Shehds LED Spot 100W Light User manual

1
1.Please keep the light in dryness and avoiding use in wet place.
2.Using intermittenlly can be extended the life.
3.Attention to clean the fan and lens usually in order to get the ventilating effects and lighting effects
better.
4.Please do not wipe the crust using organic menstruum for avoid to damaged the product.
-Statement
The product has well capability and intact packing when leave factory,All of the user should comply
with above warning item and manual ,any misuse cause of the damages are not included in our
guarantee,and also can’t be responsible for any malfunction & problem owing to ignore the manual.
LED Spot 100W Lighting

2
Please forgive that we will not be notice for technical change.
-Attention Item
1.For guarantee the life of product,please do not put it on the wet place and not use it the place over
40 degree.
2.Please don’t lay the product on the un-fixable or shakable place.
3.Ask for the professional to maintain the product in order to avoid the danger of get an electric
shock.
4.Power supply should not be changed over +&-10% while the light is using,it will be decreased the
life of lamp if the power is too high,but it will be influenced the luminosity if the power is too low.
5.After power off,if it is need used again,please cool down over 20 minuter.
6.Please look round the manual for ensure the product can be used normally.
-Display Control Instruction
Welcome to use our light.The light uses energy-saving LED,long Product life,shockproof,dustproof,
DMX receiver and self-running feature, which can produce a variety of vivid lighting effects,easy to
operate, suitable for all types of entertainment decoration,architectural lighting industry.
-Product Introduction
Power Supply:AC90--275V,50--60HZ
Power consumption:100W
Fixing lamp:LED 100W bulb
DMX-Control-channels:14 DMX Channels
Shuttle:Flash rate:0--10HZ
Dimmer:0-100% mechanic dimmer
Long Lifespan LEDs(more than 60,000 hours)
Color wheel:RD、GN、BU、YE、VT、SKY 、WHI、OR,
GOBO:7 Dynamic&6 Static
DMX 512 Channel：14CH

3
1.Set
Menu
Submenu
Detail
Run Mode
DMX/Auto/Random
Master&Slave：Receiving signals from DMX
DMX Address
001-512
Set DMX Address code
Channel Mode
Std. 14CH
Standard 14 channel mode
Top lamp Temp
001-110
Top lamp temperature range
Sound Regulator
±006
Sound control sensitive range
Invert Pan/Tilt
On/Off
Pan/Tilt Invert
Pan-Tilt Swap
On/Off
Pan/Tilt Swap channel
Pan-Tilt Encoder
On/Off
Use encoder to judge out of step and correct position automatically
RDM
On/Off
RDM mode on/off
No DMX Signal
KEEP/CLEAR
Keep or Clear channel value when DMX Signal lost
Display
On/Off
Turn off the backlight after 30 seconds without operation
Lamp on@Startup
On/Off
Turn on the light after starting
Load Default
▶
Restore default values
2.Manu
This interface is used to control the current lamp.
Press the OK key to enter the editing state. Press the UP and DOWN keys to change the channel value.
Press the MENU key to exit the edit status.
3.Advan
Here is a layer of password to prevent non-professional misoperation.
The default password is UP UP DOWN DOWN

4
DMX Channel Summary
Channel
Function
Value
Function
CH1
Dimming
0-255
Total dimming
CH2
Strobe
4-251
Strobe frequency
251-255
Open Light
CH3
Pan
0-255
Pan 540°
CH4
Tilt
0-255
Tilt 270°
CH5
Move Speed
0-255
Pan and Tilt rotation speed
CH6
Color
0-255
Color Wheel
CH7
Dynamic Gobo
10-79
Dynamic Gobo Select
80-129
Dynamic gobo clockwise rotationfast to slow
135-220
Dynamic gobo anti-clockwise rotation slow to fast
221-255
Gobo shake
CH8
Static Gobo
10-69
Static gobo select
70-129
Static gobo clockwise rotation fast to slow
135-225
Static gobo anti-clockwise rotation slow to fast
226-255
Gobo shake
CH9
Static Gobo
Rotation
0-63
Static gobo rotation 180°
64-190
Clockwise rotation
191-255
Anti-clockwise rotation
CH10
Prism
10-14
Prism switch
15-255
Prism rotation
CH11
Focus
0-255
Pattern focus
CH12
Pan fine
0-255
Pan fine 2°
CH13
Tilt fine
0-255
Tilt fine 2°
CH14
Reset
255
Reset system
