SHORE TEL SHOREPHONE POE User manual

S
SH HO OR RE EP PH HO ON NE E G GI IG G P PO OE E A AD DA AP PT TE ER R
U
Us se er r G Gu ui id de e
Notice
It is ShoreTel's policy to improve its products as new
technology, components, software, and firmware become
available. ShoreTel, therefore, reserves the right to change
specifications without prior notice.
Technical Support
If you encounter problems when installing or using this
product, please consult the ShoreTel website at:
http://support.shoretel.com
Recycling and Disposal
Disposal instructions for old products. The WEEE
(Waste Electrical and Electronic Equipment)
national environmental initiatives has been put
in place to ensure that products are recycled
using best available treatment, and recovery
and recycling techniques to ensure human
health and high environmental protection. Your
product is designed and manufactured with
high quality materials and components which
can be recycled and reused. Do not dispose of
your old product in your general household
waste bin. Informyourself about the local
separate collection system for electrical and
electronic products marked by this symbol:
Use one of the following disposal options :
1. Dispose of the complete product (including
its cables, plugs and accessories) in the
designated WEEE collection facilities.
2. If you purchase a replacement product,
return your older product (including all
components) back to the retailer. The retailer
should accept it as required by the national
WEEE legislation.

2011 ShoreTel Inc.
Ordering information:
•Product Name: SHOREPHONE GIG POE ADAPTER
•Part Number: 300-1023-02
Document P/N: PD-3501G-AC-STL_UG Rev. A01
Safety Information
Important Safety Information
♦The SHOREPHONE POE should be connected to PoE
networks only, without routing to the outside plant.
♦Only qualified personnel can install or remove the
SHOREPHONE POE.
♦AC Power Cord Set:
The power cord must have regulatory agency approval for
the specific country in which it is used (for example UL,
CSA, VDE, etc.).
The power cord must be a three-conductor type (two
current carrying conductors; one ground conductor)
terminated on one end by an IEC 60320 appliance coupler
(for connection to the SHOREPHONE POE), and on the
other end by a plug containing a ground (earthing) contact.
The power cord must be rated for a minimum of 250 VAC
RMS operation, with a minimum rated current capacity of
5 amps (or a minimum wire gauge of 18 AWG (0.75 mm2).
: A SHOREPHONE POE installed in Australia requires
power cords with a minimum wire gauge of 16 AWG (1.0 mm2).
: The SHOREPHONE POE "DATA IN" and "DATA &
POWER OUT" ports are shielded RJ45 data sockets. They
cannot
be used as Plain Old Telephone Service (POTS)
telephone sockets. Only RJ45 data connectors can be connected
to these sockets.
♦The AC wall socket-outlet must be near the
SHOREPHONE POE and easily accessible. You can
remove AC power from the SHOREPHONE POE by
disconnecting the AC power cord from either the wall
socket-outlet or the SHOREPHONE POE appliance
coupler.
♦The SHOREPHONE POE DATA IN and DATA &
POWER OUT interfaces are qualified as Safety Extra-
Low Voltage (SELV) circuits according to IEC 60950-1.
These interfaces can only be connected to SELV
interfaces on other equipment.
WARNINGS!
♦The SHOREPHONE POE should only be connected to
the IP device with which it was bought. Using the
SHOREPHONE POE with other IP devices can cause
damage to the IP device.
♦Read the installation instructions before connecting the
SHOREPHONE POE to its power source.
♦Follow basic electricity safety measures whenever
connecting the SHOREPHONE POE to its power
source.
♦A voltage mismatch can cause equipment damage and
may pose a fire hazard. If the voltage indicated on the
label is different from the power outlet voltage, do not
connect the SHOREPHONE POE to this power outlet.
♦The unit can be used only in Restricted Access
Locations.


Troubleshooting
Symptom
Corrective Steps
The POE
does not
power up
1. Verify that a reliable power cord
is used.
2. Verify that the voltage at the
power inlet is between 100 and 240
VAC.
3. Remove and re-apply power to
the device and check the indicators
during power up sequence.
The PD
does not
operate
1. Verify that the SHOREPHONE
POE detects a PD.
2. Verify that the PD is designed for
PoE operation.
3. Verify that you are using a
standard Category 5/5e/6, straight-
wired cable, with four pairs.
4. If an external power splitter is in
use, replace it with a known-good
splitter.
5. Ensure input Ethernet cable is
connected to the DATA IN port.
6. Verify that the PD is connected
to the Data & Power port.
7. Try to reconnect the same PD
into a different SHOREPHONE
POE. If it works, there is probably a
faulty port or RJ45 connection.
8. Verify that there is no short over
any of the twisted pair cables or
over the RJ45 connectors.
The end
device
operates,
but there
is no data
link
1. Verify that the port indicator on
the front panel is continuously lit.
2. If an external power splitter is in
use, replace it with a known-good
splitter.
3. Verify that for this link, you are
using standard UTP/FTP Category 5
straight (non-crossover) cabling,
with all four pairs.
4. Verify that the Ethernet cable
length is less than 100 meters from
the Ethernet source to the
load/remote terminal.
5. Try to reconnect the same PD
into a different SHOREPHONE
POE. If it works, there is probably a
faulty port or RJ45 connection.
Port Connectivity
Indication
Ethernet
Cat .5 Cable
Terminal
Figure 1: Connecting the SHOREPHONE POE
Indicators
Port LED
Indicated Behavior
Yellow On
Power is on (power is active)
Green On
A remote terminal is connected
Green Blinking
Overload state or short-circuit
Specifications
Environmental Specifications
Mode
Temperature
Humidity
Operating
0 to 40°C
32 to 104°F
10 to 90%; (no
condensation
allowed)
Storage
-20 to 70°C
-4 to 158°F
10 to 90%; (no
condensation
allowed)
Electrical Specifications
Input Voltage
100-240 VAC (50/60 Hz)
Maximal Input Current
0.5 Ampere
Available Output Power
(max.)
16.8 Watts
Nominal Output Voltage
48VDC
Ethernet Interface
Input (DATA IN): Ethernet
10/100/1000Base-T
RJ45 female socket
Output (DATA & POWER
OUT): Ethernet
10/100/1000Base-T, plus
48VDC
RJ45 female socket, with
DC voltage on wire pairs,
4 - 5 (+) & 7 - 8 (-).
Functions and Features
The SHOREPHONE POE is a Single Port Midspan that offers a
compact and cost effective power solution for IP phones, WLAN
access points, network cameras and other IP terminal
installations.
The SHOREPHONE POE converts AC power to 48VDC power is
then provided over the Ethernet cable.
The SHOREPHONE POE supports up to
10/100/1000Mbps pass through data rates.
The SHOREPHONE POE can be powered via universal
AC input and can provide up to 20W.
SHOREPHONE POE EMC Compliance:
♦FCC Part 15 class B and EN55022 class B
♦EN55024
♦VCCI
SHOREPHONE POE Safety Compliance:
♦UL/cUL per 60950-1
♦GS mark
Preliminary Steps
♦Ensure that AC power is applied to the SHOREPHONE
POE, using an operational AC cable with an appropriate
ground connection.
♦Ensure that output Ethernet cable is connected to the
DATA & POWER OUT port.
♦Verify that power ready Ethernet compatible device is
connected.
WARNING
Do not use cross over cable between the SHOREPHONE
POE output port and the load device
Installation
The SHOREPHONE POE can be placed on a desktop.
: Before placing the SHOREPHONE POE:
♦Do not to cover SHOREPHONE POE or block the airflow to
the PoE with any foreign objects. Keep the SHOREPHONE
POE away from excessive heat and humidity and free from
vibration and dust.
♦Ensure that the cable length from Ethernet network source
to the terminal does not exceed 100 meters (330 feet). The
PoE is not a repeater and does not amplify the Ethernet
data signal.
♦Use a splitter if desired; ensure that the splitter is connected
close to the terminal and not on the SHOREPHONE POE!
♦No “on-off” switch exists; simply plug the SHOREPHONE
POE into an AC power source.
Installing the Unit
Refer to Figure 1.
1. Connect the SHOREPHONE POE to an AC outlet (100 -
240VAC), using a standard power cord.
2. Connect the DATA IN jack (input) to the remote Ethernet
network switch's Patch panel and the DATA & POWER OUT jack
(output) to the terminal.
