Shindaiwa T300 Owner's manual

T300 GRASS TRIMMER
C300 BRUSHCUTTER
T300
C300
Part Number 62093-94312 Rev. 10/04
WARNING! Read this manual and familiarize yourself with its contents.
This machine is designed for cutting grass, weed, and bushes. Do
not use this machine for other purposes.
Minimize the risk of injury to yourself and others.
Do not operate or service this machine unless you clearly
understand this manual.
Keep this manual at a particular place so that you can reread it
whenever you have a question about its use.
SHINDAIWA OWNER’S/OPERATOR’S MANUAL
English..............1
Français......FR�1......FR�1
Italiano.........IT�1

2
Attention Statements .................................2
The Properly Equipped Operator.............3
General Safety Instructions ......................4
Product Description...................................5
Technical Specifications............................6
Prior To Assembly .....................................6
Before Assembling Outer Tube ...............7
Assembly Of The Outer Tube ..................7
Assembly Of The Handle ..........................8
Throttle Cable Adjustment........................8
Debris Shield Assembly............................9
Installing A Blade.....................................10
Filling The Fuel Tank..............................10
Starting The Engine ................................11
Stopping The Engine...............................12
Engine Idle Adjustment...........................12
Unit Condition Check..............................12
Prior To Operation...................................12
To Wear The Strap ...................................12
Emergency Release .................................12
Operation ..................................................13
Recommended Cutting
Attachment................................................13
Blade Sharpening.....................................14
Maintenance.............................................14
Daily Maintenance...................................14
10-hour Maintenance...............................15
10/15-hour Maintenance.........................15
50-hour Maintenance...............................15
Muffler Maintenance...............................15
Long Term Storage..................................16
Troubleshooting Guide ...........................16
Declaration Of Conformity......................19
Contents
Throughout this manual are special “at-
tention statements” surrounded by boxes
and preceded by the triangular Attention
Symbol.
Attention Statements
WARNING!
A statement preceded by the
triangularattentionsymboland
the word “WARNING” contains
information that should be acted
upon to prevent serious bodily injury.
CAUTION!
A statement preceded by the word
“CAUTION” contains information that
should be acted upon to prevent me-
chanical damage.
IMPORTANT!
A statement preceded by the word
“IMPORTANT” is one that possesses
special significance.
NOTE:
A statement preceded by the word “NOTE”
contains information that is handy to know and
may make your job easier.
Read and follow the
operator’s manual. Failure
to do so could result in
serious injury.
Wear head, eye and hear-
ing protection during the
operation of this machine.
Wear non slip gloves,
long trousers and nonskid
boots during the operation
of this machine.
Make sure no one is within 15
meters (50 feet) of an operating
attachment.
Beware of thrown objects.
The maximum
speed of the
cutting attachment
shaft in min-1.
Sound power level (mea-
sured in accordance with
2000/14/ec)
PAGE

3
The Properly Equipped Operator
WARNING!
Use Good Judgment
ALWAYS wear eye protection to shield
against thrown objects.
NEVER run the engine when
transporting the machine.
NEVER run the engine indoors - make
sure there is always good ventilation.
Fumes from engine exhaust can cause
serious injury or death.
ALWAYS clear your work area of trash
or hidden debris that could be thrown
back at you or toward a bystander.
Wear hearing protection devices, such as ear-mufers.
Wear a head protection device, such as a helmet.
Keep your hair above shoulder length.
Wear close-tting clothing
to protect legs and arms. Do
not wear clothing or jewelry
that could get caught in
machinery or underbrush.
Keep a proper footing and do
not overreach-maintain your
balance at all times during
operation.
Wear long trousers.
NEVER wear shorts.
Wear non-skid boots. Do not wear
open-toed shoes or sandals. Never
work barefooted!
Always make sure the appropriate
cutting attachment shield is correctly
installed.
Keep away from the rotating
trimming line or blade at all
times, and never lift a moving
cutting attachment above
waist-high.
When operating with a
blade, make sure the handle
is positioned to provide you
with maximum protection
from contacting the blade.
Wear non-slip gloves.
Always operate with
both hands rmly gripping
the machine.
Always wear a strap when operating
a machine equipped with a blade.
Always wear eye protection such as
goggles or safety glasses.
ALWAYS use the proper cutting tool for
the job.
ALWAYS stop the machine immediately
if it suddenly begins to vibrate or
shake. Inspect for broken, missing
or improperly installed parts or
attachments.
NEVER extend trimming line beyond
the length specied for your unit.
ALWAYS keep the unit as clean as
practical. Keep it free of loose
vegetation, mud, etc.
ALWAYS hold the machine rmly
with both hands when cutting or
trimming, and maintain control at all
times.
ALWAYS keep the handles clean.
ALWAYS disconnect the spark plug
wire before performing any
maintenance work.
ALWAYS, if a blade should bind fast in
a cut, shut off the engine immediately.
Push the branch or tree to ease the
bind and free the blade.

4
WARNING!
Never make unauthorized
attachment installations.
WARNING!
Never operate power
equipment of any kind if
you are tired or if you are under the
inuence of alcohol, drugs, or any other
substancethat could affect yourability
or judgement.
WARNING!
Minimize the Risk of Fire
NEVER smoke or light
fires near the trimmer or
brushcutter. ALWAYS stop the engine
and let it cool before refueling. Avoid
overlling and wipe off any fuel that
may have spilled. ALWAYS move
the unit to a place well away from
a fuel storage area or other readily
ammable materials before starting
the engine. NEVER place ammable
material close to the engine mufer.
General Safety
Instructions
Work Safely
Trimmers and brushcutters run at very
high speeds and can do serious damage
or injury if they are misused or abused.
Never allow a person without training or
instruction to operate your machine.
Stay Alert
You must be physically and mentally fit to
operate this machine safely.
Be Aware of the working Environment
Avoid long-term operation in very
hot or very cold weather. Make sure bystanders or observers
outside the 15 meters “danger zone”
wear eye protection.
Reduce the risk of bystanders
being struck by ying debris.
Make sure no one is within
15 meters- that’s about 16 paces-
of an operating attachment.
Always make sure the
Appropriate cutting attachment
shield is correctly installed.
Beware of a coasting blade when brushcutting.
A coasting blade can injure while it continues
to spin after the throttle trigger is released or
after the engine is stopped.
When operating in rocky terrian or near electric
wires or fences, use extreme caution to avoid
contacting such items with the cutting attachment.
Be constantly alert for objects and debris that could
be thrown either from the rotating cutting attachment
or bounced from a hard surface.
If contact is made with a hard object, stop the
engine and inspect the cutting attachment for
damage.
Be extremely careful
of slippery terrain,
especially during rainy
weather.

5
Product Descriptions
C300
Using the accompanying illustrations as a guide, familiarize yourself with your machine and its various components. Understanding your
machine helps ensure top performance, long service life, and safer operation.
T300
WARNING!
The engine exhaust from this
product contains chemicals
which may cause cancer, birth defects,
or other reproductive harm.
WARNING!
Do not make unauthorized
modications or alterations
to any of these units or their compo-
nents.
RECOIL STARTER
CHOKE LEVER
SPARK PLUG
FUEL TANK
FUEL CAP
CLEANER COVER
ON-OFF SWITCH
THROTTLE LEVER
FRONT HANDLE
OUTER TUBE
STRAP
CUTTING ATTACHMENT SHIELD
ON-OFF SWITCH
THROTTLE LEVER
HANDLEBAR
RECOIL STARTER
CHOKE LEVER
SPARK PLUG
FUEL TANK
FUEL CAP
CLEANER COVER
STRAP
OUTER TUBE
CUTTING ATTACHMENT SHIELD
8-TOOTH BLADE

6
T300/EC1 C300/EC1
S270EC
2-cycle, vertical cylinder, air cooled
6.0 kg 6.2 kg
34mm x 30mm
27.2 cm3
8,000 min-1 (rpm)
0.95 kW
3,000 min-1 (rpm)
11,500 min-1 (rpm)
50:1
650 cm3
TK, DPV1OW Diaphragm
Fully Electronic, transistor controlled
NGK BPMR6A
Semi-wet Type
Recoil Starter
Slide Switch
Loop Type Bicycle Type
1780 x 365 x 290mm 1790 x 575 x 470mm
92 dB (A) 91 dB (A)
106 dB (A)
3.4/2.3m/s22.7/3.3m/s2
4.5/6.9m/s24.0/3.7m/s2
98 dB (A)
109 dB (A)
3.2/2.2m/s22.7/2.3m/s2
7.2/7.5m/s25.0/3.2m/s2
* Sound Pressure Level: in accordance with EN ISO 11806 and ISO 7917 * Sound Power Level: in accordance with EN ISO 11806 and ISO 10884
* Vibration Level: in accordance with EN ISO 11806 and ISO 7916 Note 1: 8-tooth blade equipped Note 2: Trimmer head equipped
Technical Specications
Before assembling, make sure you have all
the components required for a complete
unit. This machine consists of the follow-
ing components and accessories. Carefully
inspect all components for damage. If you
find any damaged or missing items, ask
your Shindaiwa dealer for support.
IMPORTANT!
The terms “left,” “left-hand,” and “LH”,
“right,” “right-hand,” and “RH”; “front” and
“rear” refer to directions as viewed by the
operator during normal operation of this
product.
Prior to Assembly
Model Name.......................................................................................................................
Engine Model.........................................................................................................
Engine Type .......................................................................................................................
Dry Weight (Less Attachment) ........................................................................................
Bore x Stroke......................................................................................................................
Displacement......................................................................................................................
Engine Speed at Maximum Power Output......................................................................
Maximum Power Output ..................................................................................................
Engine Speed at Idling ......................................................................................................
Maximum Engine Speed...................................................................................................
Fuel/Oil Ratio.....................................................................................................................
Fuel Tank Capacity ............................................................................................................
Carburetor ..........................................................................................................................
Ignition System ..................................................................................................................
Spark Plug...........................................................................................................................
Air Cleaner..........................................................................................................................
Starting Method.................................................................................................................
Stopping Method................................................................................................................
Handle.................................................................................................................................
Dimensions.........................................................................................................................
Sound Pressure Level * (average data between at Idling and at Racing) note.1 ........................
Sound Power Level * (average data between at Idling and at Racing) note.1.............................
Vibration Level *, note.1........................................................................Idling 1eft/right
Vibration Level *, note.1......................................................................Racing 1eft/right
Sound Pressure Level * (average data between at Idling and at WOT) note.2 ..........................
Sound Power Level * (average data between at Idling and at WOT) note.2...............................
Vibration Level *, note.2........................................................................Idling 1eft/right
Vibration Level *, note.2........................................................................ WOT 1eft/right
T300
ENGINE ASSEMBLY
OUTER TUBE ASSEMBLY
DEBRIS SHIELD FRONT HANDLE STRAP BLADE COVER
TOOL SET
HEX WRENCH (M5)
HEX WRENCH (M6)
PLUG WRENCH
SPANNER WRENCH
C300
ENGINE ASSEMBLY
OUTER TUBE ASSEMBLY
DEBRIS SHIELD HANDLEBAR STRAP BLADE COVER
TOOL SET
HEX WRENCH (M5)
HEX WRENCH (M6)
PLUG WRENCH, BAND x 2
SPANNER WRENCH

7
Before Assembling
the Outer Tube
1. Using the hex wrench, loosen the
stopper bolt to the end.
2. Loosen the joint bolt. Do not lose the
shim washer.
Assembly of the
Outer Tube
T300
1. Slip the outer tube into the joint until
the tube bottoms. The outer tube or
gear case shaft may have to be rotated
slightly for the splines on the main
shaft to fully engage to the engine.
2. Place the D-shaped shim washer with
its flat side up in the gap of the joint.
Then, tighten the joint bolt securely
using the hex wrench.
3. Loosen the screw which tightens the
throttle lever to the outer tube. Shift the
throttle lever toward the blade.
4. Put the throttle cable into the tube.
Push throttle cable through hole in rear
grip.
5. Set the throttle cable onto the throttle
lever. Use the wrench so that the wire
edge goes into the slot of the throttle
lever securely.
NOTE:
Make sure that the throttle cable is built
into the cable guide of the throttle lever.
6. Shift the throttle lever back to original
position, pulling the earth cord and
throttle cable and tighten the screw
securely.
7. Remove the bolt tightening the cylinder
cover.
8. Put the bolt through the hole of the earth
cord terminal and tighten the bolt.
C300
1. Slip the outer tube into the joint until
the tube bottoms (up to the insert
label). The outer tube or gear case
shaft may have to be rotated slightly
for the splines on the main shaft to
fully engage to the engine.
2. Locate the outer tube so that the stop
per bolt can go into the stopper hole.
Using the hex wrench, tighten the
stopper bolt securely.
3. Place the D-shaped shim washer with
its flat side up in the gap of the joint.
Then, tighten the joint bolt securely
using the hex wrench.
CAUTION!
DO NOT REMOVE THE SHIM WASHER!
The shim washer prevents overtighten-
ing of the outer tube joint. Overtighten-
ing the outer tube joint could damage
the outer tube assembly.
4. Loosen the stopper bolt of the throttle
grip. Remove the stopper bolt and nut.
5. Fully loosen the clamp bolt of the
throttle grip.
6. Slip the right-side handlebar into the
throttle grip. Locate the throttle grip
so that the stopper bolt can pass
through the stopper hole. Securely
tighten the stopper bolt and nut.
7. Securely tighten the clamp bolt.
JOINT
STOPPER BOLT
JOINT BOLT
SHIM
WASHER
SCREW
NUT THROTTLE GRIP
STOPPER BOLT
CLAMP BOLT
STOPPER HOLE
HANDLEBAR
JOINT
STOPPER
BOLT JOINT
BOLT
SHIM WASHER
JOINT
SHIM WASHER
STOPPER
BOLT JOINT BOLT
STOPPER HOLE INSERT LABEL
OUTER TUBE

8
Assembly of the Handle
WARNING!
NEVER operate this machine
without the front handle.
Operating without the front handle may
result in serious injury.
NOTE:
Tighten four bolts diagonally to properly
secure the handle.
NOTE:
Adjust the handle at the best position for
operator comfort.
1. Put four square nuts in the recesses
on the underside of the barrier.
2. Fit the handle and barrier over the
outer pipe and tighten four bolts.
Throttle Cable
Adjustment
1. Pull the throttle trigger gently,
and check for free-play of
approximately 5mm.
2. If free-play is out of specifications:
(a) Slide the cable cap toward th
muffler side until the adjusting
nut and the lock nut appear.
(b) Loosen the lock nut slightly.
(c) Turn the adjusting nut so that
free-play is about 5mm.
(d) Then, tighten the lock nut.
(e) Slide the cable cap back.
C300
1. Loosen the two bolts of the lower cap
and remove the lower cap.
2. Position the handle bracket against the
handle label located on the outer tube.
3. Attach the lower cap with the two bolts
and tighten the bolts. Make sure the
front handle is in position per the
illustration.
4. Secure the cable to the outer pipe with
the two bands as the illustration shows.
The two bands are in the tool bag.
HANDLE
OUTER PIPE
BARRIER
BARRIER
BOLT
NUT
HANDLEBAR
THROTTLE GRIP
BOLT
LOWER CAP
HANDLE BRACKET
HANDLE LABEL
BAND
T300
FREE PLAY=5mm
FREE PLAY=5mm
C300
CABLE CAP
LOCK NUT
ADJUSTING NUT
T300

9
Debris Shield Assembly
WARNING!
NEVER operate this ma-
chine without the cutting
attachment shield. Operating without
the cutting attachment shield may
result in serious injury.
WARNING!
Carefully inspect the debris
shield assembly to make
sure it is tightened securely and does
not wobble.
Shield Extension (when trimmer
head is in use)
1. Attach the shield extension to the
cutting attachment shield.
NOTE:
Make sure the shield extension is completely
hooked at the hook receiver.
BOLT
UPPER
CLAMP
SPACER
BOLT
NUT LOWER CLAMP
OUTER TUBE
SPACER
CUTTING
ATTACHMENT
SHIELD
CUTTING ATTACHMENT SHIELD
HOOK
RECEIVER
HOOK
SHIELD EXTENTION
Cutting Attachment Shield
1. Insert the cutting attachment shield
between the outer tube and the lower
clamp. Loosen the nut and bolt which
are tightening the lower clamp if the
cutting attachment shield does not fit
with the lower clamp.
NOTE:
It may be necessary to loosen the lower
clamp bolt so that the shield will fit between
the tube and clamp.
2. Fit the two spacers and the upper clamp
over the outer pipe and tighten with
four bolts.
NOTE:
Tighten four bolts a crisscross fashion.
3. Tighten the lower clamp bolt and nut
securely.

10
Installing a Blade
1. Make sure the switch is off and the
engine is stopped.
2. Wear gloves to protect your hands.
3. Turn the unit over so the saw holder
flange extending from the gear case
is facing up.
4. Using the small end of the plug
wrench, loosen the bolt (turn clock
wise) and remove the bolt, bolt
guard, and holder B.
5. Slide the safety clip as shown in the
illustration.
WARNING!
Before operating, make sure
the blade is securely mounted.
Turn the blade with your hand slightly
and make sure the blade turns smoothly
without wobbling.
WARNING!
The blade must t at. Make
sure the direction of the arrow
indicated on the blade corresponds
with the arrow indicated on the cutting
attachment shield.
7. Put holder B and bolt guard back and
at this time only finger tighten the
bolt.
Make sure holder B is flat against the
blade and the recess in holder B must
face the blade and completely cover
the safety clip.
8. Rotate holder A until the hole in its
skirt aligns with the hole in the gear
case. Insert the hex wrench through
both holes (to prevent the shaft from
turning).
9. Holding the hex wrench and blade
with one hand, tighten the bolt (turn
counterclockwise) securely using the
small end of the plug wrench.
10. Remove the hex wrench.
WARNING!
Never operate this machine
without the safety clip in place.
6. Fit the blade over the safety clip onto
holder A. Then, slide the safety clip
back to its original position.
WARNING!
The blade must t at against
holderA.Theblade’smounting
hole must be centered over the raised
boss of holder A.
Filling the Fuel Tank
WARNING!
When adding fuel, make sure
the engine is stopped and
cooled-down. Filling or mixing fuel and
oil must be done away from any res or
other ignition sources.
CAUTION!
This engine is designed to operate only
ona 50:1mixtureconsistingof unleaded
gasoline and a premium 2-cycle mixing
oil. Use of non-approved mixing oils can
lead to excessive maintenance costs
and/or engine damage.
1. Turn the fuel cap counterclockwise and
take it off.
2. With the fuel cap hanging down from
the filler opening, fill the fuel tank with
fresh, clean fuel (mixture of fuel and oil)
and tighten the fuel cap securely.
3. If there is any fuel spilled on the
machine, make sure it is wiped off
completely.
BOLT
BOLT
GUARD
HOLDER B
SAFETY
CLIP
8-TOOTH
BLADE
HOLDER A
GEAR CASE
SAFETY CLIP SAFETY CLIP
HOLDER A
BLADE
HEX WRENCH
PLUG
WRENCH
HEX
WRENCH
