Shinkawa CV-86 Series User manual

MANUAL No. 6G14-082 Rev.2
Published in Mar. 2015
Revised in Mar. 2015
MODEL CV-86 SERIES
PIEZOELECTRIC VELOCITY TRANSDUCER
INSTRUCTION MANUAL

FOREWORD CV-86
i
For Use in Safety.....
Thank you for your using our CV-86 Series Piezoelectric Velocity Transducer.
SHINKAWA Sensor Technology applies strict quality control and inspections to ensure the high reliability of
its products.
This instruction manual contains descriptive information , specifications, principle of operation, installation
procedures and field wiring with monitor.
Please study the contents of this manual and related manuals thoroughly before installing or operating the
equipment, and keep it handy for future reference.
(This manual is applied to Model CV-861, -862 version.)
! CAUTION
1. Do not drop the transducer and otherwise mishandle.
2. Be sure to install the transducer at environmental (case) temperature within -50 to +120°C.
3. Field wiring should be performed correctly by reading this manual.
4. Install the transducer at the place where is most sensitive for vibration. the mounting surface
must be clean, smooth, flat, and large enough to accommodate the entire base of
transducer.
5. Use the specified connector and cable in the specifications.
Keep cabling away from power and control lines to prevent noise interference.
6. Do not measure insulation resistance and dielectric strength other than those at places
specified.
If measured, transducer damage may result.
7. Do not remodel this unit without permission. Otherwise the guarantee can not be made.
8. This unit is designed for use by specialists or persons thoroughly familiar with the field.
9. Make sure that the end user receives the Instruction Manual delivered with this unit.
Before Use.....
When the unit is received, inspect it for damage suffered in transport and check whether it is the item you
ordered. In the unlikely event that it was damaged in transport or does not function according to specifications,
please contact the SHINKAWA Office or the dealer nearest to you.
Store the unit under the ambient conditions given in the specification.
Avoid places where it is exposed to high humidity or corrosive gases.
Follow closely all instructions written in the manual.

CONTENTS CV-86
ii
1. GENERAL INFORMATION
1-1 GENERAL ······················································································ 1
1-2 SYSTEM CONFIGURATION EXAMPLE ··············································· 1
2. SPECIFICATIONS
2 SPECIFICATIONS ············································································ 2
3. RECEIVING INSPECTION AND STORING
3-1 RECEIVING INSPECTION ································································· 4
3-2 STORING CONSIDERATIONS ··························································· 4
4. INSTALLATION
4-1 GENERAL ······················································································ 5
4-2 INSTALLATION PROCEDURE ··························································· 5
4-3 CONNECTOR CONNECTION PROCEDURE ········································ 6
4-4 CABLE ··························································································· 7
5. WIRING DIAGRAM
5-1 WIRING PROCEDURE ····································································· 8
6. MAINTENANCE
6-1 MAINTENANCE ··············································································· 9
7. INTRINSIC SAFETY
7-1 TIIS ······························································································· 10
7-2 NEPSI ···························································································· 11
7-3 KTL ······························································································· 13

1. GENERAL INFORMATION CV-86
-1-
1-1 GENERAL
Model CV-86 Sereis Piezoelectric Velocity Transducer is piezoelectric accelerometer with internal integration
to velocity. The case configuration of the CV-86 is of the permanent mount type making it an ideal choice for
permanent machine monitoring. The CV-86 offers a frequency response and phase stability that is superior to
conventional velocity transducer.
1-2 SYSTEM CONFIGURATION EXAMPLE
Machine Case
Recorder Output
Waveform Analyzing
CV-86 Serise Piezoelectric
Velocity Transducer
CW Cable
Vibration Monitor
Signal
+24V
p
owe
r
Monitoring Dvice
Alarm Output

2. SPECIFICATIONS CV-86
-2-
CV-861 /EX CV-862 /EX
Sensitivity 3.94mV/mm/s (100mV/in/s REF.)pk ± 5% at 100Hz, 25°C (77°F REF.)
Max. Velocity 1,270mm/s (50in/s REF.)pk
Vibration Limit 2,450m/s
2
(250g REF.)pk
Shock Limit 24,500m/s
2
(2,500g REF.)pk (non-Intrinsically Safe)
23,520m/s
2
(2,400g REF.)pk (Intrinsically Safe)
Max. Shock Energy 4J (Intrinsically safe)
Linearity ± 1% of F.S.
Natural Frequency 15kHz
Frequency Response 2.5 to 3,500Hz ± 10%, 2 to 7,000Hz ± 3dB
Transverse Sensitivity Max.5%
Output Impedance 200(typical)
Grounding Case isolated, internally shielded
Temperature Response ± 10% (around the operating temperature range)
Power Supply 18 to 30VDC, 2 to 10mADC (constant current)
Operating Temperature Range -50 to +120°C (-58 to +248°F REF.)
Range of Temperature at Explosion proof
construction EX1,7 : -20 to +60C (Transducer, Cable)
EX8 : -50 to +120C (Transducer, Cable)
Relative Humidity 100%RH
Case Material Stainless Steel
Sealing Hermetic
Protection Rating IP67(CV-861 & CW-□□□F-FF, CV-862)
Weight Approx.145g(CV-861) Approx.250g(CV-862(including cable))
Accessories Supplied M6 mounting stud
Output Connector*4 MIL-C-5015 2-pin
Matching Connector*4 MS3106A-10SL-4S
Cabling CV-861 : Twisted pair shielded cable
CV-862 : Coax. cable (intergral cabling type)
Recommended Cable Shielded
Specifications AWG No.20 to No.16 gage (0.5mm
2
to 1.25mm
2
) Twisted pair shielded cable
*4 CV-861 TYPE SPECIFICATIONS
Model Code
SPECIFICATIONS
Standard type CW-
Drip-proof type CW-
Cable length Lug type*2 Armor
050 5m 0 Cut off 0 Without
100 10m R Ring lug 1 With*3
150 15m Y Spade lug
E-EF- 0-
F-FF- 0-
Cable Type Intrinsically Safety
1 Connector Type 1 TIIS (Ex ia A T4 X)
7 NEPSI (Ex ia A T4)
8 KTL (Ex ia A T4)
Note) *1 Cable length 3m (end cut off),
CW cable not required.
*2 M3.5 crimping terminals at the
cable ends are standard.
*3 With armor : Cable length 50m
Cable Type Intrinsically Safety
2With integral cable type *1 1 TIIS (Ex ia A T4 X)
(Coax. cable 3m standard) 7 NEPSI (Ex ia A T4)
6H14-062 Rev.2

3. RECEIVING INSPECTION AND STORING CV-86
-4-
3-1 RECEIVING INSPECTION
Visually inspect the transducer for obvious shipping damage. If shippng damage is apparent, file a claim with
the carrier and submit a copy to SHINKAWA Sensor Technology, LTD.
3-2 STORING CONSIDERATIONS
If storing is required temporarily, observe the following notes.
(1) Store the transducers in the shipping box.
(2) Do not store in the following places.
a) with extreme temperature.
b) with much moisture.
c) with magnetic field.
d) with shock or vibration.
e) with corrosive materials.
f) with water or dust.

4. INSTALLATION CV-86
-5-
4-1 GENERAL
Model CV-86 can be mounted to the measured point by using attached mounting stud.
! CAUTION
The mounting surface must be clean, smooth, flat, and large enough to accommodate the entire
base of the transducer.
4.2 INSTALLATION PROCEDURE
Mount the CV-86 transducer by performing the following steps.
(1) Drill and tap the mounting hole (M6, 7mm deep min.) perpendicular (90°±1°) to the mounting surface.
(2) Clean the mounting surface.
Dirt, dust, paint and oils must be wiped out from the mounting surface. Ensure the mounting hole is free
off foreign material and the threads are clean.
(3) Install the mounting stud into the transducer base and finger tighten until snug.
(4) Apply some silicon grease to the mounting surface.
(5) Install the transducer into tapped mounting hole and tighten the transducer with a torque wrench until
snug. The transducer is torqued to about 320N•cm(33kg•cm REF.).
! CAUTION
Do not over-torque. Excessive torque can result in degraded performance, internal damage
and inaccurate readings.
A
1°A
>1.1 × sensor dia.
9
mm
or more
7mm
or more
0.025
Stud Mounting : Surface Preparation
Surface texture on
greater than 8µm

4. INSTALLATION CV-86
-6-
4-3 CONNECTOR CONNECTION PROCEDURE
Connect connector by performing the following steps for Model CV-861 connector type version.
(1) Securely connect the connector of the cable to the connector receptacle of the transducer.
(2) To prevent loosening of the connector due to vibration, secure the connector with stainless wire as shown
below.
! CAUTION
1. If used in the place with much moisture, encapsulate the connector with silicon compound
that does not have an acetic base.
2. If used in outdoor environment, drip-proof type connector cable should be used.
3. Be ware not to apply the excessive force to the connector, which may cause the damage.
Lock wire hole
Stainless wire
Connecto
r
Lock wire hole

4. INSTALLATION CV-86
-7-
4-4 CABLE
Observe the following notes for cabling.
(1) Use the CW-050 standard cable for connection with the CV-861 connector type version.
Use the twisted pair, shielded cable AWG No.16 to 20 (0.5mm2to 1.25mm2) for connection between the
junction terminal and monitoring device. Select suitable cable for operating environments.
(2) The cable should not exceed 300 meters. Excessive length may limit the systems frequency response.
(3) Keep cabling away from power and control lines, to prevent noise interference.
(4) Cable should be securely fixed. Prevent the cable from bending sharply, twisting, kinking,
knotting, and straining. The recommended minimum bend radius is 80mm. Refer to below drawing.
SHINKAWA recommends that the cable should be routed, through conduit to prevent physical damage
and noise interference.
! CAUTION
Beware not to apply the excessive force to the connector cable, which may cause the
damage.
Dimension : mm

5. WIRING DIAGRAM CV-86
-8-
5-1 WIRING PROCEDURE
The CV-86 requires an external DC power source to operate. Proper operation can be obtained by applying a
DC power to the appropriate lead of transducer through a current regulating (CR) diode, as shown below.
! CAUTION
1. Never omit the current regulating diode.
2. Do not reverse polarity.
3. If the transducer is connected to the monitoring device (e.g. vibration monitor) that can
supply DC power output to the transducer, refer to the instruction of the monitoring device.
! WARNING
Beware of electric shock from high-voltage parts.
! CAUTION
1. A blocking capacitor (≈10µF) is required in series with the output signal if the readout
instrument is DC coupled.
2. When the CW shielded cables connected to the shell, do not connect the shield cable to
common terminal. (Refer to Fig.2)
CV-86
Power, signal
0V(return)
* CR diode
2 to 10mA
Power +18 to +30VDC
(Recommended+24VDC)
Signal output
0V(return)
* e.g. Motorola 1N5312
or
Diode connection
(Bottom view)
B+
(power side)
May be provided as part of monitoring device.
CV-86
IN
COM
Power, signal
0V
Typical wiring
Monitor
B+
(power side)
CV-86
IN
COM
Power, signal
0V
Monitor
Fig.1
Fig.2

6. MAINTENANCE CV-86
-9-
6-1 MAINTENANCE
The following items should be periodically checked to operate the system satisfactory.
1) Check the transducer body is properly mounted and secured.
2) Check there is no contact fault and water entered at connector.
3) Check the cable is connected securely to monitoring device.
4) Check the cable is in good condition.

7. INTRINSIC SAFETY CV-86
-10-
7-1 TIIS (Japanese Only)

7. INTRINSIC SAFETY CV-86
-11-
7-2 NEPSI (Chinese Only)

7. INTRINSIC SAFETY CV-86
-12-

7. INTRINSIC SAFETY CV-86
-13-
7-3 KTL(Korean Only) 【CV-861 Only】

Warranty
The warranty period for the delivered product shall be 3 years from the date of delivery from
our factory. But the warranty period for the special order product and software shall be 1 year,
and for the repairing parts shall be 6 months. In the event that the delivered product develops
any defects within the warranty period for which Shinkawa Electric is liable, the defective part
will be replaced or repaired in our factory at our own expense.
In the event that a Shinkawa engineer needs to be dispatched for repair purposes during the
warranty period, the cost of the repairs will be borne by Shinkawa Electric ; however, the travel
expenses shall be charged in accordance with our policies.
However, the following are excluded from our warranty:
(1) Any defects due to improper handling or operation by the user.
(2) Any defects, the case of which is not attributable to Shinkawa Electric.
(3) Any modifications or repairs made by others than Shinkawa Electric or persons
commissioned by Shinkawa Electric.
(4) Any handling, storage and operation under severe environmental conditions that exceed
the design specifications.
(5) Any defects due to fire, flood, earthquake, lightning and other Acts of God.
(6) The consumables
(7) Other defects considered not to be attributable to Shinkawa Electric.
This warranty applies exclusively to the delivered product units.
Shinkawa Electric will not be held liable for consequential damage caused either directly or
indirectly through a defect of the delivered product.
The warranty period and scope of machinery and equipment made by manufacturers other
than Shinkawa Electric shall be in accordance with the conditions of the respective
manufacturer, regardless of the provisions made above.

© 2014 SHINKAWA Sensor Technology, Inc. All rights reserved.
Hiroshima Factory
4-22 Yoshikawa-kogyodanchi, Higashi-hiroshima 739-0153, Japan
Tel. [phone] Fax. [phone]
[Quality Assurance Department] E-Mail : [email protected]
