CONTENTS
INTRODUCTION ..............................................................1
FEATURES, SPECIFICATIONS & CONTENTS ...............2
FRONT PANEL ................................................................3
REAR PANEL ...................................................................4
REMOTE CONTROL .......................................................5
RS-232 SERIAL INTERFACE ...........................................7
RS-232 PROTOCOL COMMANDS ..................................8
IR EXTENDER ................................................................. 9
TYPICAL APPLICATION ...............................................11
LIMITED WARRANTY ................................................... 12
INTRODUCTION
Congratulations on your purchase of one of the most innovative
Component Video (YPBPR)/Digital Audio (PCM)/Stereo Audio
(AR/AL) matrix switching products on the market today. The
SB-5588CT is a true matrix routing switcher for Component
Video (YPBPR)/Digital Audio (PCM) /Stereo Audio signals. The
8x8 Component Video + Digital/Analog Audio matrix switcher
with RS-232 and Ethernet is designed to work as a switcher for
multiple Audio/Video sources and displays. Capable of switching
Component Video, SPDIF and Stereo Audio signals between (8)
sources and (8) displays with compatible inputs. With a maximum
bandwidth of 325MHz, this unit will support sharp and highly
dened video in multiple resolutions of up to 1080p. Because it
is a matrix router, any input may be routed to any output; or the
same input may be routed to all outputs or any combination. It
completely eliminates the need to constantly move around audio
and video input cables and output category (RJ-45) cables. The
is useful for matrix signals from A/V source devices (such as:
VCRs, Camcorders, Video Game Consoles, Video CD players,
DVD players, Satellite Receivers, CAT5 Set Top Boxes, etc.) to AV
destination devices over CAT5 cables (such as: LCD TV, Plasma
TV Monitors, HDTV Sets, Video Projectors, etc.). RS-232 control
allows the switcher to be controlled by a computerized system
such as Hyper Terminal and in this case eliminates the need for
an infrared remote control. Selection of inputs can be made via
the front panel push buttons or an infrared remote control or RS-
232 control by a computer. Also supports (1) set of Component &
Digital/Analog Audio RCAs for a local monitor or troubleshooting.
This output is the same signal as channel (1) Output.
1
Component Video-Digital/Stereo Audio Over CAT5 Matrix Switcher Series
Thank you for purchasing the SB-5588CT Component-CAT5 Matrix Switcher. You will nd this unit easy to install and highly
reliable but it is essential that you read this manual thoroughly before attempting to use the 8x8 Component Video-Digital/
Stereo Audio Over CAT5 Matrix Switcher.
TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise — without express written permission and consent
© Copyright 2017. All Rights Reserved.
Version 2.2 SEPT 2017
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
