Shop fox W1690 User manual
-29-
Model W1690 (For Machines Mfd. Since 01/21)
PARTS
PARTS
Main
5
6
7
8
10
12V4
13
14
15
16
17V2
18 19
20V2
21
22
23
1V3
30
26
28
29
31
32
33
34
37V2
38
39 40
41
42
43
45
46
47
48
49
50
51
52
53
54
55
56
57
62V2
67
68 69
56
-30-
Model W1690 (For Machines Mfd. Since 01/21)
PARTS
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1V3 X1690001V3 REMOTE CONTROL V3.01.21 34 X1690034 R CAPACITOR 12M 450V
5X1690005 FUSE HOLDER 37V2 X1690037V2 MOTOR 1/3HP 120V 1-PH V2.01.21
6X1690006 FUSE 1-1/8" 5A 250V 38 X1690038 LOCK NUT M5-.8
7X1690007 POWER CORD 18G 3W 5-15P 39 X1690039 FLANGE
8X1690008 STRAIN RELIEF 40 X1690040 SPACER
10 X1690010 PHLP HD SCR M4-.7 X 10 41 X1690041 SLEEVE
12V4 X1690012V4 CONTROL PANEL ASSEMBLY V4.01.21 42 X1690042 FLAT WASHER 6MM
13 X1690013 PHLP HD SCR M3-.45 X 6.5 43 X1690043 CAP SCREW M6-1 X 30
14 X1690014 CONTROL PANEL SPACER 45 X1690045 FLANGE BRACKET
15 X1690015 CONTROL PANEL PHLP HD SCREW 46 X1690046 FLAT WASHER 6MM
16 X1690016 EXT TOOTH WASHER 4MM 47 X1690047 HEX BOLT M6-1 X 10
17V2 X1690017V2 HEX NUT M4-.7 48 X1690048 FAN
18 X1690018 FLAT WASHER 4MM 49 X1690049 KEY 4 X 4 X 20
19 X1690019 LOCK WASHER 4MM 50 X1690050 HEX BOLT M8-1.25 X 12
20V2 X1690020V2 PHLP HD SCR M4-.7 X 6 51 X1690051 FLANGE DISK 6.5 X 44MM
21 X1690021 PC WIRING HARNESS 52 X1690052 CAP SCREW M6-1 X 20 LH
22 X1690022 CONTROL PANEL BOLT M3-0.45 X 6.5 53 X1690053 FAN HOUSING
23 X1690023 EYE BOLT M6-1 X 20 54 X1690054 TAP SCREW M4 X 10
26 X1690026 RIVET NUT M6 X 8 55 X1690055 LOCK WASHER 6MM
28 X1690028 RUBBER FOOT 56 X1690056 PHLP HD SCR M6-1 X 16
29 X1690029 HANDLE 57 X1690057 FLAT WASHER 6MM
30 X1690030 PRIMARY FILTER 5-MICRON 62V2 X1690062V2 HOUSING V2.01.21
31 X1690031 SECONDARY FILTER 1-MICRON 67 X1690067 STEEL MESHING
32 X1690032 FOAM SEAL 1/4" X 1" X 70" 68 X1690068 HEX WRENCH 4MM
33 X1690033 FILTER RETAINING LATCH 69 X1690069 HEX WRENCH 5MM
-31-
Model W1690 (For Machines Mfd. Since 01/21)
PARTS
Labels & Cosmetics
Safety labels warn about machine hazards and how to prevent serious personal injury. The owner
of this machine MUST maintain the original location and readability of all labels on this machine.
If any label is removed or becomes unreadable, REPLACE that label before allowing machine to
be operated again. Contact us at (360) 734-3482 or www.woodstockint.com to order new labels.
MODEL 1690
3-SPEED AIR FILTER
Motor: 1/3 HP, 120V,
Single-Phase, 60 Hz
Full-Load Current Rating: 4.2A
Motor Speed: 770, 980, 1100 CFM
Airflow Performance: 720 CFM
(low), 1115 CFM (medium),
1290 CFM (high)
Filter Type: Pleated/Bag Panels
Primary Filter: 5 Micron (D3210)
Secondary Filter: 1 Micron
(D3209)
Weight: 55 lbs.
Specifications
Date
S/N
Mfd. for Woodstock in Taiwan
WARNING!
To reduce the risk of serious injury while using this
machine:
1. Read and understand owner’s manual before
operating.
2. Always wear approved eye protection and respirator.
3. Only plug power cord into a grounded outlet.
4. Only use this machine to filter wood dust—never use
to filter asbestos, lead paint dust, dust, silica,
biohazards, smoke, toxic fumes, flammable liquids, or
sprayed paint.
5. Do not use this filter near an ignition source, including
sparks from grinding, pilot lights, and open flames.
6. Always disconnect power before servicing or cleaning.
7. Do not expose to rain or use in wet locations.
8. Do not modify machine in any way.
9. Do not use if cord/plug becomes damaged—promptly
repair and protect cord from future damage.
10. Do not use without filters in place.
11. Prevent unauthorized use by children or untrained
users; restrict access or disable machine when
unattended.
4000909
Fluorescent lights may emit
infrared (IR) light, which can
interfere with remote
control. Do not hang filter
near fluorescent lighting.
YOU MUST REMOVE BLOCKS
BEFORE OPERATING.
STYROFOAM BLOCKS
INSTALLED FOR SHIPPING!
Take out filters to locate blocks.
Remove all blocks from
around impeller.
EXPLOSION HAZARD!
Do not expose to
spray paint, paint, or
other flammable
fumes.
READ & UNDERSTAND
MANUAL to avoid serious
injury! If a manual is not
available, DO NOT use
machine! Instead, go to
www.woodstockint.com
or call (360)734-3482.
WARNING!
WARNING
ACCIDENTAL
INJURY HAZARD!
Disconnect power
supply before
adjustments, setup
or maintenance!
60
70
64V2
25
71
72
59
73
58
63
WARNING!
EYE/LUNG INJURY
HAZARD!
Always wear safety
glasses and a
respirator when
using this machine
REF PART # DESCRIPTION REF PART # DESCRIPTION
25 X1690025 ELECTRICITY LABEL 64V2 X1690064V2 ID LABEL V2.01.21
58 X1690058 EYE/LUNG WARNING LABEL 70 X1690070 TOUCH-UP PAINT, OFF-WHITE
59 X1690059 EXPLOSION HAZARD LABEL 71 X1690071 FLUORESCENT BULB NOTICE TAG
60 X1690060 SHOP FOX LABEL 72 X1690072 READ MANUAL LABEL
63 X1690063 DISCONNECT POWER LABEL 73 X1690073 UNPACKING TAG
