Sharp LC-32CFE6131K User manual

LC-32CFE6131K
LC-32CHE6131K
LC-40CFE6131K
LC-43CFE6131K
LC-49CFE6031K
LC-49CFE6032K
LC-50CFE6131K
User manual
Models:
Image for illustration purposes only. Actual product may vary.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd 1User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd 1 13/08/2015 10:06:1813/08/2015 10:06:18

User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:2User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:2 13/08/2015 10:06:1913/08/2015 10:06:19

3
3
Manufacturers Guarantee
IMPORTANT GUARANTEE INFORMATIONIMPORTANT GUARANTEE INFORMATION
Congratulations on purchasing this television. We hope you have many years of trouble free
enjoyment from your purchase.
Your product is covered under the manufacturers guarantee for 12 months from the date
of purchase.
If you experience any difficulties with your TV, please refer to the ‘Frequently asked questions’ section
in this user guide.
If you are still unable to remedy the issue, try resetting the TV to factory settings. (Details in the
‘Settings menu’ section of this user guide). Alternatively you can contact the helpline on the
number below.
In the event that a fault is diagnosed, the helpline will arrange to collect the TV from your home
or work address, return it to our service centre, repair the item and then return it to you.
If we believe we cannot offer a permanent repair, we will replace the item.
Technical Support Information
Telephone UK 0871 097 1163, ROI 01443 3940
Web support: www.umc-uk.co.uk
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
UK: Calls cost 12p per minute plus your phone company’s access charge.
ROI: Calls are charged at a local rate.
You must retain all packaging materials, in addition to your proof of purchase/receipt,
as you will need these in the event of warranty/service support.
This guarantee is in addition to and does not affect your statutory rights.
If you need to call the helpline, you will need the following information.
1) Model No ______________________________________ (You can find this on the rear of the TV)
2) Date of purchase ______________________________________ (You can find this on your sales receipt)
3) Serial Number ______________________________________ (You can find this on the rear of the TV)
EXAMPLE OF LABEL ON REAR OF TV
This TV set is for domestic use only
Model No
Serial No.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:3User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:3 13/08/2015 10:06:1913/08/2015 10:06:19

4
Important safety instruction
Please read these instructions. All
the safety and operating instructions
should be read before the appliance
is operated.
Warnings
• Television sets which weigh 20kg or more must be
lifted and carried by at least 2 people.
• This television does not contain any parts that are
serviceable by the user. In case of a fault, contact
the manufacturer or authorised service department.
Exposing the internal parts inside the TV may
endanger your life. The manufacturers guarantee
does not extend to faults caused by repairs carried
out by unauthorised third parties.
• To reduce the risk of fire, electric shock or damage
to the TV, do not expose it to dust, rain or moisture.
Never expose the TV to dripping or splashing and do
not place objects filled with liquids on or near the TV.
• Do not connect any external devices (DVD player,
games console etc) when the TV is switched on.
Disconnect both the TV and device from the mains
before connecting. Only switch appliances on when
the connection process is complete.
• Do not place the television in a confined space and
do not obstruct the ventilation openings at the rear
of the television.
• When installing on a wall, ensure the TV is at
least 5cm from the wall for ventilation.
• Always ensure that the TV’s ventilation openings
are not covered with items such as newspapers,
table-cloths, curtains, etc.
• Dispose of this television and any components
including batteries in an environmentally friendly
manner. If in doubt, please contact your local
authority for details of recycling.
Safety
• For your safety, this appliance is fitted with a
fused 3 pin mains plug. Should the fuse need to be
replaced, ensure that any replacement is of the same
amperage and approved with the BSI mark.
• Never try and replace the mains plug unless you have
adequate qualifications and are legally authorised to
do so. In the event that a replacement mains cable
is required, contact the manufacturer for a suitable
replacement.
• Never use the television if it is damaged in any way.
• Always place the television on a flat level surface
avoiding anywhere which may be subject to
strong vibration.
• The ideal distance to watch the television is
approximately five times the length of the diagonal
measurements of the TV screen.
• Ensure the television is not placed on top of the
power cable as the weight of the television may
damage the cable and cause a safety hazard.
• Never place mobile phones, speakers or any
other device which may cause magnetic or radio
interference, near the television. If interference is
apparent, move the device causing the interference
away from the television.
• To disconnect the apparatus from the mains, please
use the mains plug located on the underside/rear of
the TV.
• Ensure that the mains plug is always easily accessible.
WARNING: Excessive noise when using
earphones and headphones can cause loss of
hearing.
Maintenance
• To clean your TV, wipe with a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth dipped
in a soap and water solution or a weak detergent
solution.
• Never use alcohol, paint thinner or benzene to clean
this unit.
• Before using a chemically treated cloth, read the
instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the
television through the display panel surface,
a malfunction may occur.
Packaging
• The safest way to transport your item is in the
original box/packaging - please save your packaging
for this.
• You will need the original box/packaging in the
event of warranty/service repair or support. We
are unable to carry out warranty/service if you are
unable to package the item correctly.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:4User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:4 13/08/2015 10:06:1913/08/2015 10:06:19

5
5
Important information regarding use of video
games, computers, captions or other xed image
displays
The extended use of xed image program material can cause
a permanent“shadow image”on the LCD/LED panel, also
known as “screen burn”.
This“shadow image”can appear in the background during
normal viewing. This type of irreversible LCD/LED panel
deterioration can be limited by observing the following steps:
1. Reduce the brightness/contrast setting to a minimum
suitable viewing level.
2. Do not display the xed image for extended periods
of time.
3. Turn the power o when not in use.
Examples of images that are more likely to cause“screen burn”
are as follows (this is not an exhaustive list):
• TV channel logos: e.g. shopping channel logos and
pricing displays - especially if they are bright and
stationary. Moving or low-contrast graphics are less
likely to cause ageing of the screen.
• Time displays.
• Teletext: Do not view a stationary page for a long
period of time
• TV/DVD menus: e.g. listings of DVD disc content.
• Pause mode: Do not leave the TV in pause mode
for long periods of time, e.g. when watching DVDs
or videos.
Important: Once‘shadow image/screen burn’
occurs, it will never disappear and is not
repairable under warranty.
How do I dispose of this product?
UK: Waste electrical products should not be
disposed of with household waste. Please
dispose of the product at a designated
collection point for recycling of WEEE.
For your nearest facilities, please see
www.recycle-more.co.uk or in store
for details.
ROI: Waste electrical products should not be
disposed of with household waste. Separate
disposal facilities exist. Check with your local
authority or retailer for recycling advice.
Batteries
• Do not expose batteries to high temperatures,
excessive heat, prolonged sunshine or fire as this may
cause leakage, explosion or ignition.
Observe the correct polarity when inserting batteries.
• Do not use different types of batteries together or
mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way.
• Certain regions may regulate the disposal of
batteries. Please consult your local authority.
Trademarks
HDMI
The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and
other countries.
HDTV
The“HD TV” Logo is a trademark of DIGITALEUROPE.
HDTV 1080p
The“HD TV 1080p”Logo is a trademark of DIGITALEUROPE.
DVB
The DVB logo is the registered trademark of the Digital Video
Broadcasting (DVB) project.
FREEVIEW
The FREEVIEW words and logos are trade marks of DTV
Services LTD. © DTV Services Ltd.
SAORVIEW
SAORVIEW is a registered trademark owned by RTÉ.
Dolby
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
YouTube
YouTube and the YouTube logo are trademarks of Google Inc.
Wi-Fi
The Wi-Fi CERTIFIED Logo is a certication mark of the
Wi-Fi Alliance.
Miracast
Wi-Fi CERTIFIED Miracast and Miracast are trademarks of
Wi-Fi Alliance.
Intel WiDi
Intel and the Intel WiDi logo are trademarks of Intel
Corporation in the U.S. and/or other countries.
DLNA
DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks,
service marks, or certication marks of the Digital Living
Network Alliance.
CE Statement:
Hereby, Universal Media Corporation l.t.d. declares
that this LED TV is in compliance with the essential
requirements and other relevant provisions of
Dirrective 1999/5/EC.
http://www.sharp.eu/av/documnts-of-conformity
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:5User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:5 13/08/2015 10:06:1913/08/2015 10:06:19

6
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:6User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:6 13/08/2015 10:06:1913/08/2015 10:06:19

7
7
CONTENTS
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited.
DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a
trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
Manufacturers guarantee information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
What is included in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attaching / detaching the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Securing the TV to a wall / wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TV buttons and Input Source menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-21
Connecting the TV to the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TV menu operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-33
Picture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
Sound menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Channel menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lock menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Time menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Settings menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Applications menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33
7 day TV guide and channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
USB record - Freeview / Saorview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-45
Frequently asked questions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-37
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38-45
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:7User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:7 13/08/2015 10:06:1913/08/2015 10:06:19

8
What is included in the box
Please save your box/packaging as you will need this in the event of warranty/service repair or support.
We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to
package your item in the event of warranty/service repair is in it’s original box/packaging.
WHAT IS INCLUDED IN THE BOX
1 x User guide
1 x Quick start guide
1 x TV
1 x Remote control and 2 x AAA batteries
User guide
Quick start
guide
1 x RF cable
Accessories
Included with this TV are the following accessories.
1 x Stand installation pack
1 x Mini composite / AV cable
(For LC-32CHE6131K, LC-40CFE6131K, LC-43CFE6131K
LC-49CFE6031K, LC-49CFE6032K and LC-50CFE6131K
models only)
1 x Mini component / YPbPr cable
1 x SCART to AV adapter cable
(For LC-49CFE6031K,
LC-49CFE6032K and
LC-50CFE6131K models only)
(For the LC-32CFE6131K
model only)
4 x
1 x L (left) 1 x R (right)
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:8User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:8 13/08/2015 10:06:1913/08/2015 10:06:19

9
9
Attaching/detaching the stand
ATTACHING THE STAND
4 x
3
4
1
2
L
R
4 x
3
4
1
2
L
R
L
R
1
2
Screws that are included.
(fig.1) Place the TV set on a flat and
clean surface with the panel facing
downwards to avoid damage, then
fix the stand/feet shown. The feet are
marked L (left) and R (right).
(fig.2) Secure the stand/feet to
the underside of the TV set using
the 4 screws provided.
Attaching the stand/feet
To complete the stand/feet installation you will require a cross head screw driver.
4 x
Detaching the stand
Remove the screws highlighted then remove the stand/feet from the underside of the TV set.
TV panel must be facing downwards.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:9User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:9 13/08/2015 10:06:2213/08/2015 10:06:22

10
Wall mounting
IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there
could be any electrical wires, water or gas pipes.
1) Remove the four screws located at the back of the TV set.
2) The wall mount can now be easily attached to the mounting holes, located
on the back of the TV, using the same four screws removed.
For VESA wall mounting information please refer to the Technical
Specification page.
For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards
so that the TV’s screen is ‘face on’. See fig 1 and 2.
Important – If wall mounting this TV, only use the screws already provided in the wall mounting holes
located at the back of the TV, using other screws which are longer could cause irreparable damage to
internal parts.
Securing the TV to a wall/wall mounting
SECURING THE TV TO A WALL
Note - Please ensure that children do not climb on the TV set.
Securing the TV to a wall with anti-tip straps
For maximum security in the home, when using a TV with its stand, anti-tip straps should be fitted. These
are available from supermarket websites and other websites and are an easy, inexpensive and effective
way of ensuring your TV stays safely upright. Straps are designed to be attached to the rear of the TV and
then tethered to the wall or the furniture the TV is stood on, these are fitted as follows.
The Royal Society for the Prevention of Accidents is urging people to take care with flat-screen televisions.
RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling flat-screen televisions on to
themselves. They are unsteady on their feet and are attracted by colourful television images.”
The risk is increased as televisions become lighter.
A) Using one or both of the top wall-mounting
holes and screws fasten one end of the fastening
cord/s to the TV. (the screws are already supplied in
the wall mounting holes)
B) Secure the other end of the fastening cord/s to
your wall. (you will need screws/fixings suitable
for your wall type - available separately from most
DIY stores).
fig 1 fig 2
TV
TV
Viewing angle
Viewing angle
INCORRECT CORRECT
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:10User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:10 13/08/2015 10:06:2213/08/2015 10:06:22

STANDBY - Switch on the TV when in standby or vice versa.
MUTE - Mute the sound or vice versa.
NET+ - Access the Aquos Net application.
DTV - Switch to digital TV source.
USB - Switch to USB source.
YOUTUBE - Access the Youtube App.
NUMBER BUTTONS - 0–9 to select a TV channel directly.
TV GUIDE - Opens the 7 day TV guide (digital TV mode).
- To return to the previous channel viewed.
VOL (+/-) - To increase/decrease the sound level.
PICTURE - Scrolls through picture mode options.
SOUND - Scrolls through sound mode options.
SOURCE - To display the input/source menu.
CH (+/-) - To increase or decrease the channel being watched.
MENU - To display OSD menu.
EXIT - To exit all menus.
- Allows you to navigate the on-screen menus and adjust
the system settings to your preference.
BACK - To go back a previous step.
FAV - To display favourites menu.
INFO - Press once for now/next channel information.
- Press twice for information about the current programme.
SLEEP - Press repeatedly to cycle through the sleep options.
AUDIO - To change the audio language (if available).
SUBTITLE - To switch the dialogue at the bottom of the screen (on/off).
TEXT - To enter/exit Text.
TEXT HOLD - Teletext mode - Holds current page which is
displayed (Analogue TV).
TEXT/ZOOM - Zoom function for Teletext and DVD.
DISPLAY - To switch off the screen when listening to radio.
RECORD - Access the USB record function.
REC LIST - Opens the list of what has been previously recorded.
GOTO - To go to a specific chapter.
A-B - Press once to set point, press a second time to return to point.
ANGLE - Select different angle of DVD.
REPEAT - To repeat playback.
11
11
Remote control
REMOTE CONTROL
1
4
2
3
- To restart the current chapter
- To advance forward to the next chapter
- To stop the playback/Eject Disc
(To EJECT the disc press/hold the button for 4 seconds)
- To play in fast rewind mode
- To play in fast forward mode
- To play/pause
Key
4
3
2
1
For models with integrated DVD players.
For models with PVR Function.
For models with USB Playback.
For models with 3D functions.
During the initial set up of your TV you will need to pair the remote control to the TV.
To pair the remote control to the TV, ensure the TV is in standby mode, press and hold the green
and yellow buttons (highlighted below) on the remote control for a few seconds.
Buttons to use when
pairing the remote
control to the TV.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:11User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:11 13/08/2015 10:06:2213/08/2015 10:06:22

12
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:12User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:12 13/08/2015 10:06:2213/08/2015 10:06:22

13
13
Volume up and menu right
Volume down and menu left
Programme/channel up and menu up
Programme/channel down and menu down
Displays menu/OSD
Displays the ‘Input Source’ menu
Standby power On/Off
1
2
3
4
5
6
7
TV BUTTONS AND INPUT SOURCE MENU
1
2
3
4
5
6
7
An example of the ‘Input Source’ menu
(will vary by model)
Note: The shape of the TV buttons may vary by model.
Choosing Mode Input/Source
Use the source menu to switch between
input/connections.
A) Using the buttons on the remote control:
1) Press [SOURCE] - The source menu will appear.
2) Press [\/] or [/\] to select the input you require.
3) Press [OK].
B) Using the buttons on the Television:
1) Press [SOURCE].
2) Scroll up / down using CH+/ CH- buttons to
the input/source you require.
3) Press Vol+ to change input/source to the
one selected.
For further information on input/connections please
view ‘Connections’ pages.
TV Buttons and Input Source Menu
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:13User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:13 13/08/2015 10:06:2213/08/2015 10:06:22

14
Connections
CONNECTIONS
A
C
DEFGH IJK
L
M
N
B
Earphones Earphone input
LAN* Network connection
Video Video input
YPbPr HD input (Ypbpr)
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
VGA PC VGA-PC Input
VGA PC audio in 3.5mm PC audio input
RF in RF / TV aerial input
Digital audio Digital optical audio output
HDMI 3 HDMI input
USB USB port
CI card in Common interface module
A
I
L
B
J
M
N
C
D
E
F
G
H
K
EARPHONE
Y Pb Pr
VGA/P C (Audio in)
VGA/PC IN
VIDEO R
L
Digital Audio
Output
USB CI CARD IN
*The LAN/Ethernet port is used for Freeview HD services and smart functions.
R/L Audio shared for
Video/Composite and
component/ YPbPr
R/L
Input/Outputs for the LC-32CFE6131K.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:14User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:14 13/08/2015 10:06:2313/08/2015 10:06:23

15
15
CONNECTIONS
ACDEFG
H
I
J
K
L
M
N
B
LAN* Network connection
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
VGA PC VGA-PC input
SCART SCART input
RF in RF / TV aerial input
Digital audio Digital optical audio output
HDMI 3 HDMI input
USB x 2 USB port
VGA PC audio in 3.5mm PC audio input
AV in Audio/video input
CI card in Common interface module
YPbPr HD input (Ypbpr)
Earphones Earphone input
A
I
L
B
J
M
N
C
D
E
F
G
H
K
The LAN/Ethernet port is used for Freeview HD services and smart functions.
VGA/PC IN
Digital Audio
Output
EARPHONE
USB
CI CARD IN
VGA/PC (A udio in)
AV IN Y Pb Pr
Connections
Input/Outputs for the LC-32CHE6131K,LC-40CFE6131K
and LC-43CFE6131K.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:15User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:15 13/08/2015 10:06:2513/08/2015 10:06:25

16
Connections
CONNECTIONS
ACDEFG
H
I
J
K
L
M
B
LAN* Network connection
Digital audio Digital optical audio output
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
VGA PC VGA-PC Input
VGA PC audio in 3.5mm PC audio input
RF in RF / TV aerial input
Earphones Earphone input
HDMI 3 HDMI input
YPbPr HD input (Ypbpr)
AV in Audio/video input
CI card in Common interface module
USB USB port
AI
N
L
BJ
M
C
D
E
F
G
K
VGA/PC(Audio in)
VGA/PC IN
Digital Audio
Output
EARPHONE AV IN USB
CI CARD IN
Y Pb Pr
The LAN/Ethernet port is used for Freeview HD services and smart functions.
Input/Outputs for the LC-49CFE6031K and LC-50CFE6131K.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:16User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:16 13/08/2015 10:06:2613/08/2015 10:06:26

17
17
Connections
CONNECTIONS
ACDEFGH
I
J
K
L
M
N
B
LAN* Network connection
Digital audio Digital optical audio output
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
VGA PC VGA-PC Input
VGA PC audio in 3.5mm PC audio input
RF in RF / TV aerial input
SAT In Satellite Input
Earphones Earphone input
HDMI 3 HDMI input
YPbPr HD input (Ypbpr)
AV in Audio/video input
CI card in Common interface module
USB USB port
A
I
N
L
B
J
M
C
D
E
F
G
H
K
VGA/PC(Aud
SAT IN
io in)
VGA/PC IN
Digital Audio
Output
EARPHONE AV IN USB
CI CARD IN
Y Pb Pr
The LAN/Ethernet port is used for Freeview HD services and smart functions.
Input/Outputs for the LC-49CFE6032K.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:17User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:17 13/08/2015 10:06:2813/08/2015 10:06:28

18
Connecting to a device with Composite AV/Video output
TV source should be set to Composite/AV
Connection options for the LC-32CFE6131K.
L (white)
R (red)
Video
(yellow)
L (white)
R (red)
Video
(yellow)
Connections
CONNECTIONS
Connecting to a device with SCART output (using SCART to AV cable)
TV source should be set to Composite/AV
Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is
Included In The Box’ page.
Scart
L (white)
R (red)
Video
(yellow)
Connecting to a device with Component/YPbPr output
If you are supplied with a cable from the device which has red, green, blue, red & white connectors you
must connect via Component (for picture) and by phono cable (for sound).
TV source should be set to Component/YPbPr
R (red)
L (white)
Mini
YPbPr
Y (green)
PB (blue)
PR (red)
R (red)
L (white)
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:18User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:18 13/08/2015 10:06:3013/08/2015 10:06:30

19
19
Connecting to a device with Composite AV/Video output
TV source should be set to Composite/AV
Connection options for LC-49CFE6031K, LC-49CFE6032K and
LC-50CFE6131K.
Mini
AV in
L (white)
R (red)
Video
(yellow)
Connections
Connecting to a device with SCART output (using SCART to AV cable)
TV source should be set to Composite/AV
Scart
Mini
AV in
CONNECTIONS
Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is
Included In The Box’ page.
Connecting to a device with Component/YPbPr output
If you are supplied with a cable from the device which has red, green, blue, red & white connectors you
must connect via Component (for picture) and by phono cable (for sound).
TV source should be set to Component/YPbPr
Mini
AV in
Mini
YPbPr
Y (green)
PB (blue)
PR (red)
Video (yellow)
is not connected
R (red)
L (white)
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:19User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:19 13/08/2015 10:06:3013/08/2015 10:06:30

20
Connections
CONNECTIONS
Connecting to a device with Component/YPbPr output
If you are supplied with a cable from the device which has red, green, blue, red & white connectors you
must connect via Component (for picture) and by phono cable (for sound).
TV source should be set to Component/YPbPr
Mini
AV in
Mini
YPbPr
Y (green)
PB (blue)
PR (red)
Video (yellow)
is not connected
R (red)
L (white)
Mini
AV in
L (white)
R (red)
Video
(yellow)
Connecting to a device with SCART output
TV source should be set to SCART
Scart
Scart
Connection options for the LC-32CHE6131K, LC-40CFE6131K
and LC-43CFE6131K.
Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is
Included In The Box’ page.
Connecting to a device with Composite AV/Video output
TV source should be set to Composite/AV
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:20User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:20 13/08/2015 10:06:3013/08/2015 10:06:30
