve the removal of a cover which gives protection
against exposure to microwave energy are very hazardous.
Do not operate the oven if it is not working correctly or damaged until it has been repaired by a qualified
service technician trained by SHARP. It is particularly important that the oven door closes properly and
that there is no damage to:
(1) Door (warped), (2) Hinges and Latches (broken or loosened), (3) Door Seals, Sealing Surfaces and
oven cavity (buckled or deformed), (4) Burn marks on the door seal faces.
Do not bump, or catch utensils, loose clothes and your accessories on the door safety latches when
removing food from the oven.
Never poke an object, particularly a metal object, through a grille or between the door and the oven while
the oven is operating.
Never tamper with or deactivate the door safety latches.
Always use oven gloves to prevent burns when handling utensils that are in contact with hot food. Enough
heat from the food can transfer through utensils to cause skin burns.
Should the power supply cord become damaged, it must be replaced with a special cord supplied by a
SERVICE CENTRE APPROVED BY SHARP and it must be replaced by a qualified service technician trained
by SHARP in order to avoid a hazard.
If the oven lamp fails please consult your dealer or a qualified service technician trained by SHARP.
Avoid steam burns by directing steam away from the face and hands.
Slowly lift the furthest edge of a dish's cover including microwave plastic wrap etc., and carefully open
popcorn and oven cooking bags away from the face.
Make sure that the power supply cord is undamaged, and that it does not run under the oven or over any
hot surfaces or sharp edges.
To prevent the turntable from breaking:
a. Before cleaning the turntable with water, leave the turntable to cool.
b. Do not place anything hot on a cold turntable.
c. Do not place anything cold on a hot turntable.
Do not place anything on the outer cabinet.
Do not store food or any other items inside the oven.
Make sure the utensil does not touch the interior walls during cooking.
Only allow children to use the oven without supervision when adequate instructions have been given so
that the child is able to use the oven in a safe way and understands the hazards of improper use.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
WARNING
1

2
T’NODOD
Eggs, fruits,
vegetables,
nuts, seeds,
sausages and
oysters
Puncture egg yolks and whites and
oysters before cooking to prevent
“explosion”.
Pierce skins of potatoes, apples, squash,
hot dogs, sausages and oysters so that
steam escapes.
*
*
Cook eggs in shells. This prevents
“explosion”, which may damage the
oven or injure yourself.
Cook hard/soft boiled eggs.
Overcook oysters.
Dry nuts or seeds in shells.
*
*
*
*
Popcorn Use specially bagged popcorn for the
microwave oven.
Listen while popping corn for the
popping to slow to 1-2 seconds.
*
*
Pop popcorn in regular brown bags or
glass bowls.
Exceed maximum time on popcorn
package.
*
*
Baby food Transfer baby food to small dish and
heat carefully, stirring often. Check for
suitable temperature to prevent burns.
Remove the screw cap and teat before
warming baby bottles. After warming
shake thoroughly. Check for suitable
temperature.
*
*
Heat disposable bottles.
Overheat baby bottles.
Only heat until warm.
Heat bottles with nipples on.
Heat baby food in original jars.
*
*
*
*
General Food with filling should be cut after
heating, to release steam and avoid
burns.
Use a deep bowl when cooking liquids
or cereals to prevent boiling over.
*
*
Heat or cook in closed glass jars or
airtight containers.
Deep fat fry.
Heat or dry wood, herbs, wet papers,
clothes or flowers.
Operate the oven without a load (i.e.
an absorbing material such as food or
water) in the oven cavity.
*
*
*
*
Liquids
(Beverages)
For boiling or cooking liquids see
WARNING on page 2 to prevent
explosion and delayed eruptive
boiling.
dednemmocernahtregnol
roftaeH*
time. See REHEATING-FOOD CHART
on page 8.
*
Canned foods Remove food from can. .snacnielihwdoofkoocrotaeH**
Sausage rolls,
Pies, Christmas
pudding
Cook for the recommended time.
(These foods have high sugar and/or
fat contents.)
fihctacyamyehtsakoocrevO* re.*
Meats Use a microwave proof roasting rack to
collect drained juices.
rofelbatnrut
ehtnoyltceridtaemecalP*
cooking.
*
Utensils Check the utensils are suitable for
MICROWAVE cooking before you use
them.
EVAWORCIMrofslisnetulatemesU*
cooking. Metal reflects microwave
energy and may cause an electrical
discharge known as arcing.
*
Aluminium foil Use to shield food to prevent over
cooking.
Watch for sparking. Reduce foil or keep
clear of cavity walls.
*
*
Use too much.
Shield food close to cavity walls.
Sparking can damage the cavity.
*
*
Browning dish Place a suitable insulator such as a
microwave and heat proof dinner
plate between the turntable and the
browning dish.
emitgnitaeher
pehtdeecxE*
recommended by the manufacturer.
Excessive preheating can cause the
glass turntable to shatter and/or
damage internal parts of the oven.
*
SPECIAL NOTES & WARNING

OVEN
1. Door
2. Door hinges
3. Oven lamp
4. Waveguide cover (DO NOT REMOVE)
5. Control panel
6. Coupling
7. Door latches
8. Oven cavity
9. Door seals and sealing surfaces
10. Door safety latches
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door opening button
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Turntable support (17) Coupling
Place the turntable support in the centre of the oven
oor so that it can freely rotate around the coupling.
Then place the turntable on to the turntable support
so that it locates rmly into the coupling.
To avoid turntable damage, ensure dishes and
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your
dealer or SHARP authorised service agent.
13
12
11
10 89647
12 3
5
14
15. Turntable
(glass)
17. Coupling 16. Turntable
support
SEIROSSECCADNANEVO
3
1. Remove all packing materials from the oven cavity, (do not remove the waveguide cover), and the feature
sticker from the outside of the door, if there is one. Check the unit for any damage, such as a misaligned
door, damaged door seals around the door or dents inside the oven cavity or on the door. If there is any
damage, please do not operate the oven until it has been checked by a SERVICE CENTRE APPROVED BY
SHARP and repaired, if necessary.
2. Accessories provided
1) Turntable 2) Roller stay
3) Operation manual and Cooking guide
4. This oven is designed for countertop or cabinet use as well. It should not be installed in any area where
excessive heat and steam are generated, for example, next to a conventional oven unit. The oven
should be installed so as not to block ventilation openings. Allow a space of at least 10 cm on the top,
5 cm on both sides and at the rear of the oven for adequate air circulation. When installing in a cabinet,
the minimum inside dimension of the cabinet should be 5 mm (W) x 3 5 mm (H) x mm (D). This
oven is not designed for built-in installation.
WARNING: The electrical outlet must be readily accessible so that the unit can be unplugged easily in an
emergency.
5. Neither the manufacturer nor the distributors can accept any liability for damage to the machine or personal
injury for failure to observe the correct electrical connecting procedure.
The A.C. voltage must be single phase 230 – 240V, 50Hz.
6. This appliance must be earthed.
7. Operate the oven from a general purpose domestic outlet.
If a generator is used, do not operate the oven with non-sinusoidal outputs.
INSTALLATION INSTRUCTIONS
42 5 377
3. Ensure
.
hat the coupling is installed.Place the turntable support on the oven floor, then place the
turntable onto the turntable support and coupling, ensuring it is located firmly. Refer to the diagram
ab veo NEVER operate the oven without the turtable.
t

4
1. DIGITAL DISPLAY
2. EXPRESS DEFROST key
3. TIME DEFROST key
4. AUTO MENU keys
Rice & Pasta
Jacket Potato
Pizza
Frozen Vegetables
TEA &
COFFEE
Tea & Coee
Dinner Plate
5. TIME keys
6. POWER LEVEL key:
Press to select microwave power level.
7. WEIGHT keys (up and down)
8. KITCHEN TIMER key
Press to use as a minute timer, or to
programme standing time.
9. SET CLOCK key
10. START/AUTO MINUTE key
11. STOP/CLEAR key
Press to enter time,and keep pressing to
continuously increase time.
Press to increase/decrease weight,and
keep pressing to continuously increase/decrease
weight.
RICE &
PASTA
CONTROL PANEL
EXPRESS
DEFROST
1
2
4
5
11
6
3
89
7
10

5
Your oven has a 24 hour clock mode.
1. Press the SET CLOCK key
2. Press the time keys and enter the current time. Enter the hours by pressing the 10 min. key and enter the
minutes by pressing the 1 min. and 10 sec. keys.
3. Press the SET CLOCK key nish clock setting.
NOTES:
•If the clock is set, when cooking is complete, the display will show the correct time of day. If the clock has not
been set, the display will only show“0:00” when cooking is complete.
•To check the time of day during a cooking process, press SET CLOCK key and the LED will display the time of
ect the cooking process.
•In the process of clock setting, if the STOP/CLEAR key is pressed or if there is no operation within 1 minute,
the oven will go back to the former setting.
•
If the electrical power supply to your microwave oven is interrupted, the display will intermittently show “0:00” - after
the power is reinstated. If this occurs during cooking, the programme will be erased. The time of day will also be erased.
Power Level Press the POWER LEVEL
key
Display
(Percentage)
• Your oven has 11 power levels, as shown.
• To change the power level for cooking, press
the POWER LEVEL key until the display
indicates the desired level. Press the START
key to start the oven.
• To check the power level during cooking,
press the POWER LEVEL key. As long as your
nger is pressing the POWER LEVEL key
the power level will be displayed. The oven
continues to count down although the display
will show the power level.
• If “0P” is selected, the oven will work with the
fan but no power. You can use this level to
remove the odour.
HIGH x1 100P
x2 90P
MEDIUM HIGH x3 80P
x4 70P
MEDIUM x5 60P
x6 50P
MEDIUM LOW
(DEFROST)
x7 40P
x8 30P
LOW x9 20P
x10 10P
x11 0P
Generally the following recommendations apply:
100P/ 90P - (HIGH) used for fast cooking or reheating
e.g. for casseroles, hot beverages, vegetables etc.
80P/ 70P - (MEDIUM HIGH) used for longer cooking of
dense foods such as roast joints, meat loaf and plated
meals, also for sensitive dishes such as sponge cakes.
At this reduced setting, the food will cook evenly
without over cooking at the sides.
60P/ 50P - (MEDIUM) for dense foods which require a
long cooking time when cooked conventionally, e.g.
beef casserole, it is advisable to use this power setting
to ensure the meat will be tender.
40P/ 30P - (MEDIUM LOW) to defrost, select this
power setting, to ensure that the dish defrosts evenly.
This setting is also ideal for simmering rice, pasta,
dumplings and cooking egg custard.
20P/ 10P - (LOW) For gentle defrosting, e.g. cream
or pastry.
ash.
Plug in the oven. The oven display will display: “0:00”, an audible signal will sound once.
This model has a clock function and the oven uses less than 1.0 W in stand by mode.
To set the clock, see below.
BEFORE OPERATION
SETTING THE CLOCK
MICROWAVE POWER LEVEL

ENGLISH
6
Opening the door:
To open the oven door, push the door opening button.
Starting the oven:
Prepare and place food in a suitable container onto the turntable or place directly onto the
turntable. Close the door and press the START/AUTO MINUTE key after selecting the desired
cooking mode.
Once the cooking programme has been set and the START/AUTO MINUTE key is not pressed
in 1 minute, the setting will be cancelled.
The START/AUTO MINUTE key must be pressed to continue cooking if the door is opened during
cient press will be no response.
Use the STOP/CLEAR key to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, press the STOP/CLEAR key twice.
4. To set and to cancel the child lock (refer to page 8).
Your oven can be programmed for up 99 minutes 50 seconds (99.50).
MANUAL COOKING/ MANUAL DEFROSTING
• Enter the cooking time and use microwave power levels 100P to 10P to cook or defrost (refer to page 5).
• Stir or turn the food, where possible, 2 - 3 times during cooking.
• After cooking, cover the food and leave to stand, where recommended.
• After defrosting, cover the food in foil and leave to stand until thoroughly defrosted.
Example:
To cook 2 minutes and 30 seconds on 70% microwave power.
1. Input the power level by pressing
the POWER LEVEL key 4 times
for 70 P.
x4
2. Enter the cooking time by
pressing the 1 min. key
twice and then the 10 sec.
key 3 times.
3. Press the START/AUTO MINUTE key
to start the timer.
(The display will count down through
the set cooking/defrosting time.)
NOTE:
• When the oven starts, the oven lamp will turn on and the turntable will rotate clockwise or anticlockwise.
• If the door is opened during cooking/defrosting to stir or turn over food, the cooking time on the display
stops automatically. The cooking/defrosting time starts to count down again when the door is closed and
the START/AUTO MINUTE key is pressed.
• When cooking/defrosting is complete, the time of day will reappear on the display, if the clock has
been set.
• If you wish to know the power level during cooking, press the POWER LEVEL
IMPORTANT:
• Close the door after cooking / defrosting. Please note that the light will remain on when the door is open.
• If you cook food at 100% power for more than 30 minutes, the power of the oven will automatically reduce
MANUAL OPERATION
BEFORE OPERATION
MICROWAVE COOKING
key and the power level will
be displayed.
This is for safety reasons to remind you to close the door.
to avoid overheating.

7
Notes:
nal temperature will vary according to the initial food temperature. Check food is hot after cooking.
If necessary, you can extend the cooking manually.
• The results when using auto cook depend on variances such as the shape and size of the food and your
ed with the programmed result, please
adjust the cooking time to match your requirement.
Weight/Portion Procedure
White
Rice
Wash the rice until the water runs clear. Place
rice into a large microwave safe glass bowl and
cover with the recommended amount of hot tap
water. Cook uncovered using the Auto Menu
Programme. When the oven beeps, stir the rice
and press START to resume cooking. After
cooking, stand and stir.
Dry
Pasta
Place the pasta into a large microwave safe
glass bowl and cover with the recommended
amount of hot tap water. Cook uncovered using
resume cooking. After cooking, stand and stir.
1, 2, and 3 Potatoes.
1 Potato = Approx 230g
(Initial temp 20ºC)
Please use potatoes with a similar size of
approximately 230g. Pierce each of the
potatoes twice on each side with a fork. Place
the potatoes onto the outer edge of the
turntable. Turn over and rearrange halfway
through cooking. Stand for 2-5 mins in foil
before serving.
1, 2 and 4 slices. 1 piece = 50g.
(Initial temp 5ºC)
Place the pizza pieces onto a 25cm microwave
safe plate in the centre of the turntable. Do not
cover.
0.15kg, 0.35kg and 0.5kg.
(Initial temp -18ºC)
Place vegetables in a large microwave safe
glass bowl. Cover the bowl with plastic wrap
and place onto the turntable. Stir halfway
through cooking and after cooking.
1, 2 and 3 Cups.
1 Cup = Approx 120ml
(Initial temp 5ºC)
Use a microwave safe mug. Place the mug
onto the turntable and stir after heating.
0.25kg, 0.35kg and 0.5kg.
(Initial temp 5ºC)
Use a 25cm microwave safe plate. Place your
dinner plate of food (such as meat, vegetable
and rice/potatoes) in the centre of the turntable.
Stand for 2 minutes before serving.
Auto Menu
Rice &
Pasta
Dinner Plate
Tea and Coffee
Frozen Vegetables
Chilled Pizza
Jacket Potato
Rice 1/2 Cup 1 Cup 2 Cups 4 Cups
Hot Tap
Water 2 Cups 2 1/2 Cups 4 Cups 6 Cups
Pasta 1/2 Cup 1 Cup 2 Cups 4 Cups
Hot Tap
Water 1 1/2 Cups 2 Cups 4 Cups 6 Cups
AUTO MENU CHART GUIDE
ENGLISH
NOITAREPOUNEMOTUA
The AUTO MENU keys automatically work out the correct cooking mode and cook time of the food (details on
auto menu chart guide below). Follow the example below for details on how to operate this function.
Example: To cook two jacket potatoes (0.46kg) by using the AUTO MENU function.
1.
Select the required menu by pressing
the Jacket Potato key once.
x1,
the display will show: 1
2. Press WEIGHT UP/DOWN keys or
continue to press the Jacket Potato
key to choose the required number of
potatoes (up to 3).
x1, display: 2
3. Press the START/AUTO
MINUTE key to start
cooking.
(The display will
count down through
defrosting time)
NOTES:
• The weight or quantity of the food can be input by pressing the WEIGHT UP/DOWN keys until the desired
weight/quantity is displayed. Enter the weight of the food only. Do not include the weight of the container.
A-1
A-2
Rice & Pasta has two menu options. Select A-1 for Rice menus or press the Rice & Pasta key again to
select A-2 for the Pasta menu.
•
the Auto Menu Programme. When the oven
beep, stir the pasta and press START to
taste preferences.

8
OTHER CONVENIENT FUNCTIONS
1. SEQUENCE COOKING
erent stages which can include manual cooking time and
mode and/or time defrost function. Once programmed there is no need to interfere with the cooking operation
as the oven will automatically move onto the next stage. The audible signal will sound once after the first stage.
rst stage.
Note: Auto menu cannot be set as one of the multiple sequences.
Example: If you want to defrost the food for 5 minutes, then cook with 80P microwave power for 7
minutes, the steps are as follows:
1. Press the TIME DEFROST key once, the LED display will show .
2. Enter the cooking time by pressing the 1 min. key 5 times.
3. Input the power level (80P) by pressing the POWER LEVEL key 3 times.
4. Enter the cooking time by pressing the 1 min. key 7 times.
5. Press the START/AUTO MINUTE key once to start cooking.
2. AUTO MINUTE FUNCTION
The START/AUTO MINUTE key allows you to operate the two following functions:
a. Direct start
You can directly start cooking on 100P microwave power level for 1 minute by pressing the AUTO MINUTE key.
b. Extend the cooking time
You can extend the cooking time during manual cooking, time defrost and auto menu operation in multiples of
1 minute if the START/AUTO MINUTE key is pressed while the oven is in operation. When using the weight
START/AUTO MINUTE key.
NOTE: The cooking time may be extended to a maximum of 99 minutes 50 seconds.
3. KITCHEN TIMER FUNCTION :
You can use the kitchen timer for timing where microwave cooking is not involved for example to time boiled
eggs cooked on a conventional hob or to monitor the standing time for cooked/defrosted food.
Example:
To set the timer for 5 minutes.
1. Press the KITCHEN
TIMER key once.
2. Enter the desired time
by pressing the 1 min.
key 5 times.
3. Press the START/
AUTO MINUTE key
to start the timer.
Check the display.
(The display will count down
through the set cooking/
defrosting time.)
When the timer time arrives, the audible signal will sound 5 times and the LED will display the time of day.
You can enter any time up to 99 minutes 50 seconds. To cancel the KITCHEN TIMER whilst counting down, sim-
ply press the STOP/CLEAR key.
NOTE: The KITCHEN TIMER function cannot be used whilst cooking.
4. CHILD LOCK:
Use to prevent unsupervised operation of the oven by children.
a. To set the CHILD LOCK:
Press and hold the STOP/CLEAR key for 3 seconds until a long beep sounds. The display will show:
b. To cancel the CHILD LOCK:
Press and hold the STOP/CLEAR key for 3 seconds until a long beep sounds.
00:00
defrost function, the cooking time cannot be increased by pressing

ENGLISH
9
TIME DEFROST AND EXPRESS DEFROST OPERATION
1. TIME DEFROST
This function quickly defrosts food while enabling you to choose a suitable defrost period, depending on the
food type. Follow the example below for details on how to operate this function. The time range is 0:10 – 99:50.
Example: To defrost the food for 10 minutes.
1. Select the menu required by pressing the TIME
DEFROST key once.
x1, the display will show:
2. Enter the cooking time by
pressing the 10 min. key once.
3. Press the START/AUTO
MINUTE key to start
cooking.
Notes for Time Defrost:
ve times and the LED will display the time of day, if the clock has
been set. If the clock has not been set, the display will only show “0:00” when cooking is complete.
• The preset microwave power level is 30P and can not be changed.
2. EXPRESS DEFROST
The microwave oven is pre-programmed with a time and power level so that the following food is defrosted
Follow the example below for details on how to operate these functions.
Example : To defrost 0.5kg of minced beef using EXPRESS DEFROST.
Place the meat in a shallow microwave oven safe dish or microwave safe defrost rack on the turntable.
1. Select the menu required by pressing
the EXPRESS DEFROST key once.
x1,
the display will show:
2.
Press the START/
AUTO MINUTE key to
start cooking.
(The display will
count down through
defrosting time)
Frozen foods are defrosted from -18°C.
NOTES FOR DEFROST:
• Before freezing foods, ensure food is fresh and of good quality.
at pieces of aluminium foil. This will prevent areas
from becoming warm during defrosting. Ensure the foil does not touch the oven walls.
easily: Pork, beef and chicken. The weight range for this food is 0.5kg.
EXPRESS
00:00
0.5

10
DEFROSTING ADVICE
Rearrange Foods that are placed towards the outside of the dish will defrost quicker than foods
in the centre. It is therefore essential that the food is rearranged up to 4 times during
defrosting.
Move closely packed pieces from the outside to the centre and rearrange over-lapping
areas.
This will ensure that all parts of the food defrosts evenly.
Separate Foods may be stuck together when removed from the freezer. It is important to separate
llets.
Shield Some areas of food being defrosted may become warm. To prevent them becoming
warmer and starting to cook, these areas can be shielded with small pieces of foil, which
ect microwaves, e.g. legs and wings on a chicken.
Stand Standing time is necessary to ensure food is thoroughly defrosted. Defrosting is not
complete once the food is removed from the microwave oven. Food must stand, covered,
for a length of time to ensure the centre has completly defrosted.
Turn over It is essential that all foods are turned over at least 3 - 4 times during defrosting. This is
important to ensure thorough defrosting.
NOTES:
• Remove all packaging and wrapping before defrosting.
• To defrost food, use microwave power levels 30% or 10%.
Defrosting food using your microwave oven is the quickest method of all.
It is a simple proccess but the following instructions are essential to ensure the food is thoroughly defrosted.

11
ECIVDAGNITAEHER
For the reheating of foods, follow the advice and guidelines below to ensure food is thoroughly reheated before
serving.
Plated meals Remove any poultry or meat portions, reheat these separately,
see below.
Place smaller items of food to the centre of the plate, larger and
lm
and reheat on 50%, stir/rearrange halfway through reheating.
NOTE: Ensure the food is thoroughly reheated before serving.
Sliced meat lm and reheat on 50%.
Rearrange at least once to ensure even reheating.
NOTE: Ensure the meat is thoroughly reheated before serving.
Poultry portions Place thickest parts of the portions to the outside of the dish, cover
lm and reheat on 70%.
Turn over halfway through reheating.
NOTE: Ensure the poultry is thoroughly reheated before serving.
Casseroles lm or a suitable lid and reheat
on 50%.
Stir frequently to ensure even reheating.
NOTE: Ensure the food is thoroughly reheated before serving.
To achieve the best results when reheating, select a suitable microwave power level appropriate to the type of
food. e.g. A bowl of vegetables can be reheated using 100%, while a lasagne which contains ingredients that
cannot be stirred, should be reheated using 50%.
NOTES:
• Remove food from foil or metal containers before reheating.
ected by the shape, depth, quantity and temperature of food together with the
size, shape and material of the container.
WARNING:
Never heat liquids in narrow-necked containers, as this could result in the contents erupting from
the container and may cause burns.
• re, special care must be taken when reheating foods with a high sugar or fat content,
e.g. mince pies or Christmas pudding.
re.
• Canned potatoes should not be heated in the microwave oven, follow the manufacturer's instructions on the
can.
WARNING:
The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature
is to be checked before consumption to avoid burns.

Disconnect the power supply cord before cleaning or leave the door open to inactivate the oven.
CLEAN THE OVEN AT REGULAR INTERVALS - Keep the oven clean and remove any food deposits, or it
could lead to deterioration of the surface. This could adversely affect the life of the appliance and possibly
result in a hazardous situation.
Exterior:
The outside may be cleaned with mild soap and warm water, wipe clean with a damp cloth. Avoid the use of
harsh abrasive cleaners. Keep the ventilation openings free of dust.
Door:
Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth to
remove any spills or spatters. Do not use abrasive cleaners.
Touch Control Panel:
Wipe the panel with a cloth dampened slightly with water only.
Do not scrub or use any sort of chemical cleaners. Avoid the use of excess water.
Interior walls:
To clean the interior surfaces, wipe with a soft cloth and warm water. After use wipe the waveguide cover in
the oven with a soft damp cloth to remove any food splashes. Built-up splashes may overheat and begin to
smoke or catch fire. Do not remove the waveguide cover. DO NOT USE A COMMERCIAL OVEN CLEANER,
ABRASIVE OR HARSH CLEANERS AND SCOURING PADS ON ANY PART OF YOUR MICROWAVE OVEN.
NEVER SPRAY OVEN CLEANERS DIRECTLY ONTO ANY PART OF YOUR OVEN.
Avoid using excess water. After cleaning the oven, ensure any water is removed with a soft cloth.
Turntable/Roller Stay:
Wash with mild soapy water and dry thoroughly.
Please check the following before calling for service:
. Place one cup of water (approx. 250 ml) in a glass measure in the oven and close the door securely.
Press the INSTANT COOK/START pad twice.
_______ON_______SEY?noemocpmalnevo
ehtseoD.A
_______ON_______SEY?krownafgniloocehtseoD.B
(Put your hand over the rear ventilation openings.)
_______ON_______SEY?etatorelbat
nrutehtseoD.C
(The turntable can rotate clockwise or counterclockwise. This is quite normal.)
D. After two minutes, did an audible signal sound and COOK indicator go off?
YES _______ NO _______
_______ON_______SEY?tohnevoehtedisniretawehtsI.E
If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE CENTRE
APPROVED BY SHARP.
zH05,V042–032es
ahpelgniSegatloVeniLCA
deriuqeRrewoPCA
)erudecorptsetCEI(*W750rewoPtuptuO
**)2puorG/BssalC(z
HM0542ycneuqerFevaworciM
)DxHxW(snoisnemiDedistuO
mm552
thgieW
* When tested in accordance with AS/NZS 2895.1:2007
** This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the International
Standard CISPR11.
12
SPECIFICATIONS
SERVICE CALL CHECK
CARE AND CLEANING
Turntable
1270W
10.5kg
4 0XXXX
X X
25 3
1
25mm94

A-1
DEFROST TIMES FOR MEAT, POULTRY AND BREAD
MANUAL CHART GUIDES
1. Remove wrapping and place frozen item on a shallow, Microwave safe plastic defrost
rack. If necessary, shield thin areas with aluminum foil to prevent the item from cooking
while defrosting
2. Defrost by following the steps in the “Microwave Time” column.
3. Set the microwave to 30% power.
4. When turning over, re-shield any warm areas so it continues to defrost without cooking
CUT MICROWAVE TIME
BEEF (Roast)
Steaks
Minced Beef
8-10 minutes/500g
9-11 minutes/500g
11-13 minutes/500g
PORK (Roast)
Chops
Ribs
Minced Pork
8-10 minutes/500g
9-11 minutes/500g
8-10 minutes/500g
11-13 minutes/500g
LAMB (Roast)
Shoulder
Chops
7-9 minutes/500g
7-9 minutes/500g
9-11 minutes/500g
POULTRY
Chicken (Whole)
Pieces
8-10 minutes/500g
11-13 minutes/500g
BREAD / PIES MICROWAVE TIME PROCEDURE
2 Slices of Bread 50 seconds Place between paper towel and place directly
on the turntable.
4 Slices of Bread 1 minute 30 seconds
1 Bread Roll 1 minute 30 seconds
2 Bread Rolls 3 minutes
5. Stand food in foil until defrosted.

FRESH VEGETABLE CHART
MANUAL CHART GUIDES
A-2
1. Cover required dishes with plastic wrap or a lid.
2. Drain any remaining water after standing before serving.
Vegetable Amount Microwave Time
at 100% Cooking Procedure
Asparagus (halved) 500g 4-6 minutes Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes
Beans
(top and tailed)
500g 5-7 minutes Place in a shallow microwave safe dish. Cover.
Broccoli
(uniform florets)
500g 7-9 minutes Stand for 3 minutes.
Brussels Sprouts 500g 6-8 minutes
Cabbage
(shredded)
500g 6-8 minutes
Carrots
(sliced)
500g 8-10 minutes
Cauliflower
(uniform florets)
500g 8-10 minutes
Corn on the Cob 2 whole cobs,
each cut into
quarters
8-10 minutes Rinse corn under cold water and remove the silk
and husk. Cut into quarters. Place all 8 pieces of
corn into a shallow microwave safe dish. Cover.
Mushrooms
(quartered)
500g 6-8 minutes Place in a shallow casserole dish with 2
tablespoons of butter. Cover. Stand for 3 minutes
Peas (green; top
and tailed)
500g 5-7 minutes
Potatoes – Jacket 3 Large
(230g each)
12-14 minutes Pierce with a fork. Turn over during cooking. Stand
for 3 minutes.
Potatoes – Baked 4 small 7-9 minutes Peel and quarter potatoes. Cook in a dish with ⅓
cup water. Cook covered. Stand for 3 minutes.
Pumpkin
(2cm cubes)
500g 7-9 minutes Place in a shallow casserole dish. Cover. Stand for
3 minutes
Spinach (shredded) 500g 7-9 minutes
Snow Peas
(top and tailed)
0g 2-3 minutes
Squash (whole) 500g 5-7 minutes
Sweet Potato (2cm
cubes)
500g 9-11 minutes
Zucchini (sliced or
quartered)
500g 5-7 minutes
25
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.
Place in a shallow microwave safe dish. Cover.
Stand for 3 minutes.

FROZEN VEGETABLE CHART
MANUAL CHART GUIDES
A-3
1. Place vegetables in a medium/large microwave safe bowl and cover with plastic wrap.
2. Halfway through cooking, stir the vegetables to ensure even cooking.
3. Allow to stand for 2 minutes before draining any water and serving.
Vegetable Weight Microwave Time (100%) Special Procedures
Beans (green, cut) 500g 10-12 minutes
Broccoli 500g 10-12 minutes Break apart as soon as
possible. Arrange with
flower towards the
centre.
Carrots (whole) 500g 10-12 minutes Stir halfway through.
Cauliflower 500g 11-12 minutes Break apart as soon as
possible. Arrange with
flower towards the
centre.
Corn on the Cob 4 pieces 10-11 minutes
Peas (green) 500g 9-10 minutes
Spinach 250g 7-9 minutes Break apart as soon as
possible.
Mixed Vegetables
(i.e. carrots, beans
and corn kernels)
500g 10-12 minutes Break apart as soon as
possible.
1. Wash and strain rice before measuring amounts.
2. Place rice/pasta in a medium/large microwave safe bowl with water. Cook uncovered,
stirring halfway through cooking. Allow to stand for 2 minutes before straining any
remaining water and serving.
Food Other Ingredients Cooking Time
Pasta 1 Cup 2 cups Hot Water 16-18 minutes
2 Cups 4 cups Hot Water 18-20 minutes
4 Cups 6 cups Hot Water 22-24 minutes
White Rice 1 Cup 2 ½ cups Hot Water 20-22 minutes
2 Cups 4 cups Hot Water 22-24 minutes
4 Cups 6 cups Hot Water 26-28 minutes
Quick Oats 1 Cup 2 ¼ cups Milk 9-10 minutes
Place butter, eggs and milk in a small/medium microwave safe bowl. Beat with a fork until well
combined and yolks of eggs are completely stirred in. Cook uncovered, stirring halfway through
cooking.
Egg(s) Butter Milk Cooking Medium High (70%)
1 1 tsp 1 tbsp 2 minutes
2 2 tsp 1 tbsp 3 minutes
3 1 tbsp 2 tbsp 4 minutes
4 1 tbsp ¼ cup 5 minutes 30 seconds
RICE AND PASTA COOKING CHART
SCRAMBLED EGG GUIDE

MANUAL CHART GUIDES
A-4
REHEATING/DEFROSTING CONVENIENCE - FOOD CHART
FOOD WEIGHT COOKING TIME AND POWEL LEVEL SPECIAL INSTRUCTIONS STANDING TIME
Beverage (room temp.) 250mL per cup
1 cup
2 cups
1-1 ½ minutes on HIGH (100%) 2-2 ½ minutes on HIGH (100%)
Stir after heating. _
Canned Food (room temp.) (e.g. Spaghetti, Baked Beans)
1 cup
2 cups
3 ½ minutes on MEDIUM (50%) 8 ½ minutes on MEDIUM (50%)
Place food in bowl. Cover with plastic wrap and pierce 5 times with a skewer. Stir halfway.
1-3 minutes
Canned Soup (room temp) 250mL per cup (thin soup)
1 cup
2 cups
1 ½ - 2 minutes on HIGH (100%) 4 minutes on HIGH (100%)
Place food in bowl. Cover with plastic wrap or lid. Stir halfway.
_
Meat Pie (refrigerated) Individual 180g each
1 pie
4 pies
6 minutes on MEDIUM (50%) 12 minutes on MEDIUM (50%)
Place directly on turntable, face side down. Cover with paper towel. Turn over halfway.
3 minutes
Frozen Rice/Pasta Dinners (e.g. Lasange, Risotto)
300-500g
8-10 minutes on HIGH (100%) Remove from foil container. Cover with
plastic wrap or lid. Allow to stand
2 minutes
Dinner Plate (refrigerated) 350g-400g per serve
1 serve 4-5 minutes on HIGH (100%) Slice potato. Cover plate with plastic
wrap and pierce 5 times with a skewer. Place directly on turntable. Allow to stand.
5 minutes
Casserole (refrigerated) 250g per serve
1 serve
2 serves
5 minutes on HIGH (100%) 8 minutes on HIGH (100%)
Place in a bowl, cover with plastic wrap. Place directly on turntable. Stir halfway. Allow to stand, then stir.
1-3 minutes
Croissants (frozen) 1
2
1 ½ minutes on MEDIUM LOW (30%) 2 minutes on MEDIUM LOW (30%)
Place between paper towels. Place directly on the turntable.
_
Fruit Pie individual (frozen) 135g each
1 2
5 minutes on MEDIUM LOW (30%) 7 minutes on MEDIUM LOW (30%)
Remove from foil container. Place on a plate and then onto the turntable. Allow to stand.
2 minutes
Danish Pastry whole (frozen)
400g 6 minutes on MEDIUM HIGH (70%) followed by
6 ½ minutes on MEDIUM LOW (30%)
Remove from foil container. Place on dinner plate. Allow to stand.
2 minutes
NOTE: Room Temperature +20ºC Refrigerator Temperature +3ºC Frozen Temperature -18ºC

GLASSWARE/CERAMIC (HEAT RESISTANT) METAL COOKWARE PLASTIC WRAP/ OVEN BAGS ALUMINIUM FOIL STRAW AND WOOD PAPER
PLASTIC COOKWARE MICROWAVE SAFE
BROWNING DISH
THERMOMETERS
•
MICROWAVE SAFE
•
CONVENTIONAL
GLASSWARE • Ordinary glass is not suitable for cooking but may be used for short periods for heating foods. CERAMIC • Most ovenproof china, and ceramics, are suited. • Avoid dishes that are decorated with gold or silver leaf. • Avoid using antique pottery. • If unsure, check with the manufacturer. • Metal cookware should be avoided when cooking in the microwave oven. • Microwave energy is reflected by metal.
• Plastic wrap can be used to cover food. • Some shrinkage of the wrap may occur, over an extended cooking time. • When removing wrap, lift it in such a way to avoid steam burns. • Do not tie oven bags with metal twist ties, substitute with string.
• For cooking food with high fat content, do not bring the wrap in contact with the food as it may melt.
• Small amounts may be used to shield certain parts of meat and fish when cooking or defrosting. • Remove food in foil trays, if possible, and place in a microwave safe dish. • If not possible, place the foil tray onto a heat proof plate allowing 2.5 cm between the walls of the oven. • Excessive over heating of these materials may cause a fire in the microwave oven. • Paper towels and waxed paper are suitable to use to prevent splatters. • These are suitable for use when reheating foods or for short cooking times.
• Ideal for cooking, reheating and defrosting. • Some microwave safe plastic cookware are not suitable for cooking foods with high fat and sugar content.
• Ensure that the preheating time of the dish is not exceeded. • Ensure that a microwave heat proof dinner plate or suitable insulator be placed between the turntable and the browning
dish.
YES
NO
YES
FOR
SHIELDING
NO
YES YES YES YES
NO
MICROWAVE SAFE ONLY
Advice
Use
Utensil
( )
COOKING AND UTENSIL GUIDE
A-5

1. THE ARRANGEMENT Arrange foods carefully. Place thickest areas toward outside of dish. 3. COVERING
Cover foods in the microwave if you would normally cover the food in
your ordinary oven, or to retain moisture. Cover foods such as Vegetables, Casseroles, or when Reheating.
Use to cover foods: 5. SHIELDING Shield using small pieces of aluminium foil to shield thin areas of meat, fish
and poultry or edges of cakes to prevent overcooking.
7. STIRRING Stir foods from the outside to the centre of the dish, once or twice during
cooking if possible.
Eg. Casseroles and Sauces. 9. DENSITY The depth to which microwaves penetrate food varies depending on the
food's density. Porous foods like minced beef or mashed potatoes microwave faster than dense ones like steak or whole potatoes.
11. STARTING TEMPERATURE Frozen or refrigerated foods take longer to heat than food at room temperature.
Cooking times in this book are based on normal storage temperatures. Since rooms, refrigerators and freezers differ in temperature, check cooking result at the minimum time.
13. CONDENSATION
Condensation is a normal part of microwave cooking. The humidity and
moisture in food will influence the amount of condensation in the oven. Generally, covered foods will not cause as much condensation as uncovered foods. Ensure that the ventilation openings are not blocked.
TOMATO EGG
LEWOTREPAPDIL PLASTIC WRAP
FISH CHICKEN
2. TURNING
Foods such as poultry and joints of meat should be turned over after half the cooking time.
4. PIERCING Pierce potatoes, eggs, tomatoes or any foods with a skin or membrane to
allow steam to escape.
6. STANDING TIME Standing time is important. After cooking or defrosting ensure adequate
standing time. This allows the food to continue cooking or heating. Refer to cooking guides for each menu or according to manufacturers instructions.
8. SIZE Small pieces cook faster than large ones. To speed up cooking, cut pieces
smaller than 5 cm so microwaves can penetrate to the centre from all sides. For even cooking, make all the pieces the same size.
10. FAT AND BONE Marbling within meat, or a thin, even layer of fat on a roast, speeds cooking.
Large fatty areas or excess drippings in dish attract energy away from meat, and slows cooking. Centre bones do not affect cooking, but bone on the side of meat conducts heat to the areas next to it.
12. QUANTITY Microwave cooking times are directly related to the amount of food in the
oven. Because energy is absorbed by the food itself, one potato or a single piece of chicken cooks rapidly. When the energy is divided among several items, cooking takes more time.
14. GENERAL Your microwave oven is capable of heating food and beverages very quickly
therefore, it is very important that you select the appropriate cooking time and power level for the type and quantity of food to be heated. If you are unsure of the cooking time and power level required, begin with low cooking times and power levels until the food is sufficiently heated evenly throughout.
A-6
HELPFUL HINTS
