SHIMGE SG(m) Series User manual

Models: SG(m)、SE(m)、SS(m)、QJD
Mini-type Clean-water Centrifugal Electric Pump
SERVICE MANUAL

I. Product Introduction
II. Operating Conditions
III. Structure Diagram
IV. Instructions for Installation and Use
V. Maintenance
VI. Troubleshooting
Contents

Thank you very much for choosing our products, and please read over the Operating Manual and
keep it properly before the installation and use.
Warning
• The Electric Pump must be grounded reliably before use, and shall be equipped with
an electrical leakage protection device;
• It's strictly prohibited to touch the Electric Pump during operation;
• It's strictly prohibited to run the Electric Pump without water;
• It's strictly prohibited to run the Electric Pump with the valve closed;
• For three phase-motors with integrated thermal protector shut down due to overload
or overheating, it is NOT allowed to re-connect the power until motor cooling for more
than 10 minutes.
Electric Submersible Deep Well Pumps(hereinafter referred to the “Electric Pump”) include
SG(m), SE(m), SS(m), QJD series. SG(m), SE(m), SS(m) series are oil-filled being composed of
two parts i.e. pump body and motor. Pump body is with multistage centrifugal impellers lying
upper of the Electric pump, a single-phase or three-phase asynchronous motor is at the bottom of
the Electric pump; adopting single-ended mechanical seal as dynamic seal in the motor, and at
the place of sealing of each fixed spigot is an O-shaped rubber seal ring used as the static seal.
QJD series is dry-type Electric pump being composed of two parts, i.e. pump body and
motor. Pump body is with multistage centrifugal impellers lying upper of the Electric pump, a
single-phase dry-type asynchronous motor is at the bottom of the Electric pump; adopting single
–ended mechanical seal and double-ended mechanical seal in the motor, and at the place of
sealing of each fixed spigot is an O-shaped rubber seal ring used as the static seal.
Electric pump is with high head due to its multistage impellers structure, Which are widely
applied in irrigation, deep well water lifting, tower water delivery, urban construction, and water
supply to industrial and mining enterprises.
I. Product Introduction
II. Operating Conditions
The Electric Pump shall be able to operate continuously and normally in the following
operating conditions:
1. The temperature of the medium does not exceed 40°C;
2. The pH value of the medium is 6.5~8.5;
3. The mass ratio of the solid impurities contained is not more than 0.01% and the particle
size is not bigger than 0.2mm;
4. The submersible depth of the Electric Pump in the water is 5~70m, while that of a QJD
pump is 5~20m.

1 Inlet joint
2 Oring
7 Screw and spring washer set
8 Countersunk head screw
Pump Part of SE (m) Series
III. Structure diagram
3 Countersunk head screw
4 Locating bush
5 Mesh enclosure
6 Screw
9 Coupling
10 Sleeve
11 Pump Shaft
12 Guide vane cover
13 Impeller
14 Fluid director
15 Wear washer
16 Guide vane
17 Ceramic shaft sleeve
18 Middle rubber bearing
19 Middle bearing block
20 Screw
21 Small press plate (ii)
22 Pump sleeve
23 Press plate for the cable
24 Small press plate (i)
25 Cable sheath
26 Ceramic shaft sleeve
27 Rubber bearing
28 Spring washer
29 Screw
30 Locating pin
31 Spring washer
32 Screw
33 Oring
34 Discharge chamber back ring
35 Adjusting washer
36 Discharge chamber
37 Valve cover
38 Retaining ring

1 Hexagon bolt }
Provided for
the motor
(3kW or
above)
2 Flat washer
3 Base
4 Retaining ring
5 Bottom cover
6 Pressure regulating membrane
Capacitor (single phase)
7 Bearing block
8 Bearing (quantity: 1 or 2)
9 Lower retaining sleeve (above 3kW)
or insulation paper (below 2.2.kW)
10 Motor bracket
11 Stator core with winding
Thermal protector: all single phase,
three phase of 0.75～3kW.
Three phase of 4～7.5kW required
external protection control box
12 Rotor
13 Upper retaining sleeve
14 Deep groove ball bearing
15 Wave spring
16 Mechanical seal
17 Oring
18 Oil chamber
19 Cross recessed countersunk
head screw
20 Cable plug
21 Cable press plate
22 Oring
23 Full-thread bolt
24 Sand prevention seat
25 Sand prevention cushion
26 Hex nut
27 Sand prevention sleeve
Motor Part of SE (m) Series

1 Inlet joint
6 Guide vane cover vane
2 Mesh enclosure
3 Cross recessed
countersunk head screw
4 Coupling
5 Sleeve
7 Impeller
8 Guide vane
9 Wear washer
10 Pump shaft
11 Small press plate
12 Cross recess oval head
screw
13 Press plate for the flat
cable
14 Pump sleeve
15 Small press plate
16 Shaft sleeve
17 Flat washer
18 Spring washer
19 Cross recess pan head
screw
20 Middle rubber bearing
21 Middle bearing block
22 Upper block
23 Valve cover
24 Oring
25 Adjusting shim
26 Discharge chamber
27 Dust cover
Pump Part of SG (m) Series

1 Retaining ring
2 Bottom cover
3 Pressure regulating
membrane
4 Motor bracket
5 Locating sleeve
6 Cross recessed
countersunk head screw
7 Bearing block
8 Insulation paper
9 Stator core with
winding
10 Deep groove ball
bearing
11 Rotor
12 Deep groove ball
bearing
13 Flat washer
14 Inner plug (three-pin
plug)
15 Wave spring
16 Mechanical seal
17 Upper retaining sleeve
18 Oring
19 Oil chamber
20 Closed terminal
21 Outer plug
22 Oring
23 Air Faucet
24 Sand prevention seat
25 Sand prevention cushion
26 Sand prevention sleeve
27 Cover plate
28 Hexagon socket set
screws with flat point
29 Spring washer
30 Outer plug
Motor Part of SG (m) Series

1 Inlet joint
2 Mesh enclosure
3 Oring
4 Inlet Joint back ring
5 Coupling
6 Pump shaft
7 Lower spacer bush
8 Friction pad
9 Friction plate
10 Stopping plate
11 Fixing sleeve
12 Lower rubber bearing
13 Lower supporting block
collar
14 Lower supporting block
15 Cover plate for the
guide vane
16 Impeller
17 Guide vane collar
18 Guide vane
19 Middle supporting
block collar
20 Middle supporting
block
21 Middle shaft sleeve
22 Press plate
23 Pump sleeve
24 Cable press plate
25 Backing ring
26 Adjusting shim II
27 Upper spacer bush
28 Adjusting shim
29 Shaft sleeve
30 Rubber bearing
31 Pump shaft gasket
32 Locating pin
33 Discharge chamber
34 Spring washer
35 Screw
36 Valve cover
37 Retaining ring
38 Dust cover
Pump Part of 6SE-T Series

1 Outer hexagonal screw
2 Base
3 Retaining ring
4 Bottom cover
5 Pressure regulating
membrane
6 Motor bracket
7 Locating sleeve
8 Hexagon socket
countersunk head screw
9 Bearing block
10 Lower retaining sleeve
11 Stator core with winding
12 Bearing
13 Rotor
14 Bearing
15 Upper retaining sleeve
16 Wave spring
17 Flat washer
18 Mechanical seal
19 Oring
20 Oil chamber
21 Terminal
22 Screws set
23 Spring washer
24 Framework oil seal
25 Wear ring
26 Air faucet
27 Gland for the wear ring
28 Cross-recessed lentil-
headed screw
29 Sand throwing sleeve
30 Plug
31 Outer-hexagonal flat screw
Motor Part of 6SE-T Series

10 Upper bearing block
9 Upper seat
8 Valve deck
7 O-shaped seal ring
6 Pump sleeve
5 Cable press plate
4 Small press plate
3 Oring
2 Discharge chamber
1 Dust cover
22 Coupling
21 Mesh enclosure
20 Inlet joint
19 Screw
18 Cover plate for the guide
vane
17 Impeller
16 Fluid director
15 Wear washer
14 Guide vane
13 Ceramic shaft sleeve
12 Middle rubber bearing
11 Middle bearing block
Pump Part of QJD Series

29 Slotted cheese-
head screw
28 Oring
27 Rear seat cover
26 Oring
25 Closed-end terminal
24 Capacitor
23 Lower bearing block
23 Motor Bracket
22 Stator core with
winding
21 Deep groove ball
bearing
20 Rotor
19 Deep groove ball
bearing
18 Locating sleeve
17 Cross-recessed
countersunk head screw
16 Oil chamber
15 Mechanical seal
14 Oring
13 Oil chamber cover
12 Cross-recessed
lentil-headed screw
11 Mechanical seal
10 Sand prevention cushion
9 Shaft circlip
8 Round-hole rubber jacket
7 Cable packing washer
6 Threaded gland for the cable
5 Hexagon socket set screws
with flat point
4 Spring washer
3 1-type hex nut
2 Cross recessed countersunk
head screw
Motor Part of QJD Series
1 Pump spindle shaft

Installation Diagram
Pressure gage
Check valve
≥3m
IV. Instructions for Installation and Use
Valve
Drainage hole
Well lid
Cable
Rope
Lifting rope
Water pipe
Electric Pump
Slpint
Sandy soil at the
well bottom
1.Before installation and use, please fully check whether the Electric Pump is damaged
during transportation or storage, for example, whether any cable or terminal box is in a perfect
condition. In case of any damage, please have a specialized person making replacement or
repair.
2.Before the Electric Pump operates, please completely inspect the cold insulation resistance
of the Electric Pump, which shall be not less than 100MΩ, or otherwise the corresponding
measures shall be taken and operation shall not be allowed until the relevant requirements are
met.
3.During the wiring of a three-phase electric pump, please properly install an electrical
leakage protection device to the pump. For those pumps provided with control box, please make
connecting according to the diagram in the control box or related instruction manual.

①
②
④
10mm
30mm
⑤
③
At least 10 times as the diameter of the conductor.
Drawing 1
Cable Connection Diagram
≥60mm
1.Remove the insulating layer
without damaging the
conductor.
2.Stagger long and short wires.
3.Ensure that no oil, water or
any other pollutant exists at the
connection.
1.Divide each connector into
several strands evenly (no less
than 6 ones) and tighten them.
2.Cross the two connectors so
that the overlapping length will
make the two ends are aligned
with the insulating layer.
1.Clench each strand. First get one strand
from the middle and make it wind to one
end (the wound core wire shall include the
remaining strands) and then make each of
the remaining strands wind successively as
well.
2.Follow the same procedure at the other
end.
3.Use pliers to tighten the connectors. The
best effects can be achieved by wrapping
the connectors with tin.
4.Remark: For other methods, please refer
to the attached Drawing 1 and Drawing 2.
1.First use the black tape to tightly wrap the connector
area and make two layers; do not expose the copper wire
head. Please see the attached Drawing 3.
2.Then use the pressure sensitive tape (self-adhesive
tape) to make a three-layer wrapping, 10mm longer at the
two ends should be needed based on previous layer
wrapping. Do not do wrapping until the length of the tape
drawn out is twice the original length.
3.Finally apply the plastic insulating tape (yellow
transparent) to make the last layer wrapping.
1.Properly arrange the connectors of core wires
and make a four-layer wrapping by use of the
pressure sensitive tape with two ends wrapping
a length of 30mm on the cable sheath and
10mm longer at the two ends should be needed
based on previous layer wrapping
2.Then make a three-layer wrapping with the
plastic insulating tape with the next layer about
10mm longer than the first layer at the two ends.
30mm
Plastic insulating tape Pressure sensitive tape
Black tape
Plastic
insulating tape Pressure sensitive tape
Connector of
several wires
First layer
Last layer
An electric arc welded joint is
preferred.
Drawing 2 Drawing 3
A joint made by cold welding of
casing is also acceptable.
When the first layer of the black tape is
made, no copper wire shall be exposed or
the tape shall not be punctured.
4.A single-phase electric pump with integrated automatically-reset thermal protector, when
the thermal protector works, automatic reset will happen after the temperature of the motor
decreases to a certain value, In the event of frequent protection actions, please cut off the power
supply and find out the causes and then operate the Electric Pump until the relevant trouble is
cleared. For a three-phase electric pump with integrated power failure-reset thermal protector,
upon the protection action of the protector, please first cut off the power supply and turn on the
power supply again after 10 minutes, Electric Pump will operate normally. In the event of frequent
protection actions, please cut off the power supply and find out the causes and then use the
Electric Pump until the relevant trouble is cleared.

30m
5.Before putting the Electric Pump into water, please carry out a test running for no more
than 10 seconds and simultaneously check whether the rotational director of the pump shaft is the
same as that indicated by the indicating arrow in the nameplate.
6.Connect a delivery pipe (whose specifications are selected based on Table 1) matching
with the discharge chamber. For example, tighten a soft delivery pipe with the iron wire or a clamp
or reliably connect a steel-type delivery pipe with the screwed joint, and then tie a rope to the
delivery chamber for the purpose of lifting and placing.
7.Do not strike or press the cable or use it as a lifting rope. When the Electric Pump is
operating, do not arbitrarily pull the cable, so as to prevent the cable from being damaged and
causing any electric shock accident. Upon installation, bind the cable to the delivery pipe or take
other proper measures for protection, so as to avoid any tensile deformation due to the great
dead-weight of the cable.
8.When the Electric Pump is submerged in water, its depth shall not exceed 70m (20m for
QJD series) and shall be at least 3m away from water bottom and it shall not be caught in sludge.
Simultaneously keep the mesh enclosure or the impeller from being blocked by water plants or
sundries, for such blocking may result in the Electric Pump's failure to operate normally. During
operation, please frequently check the water level and make sure that there is enough water to
cover Electric Pump.
9.Please arrange a safety warning sign on the site where the Electric Pump is operating,
which reads “DANGER: ELECTRIC SHOCK RISK AND NO ENTRY FOR PEOPLE OR ANIMAL”,
so as to prevent any accident.
DANGER: ELECTRIC SHOCK
RISK AND NO ENTRY FOR
PEOPLE OR ANIMAL
10.Oil-filled electric pumps shall not be filled with any liquid medium other than No. 10
mechanical oil. dry-type structure QJD series shall not be filled with any liquid medium.

Impeller
0
MPa
1.0
0.5
1.5
2.0
2.5
0.6
The testing pressure
shall be 0.2Mpa and
wait until 5 minutes,
no leakage occurs.
MPa
0
1.0
0.5
1.5
2.0
2.5
0.6
11.Oil-filled electric pump filled with No. 10 white food machinery oil so as to ensure that the
mechanical seal is effectively lubricated and cooled, which might leak in case of any damage or
fault of the Electric Pump. The leaked white oil might damage the botany planted or the animal
bred or pollute the drinking water or food involved in any application relating to planting, breeding,
or delivery or processing of drinking water or food. To select a product hereunder, the user shall
evaluate the relevant application and the consequence of the use of such a product so as to
confirm whether the product is suitable and even invite a related specialized person to do such
confirmation when necessary. In case of any leakage of white oil, please immediately stop using
and properly dealing with it.
12.When the Electric Pump is being used, please first cut off the power supply in case that
the Electric Pump is to be relocated or touched, so as to avoid any accident.
V. Maintenance
1.The matters needing attention prior to the disassembly of the motor for maintenance: First
wait until the motor is cool, then unscrew the oil filler bole, to release the high-pressure gas
generated inside due to burn-in, for the purpose of preventing the upper cover from jumping out to
hurt people.
2.Regularly inspect the insulation resistance between the motor bracket and the winding of
the Electric Pump, which shall be no less than 1MΩ when the operating temperature is nearly
achieved, or otherwise usage shall not be allowed until the corresponding measures are taken
and the relevant requirements are met.
3. After the 2500-hours normal usage of the Electric Pump, the Electric Pump shall be
maintained as per the steps below:
a) inspect various easy broken parts such as the mechanical seal, bearing, and impeller.
Please immediately replace in case there are damaged ones.
b) After the completion of inspection and repair, please do an air pressure test under the
pressure of 0.2MPa; to wait until 5 minutes, no leakage occurs.
Bearing
Mechanical seal
Impeller,
Mechanical seal,
Bearing

Oil Oil
Oil
Fault
c) When the replacement of No. 10 white food machinery oil for an oil-filled motor, the motor
must be fully filled.
3.If the Electric Pump is not used for a long time, it should not be submerged in water. Place
it in clean water for energized operation for minutes, clear away the condensate inside and
outside the Pump, dry it, and then carry out rust-proof treatment, and finally put it at a well-
ventilated dry place.
VI. Troubleshooting
Cause Remedy
Difficulty in
startup
Low water
yield
No rotation
suddenly
1. The supply voltage is too low.
2. The impeller is blocked.
3. The cable is too thin and the
voltage drop is too high.
4. The stator winding is burnt.
1. Adjust the voltage to ±10% of the rated
value.
2. Correct the part blocked.
3. Select a proper cable.
4. Re-insert the winding or carry out overhaul.
1. The head is too high.
2. The mesh enclosure is blocked.
3. The impeller is seriously worn.
4. The submersion depth of the
Electric Pump is less than standard
and air is absorbed.
5. There is leakage at the outlet.
1. Follow the range of head.
2. Clear away sundries like water plants.
3. Replace the impeller.
4. Adjust the submersion depth of the Electric
Pump, which shall not be less than 5m.
5. Add the Teflon tape to the place of thread for
sealing.
1. The switch is disconnected or
the fuse is burnt.
2. The impeller is blocked.
3. The stator winding is burnt.
4. The motor is overloaded and the
protector acts.
1. Inspect whether the head and the supply
voltage used conforms to the relevant
provisions and make adjustments accordingly.
2. Remove sundries.
3. Re-insert the winding or carry out overhaul.
4. Check whether the impeller is blocked or the
voltage is too low.

3
m /h L/S25 32 38 50 65 75 80 100 125 150 200
3
4
5
6
7
8
9
10
12
14
16
18
20
25
30
35
40
45
50
60
70
80
90
100
0.83
1.11
1.39
1.67
1.94
2.22
2.5
2.78
3.33
3.89
4.45
5
5.56
6.94
8.33
9.72
11.1
12.5
13.9
16.7
19.4
22.2
25
27.8
16.31
27.76
42
4.9
8.35
12.62
17.68
23.53
30.13
37.47
2.12
3.61
5.46
7.66
10.19
13.05
16.23
19.72
27.64
36.78
0.56
0.95
1.44
2.01
2.68
3.43
4.26
5.18
7.26
9.66
12.37
15.39
18.7
28.27
0.16
0.26
0.4
0.56
0.75
0.95
1.19
1.44
2.02
2.69
3.45
4.29
5.21
7.83
11.15
14.89
18.81
23.39
0.13
0.2
0.28
0.37
0.48
0.59
0.72
1.01
1.34
1.72
2.14
2.6
3.92
5.3
7.32
8.38
11.65
14.17
19.86
0.1
0.15
0.2
0.27
0.35
0.43
0.52
0.74
0.98
1.25
1.56
1.9
2.87
4.02
5.34
6.54
8.51
10.32
14.5
19.29
24.7
0.12
0.15
0.18
0.25
0.33
0.42
0.53
0.64
0.97
1.35
1.8
2.31
2.87
3.49
4.89
6.5
8.33
10.35
12.59
0.11
0.14
0.18
0.22
0.33
0.46
0.61
0.78
1
1.18
1.65
2.1
2.81
3.49
4.25
0.09
0.13
0.19
0.25
0.32
0.4
0.48
0.68
0.9
1.16
1.44
1.75
0.12
0.17
0.22
0.28
0.38
0.43
Fault Cause Remedy
Stator
winding
burnt
1. The mechanical seal is damaged and
water leakage happens, resulting
interturn or interphase short circuit.
2. The impeller is blocked.
3. The Electric Pump starts frequently or
operates without water for a long time.
4. The Electric Pump makes overload
operation.
Do troubleshooting, disassemble the
winding and re-insert the winding as
per the concerned technical
requirements as well as immerse and
dry the insulating varnish or deliver the
winding to the repair station for repair.
Table on Head Loss per 100m of the Steel Pipe
Flow rate Inner diameter of pipe [mm]
1. Head loss per 100m of the plastic pipe=Head loss per 100m of the steel pipe X 0.7
Notes:
1. All the diagrams in this Operating Manual shall be only for reference, the Electric Pump
purchased and its accessories might be different from those indicated in this Operating Manual.
Your understanding is really appreciated.
2. The products involved hereunder are subject to continuous improvements and changes
without further notice and a product (including its appearance and color) in kind shall prevail.
