Shenou S1 User manual

S1 桌面型话机快速操作指南
0
ES270 DeskPhone
Quick User Guide
表 1 状态灯
线路 1 状态
描述
橙色常亮
空闲状态下有未接/前转/DND/留言/静音/未注册等
表 2 线路键状态
线路 1/2 灯状态
描述
红色闪烁
对应线路来电/对应线路保持中
红色常亮
摘机/拨号/对应线路通话中
无亮灯
对应线路空闲状态
列表
数量
话机
1
手柄
1
网线
1
快速操作指南
1
支架
1
1-1
安装支架:将支架的卡扣对准支架板下面两个卡口后，手托住支架向上轻轻推
一下即可.（如上图）
PC 口接电脑，LAN 口接外网， 接电源， 接 RJ9 耳麦，
接话机手柄。
步骤为：按话机上软按键菜单=> 系统设置=> 高级设置=>输入高级设
置 密 码 （默认为空）=> 网 络 =>LAN 口 => 网 络 类 型（ DHCP/ 静 态
IP/PPPoE）=>进入=>保存=>确定（重启生效）。
有以下选项：静态 IP、拨号 PPPoE、DHCP 自动获取
选择静态 IP 后按导航键-下，看到 IP 地址设置，可对 IP 及网关等网
络信息进行设置，其中“.”请用键“*”输入，修改完后确定。
选择 PPPoE 输入账号和密码后按保存=>确定（重启生效）。
选择 DHCP 不用设置 IP。
1-2
按话机上的菜单键菜单=> 系统设置=> 高级设置=>输入高级设置密
码（默认为空=> Sip 帐号=>账号 X（X-1，2），之后分别配置以下帐
号参数：帐号激活状态、标签、显示名、认证用户名、注册名、密码、
SIP 服务器等
主 SIP 域名：输入 SIP 服务器 IP（“.”请用键*输入，注意 IP 话机
与 SIP 服务器间网络必须可达），之后选取“保存”，即可完成 SIP
账户的添加。
您可以摘机或按下免提键或耳麦键来进行一个呼叫。
直接呼叫：按下免提键或者摘下手柄直接拨打号码，然后按#键或按发
出软键；
重拨：按重拨键以列出所有“已拨号码”，可以有选择的拨打您需要
拨出的号码；
从呼叫记录进行呼叫： 直接按“话单”或者在待机状态下按“下导航
键”调出“未接来电”，也可按左右导航键去选择“全部记录”、“已
接号码”或“已拨号码”或者“前转来电”列表来选择一个号码，再
按“拨号”软键进行呼叫。
实现来电前转、通话转移;
来电前转：在来电振铃时，按下前转同时拨出需要转移的目的号码，
本机直接挂机。
咨询转：在通话中按下“转移”键，听到拨号音，此时拨打需要转移
的目的号码，等待对方振铃并接听起来通话后再按“转移”键可实现
转移。
*更多的详细内容以及话机配置信息请参考本话机的用户手册。您也可以
通过访问话机的 Web 页面来进行更详细的参数配置，在话机空闲时，按 C
键查看话机的 IP 地址，在电脑的浏览器中输入 IP 话机的地址，输入话机
的用户名、密码（默认均为 root），即可进入了 IP 话机的网页配置界面。
Shenou 申瓯通信
申瓯通信设备有限公司
地址：浙江省温州市牛山北路高新园区炬光园中路 118 号
邮编：325027
网址：http://www.shenou.com
1-3
显示屏
扬声器
导航键
音量键
线路键
软按键
导航键上
耳麦键/导航键下
闭音键/C 键
重拨键
免提键
麦克风
数字键盘/*/#

S1 Desk Phone Quick Start Guide
Table 1 Light-strip
Line 1 Status
Description
Yellow
steady
Under the idle status, the light will on when:
Missed Call, Transfer, DND, Message, Mute,
SIP-Unregistered.
Table 2 Line keys
Line 1/2 LED Status
Description
Red, flashing
Incoming call;On hold
Red, steady
Pick up;On communication
Light off
Idle
Name
Amount
IP Phone
1
Handset
1
Cable
1
Quick User Guide
1
Bracket
1
2-1
PC Port for Computer connection, LAN Port for Internet connection,
connected power adapter, connected headset, connected
handset.
Press the menu soft key on the phone MENU=> System setting=>
Advanced setting=>Enter Advanced Password (Empty by
default) => Network => Enter LAN Port
Type has the following options : STATIC、PPPoE、DHCP
Select STATIC and press Navigation key to see the IP address
settings and set the IP and gateway and other related network
information, including "." Use the key "*" entry.
Select PPPoE and insert username and password to register.
Select DHCP without setting IP.
NOTE: After changing the configuration, reboot for application.
2-2
Under the idle status, you can start to configure account by
pressing MENU soft key => System Setting => Advanced
Setting=>type Advanced password (it is idle by default) => SIP
Account, the main parameters for 2 SIP accounts are needed to
be set as follow:
Enable Account: Select Enable
Account: Insert your SIP account
Authen User: The authentication with the account
User Pwd：Insert your SIP password
SIP Server：Insert the SIP server IP address (you can insert “.” by
“*” key, you must confirm the connection between the phone and SIP
server), And then select Submit changes and press OK to submit the
changes.
You can pick up the handset or press Speaker/Headset key to place a call.
Dial directly: Dial number directly, then press # key or press
soft-key (It will call from the first available line);
Redial: Press Redial key/soft-key to dial the latest number;
Dial from Call history: Press Menu key, select “Call history” and
select one of “Missed calls”, “Received calls” and “Dialed numbers”
lists to dial by pressing Dial soft-key.
You can open Call history under idle status of phone by pressing
corresponding Soft key-Dir or Down key under the idle. And then you
can through the navigation key to select, “Received Calls” list, “Missed
Calls” list, “Dialed Calls” list, "Forwarded Calls" list and "All Calls" list.
*This document introduces main function operation of IP phones only.
For details (operation and configuration), refer to User Manual. And
set details on the web page of phone. In the browser, input the IP
phone's address and the phone's user name and password (default is
root), and then login into the IP phone's web configuration interface.
Shenou 申瓯通信
Shenou communication Equipment Co., Ltd
118 Juguang Rd, Juguang Park of High & New Industial Zone,
Wenzhou City, 325027, China .325027
Web:http://www.shenou.com
2-3
LCD
Hron
Volume Keys
Navigation Keys
Line Keys(LEDs)
Soft Keys
Navigation Up Key
Headset / Navigation
Mute / C Key
Redial Key
Speaker Key
Digits,*,#
Mic
