Ingersoll-Rand ARO EVO Series User manual

RELEASED: 1-28-22
REVISED: 9-30-22
(REV: B)
INGERSOLL RAND COMPANY INC
209 NORTH MAIN STREET – BRYAN, OHIO 43506
[phone] FAX [phone] © 2022
arozone.com
OPERATOR’S MANUAL EP20-XXXXX-XXX-XXX
INCLUDING: OPERATION, INSTALLATION AND MAINTENANCE
2” EVO SERIESELECTRIC DIAPHRAGM PUMP
(METALLIC FLUID SECTIONS)

Page 2 of 44 EP20-XXXXX-XXX-XXX (en)
TABLE OF CONTENTS
1. TECHNICAL SPECIFICATIONS ................... 3
1.1. Pump Data............................... 3
1.2. Variable Frequency Drive (VFD) Data ...... 3
1.2. Variable Frequency Drive (VFD) Data ...... 4
1.3. Electric Motor Data....................... 5
1.4. Nameplate Details........................ 6
1.4.1 Standard Nameplate ................ 6
1.4.2 Hazardous Nameplate ............... 6
2. MODEL DESCRIPTION CHART. . . . . . . . . . . . . . . . . . . 7
2.1. Model Code Explanation. . . . . . . . . . . . . . . . . . 7
2.2. Encoder Cable Assembly for
Ordinary Motors.............................. 7
3. OPERATING AND SAFETY PRECAUTIONS ........ 8
4. GENERAL DESCRIPTION ........................ 9
4.1. Introduction ............................. 9
4.2. Storage .................................. 9
4.3. Unpacking ............................... 9
5. MECHANICAL INSTALLATION ................... 10
5.1. Pump and Motor Installation ............. 10
5.2. Pump and Gearbox Breather Installation .. 10
5.3. VFD Mechanical installation. . . . . . . . . . . . . . . 11
6. ELECTRICAL INSTALLATION FOR
ORDINARY LOCATIONS......................... 12
6.1. VFD-Wiring Diagram...................... 12
6.2. General Wiring Practice for VFD ........... 12
6.3. VFD AC Mains – Input Power
Requirements: ........................... 13
6.4. Power Wiring............................. 13
6.4.1 VFD - Input Power Wiring ............ 13
6.4.2. VFD - Output Motor Wiring .......... 13
6.4.3. Motor - Input Power Wiring.......... 14
6.5. Control Wiring (Required)................. 15
6.5.1. Leak detector wiring diagram ....... 15
6.5.2. Thermal protection – Ordinary motor 16
6.5.3. Encoder Wiring – Ordinary Motor.... 16
6.6. Control Wiring (Recommended) .......... 17
6.6.1. Safe Stop wiring diagram............ 17
6.7. Control Wiring (Optional) ................. 17
6.7.1. Digital start/ stop control............ 17
6.7.2. Analog Input – Speed control ....... 18
6.7.3. Analog Inputs – Torque (Pressure)
Control................................... 18
6.7.4. Additional available
Input/output (Optional) ............. 19
6.8. Congured Input / Output
Summary - Ordinary...................... 19
6.9. VFD serial communication ................ 19
6.10. User dened readout.................... 20
7. ELECTRICAL INSTALLATION FOR
HAZARDOUS LOCATIONS ...................... 21
7.1. General Wiring ........................... 21
7.2. Power Wiring............................. 21
7.3. Control Wiring (Required)................. 21
7.3.1 Leak Detector Wiring ................ 21
7.3.2 Thermal Protection -
Hazardous Motor ................... 22
7.3.3 Encoder Wiring - Hazardous Motor ... 23
7.4. Control Wiring (Optional) ................. 23
7.5. Congured Input/Output
Summary - Hazardous .................... 23
7.6. VFD Serial Communication - Hazardous ... 23
8. GROUNDING .................................. 24
8.1. Pump Grounding......................... 24
8.2. VFD Grounding........................... 24
8.3. Electric Motor Grounding................. 24
9. OPERATION.................................... 25
9.1. Pre Operation Checklist................... 25
9.2. Personal Menu Settings .................. 25
9.3. VFD Smart Setup ......................... 26
10. MAINTENANCE ............................... 27
10.1. Service Kits ............................. 27
11. SUBSYSTEM OVERVIEW ....................... 28
11.1. Fluid section ............................ 28
11.2. PRV section ............................. 31
11.3. Crankcase section ....................... 33
11.4. Oil Piston pump section ................. 36
12. TROUBLESHOOTING .......................... 38
12.1 Reset VFD to Factory Default Settings .... 38
13. DIMENSIONAL DATA .......................... 39
13.1 Pump With Motor........................ 39
13.2. Variable Frequency Drive (VFD) .......... 40
14. PERFORMANCE CURVE. . . . . . . . . . . . . . . . . . . . . . . . 42
15. CERTIFICATION ............................... 43
15.1 Certication Standards and Markings .... 43
15.2 Specic Conditions of Use ............... 43
16. WARRANTY DECLARATION .................... 44

EP20-XXXXX-XXX-XXX (en) Page 3 of 44
1. TECHNICAL SPECIFICATIONS
Models...... See Model Description Chart for “-XXXXX”.
Pump Type.. Electric Diaphragm Pump
Material .... See Model Description Chart
Weight (without motor)
EP20-CXXXX-XXX-XXA............477 lbs (216 kg)
EP20-AXXXX-XXX-XXA............376 lbs (171 kg)
EP20-SXXXX-XXX-XXA ............517 lbs (235 kg)
Maximum Material
Inlet Pressure................... 60 psig (4.14 bar)
Minimum Outlet Pressure
@ Deadhead ......................
120 psig (8.3 bar)
Maximum Outlet Working
Pressure .......................... 180 psig (12.4 bar)
Maximum Flow Rate (ooded inlet) .... 140 gpm (530 lpm)
Displacement / Cycle @ 80 psig ...0.66 gal. (3 lit.)
Maximum Particle Size ...........1/4”dia. (6.4 mm)
Wet Suction Lift................... 30 ft (9.1 m)
Dry Suction Lift ...................18 ft (5.4 m)
Maximum Temperature Limits
Min Max Min Max
Ambient Temperature

0 F 104

F -18 C 40 C
Fluid Temperature
32 F 212

F 0 C 100 C
Fluid temperature should be further limited of one of the following
materials of construction is used in the wetted sections:
PTFE
40 F 212

F 4 C 100 C
WARNING
Maximum fluid temperature of 100°C should
never be exceeded to maintain hazardous area surface tempera-
ture nameplate rating.
Dimensional Data......See page 39
Mounting Dimension ..3 Equally placed
∅0.63”(∅16 mm) x
0.94" (24 mm) hole on
∅29.8”(∅ 758 mm) B.C.
1.1. Pump Data
Noise Emission Values in accordance with ISO 4871
Pump conguration EP20-AFAAA-CSV-ACA
(Santoprene
® Balls / Seats)
EP20-SFSST-CSV-ACA
(SST Balls / Seats)
Sound Power
42 hz (99 rpm) @ 100 psig 78.9 dB(A) 96.3 dB(A)
84 hz (198rpm) @ 60 psig 88.5 dB(A) 101.2 dB(A)
Sound Pressure
42 hz (99 rpm) @ 100 psig 68.8 dB(A) 86.1 dB(A)
84 hz (198rpm) @ 60 psig 78.4 dB(A) 91.0 dB(A)
1.2. Variable Frequency Drive (VFD) Data
Ordinary Hazardous
Part Number 136Z7170 136Z7171
Power 7.5 kw 7.5 kw
Input Voltage 380-500 VAC +/-10%, 3 Phase, 50/60 Hz 380-500 VAC +/-10%, 3 Phase, 50/60 Hz
Frame Size A5 A5
Ingress Protection NEMA 4X / IP66 NEMA 4X / IP66
Option A Slot N/A - Available for Fieldbus Card Options MCB 112 PTC THERMISTER CARD
Option B Slot MCB 102 ENCODER CARD MCB 102 ENCODER CARD
Eciency 97% 97%
Approximate Weight 31.5 lbs (14.3 kg) 31.5 lbs (14.3 kg)
Operating Temperature (Full Scale) 32° to 113°F (0 to 45C) 32° to 113°F (0 to 45C)
Operating Temperature (Derate)

14° to 122°F (-10 to 50C) 14° to 122°F (-10 to 50C)
Max Altitude (Without Derating) 3280.8 ft (1000 m) 3280.8 ft (1000 m)
Max Altitude (With Derating) 9842.5 ft (3000 m) 9842.5 ft (3000 m)
Continuous Output Current (380 - 440 V) 16 A 16 A
Intermittent Output Current (380 - 440 V) 25.6 A 25.6 A
Continuous Output Current (441 - 500 V) 14.5 A 14.5 A
Intermittent Output Current (441 - 500 V) 23.2 A 23.2 A
Continuous Input Current (380 - 440 V) 14.4 A 14.4 A
Intermittent Input Current (380 - 440 V) 23.0 A 23.0 A
Continuous Input Current (441 - 500 V) 13.0 A 13.0 A
Intermittent Input Current (441 - 500 V) 20.8 A 20.8 A
Do not allow uids to freeze inside of pump.
When using inlet pressures higher than 10 psig (0.69 bar), the motor torque limit (VFD parameter 416) should be lowered to ensure the pump operates within the published operating map (see
Section 14). The rule of thumb is that the inlet pressure (psig) plus the motor torque limit setting (VFD parameter 416 in %) should equal 115 or less. The formula for this is therefore: [Motor Torque
Limit in %] = [115] – [Inlet Pressure in psig]. For example, an inlet pressure of 40 psig (2.76 bar) requires a motor torque limit of 75% (115 – 40 psig).
Values are determined according to noise test code ISO 20361 using ISO noise measurement standards. Measurement locations of 1m taken at pump/driver midline as per B.3.1 and 6.2 as dened
in standard. Calculated A-weighted sound pressure level using half-spherical surface. Published using uncertainty value of 3.
The 0° to -10° C derating of the VFD is due to the limitation in visibility of the liquid crystal display (LCD). The VFD is capable of operating in temperatures as low as -18° C if running in
"auto on" mode (serial or analog control) and not dependent on the keypad for pump running status or control.

Page 4 of 44 EP20-XXXXX-XXX-XXX (en)
1.2. Variable Frequency Drive (VFD) Data
Ordinary Hazardous
Part Number 132L0263 132L0262
Power 7.5 kw 7.5 kw
Input Voltage 200-240 VAC +/- 10%, 3 Phase, 50/60 Hz 200-240 VAC +/- 10%, 3 Phase, 50/60 Hz
Frame Size B1 B1
Ingress Protection NEMA 4X / IP66 NEMA 4X / IP66
Option A Slot N/A - Available for Fieldbus Card Options MCB 112 PTC THERMISTER CARD
Option B Slot MCB 102 ENCODER CARD MCB 102 ENCODER CARD
Eciency 96% 96%
Approximate Weight 50.7 lbs (23 kg) 50.7 lbs (23 kg)
Operating Temperature (Full Scale) 32° to 113°F (0° to 45°C) 32° to 113°F (0° to 45°C)
Operating Temperature (Derate)

14° to 122°F (-10° to 50°C) 14° to 122°F (-10° to 50°C)
Max Altitude (Without Derating) 3280.8 ft (1000 m) 3280.8 ft (1000 m)
Max Altitude (With Derating) 9842.5 ft (3000 m) 9842.5 ft (3000 m)
Continuous Output Current (200-240V) 30.8 A 30.8 A
Intermittent Output Current (200-240V) 49.3 A 49.3 A
Continuous Input Current (200-240V) 28.0 A 28.0 A
Intermittent Input Current (200-240V) 44.8 A 44.8 A
Ordinary Hazardous
Part Number 132X6019 132X6020
Power 7.5 kw 7.5 kw
Input Voltage 525-600 VAC +/- 10%, 3 Phase, 50/60 Hz 525-600 VAC +/- 10%, 3 Phase, 50/60 Hz
Frame Size A5 A5
Ingress Protection NEMA 4X / IP66 NEMA 4X / IP66
Option A Slot N/A - Available for Fieldbus Card Options MCB 112 PTC THERMISTER CARD
Option B Slot MCB 102 ENCODER CARD MCB 102 ENCODER CARD
Eciency 97% 97%
Approximate Weight 31.5 lbs (14.3 kg) 31.5 lbs (14.3 kg)
Operating Temperature (Full Scale) 32° to 113°F (0° to 45°C) 32° to 113°F (0° to 45°C)
Operating Temperature (Derate)

14° to 122°F (-10° to 50°C) 14° to 122°F (-10° to 50°C)
Max Altitude (Without Derating) 3280.8 ft (1000 m) 3280.8 ft (1000 m)
Max Altitude (With Derating) 9842.5 ft (3000 m) 9842.5 ft (3000 m)
Continuous Output Current (525-550V) 11.5 A 11.5 A
Intermittent Output Current (525-550V) 18.4 A 18.4 A
Continuous Output Current (551-600V) 11.0 A 11.0 A
Intermittent Output Current (551-600V) 17.6 A 17.6 A
Continuous Input Current (525-600V) 10.4 A 10.4 A
Intermittent Input Current (525-600V) 16.6 A 16.6 A
For more details, refer to the VFD manual PN 97999-1940.
The 0° to -10° C derating of the VFD is due to the limitation in visibility of the liquid crystal display (LCD). The VFD is capable of operating in temperatures as low as -18° C if running in
"auto on" mode (serial or analog control) and not dependent on the keypad for pump running status or control.

EP20-XXXXX-XXX-XXX (en) Page 5 of 44
1.3. Electric Motor Data
ORDINARY HAZARDOUS
Part Number 67559 67560-3
Rated Power 5.5 kw 5.5 kw
Rated Torque 36 Nm 36 Nm
Eciency IE3 IE3
Number Of Phases 3 3
Polarity 4P 4P
Voltage 230 VD / 400 VY 230 VD / 400 VY
Frequency 50 Hz 50 Hz
Index Of Protection IP66 IP66
Insulation Class F F
Encoder Type Incremental Incremental
Encoder Characteristics 5V, RS422 (TTL), 1024 PTS 5V, RS422 (TTL), 1024 PTS - IP66 / 67
Encoder Connection 12 Pin connector 10 m cable - ying leads
Drain Plug Position Drive end with plug N/A
Thermal Protection 2 Pto sensors in series 3 Ptc sensors in series
Approx. Weight 236 lbs (107 kg) 304 lbs (138 Kg)
Exact Ratio 12.7 12.7
Output Shaft Spline Spline
Lubricant Type PAO ISO VG 150 PAO ISO VG 150
Lubricant Qty 4.5 Liters (pre-lled) 4.8 Liters (pre-lled) + 1 Liter Container
Main Cable Gland Type 2 x m25 + 1 x m16 with plugs 1 x m25 + 1 x m20 with plugs
Lifting Point 4 x Lifting eye - Casted 4 x Threaded holes - 3 x Lifting eye tted
ORDINAR
Y LOCATION MOTOR
(Black)
HAZARDOUS LOCATION MOTO
R
(Red)
Figure 1

Page 6 of 44 EP20-XXXXX-XXX-XXX (en)
1.4. Nameplate Details
Items supplied vary according to product conguration.
Make sure that the items supplied and the information on the nameplate correspond to the order conrmation.
1.4.1 Standard Nameplate
ARO EVO SERIES
psig bar psig
bar
PUMP MODEL

SERIAL NO.

AVG W.P.

ASSEMBLED IN

MFGR DATE

MAX W.P.

AMBIENT TEMP

arozone.com
US: Bryan, OH 43506
EU: Lakeview Dr. IE Swords
98179
USA
-18°C TO 40°C
1.4.2 Hazardous Nameplate
PUMP MODEL

SERIAL NO.

INPUT POWER

Tamb

209. N Main Street, Bryan, OH 43506
98229
CLASS 1 ZONE 1AEx db IIB T4 Gb
ZONE 21AEx tb IIIC T135°C Db
CLASS I DIV 2 GROUPS C-D T4
CLASS II DIV 2 GROUPS F-GT135°C
0123
II 2G Ex h IIB T4 Gb
II 2D Ex h IIIC T135°C Db
TPSATEX 22 XXXXX XXXX X
Ex 60079-46 IIB T4 Gb
Ex 60079-46 IIIC T135°C
Ex h IIB T4 Gb
Ex h IIIC T135°C
IECEx TPS 22.00XX X
-18°C TO +40°C
NRTL
Approval
Pending
Denitions
1. Pump Model - Congured Pump Model Number
2. Assembled In - Country of Assembly
3. Serial Number - Serial Identication Number
4. MGFR Date - Date of Manufacture
5. AVG W.P - Average Pump Working Pressure (Occurs at or near deadhead)
6. Max W.P. - Maximum Pump Working Pressure
7. Ambient Temp - Allowable Ambient Temperature Range
8. Input Power - Allowable input power for VFD
Viton® is a registered trademarks of the Chemours Company Loctite® is a registered trademark of Henkel Corporation 
Santoprene® is a registered trademark of Celanese ARO® is a registered trademark of Ingersoll-Rand Company 

EP20-XXXXX-XXX-XXX (en) Page 7 of 44
2. MODEL DESCRIPTION CHART
2.1. Model Code Explanation
EP - 20 XX
Wetted Parts
A -
Port
F - ANSI / DIN Hybrid Flange
Ball
Diaphragms
Bellows
V - Viton®
NOTICE: All possible options are shown in the chart, however, certain combinations may not be recommended.
Consult a representative or the factory if you have questions concerning availability.
Special Testing
Pumps requiring special tests will have a separate line item on the Purchase Order
S - Stainless Steel
0 - No Motor
A - Ordinary Location Motor
B - Hazardous Location Motor (IECEx, ATEX, NEC, CEC)
Motor
A - Santoprene®
A - Santoprene®
XXX- XXXXXXX
0 - None
A - 200 - 240V, 50/60 Hz, Ordinary Drive
C - 380 - 500V, 50/60 Hz, Ordinary Drive
D - 380 - 500V, 50/60 Hz, Hazardous Drive
E - 525 - 600V, 50/60 Hz, Ordinary Drive
F - 525 - 600V, 50/60 Hz, Hazardous Drive
VFD Options
A - Revision
Revision
-
C -Cast Iron
Aluminum
Seat
A - Santoprene®
Pump Crank case
C - Cast Iron
S - Integrated Spline Shaft
Pump Input Shaft
F - Aluminum
H - 440 SST
S - 316 SST
S - 316 SST
T - PTFE
T - PTFE
200 - 240V, 50/60 Hz, Hazardous DriveB -
2.2. Encoder Cable Assembly for Ordinary Motors
Each pump with an ordinary location motor comes with a 9 meter encoder cable assembly. Alternate encoder cable assembly
lengths are available through aftermarket.
This shielded cable assembly connects to the 12-pin encoder connector on the motor and the MCB 102 encoder card in the
VFD. For installation instructions, see section 6.5.3.
Part Number (PN) Description Availability
67561-003 Ordinary Motor Encoder Cable Assembly (3 m) Aftermarket
67561-006 Ordinary Motor Encoder Cable Assembly (6 m) Aftermarket
67561-009 Ordinary Motor Encoder Cable Assembly (9 m) Standard - Included with each ordinary location pump
67561-015 Ordinary Motor Encoder Cable Assembly (15 m) Aftermarket
67561-050 Ordinary Motor Encoder Cable Assembly (50 m) Aftermarket
67561-100 Ordinary Motor Encoder Cable Assembly (100 m) Aftermarket

Page 8 of 44 EP20-XXXXX-XXX-XXX (en)
3. OPERATING AND SAFETY PRECAUTIONS
READ, UNDERSTAND, AND FOLLOW THIS INFORMATION TO AVOID INJURY AND PROPERTY DAMAGE.
EXCESSIVE FLUID PRESSURE
STATIC SPARK
HAZARDOUS MATERIALS
HAZARDOUS PRESSURE
WARNING
STATIC SPARK. Can cause explosion re-
sulting in severe injury or death. Ground pump and
pumping system.
Sparks can ignite ammable material and vapors.
The pumping system and object being sprayed must
be grounded when it is pumping, ushing, recirculat-
ing or spraying flammable materials such as paints,
solvents, lacquers, etc. or used in a location where
surrounding atmosphere is conducive to spontaneous
combustion. Ground the dispensing valve or device,
containers, hoses and any object to which material is
being pumped.
Secure pump, connections and all contact points to
avoid vibration and generation of contact or static
spark.
Consult local building codes and electrical codes for
specic grounding requirements.
After grounding, periodically verify continuity of
electrical path to ground. Test with an ohmmeter from
each component (e.g., hoses, pump, clamps, contain-
er, spray gun, etc.) to ground to ensure continuity.
Ohmmeter should show 0.1 ohms or less.
Submerse the outlet hose end, dispensing valve or de-
vice in the material being dispensed if possible. (Avoid
free streaming of material being dispensed.)
Use hoses incorporating a static wire.
Use proper ventilation.
Keep inammables away from heat, open ames and
sparks.
Keep containers closed when not in use.
WARNING
Excessive fluid pressure developed by
pump can cause personal injury, pump damage or
property damage.
Fluid pressure developed by the pump do not exceed
the maximum as stated on the pump model plate.
Be sure material hoses and other components are
able to withstand fluid pressures developed by this
pump. Check all hoses for damage or wear. Be certain
dispensing device is clean and in proper working con-
dition.
WARNING
INSTALLATION OF ELECTRICAL COMPO-
NENTS FOR HAZARDOUS DUTY APPLICATIONS.
Pumps that will operate in environments defined as
“hazardous locations” must only be installed, con-
nected and set-up by qualied personnel with knowl-
edge and understanding of protection classes, regula-
tions and provisions for apparatus in hazardous areas,
for the region where the pump will operate, because
these regulations and provisions, along with the de-
nition of what constitutes hazardous areas vary by
location.
WARNING
ELECTRIC SHOCK HAZARD. This equip-
ment must be grounded. Improper grounding, setup,
or usage of the system can cause electric shock.
Turn o and remove power before disconnecting any
cables and before servicing or installing equipment.
Connect only to grounded power source.
All electrical wiring must be done by a qualied elec-
trician and comply with all local codes and regula-
tions. For North America hazardous locations (NEC/
CEC), ensure wiring is done by a qualified and certi-
ed electrician according to NFPA 70 and CSA C22.1.
Installation personnel should meet IEC 60079-14
Annex A for knowledge, skills and competencies of
responsible persons, operators, technicians and de-
signers.
The knowledge, skills and competences for mainte-
nance and inspection personnel must comply with IEC
60079-17.
The knowledge, skills and competences for repair and
overhaul personnel must comply with IEC 60079-19.
Refer to VFD label and manual for minimum capacitor
discharge time prior to any service.
WARNING
HAZARDOUS PRESSURE. Can result in
serious injury or property damage. Do not service or
clean pump, hoses or dispensing valve while the sys-
tem is pressurized.
Disconnect and lockout / tagout power supply to elec-
tric motor and VFD. Relieve pressure from the system
by opening dispensing valve or device and / or care-
fully and slowly loosening and removing outlet hose
or piping from pump.
WARNING
HAZARDOUS MATERIALS. Can cause se-
rious injury or property damage. Do not attempt to
return a pump to the factory or service center that
contains hazardous material. Safe handling practices
must comply with local and national laws and safety
code requirements.
Obtain Material Safety Data Sheets on all materials
from the supplier for proper handling instructions.
WARNING
EXPLOSION HAZARD. Models containing
aluminum wetted parts cannot be used with 1-1-1
-Trichloroethane,Methylene Chloride or other Halo-
genated Hydrocarbon solvents which may react and
explode.
Check pump crankcase section, PRV section, Oil mod-
ule section, uid caps, manifolds and all wetted parts
to assure compatibility before using with solvents of
this type.
WARNING
MISAPPLICATION HAZARD. Do not use
models containing aluminum wetted parts with food
products for human consumption. Plated parts can
contain trace amounts of lead.
CAUTION
Verify the chemical compatibility of the
pump wetted parts and the substance being pumped,
flushed or recirculated. Chemical compatibility may
change with temperature and concentration of the
chemical(s) within the substances being pumped,
flushed or circulated. For specific fluid compatibility,
consult the chemical manufacturer.
CAUTION
HOT SURFACE. Metallic wetted sections
can reach up to the same temperature as the fluid
temperature (up to 100°C). Precautions should be
taken to restrict access to hot surfaces when needed.
Proper personal protective equipment (PPE) for hot
surfaces should be worn. Check to ensure parts have
cooled down suciently prior to any maintenance.

EP20-XXXXX-XXX-XXX (en) Page 9 of 44
CAUTION
Maximum temperatures are based on
mechanical stress only. Certain chemicals will signi-
cantly reduce maximum safe operating temperature.
Consult the chemical manufacturer for chemical com-
patibility and temperature limits. Refer to PUMP DATA
on page 3 of this manual.
CAUTION
Be certain all operators of this equipment
have been trained for safe working practices, under-
stand it’s limitations, and wear safety goggles / equip-
ment when required.
CAUTION
Do not use the pump for the structural
support of the piping system. Be certain the system
components are properly supported to prevent stress
on the pump parts.
Suction and discharge connections should be flexi-
ble connections (such as hose), not rigid piped, and
should be compatible with the substance being
pumped.
CAUTION
Prevent unnecessary damage to the
pump. Do not allow pump to operate when out of ma-
terial for long periods of time.
Disconnect power supply from motor when system
sits idle for long period of time.
CAUTION
Use only genuine ARO replacement parts
to assure compatible pressure rating and longest ser-
vice life.
NOTICE
TORQUE ALL FASTENERS BEFORE OPER-
ATION. Creep of housing and gasket materials may
cause fasteners to loosen. Torque all fasteners to en-
sure against uid or air leakage.
WARNING
=Hazards or unsafe practices which could
result in severe personal injury, death or
substantial property damage.
CAUTION
=Hazards or unsafe practices which could
result in minor personal injury, product
or property damage.
NOTICE
=Important installation, operation or
maintenance information.
4. GENERAL DESCRIPTION
4.1. Introduction
The EVO Series electric diaphragm pump offers a unique
combination of benets in the positive displacement pump
market. It features a broad range of material compatibility
options, high volume delivery, secondary containment, the
ability to fully deadhead, and is ecient and intelligent. The
pump works on the principle of converting rotary motion
from an AC induction motor to linear reciprocating motion to
drive a diaphragm. The motor is coupled directly to a rotating
eccentric crankshaft to drive connecting rods and pistons
which in turn drive three independent diaphragms. Three
diaphragms are used to ensure reduced pulsation and noise
for smoother and more reliable ow. Pump cycling will begin
as a commanded speed is supplied to the variable frequency
drive (VFD). As back pressure builds, the pump will reduce
speed until maximum line pressure is reached (dispensing
device closed). The pump will resume ow as back pressure is
relieved.
4.2. Storage
Place the equipment in a clean dry area, protected from im-
pacts, vibrations, temperature extremes and in an environ-
ment with relative humidity less than 90%.
When storing for longer than six months, consult the manu-
facturer.
4.3. Unpacking
Items supplied vary according to product conguration.
Make sure that the items supplied and the information on the
nameplate correspond to the order conrmation.
Check the individual packaging and the product visually for
damage caused by inappropriate handling during shipment.
NOTE: In-case of damage, report the damage to the transport
company and thereafter contact IR distributor.
NOTICE
To protect consumer rights please keep the Label intact on the
Motor, Pump and Drive.

Page 10 of 44 EP20-XXXXX-XXX-XXX (en)
5. MECHANICAL INSTALLATION
5.1. Pump and Motor Installation
WARNING
Pump and motors are industrial products. They
must therefore be installed by qualied, experienced and autho-
rized personnel. The safety of people, animals and property must
be ensured when tting the motors into pump.
CAUTION
Prior to commissioning for all motors, rotate
the motor at no load (no mechanical load) for 2 to 5 minutes,
checking that there is no abnormal noise. If there is any abnormal
noise, see section 5 on motor manual (Page 18).
WARNING
Before starting the motor, it is advisable to
check the insulation between the phases and earth, and between
phases.
Once Pump has been fully unpackaged and inspected, use
lifting points on Crankcase to move into nal operating posi-
tion (See Figure. 2).
Ensure straps and lifting device are properly rated. Refer
section 1.1 for pump weight.
All three lifting points should be used for stability.
Lifting points on Crankcase are intended to only move
the pump.
Do not use pump Manifolds to lift the equipment.
Ensure installation location has enough overhead room
to install motor vertically from above.
Ensure adequate clearance around pump for sufficient
access and ventilation.
Ensure the pump is installed on at level surface.
Secure pump legs to oor with M14 anchors.
Refer to section 13.1 for bolt circle spacing.
Pump must be positioned such that fluid inlet and fluid
outlet port are easily accessible.
Install motor onto the pump crank case.
Ensure gearbox motor does not damage pump Manifolds.
Refer to electric motor manual for lifting points and rec-
ommendations.
Ensure motor is vertical with shaft pointing downward
when mounting to the pump.
Ensure pump Crankshaft is greased from factory.
Motor should be carefully lowered while gently rotating
back and forth to ensure proper engagement of spline
interface. Ensure motor is aligned vertically. Do not apply
excessive force on the pump input Crankshaft. Spline in-
terface will t together easily with proper alignment.
Secure gearbox ange to Crankcase ange with 4X M12 (192)
bolts.
Figure 2
5.2. Pump and Gearbox Breather Installation
Once the motor is in place, the oil breather will need to be
installed in the upper cap of the pump Crankcase.
The pump Crankcase will come pre-lled with oil.
Remove temporary shipping plug (orange) from the
breather port in upper cap of the Crankcase housing.
Remove the plastic elbow (127) and breather (126) se-
cured to one of the pump legs.
Install the plastic elbow until NPT connection is 1-2 turns
from hand-tight with the outlet of the elbow pointing up-
wards.
Install breather onto elbow such that it is in the vertical
orientation.
Sight Glass
Breather
Drain Plug
Figure 3
VFD Mechanical installation
Refer to section 3 of VFD manual for detailed mechanical
installation.
Do not remove the nameplate from the drive.
Ensure that the lifting device is suitable for the task.
Mount drive to a flat surface or ensure back plate is in-
stalled to allow adequate air ow across cooling ns.
Refer to section XX for VFD mounting dimension.
4” (100 mm)
FOR AIR FLOW
4” (100 mm)
FOR AIR FLOW
AIR FLOWAIR FLOW

EP20-XXXXX-XXX-XXX (en) Page 11 of 44
The ordinary motor gearbox will also need to have a
breather installed after installation to the pump.
Remove the temporary metallic plug from breather port.
Locate breather supplied in plastic bag secured to gear-
box lifting lug.
Install breather onto gearbox.
Breather
Figure 4
The hazardous motor gearbox will require the installation of
an oil expansion tank.
Remove the temporary shipping plug from breather port.
Locate the oil expansion tank supplied with the gearmo-
tor.
Install expansion tank in breather port securing threads
with Loctite thread locker or Omnit 100M.
Remove the upper cap from the expansion tank and loos-
en the air venting port.
Use the 1 liter container of oil supplied with the gearmo-
tor to adjust the oil level between the two marks on the
dip stick.
Replace the cap on the oil expansion tank and retighten
the air vent port.
WARNING: Regularly check the oil level (once a week) for
hazardous location applications.
Air venting
port
Breather port
Oil Expansion
Tank
Dip Stick / Oil
Level Indicator
Figure 5
5.3. VFD Mechanical installation
Refer to section 3 of VFD manual for detailed mechanical
installation.
Do not remove the nameplate from the drive.
Ensure that the lifting device is suitable for the task.
Mount drive to a at vertical surface or ensure back plate
is installed to allow adequate air ow across cooling ns.
Refer to section 13.2 for VFD mounting dimension.
4” (100 mm
)
FOR AIR FLOW
4” (100 mm
)
FOR AIR FLOW
AIR FLOW
AIR FLOW
Figure 6
Accessory Option: Stainless Steel Backplate for use when the
VFD cannot be mounted directly to a at surface for proper
cooling. See section 1.2 to conrm VFD frame size.
A5 Frame Size: PN 130B3242
B1 Frame Size: PN 130B3434

Page 12 of 44 EP20-XXXXX-XXX-XXX (en)
6. ELECTRICAL INSTALLATION FOR ORDINARY LOCATIONS
6.1. VFD-Wiring Diagram
––
Motor
Analog Output
ON=Terminated
OFF=Open
91 (L1)
92 (L2)
93 (L3)
PE
88 (-)
89 (+)
53 (A IN)
54 (A IN)
37 (D IN)1)
18 (D IN)
10 V DC
15 mA 130/200 mA
+- +-
(U) 96
(V) 97
(W) 98
(PE) 99
(P RS485) 68
(N RS485) 69
0 V
5V
S801
0/4–20 mA
RS-485
03
240 V AC, 2 A
24 V DC
02
01
05
04
06
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
19 (D IN)
24 V (NPN)
0 V (PNP)
24 V
0 V
0 V (PNP)
24 V (NPN)
(D IN/OUT)1)
0 V
24 V
29
24 V (NPN)
0 V (PNP)
0 V (PNP)
24 V (NPN)
33 (D IN)
32 (D IN)
12
ON
S201
ON
21
S202
ON=0/4–20 mA
95
P 5-00
21
ON
S801
(R+) 82
(R-) 81
: Chassis
240 V AC, 2 A
400 V AC, 2 A
: PE
3-phase
power
input
+10 V DC
DC bus
0/-10 V DC to
+10 V DC
0/4–20 mA
0/-10 V DC to
+10 V DC
0/4–20 mA
50 (+10 V OUT)
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT)
20 (COM D IN)
27 (D IN/OUT)
Switch mode
power supply
Brake
resistor
Relay 1
Relay 2
1)
(COM A OUT) 39
(A OUT) 42
: Ground
: Ground 1
: Ground 2
(COM RS485) 61
2)
RS485
interface
OFF=0/-10 V DC
to +10 V DC
A Analog
DDigital
1 Terminal 37 (optional) is used for Safe Torque O
(STO).
2 Do not connect cable shield.
6.2. General Wiring Practice for VFD
Due to limited number of knockouts in VFD, it is recommended to combine signal wires (Safe Stop cable, Leak detector ca-
ble, Thermistor cable) into a single cable.
Route control wiring in separate conduit and as far away from power wires as possible.
A dedicated ground wire is needed, It is not recommended grounding through the conduit.
Keep wire runs as short as possible to help avoid problems.
NO
TE: Knockouts shaded in gray are already pre-drilled as the VFD comes from the factory.
All cable gland holes are M25 or 3/4" NPT (28.4 mm)
Low Voltage Bundled Cable
*Leak Detects (3x)
*Motor Thermistor
*Safe Stop (E-Stop)
Drill out with 1-1/8" Metal
Cutting Hole Saw
(Ensure no debris is left
inside of the VFD)
Motor
Cable
Encoder
Cable Incoming
Mains Cable Ensure any unused cable
gland holes are properly
plugged to maintain
IP66 / Nema 4x protectio
n
Recommended VFD Cable Entry Positions (A5 Frame Size)
Figure 7

EP20-XXXXX-XXX-XXX (en) Page 13 of 44
Recommended VFD Cable Entry Positions (B1 Frame Size)
NOTE: Knockouts shaded in gray are already pre-drilled as the VFD comes from the factory.
Motor Cable
1" NPT or M32 (34.7 mm)
2 plcs - Optional Glands
1/2" NPT or M20 (22.5 mm)
Encoder Cable
3/4" NPT or
M25 (28.4 mm)
Incoming
Mains Cable
1" NPT or M32
(34.7 mm)
Low Voltage Bundled Cabl
e
*Leak Detects (3x)
*Motor Thermistor
*Safe Stop (E-Stop)
1" NPT or M32 (34.7 mm)
Figure 8
6.3. VFD AC Mains – Input Power Requirements:
Supply terminals (6-pulse) L1, L2, L3
Supply voltage
(1)(2)
200 - 240 V +/- 10%, 380 - 500 V +/- 10%, or 525 - 600 V +/- 10%
Supply frequency 47.5 - 63 Hz
Maximum imbalance temporary between mains phases 3.0% of rated supply voltage
True power factor (λ) ≥ 0.9 nominal at rated load
Displacement power factor (cos Φ) Near unity (> 0.98)
Switching on the input supply L1, L2, L3 (power - ups) ≤ 7.5 kW (10 hp) Maximum twice per minute
1. Mains voltage low/mains dropout: During low mains voltage or a mains dropout, the drive continues until the DC-link voltage drops below the min-
imum stop level, which typically corresponds to 15% below the drive’s lowest rated supply voltage. Power-up and full torque cannot be expected at
mains voltage lower than 10% below the drive’s lowest rated supply voltage.
2. The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600 V maximum.
6.4. Power Wiring
6.4.1 VFD - Input Power Wiring
Size the wiring based on the input current of the drive (see page 3). For maximum cable cross-sections, see the table below
(from VFD manual, table 8.1.4)
Comply with local and national electrical codes for cable sizes.
Cable glands should be selected to match the cable diameter and to maintain the IP / Nema rating of the VFD.
Connect the 3-phase AC input power wiring to terminals L1, L2, and L3.
Ground the cable in accordance with the grounding instructions, see 4.3 Grounding and 4.5.1 Grounding the Cable Shield
in VFD manual.
When supplied from an isolated mains source (IT mains or oating delta) or TT / TN-S mains with a grounded leg (ground-
ed delta), ensure that parameter 14-50 RFI Filter is set to [0] O. This setting prevents damage to the DC link and reduces
ground capacity currents in accordance with IEC 61800-3.
Power Cable Cross Sections
Maximum cable cross section (mm
2
[AWG])
Enclosure Mains Motor
A5 4 (12) 4 (12)
B1 10 (7) 10 (7)
6.4.2. VFD - Output Motor Wiring
Use shielded cables.
Size the wiring based on the full load current of the motor (see motor nameplate). For maximum cable cross-sections, see
the table above (from VFD manual, table 8.1.4)
Cable glands should be selected to match the cable diameter and to maintain the IP/Nema rating of the VFD.
Comply with local and national electrical codes for cable sizes.
Strip a section of the outer cable insulation.

Page 14 of 44 EP20-XXXXX-XXX-XXX (en)
Position the stripped wire under the cable clamp to establish mechanical xation and electrical contact between the cable
shield and ground.
Connect the ground wire to the nearest grounding terminal in accordance with the grounding instructions, Refer to sec-
tion 7.2 for Grounding.
Connect the 3-phase motor wiring to terminals 96 (U), 97 (V), and 98 (W).
Do not wire a starting or pole-changing device (for example a Dahlander motor or slip ring asynchronous motor) between
the drive and the motor.
Ensure 2 Phases are inverted between the VFD and the motor (as shown by schematic below) to ensure proper rotation
direction of the motor. If motor direction is not wired correctly, VFD Alarm 61 (Feedback Error) will trip at startup. If this oc-
curs, swap any two phases, reset the alarm and restart the motor.
99(PE)
91(L1)92(L2)93(L3)95(PE)
3-PHASE
POWER
INPUT
U2V2W2
U1V1W1
96(U)97(V)98(W)
MOTOR VFD
99(PE)
91(L1)92(L2)93(L3)95(PE)
3-PHASE
POWER
INPUT
U2V2W2
U1V1W1
96(U)97(V)98(W)
MOTOR VFD
400V Wye Wiring Schematic
(For use with 380 - 500V or 525 - 600V VFD)
230V Delta Wiring Schematic
(For use with 200 - 240V VFD)
6.4.3. Motor - Input Power Wiring
The cables must be tted with connectors suitable for the cable cross-section and the terminal diameter.
They must be crimped in accordance with the connector supplier’s instructions.
If using cables without connectors, attach some calipers.
If any nuts on the brass terminal block are lost, they must be replaced by brass nuts, not steel ones.
When closing the box, ensure that the seal is correctly positioned.
Cable glands should be selected to match the cable diameter and to maintain the IP rating of the motor.
Motor should be wired with shorting tabs in the DELTA conguration when used with 200-240V VFD, and should be wired
with shorting tabs in the WYE conguration when used with the 380-500V or 525-600V VFD options. See wiring schematic
above.
Type of cable gland Ø min. - Ø max. (mm) cable
Steel Polyamide cable gland Brass cable gland
ISO M16 5-10 5.5-9.5
ISO M20 9.5-15 8.5-13
ISO M25 13-19 12-17
+DC
BR-B
M A I N S
L1 L2 L3
91 92 93
RELAY 1 RELAY 2
99
U V W
MOTOR
99
Mains input, motor, and grounding for basic drives. Actual congurations vary with unit types and optional equipment.
Figure 9

EP20-XXXXX-XXX-XXX (en) Page 15 of 44
6.5. Control Wiring (Required)
6.5.1. Leak detector wiring diagram
General Description:
An ARO Diaphragm pump equipped with the ARO Leak Detection Sensor warns of a Diaphragm failure by sensing the pres-
ence of liquid in the air cap of the pump. This system uses a liquid sensor in each of the three air caps which will send an out-
put signal to the VFD to shut down the motor when uid is detected.
Installation and Warnings:
NOTE: All WIRING MUST COMPLY WITH ALL LOCAL AND / OR NATIONAL ELECTRICAL CODES.
The Leak Detection Sensor components must be installed by a qualied electrician in compliance with all national, state
and local codes and regulations to reduce the risk of electrical shock or other serious injury during installation and opera-
tion.
Some local electrical codes may require the installation of rigid conduit.
ARO is not responsible for accidents resulting from improper installation of components or hardware.
Do not attempt any service without disconnecting all electrical supply source.
White
Red
Black
White
Red
Black
White
Red
Black
Leak Detect Diaphragm 1
Leak Detect Diaphragm 2
Leak Detect Diaphragm 3
Pin 18 on VFD
(Digital input)
Pin 19 on VFD
(Digital input)
Pin 32 on VFD
(Digital input)
Pin 13 on VFD
(24V DC)
Pin 20 on VFD
(Common)
Leak Detection Sensor PN Voltage Device Rating (mA) Temperature Rating
96270-2 (ATEX / IECEx / NEC / CEC) 24 VDC 40 -0°F - 176°F (-18°C - 80°C)
NOTE: The same leak detection sensor is used for both ordinary and hazardous applications.
The Leak Detection Sensor comes with 2m of cable length with ying lead connections. It is recommended to combine
leak sensor cables into a single low voltage cable bundle to send to the VFD.
It is also recommended to install the leak detects as shown below to keep track of which leak detect corresponds to each
Diaphragm as the VFD will indicate which leak detect has tripped. Leak detect #1 would correspond with the lowest cylin-
der with the signal wire tied to digital input 18 of the VFD.
Leak detector
#1 location
Leak detector
#2 location
Leak detector
#3 location
Figure 10

Page 16 of 44 EP20-XXXXX-XXX-XXX (en)
6.5.2. Thermal protection – Ordinary motor
Motor is installed with 2 normally closed contact sensors (PTO) in series for ordinary motors and will need to be wired from
the motor terminal box to the VFD as per below wiring diagram. Cable extension and cable glands are not provided.
It is recommended to use the M16 cable gland on the motor terminal box for the PTO control cable.
PTO Thermal Switches
(Installed on motor)
Normally closed
(NC)
Normally closed
(NC)
Pin 20 on VFD
(Common)
Pin 33 on VFD
(Digital Input)
6.5.3. Encoder Wiring – Ordinary Motor
Motor is installed with a 1024 pts TTL encoder with a 12-pin connector on the outside of the motor terminal box.
Each ordinary location pump comes with a 9 meter encoder extension cable with a soldered 12-pin connector (PN 67561-
009). Alternate encoder cable assembly lengths are available through aftermarket (see page 7).
Flying leads need to be wired to the MCB102 encoder card installed in the option B slot of the VFD as per encoder card wir-
ing details shown below.
NOTE: The encoder cable will have either a green or black outer jacket.
TO MOTOR
12 PIN CONNECTOR TO MCB 102
ON VFD
VFD Encoder Card Connections:
NOTE: Ensure the cable shielding is grounded to the VFD frame.
It is highly recommended to use the ARO encoder cable assembly to minimize the chance of installation issues. For customers
who wish to build their own encoder cable assembly, please reach out to your ARO representative for additional details re-
garding the required cable type and the pin-out descriptions of the 12 pin connector.
Individual Wire Colors
(Black Outer Jacket)
Individual Wire Colors
(Green Outer Jacket) Description Encoder Card
Terminal
Red / White Brown 5V (3)
Blue / White White GND (4)
Yellow Yellow A Input (5)
Green Green A Inv Input (6)
Red Pink B Input (7)
Orange Grey B Inv Input (8)
Blue Blue C or Z Input (9)
Purple Red C Inv or Z inv Input (10)
N/A Green / Yellow Shield N/A

EP20-XXXXX-XXX-XXX (en) Page 17 of 44
6.6. Control Wiring (Recommended)
6.6.1. Safe Stop wiring diagram
It is recommended to install an external Emergency Stop (Safe Stop). Referred to in VFD manual as Safe Torque O (STO).
The VFD will come with pin 37 (E-stop digital input) wired to 24V (pin 12 or 13). This jumper will need to be removed when
the E-stop is installed.
The E-Stop should be mechanically latching and normally closed. The pump will only run when 24V is supplied to pin 37.
An open circuit will stop the pump.
Pin 12 on VFD
(+24 V OUT)
Pin 37 on VFD
(Digital Input)
6.7. Control Wiring (Optional)
6.7.1. Digital start/ stop control
If the VFD is run using analog or digital control methods in the "Auto On" mode, then a Start / Stop command will be re-
quired to run.
To congure the VFD for a digital Start/Stop command, install a switch between pin 20 (common) and digital input 27 or
29.
Update VFD parameter 512 or 513 respectively to "[8] Start".
Additionally, a digital reset command can be used with the same procedure on a dierent digital input with the VFD pa-
rameter set to "[1] Reset" instead.
NOTE: Terminal pins 27 and 29 are available to be congured for any digital input or output. By default these are both cong-
ured to "Input" per VFD parameters 501 and 502. Note that all digital inputs are congured for NPN.
+24 V
+24 V
D IN
D IN
D IN
COM
D IN
D IN
D IN
D IN
12
13
18
19
20
27
29
32
33
37
Drive
VFD Parameter Function Setting
512 Terminal 27 digital input [8] Start
513 Terminal 29 digital input [1] Reset

Page 18 of 44 EP20-XXXXX-XXX-XXX (en)
6.7.2. Analog Input – Speed control
A 0 - 10 V or 4 - 20 mA signal can be used to control VFD speed from 0 - 100% using analog input 53.
The VFD is set to receive a 0-10 V input signal as congured from the factory. To change to 4-20 mA input signal, toggle the
A53 switch from "U" to "I" inside the VFD.
The analog speed control function will only work in "Auto On" mode. Additionally, it requires a digital "Start" command to
run (see previous section).
+10V
A IN
A IN
COM
A OUT
COM
50
53
54
55
42
39
A53
U - I
0–10 V
+
-
Drive
+10 V
A IN
A IN
COM
A OUT
COM
50
53
54
55
42
39
+
-
A53
U - I
4-20mA
Drive
+10 V
A IN
A IN
COM
A OUT
COM
50
53
54
55
42
39
A53
U - I
≈5kΩ
Drive
VFD Parameter Description Default Parameter
610 Terminal 53 Low Voltage 0.07 V
611 Terminal 53 High Voltage 10.00 V
612 Terminal 53 Low Current 4 mA
613 Terminal 53 High Current 20 mA
6.7.3. Analog Inputs – Torque (Pressure) Control
A 0 - 10 V or 4 - 20 mA signal can also be used to control the VFD torque limit setting (parameter 416) from 0 - 100% using
analog input 54. The same wiring schematics from section 6.7.2 apply with the only dierence being the use of analog in-
put 54.
The VFD is set to receive a 0 - 10 V input signal as congured from the factory. To change to 4 - 20 mA input signal, toggle
the A54 switch to "U" to "I" inside the VFD.
To enable torque limit control via the analog 54 input, change VFD parameter 420 (Torque Limit Factor Source) from "[0] No
Function" to "[6] Analog in 54".
+10 V
A IN
A IN
COM
A OUT
COM
50
53
54
55
42
39
A54
U - I
≈5kΩ
Drive
NOTE: Once parameter 420 is set to "[6] Analog in 54", this will be the source of the torque limit setting whether the VFD is in
"Hand On" or "Auto On" mode. The pump will not operate if there is no signal on A54 or if the signal is too low.
VFD Parameter Description Default Parameter New Setting
420 Torque Limit Factor Source [0] No Function [6] Analog in 54
620 Terminal 54 Low Voltage 0.07 V ----
621 Terminal 54 High Voltage 10.00 V ----
622 Terminal 54 Low Current 4.00 mA ----
623 Terminal 54 High Current 20.00 mA ----

EP20-XXXXX-XXX-XXX (en) Page 19 of 44
6.7.4. Additional available Input/output (Optional)
1. T27 and T29 are congurable for digital input or output.
Digital output can be either digital or pulse output. The options for parameters 530 and 531 are all digital, however,
to enable pulse output the parameters in the table below should be set as shown. The pulse output variable can then be
selected using parameters 560 and 563.
VFD Parameter Function Setting
501 Terminal 27 mode [1] Output
502 Terminal 29 mode [1] Output
530 Terminal 27 Digital Output [55] Pulse Output
531 Terminal 29 Digital Output [55] Pulse Output
560 Terminal 27 Pulse Output Variable Select output variable to display from the list
552 Pulse Output Max Freq #27 5000 (default)
563 Terminal 29 Pulse Output Variable Select output variable to display from the list
555 Pulse Output Max Freq #29 5000 (default)
2. T42 analog output
Refer to Personal menu table (650, 651 and 652) to set parameter in VFD for this terminal.
3. Relays
Two relays are available for use (Parameter 540).
Refer to section 8.6.11 (page – 69) in VFD manual for detailed relay information.
6.8. Congured Input / Output Summary - Ordinary
Intended function Alarm Digital I/O Terminal Ground Terminal 24VDC Terminal
Diaphragm 1 Leak Detect AA1 - Diaphragm 1 Leak 18 20, 39 or 55 12 or 13
Diaphragm 2 Leak Detect AA2 - Diaphragm 2 Leak 19 20, 39 or 55 12 or 13
Diaphragm 3 Leak Detect AA3 - Diaphragm 3 Leak 32 20, 39 or 55 12 or 13
PTO (normally closed) -
Ordinary pump only Alarm 11 33 20, 39 or 55 N / A
Safe Stop (E Stop) Alarm 68 37 N / A 12 or 13
User Congurable I/O 27 20, 39 or 55 N / A
User Congurable I/O 29 20, 39 or 55 N / A
Analog In Terminal Ground Terminal 10VDC Terminal
Speed Control 53 20, 39 or 55 50
Torque Control 54 20, 39 or 55 50
Analog Out Terminal
User Congurable Output 42 20, 39 or 55 N / A
6.9. VFD serial communication
1. Drive will have RS485 serial communication port.
Connect RS485 serial communication wiring to terminals (+) 68 and (-) 69.
2. Connect RS485 serial communication wiring to terminals (+) 68 and (-) 69.
3. Drive will support Modbus RTU eld communication.
4. Set the below parameter for serial communication set-up.
VFD Parameter Function
8-30 Select Option [2] for Modbus RTU. Changing parameter is not
eective until after powering o frequency converter.
8-31 Enter the valid address for the frequency converter
(standard) port. e.g. [1-247]
8-32 Select option for the Baud rate match with FC (standard) port.
531 Terminal 29 Digital Output
560 Terminal 27 Pulse Output Variable
552 Pulse Output Max Freq # 27
563 Terminal 29 Pulse Output Variable
555 Pulse Output Max Freq # 29

Page 20 of 44 EP20-XXXXX-XXX-XXX (en)
Fieldbus Communication Option A Cards:
These are available for aftermarket installation only and should be installed in the VFD option A slot. Please note this is only
available for ordinary applications.
Part Number Description
130B1200 Probus DP VI MCA 101, coated
130B1202 DeviceNet MCA 104, coated
130B1205 CAN Open MCA 105, coated
130B1235 PROFINET MCA 120, coated
130B1219 EtherNet IP MCA 121, coated
130B1296 Modbus TCP MCA 122, coated
130B5646 EtherCAT MCA 124, coated
RS485
61
68
69
+
_
6.10. User dened readout
Parameters 030, 031, and 032 are available to modify the “User Dened Readout” that will display in the top left corner of
the main menu screen. By default, these values are set to scale motor frequency to actual pump rpm. To update the “User
Dened Readout”, refer to the following parameter descriptions.
1. Select the unit to be displayed on LCP from option given in parameter 030.
2. Minimum value is set to zero in parameter 031.
3. Maximum value is set for parameter 032 based on maximum motor frequency (92 Hz) set in parameter 414 and calcu-
lated as below.
Pump unit (Maximum) = Motor sync. RPM (1500) X Maximum motor frequency (92 Hz) x unit conversion factor (X)
“Motor Frequency (50 Hz) X GB ratio (12.7)”
Pump Unit (parameter 030) * Unit conversion factor (X)
RPM 1
Gallons per Minute 0.65
Liters per Minute 2.46
NOTE: Adjust unit conversion factor for the selected unit given in parameter 030 to calculate maximum value for parameter
032 per the above formula.
* Unit conversion factor values are approximate and depend on back pressure.
