Shop fox W1703 User manual

INSTRUCTION MANUAL
MODEL W1703/W1714
10" TABLE SAW
Phone: [phone] • On-Line Technical Support: [email protected]
COPYRIGHT © OCTOBER, 2003 BY WOODSTOCK INTERNATIONAL, INC. REVISED JUNE, 2004.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. Printed in Taiwan

PARTS
-56-
REF PART # DESCRIPTION REF PART # DESCRIPTION
67
48
51
158
124
161
159 162
160
49
143
11
10 156
166
157
153
149
150
148
155
9
7
154
170
4119
115
117 (110V)
118
2
8
3
116
12
14
152
151
147
154
153
120
123
122
121
129
130
165
128 127
126
125
164
1
144
145
146
131
166
166
139
136
156
147
132
156
135
134
156
133
166
137
141
142
138
144
117A (220V)
W1703
OR 173 (220V)
173A (110V)
W1714
Parts

PARTS
-57-
30
27
26
24
25
172
28
22
169
32
23
169
22
21
169
15
6
31
171
18
17
16
29
19

35 37 38
83
82
81
168
39
78
76
77
75
80
79
70 41 69
68
67
66
34
41 64
71
73
74
77
84
72
40
86
85
87
88
89
90
9341 41
41
108
109
103
111
112
114
113
109
105
102
101
99
100
112
114
113
111 163
110
107
104
103106
95 94
97 96
98 92
91
46
62
61
57
58
59
56
60
59
52 53
47
55 54
44
43
42
167
52-1
52-2
52-3
52-4
52-5
33
36
63
45
45-1
PARTS
-58-

PARTS
-59-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1703001 BLADE GUARD LABEL
2 X1703002 ELECTRIC LABEL
3 XPN14 HEX NUT 8-32
4 X1703004 TAP SCREW #10 X 11⁄2"
6 X1703006 SHOP FOX LOGO
7 X1703007 MACHINE LABEL
8 X1703008 WARNING LABEL- UNPLUG
9 X1703009 READ MANUAL LABEL
10 XPN06 HEX NUT 1⁄2-12
11 XPW01 FLAT WASHER 1⁄2"
12 XPW06 FLAT WASHER 1⁄4"
13 XPB05 HEX BOLT 1⁄4-20 X 3⁄4"
15 XPN07 HEX NUT 10-24
16 XPS22 PHLP HD SCR 10-24 X 5⁄8"
17 X1703017 GEAR WASHER
18 X1703018 TAB
19 W1005 DUST HOOD
21 XPB03 HEX BOLT 5⁄16-18 X 1
22 XPN02 HEX NUT 5⁄16-18
23 XPCB01 CARRIAGE BOLT 5⁄16-18 X 5⁄8"
24 XPW06 FLAT WASHER 1⁄4"
25 XPN05 HEX NUT 1⁄4-20
26 XPS19 PHLP HD SCR 1⁄4-20 X 1
27 X1703027 RUBBER FEET
28 X1703028 BOTTOM LONG BRACKET
29 X1703029 TOP LONG BRACKET
30 X1703030 BOTTOM SHORT BRACKET
31 X1703031 TOP SHORT BRACKET
32 X1703032 FOOT STAND
33 XPAW03M ALLEN WRENCH 3MM
34 XPB05 HEX BOLT 1⁄4-20 X 3⁄4"
35 XPAW04M ALLEN WRENCH 4MM
36 XPAW02M ALLEN WRENCH 2MM
37 X1703037 OPEN END WRENCH 12MM
38 X1703038 COMBINATION WRENCH 23MM
39 XPN08 HEX NUT 3⁄8-16
40 X1703040 TIE ROD
41 XPN09 HEX NUT 5⁄8-18
42 X1703042 FIBER WASHER 5⁄16"
43 X1703043 GUARD COVER
44 X1703044 GUARD PLATE
45 XPEC07M E-CLIP 7MM
45-1 X1703045-1 SPACER
46 XPCB09 CARRIAGE BOLT 5⁄16-18 X 13⁄4"
47 X1703047 MOTOR CORD/PLUG SET 14 AWG
47 X1714047 12 AWG MOTOR CORD/PLUG SET
48 X1703048 NYLON CLAMP PG-16
49 XPWRCRD110L POWER CORD 110V, L/PLUG
49 XPWRCRD220L POWER CORD 220V, 12AWG
50 X1703050 SWITCH CORD
51 X1703051 CABLE CLAMP UC-5
52 X1714052 MOTOR 2HP (W1714)
52 X1703052 MOTOR 1.5HP (W1703)
52-1 X1703052-1 FAN COVER
52-2 X1703052-2 CAPACITOR COVER
52-3 X1703052-3 MOTOR FAN
52-4 X1703052-4 WIRING BOX
52-5 XPC400A CAPACITOR 400 MFD, 125 VAC
53 XPK23M KEY 5 X 5 X 25
54 X1703054 V-BELT 3VX-470
55 XPSS11 SETSCREW 1⁄4-20 X 1⁄4"
56 X1703056 MOTOR PULLEY
57 XPN02 HEX NUT 5⁄16-18
58 XPLW01 LOCK WASHER 5⁄16"
59 XPW07 FLAT WASHER 5⁄16"
60 XPB03 HEX BOLT 5⁄16-18 X 1
61 X1703061 MOTOR PLATE
62 X1703062 MOTOR PLATE ROD
63 XPSS05 SETSCREW 5⁄16-18 X 1⁄4"
64 X1703064 MOTOR BRACKET
66 XPB03 HEX BOLT 5⁄16-18 X 1
67 XPLW01 LOCK WASHER 5⁄16"
68 XPW07 FLAT WASHER 5⁄16"
69 X1703069 REAR TRUNNION BRACKET
70 X1703070 REAR TRUNNION
71 XPSS05 SETSCREW 5⁄16-18 X 1⁄4"
72 X1703072 ARBOR PULLEY
73 X1703073 JAM NUT 5⁄8-24
74 XPR23M INT RETAINING RING 40MM
75 X1703075 LOADING SPRING
76 XPK23M KEY 5 X 5 X 25
77 XP6203 BALL BEARING 6203ZZ
78 X1703078 ARBOR
79 XPRP49M ROLL PIN 5 X 25
80 X1703080 ARBOR BRACKET
81 X1703081 BLADE (NOT INCLUDED)
82 X1703082 FLANGE
83 X1703083 ARBOR NUT
84 X1703084 ARBOR BRACKET SHAFT
85 X1703085 SPACER
86 X1703086 FIBER WASHER
87 X1703087 ROLL PIN 3.5 X 20

PARTS
-60-
REF PART # DESCRIPTION REF PART # DESCRIPTION
132 XPLW01 LOCK WASHER 5⁄16"
133 XPB03 HEX BOLT 5⁄16-18 X 1
134A X1703134A BLD GUARD BRACKET ASSY
134 X1703134 BRACKET
135 X1703135 BRACKET
136 X1703136 ROLL PIN 8 X 20
137 X1703137 ANIT-KICK BACK SPRING
138 X1703138 ANTI-KICK BACK
139 X1703139 MOUNT
141 X1703141 SPLITTER
142 X1703142 PIN 6 X 30
143 X1703143 SUPPORTING ARM
144 X1703144 SPEED NUT 1⁄4"
145 X1703145 PIN 6 X 48
146 X1703146 BLADE GUARD
146A X1703146A BLADE GUARD ASSEMBLY
147 XPN02 HEX NUT 5⁄16-18
148 XPW07 FLAT WASHER 5⁄16"
149 XPFH14 FLAT HD SCR 5⁄16-18 X 3⁄4"
150 X1703150 BEARING BRACKET
151 XPB90 HEX BOLT 7⁄16-14 X 11⁄4"
152 XPLW05 LOCK WASHER 7⁄16"
153 X1703153 EXT WING - SHEET METAL
154 X1714154 EXT WING - CAST IRON
155 X1703155 SCALE
156 XPW07 FLAT WASHER 5⁄16"
157 X1703157 CABINET
158 X1703158 TABLE
159 XPSS04 SETSCREW 1⁄4-20 X 5⁄16"
160 X1703160 BUMPER
161 X1703161 DADO TABLE INSERT
162 X1703162 TABLE INSERT
163 X1703163 POINTER
164 XPFH09 FLAT HD SCR 1⁄4-20 X 5⁄16"
165 X1703165 MITER GAUGE BODY
165A X1703165A MITER GAUGE ASSEMBLY
166 XPB32 HEX BOLT 5⁄16-18 X 5⁄8"
167 XPWN03 WING NUT 5⁄16-18
168 X1703168 THRD SHAFT 3⁄8-16 X 27⁄8"
169 XPW07 FLAT WASHER 5⁄16"
170 X1703170 WARN LABEL- SAFETY GLASSES
171 X1703171 STAND STRIPE STICKERS
172 X1703172 STAND STRIPE STICKERS
173 X1714173 MAGNETIC SWITCH ASSY 220V
173A X1714173A MAGNETIC SWITCH ASSY 110V
88 X1703088 ELEVATING SHAFT
89 X1703089 ECCENTRIC
90 X1703090 WAVE WASHER
91 XPB32 HEX BOLT 5⁄16-18 X 5⁄8"
92 XPRP49M ROLL PIN 5 X 25
93 X1703093 FRONT TRUNNION
94 XPN05 HEX NUT 1⁄4-20
95 XPSS16 SETSCREW 1⁄4-20 X 11⁄2"
96 XPW06 FLAT WASHER 1⁄4"
97 XPB05 HEX BOLT 1⁄4-20 X 3⁄4"
98 X1703098 STOP BLOCK
99 XPLW01 LOCK WASHER 5⁄16"
100 XPW07 FLAT WASHER 5⁄16"
101 XPB12 HEX BOLT 5⁄16-18 X 11⁄4"
102 X1703102 FRONT BRACKET
103 X1703103 FIBER WASHER
104 X1703104 ROLL PIN 3.5 X 20
105 X1703105 HEX NUT 9⁄16-20
106 X1703106 ECCENTRIC
107 X1703107 TILT SHAFT
108 XPSS11 SETSCREW 1⁄4-20 X 1⁄4"
109 X1703109 SET COLLAR
110 XPSS11 SETSCREW 1⁄4-20 X 1⁄4"
111 XPW02 FLAT WASHER 3⁄8"
112 X1703112 HAND WHEEL HANDLE
113 X1703113 HAND WHEEL
114 XPSW03-1 KNOB
115 XPN07 HEX NUT 10-24
116 X1703116 SWITCH FIXING PLATE
117 X1703117 MAGNETIC SWITCH ASSY 110V
117A X1703117A MAGNETIC SWITCH ASSY 220V
118 XPS10 PHLP HD SCR 10-24 X 11⁄2"
119 X1703119 START/STOP SWITCH ASSY
120 XPSS11 SETSCREW 1⁄4"-20 X 1⁄4"
121 XPRP61M ROLL PIN 3 X 12
122 X1703122 POINTER
123 X1703123 STOP LINK
124 XPSS31 SETSCREW 10-24 X 5⁄8"
125 X1703125 MITER BAR
126 X1703126 SLIDING BLOCK
127 XPS21 PHLP HD SCR 8-32 X 3⁄4"
128 XPN14 HEX NUT 8-32
129 X1703129 HAND KNOB
130 XPW07 FLAT WASHER 5⁄16"
131 X1703131 GUARD SUPPORT SHAFT
