Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
198
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
INTEGRATED CIRCUITS
IC6201 9GJSN755860PJ J Scan IC
IC6202 9GJSN755860PJ J Scan IC
IC6203 9GJSN755860PJ J Scan IC
IC6204 9GJSN755860PJ J Scan IC
IC6205 9GJSN755860PJ J Scan IC
IC6206 9GJSN755860PJ J Scan IC
CAPACITORS
C6201 9GJACG1088 J 0.1 250V Ceramic
C6202 9GJACG1088 J 0.1 250V Ceramic
C6212 9GJACG1088 J 0.1 250V Ceramic
C6213 9GJACG1088 J 0.1 250V Ceramic
C6222 9GJACG1088 J 0.1 250V Ceramic
C6223 9GJACG1088 J 0.1 250V Ceramic
C6232 9GJACG1088 J 0.1 250V Ceramic
C6233 9GJACG1088 J 0.1 250V Ceramic
C6242 9GJACG1088 J 0.1 250V Ceramic
C6243 9GJACG1088 J 0.1 250V Ceramic
C6252 9GJACG1088 J 0.1 250V Ceramic
C6253 9GJACG1088 J 0.1 250V Ceramic
C6203 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6205 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6206 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6210 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6215 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6219 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6220 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6227 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6229 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6231 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6235 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6236 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6240 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6244 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6246 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6251 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6255 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6259 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6260 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6262 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOWTO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
NOTES
•Parts marked by "NSP" are generally unavailable because they are
not in our Master Spare Parts List.
•The åmark found on some component parts indicates the
importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical
designation.
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone [phone].
NSP 9GJAWV1927 – SCAN FUKUGO ASSY —
NSP 9GJAWZ6666 – – SCAN (A) ASSY —
NSP 9GJAWZ6667 – – SCAN (B) ASSY —
NSP 9GJAWZ6672 – – X CONNECTOR (A) ASSY —
NSP 9GJAWZ6673 – – X CONNECTOR (B) ASSY —
NSP 9GJAWZ6674 – – BRIDGE A ASSY —
NSP 9GJAWZ6675 – – BRIDGE B ASSY —
NSP 9GJAWZ6676 – – BRIDGE C ASSY —
NSP 9GJAWZ6677 – – BRIDGE D ASSY —
9GJAWV1926 J ADDRESS FUKUGO ASSY
NSP 9GJAWZ6668 – – CLAMP A ASSY —
NSP 9GJAWZ6669 – – CLAMP B ASSY —
NSP 9GJAWZ6678 – – ADR CONNECT A ASSY —
NSP 9GJAWZ6679 – – ADR CONNECT B ASSY —
NSP 9GJAWZ6680 – – ADR CONNECT C ASSY —
NSP 9GJAWZ6681 – – ADR CONNECT D ASSY —
9GJAWZ6682 J – ADR RESONANCE ASSY
9GJAWV1930 J X DRIVE ASSY
9GJAWV1931 J HDY DRIVE ASSY
9GJAWZ6683 J –Y DRIVE ASSY
9GJAWZ6692 J – SUB ADDRESS A ASSY
9GJAWZ6693 J – SUB ADDRESS B ASSY
9GJAWV1929 J DIGITAL VIDEO ASSY
NSP 9GJAWV1923 – HD FUKUGO ASSY —
9GJAWZ6654 J – MR INTERFACE ASSY
9GJAWZ6655 J – LED ASSY
9GJAWZ6656 J – FRONT KEY ASSY
9GJAWZ6657 J – FRONT KEY CONN ASSY
9GJAWZ6658 J – IR (P) ASSY
9GJAWZ6660 J – THERMAL SENSOR ASS
NSP 9GJAWV1935 – HD AUDIO ASSY —
9GJAWZ6687 J – AUDIO AMP ASSY
9GJAWZ6688 J – SP TERMINAL ASSY
MARK ★: SPARE PARTS-DELIVERY SECTION
Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
PRINTEDWIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM) 9GJAWZ6666
SCAN (A) ASSY

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
199
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6666
SCAN (A) ASSY (Continued)
C6263 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6264 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6265 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6266 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6208 9GJCCSRCH181J5 J 180p 50V Ceramic
C6209 9GJCCSRCH181J5 J 180p 50V Ceramic
C6217 9GJCCSRCH181J5 J 180p 50V Ceramic
C6218 9GJCCSRCH181J5 J 180p 50V Ceramic
C6226 9GJCCSRCH181J5 J 180p 50V Ceramic
C6230 9GJCCSRCH181J5 J 180p 50V Ceramic
C6238 9GJCCSRCH181J5 J 180p 50V Ceramic
C6239 9GJCCSRCH181J5 J 180p 50V Ceramic
C6245 9GJCCSRCH181J5 J 180p 50V Ceramic
C6250 9GJCCSRCH181J5 J 180p 50V Ceramic
C6257 9GJCCSRCH181J5 J 180p 50V Ceramic
C6258 9GJCCSRCH181J5 J 180p 50V Ceramic
C6204 9GJCCSRCH390J5 J 39p 50V Ceramic
C6207 9GJCCSRCH390J5 J 39p 50V Ceramic
C6214 9GJCCSRCH390J5 J 39p 50V Ceramic
C6216 9GJCCSRCH390J5 J 39p 50V Ceramic
C6224 9GJCCSRCH390J5 J 39p 50V Ceramic
C6225 9GJCCSRCH390J5 J 39p 50V Ceramic
C6234 9GJCCSRCH390J5 J 39p 50V Ceramic
C6237 9GJCCSRCH390J5 J 39p 50V Ceramic
C6248 9GJCCSRCH390J5 J 39p 50V Ceramic
C6249 9GJCCSRCH390J5 J 39p 50V Ceramic
C6254 9GJCCSRCH390J5 J 39p 50V Ceramic
C6256 9GJCCSRCH390J5 J 39p 50V Ceramic
C6211 9GJCKSRYF104Z1 J 0.1 50V Ceramic
C6221 9GJCKSRYF104Z1 J 0.1 50V Ceramic
C6228 9GJCKSRYF104Z1 J 0.1 50V Ceramic
C6241 9GJCKSRYF104Z1 J 0.1 50V Ceramic
C6247 9GJCKSRYF104Z1 J 0.1 50V Ceramic
C6261 9GJCKSRYF104Z1 J 0.1 50V Ceramic
RESISTORS
R6207 9GJRAB4C221J J Resistor Array
R6209 9GJRAB4C221J J Resistor Array
R6222 9GJRAB4C221J J Resistor Array
R6228 9GJRAB4C221J J Resistor Array
R6232 9GJRAB4C221J J Resistor Array
R6239 9GJRAB4C221J J Resistor Array
R6201 9GJRS1/16S221J J 220 1/16W Chip
R6203 9GJRS1/16S221J J 220 1/16W Chip
R6205 9GJRS1/16S221J J 220 1/16W Chip
R6208 9GJRS1/16S221J J 220 1/16W Chip
R6210 9GJRS1/16S221J J 220 1/16W Chip
R6214 9GJRS1/16S221J J 220 1/16W Chip
R6215 9GJRS1/16S221J J 220 1/16W Chip
R6216 9GJRS1/16S221J J 220 1/16W Chip
R6220 9GJRS1/16S221J J 220 1/16W Chip
R6221 9GJRS1/16S221J J 220 1/16W Chip
R6223 9GJRS1/16S221J J 220 1/16W Chip
R6227 9GJRS1/16S221J J 220 1/16W Chip
R6229 9GJRS1/16S221J J 220 1/16W Chip
R6230 9GJRS1/16S221J J 220 1/16W Chip
R6235 9GJRS1/16S221J J 220 1/16W Chip
R6236 9GJRS1/16S221J J 220 1/16W Chip
R6237 9GJRS1/16S221J J 220 1/16W Chip
R6240 9GJRS1/16S221J J 220 1/16W Chip
R6243 9GJRS1/16S221J J 220 1/16W Chip
MISCELLANEOUS PARTS
CN6201 9GJAKP1218 J Connector, 15-pin
K6202 9GJAKX9002 J Test Point (Chip1608)
K6212 9GJAKX9002 J Test Point (Chip1608)
K6219 9GJAKX9002 J Test Point (Chip1608)
K6225 9GJAKX9002 J Test Point (Chip1608)
K6231 9GJAKX9002 J Test Point (Chip1608)
K6239 9GJAKX9002 J Test Point (Chip1608)
K6244 9GJAKX9002 J Test Point (Chip1608)
INTEGRATED CIRCUITS
IC6001 9GJSN755860PJ J Scan IC
IC6002 9GJSN755860PJ J Scan IC
IC6003 9GJSN755860PJ J Scan IC
IC6004 9GJSN755860PJ J Scan IC
IC6005 9GJSN755860PJ J Scan IC
IC6006 9GJSN755860PJ J Scan IC
CAPACITORS
C6001 9GJACG1088 J 0.1 250V Ceramic
C6002 9GJACG1088 J 0.1 250V Ceramic
C6011 9GJACG1088 J 0.1 250V Ceramic
C6012 9GJACG1088 J 0.1 250V Ceramic
C6021 9GJACG1088 J 0.1 250V Ceramic
C6022 9GJACG1088 J 0.1 250V Ceramic
C6031 9GJACG1088 J 0.1 250V Ceramic
C6032 9GJACG1088 J 0.1 250V Ceramic
C6041 9GJACG1088 J 0.1 250V Ceramic
C6042 9GJACG1088 J 0.1 250V Ceramic
C6051 9GJACG1088 J 0.1 250V Ceramic
C6052 9GJACG1088 J 0.1 250V Ceramic
C6004 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6005 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6009 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6013 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6015 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6020 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6026 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6027 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6029 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6033 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6038 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6040 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6044 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6048 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6049 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6054 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6058 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6059 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6060 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6062 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6063 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6064 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6065 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6066 9GJCCSRCH151J5 J 150p 50V Ceramic (Chip)
C6007 9GJCCSRCH181J5 J 180p 50V Ceramic
C6008 9GJCCSRCH181J5 J 180p 50V Ceramic
C6014 9GJCCSRCH181J5 J 180p 50V Ceramic
C6019 9GJCCSRCH181J5 J 180p 50V Ceramic
C6025 9GJCCSRCH181J5 J 180p 50V Ceramic
C6028 9GJCCSRCH181J5 J 180p 50V Ceramic
C6035 9GJCCSRCH181J5 J 180p 50V Ceramic
C6039 9GJCCSRCH181J5 J 180p 50V Ceramic
C6046 9GJCCSRCH181J5 J 180p 50V Ceramic
C6047 9GJCCSRCH181J5 J 180p 50V Ceramic
C6056 9GJCCSRCH181J5 J 180p 50V Ceramic
C6057 9GJCCSRCH181J5 J 180p 50V Ceramic
C6003 9GJCCSRCH390J5 J 39p 50V Ceramic
C6006 9GJCCSRCH390J5 J 39p 50V Ceramic
C6017 9GJCCSRCH390J5 J 39p 50V Ceramic
C6018 9GJCCSRCH390J5 J 39p 50V Ceramic
C6023 9GJCCSRCH390J5 J 39p 50V Ceramic
C6024 9GJCCSRCH390J5 J 39p 50V Ceramic
C6034 9GJCCSRCH390J5 J 39p 50V Ceramic
C6037 9GJCCSRCH390J5 J 39p 50V Ceramic
C6043 9GJCCSRCH390J5 J 39p 50V Ceramic
C6045 9GJCCSRCH390J5 J 39p 50V Ceramic
C6053 9GJCCSRCH390J5 J 39p 50V Ceramic
C6055 9GJCCSRCH390J5 J 39p 50V Ceramic
C6010 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6016 9GJCKSRYF104Z1 J 0.1 16V Ceramic
9GJAWZ6667
SCAN (B) ASSY

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
200
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6667
SCAN (B) ASSY (Continued)
DIODES
D6421 9GJD1FL20U(S) J Diode
D6422 9GJD1FL20U(S) J Diode
CAPACITORS
C6421 9GJACG1098 J 0.1 100V Ceramic
C6422 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6421 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6675
BRIDGE (B) ASSY
DIODES
D6431 9GJD1FL20U(S) J Diode
D6432 9GJD1FL20U(S) J Diode
CAPACITORS
C6431 9GJACG1098 J 0.1 100V Ceramic
C6432 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6431 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6676
BRIDGE (C) ASSY
DIODES
D6441 9GJD1FL20U(S) J Diode
D6442 9GJD1FL20U(S) J Diode
CAPACITORS
C6441 9GJACG1098 J 0.1 100V Ceramic
C6442 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6441 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6677
BRIDGE (D) ASSY
DIODES
D6451 9GJD1FL20U(S) J Diode
D6452 9GJD1FL20U(S) J Diode
CAPACITORS
C6451 9GJACG1098 J 0.1 100V Ceramic
C6452 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6451 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6674
BRIDGE (A) ASSY
C6030 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6036 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6050 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6061 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R6007 9GJRAB4C221J J Resistor Array
R6012 9GJRAB4C221J J Resistor Array
R6021 9GJRAB4C221J J Resistor Array
R6028 9GJRAB4C221J J Resistor Array
R6032 9GJRAB4C221J J Resistor Array
R6040 9GJRAB4C221J J Resistor Array
R6001 9GJRS1/16S221J J 220 1/16W Chip
R6004 9GJRS1/16S221J J 220 1/16W Chip
R6006 9GJRS1/16S221J J 220 1/16W Chip
R6008 9GJRS1/16S221J J 220 1/16W Chip
R6011 9GJRS1/16S221J J 220 1/16W Chip
R6014 9GJRS1/16S221J J 220 1/16W Chip
R6015 9GJRS1/16S221J J 220 1/16W Chip
R6017 9GJRS1/16S221J J 220 1/16W Chip
R6020 9GJRS1/16S221J J 220 1/16W Chip
R6022 9GJRS1/16S221J J 220 1/16W Chip
R6024 9GJRS1/16S221J J 220 1/16W Chip
R6027 9GJRS1/16S221J J 220 1/16W Chip
R6029 9GJRS1/16S221J J 220 1/16W Chip
R6031 9GJRS1/16S221J J 220 1/16W Chip
R6035 9GJRS1/16S221J J 220 1/16W Chip
R6036 9GJRS1/16S221J J 220 1/16W Chip
R6037 9GJRS1/16S221J J 220 1/16W Chip
R6041 9GJRS1/16S221J J 220 1/16W Chip
R6043 9GJRS1/16S221J J 220 1/16W Chip
MISCELLANEOUS PARTS
CN6001 9GJAKP1218 J Connector, 15-pin
K6001 9GJAKX9002 J Test Point (Chip1608)
K6012 9GJAKX9002 J Test Point (Chip1608)
K6018 9GJAKX9002 J Test Point (Chip1608)
K6025 9GJAKX9002 J Test Point (Chip1608)
K6031 9GJAKX9002 J Test Point (Chip1608)
K6038 9GJAKX9002 J Test Point (Chip1608)
K6044 9GJAKX9002 J Test Point (Chip1608)
9GJAWZ6672
X CONNECTOR (A) ASSY
RESISTORS
R6401 9GJRS1/16S0R0J J 0 1/16W Chip
9GJAWZ6673
X CONNECTOR (B) ASSY
RESISTORS
R6451 9GJRS1/16S0R0J J 0 1/16W Chip

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
201
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6668
CLAMP (A) ASSY
DIODES
D6461 9GJD1FL20U(S) J Diode
D6462 9GJD1FL20U(S) J Diode
CAPACITORS
C6461 9GJACG1098 J 0.1 100V Ceramic
C6462 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6461 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6669
CLAMP (B) ASSY
DIODES
D6471 9GJD1FL20U(S) J Diode
D6472 9GJD1FL20U(S) J Diode
CAPACITORS
C6471 9GJACG1098 J 0.1 100V Ceramic
C6472 9GJACG1098 J 0.1 100V Ceramic
MISCELLANEOUS PARTS
CN6471 9GJB4B-PH-SM3 J PH Connector (SMT)
9GJAWZ6678
ADR CONNECT (A) ASSY
INTEGRATED CIRCUITS
IC6501 9GJTC74VHC541F J Logic IC
TRANSISTORS
Q6502 9GJ2SC2712 J 2SC2712
Q6503 9GJ2SK209 J 2SK209
DIODE
D6501 9GJDA227 J Diode
COILS
L6501 9GJATH1081 J Coil 22µH/0.11A (Chip)
L6502 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C6504 9GJACG1094 J 330p 100V Ceramic
C6513 9GJACG1094 J 330p 100V Ceramic
C6515 9GJACG1094 J 330p 100V Ceramic
C6516 9GJACG1094 J 330p 100V Ceramic
C6517 9GJACG1094 J 330p 100V Ceramic
C6518 9GJACG1094 J 330p 100V Ceramic
C6519 9GJACG1094 J 330p 100V Ceramic
C6520 9GJACG1094 J 330p 100V Ceramic
C6528 9GJACG1094 J 330p 100V Ceramic
C6531 9GJACH1341 J 47 6.3V Electrolytic
C6533 9GJACH1341 J 47 6.3V Electrolytic
C6534 9GJACH1341 J 47 6.3V Electrolytic
C6536 9GJCCSRCH121J5 J 120p 50V Ceramic
C6537 9GJCCSRCH121J5 J 120p 50V Ceramic
C6538 9GJCCSRCH121J5 J 120p 50V Ceramic
C6507 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6508 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6510 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6522 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6523 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6524 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6525 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6532 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6535 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R6519 9GJRAB4C100J J Resistor Array
R6520 9GJRAB4C100J J Resistor Array
R6521 9GJRAB4C100J J Resistor Array
R6522 9GJRAB4C100J J Resistor Array
R6526 9GJRAB4C100J J Resistor Array
R6528 9GJRAB4C100J J Resistor Array
R6530 9GJRAB4C100J J Resistor Array
R6531 9GJRAB4C100J J Resistor Array
R6534 9GJRAB4C100J J Resistor Array
R6535 9GJRAB4C100J J Resistor Array
R6536 9GJRAB4C100J J Resistor Array
R6537 9GJRAB4C100J J Resistor Array
R6541 9GJRAB4C100J J Resistor Array
R6543 9GJRAB4C100J J Resistor Array
R6545 9GJRAB4C100J J Resistor Array
R6547 9GJRAB4C100J J Resistor Array
R6516 9GJRAB4C473J J Resistor Array
R6501 9GJRS1/16S0R0J J 0 1/16W Chip
R6507 9GJRS1/16S0R0J J 0 1/16W Chip
R6548 9GJRS1/16S0R0J J 0 1/16W Chip
R6549 9GJRS1/16S0R0J J 0 1/16W Chip
R6550 9GJRS1/16S0R0J J 0 1/16W Chip
R6551 9GJRS1/16S0R0J J 0 1/16W Chip
R6552 9GJRS1/16S0R0J J 0 1/16W Chip
R6553 9GJRS1/16S0R0J J 0 1/16W Chip
R6525 9GJRS1/16S100J J 10 1/16W Chip
R6527 9GJRS1/16S100J J 10 1/16W Chip
R6529 9GJRS1/16S100J J 10 1/16W Chip
R6532 9GJRS1/16S100J J 10 1/16W Chip
R6540 9GJRS1/16S100J J 10 1/16W Chip
R6542 9GJRS1/16S100J J 10 1/16W Chip
R6544 9GJRS1/16S100J J 10 1/16W Chip
R6546 9GJRS1/16S100J J 10 1/16W Chip
R6514 9GJRS1/16S103J J 10k 1/16W Chip
R6512 9GJRS1/16S221J J 220 1/16W Chip
R6508 9GJRS1/16S224J J 220k 1/16W Chip
R6509 9GJRS1/16S224J J 220k 1/16W Chip
R6510 9GJRS1/16S393J J 39k 1/16W Chip
R6511 9GJRS1/16S472J J 4.7k 1/16W Chip
R6515 9GJRS1/16S472J J 4.7k 1/16W Chip
R6513 9GJRS1/16S474J J 470k 1/16W Chip
MISCELLANEOUS PARTS
CN6501 9GJAKM1202 J Connector, 55-pin

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
202
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6679
ADR CONNECT (B) ASSY
INTEGRATED CIRCUITS
IC6601 9GJTC74VHC541F J Logic IC
TRANSISTORS
Q6602 9GJ2SC2712 J 2SC2712
Q6603 9GJ2SK209 J 2SK209
DIODE
D6601 9GJDA227 J Diode
COILS
L6601 9GJATH1081 J Coil 22µH/0.11A (Chip)
L6602 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C6604 9GJACG1094 J 330p 100V Ceramic
C6613 9GJACG1094 J 330p 100V Ceramic
C6614 9GJACG1094 J 330p 100V Ceramic
C6615 9GJACG1094 J 330p 100V Ceramic
C6616 9GJACG1094 J 330p 100V Ceramic
C6617 9GJACG1094 J 330p 100V Ceramic
C6618 9GJACG1094 J 330p 100V Ceramic
C6619 9GJACG1094 J 330p 100V Ceramic
C6620 9GJACG1094 J 330p 100V Ceramic
C6628 9GJACG1094 J 330p 100V Ceramic
C6631 9GJACH1341 J 47 6.3V Electrolytic
C6633 9GJACH1341 J 47 6.3V Electrolytic
C6634 9GJACH1341 J 47 6.3V Electrolytic
C6636 9GJCCSRCH121J5 J 120p 50V Ceramic
C6637 9GJCCSRCH121J5 J 120p 50V Ceramic
C6638 9GJCCSRCH121J5 J 120p 50V Ceramic
C6607 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6608 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6609 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6610 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6622 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6623 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6624 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6625 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6632 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6635 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R6619 9GJRAB4C100J J Resistor Array
R6620 9GJRAB4C100J J Resistor Array
R6621 9GJRAB4C100J J Resistor Array
R6622 9GJRAB4C100J J Resistor Array
R6626 9GJRAB4C100J J Resistor Array
R6628 9GJRAB4C100J J Resistor Array
R6630 9GJRAB4C100J J Resistor Array
R6631 9GJRAB4C100J J Resistor Array
R6634 9GJRAB4C100J J Resistor Array
R6635 9GJRAB4C100J J Resistor Array
R6636 9GJRAB4C100J J Resistor Array
R6637 9GJRAB4C100J J Resistor Array
R6641 9GJRAB4C100J J Resistor Array
R6643 9GJRAB4C100J J Resistor Array
R6645 9GJRAB4C100J J Resistor Array
R6647 9GJRAB4C100J J Resistor Array
R6616 9GJRAB4C473J J Resistor Array
R6601 9GJRS1/16S0R0J J 0 1/16W Chip
R6607 9GJRS1/16S0R0J J 0 1/16W Chip
R6648 9GJRS1/16S0R0J J 0 1/16W Chip
R6649 9GJRS1/16S0R0J J 0 1/16W Chip
R6650 9GJRS1/16S0R0J J 0 1/16W Chip
R6651 9GJRS1/16S0R0J J 0 1/16W Chip
R6652 9GJRS1/16S0R0J J 0 1/16W Chip
R6653 9GJRS1/16S0R0J J 0 1/16W Chip
R6625 9GJRS1/16S100J J 10 1/16W Chip
R6627 9GJRS1/16S100J J 10 1/16W Chip
R6629 9GJRS1/16S100J J 10 1/16W Chip
R6632 9GJRS1/16S100J J 10 1/16W Chip
R6640 9GJRS1/16S100J J 10 1/16W Chip
R6642 9GJRS1/16S100J J 10 1/16W Chip
R6644 9GJRS1/16S100J J 10 1/16W Chip
R6646 9GJRS1/16S100J J 10 1/16W Chip
R6614 9GJRS1/16S103J J 10k 1/16W Chip
R6612 9GJRS1/16S221J J 220 1/16W Chip
R6608 9GJRS1/16S224J J 220k 1/16W Chip
R6609 9GJRS1/16S224J J 220k 1/16W Chip
R6610 9GJRS1/16S393J J 39k 1/16W Chip
R6611 9GJRS1/16S472J J 4.7k 1/16W Chip
R6615 9GJRS1/16S472J J 4.7k 1/16W Chip
R6613 9GJRS1/16S474J J 470k 1/16W Chip
MISCELLANEOUS PARTS
CN6601 9GJAKM1202 J Connector, 55-pin
9GJAWZ6676
ADR CONNECT (C) ASSY
INTEGRATED CIRCUITS
IC6801 9GJTC74VHC541F J Logic IC
TRANSISTORS
Q6802 9GJ2SC2712 J 2SC2712
Q6803 9GJ2SK209 J 2SK209
DIODE
D6801 9GJDA227 J Diode
COILS
L6801 9GJATH1081 J Coil 22µH/0.11A (Chip)
L6802 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C6804 9GJACG1094 J 330p 100V Cerramic
C6813 9GJACG1094 J 330p 100V Cerramic
C6814 9GJACG1094 J 330p 100V Cerramic
C6815 9GJACG1094 J 330p 100V Cerramic
C6816 9GJACG1094 J 330p 100V Cerramic
C6817 9GJACG1094 J 330p 100V Cerramic
C6818 9GJACG1094 J 330p 100V Cerramic
C6819 9GJACG1094 J 330p 100V Cerramic
C6820 9GJACG1094 J 330p 100V Cerramic
C6828 9GJACG1094 J 330p 100V Cerramic
C6831 9GJACH1341 J 47 6.3V Electrolytic
C6833 9GJACH1341 J 47 6.3V Electrolytic
C6834 9GJACH1341 J 47 6.3V Electrolytic
C6836 9GJCCSRCH121J5 J 120p 50V Cerramic
C6837 9GJCCSRCH121J5 J 120p 50V Cerramic
C6838 9GJCCSRCH121J5 J 120p 50V Cerramic
C6807 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6808 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6809 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6810 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6822 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6823 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6824 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6825 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6832 9GJCKSRYF104Z1 J 0.1 16V Cerramic
C6835 9GJCKSRYF104Z1 J 0.1 16V Cerramic
RESISTORS
R6819 9GJRAB4C100J J Resistor Array
R6820 9GJRAB4C100J J Resistor Array
R6821 9GJRAB4C100J J Resistor Array
R6822 9GJRAB4C100J J Resistor Array
R6826 9GJRAB4C100J J Resistor Array
R6828 9GJRAB4C100J J Resistor Array
R6830 9GJRAB4C100J J Resistor Array

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
203
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6676
ADR CONNECT (C) ASSY (Continued)
R6831 9GJRAB4C100J J Resistor Array
R6834 9GJRAB4C100J J Resistor Array
R6835 9GJRAB4C100J J Resistor Array
R6836 9GJRAB4C100J J Resistor Array
R6837 9GJRAB4C100J J Resistor Array
R6841 9GJRAB4C100J J Resistor Array
R6843 9GJRAB4C100J J Resistor Array
R6845 9GJRAB4C100J J Resistor Array
R6847 9GJRAB4C100J J Resistor Array
R6816 9GJRAB4C473J J Resistor Array
R6801 9GJRS1/16S0R0J J 0 1/16W Chip
R6807 9GJRS1/16S0R0J J 0 1/16W Chip
R6848 9GJRS1/16S0R0J J 0 1/16W Chip
R6849 9GJRS1/16S0R0J J 0 1/16W Chip
R6850 9GJRS1/16S0R0J J 0 1/16W Chip
R6851 9GJRS1/16S0R0J J 0 1/16W Chip
R6852 9GJRS1/16S0R0J J 0 1/16W Chip
R6853 9GJRS1/16S0R0J J 0 1/16W Chip
R6825 9GJRS1/16S100J J 10 1/16W Chip
R6827 9GJRS1/16S100J J 10 1/16W Chip
R6829 9GJRS1/16S100J J 10 1/16W Chip
R6832 9GJRS1/16S100J J 10 1/16W Chip
R6840 9GJRS1/16S100J J 10 1/16W Chip
R6842 9GJRS1/16S100J J 10 1/16W Chip
R6844 9GJRS1/16S100J J 10 1/16W Chip
R6846 9GJRS1/16S100J J 10 1/16W Chip
R6814 9GJRS1/16S103J J 10k 1/16W Chip
R6812 9GJRS1/16S221J J 220 1/16W Chip
R6808 9GJRS1/16S224J J 220k 1/16W Chip
R6809 9GJRS1/16S224J J 220k 1/16W Chip
R6810 9GJRS1/16S393J J 39k 1/16W Chip
R6811 9GJRS1/16S472J J 4.7k 1/16W Chip
R6815 9GJRS1/16S472J J 4.7k 1/16W Chip
R6813 9GJRS1/16S474J J 470k 1/16W Chip
MISCELLANEOUS PARTS
CN6801 9GJAKM1202 J Connector, 55-pin
9GJAWZ6677
ADR CONNECT (D) ASSY
INTEGRATED CIRCUITS
IC6901 9GJTC74VHC541F J Logic IC
TRANSISTORS
Q6902 9GJ2SC2712 J 2SC2712
Q6903 9GJ2SK209 J 2SK209
DIODE
D6901 9GJDA227 J Diode
COILS
L6901 9GJATH1081 J Coil 22µH/0.11A (Chip)
L6902 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C6904 9GJACG1094 J 330p 100V Ceramic
C6913 9GJACG1094 J 330p 100V Ceramic
C6914 9GJACG1094 J 330p 100V Ceramic
C6915 9GJACG1094 J 330p 100V Ceramic
C6916 9GJACG1094 J 330p 100V Ceramic
C6917 9GJACG1094 J 330p 100V Ceramic
C6918 9GJACG1094 J 330p 100V Ceramic
C6919 9GJACG1094 J 330p 100V Ceramic
C6920 9GJACG1094 J 330p 100V Ceramic
C6928 9GJACG1094 J 330p 100V Ceramic
C6931 9GJACH1341 J 47 6.3V Electrolytic
C6933 9GJACH1341 J 47 6.3V Electrolytic
C6934 9GJACH1341 J 47 6.3V Electrolytic
C6936 9GJCCSRCH121J5 J 120p 50V Ceramic
C6937 9GJCCSRCH121J5 J 120p 50V Ceramic
C6938 9GJCCSRCH121J5 J 120p 50V Ceramic
C6907 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6908 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6909 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6910 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6922 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6923 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6924 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6925 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6932 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C6935 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R6919 9GJRAB4C100J J Resistor Array
R6920 9GJRAB4C100J J Resistor Array
R6921 9GJRAB4C100J J Resistor Array
R6922 9GJRAB4C100J J Resistor Array
R6926 9GJRAB4C100J J Resistor Array
R6928 9GJRAB4C100J J Resistor Array
R6930 9GJRAB4C100J J Resistor Array
R6931 9GJRAB4C100J J Resistor Array
R6934 9GJRAB4C100J J Resistor Array
R6935 9GJRAB4C100J J Resistor Array
R6936 9GJRAB4C100J J Resistor Array
R6937 9GJRAB4C100J J Resistor Array
R6941 9GJRAB4C100J J Resistor Array
R6943 9GJRAB4C100J J Resistor Array
R6945 9GJRAB4C100J J Resistor Array
R6947 9GJRAB4C100J J Resistor Array
R6916 9GJRAB4C473J J Resistor Array
R6901 9GJRS1/16S0R0J J 0 1/16W Chip
R6907 9GJRS1/16S0R0J J 0 1/16W Chip
R6948 9GJRS1/16S0R0J J 0 1/16W Chip
R6949 9GJRS1/16S0R0J J 0 1/16W Chip
R6950 9GJRS1/16S0R0J J 0 1/16W Chip
R6951 9GJRS1/16S0R0J J 0 1/16W Chip
R6952 9GJRS1/16S0R0J J 0 1/16W Chip
R6953 9GJRS1/16S0R0J J 0 1/16W Chip
R6925 9GJRS1/16S100J J 10 1/16W Chip
R6927 9GJRS1/16S100J J 10 1/16W Chip
R6929 9GJRS1/16S100J J 10 1/16W Chip
R6932 9GJRS1/16S100J J 10 1/16W Chip
R6940 9GJRS1/16S100J J 10 1/16W Chip
R6942 9GJRS1/16S100J J 10 1/16W Chip
R6944 9GJRS1/16S100J J 10 1/16W Chip
R6946 9GJRS1/16S100J J 10 1/16W Chip
R6914 9GJRS1/16S103J J 10k 1/16W Chip
R6912 9GJRS1/16S221J J 220 1/16W Chip
R6908 9GJRS1/16S224J J 220k 1/16W Chip
R6909 9GJRS1/16S224J J 220k 1/16W Chip
R6910 9GJRS1/16S393J J 39k 1/16W Chip
R6911 9GJRS1/16S472J J 4.7k 1/16W Chip
R6915 9GJRS1/16S472J J 4.7k 1/16W Chip
R6913 9GJRS1/16S474J J 470k 1/16W Chip
MISCELLANEOUS PARTS
CN6901 9GJAKM1202 J Connector, 55-pin

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
204
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6682
ADR RESONANCE ASSY
INTEGRATED CIRCUITS
åIC6704 9GJICP-S1.0 J IC Protector, 1A/50V
IC6701 9GJTND301S J FET
IC6702 9GJTND301S J FET
IC6703 9GJTND301S J FET
TRANSISTORS
Q6704 9GJ2SB1132 J 2SB1132
Q6705 9GJ2SB1132 J 2SB1132
Q6712 9GJ2SB1132 J 2SB1132
Q6701 9GJ2SD1664 J 2SD1664
Q6702 9GJ2SD1664 J 2SD1664
Q6703 9GJ2SD1664 J 2SD1664
Q6710 9GJFS30ASJ-2 J FS30ASJ
Q6711 9GJFS30ASJ-2 J FS30ASJ
Q6706 9GJFX20ASJ-2 J FX20ASJ
Q6707 9GJFX20ASJ-2 J FX20ASJ
Q6708 9GJFX20ASJ-2 J FX20ASJ
Q6709 9GJFX20ASJ-2 J FX20ASJ
DIODES
D6701 9GJ1SS355 J Diode
D6703 9GJ1SS355 J Diode
D6704 9GJ1SS355 J Diode
D6706 9GJ1SS355 J Diode
D6709 9GJD1FL20U(S) J Diode
D6710 9GJD1FL20U(S) J Diode
D6717 9GJD1FL20U(S) J Diode
D6718 9GJD1FL20U(S) J Diode
D6711 9GJSPX-62S J Diode
D6712 9GJSPX-62S J Diode
D6713 9GJSPX-62S J Diode
D6714 9GJSPX-62S J Diode
D6702 9GJUDZ15B J Zener Diode
D6705 9GJUDZ15B J Zener Diode
D6716 9GJUDZ15B J Zener Diode
COIL
L6704 9GJATH1121 J Choke Coil
CAPACITORS
C6716
C6718 9GJACE1159 J 1 100V Film
C6720 9GJACG1101 J 0.01 100V Ceramic
C6721 9GJACG1101 J 0.01 100V Ceramic
C6722 9GJACG1102 J 0.0068100V Ceramic
C6703 9GJACH1347 J 56 80V Electrolytic
C6704 9GJACH1347 J 56 80V Electrolytic
C6705 9GJACH1347 J 56 80V Electrolytic
C6706 9GJACH1347 J 56 80V Electrolytic
C6707 9GJACH1347 J 56 80V Electrolytic
C6708 9GJACH1347 J 56 80V Electrolytic
C6701 9GJCEHV470M16 J 47 16V Electrolytic
C6702 9GJCEHV470M16 J 47 16V Electrolytic
C6709 9GJCEHV470M16 J 47 16V Electrolytic
C6710 9GJCKSRYF104Z1 J 0.01 100V Ceramic
C6711 9GJCKSRYF104Z1 J 0.01 100V Ceramic
C6713 9GJCKSRYF104Z1 J 0.01 100V Ceramic
RESISTORS
R6743 9GJRS1/16S0R0J J 0 1/16W Chip
R6702 9GJRS1/16S100J J 10 1/16W Chip
R6707 9GJRS1/16S104J J 100k 1/16W Chip
R6701 9GJRS1/16S2R2J J 2.2 1/16W Chip
R6703 9GJRS1/16S2R2J J 2.2 1/16W Chip
R6704 9GJRS1/16S2R2J J 2.2 1/16W Chip
R6705 9GJRS1/16S2R2J J 2.2 1/16W Chip
R6722 9GJRS1/16S220J J 22 1/16W Chip
R6728 9GJRS1/16S220J J 22 1/16W Chip
R6730 9GJRS1/16S220J J 22 1/16W Chip
R6720 9GJRS1/16S222J J 2.2k 1/16W Chip
R6721 9GJRS1/16S222J J 2.2k 1/16W Chip
R6726 9GJRS1/16S222J J 2.2k 1/16W Chip
R6727 9GJRS1/16S222J J 2.2k 1/16W Chip
R6737 9GJRS1/16S222J J 2.2k 1/16W Chip
R6738 9GJRS1/16S222J J 2.2k 1/16W Chip
R6706 9GJRS1/16S4R7J J 4.7 1/16W Chip
R6725 9GJRS1/16S473J J 47k 1/16W Chip
R6731 9GJRS1/16S473J J 47k 1/16W Chip
R6732 9GJRS1/16S473J J 47k 1/16W Chip
R6735 9GJRS1/16S473J J 47k 1/16W Chip
R6739 9GJRS1/16S473J J 47k 1/16W Chip
R6740 9GJRS1/16S473J J 47k 1/16W Chip
R6744 9GJRS1/16S473J J 47k 1/16W Chip
MISCELLANEOUS PARTS
CN6701 9GJAKP1221 J Connector, 23-pin
CN6702 9GJB4B-PH-SM3 J PH Connector (SMT)
CN6703 9GJB5B-PH-SM3 J PH Connector (SMT)
9GJAWV1930
X DRIVE ASSY
[X LOGIC BLOCK]
INTEGRATED CIRCUITS
IC3003 9GJPE1012A J PE1012A
IC3004 9GJTC74ACT540F J TC74ACT540FT
IC3001 9GJTC74ACT541F J TC74ACT541FT
IC3008 9GJTC74ACT541F J TC74ACT541FT
COIL
L3001 9GJLFEA100J J Inductor
CAPACITORS
C3005 9GJCEHAT470M16 J 47 16V Electrolytic
C3001 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3003 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3004 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3006 9GJCKSRYF104Z5 J 0.1 50V Ceramic
RESISTORS
R3009 9GJRAB4C0R0J J 0 Resistor Array
R3010 9GJRAB4C0R0J J 0 Resistor Array
R3011 9GJRAB4C0R0J J 0 Resistor Array
R3012 9GJRAB4C0R0J J 0 Resistor Array
R3001 9GJRAB4C470J J 47 Resistor Array
R3003 9GJRAB4C470J J 47 Resistor Array
R3026 9GJRAB4C470J J 47 Resistor Array
R3029 9GJRAB4C470J J 47 Resistor Array
R3002 9GJRAB4C472J J 4.7k Resistor Array
R3005 9GJRAB4C472J J 4.7k Resistor Array
R3030 9GJRAB4C472J J 4.7k Resistor Array
R3033 9GJRAB4C472J J 4.7k Resistor Array
R3006 9GJRS1/16S0R0J 0 1/16W Chip
R3027 9GJRS1/16S0R0J 0 1/16W Chip
R3031 9GJRS1/16S0R0J 0 1/16W Chip
R3007 9GJRS1/16S472J 4.7k 1/16W Chip
MISCELLANEOUS PARTS
CN3001 9GJKF050HA30L J Connector, 30-pin
K3001 9GJAKX9002 J Test Point (Chip 1608)
K3003 9GJAKX9002 J Test Point (Chip 1608)
K3004 9GJAKX9002 J Test Point (Chip 1608)
K3008 9GJAKX9002 J Test Point (Chip 1608)
K3010 9GJAKX9002 J Test Point (Chip 1608)
K3012 9GJAKX9002 J Test Point (Chip 1608)
K3013 9GJAKX9002 J Test Point (Chip 1608)
K3014 9GJAKX9002 J Test Point (Chip 1608)
K3015 9GJAKX9002 J Test Point (Chip 1608)
K3017 9GJAKX9002 J Test Point (Chip 1608)
K3018 9GJAKX9002 J Test Point (Chip 1608)

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
205
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1930
X DRIVE ASSY (Continued)
[X SUS BLOCK]
INTEGRATED CIRCUITS
IC3102 9GJHCPL-M611 J HCPL-M611
IC3200 9GJSTK795-460 J STK795-460
IC3201 9GJSTK795-460 J STK795-460
IC3101 9GJTC74ACT541F J TC74ACT541F
IC3103 9GJTND301S J TND301S
IC3104 9GJTND301S J TND301S
IC3106 9GJTND301S J TND301S
IC3107 9GJTND301S J TND301S
IC3110 9GJTND301S J TND301S
IC3113 9GJTND301S J TND301S
IC3109 9GJUPC78L05T J UPC78L05T
TRANSISTORS
Q3117 9GJ2SJ181L J 2SJ181L
Q3116 9GJ2SJ522 J 2SJ522
Q3119 9GJ2SJ522 J 2SJ522
Q3120 9GJ2SJ522 J 2SJ522
Q3101 9GJ2SK2503 J 2SK2503
Q3103 9GJFS16VS-9 J FS16VS
Q3104 9GJFS16VS-9 J FS16VS
Q3105 9GJFS16VS-9 J FS16VS
Q3106 9GJFS16VS-9 J FS16VS
Q3109 9GJFS16VS-9 J FS16VS
Q31010 9GJFS16VS-9 J FS16VS
Q31011 9GJFS16VS-9 J FS16VS
Q31012 9GJFS16VS-9 J FS16VS
Q31013 9GJFS16VS-9 J FS16VS
Q31014 9GJFS16VS-9 J FS16VS
Q3124 9GJFS16VS-9 J FS16VS
Q3125 9GJFS16VS-9 J FS16VS
Q3126 9GJFS16VS-9 J FS16VS
Q3127 9GJFS16VS-9 J FS16VS
Q3123 9GJFS2AS-14A J FS2AS
Q3122 9GJFS7VS-14A J FS7VS
Q3128 9GJFS7VS-14A J FS7VS
Q3102 9GJHN1B04FU J HN1B04FU
Q3118 9GJHN1B04FU J HN1B04F
DIODES
D3119 9GJ1SS184 J Diode
D3108 9GJ1SS355 J Diode
D3124 9GJ1SS355 J Diode
D3125 9GJ1SS355 J Diode
D3130 9GJ1SS355 J Diode
D3133 9GJ1SS355 J Diode
D3101 9GJD1FL40 J Diode
D3102 9GJD1FL40 J Diode
D3117 9GJD1FL40 J Diode
D3126 9GJD1FL40 J Diode
D3131 9GJD1FL40 J Diode
D3200 9GJD1FL40 J Diode
D3202 9GJD1FL40 J Diode
D3203 9GJD1FL40 J Diode
D3205 9GJD1FL40 J Diode
D3207 9GJD1FL40 J Diode
D3208 9GJD1FL40 J Diode
D3210 9GJD1FL40 J Diode
D3211 9GJD1FL40 J Diode
D3212 9GJD1FL40 J Diode
D3213 9GJD1FL40 J Diode
D3215 9GJD1FL40 J Diode
D3120 9GJUDZ15B J Zener Diode
D3127 9GJUDZ15B J Zener Diode
D3128 9GJUDZ15B J Zener Diode
D3129 9GJUDZ15B J Zener Diode
D3135 9GJUDZ15B J Zener Diode
D3136 9GJUDZ15B J Zener Diode
COILS
L3206 9GJATH1112 J Inductor
L3207 9GJATH1112 J Inductor
L3201 9GJATH1113 J Choke Coil
L3204 9GJATH1113 J Choke Coil
L3202 9GJATH1118 J Choke Coil
L3205 9GJATH1118 J Choke Coil
L3210 9GJATH1118 J Choke Coil
L3211 9GJATH1118 J Choke Coil
L3101 9GJLFEA100J J Inductor
L3107 9GJLFEA101J J Inductor
L3108 9GJLFEA101J J Inductor
L3103 9GJLFEA470J J Inductor
CONTROLS
VR3200 9GJACP1089 J 1k (B)
VR3201 9GJACP1089 J 1k (B)
VR3202 9GJACP1089 J 1k (B)
VR3203 9GJACP1089 J 1k (B)
CAPACITORS
C3205 9GJACE1160 J 1.5 250V MPP
C3206 9GJACE1160 J 1.5 250V MPP
C3212 9GJACE1160 J 1.5 250V MPP
C3213 9GJACE1160 J 1.5 250V MPP
C3225 9GJACE1160 J 1.5 250V MPP
C3226 9GJACE1160 J 1.5 250V MPP
C3131 9GJACG1092 J 0.1 630V Ceramic
C3139 9GJACG1092 J 0.1 630V Ceramic
C3143 9GJACG1092 J 0.1 630V Ceramic
C3223 9GJACG1100 J 100p 500V Ceramic
C3224 9GJACG1100 J 100p 500V Ceramic
C3132 9GJACH1346 J 47 350V Electrolytic
C3200 9GJACH1348 J 330 315V Electrolytic
C3201 9GJACH1348 J 330 315V Electrolytic
C3202 9GJACH1348 J 330 315V Electrolytic
C3203 9GJACH1348 J 330 315V Electrolytic
C3204 9GJACH1348 J 330 315V Electrolytic
C3205 9GJACH1348 J 330 315V Electrolytic
C3206 9GJACH1348 J 330 315V Electrolytic
C3207 9GJACH1348 J 330 315V Electrolytic
C3208 9GJACH1348 J 330 315V Electrolytic
C3209 9GJACH1348 J 330 315V Electrolytic
C3214 9GJCCSRCH331J5 J 330p 50V CH
C3215 9GJCCSRCH331J5 J 330p 50V CH
C3216 9GJCCSRCH331J5 J 330p 50V CH
C3217 9GJCCSRCH331J5 J 330p 50V CH
C3218 9GJCCSRCH331J5 J 330p 50V CH
C3219 9GJCCSRCH331J5 J 330p 50V CH
C3220 9GJCCSRCH331J5 J 330p 50V CH
C3221 9GJCCSRCH331J5 J 330p 50V CH
C3112 9GJCEHAT101M16 J 100 16V Electrolytic
C3133 9GJCEHAT101M16 J 100 16V Electrolytic
C3203 9GJCEHAT101M16 J 100 16V Electrolytic
C3210 9GJCEHAT101M16 J 100 16V Electrolytic
C3102 9GJCEHAT101M25 J 100 25V Electrolytic
C3107 9GJCEHAT101M25 J 100 25V Electrolytic
C3115 9GJCEHAT101M25 J 100 25V Electrolytic
C3204 9GJCEHAT101M25 J 100 25V Electrolytic
C3211 9GJCEHAT101M25 J 100 25V Electrolytic
C3101 9GJCEHAT221M25 J 220 25V Electrolytic
C3104 9GJCEHAT470M16 J 47 16V Electrolytic
C3106 9GJCEHAT470M16 J 47 16V Electrolytic
C3134 9GJCEHAT470M16 J 47 16V Electrolytic
C3141 9GJCEHAT470M16 J 47 16V Electrolytic
C3135 9GJCEHAT470M25 J 47 25V Electrolytic
C3154 9GJCKSRYB332K5 J 3300p 50V Ceramic (Chip)
C3163 9GJCKSRYB332K5 J 3300p 50V Ceramic (Chip)
C3103 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3105 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3108 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3109 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3111 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3113 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3114 9GJCKSRYF104Z5 J 0.1 50V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
206
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1930
X DRIVE ASSY (Continued)
C3117 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3130 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3140 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C3147 9GJCKSRYF104Z5 J 0.1 50V Ceramic
RESISTORS
R3183 9GJACN1156 J 15 1/2W Surge Resistor
R3184 9GJACN1156 J 15 1/2W Surge Resistor
R3187 9GJACN1156 J 15 1/2W Surge Resistor
R3113 9GJRAB4C100J J Resistor Array
R3114 9GJRAB4C100J J Resistor Array
R3121 9GJRAB4C100J J Resistor Array
R3122 9GJRAB4C100J J Resistor Array
R3126 9GJRAB4C100J J Resistor Array
R3132 9GJRAB4C100J J Resistor Array
R3140 9GJRAB4C100J J Resistor Array
R3141 9GJRAB4C100J J Resistor Array
R3212 9GJRS1/10S184J J 180k 1/10W Chip
R3217 9GJRS1/10S184J J 180k 1/10W Chip
R3230 9GJRS1/10S184J J 180k 1/10W Chip
R3234 9GJRS1/10S184J J 180k 1/10W Chip
R3237 9GJRS1/10S184J J 180k 1/10W Chip
R3240 9GJRS1/10S184J J 180k 1/10W Chip
R3242 9GJRS1/10S184J J 180k 1/10W Chip
R3245 9GJRS1/10S184J J 180k 1/10W Chip
R3250 9GJRS1/16S3300F J 330 1/16W Chip
R3251 9GJRS1/16S3300F J 330 1/16W Chip
R3252 9GJRS1/16S3300F J 330 1/16W Chip
R3253 9GJRS1/16S3300F J 330 1/16W Chip
R3134 9GJRS1/2S100J J 10 1/2W Chip
R3163 9GJRS1/2S100J J 10 1/2W Chip
R3103 9GJRS1/2S102J J 1k 1/2W Chip
R3109 9GJRS1/2S2R2J J 2.2 1/2W Chip
R3102 9GJRS1/2S561J J 560 1/2W Chip
R3215 9GJRS1MMF101J J 100 Metal Oxide
R3216 9GJRS1MMF101J J 100 Metal Oxide
R3228 9GJRS1MMF122J J 1.2k Metal Oxide
R3229 9GJRS1MMF122J J 1.2k Metal Oxide
R3202 9GJRS1MMF563J J 56k Metal Oxide
R3203 9GJRS1MMF563J J 56k Metal Oxide
R3178 9GJRS2MMF181J J 180k Metal Oxide
R3179 9GJRS2MMF181J J 180k Metal Oxide
R3205 9GJRS1/16S0R0J J 0 1/16W Chip
R3210 9GJRS1/16S0R0J J 0 1/16W Chip
R3219 9GJRS1/16S0R0J J 0 1/16W Chip
R3220 9GJRS1/16S0R0J J 0 1/16W Chip
R3104 9GJRS1/16S100J J 10 1/16W Chip
R3115 9GJRS1/16S100J J 10 1/16W Chip
R3116 9GJRS1/16S100J J 10 1/16W Chip
R3117 9GJRS1/16S100J J 10 1/16W Chip
R3118 9GJRS1/16S100J J 10 1/16W Chip
R3127 9GJRS1/16S100J J 10 1/16W Chip
R3128 9GJRS1/16S100J J 10 1/16W Chip
R3129 9GJRS1/16S100J J 10 1/16W Chip
R3130 9GJRS1/16S100J J 10 1/16W Chip
R3185 9GJRS1/16S100J J 10 1/16W Chip
R3196 9GJRS1/16S100J J 10 1/16W Chip
R3197 9GJRS1/16S100J J 10 1/16W Chip
R3198 9GJRS1/16S100J J 10 1/16W Chip
R3199 9GJRS1/16S100J J 10 1/16W Chip
R3200 9GJRS1/16S100J J 10 1/16W Chip
R3206 9GJRS1/16S100J J 10 1/16W Chip
R3207 9GJRS1/16S100J J 10 1/16W Chip
R3208 9GJRS1/16S100J J 10 1/16W Chip
R3209 9GJRS1/16S100J J 10 1/16W Chip
R3224 9GJRS1/16S100J J 10 1/16W Chip
R3225 9GJRS1/16S100J J 10 1/16W Chip
R3226 9GJRS1/16S100J J 10 1/16W Chip
R3107 9GJRS1/16S101J J 100 1/16W Chip
R3106 9GJRS1/16S102J J 1k 1/16W Chip
R3125 9GJRS1/16S102J J 1k 1/16W Chip
R3190 9GJRS1/16S102J J 1k 1/16W Chip
R3110 9GJRS1/16S103J J 10k 1/16W Chip
R3111 9GJRS1/16S103J J 10k 1/16W Chip
R3186 9GJRS1/16S103J J 10k 1/16W Chip
R3189 9GJRS1/16S103J J 10k 1/16W Chip
R3191 9GJRS1/16S103J J 10k 1/16W Chip
R3192 9GJRS1/16S103J J 10k 1/16W Chip
R3201 9GJRS1/16S103J J 10k 1/16W Chip
R3227 9GJRS1/16S103J J 10k 1/16W Chip
R3135 9GJRS1/16S104J J 100k 1/16W Chip
R3177 9GJRS1/16S113J J 11k 1/16W Chip
R3101 9GJRS1/16S122J J 1.2k 1/16W Chip
R3112 9GJRS1/16S122J J 1.2k 1/16W Chip
R3119 9GJRS1/16S122J J 1.2k 1/16W Chip
R3123 9GJRS1/16S122J J 1.2k 1/16W Chip
R3124 9GJRS1/16S122J J 1.2k 1/16W Chip
R3188 9GJRS1/16S122J J 1.2k 1/16W Chip
R3211 9GJRS1/16S122J J 1.2k 1/16W Chip
R3180 9GJRS1/16S153J J 15k 1/16W Chip
MISCELLANEOUS PARTS
CN3101 9GJKM250MA13 J Plug, 13-pin
CN3102 9GJKM250MA3 J Plug, 3-pin
K3102 9GJAKX9002 J Test Point
K3103 9GJAKX9002 J Test Point
K3104 9GJAKX9002 J Test Point
KN3105 9GJANK-142 J Ground Plate
KN3106 9GJANK-142 J Ground Plate
KN3107 9GJANK-142 J Ground Plate
KN3108 9GJANK-142 J Ground Plate
KN3109 9GJANK-142 J Ground Plate
KN3110 9GJANK-142 J Ground Plate
KN3111 9GJANK-142 J Ground Plate
KN3112 9GJANK-142 J Ground Plate
KN3113 9GJANK-142 J Ground Plate
KN3114 9GJANK-142 J Ground Plate
3101 9GJAEH1049 J Spacer
[X DD CON BLOCK]
INTEGRATED CIRCUITS
IC3712 9GJAN1431M J AN1431M-TLB
IC3701 9GJMIP161 J MIP161
IC3702 9GJTLP181(GR) J TLP181(GR)
IC3703 9GJTLP181(GR) J TLP181(GR)
IC3704 9GJTLP181(GR) J TLP181(GR)
TRANSISTORS
Q3701 9GJ2SC2712 J 2SC2712
Q3800 9GJHN1A01FU J HN1A01FU
DIODES
D3710 9GJ1SS355 J Diode
D3711 9GJ1SS355 J Diode
D3705 9GJD1FL20U(S) J Diode
D3706 9GJD1FL20U(S) J Diode
D3702 9GJEC8FS6 J Diode
D3708 9GJRD110P J Zener Diode
D3709 9GJRD110P J Zener Diode
D3713 9GJRD110P J Zener Diode
D3703 9GJUDZ18B J Zener Diode
D3707 9GJUDZS5.6B J Zener Diode
COIL
L3701 9GJATH1110 J Inductor
TRANSFORMER
T3701 9GJATK1153 J VRN
CONTROL
VR3701 9GJACP1089 J 1k (B)
CAPACITORS
C3701 9GJACH1345 J 22 315V Electrolytic
C3717 9GJACH1346 J 47 350V Electrolytic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
207
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1930
X DRIVE ASSY (Continued)
C3704 9GJCEHAT101M16 J 100 16V Electrolytic
C3706 9GJCEHAT101M25 J 100 25V Electrolytic
C3711 9GJCEHAT101M25 J 100 25V Electrolytic
C3714 9GJCEHAT101M25 J 100 25V Electrolytic
C3712 9GJCEHAT331M16 J 330 16V Electrolytic
C3705 9GJCKSQYF104Z50 J 0.1 50V Ceramic (Chip)
C3703 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
C3707 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
C3708 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
C3710 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
C3715 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
C3716 9GJCKSRYB104K16 J 0.1 16V Ceramic (Chip)
RESISTORS
R3732 9GJRS1/16S1001F J 1k 1/16W Chip
R3806 9GJRS1/16S1802F J 18k 1/16W Chip
R3701 9GJRS1/16S1803F J 180k 1/16W Chip
R3702 9GJRS1/16S1803F J 180k 1/16W Chip
R3703 9GJRS1/16S1803F J 180k 1/16W Chip
R3704 9GJRS1/16S1803F J 180k 1/16W Chip
R3706 9GJRS1/16S1803F J 180k 1/16W Chip
R3707 9GJRS1/16S1803F J 180k 1/16W Chip
R3708 9GJRS1/16S1803F J 180k 1/16W Chip
R3709 9GJRS1/16S1803F J 180k 1/16W Chip
R3710 9GJRS1/16S1803F J 180k 1/16W Chip
R3711 9GJRS1/16S1803F J 180k 1/16W Chip
R3712 9GJRS1/16S1803F J 180k 1/16W Chip
R3713 9GJRS1/16S1803F J 180k 1/16W Chip
R3714 9GJRS1/16S1803F J 180k 1/16W Chip
R3715 9GJRS1/16S1803F J 180k 1/16W Chip
R3716 9GJRS1/16S1803F J 180k 1/16W Chip
R3717 9GJRS1/16S1803F J 180k 1/16W Chip
R3805 9GJRS1/16S2702F J 27k 1/16W Chip
R3731 9GJRS1/16S3900F J 390 1/16W Chip
R3802 9GJRS1/2S102J J 1k 1/2W Chip
R3738 9GJRS1/2S102J J 1k 1/2W Chip
R3739 9GJRS1/2S102J J 1k 1/2W Chip
R3800 9GJRS1/2S823J J 82k 1/2W Chip
R3801 9GJRS1/2S823J J 82k 1/2W Chip
R3705 9GJRS1/16S100J J 10 1/16W Chip
R3724 9GJRS1/16S101J J 100 1/16W Chip
R3726 9GJRS1/16S102J J 1k 1/16W Chip
R3733 9GJRS1/16S102J J 1k 1/16W Chip
R3723 9GJRS1/16S103J J 10k 1/16W Chip
R3725 9GJRS1/16S103J J 10k 1/16W Chip
R3727 9GJRS1/16S103J J 10k 1/16W Chip
R3729 9GJRS1/16S103J J 10k 1/16W Chip
R3730 9GJRS1/16S103J J 10k 1/16W Chip
R3803 9GJRS1/16S103J J 10k 1/16W Chip
R3807 9GJRS1/16S104J J 100k 1/16W Chip
R3721 9GJRS1/16S221J J 220 1/16W Chip
R3736 9GJRS1/16S222J J 2.2k 1/16W Chip
R3734 9GJRS1/16S272J J 2.7k 1/16W Chip
R3719 9GJRS1/16S471J J 470 1/16W Chip
R3728 9GJRS1/16S472J J 4.7k 1/16W Chip
R3735 9GJRS1/16S472J J 4.7k 1/16W Chip
R3737 9GJRS1/16S472J J 4.7k 1/16W Chip
R3804 9GJRS1/16S472J J 4.7k 1/16W Chip
R3720 9GJRS1/16S822J J 8.2k 1/16W Chip
R3722 9GJRS1/16S822J J 8.2k 1/16W Chip
9GJAWZ6683
Y DRIVE ASSY
[Y DRIVE LOGIC BLOCK]
INTEGRATED CIRCUITS
IC2006 9GJPE1013B J PE1013B
IC2007 9GJTC74ACT540FT J TC74ACT540FT
IC2001 9GJTC74ACT541FT J TC74ACT541FT
IC2003 9GJTC74ACT541FT J TC74ACT541FT
IC2004 9GJTC74ACT541FT J TC74ACT541FT
IC2005 9GJTC74ACT541FT J TC74ACT541FT
TRANSISTORS
Q2121 9GJ2SK2201 J 2SK2201
Q2101 9GJHN1C01FU J HN1C01FU
Q2102 9GJHN1C01FU J HN1C01FU
DIODE
D2101 9GJ1SS355 J Diode
COIL
L2001 9GJLFEA100J J Inductor
CAPACITORS
C2101 9GJCEHAT100M50 J 10 50V Electrolytic
C2103 9GJCEHAT1R0M50 J 1 50V Electrolytic
C2003 9GJCEHAT470M16 J 47 16V Electrolytic
C2001 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2004 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2005 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2007 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2008 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2010 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2102 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2104 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2121 9GJCKSRYF104Z5 J 0.1 50V Ceramic
RESISTORS
R2015 9GJRAB4C0R0J J Resistor Array
R2016 9GJRAB4C0R0J J Resistor Array
R2017 9GJRAB4C0R0J J Resistor Array
R2018 9GJRAB4C0R0J J Resistor Array
R2001 9GJRAB4C470J J Resistor Array
R2002 9GJRAB4C470J J Resistor Array
R2005 9GJRAB4C470J J Resistor Array
R2011 9GJRAB4C470J J Resistor Array
R2037 9GJRAB4C470J J Resistor Array
R2038 9GJRAB4C470J J Resistor Array
R2035 9GJRAB4C472J J Resistor Array
R2036 9GJRAB4C472J J Resistor Array
R2039 9GJRAB4C472J J Resistor Array
R2040 9GJRAB4C472J J Resistor Array
R2019 9GJRS1/16S0R0J J 0 1/16W Chip
R2028 9GJRS1/16S0R0J J 0 1/16W Chip
R2032 9GJRS1/16S0R0J J 0 1/16W Chip
R2042 9GJRS1/16S0R0J J 0 1/16W Chip
R2044 9GJRS1/16S0R0J J 0 1/16W Chip
R2105 9GJRS1/16S102J J 1.2k 1/16W Chip
R2106 9GJRS1/16S103J J 10k 1/16W Chip
R2121 9GJRS1/16S123J J 12k 1/16W Chip
R2101 9GJRS1/16S125J J 1.2M 1/16W Chip
R2123 9GJRS1/16S183J J 18k 1/16W Chip
R2102 9GJRS1/16S223J J 22k 1/16W Chip
R2103 9GJRS1/16S333J J 33k 1/16W Chip
R2104 9GJRS1/16S333J J 33k 1/16W Chip
R2107 9GJRS1/16S333J J 33k 1/16W Chip
R2122 9GJRS1/16S393J J 39k 1/16W Chip
MISCELLANEOUS PARTS
CN2001 9GJAKM1201 J Connector, 50-pin
K2001 9GJAKX9002 J Test Point
K2002 9GJAKX9002 J Test Point
K2003 9GJAKX9002 J Test Point
K2004 9GJAKX9002 J Test Point
K2005 9GJAKX9002 J Test Point
K2009 9GJAKX9002 J Test Point
K2010 9GJAKX9002 J Test Point
K2013 9GJAKX9002 J Test Point
K2021 9GJAKX9002 J Test Point
K2027 9GJAKX9002 J Test Point
K2028 9GJAKX9002 J Test Point

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
208
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6683
Y DRIVE ASSY (Continued)
K2029 9GJAKX9002 J Test Point
K2037 9GJAKX9002 J Test Point
K2039 9GJAKX9002 J Test Point
K2040 9GJAKX9002 J Test Point
K2041 9GJAKX9002 J Test Point
K2053 9GJAKX9002 J Test Point
2101 9GJAXX1057 J Senser
9GJBMZ20P040FM J Screw
9GJNB20FMC J Nut
[Y DRIVE SUS BLOCK]
INTEGRATED CIRCUITS
IC2202 9GJHCPL-M611 J HCPL-M611
IC2208 9GJHCPL-M611 J HCPL-M611
IC2206 9GJSTK795-460 J STK795-460
IC2214 9GJSTK795-460 J STK795-460
IC2201 9GJTC74ACT541F J TC74ACT541F
IC2203 9GJTND301S J TND301S
IC2204 9GJTND301S J TND301S
IC2210 9GJTND301S J TND301S
IC2212 9GJTND301S J TND301S
IC2213 9GJTND301S J TND301S
IC2216 9GJTND301S J TND301S
IC2217 9GJTND301S J TND301S
IC2205 9GJUPC78L05T J UPC78L05T
IC2209 9GJUPC78L05T J UPC78L05T
TRANSISTORS
Q2203 9GJ2SJ522 J 2SJ522
Q2204 9GJ2SJ522 J 2SJ522
Q2205 9GJ2SJ522 J 2SJ522
Q2201 9GJ2SK2503 J 2SK2503
Q2215 9GJFQB34N20 J FQB34N20
Q2217 9GJFQB34N20 J FQB34N20
Q2218 9GJFQB34N20 J FQB34N20
Q2219 9GJFQB34N20 J FQB34N20
Q2220 9GJFQB34N20 J FQB34N20
Q2221 9GJFQB34N20 J FQB34N20
Q2226 9GJFQB34N20 J FQB34N20
Q2227 9GJFQB34N20 J FQB34N20
Q2232 9GJFQB34N20 J FQB34N20
Q2233 9GJFQB34N20 J FQB34N20
Q2210 9GJFS16VS-9 J FS16VS-9
Q2211 9GJFS16VS-9 J FS16VS-9
Q2212 9GJFS16VS-9 J FS16VS-9
Q2209 9GJHN1B04FU J HN1B04FU
DIODES
D2225 9GJ1SS184 J Diode
D2202 9GJ1SS226 J Diode
D2204 9GJ1SS226 J Diode
D2211 9GJ1SS355 J Diode
D2201 9GJD1FL40 J Diode
D2203 9GJD1FL40 J Diode
D2205 9GJD1FL40 J Diode
D2208 9GJD1FL40 J Diode
D2210 9GJD1FL40 J Diode
D2212 9GJD1FL40 J Diode
D2214 9GJD1FL40 J Diode
D2215 9GJD1FL40 J Diode
D2216 9GJD1FL40 J Diode
D2221 9GJD1FL40 J Diode
D2222 9GJD1FL40 J Diode
D2223 9GJD1FL40 J Diode
D2226 9GJD1FL40 J Diode
D2227 9GJD1FL40 J Diode
D2228 9GJD1FL40 J Diode
D2239 9GJD1FL40 J Diode
D2243 9GJD1FL40 J Diode
D2209 9GJDF20L60 J Diode
D2206 9GJUDZ15B J Zener Diode
D2207 9GJUDZ15B J Zener Diode
COILS
L2207 9GJATH1110 J Inductor
L2213 9GJATH1112 J Inductor
L2214 9GJATH1112 J Inductor
L2206 9GJATH1113 J Choke Coil
L2211 9GJATH1113 J Choke Coil
L2208 9GJATH1118 J Choke Coil
L2212 9GJATH1118 J Choke Coil
L2215 9GJATH1118 J Choke Coil
L2216 9GJATH1118 J Choke Coil
L2210 9GJLFEA100J J Inductor
L2203 9GJLFEA101J J Inductor
L2205 9GJLFEA101J J Inductor
L2201 9GJLFEA470J J Inductor
L2204 9GJLFEA470J J Inductor
CONTROLS
VR2201 9GJACP1089 J 1k (B)
VR2202 9GJACP1089 J 1k (B)
VR2203 9GJACP1089 J 1k (B)
VR2204 9GJACP1089 J 1k (B)
CAPACITORS
C2228 9GJACE1160 J 1.5 250V Ceramic
C2230 9GJACE1160 J 1.5 250V Ceramic
C2231 9GJACE1160 J 1.5 250V Ceramic
C2250 9GJACE1160 J 1.5 250V Ceramic
C2251 9GJACE1160 J 1.5 250V Ceramic
C2252 9GJACE1160 J 1.5 250V Ceramic
C2209 9GJACG1092 J 0.1 630V Ceramic
C2210 9GJACG1092 J 0.1 630V Ceramic
C2233 9GJACG1100 J 100p 500V Ceramic
C2248 9GJACG1100 J 100p 500V Ceramic
C2211 9GJACH1346 J 47 350V Electrolytic
C2216 9GJACH1348 J 330 315V Electrolytic
C2217 9GJACH1348 J 330 315V Electrolytic
C2219 9GJACH1348 J 330 315V Electrolytic
C2234 9GJACH1348 J 330 315V Electrolytic
C2235 9GJACH1348 J 330 315V Electrolytic
C2236 9GJACH1348 J 330 315V Electrolytic
C2253 9GJCCSRCH331J5 J 330p 50V Ceramic
C2254 9GJCCSRCH331J5 J 330p 50V Ceramic
C2255 9GJCCSRCH331J5 J 330p 50V Ceramic
C2256 9GJCCSRCH331J5 J 330p 50V Ceramic
C2257 9GJCCSRCH331J5 J 330p 50V Ceramic
C2258 9GJCCSRCH331J5 J 330p 50V Ceramic
C2259 9GJCCSRCH331J5 J 330p 50V Ceramic
C2260 9GJCCSRCH331J5 J 330p 50V Ceramic
C2221 9GJCEHAT101M16 J 100 16V Electrolytic
C2225 9GJCEHAT101M16 J 100 16V Electrolytic
C2226 9GJCEHAT101M16 J 100 16V Electrolytic
C2246 9GJCEHAT101M16 J 100 16V Electrolytic
C2204 9GJCEHAT101M25 J 100 25V Electrolytic
C2227 9GJCEHAT101M25 J 100 25V Electrolytic
C2237 9GJCEHAT101M25 J 100 25V Electrolytic
C2240 9GJCEHAT101M25 J 100 25V Electrolytic
C2247 9GJCEHAT101M25 J 100 25V Electrolytic
C2202 9GJCEHAT221M25 J 220 25V Electrolytic
C2232 9GJCEHAT331M2A J 330 25V Electrolytic
C2218 9GJCEHAT470M16 J 47 16V Electrolytic
C2224 9GJCEHAT470M16 J 47 16V Electrolytic
C2229 9GJCEHAT470M16 J 47 16V Electrolytic
C2212 9GJCEHAT470M25 J 47 25V Electrolytic
C2214 9GJCEHAT470M25 J 47 25V Electrolytic
C2264 9GJCKSRYB472K5 J 4700p 50V Ceramic
C2270 9GJCKSRYB472K5 J 4700p 50V Ceramic
C2201 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2203 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2205 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2208 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2213 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2220 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2222 9GJCKSRYF104Z5 J 0.1 50V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
209
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6683
Y DRIVE ASSY (Continued)
C2223 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2238 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2239 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2241 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2242 9GJCKSRYF104Z5 J 0.1 50V Ceramic
RESISTORS
R2235 9GJRAB4C100J J Resistor Array
R2273 9GJRAB4C100J J Resistor Array
R2291 9GJRAB4C100J J Resistor Array
R2305 9GJRAB4C100J J Resistor Array
R2315 9GJRAB4C100J J Resistor Array
R2317 9GJRAB4C100J J Resistor Array
R2342 9GJRAB4C100J J Resistor Array
R2253 9GJRS1/10S184J J 180k 1/10W Chip
R2256 9GJRS1/10S184J J 180k 1/10W Chip
R2270 9GJRS1/10S184J J 180k 1/10W Chip
R2283 9GJRS1/10S184J J 180k 1/10W Chip
R2332 9GJRS1/10S184J J 180k 1/10W Chip
R2338 9GJRS1/10S184J J 180k 1/10W Chip
R2354 9GJRS1/10S184J J 180k 1/10W Chip
R2355 9GJRS1/10S184J J 180k 1/10W Chip
R2358 9GJRS1/16S3300F J 330p 1/16W Chip
R2359 9GJRS1/16S3300F J 330p 1/16W Chip
R2360 9GJRS1/16S3300F J 330p 1/16W Chip
R2361 9GJRS1/16S3300F J 330p 1/16W Chip
R2263 9GJRS1/2S100J J 10 1/2W Chip
R2264 9GJRS1/2S100J J 10 1/2W Chip
R2203 9GJRS1/2S102J J 1k 1/2W Chip
R2209 9GJRS1/2S2R2J J 2.2 1/2W Chip
R2202 9GJRS1/2S561J J 560 1/2W Chip
R2278 9GJRS1MMF101J J 100 1W Metal Oxide
R2303 9GJRS1MMF101J J 100 1W Metal Oxide
R2233 9GJRS1MMF152J J 1.5k 1W Metal Oxide
R2234 9GJRS1MMF152J J 1.5k 1W Metal Oxide
R2274 9GJRS1MMF471J J 470 1W Metal Oxide
R2275 9GJRS1MMF471J J 470 1W Metal Oxide
R2298 9GJRS2MMF3R3J J 3.3 2W Metal Oxide
R2299 9GJRS2MMF3R3J J 3.3 2W Metal Oxide
R2277 9GJRS3LMFR47J J 0.47 3W Metal Oxide
R2276 9GJRS3LMFR56J J 0.56 3W Metal Oxide
R2265 9GJRS1/16S0R0J J 0 1/16W Chip
R2268 9GJRS1/16S0R0J J 0 1/16W Chip
R2269 9GJRS1/16S0R0J J 0 1/16W Chip
R2326 9GJRS1/16S0R0J J 0 1/16W Chip
R2327 9GJRS1/16S0R0J J 0 1/16W Chip
R2204 9GJRS1/16S100J J 10 1/16W Chip
R2212 9GJRS1/16S100J J 10 1/16W Chip
R2213 9GJRS1/16S100J J 10 1/16W Chip
R2214 9GJRS1/16S100J J 10 1/16W Chip
R2215 9GJRS1/16S100J J 10 1/16W Chip
R2216 9GJRS1/16S100J J 10 1/16W Chip
R2217 9GJRS1/16S100J J 10 1/16W Chip
R2221 9GJRS1/16S100J J 10 1/16W Chip
R2251 9GJRS1/16S100J J 10 1/16W Chip
R2252 9GJRS1/16S100J J 10 1/16W Chip
R2271 9GJRS1/16S100J J 10 1/16W Chip
R2272 9GJRS1/16S100J J 10 1/16W Chip
R2285 9GJRS1/16S100J J 10 1/16W Chip
R2290 9GJRS1/16S100J J 10 1/16W Chip
R2295 9GJRS1/16S100J J 10 1/16W Chip
R2296 9GJRS1/16S100J J 10 1/16W Chip
R2297 9GJRS1/16S100J J 10 1/16W Chip
R2304 9GJRS1/16S100J J 10 1/16W Chip
R2311 9GJRS1/16S100J J 10 1/16W Chip
R2312 9GJRS1/16S100J J 10 1/16W Chip
R2328 9GJRS1/16S100J J 10 1/16W Chip
R2339 9GJRS1/16S100J J 10 1/16W Chip
R2207 9GJRS1/16S101J J 100 1/16W Chip
R2249 9GJRS1/16S101J J 100 1/16W Chip
R2206 9GJRS1/16S102J J 1k 1/16W Chip
R2230 9GJRS1/16S102J J 1k 1/16W Chip
R2248 9GJRS1/16S102J J 1k 1/16W Chip
R2210 9GJRS1/16S103J J 10k 1/16W Chip
R2211 9GJRS1/16S103J J 10k 1/16W Chip
R2218 9GJRS1/16S103J J 10k 1/16W Chip
R2219 9GJRS1/16S103J J 10k 1/16W Chip
R2222 9GJRS1/16S104J J 100k 1/16W Chip
R2229 9GJRS1/16S122J J 1.2k 1/16W Chip
R2228 9GJRS1/16S332J J 3.3k 1/16W Chip
R2205 9GJRS1/16S471J J 470 1/16W Chip
R2247 9GJRS1/16S471J J 470 1/16W Chip
R2208 9GJRS1/16S512J J 5.1k 1/16W Chip
R2201 9GJRS1/16S821J J 820 1/16W Chip
R2220 9GJRS1/16S821J J 820 1/16W Chip
MISCELLANEOUS PARTS
CN2201 9GJKM250MA15 J Plug, 15-pin
CN2202 9GJKM250MA3 J Plug, 3-pin
K2211 9GJAKX9002 J Test Point
K2214 9GJAKX9002 J Test Point
K2213 9GJAKX9002 J Test Point
K2214 9GJAKX9002 J Test Point
K2215 9GJAKX9002 J Test Point
K2216 9GJAKX9002 J Test Point
K2217 9GJAKX9002 J Test Point
KN2201 9GJANK-142 J Ground Plate
KN2202 9GJANK-142 J Ground Plate
KN2203 9GJANK-142 J Ground Plate
KN2204 9GJANK-142 J Ground Plate
KN2205 9GJANK-142 J Ground Plate
KN2206 9GJANK-142 J Ground Plate
KN2207 9GJANK-142 J Ground Plate
KN2208 9GJANK-142 J Ground Plate
KN2209 9GJANK-142 J Ground Plate
KN2210 9GJANK-142 J Ground Plate
2201 9GJAEH1049 J Spacer
[Y DRIVE SCAN BLOCK]
INTEGRATED CIRCUITS
IC2501 9GJHCPL-M611 J HCPL-M611
IC2502 9GJHCPL-M611 J HCPL-M611
IC2505 9GJHCPL-M611 J HCPL-M611
IC2510 9GJHCPL-M611 J HCPL-M611
IC2512 9GJHCPL-M611 J HCPL-M611
IC2513 9GJHCPL-M611 J HCPL-M611
IC2514 9GJHCPL-M611 J HCPL-M611
IC2516 9GJHCPL-M611 J HCPL-M611
IC2525 9GJHCPL-M611 J HCPL-M611
IC2503 9GJTC74ACT540F J TC74ACT540F
IC2504 9GJTC74ACT540F J TC74ACT540F
IC2506 9GJTC74ACT540F J TC74ACT540F
COILS
L2501 9GJLFEA100J J Inductor
L2502 9GJLFEA100J J Inductor
L2503 9GJLFEA100J J Inductor
CAPACITORS
C2506 9GJCEHAT220M2D J 22 200V Electrolytic
C2527 9GJCEHAT220M2D J 22 200V Electrolytic
C2502 9GJCEHAT221M16 J 220 16V Electrolytic
C2524 9GJCEHAT470M16 J 47 16V Electrolytic
C2525 9GJCEHAT470M16 J 47 16V Electrolytic
C2501 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2503 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2504 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2505 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2507 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2508 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2513 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2515 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2516 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2517 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2519 9GJCKSRYF104Z5 J 0.1 50V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
210
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6683
Y DRIVE ASSY (Continued)
C2530 9GJCKSRYF104Z5 J 0.1 50V Ceramic
RESISTORS
R2502 9GJRAB4C101J J Resistor Array
R2504 9GJRAB4C101J J Resistor Array
R2571 9GJRS1/16S0R0J J 0 1/16W Chip
R2573 9GJRS1/16S0R0J J 0 1/16W Chip
R2574 9GJRS1/16S0R0J J 0 1/16W Chip
R2575 9GJRS1/16S0R0J J 0 1/16W Chip
R2508 9GJRS1/16S101J J 100 1/16W Chip
R2501 9GJRS1/16S102J J 1k 1/16W Chip
R2509 9GJRS1/16S102J J 1k 1/16W Chip
R2519 9GJRS1/16S102J J 1k 1/16W Chip
R2534 9GJRS1/16S102J J 1k 1/16W Chip
R2541 9GJRS1/16S102J J 1k 1/16W Chip
R2543 9GJRS1/16S102J J 1k 1/16W Chip
R2546 9GJRS1/16S102J J 1k 1/16W Chip
R2552 9GJRS1/16S102J J 1k 1/16W Chip
R2569 9GJRS1/16S102J J 1k 1/16W Chip
R2503 9GJRS1/16S471J J 470 1/16W Chip
R2505 9GJRS1/16S471J J 470 1/16W Chip
R2506 9GJRS1/16S471J J 470 1/16W Chip
R2507 9GJRS1/16S471J J 470 1/16W Chip
R2512 9GJRS1/16S471J J 470 1/16W Chip
R2525 9GJRS1/16S471J J 470 1/16W Chip
R2533 9GJRS1/16S471J J 470 1/16W Chip
R2545 9GJRS1/16S471J J 470 1/16W Chip
R2551 9GJRS1/16S471J J 470 1/16W Chip
MISCELLANEOUS PARTS
CN2501 9GJAKM1200 J Connector, 15-pin
CN2502 9GJAKM1200 J Connector, 15-pin
[Y DRIVE DD-CON BLOCK]
INTEGRATED CIRCUITS
IC2715 9GJAN1431M J AN1431M
IC2716 9GJAN1431M J AN1431M
IC2717 9GJAN1431M J AN1431M
IC2709 9GJHCNR201 J HCNR201
IC2708 9GJM5223AFP J M5223AFP
IC2710 9GJM5223AFP J M5223AFP
IC2718 9GJM5223AFP J M5223AFP
IC2711 9GJMIP0223SC J MIP0223SC
IC2701 9GJMIP161 J MIP161
IC2704 9GJMIP301 J MIP301
IC2702 9GJTLP181(GR) J TLP181
IC2703 9GJTLP181(GR) J TLP181
IC2705 9GJTLP181(GR) J TLP181
IC2706 9GJTLP181(GR) J TLP181
IC2707 9GJTLP181(GR) J TLP181
IC2712 9GJTLP181(GR) J TLP181
IC2713 9GJTLP181(GR) J TLP181
IC2714 9GJTLP181(GR) J TLP181
TRANSISOTRS
Q2701 9GJ2SC2712 J 2SC2712
Q2703 9GJ2SC2712 J 2SC2712
Q2704 9GJHN1A01FU J HN1A01FU
DIODES
D2712 9GJ1SS355 J Diode
D2717 9GJ1SS355 J Diode
D2718 9GJ1SS355 J Diode
D2732 9GJ1SS355 J Diode
D2734 9GJ1SS355 J Diode
D2736 9GJ1SS355 J Diode
D2737 9GJ1SS355 J Diode
D2704 9GJD1FL20U(S) J Diode
D2706 9GJD1FL20U(S) J Diode
D2707 9GJD1FL20U(S) J Diode
D2715 9GJD1FL20U(S) J Diode
D2726 9GJD1FL20U(S) J Diode
D2728 9GJD1FL20U(S) J Diode
D2702 9GJD1FL40 J Diode
D2714 9GJD1FL40 J Diode
D2727 9GJD1FL40 J Diode
D2711 9GJD1FS4 J Diode
D2725 9GJEC8FS6 J Diode
D2733 9GJRD110P J Zener Diode
D2724 9GJU1ZB330 J Zener Diode
D2713 9GJU1ZB36 J Zener Diode
D2740 9GJUDZ12B J Zener Diode
D2709 9GJUDZ3.6B J Zener Diode
D2716 9GJUDZ3.6B J Zener Diode
D2729 9GJUDZ33B J Zener Diode
D2731 9GJUDZ33B J Zener Diode
D2703 9GJUDZ36B J Zener Diode
D2710 9GJUDZ36B J Zener Diode
D2720 9GJUDZS5.6B J Zener Diode
D2730 9GJUDZS5.6B J Zener Diode
D2739 9GJUDZS5.6B J Zener Diode
COIL
L2701 9GJATH1110 J Inductor
TRANSFORMERS
T2702 9GJATK1150 J SMD Transformeer
T2703 9GJATK1151 J VH Transformer
T2701 9GJATK1152 J VOFS Transformer
CONTROLS
VR2702 9GJACP1089 J 1k (B)
VR2703 9GJACP1089 J 1k (B)
VR2701 9GJACP1090 J 2.2k (B)
CAPACITORS
C2701 9GJACH1345 J 22 315V Electrolytic
C2735 9GJACH1345 J 22 315V Electrolytic
C2706 9GJCEHAT101M16 J 100 16V Electrolytic
C2725 9GJCEHAT101M16 J 100 16V Electrolytic
C2737 9GJCEHAT101M16 J 100 16V Electrolytic
C2709 9GJCEHAT101M25 J 100 25V Electrolytic
C2718 9GJCEHAT101M25 J 100 25V Electrolytic
C2720 9GJCEHAT101M25 J 100 25V Electrolytic
C2739 9GJCEHAT101M25 J 100 25V Electrolytic
C2745 9GJCEHAT101M25 J 100 25V Electrolytic
C2708 9GJCEHAT101M2A J 100 200V Electrolytic
C2740 9GJCEHAT101M2C J 100 200V Electrolytic
C2704 9GJCEHAT221M25 J 220 25V Electrolytic
C2715 9GJCEHAT331M16 J 330 16V Electrolytic
C2746 9GJCEHAT331M25 J 330 25V Electrolytic
C2723 9GJCEHAT470M16 J 47 16V Electrolytic
C2751 9GJCEHAT470M16 J 47 16V Electrolytic
C2712 9GJCEHAT471M35 J 470 35V Electrolytic
C2711 9GJCKSRYB103K5 J 0.01 50V Ceramic
C2705 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2713 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2714 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2719 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2721 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2722 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2724 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2727 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2729 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2731 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2733 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2736 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2742 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2743 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2747 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2748 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2749 9GJCKSRYB104K16 J 0.1 16V Ceramic
C2728 9GJCKSRYB471K50 J 470 50V Ceramic
C2730 9GJCKSRYB471K50 J 470 50V Ceramic
C2707 9GJCKSRYF104Z5 J 0.1 50V Ceramic
C2738 9GJCKSRYF104Z5 J 0.1 50V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
211
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6683
Y DRIVE ASSY (Continued)
RESISTORS
R2735 9GJRS1/16S1000F J 100 1/16W Chip
R2791 9GJRS1/16S1000F J 100 1/16W Chip
R2780 9GJRS1/16S1103F J 110 1/16W Chip
R2715 9GJRS1/16S1201F J 1.2k 1/16W Chip
R2728 9GJRS1/16S1201F J 1.2k 1/16W Chip
R2733 9GJRS1/16S1201F J 1.2k 1/16W Chip
R2787 9GJRS1/16S1302F J 13k 1/16W Chip
R2766 9GJRS1/16S1501F J 1.5k 1/16w Chip
R2785 9GJRS1/16S1503F J 150k 1/16W Chip
R2777 9GJRS1/16S1802F J 18k 1/16W Chip
R2786 9GJRS1/16S1802F J 18k 1/16W Chip
R2776 9GJRS1/16S2702F J 27k 1/16W Chip
R2705 9GJRS1/16S3002F J 30k 1/16W Chip
R2706 9GJRS1/16S3002F J 30k 1/16W Chip
R2709 9GJRS1/16S3002F J 30k 1/16W Chip
R2710 9GJRS1/16S3002F J 30k 1/16W Chip
R2778 9GJRS1/16S3002F J 30k 1/16W Chip
R2781 9GJRS1/16S3002F J 30k 1/16W Chip
R2783 9GJRS1/16S4701F J 4.7k 1/16W Chip
R2734 9GJRS1/16S4702F J 47k 1/16W Chip
R2736 9GJRS1/16S4702F J 47k 1/16W Chip
R2779 9GJRS1/16S5102F J 51k 1/16W Chip
R2773 9GJRS1/16S5601F J 5.6k 1/16W Chip
R2784 9GJRS1/16S5602F J 56k 1/16W Chip
R2782 9GJRS1/16S6801F J 6.8k 1/16W Chip
R2744 9GJRS1/16S9102F J 91k 1/16W Chip
R2745 9GJRS1/16S9102F J 91k 1/16W Chip
R2746 9GJRS1/16S9102F J 91k 1/16W Chip
R2747 9GJRS1/16S9102F J 91k 1/16W Chip
R2748 9GJRS1/16S9102F J 91k 1/16W Chip
R2749 9GJRS1/16S9102F J 91k 1/16W Chip
R2750 9GJRS1/16S9102F J 91k 1/16W Chip
R2751 9GJRS1/16S9102F J 91k 1/16W Chip
R2752 9GJRS1/16S9102F J 91k 1/16W Chip
R2753 9GJRS1/16S9102F J 91k 1/16W Chip
R2711 9GJRS1/2S102J J 1k 1/2W Chip
R2716 9GJRS1/2S102J J 1k 1/2W Chip
R2767 9GJRS1/2S102J J 1k 1/2W Chip
R2770 9GJRS1/2S102J J 1k 1/2W Chip
R2788 9GJRS1/2S561J J 560 1/2W Chip
R2792 9GJRS1/2S561J J 560 1/2W Chip
R2771 9GJRS1/2S823J J 82k 1/2W Chip
R2772 9GJRS1/2S823J J 82k 1/2W Chip
R2712 9GJRS3LMF272J J 2.7k 3W Metal Oxide
R2707 9GJRS1/16S100J J 10 1/16W Chip
R2725 9GJRS1/16S100J J 10 1/16W Chip
R2743 9GJRS1/16S100J J 10 1/16W Chip
R2717 9GJRS1/16S101J J 100 1/16W Chip
R2732 9GJRS1/16S101J J 100 1/16W Chip
R2759 9GJRS1/16S101J J 100 1/16W Chip
R2713 9GJRS1/16S102J J 1k 1/16W Chip
R2718 9GJRS1/16S102J J 1k 1/16W Chip
R2754 9GJRS1/16S102J J 1k 1/16W Chip
R2760 9GJRS1/16S102J J 1k 1/16W Chip
R2790 9GJRS1/16S102J J 1k 1/16W Chip
R2714 9GJRS1/16S103J J 10k 1/16W Chip
R2719 9GJRS1/16S103J J 10k 1/16W Chip
R2729 9GJRS1/16S103J J 10k 1/16W Chip
R2730 9GJRS1/16S103J J 10k 1/16W Chip
R2739 9GJRS1/16S103J J 10k 1/16W Chip
R2755 9GJRS1/16S103J J 10k 1/16W Chip
R2758 9GJRS1/16S103J J 10k 1/16W Chip
R2761 9GJRS1/16S103J J 10k 1/16W Chip
R2764 9GJRS1/16S103J J 10k 1/16W Chip
R2765 9GJRS1/16S103J J 10k 1/16W Chip
R2789 9GJRS1/16S104J J 100k 1/16W Chip
R2726 9GJRS1/16S151J J 150 1/16W Chip
R2727 9GJRS1/16S151J J 150 1/16W Chip
R2747 9GJRS1/16S221J J 220 1/16W Chip
R2757 9GJRS1/16S221J J 220 1/16W Chip
R2723 9GJRS1/16S222J J 2.2k 1/16W Chip
R2763 9GJRS1/16S222J J 2.2k 1/16W Chip
R2720 9GJRS1/16S272J J 2.7k 1/16W Chip
R2768 9GJRS1/16S272J J 2.7k 1/16W Chip
R2737 9GJRS1/16S470J J 47 1/16W Chip
R2702 9GJRS1/16S471J J 470 1/16W Chip
R2721 9GJRS1/16S472J J 4.7k 1/16W Chip
R2722 9GJRS1/16S472J J 4.7k 1/16W Chip
R2724 9GJRS1/16S472J J 4.7k 1/16W Chip
R2731 9GJRS1/16S472J J 4.7k 1/16W Chip
R2756 9GJRS1/16S472J J 4.7k 1/16W Chip
R2762 9GJRS1/16S472J J 4.7k 1/16W Chip
R2769 9GJRS1/16S472J J 4.7k 1/16W Chip
R2774 9GJRS1/16S472J J 4.7k 1/16W Chip
R2775 9GJRS1/16S472J J 4.7k 1/16W Chip
9GJAWZ6692
SUB ADDRESS (A) ASSY
INTEGRATED CIRCUITS
IC8801 9GJM5223AFP J M5223AFP
IC8802 9GJM5223AFP J M5223AFP
IC8804 9GJM5223AFP J M5223AFP
IC8803 9GJTC74VHC74FT J TC74VHC74FT
TRANSISOTRS
Q8801 9GJ2SA1163 J 2SA1163
Q8802 9GJ2SA1163 J 2SA1163
Q8803 9GJ2SC2712 J 2SC2712
Q8804 9GJ2SC2712 J 2SC2712
Q8805 9GJ2SC2712 J 2SC2712
Q8808 9GJ2SC2712 J 2SC2712
Q8806 9GJ2SK209 J 2SK209
DIODES
D8801 9GJ1SS355 J Diode
D8802 9GJ1SS355 J Diode
D8803 9GJ1SS355 J Diode
D8809 9GJ1SS355 J Diode
D8806 9GJDA227 J Diode
D8807 9GJDA227 J Diode
D8808 9GJUDZ27B J Zener Diode
D8804 9GJUDZS5.1B J Zener Diode
COILS
L8801 9GJATH1074 J Choke Coil 100µH/0.45A
L8802 9GJATH1081 J Coil 22µH/0.11A (Chip)
L8803 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C8806 9GJCCSRCH101J5 J 100p 50V Ceramic
C8822 9GJCEHV100M16 J 10 16V Electrolytic
C8804 9GJCEHV100M35 J 10 35V Electrolytic
C8801 9GJCEHV470M16 J 47 16V Electrolytic
C8808 9GJCEHV470M16 J 47 16V Electrolytic
C8807 9GJCEVNP2R2M35 J 2.2 35V Electrolytic
C8802 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8803 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8805 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8809 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8810 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8811 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8812 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8813 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8814 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8815 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8816 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8817 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8820 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8821 9GJCKSRYF104Z1 J 0.1 16V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
212
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
RESISTORS
R8806 9GJRS1/16S1002 J 10k 1/16W Chip
R8807 9GJRS1/16S1002 J 10k 1/16W Chip
R8837 9GJRS1/16S1002 J 10k 1/16W Chip
R8838 9GJRS1/16S1002 J 10k 1/16W Chip
R8841 9GJRS1/16S1002 J 10k 1/16W Chip
R8858 9GJRS1/16S1202 J 12k 1/16W Chip
R8828 9GJRS1/16S2202 J 22k 1/16W Chip
R8829 9GJRS1/16S2202 J 22k 1/16W Chip
R8832 9GJRS1/16S2202 J 22k 1/16W Chip
R8846 9GJRS1/16S2202 J 22k 1/16W Chip
R8864 9GJRS1/16S2202 J 22k 1/16W Chip
R8826 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8827 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8839 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8840 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8833 9GJRS1/16S4702 J 47k 1/16W Chip
R8859 9GJRS1/16S5602 J 56k 1/16W Chip
R8801 9GJRS1/2S1R5J J 1.5 1/2W Chip
R8802 9GJRS1/2S1R5J J 1.5 1/2W Chip
R8803 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8804 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8805 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8809 9GJRS1/16S102J J 1k 1/16W Chip
R8808 9GJRS1/16S103J J 10k 1/16W Chip
R8819 9GJRS1/16S103J J 10k 1/16W Chip
R8822 9GJRS1/16S103J J 10k 1/16W Chip
R8834 9GJRS1/16S103J J 10k 1/16W Chip
R8855 9GJRS1/16S103J J 10k 1/16W Chip
R8860 9GJRS1/16S103J J 10k 1/16W Chip
R8861 9GJRS1/16S103J J 10k 1/16W Chip
R8823 9GJRS1/16S104J J 100k 1/16W Chip
R8813 9GJRS1/16S105J J 1M 1/16W Chip
R8851 9GJRS1/16S220J J 22 1/16W Chip
R8868 9GJRS1/16S220J J 22 1/16W Chip
R8847 9GJRS1/16S222J J 2.2k 1/16W Chip
R8848 9GJRS1/16S222J J 2.2k 1/16W Chip
R8821 9GJRS1/16S223J J 22k 1/16W Chip
R8849 9GJRS1/16S223J J 22k 1/16W Chip
R8852 9GJRS1/16S223J J 22k 1/16W Chip
R8816 9GJRS1/16S272J J 2.7k 1/16W Chip
R8810 9GJRS1/16S273J J 27k 1/16W Chip
R8814 9GJRS1/16S332J J 3.3k 1/16W Chip
R8815 9GJRS1/16S333J J 33k 1/16W Chip
R8817 9GJRS1/16S333J J 33k 1/16W Chip
R8818 9GJRS1/16S333J J 33k 1/16W Chip
R8820 9GJRS1/16S472J J 4.7k 1/16W Chip
R8830 9GJRS1/16S472J J 4.7k 1/16W Chip
R8831 9GJRS1/16S472J J 4.7k 1/16W Chip
R8854 9GJRS1/16S472J J 4.7k 1/16W Chip
R8811 9GJRS1/16S682J J 6.8k 1/16W Chip
R8812 9GJRS1/16S682J J 6.8k 1/16W Chip
R8842 9GJRS1/16S682J J 6.8k 1/16W Chip
R8862 9GJRS1/16S682J J 6.8k 1/16W Chip
R8865 9GJRS1/16S682J J 6.8k 1/16W Chip
MISCELLANEOUS PARTS
CN8803 9GJAKM1205 J Connector, 23-pin
CN8801 9GJS3B-PH-SM3 J PH Connector
CN8802 9GJS8B-PH-SM3 J PH Connector
9GJAWZ6693
SUB ADDRESS (B) ASSY
INTEGRATED CIRCUITS
IC8901 9GJM5223AFP J M5223AFP
IC8902 9GJM5223AFP J M5223AFP
IC8904 9GJM5223AFP J M5223AFP
IC8903 9GJTC74VHC74FT J TC74VHC74FT
TRANSISOTRS
Q8901 9GJ2SA1163 J 2SA1163
Q8902 9GJ2SA1163 J 2SA1163
Q8903 9GJ2SC2712 J 2SC2712
Q8904 9GJ2SC2712 J 2SC2712
Q8905 9GJ2SC2712 J 2SC2712
Q8908 9GJ2SC2712 J 2SC2712
Q8906 9GJ2SK209 J 2SK209
DIODES
D8901 9GJ1SS355 J Diode
D8902 9GJ1SS355 J Diode
D8903 9GJ1SS355 J Diode
D8909 9GJ1SS355 J Diode
D8906 9GJDA227 J Diode
D8907 9GJDA227 J Diode
D8908 9GJUDZ27B J Zener Diode
D8904 9GJUDZS5.1B J Zener Diode
COILS
L8901 9GJATH1074 J Choke Coil 100µH/0.45A
L8902 9GJATH1081 J Coil 22µH/0.11A (Chip)
L8903 9GJATH1081 J Coil 22µH/0.11A (Chip)
CAPACITORS
C8906 9GJCCSRCH101J5 J 100p 50V Ceramic
C8922 9GJCEHV100M16 J 10 16V Electrolytic
C8904 9GJCEHV100M35 J 10 35V Electrolytic
C8901 9GJCEHV470M16 J 47 16V Electrolytic
C8908 9GJCEHV470M16 J 47 16V Electrolytic
C8907 9GJCEVNP2R2M35 J 2.2 35V Electrolytic
C8902 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8903 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8905 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8909 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8910 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8911 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8912 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8913 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8914 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8915 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8916 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8917 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8920 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C8921 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R8906 9GJRS1/16S1002 J 10k 1/16W Chip
R8907 9GJRS1/16S1002 J 10k 1/16W Chip
R8937 9GJRS1/16S1002 J 10k 1/16W Chip
R8938 9GJRS1/16S1002 J 10k 1/16W Chip
R8941 9GJRS1/16S1002 J 10k 1/16W Chip
R8958 9GJRS1/16S1202 J 12k 1/16W Chip
R8928 9GJRS1/16S2202 J 22k 1/16W Chip
R8929 9GJRS1/16S2202 J 22k 1/16W Chip
R8932 9GJRS1/16S2202 J 22k 1/16W Chip
R8946 9GJRS1/16S2202 J 22k 1/16W Chip
R8964 9GJRS1/16S2202 J 22k 1/16W Chip
R8926 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8927 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8939 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8940 9GJRS1/16S4701 J 4.7k 1/16W Chip
R8933 9GJRS1/16S4702 J 47k 1/16W Chip
R8959 9GJRS1/16S5602 J 56k 1/16W Chip
R8901 9GJRS1/2S1R5J J 1.5 1/2W Chip
R8902 9GJRS1/2S1R5J J 1.5 1/2W Chip
R8903 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8904 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8905 9GJRS1/2S2R2J J 2.2 1/2W Chip
R8909 9GJRS1/16S102J J 1k 1/16W Chip
R8908 9GJRS1/16S103J J 10k 1/16W Chip
R8919 9GJRS1/16S103J J 10k 1/16W Chip
9GJAWZ6692
SUB ADDRESS (A) ASSY (Continued)

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
213
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWZ6693
SUB ADDRESS (B) ASSY (Continued)
R8922 9GJRS1/16S103J J 10k 1/16W Chip
R8934 9GJRS1/16S103J J 10k 1/16W Chip
R8955 9GJRS1/16S103J J 10k 1/16W Chip
R8960 9GJRS1/16S103J J 10k 1/16W Chip
R8961 9GJRS1/16S103J J 10k 1/16W Chip
R8923 9GJRS1/16S104J J 100k 1/16W Chip
R8913 9GJRS1/16S105J J 1M 1/16W Chip
R8951 9GJRS1/16S220J J 22 1/16W Chip
R8968 9GJRS1/16S220J J 22 1/16W Chip
R8947 9GJRS1/16S222J J 2.2k 1/16W Chip
R8948 9GJRS1/16S222J J 2.2k 1/16W Chip
R8921 9GJRS1/16S223J J 22k 1/16W Chip
R8949 9GJRS1/16S223J J 22k 1/16W Chip
R8952 9GJRS1/16S223J J 22k 1/16W Chip
R8916 9GJRS1/16S272J J 2.7k 1/16W Chip
R8910 9GJRS1/16S273J J 27k 1/16W Chip
R8914 9GJRS1/16S332J J 3.3k 1/16W Chip
R8915 9GJRS1/16S333J J 33k 1/16W Chip
R8917 9GJRS1/16S333J J 33k 1/16W Chip
R8918 9GJRS1/16S333J J 33k 1/16W Chip
R8920 9GJRS1/16S472J J 4.7k 1/16W Chip
R8930 9GJRS1/16S472J J 4.7k 1/16W Chip
R8931 9GJRS1/16S472J J 4.7k 1/16W Chip
R8954 9GJRS1/16S472J J 4.7k 1/16W Chip
R8911 9GJRS1/16S682J J 6.8k 1/16W Chip
R8912 9GJRS1/16S682J J 6.8k 1/16W Chip
R8942 9GJRS1/16S682J J 6.8k 1/16W Chip
R8962 9GJRS1/16S682J J 6.8k 1/16W Chip
R8965 9GJRS1/16S682J J 6.8k 1/16W Chip
MISCELLANEOUS PARTS
CN8903 9GJAKM1205 J Connector, 23-pin
CN8901 9GJS3B-PH-SM3 J PH Connector
CN8902 9GJS8B-PH-SM3 J PH Connector
9GJAWV1929
DIGITAL VIDEO ASSY
[INTERFACE BLOCK]
SEMICONDUCTORS
IC1001 9GJTC74VHC541F J TC74VHC541F
IC1002 9GJTC74VHC541F J TC74VHC541F
IC1003 9GJTC74VHC541F J TC74VHC541F
IC1004 9GJTC74VHC541F J TC74VHC541F
IC1005 9GJTC74VHC541F J TC74VHC541F
IC1006 9GJTC74VHC541F J TC74VHC541F
IC1007 9GJTC74VHC541F J TC74VHC541F
IC1008 9GJTC74VHC541F J TC74VHC541F
FILTERS
F1001 9GJATF1194 J EMI Filter
F1002 9GJATF1194 J EMI Filter
F1003 9GJATF1194 J EMI Filter
F1004 9GJATF1194 J EMI Filter
F1005 9GJATF1194 J EMI Filter
F1006 9GJATF1194 J EMI Filter
CAPACITORS
C1001 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1002 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1003 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1004 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1005 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1006 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1007 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1008 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R1044 9GJRAB4C101J J Resistor Array
R1001 9GJRAB4C103J J Resistor Array
R1002 9GJRAB4C103J J Resistor Array
R1003 9GJRAB4C103J J Resistor Array
R1004 9GJRAB4C103J J Resistor Array
R1005 9GJRAB4C103J J Resistor Array
R1006 9GJRAB4C103J J Resistor Array
R1007 9GJRAB4C103J J Resistor Array
R1036 9GJRAB4C103J J Resistor Array
R1063 9GJRAB4C103J J Resistor Array
R1064 9GJRAB4C103J J Resistor Array
R1065 9GJRAB4C103J J Resistor Array
R1066 9GJRAB4C103J J Resistor Array
R1067 9GJRAB4C103J J Resistor Array
R1068 9GJRAB4C103J J Resistor Array
R1069 9GJRAB4C103J J Resistor Array
R1008 9GJRAB4C470J J Resistor Array
R1009 9GJRAB4C470J J Resistor Array
R1010 9GJRAB4C470J J Resistor Array
R1011 9GJRAB4C470J J Resistor Array
R1012 9GJRAB4C470J J Resistor Array
R1013 9GJRAB4C470J J Resistor Array
R1014 9GJRAB4C470J J Resistor Array
R1015 9GJRAB4C470J J Resistor Array
R1016 9GJRAB4C470J J Resistor Array
R1017 9GJRAB4C470J J Resistor Array
R1019 9GJRAB4C470J J Resistor Array
R1020 9GJRAB4C470J J Resistor Array
R1027 9GJRAB4C470J J Resistor Array
R1032 9GJRAB4C470J J Resistor Array
R1034 9GJRAB4C470J J Resistor Array
R1035 9GJRAB4C470J J Resistor Array
R1037 9GJRAB4C470J J Resistor Array
R1038 9GJRAB4C470J J Resistor Array
R1040 9GJRAB4C470J J Resistor Array
R1041 9GJRAB4C470J J Resistor Array
R1042 9GJRAB4C470J J Resistor Array
R1043 9GJRAB4C470J J Resistor Array
R1048 9GJRAB4C470J J Resistor Array
R1049 9GJRAB4C470J J Resistor Array
R1051 9GJRAB4C470J J Resistor Array
R1052 9GJRAB4C470J J Resistor Array
R1053 9GJRAB4C470J J Resistor Array
R1054 9GJRAB4C470J J Resistor Array
R1059 9GJRS1/16S100J J 10 1/16W Chip
R1074 9GJRS1/16S100J J 10 1/16W Chip
R1050 9GJRS1/16S101J J 100 1/16W Chip
R1070 9GJRS1/16S103J J 10k 1/16W Chip
R1071 9GJRS1/16S103J J 10k 1/16W Chip
R1072 9GJRS1/16S103J J 10k 1/16W Chip
R1073 9GJRS1/16S103J J 10k 1/16W Chip
R1023 9GJRS1/16S470J J 47 1/16W Chip
R1024 9GJRS1/16S470J J 47 1/16W Chip
R1025 9GJRS1/16S470J J 47 1/16W Chip
R1026 9GJRS1/16S470J J 47 1/16W Chip
R1028 9GJRS1/16S470J J 47 1/16W Chip
R1029 9GJRS1/16S470J J 47 1/16W Chip
R1030 9GJRS1/16S470J J 47 1/16W Chip
R1031 9GJRS1/16S470J J 47 1/16W Chip
R1039 9GJRS1/16S470J J 47 1/16W Chip
R1045 9GJRS1/16S470J J 47 1/16W Chip
R1046 9GJRS1/16S470J J 47 1/16W Chip
R1047 9GJRS1/16S470J J 47 1/16W Chip
R1060 9GJRS1/16S470J J 47 1/16W Chip
R1061 9GJRS1/16S470J J 47 1/16W Chip
R1062 9GJRS1/16S470J J 47 1/16W Chip
R1075 9GJRS1/16S473J J 47k 1/16W Chip
MISCELLANEOUS PARTS
CN1001 9GJB12B-PH-SM3 J PH Connector
CN1003 9GJAKM1201 J Connector, 50-pin
CN1004 9GJAKM1201 J Connector, 50-pin
K1001 9GJAKX9002 J Test Point

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
214
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1929
DIGITAL VIDEO ASSY (Continued)
[PANEL UCOM BLOCK]
INTEGRATED CIRCUITS
IC1101 9GJHD64F2328VF J HD64F2328VF
IC1103 9GJNC7SZ08P5 J NC7SZ08P5
IC1102 9GJPST9228N J PST9228N
TRANSISOTRS
Q1101 9GJDTC143EK J DTC143EK
Q1103 9GJDTC143EK J DTC143EK
DIODE
D1101 9GJAEL1171 J LED (Red/Green)
PACKAGED CIRCUIT
X1101 9GJASS1160 J Ceramic Resonator
(25MHz)
CAPACITORS
C1123 9GJCCSRCH7R0D50 J 7p 50V Chip
C1124 9GJCCSRCH7R0D50 J 7p 50V Chip
C1101 9GJCEV101M4 J 100 4V Electrolytic
C1102 9GJCKSRYB102K5 J 1000p 50V Chip
C1109 9GJCKSRYB102K5 J 1000p 50V Chip
C1110 9GJCKSRYB102K5 J 1000p 50V Chip
C1112 9GJCKSRYB102K5 J 1000p 50V Chip
C1113 9GJCKSRYB102K5 J 1000p 50V Chip
C1114 9GJCKSRYB102K5 J 1000p 50V Chip
C1115 9GJCKSRYB102K5 J 1000p 50V Chip
C1116 9GJCKSRYB102K5 J 1000p 50V Chip
C1129 9GJCKSRYB102K5 J 1000p 50V Chip
C1130 9GJCKSRYB102K5 J 1000p 50V Chip
C1131 9GJCKSRYB102K5 J 1000p 50V Chip
C1132 9GJCKSRYB102K5 J 1000p 50V Chip
C1117 9GJCKSRYB103K5 J 0.01 50V Chip
C1121 9GJCKSRYB103K5 J 0.01 50V Chip
C1120 9GJCKSRYB472K5 J 4700p 50V Chip
C1103 9GJCKSRYF104Z1 J 0.1 16V Chip
C1104 9GJCKSRYF104Z1 J 0.1 16V Chip
C1105 9GJCKSRYF104Z1 J 0.1 16V Chip
C1106 9GJCKSRYF104Z1 J 0.1 16V Chip
C1107 9GJCKSRYF104Z1 J 0.1 16V Chip
C1108 9GJCKSRYF104Z1 J 0.1 16V Chip
C1111 9GJCKSRYF104Z1 J 0.1 16V Chip
C1118 9GJCKSRYF104Z1 J 0.1 16V Chip
C1119 9GJCKSRYF104Z1 J 0.1 16V Chip
C1122 9GJCKSRYF104Z1 J 0.1 16V Chip
C1125 9GJCKSRYF104Z1 J 0.1 16V Chip
C1126 9GJCKSRYF104Z1 J 0.1 16V Chip
C1127 9GJCKSRYF104Z1 J 0.1 16V Chip
C1128 9GJCKSRYF104Z1 J 0.1 16V Chip
RESISTORS
R1104 9GJRAB4C472J J Resistor Array
R1107 9GJRAB4C472J J Resistor Array
R1110 9GJRAB4C472J J Resistor Array
R1113 9GJRAB4C472J J Resistor Array
R1114 9GJRAB4C472J J Resistor Array
R1116 9GJRAB4C472J J Resistor Array
R1121 9GJRAB4C472J J Resistor Array
R1124 9GJRAB4C472J J Resistor Array
R1127 9GJRAB4C472J J Resistor Array
R1129 9GJRAB4C472J J Resistor Array
R1128 9GJRD1/4PU473J J Resistor Array
R1109 9GJRS1/16S0R0J J 0 1/16W Chip
R1112 9GJRS1/16S0R0J J 0 1/16W Chip
R1130 9GJRS1/16S0R0J J 0 1/16W Chip
R1131 9GJRS1/16S0R0J J 0 1/16W Chip
R1115 9GJRS1/16S101J J 100 1/16W Chip
R1117 9GJRS1/16S101J J 100 1/16W Chip
R1134 9GJRS1/16S101J J 100 1/16W Chip
R1126 9GJRS1/16S102J J 1k 1/16W Chip
R1119 9GJRS1/16S470J J 47 1/16W Chip
R1101 9GJRS1/16S471J J 470 1/16W Chip
R1103 9GJRS1/16S471J J 470 1/16W Chip
R1105 9GJRS1/16S472J J 47k 1/16W Chip
R1106 9GJRS1/16S472J J 47k 1/16W Chip
R1108 9GJRS1/16S472J J 47k 1/16W Chip
R1120 9GJRS1/16S472J J 47k 1/16W Chip
R1122 9GJRS1/16S472J J 47k 1/16W Chip
R1123 9GJRS1/16S472J J 47k 1/16W Chip
R1125 9GJRS1/16S472J J 47k 1/16W Chip
R1132 9GJRS1/16S472J J 47k 1/16W Chip
R1136 9GJRS1/16S472J J 47k 1/16W Chip
R1137 9GJRS1/16S472J J 47k 1/16W Chip
MISCELLANEOUS PARTS
K1101 9GJAKX9002 J Test Point
K1102 9GJAKX9002 J Test Point
K1103 9GJAKX9002 J Test Point
K1104 9GJAKX9002 J Test Point
K1107 9GJAKX9002 J Test Point
K1108 9GJAKX9002 J Test Point
[MODULE UCOM BLOCK]
INTEGRATED CIRCUITS
IC1204 9GJ24LC04B(I)SN J 24LC04B(I)SN
IC1208 9GJPST9246N J PST9246N
IC1202 9GJTC74VHC08FT J TC74VHC08FT
IC1201 9GJTC74VHC21FT J TC74VHC21FT
IC1205 9GJTC74VHC541F J TC74VHC541F
IC1203 9GJTC74VHCT541 J TC74VHCT541
IC1206 9GJTC7W126FU J TC7W126FU
DIODES
D1201 9GJ1SS355 J Diode
D1202 9GJ1SS355 J Diode
PACKAGED CIRCUIT
X1201 9GJASS1159 J Ceramic Resonator (16MHz)
CAPACITORS
C1213 9GJCCSRCH470J50 J 47p 50V Chip
C1243 9GJCCSRCH470J50 J 47p 50V Chip
C1244 9GJCCSRCH470J50 J 47p 50V Chip
C1245 9GJCCSRCH470J50 J 47p 50V Chip
C1235 9GJCCSRCH7R0D50 J 7p 50V Chip
C1236 9GJCCSRCH7R0D50 J 7p 50V Chip
C1225 9GJCEV470M6R3 J 6.3 47V Electrolytic
C1232 9GJCEV470M6R3 J 6.3 47V Electrolytic
C1201 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1202 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1203 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1206 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1207 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1208 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1209 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1210 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1211 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1214 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1215 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1216 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1218 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1219 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1223 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1224 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1226 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1227 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1229 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1237 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1238 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1241 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1242 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1247 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1234 9GJCKSRYB103K5 J 0.01 50V Ceramic (Chip)

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
215
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1929
DIGITAL VIDEO ASSY (Continued)
C1233 9GJCKSRYB472K5 J 4700p 50V Ceramic (Chip)
C1204 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1205 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1212 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1217 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1221 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1222 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1228 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1230 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1231 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1239 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1240 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1246 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1248 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1249 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
C1250 9GJCKSRYF104Z1 J 0.1 16V Ceramic (Chip)
RESISTORS
R1209 9GJRAB4C101J J Resistor Array
R1214 9GJRAB4C101J J Resistor Array
R1245 9GJRAB4C101J J Resistor Array
R1242 9GJRAB4C103J J Resistor Array
R1207 9GJRAB4C123J J Resistor Array
R1213 9GJRAB4C473J J Resistor Array
R1216 9GJRAB4C473J J Resistor Array
R1202 9GJRS1/16S0R0J J 0 1/16W Chip
R1229 9GJRS1/16S0R0J J 0 1/16W Chip
R1234 9GJRS1/16S0R0J J 0 1/16W Chip
R1258 9GJRS1/16S0R0J J 0 1/16W Chip
R1210 9GJRS1/16S101J J 100 1/16W Chip
R1211 9GJRS1/16S101J J 100 1/16W Chip
R1217 9GJRS1/16S101J J 100 1/16W Chip
R1218 9GJRS1/16S101J J 100 1/16W Chip
R1222 9GJRS1/16S101J J 100 1/16W Chip
R1223 9GJRS1/16S101J J 100 1/16W Chip
R1224 9GJRS1/16S101J J 100 1/16W Chip
R1235 9GJRS1/16S101J J 100 1/16W Chip
R1236 9GJRS1/16S101J J 100 1/16W Chip
R1237 9GJRS1/16S101J J 100 1/16W Chip
R1239 9GJRS1/16S101J J 100 1/16W Chip
R1240 9GJRS1/16S101J J 100 1/16W Chip
R1243 9GJRS1/16S101J J 100 1/16W Chip
R1244 9GJRS1/16S101J J 100 1/16W Chip
R1246 9GJRS1/16S101J J 100 1/16W Chip
R1249 9GJRS1/16S101J J 100 1/16W Chip
R1250 9GJRS1/16S101J J 100 1/16W Chip
R1256 9GJRS1/16S101J J 100 1/16W Chip
R1232 9GJRS1/16S102J J 1k 1/16W Chip
R1204 9GJRS1/16S103J J 10k 1/16W Chip
R1205 9GJRS1/16S103J J 10k 1/16W Chip
R1215 9GJRS1/16S103J J 10k 1/16W Chip
R1219 9GJRS1/16S103J J 10k 1/16W Chip
R1220 9GJRS1/16S103J J 10k 1/16W Chip
R1231 9GJRS1/16S103J J 10k 1/16W Chip
R1238 9GJRS1/16S103J J 10k 1/16W Chip
R1247 9GJRS1/16S103J J 10k 1/16W Chip
R1248 9GJRS1/16S103J J 10k 1/16W Chip
R1208 9GJRS1/16S123J J 12k 1/16W Chip
R1212 9GJRS1/16S123J J 12k 1/16W Chip
R1203 9GJRS1/16S222J J 2.2k 1/16W Chip
R1227 9GJRS1/16S222J J 2.2k 1/16W Chip
R1228 9GJRS1/16S222J J 2.2k 1/16W Chip
R1230 9GJRS1/16S472J J 4.7k 1/16W Chip
R1226 9GJRS1/16S473J J 47k 1/16W Chip
R1251 9GJRS1/16S473J J 47k 1/16W Chip
R1252 9GJRS1/16S473J J 47k 1/16W Chip
R1254 9GJRS1/16S473J J 47k 1/16W Chip
R1261 9GJRS1/16S473J J 47k 1/16W Chip
R1221 9GJRS1/16S474J J 470k 1/16W Chip
R1253 9GJRS1/16S474J J 470k 1/16W Chip
R1257 9GJRS1/16S474J J 470k 1/16W Chip
R1259 9GJRS1/16S474J J 470k 1/16W Chip
R1260 9GJRS1/16S474J J 470k 1/16W Chip
R1262 9GJRS1/16S474J J 470k 1/16W Chip
R1255 9GJRS1/16S682J J 6.8k 1/16W Chip
MISCELLANEOUS PARTS
CN1201 9GJCKS3130 J Plug, 8-pin
CN1202 9GJCKS3130 J Plug, 8-pin
CN1203 9GJB3B-PH-SM3 J PH Connector
[DIGITAL BLOCK]
SEMICONDUCTORS
IC1802 9GJFS781BZB J FS781BZB
IC1704 9GJNC7SZ08P5 J NC7SZ08P5
IC1301 9GJPD6358A J PD6358A
IC1401 9GJPD6358A J PD6358A
IC1703 9GJPE5064A J PE5064A
IC1501 9GJTC74VCX541F J TC74VCX541F
IC1502 9GJTC74VCX541F J TC74VCX541F
IC1601 9GJTC74VCX541F J TC74VCX541F
IC1602 9GJTC74VCX541F J TC74VCX541F
IC1702 9GJTC74VHC541F J TC74VHC541F
IC1801 9GJTC74VHC541F J TC74VHC541F
IC1803 9GJTC74VHC74F J TC74VHC74F
IC1701 9GJTC74VHCT541 J TC74VHCT541
DIODES
D1301 9GJ1SS226 J Diode
D1302 9GJ1SS226 J Diode
D1303 9GJ1SS226 J Diode
D1305 9GJ1SS226 J Diode
PACKAGED CIRCUIT
X1801 9GJASS1146 J Crystal Resonator
(50.000MHz)
FILTERS
F1301 9GJATF1194 J EMI Filter
F1302 9GJATF1194 J EMI Filter
F1303 9GJATF1194 J EMI Filter
F1304 9GJATF1194 J EMI Filter
F1501 9GJATF1194 J EMI Filter
F1502 9GJATF1194 J EMI Filter
F1503 9GJATF1194 J EMI Filter
F1504 9GJATF1194 J EMI Filter
F1505 9GJATF1194 J EMI Filter
F1601 9GJATF1194 J EMI Filter
F1602 9GJATF1194 J EMI Filter
F1603 9GJATF1194 J EMI Filter
F1604 9GJATF1194 J EMI Filter
F1605 9GJATF1194 J EMI Filter
CAPACITORS
C1807 9GJCCSRCH271J5 J 270p 50V Ceramic (Chip)
C1802 9GJCEV100M16 J 10 16V Electrolytic
C1306 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1322 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1406 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1422 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1711 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1806 9GJCEV101M4 J 100 4V Ceramic (Chip)
C1504 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1506 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1507 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1508 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1604 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1605 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1606 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1607 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1608 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1712 9GJCKSRYB102K5 J 1000p 50V Ceramic (Chip)
C1303 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1304 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1305 9GJCKSRYF104Z1 J 0.1 16V Ceramic

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
216
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1929
DIGITAL VIDEO ASSY (Continued)
C1307 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1308 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1309 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1310 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1311 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1312 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1313 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1314 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1315 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1316 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1317 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1318 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1319 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1320 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1321 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1323 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1324 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1325 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1326 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1327 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1328 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1329 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1330 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1331 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1332 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1333 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1334 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1335 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1336 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1403 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1404 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1405 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1407 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1408 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1409 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1410 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1411 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1412 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1413 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1414 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1415 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1416 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1417 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1418 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1419 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1420 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1421 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1423 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1424 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1425 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1426 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1427 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1428 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1429 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1430 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1431 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1432 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1433 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1434 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1435 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1436 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1501 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1503 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1601 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1603 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1701 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1702 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1703 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1704 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1705 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1706 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1707 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1708 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1709 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1710 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1713 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1803 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1804 9GJCKSRYF104Z1 J 0.1 16V Ceramic
C1805 9GJCKSRYF104Z1 J 0.1 16V Ceramic
RESISTORS
R1502 9GJRAB4C101J J Resistor Array
R1517 9GJRAB4C101J J Resistor Array
R1606 9GJRAB4C101J J Resistor Array
R1622 9GJRAB4C101J J Resistor Array
R1307 9GJRAB4C220J J Resistor Array
R1310 9GJRAB4C220J J Resistor Array
R1311 9GJRAB4C220J J Resistor Array
R1312 9GJRAB4C220J J Resistor Array
R1313 9GJRAB4C220J J Resistor Array
R1314 9GJRAB4C220J J Resistor Array
R1315 9GJRAB4C220J J Resistor Array
R1317 9GJRAB4C220J J Resistor Array
R1318 9GJRAB4C220J J Resistor Array
R1321 9GJRAB4C220J J Resistor Array
R1322 9GJRAB4C220J J Resistor Array
R1326 9GJRAB4C220J J Resistor Array
R1327 9GJRAB4C220J J Resistor Array
R1328 9GJRAB4C220J J Resistor Array
R1329 9GJRAB4C220J J Resistor Array
R1330 9GJRAB4C220J J Resistor Array
R1331 9GJRAB4C220J J Resistor Array
R1332 9GJRAB4C220J J Resistor Array
R1333 9GJRAB4C220J J Resistor Array
R1334 9GJRAB4C220J J Resistor Array
R1335 9GJRAB4C220J J Resistor Array
R1336 9GJRAB4C220J J Resistor Array
R1337 9GJRAB4C220J J Resistor Array
R1338 9GJRAB4C220J J Resistor Array
R1339 9GJRAB4C220J J Resistor Array
R1340 9GJRAB4C220J J Resistor Array
R1341 9GJRAB4C220J J Resistor Array
R1342 9GJRAB4C220J J Resistor Array
R1343 9GJRAB4C220J J Resistor Array
R1344 9GJRAB4C220J J Resistor Array
R1407 9GJRAB4C220J J Resistor Array
R1410 9GJRAB4C220J J Resistor Array
R1411 9GJRAB4C220J J Resistor Array
R1412 9GJRAB4C220J J Resistor Array
R1413 9GJRAB4C220J J Resistor Array
R1414 9GJRAB4C220J J Resistor Array
R1415 9GJRAB4C220J J Resistor Array
R1417 9GJRAB4C220J J Resistor Array
R1418 9GJRAB4C220J J Resistor Array
R1421 9GJRAB4C220J J Resistor Array
R1422 9GJRAB4C220J J Resistor Array
R1426 9GJRAB4C220J J Resistor Array
R1427 9GJRAB4C220J J Resistor Array
R1428 9GJRAB4C220J J Resistor Array
R1429 9GJRAB4C220J J Resistor Array
R1430 9GJRAB4C220J J Resistor Array
R1431 9GJRAB4C220J J Resistor Array
R1432 9GJRAB4C220J J Resistor Array
R1433 9GJRAB4C220J J Resistor Array
R1434 9GJRAB4C220J J Resistor Array
R1435 9GJRAB4C220J J Resistor Array
R1436 9GJRAB4C220J J Resistor Array
R1437 9GJRAB4C220J J Resistor Array
R1438 9GJRAB4C220J J Resistor Array
R1439 9GJRAB4C220J J Resistor Array
R1440 9GJRAB4C220J J Resistor Array
R1441 9GJRAB4C220J J Resistor Array
R1442 9GJRAB4C220J J Resistor Array
R1443 9GJRAB4C220J J Resistor Array
R1444 9GJRAB4C220J J Resistor Array
R1501 9GJRAB4C470J J Resistor Array

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
217
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
9GJAWV1929
DIGITAL VIDEO ASSY (Continued)
R1514 9GJRAB4C470J J Resistor Array
R1607 9GJRAB4C470J J Resistor Array
R1627 9GJRAB4C470J J Resistor Array
R1701 9GJRAB4C470J J Resistor Array
R1703 9GJRAB4C470J J Resistor Array
R1704 9GJRAB4C470J J Resistor Array
R1705 9GJRAB4C470J J Resistor Array
R1706 9GJRAB4C470J J Resistor Array
R1707 9GJRAB4C470J J Resistor Array
R1708 9GJRAB4C470J J Resistor Array
R1709 9GJRAB4C470J J Resistor Array
R1712 9GJRAB4C470J J Resistor Array
R1713 9GJRAB4C470J J Resistor Array
R1714 9GJRAB4C470J J Resistor Array
R1715 9GJRAB4C470J J Resistor Array
R1716 9GJRAB4C470J J Resistor Array
R1717 9GJRAB4C470J J Resistor Array
R1551 9GJRS1/2S680J J 68 1/2W Chip
R1552 9GJRS1/2S680J J 68 1/2W Chip
R1308 9GJRS1/16S0R0J J 0 1/16W Chip
R1409 9GJRS1/16S0R0J J 0 1/16W Chip
R1649 9GJRS1/16S0R0J J 0 1/16W Chip
R1723 9GJRS1/16S0R0J J 0 1/16W Chip
R1819 9GJRS1/16S0R0J J 0 1/16W Chip
R1347 9GJRS1/16S101J J 100 1/16W Chip
R1348 9GJRS1/16S101J J 100 1/16W Chip
R1349 9GJRS1/16S101J J 100 1/16W Chip
R1350 9GJRS1/16S101J J 100 1/16W Chip
R1351 9GJRS1/16S101J J 100 1/16W Chip
R1543 9GJRS1/16S101J J 100 1/16W Chip
R1544 9GJRS1/16S101J J 100 1/16W Chip
R1545 9GJRS1/16S101J J 100 1/16W Chip
R1546 9GJRS1/16S101J J 100 1/16W Chip
R1547 9GJRS1/16S101J J 100 1/16W Chip
R1643 9GJRS1/16S101J J 100 1/16W Chip
R1644 9GJRS1/16S101J J 100 1/16W Chip
R1645 9GJRS1/16S101J J 100 1/16W Chip
R1646 9GJRS1/16S101J J 100 1/16W Chip
R1647 9GJRS1/16S101J J 100 1/16W Chip
R1722 9GJRS1/16S101J J 100 1/16W Chip
R1807 9GJRS1/16S101J J 100 1/16W Chip
R1808 9GJRS1/16S101J J 100 1/16W Chip
R1809 9GJRS1/16S101J J 100 1/16W Chip
R1810 9GJRS1/16S101J J 100 1/16W Chip
R1816 9GJRS1/16S101J J 100 1/16W Chip
R1818 9GJRS1/16S101J J 100 1/16W Chip
R1802 9GJRS1/16S102J J 1k 1/16W Chip
R1301 9GJRS1/16S103J J 10k 1/16W Chip
R1306 9GJRS1/16S103J J 10k 1/16W Chip
R1401 9GJRS1/16S103J J 10k 1/16W Chip
R1402 9GJRS1/16S103J J 10k 1/16W Chip
R1710 9GJRS1/16S103J J 10k 1/16W Chip
R1711 9GJRS1/16S103J J 10k 1/16W Chip
R1801 9GJRS1/16S103J J 10k 1/16W Chip
R1806 9GJRS1/16S103J J 10k 1/16W Chip
R1803 9GJRS1/16S222J J 2.2k 1/16W Chip
R1804 9GJRS1/16S222J J 2.2k 1/16W Chip
R1812 9GJRS1/16S222J J 2.2k 1/16W Chip
R1813 9GJRS1/16S222J J 2.2k 1/16W Chip
R1721 9GJRS1/16S223J J 22k 1/16W Chip
R1811 9GJRS1/16S332J J 3.3k 1/16W Chip
R1303 9GJRS1/16S470J J 47 1/16W Chip
R1304 9GJRS1/16S470J J 47 1/16W Chip
R1319 9GJRS1/16S470J J 47 1/16W Chip
R1325 9GJRS1/16S470J J 47 1/16W Chip
R1403 9GJRS1/16S470J J 47 1/16W Chip
R1404 9GJRS1/16S470J J 47 1/16W Chip
R1419 9GJRS1/16S470J J 47 1/16W Chip
R1425 9GJRS1/16S470J J 47 1/16W Chip
R1702 9GJRS1/16S470J J 47 1/16W Chip
R1719 9GJRS1/16S470J J 47 1/16W Chip
R1815 9GJRS1/16S470J J 47 1/16W Chip
R1817 9GJRS1/16S470J J 47 1/16W Chip
R1718 9GJRS1/16S472J J 4.7k 1/16W Chip
R1539 9GJRS1/16S474J J 470k 1/16W Chip
R1540 9GJRS1/16S474J J 470k 1/16W Chip
R1541 9GJRS1/16S474J J 470k 1/16W Chip
R1542 9GJRS1/16S474J J 470k 1/16W Chip
R1639 9GJRS1/16S474J J 470k 1/16W Chip
R1640 9GJRS1/16S474J J 470k 1/16W Chip
R1641 9GJRS1/16S474J J 470k 1/16W Chip
R1642 9GJRS1/16S474J J 470k 1/16W Chip
R1805 9GJRS1/16S820J J 82 1/16W Chip
R1820 9GJRS1/16S820J J 82 1/16W Chip
R1821 9GJRS1/16S820J J 82 1/16W Chip
R1548 9GJRS1/16S824J J 820k 1/16W Chip
R1648 9GJRS1/16S824J J 820k 1/16W Chip
MISCELLANEOUS PARTS
CN1701 9GJAKM1201 J Connector, 50-pin
CN1501 9GJAKM1202 J Connector, 55-pin
CN1502 9GJAKM1202 J Connector, 55-pin
CN1504 9GJAKM1202 J Connector, 55-pin
CN1505 9GJAKM1202 J Connector, 55-pin
CN1601 9GJAKM1202 J Connector, 55-pin
CN1602 9GJAKM1202 J Connector, 55-pin
CN1604 9GJAKM1202 J Connector, 55-pin
CN1605 9GJAKM1202 J Connector, 55-pin
CN1503 9GJB8B-PH-SM3 J PH Connector
CN1603 9GJB8B-PH-SM3 J PH Connector
CN1301 9GJCKS3130 J Plug, 8-pin
CN1702 9GJKF050HA30L J Connector, 30-pin
K1301 9GJAKX9002 J Test Point
K1302 9GJAKX9002 J Test Point
K1308 9GJAKX9002 J Test Point
K1311 9GJAKX9002 J Test Point
K1312 9GJAKX9002 J Test Point
K1313 9GJAKX9002 J Test Point
K1314 9GJAKX9002 J Test Point
K1316 9GJAKX9002 J Test Point
K1321 9GJAKX9002 J Test Point
K1324 9GJAKX9002 J Test Point
K1326 9GJAKX9002 J Test Point
K1327 9GJAKX9002 J Test Point
K1328 9GJAKX9002 J Test Point
K1329 9GJAKX9002 J Test Point
K1330 9GJAKX9002 J Test Point
K1331 9GJAKX9002 J Test Point
K1333 9GJAKX9002 J Test Point
K1501 9GJAKX9002 J Test Point
K1502 9GJAKX9002 J Test Point
K1601 9GJAKX9002 J Test Point
K1602 9GJAKX9002 J Test Point
K1728 9GJAKX9002 J Test Point
K1729 9GJAKX9002 J Test Point
[D-D CONVERTER BLOCK]
TRANSISOTRS
Q1902 9GJ2SC2712 J 2SC2712
Q1905 9GJ2SC2712 J 2SC2712
Q1907 9GJ2SC2712 J 2SC2712
Q1903 9GJDTC143EK J DTC143EK
Q1901 9GJHN1C01FU J HN1C01FU
Q1904 9GJHN1C01FU J HN1C01FU
Q1906 9GJHN1C01FU J HN1C01FU
DIODES
D1903 9GJ1SS355 J Diode
D1904 9GJ1SS355 J Diode
D1905 9GJ1SS355 J Diode
D1906 9GJ1SS355 J Diode
D1911 9GJ1SS355 J Diode
D1912 9GJ1SS355 J Diode
D1908 9GJHZU2.2B J Zener Diode
D1902 9GJUDZ3.6B J Zener Diode
D1909 9GJUDZ3.6B J Zener Diode
