Shinhoo GPA-IV Series User manual

GPA-IV
Installation and
Operation Manual
Energy-saving Pipeline
Canned Motor Pump
Series

GPA-
01
01. Read the instal l a tion manual 11. Some models are not suitable for
carefully before installation and drinking water.
use. 12. The liquid may be high-temperature
02. The manufacturer will not be liable and high-pressure; therefore, the
for any personal injur y, p ump liqu i d in t h e sy s te m m us t be
d a m a g e a n d o t h e r p ro p e r t y completely drained or the shut-off
damage due to failure to comply valves o n bo th s i des must be
with contents specified in safety c l o s e d b e f o r e m o v i n g a n d
warning signs. dismantling the pump to prevent
burning.
03. The installers and operators must
comply with local safety regulations. 13. If removing the exhaust bolt, high-
temperature and high-pressure
04. The user must confirm that only liquid will be overflew. Therefore,
q u a l i f i e d p e r s o n n e l w i t h it is necessary to insure that the
profe s s ional cer t if ica tion and outf l o w l i q u i d w i l l n o t ca u s e
prof i c ienc y o f t h i s ma n u a l i s personal injur y or damage other
allowed to install and maintain this parts.
product.
14. Ventilation must be ensured in
05. The pump must not be installed in a s u m m e r o r h i g h a m b i e n t
pla c e th a t is damp or may b e t e m p e r ature period to avoid
splashed by water. condensation that may cause
electrical malfunctions.
06. For convenient access of maintaince,
a shut-off valve shall be installed on 15. In winter, the pump system does
each side of the pump not work or when the a m b ient
temperature drops below 0℃,
07. The power supply of the pump shall
liqu i d i n t h e s y ste m sh a l l b e
be cut off before installation and
completely drained so as to avoid
maintainace.
frost cracking of pump body.
08. For domestic hot water, copper or
16. If the pump is left unused for a long
stainless steel pump body shall be
time, please close the pipe valve in
used.
the inlet and outlet of the pump and
09. Heat supply pipelines shall not be cut off the power supply.
frequently filled with non-softened
17. If he flexibl e cord of cable ist
water so as to avoid increasing
damaged, it must be replaced by a
calcium in the circulating water
qualified person.
inside the pipeline, which may thus
block the impeller. 18. Please close the valve at the inlet of
the pump and cut off power of the
10. Do not start the pump without liquid.
pump immediately if overheating
Notes:
IV

02
and abnormality of motor is detected, and contact your vendor or service
center immediately.
19. If trouble cannot be addressed according to the manual, please close the valves on
the inlet and outlet of the pump immediately, cut off power supply and contact your
vendor or service center immediately.
20. This product shall be put in a place out of reach of children. After installation, take an
isolation measures to avoid access of children.
21. This product shall be stored in a dry, well ventilated and cool place under room
temperature.
22. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Warning
Before installation, you must carefully read the installation
and operation manual. The installation and use of the
equipment must comply with local re g ulation and
applicable operation standards.
Warning
Those who have weak physical strength, react slowly
orlack experience and knowledge (including children) can
use this motor pump only under the monitoring and
direction of his/her safety personnel.
Caution
Note
1. Signs
Caution
Note
Warning
Failure to comply with this safety instruction may lead to
personal injury!
Failure to comply with this safety instruction may lead to
equipment malfunction or damage!
1. Signs
Note or instruction for easy and safe operations.
GPA-IV

2. General
2.1. GPA-Ⅳ series
circulation motor pump
is mainly u s e d i n
d o m e s t i c heating
and hot water system.
The product is most applicable to
the following systems:
·Stable and variable-flow heat
supply system
·Variable-temperature pipeline
heat supply system
·HVAC system
· Industrial circulation system
·Domestic heating and
domestic water supply system
T h i s p u m p i s e q u i p p e d
w i t h p er m an e n t - m a g n e t
m o t o r a n d differential pressure
controller, capable of
automat i c ally & c o n t i n u o u s l y
adjusting motor performance to
meet the actual needs of system.
This pump is equipped with
control panel on the front for easy
operation by users.
2.2. Advantages
Easy installation and start-up
· Provided with self-adaptive
mode AUTO
(Initial setting). In most cases,
the motor pump needs no
adjustment and can be readily
started and automatically
adjusted to meet the actual
needs of the systems.
High-degree comfort
·Low operational noise of
motor pump and whole system.
Low energy consumption
·Co m p a r e d w i t h
t r a d i t i o n a l circulation motor
pumps, it has lower energy
consumption. GPA series
circulation motor pump is
attached with Europe Energy
Label Class A marking, and the
minimum energy consumption
can reach up to 10W.
03
GPA-IV

04
3.1. Ambient Temperature
Ambient temperature: 0 ℃～ +40 ℃
3.2. Relative humidity（RH）:
Max. humidity: 95%
3.3. Medium (liquid delivery) temperature
Liquid delivery temperature: +2 ℃～ 110 ℃
To avoid condensation in control box and the stator, the temperature of liquid
pumped by the motor pump must be always higher than ambient temperature.
3.4. System Pressure
Maximum pressure 1.0Mpa(10bar).
3.5. Degree of Protection
IP42
3.6. Inlet Pressure
Liquid Temperature
<85℃90℃110℃
Inlet Pressure
0.05bar 0.28bar 1bar
0.5m head 2.8m head
3.7. Pumping Liquid
The pumping liquid includes thin, clean, non-corrosive and non-explosive
liquid which shall not contain any solid particles, fiber or mineral oil, and the
pump must definitely not be used to pump inflammable liquid such as rapeseed
oil and gasoline. If the pump is used in a place with relatively high v is co si t y,
th e p u mp h a s lo w e r performance. So when choosing a pump, the viscosity
of liquid must be taken into account.
3. Operating Conditions
10m head
GPA-IV

05
4. Installation
4.1Installation
· When installing GPA -Ⅳseries circulating pump, the arrow on motor pump case
indicates the flow direction of liquid through the pump.
· When installing the motor pump in the p ip eline, two supplied gaskets must
be installed at the inlet and outlet.
· During the installation, the shaft of motor pump must be horizontal.
GPA-IV

4.2Position of Junction Box
4.3Changing Position of Junction Box
The junction box can be rotated in a step of 45°
The procedure for changing the position of junction box are as follows:
1.Close the valves at the inlet and outlet and release the pressure;
2.Unscrew and remove the four socket head screws that fasten the pump body;
3.Rotate the motor to the expected position and align the four screw holes;
4.Install the four socket head screws again and fasten them clockwise;
5.Open the valves at the inlet and outlet.
06
GPA-IV

Warning
Pumping liquid may be high-temperature and high-pressure; therefore,
the liq u i d i n t h e s y s t e m mu st be completely drained or the valves
on both sides of motor pump must be closed before removing the socket
head screws.
When changing the position of junction box, the motor pumpcan be
started only after the system is filled with pumping liquid or the valves
on both sides of motor pump are opened.
Catution
4.4Thermal Insulation of Motor Pump Body
Limiting the heat loss of motor Pump body and pipeline.
Mo t or p u mp b ody a nd p ipel i ne s hould be ther m ally insulated to
reduc e the irheat loss.
Do not isolate or cover the junction box and control panel.
Caution
Note
07
GPA-IV

08
5. Electrical Connection
GPA-IV

Electrical connection and protection shall comply with local codes and norms.
Warning
The motor pump must be earthed
The motor pump must be connected to an external power switch,
and the minimum space between all the electrodes is 3mm.
·GPA -Ⅳseries circulating motor pump needs no protection from external motor.
·Check if the supply voltage and frequency are the same as parameters indicated
on the nameplate of the motor pump.
·Connect the motor pump and power supply with the plug supplied together with
the pump.
·After the power is supplied, the indicator lamp on the control panel is ON.
09
GPA-IV

6.1Controls on Control Panel
Position
1
2
3
Descriptions
Flow during runtime
Speed reduce button
L i g h t i n g a r e a i n d i c a t i n g
f o u r o p e r a t i n g m o d e
Setting button showing pump
operating mode
Speed increase button
Lighting area display showing
the speed
6.2Troubleshooting
Wi t h po wer o n, p osit i on 6 lig h ting
area indicating the situation : Operating,
speed area display in g light are always
lit; with flashing lights indicating the pump
p r o bl e m, c or r es p o n d i ng f a u lt are as
follows:
If malfunction is detected, the power
supply must be cut off before trouble-shooting.
After the trouble is addressed, re-connect
the power and start the motor pump.
Fault Code
Speed 1 flashing
Speed 2 flashing
Speed 3 flashing
Speed 4 flashing
Speed 5 flashing
Speed 6 flashing
Speed 7 flashing
Description
Over-voltage protection
Under-voltage protection
Over-current protection
Missing phase protection
Locked-rotor protection
Under-load protection
Motor start failure protection
(Motor paramaters do not match)
6.3Indication Lamp Area of Motor Pump Setting
GPA -Ⅳseries circulation pumps have 28 kinds of settings, pressing the
button to choose.
13 different light area indicating all the settings;
10
6. Control Panel
4
5
6
GPA-IV

Times to press the button
0
1
2
3
Lighting area
AUTO(factory reset)
BL(1-9)
HD(1-9)
HS(1-9)
Description
Autoadaptation
Proportional pressure curve
Constant pressure curve
Constant speed curve
6.4Button for selecting motor pump settings
By pressing the button once at 2 seconds interval, the motor pump setting
mode will change once.
A cycle is cons ti tuted of every four presses o n th e button. For details,
please refer to Section 6.3.
7.Motor Pump Setting
7.1 Motor Pump Setting Based on System Type
Initial setting= AUTO (Self-adaptive mode)
Recommended and available motor pump setting
Position System Type
A
B
C
Floor heating system
Dual pipeline heating system
Single pipeline heating system
M o t o r P u m p S e t t i n g
AUTO
AUTO
BL1
Recommended Options
HD 1-9 )
BL (1-9)
B L (1-9)
(
11
GPA-IV

·AUTO (Self Adaptive Mode) mode can adju s t th e pe rfor m ance of m otor
pump based on the actual heat demand of the system. As th e p erformanc e
is adjusted gradually, it is suggested, before changing motor pump setting,
to maintain AUTO (Automatically Adapt iv e Mode) mode setting for at lea st
one week.
·If you select to change back to AUTO (Se l f Ad apti v e M o d e ) m o d e , t h e
GPA series motor pump can memorize i t s l a s t s e t ting in AUTO m ode and
continue adjusting the performance automatically.
·It may take several minutes or even hours to re a ch t he o p tima l op e ration
mode after motor pump setting is changed from t h e o p t i m a l s e t t i n g ( t h e
“Recom m e n d e d a b o v e m e n t i o n ” ) t o o t h e r o p t i o n a l s e t t i n g . I f t h e
opt i m a l s e t t i n g o f m o t o r pu m p f a il s t o enable e a c h r o o m t o o b t a i n
d e s i r e d h e a t d i s t r i b u t i o n , t h e n y o u s h o u l d change the motor pu m p
s e t ti n g t o other settings
·Please refer to Section 12.1 for the relations between motor pump setting
and performance curve.
7.2 Control of Motor Pump
When the motor pump is working, the motor pump is controlled according to
the prin c i p l e o f “ P r o p o rtional Pre s s u r e C o n t r o l ( BL)” or “Const ant
Pressure Control (HD)”.
In these two control modes, the motor pump performance and c orre s ponding
power consumption will be regulated according to t he h eat demand of the
system.
Proportional Pressure Control
In this control mode, the differential pressure of both ends of the motor pump
will be controlled by the flow rate. In the Q/H Figure, propor tion a l pr essure
curve is represented with BL(1-9). Please refer to Section 11.3.
Constant Pressure Control
In this control mode, the differenti a l p r e s s u r e o f b o th ends of the mot o r
pump remains cons t ant and i s ir relevant to the flow rate. In the Q/H Figure,
constant pressure curve is a horizontal performance curve represented with
HD1(1-9). Please refer to Section 11.3.
：
12
GPA-IV

8.Bypass valve system installed between
the Inlet pipeline and return pipeline
8.1Purposes of bypass valve
13
Bypass valve
The purpose of bypas s v a l v e : w h e n a l l t he v a l v e s a n d / or t emperature -
sensing valves of heat radiator in the fl oo r heating l o o p a r e c l osed, it can
ensure that the heat from boiler can be distributed.
Elements in the system:
bypass valve
flow meter, position L.
GPA-IV

8.2Manually-operated Bypass Valve
1、Adjust the by-pass valve, pump should be set on HS1 ( Constant speed I)
The minimum flow rate（ Q min） of the sys tem shall be always guar anteed.
Please refer to bypass valve manual provided by the manufacturer.
2、After the regulating of bypass valve completes, set the pump in accordance
with Section 10.1 of Pump Setting.
8.3 Automatic Bypass Valve (temperature-sensing type)
Follow the following procedures:
1、Adjust the by-pass valve, pump should be set on HS1 ( Constant speed I)
The minimum flow rate（ Q min） of the system sh all be alwa ys guaranteed.
Please refer to bypass valve manual provided by the manufacturer.
2、After the regulating of bypass valve completes, set the pump to lowest or
highest constant pressure mode. For the relations between pump setting and
performance curve, please refer to Section 10.1 of Pump Setting and Pump
Performance.
In accordance with the following procedures
9.Start up
9.1Before Start Up
Before starting the motor pump, ensure that the system is filled with liquid,
air has been completely exhausted, and the inlet of motor pump mu st r each
minimum inlet pressure. Please refer to Chapter 3.
9.2 Exhaust the Motor Pump
GPA -Ⅳseries motor pump is e q u i p p e d
w i t h s e l f - v e n t i n g function. Before the
start up, it is not necessary to vent the air.
Air in the m o t o r p u m p m a y c ause noise.
After the motor pump is put into operation
for several m i n u t e s , t h e n o i s e
w i l l disappear.
B a s e d o n t h e s y s t e m s c a l e a n d
structure, set the GPA series motor p u m p
t o Hs 9 ( Constant speed 9) f o r a short
period of time and air in the pump can be
quickly vented.
14
When all valves are closed, the minimum flow r a t e m u s t b e g u a r a n t e e d.
The setting of pump p o s it i on d ep e n d s on t h e ty p e o f b y p a s s v a l v e , i . e.
manual bypass valve or temperature-sensing bypass valve.
After air is vented from the mo t or pump and noise disappear, set the
motor pump in accordance with the manual. Please refer to Chapter 7.
Motor pump cannot run in idle speed without pumping liquid.
Caution
GPA-IV

9.3Vent the heating system
10.Motor Pump Setting and Performance
10.1Relations between Motor Pump Setting and Performance
15
Note:The red curre sta nds for constant speed gear (fr om 1 to 9),t he s hadow area
of blue one is automatic gear,the green one is ratio gear (from 1 to 9),and the yellow
one is constant pressure gear (from 1 to 9)
GPA-IV

Setting
BL（1-9）
HD（1-9）
HS（1-9）
Q（0-100%）
Pump Characteristics
Curve
Functions
AUTO function will automatically control the pump
performance within the specified scope.
·adjust pump performance based on system scale;
·adjust pump performance based on load variance
within a period of time;
U n d er t h e AU T O mo d e, t he p u m p w i l l b e s e t t o
proportional pressure control;
AUTO
（Initial
Setting）
The operating point of the pump will move up and down on
the lowe s t p r o p o r t i o n al pressure cur v e ba s ed o n t h e
demand of system flow rate. When flow demand decreases,
the pressure supply of pump drops ; w h e n f l o w d e m a n d
increases, the pressure supply of pump rises.
The operation point of the pump will move around the
constant pressure curve based on the dema n d of
system flow rate. The head (pressure) is kept constant,
regardless of the flow request..
It runs on the constant curve in a constant velocity.
Under the Velocity HS(1-9) mode, the pump is set
to work on the hi g h e s t c u r v e u n d er al l w o r k i n g
conditions. Set under HS9 m o d e i n a s h o r t t i m e,
fast venting can be arranged on the pump.
Indicating the flow percentage when pump is running
Highest to
Lowest
Proportional
Pressure Curve
Proportional
Pressure Curve
Constant
Pressure Curve
Constant
speed curve
Flow display
11.Performance Curve
11.1Guide on Performance Curve
Every setting of the motor pump has corresponding performance curve
(Q/H curve). However A UTO ( S e l f A d aptive Mode ) m o d e c o v e r s j u s t o ne
performance scope.
The input power curve (P1 curve) belongs to every Q/H curve . Po wer
curve represents the power consumption of motor pump in g i ven Q/H c urve
with Watt as the unit.
11.2Curve conditions
The followings are applicable to the performance curve specified in the
GPA Ⅳseries manual:
·Test liquid: air-free water.
·Applicable density of curve ρ=983.2 kg/m3, and liquid temperature +60℃.
·All curves represent averaged value, and shall not be used as guarantee
curve. If a specific performance is needed, then separate measuring shall be
conducted.
·The applicable Kinetic viscosity of the curve υ=0.474 mm2/s（0.474CcST）
11.3Performance Curve GPA -Ⅳ Series
16
GPA-IV

·Constant speed & AUTO mode performance curve
17
GPAXX-6 Ⅳ Performance Chart(Constant Speed+auto Mode)
GPAXX-8 Ⅳ Performance Chart(Constant Speed+auto Mode)
GPAXX-10 Ⅳ Performance Chart(Constant Speed+auto Mode)
GPA-IV

·Constant pressure mode performance curve
GPAXX-6 Ⅳ Performance Chart(Constant Pressure)
GPAXX-8 Ⅳ Performance Chart(Constant Pressure)
GPAXX-10 Ⅳ Performance Chart(Constant Pressure)
18
GPA-IV

·Proportional pressure performance curve
GPAXX-6 Ⅳ Performance Chart(Bl Mode)
GPAXX-8 Ⅳ Performance Chart(Bl Mode)
GPAXX-10 Ⅳ Performance Chart(Bl Mode)
19
GPA-IV
