Sharp GP2AP01VT10F User manual

GP2AP01VT10F
1 / 18
1.Thesespecificationsheetsincludematerialsprotected undercopyrightof Sharp Corporation("Sharp").
Pleasehandlewith greatcares and do notreproduce orcauseanyoneto reproducethem withoutSharp'sconsent.
2.When usingthisSharp product, please observethe absolutemaximumratings,other conditions and instructions foruse
describedin the specification sheets,aswellastheprecautionsmentionedbelow.
Sharp assumesno responsibility for anydamages resulting fromuseoftheproductwhich doesnotcomplywithabsolute
maximumratings,otherconditionsand instructions foruse included inthespecificationsheets, and the precautions
mentionedbelow.
(Precautions)
(1) Inmaking catalogueorinstruction manual basedon thespecification sheets,please verifythevalidityofthecatalogue
orinstructionmanualsafterassemblingSharpproductsincustomer's products attheresponsibilityofcustomer.
(2)This Sharp productis designedfor use in the followingapplicationareas;
• Computers • OA equipment • Telecommunication equipment (Terminal) • Measuring equipment
• Tooling machines ・Audio visual equipment • Home appliances
IftheuseoftheSharpproductintheaboveapplicationareasis forequipmentlisted in paragraphs (3)or(4),
pleasebesureto observe the precautionsgiveninthoserespectiveparagraphs.
(3)Appropriatemeasures, such as fail-safe design andredundantdesign consideringthesafety design oftheoverall
systemand equipment,shouldbe takento ensure reliabilityandsafetywhenSharpproduct is used for equipment
inresponsibilityofcustomer which demandshighreliabilityandsafety in function andprecision,such as;
• Transportation control and safety equipment (aircraft, train, automobile etc.)
• Traffic signals • Gas leakage sensor breakers • Rescue andsecurityequipment
• Other safety equipment
(4)Sharp productisdesignedforconsumergoodsandcontrolledasconsumergoodsinproductionandquality.
Pleasedonotusethisproductfor equipmentwhichrequireextremely highreliabilityandsafetyin functionand
precision,such as ;
• Space equipment • Telecommunication equipment (for trunk lines)
• Nuclear power control equipment • Medical equipment
(5)Please contactand consultwithaSharpsalesrepresentative ifthereareanyquestionregarding interpretationof
theabovefour paragraphs.
3. Disclaimer
Thewarrantyperiod forSharpproductisone(1)yearafter shipment.
Duringtheperiod, if there are anyproducts problem,Sharpwillrepair (if applicable),replaceor refund.
Excepttheabove, bothparties willdiscusstocope withtheproblems.
ThefailedSharpproductafterthe aboveone (1)yearperiodwillbecopedwithbySharp, provided thatbothparties
shall discuss anddetermine on sharingresponsibilitybased ontheanalysisresults thereofsubjecttotheabove scope
ofwarranty.
ThewarrantydescribedhereinisonlyforSharp product itselfwhicharepurchasedbyordeliveredtocustomer.
Damages arisingfromSharp productmalfunctionorfailure shallbe excepted.
Sharp will notberesponsible fortheSharpproductduetothemalfunctionorfailures thereofwhich arecaused by:
(1)storagekeeptrouble duringtheinventoryin themarketingchannel.
(2)intentionalact, negligence orwrong/poor handling.
(3)equipment whichSharpproductsareconnectedto or mountedin.
(4)disassembling,reformingorchanging Sharp products.
(5)installationproblem.
(6)actofGodorother disaster(naturaldisaster,fire, flood, etc.)
(7)externalfactors(abnormalvoltage, abnormalelectromagnetic wave,fire,etc.)
(8)specialenvironment(factory,coastalareas,hotspring area,etc.)
(9) phenomenon whichcannot be foreseen basedon the practicaltechnologies at the time of shipment.
(10)thefactorsnotincluded in theproductspecificationsheet.
4. Pleasecontactandconsult withaSharpsales representative for anyquestions aboutSharpproduct.

GP2AP01VT10F
2 / 18
1. Application
This technicalsheetsapplies totheoutline andcharacteristics of time of flightsensor
ModelNo.GP2AP01VT10F
2. Outline Refer to thedrawingpage7.
3. Ratingsand characteristics Refertotheattached sheet,Page8to9.
4. Reliability Refertotheattachedsheet,Page10.
5. Outgoinginspection Refer totheattachedsheet,Page11.
6. Supplement
1)This product isbuilt-inSPAD(singlephotonavalanchediode).
2)Brominatedflame retardants
Specificbrominated flame retardantssuch as thePBBandPBDE arenotused in thisdeviceat all.
3)This productshallnotcontain thefollowing materials.
Also, thefollowing materials shallnotbeused in theproduction process forthisproduct.
MaterialsforODS :CFCs,Halon,Carbontetrachloride,1,1,1-Trichloroethane(Methylchloroform)
4) Compliancewitheachregulation
4.1)TheRoHS directive (2011/65/EU)
This productcomplies withtheRoHS directive (2011/65/EU).
Objectsubstances:mercury,lead,cadmium,hexavalentchromium,polybrominatedbiphenyls（PBB）
andpolybrominateddiphenyl ethers（PBDE）
4.2)Contentofsixsubstancesspecifiedin ManagementMethodsforControlofPollutionCausedbyElectronic
InformationProductsRegulation (Chinese : 电子信息产品污染控制管理办法).
MarkingStyles forthe Namesand ContentsoftheHazardous Substances
Category
Hazardous Substances
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
chromium
(Cr6+)
Polybrominated
biphenyls
(PBB)
Polybrominated
diphenyl ethers
(PBDE)
Timeofflight
sensor
○
○
○
○
○
○
Thistableispreparedinaccordance withtheprovisionsofSJ/T11364.
○：Indicatesthatsaid hazardoussubstancecontainedin allofthehomogeneousmaterialsforthis partis
belowthelimitrequirementofGB/T26572
5) Countryoforigin: China
6)Product mass: Approx.0.017g
7)The moistureabsorptionlevelofthisproduct isMSL.3.
8)Tapingspecifications:Refer to theattachedsheet, Page13 to 15.
9)Tapingmoisture-proof packing:Refertotheattached sheet, Page16 to18.
10)EyeSafetyConsiderations
GP2AP01VT10Fcontains a laser emitter and corresponding drive circuitry. The laseroutput is Class 1 laser safety under
allreasonablyforeseeableincludingsinglefaultsincompliancewithIEC60825-1:2014.Thelaseroutputwillremainwithin
Class 1 limits as long as the Sharp recommended device settings are used and the operating conditions specified in this
datasheetare respected.Thelaseroutputpower mustnotbeincreasedbyanymeansand no optics shouldbe usedwith the
intention offocusingthelaserbeam.

GP2AP01VT10F
3 / 18
7. Notes
1) Notes concerning receiver surface
Please note enough that it is likely to malfunction when a surface is dirty with garbage and dust, etc.
Moreover, please do not touch a surface.
2)Please takeproper methodsto preventESD.TheIC builtinGP2AP01VT10Fis ESD-sensitive becauseit isfabricatedby
sub-micronCMOSprocess. Forexample,inhandlingGP2AP01VT10F,humanbodyandsolderingironetc. should be
grounded.
3)Beforethecircuitdesign
In circuitdesigning,makeallowanceforthedegradationofthelaseroutput thatresultsfromlong continuous
operation.
4)Notesambient light
Whensetto avoid malfunctionsdue toastrongdisturbancelight, suchanarrangementto receiveambientlightdirectlyonthe
detector, pleasebeavoided.Also byplacing this productinclose to othercomponents,it maybeamalfunctionwith thelight
reflectedfromtheirproduct,structural arrangementtoreduce theamountoflightreceivingsurfaceoftheouter,please
consider.
5) After being mounted and soldered, if GP2AP01VT10Fis deformed by externalforce or impact, e.g. something falls onto the
device, it mayresult in defective implementationsuchas lift-offoftheterminals.Careful handlingshouldbetaken.
6) For soldering : Refer to Page 12.
7) Recommended external circuit
Components
Recommendedvalues
CX1
4.7μF
CX2
100nF
RGPIO
47kΩ
RSDA
10kΩ
RSCL
10kΩ
RXSHUT
47kΩ
(TopView)
Emitter
Detector
VVCSEL
VI2C
①AVDDVCSEL
②AVSSVCSEL
⑪
AVDD
⑩
SCL
⑨SDA
⑦
GPIO1
⑧(DNC)
⑤
XSHUT
⑥
(GND3)
⑫
(GND4)
④(GND2)
③GND
SCL
SDA
GPIO1
XSHUT
CX1
CX2
RXSHUT
RSCL
RGPIO RSDA
VDD

GP2AP01VT10F
4 / 18
Therearecasestogenerate anoisebecauseVCSEL drivingcurrent flows AVDDVCSELterminal,andto distortawaveform
of VCSELdrivingcurrent.
To reducetheseinfluences,pleasearrangeCX1 within5mmfromAVDDVCSELterminal,andwirebetween
AVDDVCSELterminal, CX1andGND terminalascloseaspossible.Also,the wiringofAVDDVCSELisseparated from
VDD and VI2C terminals,andthe power sourceofVVCSEL isseparated fromVDD isrecommended.
Andinordertoreducetheinfluenceofthepowersupplynoise, pleasearrangeCX2within5mmfromAVDD terminal.
Please evaluate with the actual electrical implementation, and carefully make sure that there isnoproblem.
SDA terminal is NMOS open-drain output and digital input. XSHUT and SCL terminals are digital input. GPIO1
terminal is NMOS open-drain output.
8) Blockdiagram
GP2AP01VT00Fmodule
GP2AP01VT10Fsilicon
IR-
IR+
AVDDVCSEL
①
IREmitter
AVSSVCSEL
②
I2C
⑩
SCL
⑨
SDA
(GND4) ⑫
GND
⑪
AVDD
⑧
DNC
⑦
GPIO1
GND
⑥(GND3)
GND
③
(GND2)
④
GND
XSHUT
⑤
IRemitter
driver
Ranging

GP2AP01VT10F
5 / 18
9)Footpattern of PCB
(1)Dimensionsare shownfor reference.
1. Dimensionin parenthesisareshownforreference.
2. Unit:mm
(2) Recommendable sizeofsoldercreamedpaste(Reference)
:Solderingpastearea
*Dimensions inparenthesisareshown forreference.
Unit:mm
Pin
Name
Function
①
AVDDVCSEL
SupplyVoltageforVCSEL
②
AVSSVCSEL
Ground for VCSEL
③
GND
Ground
④
GND2
Ground
⑤
XSHUT
DigitalI
⑥
GND3
Ground
⑦
GPIO1
DigitalI/O
⑧
DNC
No connect
⑨
SDA
I2CDataBus
⑩
SCL
I2CClock
⑪
AVDD
SupplyVoltage
⑫
GND4
Ground
(Top View)
(BottomView)
MountCenter
①
⑤
⑪
⑦
①
⑤
⑪
⑦
①
⑤
⑪
⑦
●
●

GP2AP01VT10F
6 / 18
10) PinDescription
Pin Name
Functional description Equivalent Internal Circuit
Power Supply
VCSEL Power Supply
Ground
VCSEL Ground
I2C serial data line
The terminal is pulled-up to VI2C
I2C serial clock line
The terminal is pulled-up to VI2C
Interrupt pin
The terminal is pulled-up to VI2C
Open drain output terminal
Active/Shutdown control pin
*ESD protection device
External circuit
XSHUT
SCL
GPIO1
SDA
AVSSVCSEL
GND
AVDDVCSEL
AVDD
Internal
Regulater
GND
SDA
VI2C
*
GND
AVDD
*
Internal
Regulater
GND
SCL
VI2C
*
Internal
Regulater
GND
GPIO1
VI2C
*
Internal
Reaulater
GND
XSHUT
*
GND
AVDDVCSEL
*
GND
AVSSVCSEL
*
*

GP2AP01VT10F
7 / 18
2. OutlineDimensions

GP2AP01VT10F
8 / 18
3. RatingsandCharacteristics
3.1 AbsoluteMaximumRatings
Parameter
Symbol
Rating
Unit
Remarks
Powersupplyvoltage
VDD
-0.5 to 3.6
V
VCSELvoltage
VVCSEL
-0.5 to 3.6
V
I2Cvoltage
VI2C
-0.5 to 3.6
V
Operating temperature
Topr
-20 to 70
℃
Storagetemperature
Tstg
-40 to 85
℃
Solderingtemperature
Tsol
250
℃
peak temperatureduration:10s
3.2 RecommendedOperatingConditions
Parameter
Symbol
Operating condition
Unit
Remarks
Powersupplyvoltage
VDD
2.6 to 3.5
V
VCSELvoltage
VVCSEL
2.6 to 3.5
V
I2Cvoltage
VI2C
1.7 to 3.5
V
Optimumoperating temperature
Topr
-20 to 70
℃
Functionaloperatingtemperature
Tfunc
-20 to 70
℃
SCL,SDAinputlowlevel
VIL
-0.5 to 0.6
V
SCL,SDAinputhighlevel
VIH
1.12 to VDD+0.5
V
3.3 ElectricalandOpticalCharacteristics
3.3.1ElectricalCharacteristics Ta=25℃, VDD=VVCSEL=VI2C=2.8V
(Unless otherwise specified, the external circuit constants follow the recommended external circuit of page 3.)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Remarks
Currentconsumption(AVDD)
ICC_VDD
6
10
14
mA
Currentconsumption(VDDVCSEL)
ICC_VCSEL
13
20
27
mA
Currentconsumption (PowerDown)
ICC-S
－
－
5
μA
I2Cclock frequency
f
1
－
400
kHz
SDAoutputlowlevelvoltage
VOL_SDA
0
－
0.4
V
IOL_SDA=3mA
GPIO1outputlowlevelvoltage
VOL_GPIO1
0
－
0.4
V
IOL_GPIO1=3mA
XSHUToutputlowlevelvoltage
VoLXSHUT
0
－
0.4
V
IOL_XSHUT=3mA
3.3.2 VCSELCharacteristics
Ta=25℃, VDD=VVCSEL=VI2C=2.8V
(Unless otherwise specified, the external circuit constants follow the recommended external circuit of page 3.)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Remarks
VCSELpeak wavelength
λP_PS
－
940
－
nm
VCSELpeak current
Ivcsel
59
mA

GP2AP01VT10F
9 / 18
3.3.3 Ranging Characteristics Ta=25℃, VDD=VVCSEL=VI2C=2.8V,and after the calibration
(Unless otherwise specified, the external circuit constants follow the recommended external circuit of page 3.)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Remarks
Min Range distance & accuracy
(Whiteindoor)
Rmin
－
10
－
cm
※Condition ①
Rminacc
－
－
±5
％
MaxRangedistance& accuracy
(Whiteindoor)
Rinw
120
180
－
cm
※Condition ②
Rinaccw
－
－
±4
％
Max Rangedistance &accuracy
(Grayindoor)
Ring
70
80
－
cm
※Condition ③
Rinaccg
－
－
±7
％
Max Rangedistance &accuracy
(Whiteoutdoor)
Routw
60
－
－
cm
※Condition ④
Routaccw
－
－
±7
％
Max Rangedistance &accuracy
(Grayoutdoor)
Routg
40
－
－
cm
※Condition ⑤
Routaccg
－
－
±12
％
Rangingspeed
Trange
－
－
33
msec
3.3.4Rangingoffseterror
(Unless otherwise specified, the external circuit constants follow the recommended external circuit of page 3.)
Parameter
Symbol
Min.
Typ.
Max.
Unit
Remarks
RangeOffset
Roffset
－
－
3
％
※Condition ②～⑤
Rangeoffset =3σ/Average,
Ta=25℃,
VDD=VVCSEL=VI2C=2.8V
Voltage drift
Vdrift
－
10
15
mm
Ta=25℃,
VDD=VVCSEL=VI2C=2.6～3.5V
Temperaturedrift
Tdrift
－
10
30
mm
Ta=-20℃～+70℃,
VDD=VVCSEL=VI2C=2.8V
※Rangingcondition
Condition
Target&Reflectance
Environment
RangeAccuracy&Offsetcondition
①
White 88％
Indoor:no infrared
10cm
②
White 88％
Indoor:no infrared
120cm
③
Gray17％
Indoor:noinfrared
70cm
④
White 88％
Outdoor:equivalentto5kLuxdaylight
60cm
⑤
Gray17％
Outdoor:equivalentto5kLuxdaylight
40cm

GP2AP01VT10F
10 / 18
4. Reliability
Thereliabilityofproducts shallsatisfyitems listedbelow.
Confidence level : 90%
LTPD:10or20
Test Items
TestCondition
Failure Judgment
Criteria
Samples (n)
Defective (C)
* Temperature
cycling
1 cycle -40℃(30min) to +85℃(30min)
20 cyclestest
ICC_VDD > UＰ × 1.2
Up: Upper
specification
limit
Range accuracy <-10%
Range accuracy >+10%
Condition:
VDD=VVCSEL=VI2C
=2.8V,
White Card88％,
Indoorat 120cm
n=22, c=0
*High temp. and high
humiditystorage
+60℃,90%RH,240h
n=22, c=0
*High temp.storage
+85℃, 240h
n=22, c=0
*Low temp.storage
-40℃, 240h
n=22, c=0
Operation life
+25℃, VDD=VDDVCSEL=VI2C=3.5V, 240h
n=11, c=0
Mechanicalshock
1000m/s2, 6ms
3times/±X, ±Y,±Zdirection
n=22, c=0
Variable frequency
vibration
200m/s2
100 to 2000 to 100Hz/ Approx. for 4min
48 min/X,Y,Zdirection
n=22, c=0
Reflowsolderheat
250℃, 10s, three times.
Temperature profile as shown in page 12.
n=22, c=0
In the test *mark above, the sample to be tested shall be left at normal temperature
and humidity for 2h after it is taken out of the chamber. (No dew point)
Thesetestresults are samplingexamples fromaspecificlotforreferencepurposeonly, anddonotconstituteanywarranty
orassurance inconnectionwiththeproducts.

GP2AP01VT10F
11 / 18
5. Outgoinginspection
(1) Inspection lot
Inspection shallbecarried outpereachdeliverylot.
(2) Inspection method
Asinglesamplingplan,normalinspectionlevel ⅡbasedonISO 2859shallbe adopted.
Parameter
Inspection itemsand test method
AQL(%)
Major
defect
1. Disconnection, short
0.1
2. Electrical characteristicsdefectinparameter 3.3
Minor
defect
Appearance defect
0.25
Parameter
Judgmentcriteria
Cracks, Chipping,
Scratches，
Stains, Burrs
One which affects the characteristics of
Parameter3.3shallbedefect.

GP2AP01VT10F
12 / 18
25℃
ＭＡＸ
MAX120s
1～5℃/s
220℃
MAX50s
250℃
MAX10s
190℃
1～5℃/s
150℃
85℃
1～5℃/s
Precautions forSoldering
(1)Incaseofsolderreflow
Reflowisallowedonlythree atthetemperature andthe time
withinthetemperatureprofileasshowninthe figurebelow.
This Profile temperature isthesensorsurfacepackagetemperature.
Reflowinterval shall bewithin7daysunder conditions,10to30℃,70%RHor less.
(2)Otherprecautions
An infraredlamp usedto heatup forsolderingmaycausealocalizedtemperaturerise in theresinofpackageinside.
Even ifwithinthetemperatureprofileabove,thereis thepossibilitythat thegoldwire inpackageisbroken.
Pleaseuseafterconfirmationtheconditionsfullyactualsolderreflowmachine.

GP2AP01VT10F
13 / 18
Taping specifications
1. Application
Thispackingspecificationsheets specifythetapingspecificationsforGP2AP01VT10F.
2.Taping method
2.1.TapestructureandDimensions(Refertopage14.)
Thetapeshallhaveastructureinwhicha covertape issealedpressed
on thecarriertapeofconductive Polycarbonate.
2.2.ReelstructureandDimensions (Refertopage15.)
Thetapingreel shall beconductiveplastic withitsdimensions as shownin
theattacheddrawing.
2.3.Directionofproductinsertion (Refertopage15.)
Thesensor directionin carriertapeshallbe; thedetectorofthesensorlocatestothefeeding
hole sideofthecarriertapeand the sensorwindowfaces to thetopofthe pocket ofthecarrier tape.
2.4.Thewaytorepair tapedfailure devices
Thewaytorepair taped failuredevicescutabottomofcarriertape with acutter,
andafter replacingtogood devices,thecuttingportion shallbesealed
with adhesive tape.
3.Adhesivenessof covertape
Theexfoliationforcebetween carriertapecovertapeshallbe 0.2N to1.2N
fortheanglefrom160degreesto 180degrees．
4. Rolling method and quantity
Wind the tapeback on the reelso that the covertapewill beoutsidethetape.
Attach16cmormoreof blanktape to thetrailerand 40cmormoreofblanktape totheleader
and fixthebothendswith adhesivetape.
Onereelshallcontain 1000pcs.Except for thecase thatdeviceisremoved.
TheremustnotbecontinuouslytwoormoreStock-Outs.
5. Safety protectionduringshipping
There shallbenodeformationofcomponent ordegradationofelectrical characteristics
due to shipping.
6. Surfaceresistivity
Name
Surfaceresistivity(Ω／□)
Material
Carriertape
1×104to 1×108
Electroconductivepolycarbonate
Covertape
1×104to 1×107
Polyethyleneterephthalate
Reel
Lessthan1×109
Polyphenyleneether

GP2AP01VT10F
14 / 18
7. Tapeand Realstructures
7.1 Tape structureandDimensions
Tapeoutlinedrawing

GP2AP01VT10F
15 / 18
7.2 Reelstructure and Dimensions
7.3.Directionofproduct insertion
Checkword
a
b
c
d
e
f
g
mm
φ180±2.0
13.5±1.0
φ60±1.0
φ13±0.2
φ21±0.8
17.1±1.0
2±0.5
Symbol
Unit
a
b
c
f
d
g
e
Barcode label
(Based onEIAJC-3)
Indicator
Pull outdirection
IR EMITTER
Static electricity label
MSL3、ROHS label
Detector

GP2AP01VT10F
16 / 18
Taping moisture-proofpacking
1. Application
Thispackingspecificationsheets applyto the moist-proofpacking fortheGP2AP01VT10Finthetaping package.
2. Packaging specifications
2.1 Packaging material
2.2 Packaging method
(1) Fillnecessaryinformation tobarcodelabels.
(2) Pasteoneofthebarcodelabelsand a moistureindicator toatapereel (contains1,000devicesper reel).
(3) Sealthealuminum laminated bagthatcontainsthe tapereeland siccative,and pasteone ofthe barcodelabels.
(4) Pack5aluminumlaminatedbags(contains1reeleach)into thedesignatedpackingcase,whereUrethane
cushioningmaterialareplacedon thetopof thepacking case.
Minimumorder/shipmentquantityshouldbe1 laminatedbag.
(5) Thepacking casewouldbethen sealedwiththecrafttape,with barcode label(basedon EIAJC-3).
(Totalof5,000pcs.percarton) *Exceptfor the casethatdeviceisremoved.
3. StorageandTreatmentafterUnsealed
3.1 Storage conditions The delivered product should be stored withthe conditionsshownbelow;
Storage temperature:10 to30℃
Humidity:below70%RH
Thewarrantytermforthe shippedproductshall befor1 yearaftershippingto thedesignated place by theordered customer.
3.2 Treatment afteropen
(1) Afterunsealed, devices shouldbe mountedunderthetemperatureconditionof10 to30℃,atthehumiditycondition
ofbelow70%RH,within7days.
(2) Incase thatlongtermstorageisneeded,devicesshould eitherbestoredindrybox,orre-sealedtomoist-proofbag
with siccativeandleave themintheenvironmentwherethetemperatureis10to 30℃, at thehumiditycondition
ofbelow70%RH.Devicesmust be mounted within2weeks.
3.3 Bakingbefore mounting
In theeventthatthedevicesarenotmaintainedinthestorageconditionsdescribedabove,ortheenclosedsiccativeindicator
alreadyturneditscolortopink,baking must beappliedbefore devicesareto be mounted.
Thecase thatDeviceswasnot mountedunderthetemperatureconditionof10to30℃atthehumidity
conditionofbelow70%RHorlower within7days,Bakingprocess mustbeappliedbeforedevicesare tobemounted.:
Pleasealso note that bakingshould only be appliedtwice.
Recommendedcondition : ①100to110℃,12to24hours ②125℃, 6to24hours
※Baking will not properly done in packing condition.
To complete the baking properly, devices should be placed to the metal tray.
Recommendedconditionofreelbaking:125℃,6to 24hours
※Inthecase ofreelbaking,hung thereelintheovenbypassing theshaftin thecenterhole of reel.
Pleaseavoidlayingthereel.
Name
Material
Countermeasure for
ESD
Quantity
Aluminumlaminatebag
Aluminumpolyethylene
Conductive type
Referto 2.2
Label
Paper(-made)
Non
Siccative
-
Non
Packingcase
Paper
Non
Cushioning material
Urethane
Non
Indicator
Paper
Non
Packageshape
Product
Quantity
Moisture-proofsackQuantity
Tapereel(φ180mm)
1model
1000pcs./reel *
1reel/ laminatedbag

GP2AP01VT10F
17 / 18
3.4 Placementof reelsin anoven
1)Please hang reelsbyusinga centerholeforfixing the reel.
Pleasekeep somespacebetweenreelsfor betterair rotation in the oven.
Pleasedo notlayareel downin theoven toavoid anydamagesforthe tape edge
and theflangeofreel.
2)Please makesure the carriertapedoesnothaveanyslackin areelbeforebaking
to avoid peelingthecovertape off.
Sincethetapeusingfor fixingcarriertape isnotheatproof,there isacase to remainglue.
So ifnecessary, please change the tape to aheatproofone.

GP2AP01VT10F
18 / 18
2,000pcs products
Inner Packing
4.Packing
Cover tape
Carrier tape
EIAJ C-3 Label
Taping reel containing products
Silica gel
Aluminium laminated bag
Humidity indicator
Aluminium laminated bag
containing a taping reel
Aluminium laminated bag with tape-reel (5 bags)
Cushioning material
Packing case
Kraft tape
Outer Packaging
Outer packing material: Packing case(Corrugated cardboard), Cushioning material (Urethane)
Humidity indicator card (paper), Label(paper), Silica gel, Craft tape
Quantity: 10,000pcs./box
The contents of the carton indication conforms to EIAJ C-3 and the following items are indicated.
Regular packaged mass: Approximately 700g
Aluminium laminated bag (Alumi-Polyethylene)
②
③
④
⑤
Model No., Internal production control name, Quantity, Packing date, Corporate name, Country of origin
①Outer Packaging drawing
①Inner Packaging drawing
③Quantity :2,000pcs./Reel
②Inner packing material:・Reel(PPE) ・Carrier tape (PC) ・Cover tape(PET)
MSL3 ROHS label
EIAJ C-3 label
MSL3 ROHS label
EIAJ C-3 label
Static electricity
Static electricity
Moisture sensitive label
30mm
20mm
<Static electricity／
MSL3／RoHS label>
38mm
38mm
<Moisture sensitive label>
550g
1,000pcs./Reel
1,000pcsproducts
5,000pcs/box
