Sharp R-1340R User manual

5合1純蒸氣焗爐
5-IN-1 PURE STEAM OVEN
使用說明書 OPERATION MANUAL
R-1340R
使用前，請仔細閱讀說明書並妥善保存。
READ THE MANUAL CAREFULLY BEFORE USING THE APPLIANCE AND KEEP IT PROPERLY FOR FUTURE REFERENCE.

CONTENTS
Contents E-1
Precautions E-2
Specifications E-2
Important Safety Instructions E-3
Cleaning and Care E-7
Oven and Accessories E-8
Installation E-9
Before First Use E-10
Control Panel E-11
Clock Setting E-11
Cooking Chart E-12
Steam Cooking Mode E-13
• Steam Instruction E-13
• Pure Steam E-14
• Steam & Convection E-15
• Steam & Microwave E-16
microwavemanual_r11.indd 2 6/22/16 5:27 pm

CONTENTS
Contents E-1
Precautions E-2
Specifications E-2
Important Safety Instructions E-3
Cleaning and Care E-7
Oven and Accessories E-8
Installation E-9
Before First Use E-10
Control Panel E-11
Clock Setting E-11
Cooking Chart E-12
Steam Cooking Mode E-13
• Steam Instruction E-13
• Pure Steam E-14
• Steam & Convection E-15
• Steam & Microwave E-16
Convection Cooking Mode ....................................................... E-17
• Convection ..................................................................... E-17
• Convection & Microwave ................................................ E-18
Grill Cooking Mode ................................................................... E-19
• Grill ................................................................................ E-19
• Grill Fan .......................................................................... E-20
• Grill & Microwave ........................................................... E-21
• Grill Fan & Microwave ..................................................... E-22
Fermentation Mode .................................................................. E-23
Microwave Cooking Mode ........................................................ E-24
• Microwave Power Chart ................................................. E-25
Auto Cooking Mode ................................................................. E-26
• Auto Menu Chart ........................................................... E-27
Preheating Mode ...................................................................... E-30
Defrost Mode ........................................................................... E-31
Descale Mode .......................................................................... E-32
Child Lock ................................................................................ E-33
Trouble Shooting ...................................................................... E-34
E-1
English

PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
Do not use the oven with the door open.
WARNING: If the oven door or door seals are damaged, the oven must not be used until it has been repaired by a qualified technician.
If the product is not cleaned regularly, the appliance surface will be degraded to affect the appliance service life and danger may occur. Liquids and other food must not be heated in sealed containers since they are liable to explode.
It is hazardous for anyone except for a qualified technician to disassemble, repair or modify the oven.
Model: R-1340R
Rated Voltage 220-230V~50Hz Rated Input Power (Maximum) 2750W
Rated Input Power (Microwave) 1550W Oven Capacity 34L
Rated Output Power (Microwave) 900W Outside Dimensions (W x H x D) 501 x 418 x 526* mm
Rated Output Power (Grill) 1200W Cavity Dimensions (W x H x D) 405 x 210 x 385 mm
Rated Input Power (Convection) 1750W Weight ~34kg
Rated Input Power (Steam) 1500W Color Red
* Does not include door handle
E-2

PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS
SPECIFICATIONS
Do not use the oven with the door open.
WARNING:
WARNING
To reduce the risk of fire, electric shock or injury to persons. Please follow the precautions and the following safety instructions:
1. WARNING: Liquids and other food must not be heated in sealed containers since they are liable to explode.
2. WARNING: It is hazardous for anyone except for a qualified technician to disassemble, repair or modify the oven.
3. This appliance cannot be used by children and they should be supervised to ensure that they do not play with the appliance.
4. This appliance cannot be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless
this person can use the oven safely under supervision and guidance.
5. Keep the appliance and its cord out of reach of children.
6. Utensils should be checked to ensure that they are suitable for use in each cooking mode.
7. The oven should be cleaned regularly to prevent the air inlet and outlet from being blocked by foreign matter and dust.
8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9. If smoke is observed, switch off or unplug the appliance and keep the oven door closed. Steam from the oven may cause burns.
10. Do not overcook food, they may catch fire.
11. Do not use the oven cavity for storage purpose.
12. Remove wire twist-ties and metal handles from paper or plastic containers/ bags before placing them in the oven.
Model: R-1340R
Rated Voltage 220-230V~50Hz Rated Input Power (Maximum)
Rated Input Power (Microwave) 1550W Oven Capacity 34L
Rated Output Power (Microwave) 900W Outside Dimensions (W x H x D)
Rated Output Power (Grill) 1200W Cavity Dimensions (W x H x D)
Rated Input Power (Convection) 1750W Weight
Rated Input Power (Steam) 1500W Color Red
* Does not include door handle
E-3
English

IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS
13. Install or locate this oven only in accordance with the installation instructions provided.
14. Eggs with shell and whole hard-boiled eggs should not be heated in oven since they may explode.
15. This appliance is for household use only.
16. If the power supply cord is damaged, do not use the product. Please call SHARP service center for repair.
17. Do not store or use this appliance outdoors.
18. Do not put the product at a damp place, e.g. near a gas stove, electrified area or sink.
19. The oven surface, air outlet and oven cavity may become very hot during and after use. Do not touch these parts; otherwise you maybe
scalded.
20. Do not let cord hang over edge of table or counter.
21. If the product is not cleaned regularly, the appliance surface will be degraded to affect the appliance service life and danger may occur.
22. After you use a milk bottle or heat baby food, you should check the temperature before feeding to avoid hurt.
23. Heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
24. WARNING: Accessible parts may become hot during use. Children should be kept away.
25. Do not use steam cleaner.
26. The oven door, outer cabinet and oven cavity will become hot during use, please do not touch.
E-4

IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS
13. Install or locate this oven only in accordance with the installation instructions provided.
14. Eggs with shell and whole hard-boiled eggs should not be heated in oven since they may explode.
15. This appliance is for household use only.
16. If the power supply cord is damaged, do not use the product. Please call SHARP service center for repair.
17. Do not store or use this appliance outdoors.
18. Do not put the product at a damp place, e.g. near a gas stove, electrified area or sink.
19.
scalded.
20. Do not let cord hang over edge of table or counter.
21. If the product is not cleaned regularly, the appliance surface will be degraded to affect the appliance service life and danger may occur.
22. After you use a milk bottle or heat baby food, you should check the temperature before feeding to avoid hurt.
23. Heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
24. WARNING: Accessible parts may become hot during use. Children should be kept away.
25. Do not use steam cleaner.
26. The oven door, outer cabinet and oven cavity will become hot during use, please do not touch.
27. Use the cooking thermometers to measure the temperature of food.
28. The oven is for household used only. It must not be placed in a cabinet.
29. The oven is used for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth
may lead to the risk of injury or ignition.
30. After cooking and the oven has cooled, remove and empty the water tank, wipe oven cavity with a soft cloth or sponge. Wait a few
minutes, empty the drip tray.
31. Do not immerse the appliance in water or other liquid when cleaning.
32. Put a teaspoon in the container when heating beverages. This will ensure that the liquid does not boil suddenly after being removed from
the oven cavity.
E-5
English

IMPORTANT SAFETY INSTRUCTIONS CLEANING AND CARE
33. DANGER: Electric Shock Hazard. Touching the internal components can cause serious personal injury or death. Do not disassemble this
appliance.
34. WARNING: Do not open the oven with your face close to the oven. Steam from the oven may cause burns.
35. WARNING: Electric Shock Hazard. Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is
properly installed and grounded.
36. The oven must be grounded before use. In case of electric leakage, the ground can provide a current loop to avoid electric shock. The power
supply plug must be inserted into a single-phase bipolar socket with grounding.
37. Consult a qualified technician if you do not understand the grounding instructions.
E-6

IMPORTANT SAFETY INSTRUCTIONS CLEANING AND CARE
33. DANGER:
appliance.
34. WARNING: Do not open the oven with your face close to the oven. Steam from the oven may cause burns.
35. WARNING:
properly installed and grounded.
36.
supply plug must be inserted into a single-phase bipolar socket with grounding.
37. Consult a qualified technician if you do not understand the grounding instructions.
Remove the power supply plug.
1. Clean the cavity of the oven with a slightly moist cloth.
2. Clean the accessories in soapy water.
3. The door frame and seal and other parts must be cleaned carefully with a moist cloth when they are dirty.
4. Do not use a corrosive cleaning agent; otherwise it will damage or corrode the product.
5. Place half a lemon in a bowl, add 300ml water and heat on 900W microwave power for 10 minutes. Wipe the oven clean using a soft, dry
cloth.
E-7
English

OVEN AND ACCESSORIES
1. Control panel
2. Display
3. Heating tube
4. Oven light
5. Door glass
6. Convection fan
7. Steam inlet and outlet
8. Water tank
9. Drip tray
10. Grill rack
(Do not use when
microwave cooking)
11. Glass tray
1
3
4
5
6
7
8
9
10
11
2
INSTALLATION
E-8

OVEN AND ACCESSORIES
1. Control panel
2. Display
3. Heating tube
4. Oven light
5. Door glass
6.
7.
8. Water tank
9. Drip tray
10. Grill rack
11. Glass tray
INSTALLATION
BEFORE INSTALLATION
Remove all packing materials and accessories. Check the oven for any
damage such as broken door. Do not install if oven is damaged.
Do not remove the light brown Mica cover attached to the oven
cavity to protect the magnetron.
1. Select a flat surface that provide enough space for good ventilation.
(a) Place at a position more than 85cm above the ground.
(b) Place against the back wall. Reserve a gap not less than 20cm
from the right and left wall. And leave at least 30cm space
above the oven.
(c) Do not remove the legs at the bottom of the oven.
(d) Do not block the air inlet and outlet.
(e) Place the oven as far away from radios and TV as possible.
Operations of oven may cause interference to your radio or
TV reception.
2. Plug your oven into a standard household outlet. Be sure the
voltage and the frequency is same as rating label.
WARNING: Do not install the oven at a damp place or
near heat-producing appliance e.g. near a gas stove,
electrified area or sink. The oven surface will become
very hot during use. Please do not touch.
20cm
0cm
20cm
min 85cm
30cm
E-9
English

BEFORE FIRST USE CONTROL PANEL
INITIAL CLEANING AND HEATING
• Remove all accessories
• Ventilate the room
• Press “ “ to choose the convection mode “ “ .
• Press “ “ to select temperature at 230˚C.
• Press “ “ and “ “ to heat the empty oven for 1 hour.
• Touch “ “ to start.
• After finished, wipe the oven cavity with a moist cloth.
E-10

BEFORE FIRST USE CONTROL PANEL
INITIAL CLEANING AND HEATING
• Remove all accessories
• Ventilate the room
• Press “ “ to choose the convection mode “ “ .
• Press “ “ to select temperature at 230˚C.
• Press “ “ and “ “ to heat the empty oven for 1 hour.
• Touch “ “ to start.
• After finished, wipe the oven cavity with a moist cloth.
CLOCK SETTING
1. Press “ “ and hold for 3 seconds to set the clock.
2. Press “ “ or “ “ to set the time (between 00:00 and 23:59).
3. After you have set the time, press “ “ to finish setting.
E-11
English

COOKING CHART
Cooking Mode Preheat Temperature / Power Time Range
Pure Steam N 50 - 100˚C 90 mins
Steam & Convection N Steam: L1 - L4
Convection: 180 - 220˚C 90 mins
Steam & Microwave N Steam: 80 - 100˚C
Microwave: 100 - 300W 90 mins
Convection Y*1 50 - 230˚C 5 hours
Convection & Microwave Y*1 Convection: 50 - 230˚C
Microwave: 100 - 700W 90 mins
Grill N 1 - 3 90 mins
Grill Fan Y*1 35 - 180˚C 5 hours
Grill & Microwave N Grill: 1 - 3
Microwave: 100 - 700W 90 mins
Grill Fan & Microwave Y Grill fan: 100 - 180˚C
Microwave: 100 - 700W 90 mins
Microwave N 100 - 900W 90 mins*2
*¹ Preheat is not available if the temperature is set at 50˚C or below
*2If the microwave power set at 900W, the maximum cooking time is 30 minutes
STEAM COOKING MODE
Before starting the steam cooking mode, please clean the water tank and fill water.
Install the drip tray properly.
Remove and empty the water tank.
The drip tray should be removed and clean on a regular basis.
: Water tank is not close well, check whether the water tank is install properly.
If the water tank is fully filled and properly installed, but abnormal buzzer ring and the lack of water icon show on the screen,
E-12

COOKING CHART
Cooking Mode Preheat Temperature / Power
Pure Steam N 50 - 100˚C
Steam & Convection N Steam: L1 - L4
Convection: 180 - 220˚C
Steam & Microwave N Steam: 80 - 100˚C
Microwave: 100 - 300W
Convection Y*1 50 - 230˚C
Convection & Microwave Y*1 Convection: 50 - 230˚C
Microwave: 100 - 700W
Grill N 1 - 3
Grill Fan Y*1 35 - 180˚C
Grill & Microwave N Grill: 1 - 3
Microwave: 100 - 700W
Grill Fan & Microwave Y Grill fan: 100 - 180˚C
Microwave: 100 - 700W
Microwave N 100 - 900W 90 mins
STEAM COOKING MODE
STEAM INSTRUCTION
1. Before steam cooking:
• Before starting the steam cooking mode, please clean the water tank and fill water.
• Install the drip tray properly.
2. During steam cooking:
During steam cooking mode, if no water in the water tank, abnormal buzzer will ring and the lack of water icon will show on the screen
to remind you to refill water. Press ” “ after position back the water tank to resume cooking.
3. After steam cooking:
• Remove and empty the water tank.
• The drip tray should be removed and clean on a regular basis.
4. Defect codes
Below defect codes may appear during steam cooking :
E-06: Water tank is not close well, check whether the water tank is install properly.
Note: If the water tank is fully filled and properly installed, but abnormal buzzer ring and the lack of water icon show on the screen,
please contact SHARP service center for repair.
E-13
English

STEAM COOKING MODE
oC blinks.
oC, 190oC, 200oC, 210oC, 220oC)
STEAM COOKING MODE
1. Press “ “ to enter into the pure steam mode, the default time 10:00 blinks.
2. Press “ “or “ “ to select the cooking time. The maxmum cooking time is 90 minutes.
3. Press the “ “, the default temperature 100oC blinks, then press “ “ or “ “ to select a temperature (50oC, 60oC, 70oC, 80oC,
85oC, 90oC, 95oC, 100oC).
4. Press “ “ button to start cooking.
If you want to change the setting, press “ “ to enter into time setting mode, or press “ “ to enter into steam temperature setting
mode before cooking.
PURE STEAM
E-14

STEAM COOKING MODE
1. Press ” “ 3 times to select steam & convection cooking mode, the default temperature 180oC blinks.
2. Press ” “ or ” “ to select temperature. (180oC, 190oC, 200oC, 210oC, 220oC)
3. Press ” “ the default steam level ”L3“ flash, then press ” “ or ” “ to set the steam level [L1 (min), L2, L3, L4 (max)].
4. Press ” “ and then press ” “ or ” “ to set the cooking time. The maximum cooking time is 90 minutes.
5. Press ” “ button to start cooking.
If you want to change the setting, press ” “ to enter into time setting mode, or press ” “ to enter into steam level or temperature
setting mode before cooking.
STEAM & CONVECTION
STEAM COOKING MODE
1. Press “ “ to enter into the pure steam mode, the default time 10:00 blinks.
2. Press “ “or “ “ to select the cooking time. The maxmum cooking time is 90 minutes.
3. Press the “ “, the default temperature 100o
85oC, 90oC, 95oC, 100oC).
4. Press “ “ button to start cooking.
mode before cooking.
E-15
English

CONVECTION COOKING MODE
oC blinks.
oC to 230oC. (50oC, 100oC, 105oC, 110oC, 115oC, 120oC, 125oC, 130oC, 135oC,
oC, 150oC, 155oC, 160oC, 165oC, 170oC, 175oC, 180oC, 185oC, 190oC, 195oC, 200oC, 205oC, 210oC, 215oC, 220oC, 225oC,
oC or below.)
STEAM COOKING MODE
1. Press ” “ 2 times to select steam & microwave cooking mode , the default cooking time ”10:00“ blinks.
2. Press ” “ or ” “ to select the cooking time. The maximum cooking time is 90 minutes.
3. Press ” “, then press ” “ or ” “ to set the power (100W, 300W).
4. Press ” “, the default steam temperature 100oC blinks, then press “ “ or “ “ to select the steam temperature (80oC, 85oC,
90oC, 95oC, 100oC).
5. Press ” “ button to start cooking.
If you want to charge the setting, press ” “ to enter
into time setting mode, or press ” “ to enter into
steam temperature or microware power setting mode
before cooking.
Fill water here
Water tank
STEAM & MICROWAVE
E-16

CONVECTION COOKING MODE
1. Press ” “ to select convection cooking mode, the default temperature 180oC blinks.
2. Press ” “ or ” “ to select temperature from 50oC to 230oC. (50oC, 100oC, 105oC, 110oC, 115oC, 120oC, 125oC, 130oC, 135oC,
140oC, 145oC, 150oC, 155oC, 160oC, 165oC, 170oC, 175oC, 180oC, 185oC, 190oC, 195oC, 200oC, 205oC, 210oC, 215oC, 220oC, 225oC,
230oC)
3. Press ” “ to select the time setting mode. The default time is 10 minutes. Press ” “ or ” “ to select the cooking time.
The maximum cooking time is 5 hours.
4. Press ” “ button to start cooking.
If you want to change the setting, you can press ” “ to enter into time setting mode, or press ” “ to enter into temperature setting
mode before cooking.
* If preheat is needed, press ” “ after setting, ” “ icon will be showed on the screen.
(Preheat is not available if the temperature is set at 50oC or below.)
CONVECTION
STEAM COOKING MODE
1. Press ” “ 2 times to select steam & microwave cooking mode , the default cooking time ”10:00“ blinks.
2. Press ” “ or ” “ to select the cooking time. The maximum cooking time is 90 minutes.
3. Press ” “, then press ” “ or ” “ to set the power (100W, 300W).
4. Press ” “, the default steam temperature 100oC blinks, then press “ “ or “ “ to select the steam temperature (80
90oC, 95oC, 100oC).
5. Press ” “ button to start cooking.
If you want to charge the setting, press ” “ to enter
into time setting mode, or press ” “ to enter into
steam temperature or microware power setting mode
before cooking.
E-17
English

CONVECTION COOKING MODE
1. Press ” “ 3 times to select convection & microwave cooking mode. The default temperature is 180 degrees. The default microwave
power is 300W.
2. Press ” “ or ” “ to select from 50oC to 230oC. (50oC, 100oC, 105oC, 110oC, 115oC, 120oC, 125oC, 130oC, 135oC, 140oC, 145oC,
150oC, 155oC, 160oC, 165oC, 170oC, 175oC, 180oC, 185oC, 190oC, 195oC, 200oC, 205oC, 210oC, 215oC, 220oC, 225oC, 230oC).
3. Press ” “, the default microwave power 300W blinks, then press ” “ or ” “ to adjust the power. (100W, 300W, 450W, 700W).
4. Press ” “ and then press ” “ or ” “ to set the cooking time. The maximum cooking time is 90 minutes.
5. Press ” “ button to start cooking.
If you want to change the setting, you can press ” “ to enter into time setting mode, or press ” “ to enter into temperature or
microwave power setting mode before cooking.
* If preheat is needed, press ” “ after setting, ” “ icon will be showed on the screen.
(Preheat is not available if the temperature is set at 50oC or below.)
CONVECTION & MICROWAVE
GRILL COOKING MODE
E-18
