Sharp 32BB2I Technical manual

32BD2I
32BD2IW
32BD3I
32BB2I 32BF2I
32BB2IW 32BF3I
32BB3I 32BF4I
32BB4I 32BF5I
32BB5I
Quick Start Set Up Guide
For information on using the TV’s features, please refer to the operating Instructions.
Quick & easy guide for setting up your TV
What is included in the box
Using the remote control
Setting up the TV for the rst time - including attaching the stand
Connecting other devices to the Television
Need help setting up or using your TV?
Please contact the UK & ROI Helpline*
Telephone UK 0330 024 0803 or ROI 01443 3323
Online support at: www.umc-uk.co.uk
Email support at: servic[email protected].uk
*Calls to 0330 numbers are charged at standard call rates and are included as part of any bundled minutes with your
phone provider.
Calls to the ROI number are charged at the local call rate.
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
Bank Holidays - 10am to 4pm
Closed Christmas and New Years day
Model Numbers
Trademark Sharp
Model ID 32BB2I 32BD3I
32BB2IW 32BD2IW
32BB3I 32BD2I
32BB4I 32BB5I
32BF2I
32BF3I
32BF4I
32BF5I
Energy eciency class A+
Visible screen size (diagonal) 81 cm / 32 inches
On-mode power consumption 31.0 W
Annual energy consumption *1 45 kWh
Standby power consumption *2 <0.50 W
O mode power consumption n/a
Screen resolution 1366 (H) x 768 (V) 1920 (H) x 1080 (V)
*1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4
hours per day for 365 days. The actual energy consumption will depend on how the television is used.
*2: When the TV is turned o with the remote control/standby button and no function is active.
Product che
Additional Technical Information
RF 75 ohm Antenna / Analog / DVB
Inputs 3 x HDMI, 2 x USB, 1 x SCART,
1 x RJ45 LAN/Ethernet, 1 x Composite/CVBS Video & Component/YPbPr
Input, 1 x L/R Audio input for Composite/CVBS & Component/YPbPr
Sound Outputs 1 x Digital Optical Audio output, 1 x 3.5mm Headphone
Speaker* / Amplier Watts (RMS) 2 x 10 / 2 x 8
Voltage and power consumption AC 220V ~ 240V; 50Hz
31/45/70W (home mode/standard/max)
(<0.5W in Standby)
AC 220V ~ 240V; 50Hz
31/45/80W (home mode/
standard/max)
(<0.5W in Standby)
Dimensions including stand (mm) 730W x 470H x 179D
Net weight (Kgs) 4.6 4.8
Wall Mounting VESA 200 x 100 (mm)
32BB2I 32BD3I
32BB2IW 32BF2I
32BB3I 32BF3I
32BB4I 32BF4I
32BB5I 32BF4I
32BD2I 32BF5I
32BD2IW
Win a
Soundbar
Register your manufacturers guarantee online
within 14 days of purchase at
www.registertoday.co.uk/sharp
and enter into a prize draw to
Terms and conditions apply. Online registration only. stration only
.
SHA/QSW/0110
*Built-in Harman Kardon speaker systems (Full-range speaker and tweeter).
Harman Kardon is trademark of HARMAN International
Industries, Incorporated, registered in the United States
and/or other countries.
The terms HDMI, HDMI High-Denition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc.
Technical Specication
Please save your box/packaging as you will need this in the event of warranty/service repair or support. We
are unable to carry out warranty/service if you are unable to package it correctly. The safest way to package
your item in the event of warranty/service repair is in it’s original box/packaging.
REMOTE CONTROL
1
4
2
3
Key
3
2
1
For models with integrated DVD players.
For models with PVR Function.
For models with USB Playback.
4
( / / / / OK )
Accessories
Included with this TV are the following accessories
What is included in the box
1 x Safety Leaflet
1 x Quick start guide
1 x TV
1 x Remote Control and 2 x AAA Batteries
1 x Stand installation pack
4 x
1 x L (left) 1 x R (right)
Additional Accessories
Should you wish to connect older/analogue devices to your television, you can purchase the necessary
cables either from your retailer or at www.umc-uk.co.uk/cables
To receive Freeview channels, in particular Freeview HD channels, you will need a Digital TV aerial and be in a good Freeview
coverage area.
You can check coverage for your postcode at www.freeview.co.uk.
Please note that any Freeview HD channels found during tuning will be placed in channel positions above 100. For example,
101 (BBC1 HD) 102 (BBC2 HD) etc.
RF Cable
Sky Remote Code
If you wish to use your Sky remote to operate the TV’s basic
functions, you will need a Sky remote control (Revision 9 or later)
and you will need to program it with the code 2134. If you wish to
use your Sky Q remote to operate the TV’s basic functions, you will
need to program it with the code 4170.
SHA-QSW-0110 32BB2I.indd 1SHA-QSW-0110 32BB2I.indd 1 09/10/2019 14:37:1309/10/2019 14:37:13

Screen 1
When you first turn on the set, you will be welcomed by the First Time Installation screen as shown above.
Language: Select your preferred on-screen display language. This will change the language in which the menus and associated
information is displayed in. When the setup has been completed, this can be changed by selecting Menu > Settings > Language.
4
Fitting the stand
Connecting your set
First time installation
1 2
Screen 2
Tuning Mode: Select what you wish to tune via TV’s built-in tuner. You can choose from Freeview TV, Analogue TV and ALL
(Freeview + Analogue). At the next step, the set will tune in selected option.
Country: Select the correct country in which the set will be used in. This will enable the TV to correctly install the functions ap-
plicable in the country of use.
Environment: Use this option to select either Home or Store mode.
HOME MODE is a power saving mode which reduces the energy used by up to 25% (by reducing the power to the LED/LCD panel).
When in STORE MODE the picture will be brighter. An on-screen banner showing the sets functionality will appear on the screen
after 2 minutes.
Note: In Home Mode, the TV will switch itself to the standby mode after 4 hours in the event that the buttons on the remote
control or TV are not used.
For the stand installation, there is one type of screw
provided as shown below.
To complete the stand installation you will require a
cross head screw driver.
Place the TV set on a flat and clean surface with the
panel facing downwards to avoid damage.
Setting up the TV set for the rst time
1) Connect the TV to your power socket.
2) If you wish to use the TV to receive Freeview/Saorview channels,
connect the RF input from the TV to your outdoor Digital TV aerial.
If you do not wish to receive Freeview/Saorview, skip this step.
1
2
12
4 x
3
4
1
2
3
Used for attaching the stand
to the TV set (g.2)
4 x
TV panel must be facing downwards.
Place the TV set on a flat and clean surface with
the panel facing downwards to avoid damage.
When the stand feet are installed correctly the
stand feet will be longest at the front of the TV
and shortest at the back with the feet pointing
away from each other.
When the stand/feet are in the correct position, secure
the feet to the underside of the TV set using 4 screws
provided.
3Powering On the TV
Switch on the television by pressing
the TV control stick located on the
TV set.
TV control stick
Insert the batteries supplied into the
remote control and press the standby
button to power on the TV.
TV Control Stick Remote Control: Installing Batteries
Back/Shortest
Front/Longest
Wall Mounting the TV
Image for illustration only.
1. Remove the four screws that are supplied
in the wall mounting holes.
2. The wall mount can now be easily
attached to the mounting holes on
the rear of the TV.
3. Install the wall mounting bracket to the
television as advised by the bracket
manufacturer.
The picture shows the use of spacers, which
are not applicable to all sets/installations.
Connectivity
J
I
H
K
M
Ethernet/LAN* Network connection
Digital Audio Digital Optical Audio Output
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
L/R HDMI input (ARC)
Video/YPbPr HD input (YPbPr)
SCART SCART input
RF in RF / TV aerial input
HDMI 3 HDMI input
Earphones Earphone input
Service Input Input is used only by service centres
CI card in Common interface module
USB 2.0 USB port 2.0
* The Ethernet/LAN port is used for Freeview HD services and smart functions.
AH
L
K
BI
M
C
D
E
F
G
J
1 2
SCART
ETHERNET DIGITAL
AUDIO OUT
OPTICAL L R VIDEO/Y Pb Pr
AB
CD
E
F
Audio shared for Video/Composite
and component/ YPbPr
Video Input (green) and HD input
(Ypbpr)
G
L
